Appl. Mech., Volume 3, Issue 1 (March 2022) – 20 articles

Cover Story (view full-size image): The design of flexible and efficient propulsion systems is crucial for the development of future low-emission aircraft. Applying shape-adaptive blades in jet engine compressors presents a high potential for increasing efficiency, since such blades are capable of adapting to different flight phases and aerodynamic conditions. Such blade morphing behavior can be achieved through structurally integrated actuation. Since no morphing aircraft engine blades exist to date, a multidisciplinary method for their design is introduced. This new method brings together existing structural and aerodynamic design methodologies, couples them already at the earliest stages of the design process, and addresses the challenges of such a tightly coupled multidisciplinary design approach. View this paper
  • Issues are regarded as officially published after their release is announced to the table of contents alert mailing list.
  • You may sign up for e-mail alerts to receive table of contents of newly released issues.
  • PDF is the official format for papers published in both, html and pdf forms. To view the papers in pdf format, click on the "PDF Full-text" link, and use the free Adobe Reader to open them.
Order results
Result details
Select all
Export citation of selected articles as:
26 pages, 13813 KiB
Article
Numerical and Experimental Studies of Free-Fall Drop Impact Tests Using Strain Gauge, Piezoceramic, and Fiber Optic Sensors
by Ignazio Dimino, Gianluca Diodati, Francesco Di Caprio, Monica Ciminello, Aniello Menichino, Michele Inverno, Marika Belardo and Luigi Di Palma
Appl. Mech. 2022, 3(1), 313-338; https://doi.org/10.3390/applmech3010020 - 18 Mar 2022
Cited by 1 | Viewed by 2754
Abstract
The present work is framed inside a broader activity aimed at improving the accuracy of numerical models in predicting the crashworthiness behavior of flexible fuel tanks. This paper describes a comprehensive experimental and numerical study aimed at estimating the impact force of a [...] Read more.
The present work is framed inside a broader activity aimed at improving the accuracy of numerical models in predicting the crashworthiness behavior of flexible fuel tanks. This paper describes a comprehensive experimental and numerical study aimed at estimating the impact force of a test article, consisting of a soft nylon bag filled with water, subjected to crash impact tests. In order to understand and improve response predictions, the test article drops freely from different heights, and then strikes onto a rigid plate which is instrumented with different types of sensors. Strain gauges, piezoceramic sensors, and fiber optics are used to measure the strain induced by the impact force during the experiments. To tune the test matrix and the measurement chain parameters, numerical computations are carried out to predict the dynamics of drop impact through FE explicit analyses. Through analysis and comparison with experimental results, a relationship between strain and impact energy correlated with the drop height is established, and the overall accuracy of the entire measurement chain is assessed to determine the effectiveness of such a methodology in a full-scale test on a flexible fuel tank structure. Full article
Show Figures

Figure 1

17 pages, 11714 KiB
Article
A 3D-Printed Honeycomb Cell Geometry Design with Enhanced Energy Absorption under Axial and Lateral Quasi-Static Compression Loads
by Marco Menegozzo, Andrés Cecchini, Frederick A. Just-Agosto, David Serrano Acevedo, Orlando J. Flores Velez, Isaac Acevedo-Figueroa and Jancary De Jesús Ruiz
Appl. Mech. 2022, 3(1), 296-312; https://doi.org/10.3390/applmech3010019 - 14 Mar 2022
Cited by 5 | Viewed by 3087
Abstract
This work presents an innovative honeycomb cell geometry design with enhanced in-plane energy absorption under quasi-static lateral loads. Numerical and experimental compression tests results under axial and lateral loads are analyzed. The proposed cell geometry was designed to overcome the limitations posed by [...] Read more.
This work presents an innovative honeycomb cell geometry design with enhanced in-plane energy absorption under quasi-static lateral loads. Numerical and experimental compression tests results under axial and lateral loads are analyzed. The proposed cell geometry was designed to overcome the limitations posed by standard hexagonal honeycombs, which show relatively low stiffness and energy absorption under loads that have a significant lateral component. To achieve this, the new cell geometry was designed with internal diagonal walls to support the external walls, increasing its stiffness and impact energy absorption in comparison with the hexagonal cell. 3D-printed unit-cell specimens made from ABS thermoplastic material were subjected to experimental quasi-static compression tests, in both lateral and axial directions. Energy absorption was compared to that of the standard hexagonal cell, with the same mass and height. Finite element models were developed and validated using experimental data. Results show that the innovative geometry absorbs approximately 15% more energy under lateral compression, while maintaining the same level of energy absorption of the standard hexagonal cell in the axial direction. The present study demonstrates that the proposed cell geometry has the potential to substitute the standard hexagonal honeycomb in applications where significant lateral loads are present. Full article
(This article belongs to the Special Issue Mechanical Design Technologies for Beam, Plate and Shell Structures)
Show Figures

Figure 1

37 pages, 9075 KiB
Article
On Scaled Normal Stresses in Multiaxial Fatigue and Their Exemplary Application to Ductile Cast Iron
by Michael Wächter, Alexander Linn, Ralf Wuthenow, Alfons Esderts, Christian Gaier, Jan Kraft, Carl Fällgren and Michael Vormwald
Appl. Mech. 2022, 3(1), 259-295; https://doi.org/10.3390/applmech3010018 - 08 Mar 2022
Cited by 6 | Viewed by 3187
Abstract
The approaches used to calculate the fatigue life of components must inevitably consider multiaxial stresses. Compared to proportional loading, the calculation of nonproportional loading is particularly challenging, especially since different materials exhibit the effects of nonproportional hardening and shifts in fatigue life. In [...] Read more.
The approaches used to calculate the fatigue life of components must inevitably consider multiaxial stresses. Compared to proportional loading, the calculation of nonproportional loading is particularly challenging, especially since different materials exhibit the effects of nonproportional hardening and shifts in fatigue life. In this paper, the critical plane approach of scaled normal stresses, first proposed by Gaier and Dannbauer and later published in a modified version by Riess et al., is investigated in detail. It is shown that, on the one hand, compatibilities exist or can be established with known proportional strength criteria that can account for the varying ductility of different materials. Furthermore, it is demonstrated that the scaled normal stress approach can be formulated in such a way that different strength criteria can be used therein. As an example, the generally formulated approach for scaled normal stresses is applied to test results from ductile cast iron material EN-GJS-500-14. Different correction factors accounting for nonproportional loading are investigated. Through appropriate parameterization of one of the studied corrections, proportional and nonproportional test results were observed to fall within one common scatter band. Full article
Show Figures

Figure 1

15 pages, 1850 KiB
Article
Operational Modal Analysis of an Axial Compressor Rotor and Casing System for the Online Identification of a Digital Twin
by Mona Amer, Joerg Wallaschek and Joerg R. Seume
Appl. Mech. 2022, 3(1), 244-258; https://doi.org/10.3390/applmech3010017 - 07 Mar 2022
Cited by 4 | Viewed by 2865
Abstract
Modal parameter identification can be a valuable tool in mechanical engineering to predict vibrational behaviour and avoid machine damage during operation. Operational modal analysis is an output-only identification tool motivated by the structural identification of civil engineering structures, which are excited by ambient [...] Read more.
Modal parameter identification can be a valuable tool in mechanical engineering to predict vibrational behaviour and avoid machine damage during operation. Operational modal analysis is an output-only identification tool motivated by the structural identification of civil engineering structures, which are excited by ambient conditions. This technique is increasingly applied in mechanical engineering in order to characterise the system behaviour during operation as modal parameters can vary under operating conditions. The following study investigates the application of operational modal analysis on an axial compressor under operating conditions. Since the modal parameters of the system change depending on the life history and during the operation of the system, a corresponding data analysis might allow us to identify the present status of the system. Eigenfrequencies and eigenvectors are studied for the use of structural health monitoring approaches. According to the analysis, eigenfrequencies represent robust parameters for the studied purpose. Eigenvectors are sensitive to damages but need further investigation, especially for rotating machinery. This study will help the user to set up a virtual model, which describes the system behaviour for different boundary conditions. This in turn, will provide an accurate prediction of the vibrational behaviour in order to assure a safe operation. Full article
Show Figures

Figure 1

17 pages, 8971 KiB
Article
Optimal Modeling of an Elevator Chassis under Crash Scenario Based on Characterization and Validation of the Hyperelastic Material of Its Shock Absorber System
by Dimitrios Giagopoulos, Alexandros Arailopoulos and Iraklis Chatziparasidis
Appl. Mech. 2022, 3(1), 227-243; https://doi.org/10.3390/applmech3010016 - 05 Mar 2022
Viewed by 1915
Abstract
A wide variety of hyperelastic rubber-like materials, exhibiting strong nonlinear stress–strain relations under large deformations, is applied in various industrial mechanical systems and engineering applications involving shock and vibration absorbers. An optimal design procedure of an elevator chassis crashing on a hyperelastic shock [...] Read more.
A wide variety of hyperelastic rubber-like materials, exhibiting strong nonlinear stress–strain relations under large deformations, is applied in various industrial mechanical systems and engineering applications involving shock and vibration absorbers. An optimal design procedure of an elevator chassis crashing on a hyperelastic shock absorber in a fail scenario, applicable in large-scale mechanical systems or industrial structures of high importance under strong nonlinear dynamic excitation, is presented in this work. For the characterization of the hyperelastic absorber, a Mooney–Rivlin material model was adopted, and a series of in-lab compression quasi-static tests were conducted. Applying a fully parallelizable state-of-the-art stochastic model updating methodology, coupled with robust, accurate and efficient Finite Element Analysis (FEA) software, the hyperelastic behavior of the shock absorber was validated under uniaxial large deformation, in order to tune all material parameters and develop a high-fidelity FE model of the shock absorber system. Next, a series of in situ full-scale experimental trials were carried out using a test-case elevator chassis, representing the crash scenario on the buffer absorber system, after a controlled free fall. A limited number of sensors, i.e., triaxial accelerometers and strain gauges, were placed at characteristic points of the real structure of the elevator chassis recording experimental data. A discrete Finite Element (FE) model of the experimentally tested arrangement involving the elevator chassis and updated buffer absorber system along with all boundary conditions was developed and used in explicit nonlinear analysis of the crash scenario. Steel material properties and the characterized updated Mooney–Rivlin material model were assigned to the elevator chassis and buffer, respectively. A direct comparison of the numerical and experimental data validated the reliability and accuracy of the methodology applied, whereas results of the analysis were used in order to redesign and optimize a new-design elevator chassis, achieving minimum design stresses and satisfying serviceability limit states. Full article
(This article belongs to the Special Issue Mechanical Design Technologies for Beam, Plate and Shell Structures)
Show Figures

Figure 1

17 pages, 20846 KiB
Article
On the Free Vibration and the Buckling Analysis of Laminated Composite Beams Subjected to Axial Force and End Moment: A Dynamic Finite Element Analysis
by MirTahmaseb Kashani and Seyed M. Hashemi
Appl. Mech. 2022, 3(1), 210-226; https://doi.org/10.3390/applmech3010015 - 23 Feb 2022
Cited by 2 | Viewed by 2061
Abstract
This work presents the bending–torsion coupled free vibration analysis of prestressed, layered composite beams subjected to axial force and end moment using the traditional finite element method (FEM) and dynamic finite element (DFE) techniques. Current trends in the literature, in terms of different [...] Read more.
This work presents the bending–torsion coupled free vibration analysis of prestressed, layered composite beams subjected to axial force and end moment using the traditional finite element method (FEM) and dynamic finite element (DFE) techniques. Current trends in the literature, in terms of different types of modeling techniques and constraints, were briefly examined. The Galerkin-type weighted residual method was applied to convert the coupled differential equations of motion into a discrete problem using a polynomial interpolation function in the finite element method. In the dynamic finite element method, trigonometric shape functions were implemented to describe the equations in terms of nodal displacements. The eigenvalue problem resulting from the discretization along the length of the beam was solved in order to determine the system’s natural frequencies and modes. The results, showing the effects of axial load, end moment, and combined loading on natural frequencies, are discussed and are followed by some concluding remarks. Full article
(This article belongs to the Special Issue Mechanical Design Technologies for Beam, Plate and Shell Structures)
Show Figures

Figure 1

28 pages, 8527 KiB
Article
A Coupling Method for the Design of Shape-Adaptive Compressor Blades
by Zhuzhell Montano, Marcel Seidler, Johannes Riemenschneider and Jens Friedrichs
Appl. Mech. 2022, 3(1), 182-209; https://doi.org/10.3390/applmech3010014 - 11 Feb 2022
Cited by 3 | Viewed by 2557
Abstract
The design of flexible and efficient aircraft engines and propulsion systems plays a crucial role in the development of future low-emission aircraft. Implementing shape-variable blades to compressor front stage rotors presents a high potential for increasing efficiency, since through adaptation, the blades are [...] Read more.
The design of flexible and efficient aircraft engines and propulsion systems plays a crucial role in the development of future low-emission aircraft. Implementing shape-variable blades to compressor front stage rotors presents a high potential for increasing efficiency, since through adaptation, the blades are capable of optimizing their shape for different flight phases and aerodynamic conditions. Modifying the shape of the blades by using structurally integrated actuators allows this adaptation and therefore helps enhance their aerodynamic behavior for different flight regimes. Since up to now no morphing compressor or any other aircraft engine blades exist, here a multidisciplinary method for their design is introduced. This new method brings together existing structural and aerodynamic design methodologies, couples them together already at the earliest stages of the design process, while addressing the challenges that arise with a tightly coupled multidisciplinary design. As a result, first performance gain evaluations applied to the NASA 67 rotor test case are presented, showing the potential of morphing compressor blades and the potential of the introduced design methodology. Full article
Show Figures

Figure 1

8 pages, 1231 KiB
Article
Measuring Foot Progression Angle during Walking Using Force-Plate Data
by Teddy Caderby, Jérémie Begue, Georges Dalleau and Nicolas Peyrot
Appl. Mech. 2022, 3(1), 174-181; https://doi.org/10.3390/applmech3010013 - 11 Feb 2022
Cited by 4 | Viewed by 6165
Abstract
Foot progression angle (FPA) is a gait-related clinical measurement commonly used for assessing the rotational profile of the lower extremity. This study examined the accuracy of two methods based on force-plate data for estimating FPA during walking by comparing them with a reference [...] Read more.
Foot progression angle (FPA) is a gait-related clinical measurement commonly used for assessing the rotational profile of the lower extremity. This study examined the accuracy of two methods based on force-plate data for estimating FPA during walking by comparing them with a reference method using a motion capture system. Ten healthy adults performed a series of overground walking trials at three different speeds: slow, preferred and fast. FPA was estimated from two methods using data on center of pressure—one method previously reported in the literature, and a novel method proposed here. The FPA estimated by each of these two force-plate methods were compared with the reference FPA determined from kinematic data. Results showed that the novel force-plate method was more accurate and precise when measuring the FPA in the three speed conditions than the force-plate method previously reported in the literature. The mean absolute error obtained with this novel method was 3.3° ± 2.1° at slow speed, 2.0° ± 1.2° at preferred speed and 2.0° ± 1.2° at fast speed, with no significant effect of gait speed (p > 0.05). These findings suggest that the novel force-plate method proposed here is valid for determining FPA during walking at various speeds. In the absence of kinematic data, this method constitutes an attractive alternative for measuring FPA. Full article
Show Figures

Figure 1

14 pages, 2265 KiB
Review
Sensory Utilizable Design Elements: Classifications, Applications and Challenges
by André Harder, Maximilian Hausmann, Benjamin Kraus, Eckhard Kirchner and Alexander Hasse
Appl. Mech. 2022, 3(1), 160-173; https://doi.org/10.3390/applmech3010012 - 04 Feb 2022
Cited by 6 | Viewed by 2192
Abstract
The sensory acquisition of in situ data in technical systems is one of the key requirements set by ongoing digitalization. The sensory utilization of mechanical design elements is a step towards the accomplishment of this requirement. To set a common ground for further [...] Read more.
The sensory acquisition of in situ data in technical systems is one of the key requirements set by ongoing digitalization. The sensory utilization of mechanical design elements is a step towards the accomplishment of this requirement. To set a common ground for further research in the context of sensory utilizable design elements, this paper reviews the current state of research in this topic. First, the aim, potentials and classification of sensory utilizable design elements are introduced. Next, examples of sensory utilizable design elements are presented. These examples are used to demonstrate the technical and methodical challenges that have to be addressed in order to establish sensory utilizable design elements as a solution for the requirements of digitalization. Full article
Show Figures

Figure 1

16 pages, 359 KiB
Review
A Brief Review of Selected Biomechanical Variables for Sport Performance Monitoring and Training Optimization
by Jernej Pleša, Žiga Kozinc and Nejc Šarabon
Appl. Mech. 2022, 3(1), 144-159; https://doi.org/10.3390/applmech3010011 - 01 Feb 2022
Cited by 7 | Viewed by 4432
Abstract
Traditional neuromuscular tests (e.g., jumping and sprinting tasks) are useful to assess athletic performance, but the basic outcomes (e.g., jump height, sprint time) offer only a limited amount of information, warranting a more detailed approach to performance testing. With a more analytical approach [...] Read more.
Traditional neuromuscular tests (e.g., jumping and sprinting tasks) are useful to assess athletic performance, but the basic outcomes (e.g., jump height, sprint time) offer only a limited amount of information, warranting a more detailed approach to performance testing. With a more analytical approach and biomechanical testing, neuromuscular function can be assessed in-depth. In this article, we review the utility of selected biomechanical variables (eccentric utilization ratio, force–velocity relationship, reactive strength index, and bilateral deficit) for monitoring sport performance and training optimization. These variables still represent a macroscopic level of analysis, but provide a more detailed insight into an individual’s neuromuscular capabilities, which can be overlooked in conventional testing. Although the aforementioned “alternative” variables are more complex in biomechanical terms, they are relatively simple to examine, with no need for additional technology other than what is already necessary for performing the conventional tests (for example, even smartphones can be used in many cases). In this review, we conclude that, with the exception of the eccentric utilization ratio, all of the selected variables have some potential for evaluating sport performance. Full article
19 pages, 7712 KiB
Article
On the Modeling of Ship Stiffened Panels Subjected to Uniform Pressure Loads
by Efstathios L. Platypodis and Konstantinos N. Anyfantis
Appl. Mech. 2022, 3(1), 125-143; https://doi.org/10.3390/applmech3010010 - 01 Feb 2022
Cited by 2 | Viewed by 4406
Abstract
Stiffened panels constitute structural assemblies of the entire ship hull, i.e., double bottom, side shell, deck areas, etc. Prescriptive dimensioning of the stiffeners (web thickness and height and flange thickness and breadth) is solely based on the application of beam bending theories. This [...] Read more.
Stiffened panels constitute structural assemblies of the entire ship hull, i.e., double bottom, side shell, deck areas, etc. Prescriptive dimensioning of the stiffeners (web thickness and height and flange thickness and breadth) is solely based on the application of beam bending theories. This work is divided into two parts. The first part involves the assessment of the structural response of one-way (single-bay) stiffened panels under uniform pressure. The objective is to evaluate the effectiveness of alternative approaches in obtaining accurate secondary stress fields. Both state-of-the-art analytical solutions (Paik, Schade, CSR, Miller) and numerical calculation tools (finite element analysis (FEA)) are employed and compared for this purpose. When it comes to cross-stiffened panels, numerical methods are usually used within the design process which is time demanding. The second part of this work focuses on the development of a fast, yet effective, prescriptive approach. This approach will allow the dimensioning of the longitudinal stiffeners by considering the secondary stress field. Combining finite element analysis and the Euler–Bernoulli bending theory, the effect of the transverse stiffeners to the longitudinal stiffeners is examined in order to estimate the type of support on the boundaries of the transverse stiffeners. Determining the type of support, will make it possible to apply the classical formula of bending stress instead of using finite element analysis, thus limiting the computational cost. Preliminary calculations show that most of the examined cases may be treated as fully clamped beams subjected to uniform pressure. Full article
(This article belongs to the Special Issue Mechanics and Control using Fractional Calculus)
Show Figures

Figure 1

2 pages, 243 KiB
Correction
Correction: Riccio et al. Effects of Curing on Photosensitive Resins in SLA Additive Manufacturing. Appl. Mech. 2021, 2, 942–955
by Carmela Riccio, Marco Civera, Oliver Grimaldo Ruiz, Perla Pedullà, Mariana Rodriguez Reinoso, Giulia Tommasi, Martina Vollaro, Vito Burgio and Cecilia Surace
Appl. Mech. 2022, 3(1), 123-124; https://doi.org/10.3390/applmech3010009 - 28 Jan 2022
Cited by 1 | Viewed by 1691
Abstract
The Authors of the paper “Effects of Curing on Photosensitive Resins in SLA Additive Manufacturing” [...] Full article
2 pages, 189 KiB
Editorial
Acknowledgment to Reviewers of Applied Mechanics in 2021
by Applied Mechanics Editorial Office
Appl. Mech. 2022, 3(1), 121-122; https://doi.org/10.3390/applmech3010008 - 28 Jan 2022
Viewed by 1530
Abstract
Rigorous peer-reviews are the basis of high-quality academic publishing [...] Full article
18 pages, 2049 KiB
Article
Dynamic Finite Element Modelling and Vibration Analysis of Prestressed Layered Bending–Torsion Coupled Beams
by MirTahmaseb Kashani and Seyed M. Hashemi
Appl. Mech. 2022, 3(1), 103-120; https://doi.org/10.3390/applmech3010007 - 16 Jan 2022
Cited by 6 | Viewed by 3625
Abstract
Free vibration analysis of prestressed, homogenous, Fiber-Metal Laminated (FML) and composite beams subjected to axial force and end moment is revisited. Finite Element Method (FEM) and frequency-dependent Dynamic Finite Element (DFE) models are developed and presented. The frequency results are compared with those [...] Read more.
Free vibration analysis of prestressed, homogenous, Fiber-Metal Laminated (FML) and composite beams subjected to axial force and end moment is revisited. Finite Element Method (FEM) and frequency-dependent Dynamic Finite Element (DFE) models are developed and presented. The frequency results are compared with those obtained from the conventional FEM (ANSYS, Canonsburg, PA, USA) as well as the Homogenization Method (HM). Unlike the FEM, the application of the DFE formulation leads to a nonlinear eigenvalue problem, which is solved to determine the system’s natural frequencies and modes. The governing differential equations of coupled flexural–torsional vibrations, resulting from the end moment, are developed using Euler–Bernoulli bending and St. Venant torsion beam theories and assuming linear harmonic motion and linearly elastic materials. Illustrative examples of prestressed layered, FML, and unidirectional composite beam configurations, exhibiting geometric bending-torsion coupling, are studied. The presented DFE and FEM results show excellent agreement with the homogenization method and ANSYS modeling results, with the DFE’s rates of convergence surpassing all. An investigation is also carried out to examine the effects of various combined axial loads and end moments on the stiffness and fundamental frequencies of the structure. An illustrative example, demonstrating the application of the presented methods to the buckling analysis of layered beams is also presented. Full article
(This article belongs to the Special Issue Mechanical Design Technologies for Beam, Plate and Shell Structures)
Show Figures

Figure 1

15 pages, 4627 KiB
Article
Effect of the Cyclic Crack Opening-Closure during Epoxy-Curing Period of a CFRP Strengthening System Bonded on Concrete Substrate
by Marc Quiertant, Claude Boulay, Laurent Siegert and Christian Tourneur
Appl. Mech. 2022, 3(1), 88-102; https://doi.org/10.3390/applmech3010006 - 13 Jan 2022
Viewed by 1842
Abstract
This article investigates the potential detrimental effects of cyclic load during the installation of externally bonded (EB) carbon fiber-reinforced polymer (CFRP) on a damaged reinforced concrete (RC) structure. Four RC specimens were tested in three point bending to study the consequences of crack [...] Read more.
This article investigates the potential detrimental effects of cyclic load during the installation of externally bonded (EB) carbon fiber-reinforced polymer (CFRP) on a damaged reinforced concrete (RC) structure. Four RC specimens were tested in three point bending to study the consequences of crack cyclic opening-closure during epoxy-curing period. A first RC specimen (without bonded CFRP) was loaded monotonically up to failure to serve as undamaged control sample. The three other specimens were pre-cracked before being subjected to a fatigue loading procedure to simulate service condition of a damaged RC structure. Two of the three pre-cracked specimens were strengthened by EB CFRP. One specimen was repaired before the fatigue test while the other one was repaired during the fatigue test. Finally, remaining capacities of all three pre-cracked specimens were measured through monotonic bending tests until failure. It was found that, although bonding of CFRP reinforcement during cyclic load can induce some interesting features with regard to serviceability, cyclic crack opening and closing alters the cure process of epoxy located below the initial crack and decreases the effectiveness of the strengthening at ultimate state. Extended experimental studies are then needed to assess reliable safety factor for the design of repairing operations in which the bridge has to be maintained in service during CFRP installation. Full article
(This article belongs to the Special Issue Mechanical Properties of Epoxy Construction Materials)
Show Figures

Figure 1

10 pages, 3468 KiB
Article
Effect of Permittivity on the Electric-Field-Driven Rotation Dynamics in a Liquid Film
by Reza Shirsavar, Saeid Mollaei, Mansoure Moeini Rizi, Ali-Reza Moradi, Ahmad Amjadi, Mehdi Habibi and Ali Najafi
Appl. Mech. 2022, 3(1), 78-87; https://doi.org/10.3390/applmech3010005 - 07 Jan 2022
Cited by 1 | Viewed by 2202
Abstract
Applying a constant electric field on a suspended film of liquid that carries an electric current, either by the transport of ions or surface charges, induces a rotation in the film. This system is known as “liquid film motor”. So far, the effect [...] Read more.
Applying a constant electric field on a suspended film of liquid that carries an electric current, either by the transport of ions or surface charges, induces a rotation in the film. This system is known as “liquid film motor”. So far, the effect of permittivity of the liquid on its rotation has been ignored. We showed that the permittivity of the liquid can significantly affect the dynamics of rotation. Using an experimental approach, we studied the liquid film rotation for a broad range of pure liquids with diverse permittivities and surface tensions. We observed two different regimes of rotation depending on the permittivity of the liquids. We also found that there is no correlation between the surface tension of the liquid and the angular velocity of the rotation. We considered a theoretical framework and suggested scenarios to explain our experimental observations. These results help in better understanding the physics of liquid film motors and suggest opportunities for new flow manipulation techniques at small scales. Full article
Show Figures

Figure 1

14 pages, 2329 KiB
Article
Mechanical Properties and Leak-Tightness of Polymeric Pipe Adhesive Joints
by Anna Rudawska, Magd Abdel Wahab, Miroslav Müller and Dana Stančeková
Appl. Mech. 2022, 3(1), 64-77; https://doi.org/10.3390/applmech3010004 - 04 Jan 2022
Cited by 1 | Viewed by 2449
Abstract
This paper presents issues related to the determination of the selected mechanical properties of adhesive joints made of polymeric pipes and the evaluation of the leak-tightness of the adhesive joints. The article attempts to demonstrate that the type of adhesive may affect the [...] Read more.
This paper presents issues related to the determination of the selected mechanical properties of adhesive joints made of polymeric pipes and the evaluation of the leak-tightness of the adhesive joints. The article attempts to demonstrate that the type of adhesive may affect the quality of adhesive joints in terms of both tightness and strength of joints. Five types of the polymer pipes differing in a polypropylene and a polyvinyl chloride, diameter and a wall thickness were used in the experiments. Two types of the adhesives were used to make the adhesive joints: Loctite 3430 A&B Hysol, a two-component epoxy adhesive, and Loctite 406, a one-component cyanoacrylate adhesive. Based on the leak-tightness tests results, it was possible to determine the quality of their adhesive joints without damaging the samples, while their tensile strength was determined through the strength tests. The tests performed allowed for the conclusion that the use of the polyvinyl chloride pipes and Loctite 406 one-component adhesive is recommended for this type of adhesive joints. Full article
Show Figures

Figure 1

18 pages, 2647 KiB
Article
Experimental and Numerical Studies of Stress Distribution in an Expanding Pin Joint System
by Soheil Salahshour, Øyvind Karlsen and Hirpa Gelgele Lemu
Appl. Mech. 2022, 3(1), 46-63; https://doi.org/10.3390/applmech3010003 - 30 Dec 2021
Cited by 2 | Viewed by 3886
Abstract
Pin joints are widely used mechanisms in different industrial machineries such as aircrafts, cranes, ships, and offshore drilling equipment providing a joint with possibility of relative rotation about one single axis. The rigidity of the joint and its service lifetime depend on the [...] Read more.
Pin joints are widely used mechanisms in different industrial machineries such as aircrafts, cranes, ships, and offshore drilling equipment providing a joint with possibility of relative rotation about one single axis. The rigidity of the joint and its service lifetime depend on the clamping force in the contact region that is provided by the applied torque. However, due to the tolerance needed for insertion of a pin in the equipment support bore, the pin is prone to relative displacement inside the bore. The amplitude of this relative displacement usually increases as time passes and since the material of the support often has lower quality grade than the pin, it leads to creation of slack in the equipment and malfunctioning of the machine. An Expanding Pin System (EPS) can be a solution to this problem where the split sleeve expands to remove the gap while the joint is torqued. Therefore, slack in the joint system disappears and 360° contact area could be achieved, providing a better stress distribution and preventing the stress localization. Determining the EPS preload and the resulting contact pressure and stresses in the joint parts are important to avoid damaging to the contact surfaces of the joints and making the dismantling of the EPS difficult. Therefore, finding the amount of the required torque is a compromise between preventing slack in the EPS and prohibiting damage to the joint parts. Stress analysis in this study is performed based on the industrially recommended torque for the EPS type under study. This article reports the study conducted on the stress distribution and the magnitude of stresses exerted to the equipment support when EPS is installed on the machine. To achieve this purpose and to investigate the stress distribution in the joint, both experimental and finite element (FE) methods were used. The experimental results show how much of the applied energy to the EPS in the form of torque is spent to expand the split sleeve and test boss and also to overcome friction. The finite element analysis provides magnitude and distribution of stresses in the EPS components. Full article
Show Figures

Figure 1

32 pages, 12791 KiB
Article
Interpretation of Cone Penetration Test Data of an Embankment for Coupled Numerical Modeling
by Mohammad Nurul Islam, Carthigesu T. Gnanendran and Siva T. Sivakumar
Appl. Mech. 2022, 3(1), 14-45; https://doi.org/10.3390/applmech3010002 - 29 Dec 2021
Cited by 2 | Viewed by 2612
Abstract
The Nerang Broadbeach Roadway (NBR) embankment in Australia is founded on soft clay deposits. The embankment sections were preloaded and surcharged-preloaded to limit the post-construction deformation and to avoid stability failure. In this paper, we discuss the NBR embankment’s geology, geotechnical properties of [...] Read more.
The Nerang Broadbeach Roadway (NBR) embankment in Australia is founded on soft clay deposits. The embankment sections were preloaded and surcharged-preloaded to limit the post-construction deformation and to avoid stability failure. In this paper, we discuss the NBR embankment’s geology, geotechnical properties of the subsurface, and long-term field monitoring data from settlement plates and piezometers. We demonstrate a comparison of cone penetration test (CPT) and piezo cone dissipation test (CPT-u) interpreted geotechnical properties and the NBR embankment’s foundation stratification with laboratory and field measured data. We also developed two elasto-viscoplastic (EVP) models for long-term performance prediction of the NBR embankment. In this regard, we considered both the associated and the non-associated flow rule in the EVP model formulation to assess the flow rule effect of soft clay. We also compared EVP model predictions with the Modified Cam Clay (MCC) model to evaluate the effect of viscous behavior of natural Estuarine clay. Both EVP models require six parameters, and five of them are similar to the MCC model. We used the secondary compression index of clay in the EVP model formulations to include the viscous response of clay. We obtained numerical models’ parameters from laboratory tests and interpretation of CPT and CPTu data. We observed that the EVP models predicted well compared with the MCC model because of the inclusion of soft clay’s viscosity in the EVP models. Moreover, the flow rule effect in the embankment’s performance predictions was noticeable. The non-associated flow rule EVP model predicted the field monitoring settlement and pore pressure better compared to the MCC model and the associated flow EVP model. Full article
(This article belongs to the Special Issue Mechanics Applied in Construction Engineering)
Show Figures

Figure 1

13 pages, 1131 KiB
Article
Subspace Reduction for Stochastic Planar Elasticity
by Harri Hakula and Mikael Laaksonen
Appl. Mech. 2022, 3(1), 1-13; https://doi.org/10.3390/applmech3010001 - 22 Dec 2021
Viewed by 2108
Abstract
Stochastic eigenvalue problems are nonlinear and multiparametric. They require their own solution methods and remain one of the challenge problems in computational mechanics. For the simplest possible reference problems, the key is to have a cluster of at the low end of the [...] Read more.
Stochastic eigenvalue problems are nonlinear and multiparametric. They require their own solution methods and remain one of the challenge problems in computational mechanics. For the simplest possible reference problems, the key is to have a cluster of at the low end of the spectrum. If the inputs, domain or material, are perturbed, the cluster breaks and tracing of the eigenpairs become difficult due to possible crossing of the modes. In this paper we have shown that the eigenvalue crossing can occur within clusters not only by perturbations of the domain, but also of material parameters. What is new is that in this setting, the crossing can be controlled; that is, the effect of the perturbations can actually be predicted. Moreover, the basis of the subspace is shown to be a well-defined concept and can be used for instance in low-rank approximation of solutions of problems with static loading. In our industrial model problem, the reduction in solution times is significant. Full article
(This article belongs to the Special Issue Mechanics and Control using Fractional Calculus)
Show Figures

Figure 1
