3D Printing in Medicine and Biomedical Engineering

A topical collection in Materials (ISSN 1996-1944). This collection belongs to the section "Biomaterials".

Viewed by 98989

Editor

Dr. Filip Górski

E-Mail Website
Collection Editor
Faculty of Mechanical Engineering and Management, Poznan University of Technology, 60-965 Poznań, Poland
Interests: CAD/CAM/CAE systems; reverse engineering; 3D printing; virtual reality
Special Issues, Collections and Topics in MDPI journals

Topical Collection Information

Dear Colleagues,

Medicine and biomedical engineering are today among the most vital applications of 3D printing, also known as additive manufacturing (AM). Both doctors and patients, as well as scientists can benefit from recent advancements in this technology and its increasing availability at acceptable cost. Additive manufacturing of polymers, metals, and composites is invaluable to making customized implants, orthopedic and prosthetic supplies, pre- and mid-surgery supplies, and a number of other medical and biomedical devices, as well as training and educational models for students. Bioprinting allows the building of complex structures using living cells of various types.

However, many aspects of 3D printing in medicine and biomedical engineering remain unknown and need thorough studies in order to make progress, especially considering the whole process of making medical products—starting from obtaining patients’ data via medical imaging through data processing, design of products, selecting or often designing new materials, preparing and organizing manufacturing processes, and tuning them to obtain products fulfilling often strict requirements of strength, accuracy, surface quality, and chemical and biological reactivity. Therefore, this Topical Collection is dedicated to research and review papers tackling the problems of using additive technologies for medical and biomedical engineering applications.

Possible topics for this Topical Collection include, but are not limited to, the following:

  • 3D printing for making customized implants;
  • 3D-printed orthopedic and prosthetic supplies and studies on them;
  • 3D-printed pre- and mid-surgery supplies;
  • 3D-printed medical devices;
  • Bioprinting of tissues and organs;
  • Preparing 3D printing processes for medicine—studies on the influence of process parameters on the properties of obtained products;
  • New materials for 3D printing in medicine and biomedical engineering—design and studies of mechanical, chemical, and biological properties;
  • Medical imaging—MRI, CT, ultrasound, optical and laser scanning, and data processing for the preparation of 3D printing processes; and
  • Numerical simulation of 3D-printed structures used in medicine.

Dr. Filip Górski
Collection Editor

Manuscript Submission Information

Manuscripts should be submitted online at www.mdpi.com by registering and logging in to this website. Once you are registered, click here to go to the submission form. Manuscripts can be submitted until the deadline. All submissions that pass pre-check are peer-reviewed. Accepted papers will be published continuously in the journal (as soon as accepted) and will be listed together on the collection website. Research articles, review articles as well as short communications are invited. For planned papers, a title and short abstract (about 100 words) can be sent to the Editorial Office for announcement on this website.

Submitted manuscripts should not have been published previously, nor be under consideration for publication elsewhere (except conference proceedings papers). All manuscripts are thoroughly refereed through a single-blind peer-review process. A guide for authors and other relevant information for submission of manuscripts is available on the Instructions for Authors page. Materials is an international peer-reviewed open access semimonthly journal published by MDPI.

Please visit the Instructions for Authors page before submitting a manuscript. The Article Processing Charge (APC) for publication in this open access journal is 2600 CHF (Swiss Francs). Submitted papers should be well formatted and use good English. Authors may use MDPI's English editing service prior to publication or during author revisions.

Published Papers (32 papers)
