Optics, Volume 3, Issue 2 (June 2022) – 7 articles

In many optical engineering applications, a spherical cap shaped optical element is widely used such as concave or convex mirrors in reflective optics. Such an element can also tilt around the vertex which corresponds to an off-axis optical design. The optical backscattering of such an optical element sometimes could be important. For example, in the space-based gravitational wave detection, the backscattering of such an element could be superimposed with the local oscillator and limits the sensitivity of the spacecraft. The scattered contributions depend on the scattering property of the mirror surfaces and the geometrical arrangement including the radius of curvature, the tilt and the interval between the scattering source and detector plane. Based on random estimation method, this paper starts from the radiometry, combines these variables and calculates the theoretical amount of back scattered light for both diffuse and superpolished surfaces. The results are compared with analytical and ray tracing solution. The conclusions can be used to further improve the optical design of the telescope or extended to other cases where the backscattered light should be controlled. Full article

Temperature is one of the most relevant physical quantities that affects almost all processes in nature. However, the realization of accurate temperature standards using current temperature references, like the triple point of water, is difficult due to the requirements on material purity and stability of the environment. In addition, in harsh environments, current temperature sensors with electrical readout, like platinum resistors, are difficult to implement, urging the development of optical temperature sensors. In 2018, the European consortium Photoquant, consisting of metrological institutes and academic partners, started investigating new temperature standards for self-calibrated, embedded optomechanical sensor applications, as well as optimised high resolution and high reliability photonic sensors, to measure temperature at the nano and meso-scales and as a possible replacement for the standard platinum resistant thermometers. This article presents an overview of the results obtained with sensor prototypes that exploit photonic and optomechanical techniques for sensing temperatures over a large temperature range (5 K to 300 K). Different concepts are demonstrated, including ring resonators, ladder-like resonators and suspended membrane optomechanical thermometers, highlighting initial performance and challenges, like self-heating that need to be overcome to realize photonic and optomechanical thermometry applications. Full article

With the development of rail transit in terms of speed and carrying capacity, train safety problems caused by wheel tread defects and wear have become more prominent. The wheel is an important part of the train, and the wear and defects of the wheel tread are directly related to the safety of the train; therefore, wheel tread testing is a key element of train testing. In phase measuring profilometry (PMP), the virtual sine grating generated by the computer is projected onto the measured wheel tread by a digital projector, and then a camera is used to obtain the modulated deformed grating on the surface of the wheel tread. Next, the wrapped phase is obtained by the improved Stoilov algorithm, and the unwrapped phase is obtained by the phase unwrapped algorithm. Finally, the three-dimensional (3D) profile of the wheel tread is reconstructed. This paper presents an improved Stoilov algorithm based on probability and statistics. Supposing that the probability of real data was the highest, we chose the cosine square matrix value of the phase shift for processing. After ruling out the singular points of large error, we obtained the closest value to the true phase shift using the method of probability and statistics. The experimental results show that this method can effectively restrain the singular phenomenon, and the 3D profile of wheel tread can be reconstructed successfully. Full article

Correlation plenoptic imaging (CPI) is an optical imaging technique based on intensity correlation measurement, which enables detecting, within fundamental physical limits, both the spatial distribution and the direction of light in a scene. This provides the possibility to perform tasks such as three-dimensional reconstruction and refocusing of different planes. Compared with standard plenoptic imaging devices, based on direct intensity measurement, CPI overcomes the problem of the strong trade-off between spatial and directional resolution. Here, we study the resolution limit in a recent development of the technique, called correlation plenoptic imaging between arbitrary planes (CPI-AP). The analysis, based on Gaussian test objects, highlights the main properties of the technique, as compared with standard imaging, and provides an analytical guideline to identify the limits at which an object can be considered resolved. Full article

Shearography is a coherent optical technique that allows the identification of the first derivative of deformation in the shearing direction. Due to direct measuring strain information, shearography is suited for non-destructive testing and evaluation (NDT/NDE). However, if there is a small defect parallel to the shearing direction, the first derivative of deformation in the direction has no noticeable change, and the defect is not visible. Therefore, the development of a shearography system with dual-directional simultaneous measurement of the first derivatives of deformation both in x- and y-directions is highly demanded in the field of NDT/NDE. It is suited to inspect complicated defects, such as long and narrow slots, microcracks, etc. This paper presents a review of shearography for different dual-directional systems developed in the last two decades. After a brief overview of shearography, the paper will display two dual-directional shearographic techniques—temporal phase-shift (TPS) and spatial phase-shift (SPS) methods. TPS dual-shearing systems are suited for static measurements, while the SPS dual-shearing systems are useful for dynamic measurements. The basic theories, optical layouts, and comparisons are presented. The advantages and disadvantages of practical applications are discussed. Full article

Incorporating active components in photonic structures with a topological configuration has been shown to achieve lasing at topological edge states. Here, we report an electrically tunable topological edge-state laser in a one-dimensional complex Su–Schrieffer–Heeger chain. The proposed design is realized in an electrically injected Fabry–Perot (FP) laser chain. The lasing in topologically induced edge states is experimentally observed and a selective enhancement is realized by introducing a topological defect in the center. This work presents a versatile platform to investigate novel concepts such as the topological mode for mainstream photonic applications. Full article

In this study, we demonstrate that drugs in plastic packaging can be identified without being opened using attenuated total reflection terahertz time domain spectroscopy. In this system, the terahertz wave undergoes total internal reflection at the interface between prism and sample, producing an evanescent wave at the interface. The penetration depth of the evanescent waves is larger than the thickness of typical plastic packaging in the sub-terahertz frequency region; therefore, it becomes possible to detect the sample without opening the package. Here, we show that some saccharides samples such as lactose in plastic packaging can be identified using its spectral fingerprint by placing the packaged lactose on the prism. This method has the potential to be used in the non-destructive testing and analysis of a wide variety of samples, such as medicine sachets, to reduce medication dispensing errors in pharmacies. Full article
