Drones, Volume 3, Issue 3 (September 2019)

  • Issues are regarded as officially published after their release is announced to the table of contents alert mailing list.
  • You may sign up for e-mail alerts to receive table of contents of newly released issues.
  • PDF is the official format for papers published in both, html and pdf forms. To view the papers in pdf format, click on the "PDF Full-text" link, and use the free Adobe Readerexternal link to open them.
Order results
Result details
Select all
Export citation of selected articles as:
Open AccessArticle
Towards Improved Hybrid Actuation Mechanisms for Flapping Wing Micro Air Vehicles: Analytical and Experimental Investigations
Drones 2019, 3(3), 73; https://doi.org/10.3390/drones3030073 - 13 Sep 2019
Viewed by 127
Abstract
A new strategy is proposed in order to effectively design the components of actuation mechanisms for flapping wing micro air vehicles. To this end, the merits and drawbacks of some existing types of conventional flapping actuation mechanisms are first discussed qualitatively. Second, the [...] Read more.
A new strategy is proposed in order to effectively design the components of actuation mechanisms for flapping wing micro air vehicles. To this end, the merits and drawbacks of some existing types of conventional flapping actuation mechanisms are first discussed qualitatively. Second, the relationships between the design of flapping wing actuation mechanism and the entrance requirements including the upstroke and downstroke angles and flapping frequency are determined. The effects of the components of the actuation mechanism on the kinematic and kinetic parameters are investigated. It is shown that there are optimum values for different parameters in order to design an efficient mechanism. Considering the optimized features for an actuation mechanism, the design, analysis, and fabrication of a new hybrid actuation mechanism for FWMAV named “Thunder I” with fourteen components consisting of two six-bar mechanisms are performed. The results show that this designed hybrid actuation mechanism has high symmetrical flapping motion with hinged connections for all components. The proposed methodology for the modeling and fabrication of Thunder I’s actuation mechanism can be utilized as guidelines to design efficient FWMAVs actuation mechanisms. Full article
(This article belongs to the Special Issue Bio-Inspired Drones)
Show Figures

Figure 1

Open AccessArticle
Deep Reinforcement Learning for Drone Delivery
Drones 2019, 3(3), 72; https://doi.org/10.3390/drones3030072 - 10 Sep 2019
Viewed by 364
Abstract
Drones are expected to be used extensively for delivery tasks in the future. In the absence of obstacles, satellite based navigation from departure to the geo-located destination is a simple task. When obstacles are known to be in the path, pilots must build [...] Read more.
Drones are expected to be used extensively for delivery tasks in the future. In the absence of obstacles, satellite based navigation from departure to the geo-located destination is a simple task. When obstacles are known to be in the path, pilots must build a flight plan to avoid them. However, when they are unknown, there are too many or they are in places that are not fixed positions, then to build a safe flight plan becomes very challenging. Moreover, in a weak satellite signal environment, such as indoors, under trees canopy or in urban canyons, the current drone navigation systems may fail. Artificial intelligence, a research area with increasing activity, can be used to overcome such challenges. Initially focused on robots and now mostly applied to ground vehicles, artificial intelligence begins to be used also to train drones. Reinforcement learning is the branch of artificial intelligence able to train machines. The application of reinforcement learning to drones will provide them with more intelligence, eventually converting drones in fully-autonomous machines. In this work, reinforcement learning is studied for drone delivery. As sensors, the drone only has a stereo-vision front camera, from which depth information is obtained. The drone is trained to fly to a destination in a neighborhood environment that has plenty of obstacles such as trees, cables, cars and houses. The flying area is also delimited by a geo-fence; this is a virtual (non-visible) fence that prevents the drone from entering or leaving a defined area. The drone has to avoid visible obstacles and has to reach a goal. Results show that, in comparison with the previous results, the new algorithms have better results, not only with a better reward, but also with a reduction of its variance. The second contribution is the checkpoints. They consist of saving a trained model every time a better reward is achieved. Results show how checkpoints improve the test results. Full article
Show Figures

Graphical abstract

Open AccessArticle
Nature-Inspired Drone Swarming for Real-Time Aerial Data-Collection Under Dynamic Operational Constraints
Drones 2019, 3(3), 71; https://doi.org/10.3390/drones3030071 - 04 Sep 2019
Viewed by 212
Abstract
Unmanned Aerial Vehicles (UAVs) with acceptable performance are becoming commercially available at an affordable cost. Due to this, the use of drones for real-time data collection is becoming common practice by individual practitioners in the areas of e.g., precision agriculture and civil defense [...] Read more.
Unmanned Aerial Vehicles (UAVs) with acceptable performance are becoming commercially available at an affordable cost. Due to this, the use of drones for real-time data collection is becoming common practice by individual practitioners in the areas of e.g., precision agriculture and civil defense such as fire fighting. At the same time, as UAVs become a house-hold item, a plethora of issues—which can no longer be ignored and considered niche problems—are coming of age. These range from legal and ethical questions to technical matters such as how to implement and operate a communication infrastructure to maintain control over deployed devices. With these issues being addressed, approaches that focus on enabling collectives of devices to operate semi-autonomously are also increasing in relevance. In this article we present a nature-inspired algorithm that enables a UAV-swarm to operate as a collective which provides real-time data such as video footage. The collective is able to autonomously adapt to changing resolution requirements for specific locations within the area under surveillance. Our distributed approach significantly reduces the requirements on the communication infrastructure and mitigates the computational cost otherwise incurred. In addition, if the UAVs themselves were to be equipped with even rudimentary data-analysis capabilities, the swarm could react in real-time to the data it generates and self-regulate which locations within its operational area it focuses on. The approach was tested in a swarm of 25 UAVs; we present out preliminary performance evaluation. Full article
(This article belongs to the Special Issue Bio-Inspired Drones)
Show Figures

Figure 1

Open AccessArticle
Evaluation of a Baseline Controller for Autonomous “Figure-8” Flights of a Morphing Geometry Quadcopter: Flight Performance
Drones 2019, 3(3), 70; https://doi.org/10.3390/drones3030070 - 31 Aug 2019
Viewed by 284
Abstract
This article describes the design, fabrication, and flight test evaluation of a morphing geometry quadcopter capable of changing its intersection angle in-flight. The experiments were conducted at the Aircraft Computational and Resource Aware Fault Tolerance (AirCRAFT) Lab, Parks College of Engineering, Aviation and [...] Read more.
This article describes the design, fabrication, and flight test evaluation of a morphing geometry quadcopter capable of changing its intersection angle in-flight. The experiments were conducted at the Aircraft Computational and Resource Aware Fault Tolerance (AirCRAFT) Lab, Parks College of Engineering, Aviation and Technology at Saint Louis University, St. Louis, MO. The flight test matrix included flights in a “Figure-8” trajectory in two different morphing configurations (21° and 27°), as well as the nominal geometry configuration, two different flight velocities (1.5 m/s and 2.5 m/s), two different number of waypoints, and in three planes—horizontal, inclined, and double inclined. All the experiments were conducted using standard, off-the-shelf flight controller (Pixhawk) and autopilot firmware. Simulations of the morphed geometry indicate a reduction in pitch damping (42% for 21° morphing and 57.3% for 27° morphing) and roll damping (63.5% for 21° morphing and 65% for 27° morphing). Flight tests also demonstrated that the dynamic stability in roll and pitch dynamics were reduced, but the quadcopter was still stable under morphed geometry conditions. Morphed geometry also has an effect on the flight performance—with a higher number of waypoints (30) and higher velocity (2.5 m/s), the roll dynamics performed better as compared to the lower waypoints and lower velocity condition. The yaw dynamics remained consistent through all the flight conditions, and were not significantly affected by asymmetrical morphing of the quadcopter geometry. We also determined that higher waypoint and flight velocity conditions led to a small performance improvement in tracking the desired trajectory as well. Full article
Show Figures

Figure 1

Open AccessArticle
Photometric Long-Range Positioning of LED Targets for Cooperative Navigation in UAVs
Drones 2019, 3(3), 69; https://doi.org/10.3390/drones3030069 - 30 Aug 2019
Viewed by 219
Abstract
Autonomous flight with unmanned aerial vehicles (UAVs) nowadays depends on the availability and reliability of Global Navigation Satellites Systems (GNSS). In cluttered outdoor scenarios, such as narrow gorges, or near tall artificial structures, such as bridges or dams, reduced sky visibility and multipath [...] Read more.
Autonomous flight with unmanned aerial vehicles (UAVs) nowadays depends on the availability and reliability of Global Navigation Satellites Systems (GNSS). In cluttered outdoor scenarios, such as narrow gorges, or near tall artificial structures, such as bridges or dams, reduced sky visibility and multipath effects compromise the quality and the trustworthiness of the GNSS position fixes, making autonomous, or even manual, flight difficult and dangerous. To overcome this problem, cooperative navigation has been proposed: a second UAV flies away from any occluding objects and in line of sight from the first and provides the latter with positioning information, removing the need for full and reliable GNSS coverage in the area of interest. In this work we use high-power light-emitting diodes (LEDs) to signalize the second drone and we present a computer vision pipeline that allows to track the second drone in real-time from a distance up to 100 m and to compute its relative position with decimeter accuracy. This is based on an extension to the classical iterative algorithm for the Perspective-n-Points problem in which the photometric error is minimized according to a image formation model. This extension allow to substantially increase the accuracy of point-feature measurements in image space (up to 0.05 pixels), which directly translates into higher positioning accuracy with respect to conventional methods. Full article
(This article belongs to the Special Issue UAS Navigation and Orientation)
Show Figures

Figure 1

Open AccessArticle
Deep Learning-Based Damage Detection from Aerial SfM Point Clouds
Drones 2019, 3(3), 68; https://doi.org/10.3390/drones3030068 - 27 Aug 2019
Viewed by 274
Abstract
Aerial data collection is well known as an efficient method to study the impact following extreme events. While datasets predominately include images for post-disaster remote sensing analyses, images alone cannot provide detailed geometric information due to a lack of depth or the complexity [...] Read more.
Aerial data collection is well known as an efficient method to study the impact following extreme events. While datasets predominately include images for post-disaster remote sensing analyses, images alone cannot provide detailed geometric information due to a lack of depth or the complexity required to extract geometric details. However, geometric and color information can easily be mined from three-dimensional (3D) point clouds. Scene classification is commonly studied within the field of machine learning, where a workflow follows a pipeline operation to compute a series of engineered features for each point and then points are classified based on these features using a learning algorithm. However, these workflows cannot be directly applied to an aerial 3D point cloud due to a large number of points, density variation, and object appearance. In this study, the point cloud datasets are transferred into a volumetric grid model to be used in the training and testing of 3D fully convolutional network models. The goal of these models is to semantically segment two areas that sustained damage after Hurricane Harvey, which occurred in 2017, into six classes, including damaged structures, undamaged structures, debris, roadways, terrain, and vehicles. These classes are selected to understand the distribution and intensity of the damage. The point clouds consist of two distinct areas assembled using aerial Structure-from-Motion from a camera mounted on an unmanned aerial system. The two datasets contain approximately 5000 and 8000 unique instances, and the developed methods are assessed quantitatively using precision, accuracy, recall, and intersection over union metrics. Full article
(This article belongs to the Special Issue Deep Learning for Drones and Its Applications)
Show Figures

Figure 1

Open AccessArticle
Improving Intertidal Reef Mapping Using UAV Surface, Red Edge, and Near-Infrared Data
Drones 2019, 3(3), 67; https://doi.org/10.3390/drones3030067 - 27 Aug 2019
Viewed by 252
Abstract
Coastal living reefs provide considerable services from tropical to temperate systems. Threatened by global ocean-climate and local anthropogenic changes, reefs require spatially explicit management at the submeter scale, where socioecological processes occur. Drone surveys have adequately addressed these requirements with red-green-blue (RGB) orthomosaics [...] Read more.
Coastal living reefs provide considerable services from tropical to temperate systems. Threatened by global ocean-climate and local anthropogenic changes, reefs require spatially explicit management at the submeter scale, where socioecological processes occur. Drone surveys have adequately addressed these requirements with red-green-blue (RGB) orthomosaics and digital surface models (DSMs). The use of ancillary spectral bands has the potential to increase the mapping of all reefscapes that emerge during low tide. This research investigates the contribution of the drone-based red edge (RE), near-infrared (NIR), and DSM into the classification accuracy of five main habitats of the largest intertidal biogenic reefs in Europe, built by the honeycomb worm Sabellaria alveolata. Based on photoquadrats and the maximum likelihood algorithm, overall, producer’s and user’s accuracies were distinctly augmented. When isolated, the DSM provided the highest gain percentage (3.42%), followed by the NIR (2.58%), and RE (2.02%). When joined, the combination of the DSM with both RE and NIR was the best contributor (4.98%), followed by the DSM with RE (4.80%), DSM with NIR (3.74%), and RE with NIR (3.22%). At the class scale, all datasets increasingly advantaged sand, gravel, reef, mud and water. The rather low effect of the DSM with NIR (3.74%) was assumed to be linked with a statistical noise originated from redundant information in the intertidal area. Full article
Show Figures

Graphical abstract

Open AccessReview
A Survey of Recent Extended Variants of the Traveling Salesman and Vehicle Routing Problems for Unmanned Aerial Vehicles
Drones 2019, 3(3), 66; https://doi.org/10.3390/drones3030066 - 24 Aug 2019
Viewed by 335
Abstract
The use of Unmanned Aerial Vehicles (UAVs) is rapidly growing in popularity. Initially introduced for military purposes, over the past few years, UAVs and related technologies have successfully transitioned to a whole new range of civilian applications such as delivery, logistics, surveillance, entertainment, [...] Read more.
The use of Unmanned Aerial Vehicles (UAVs) is rapidly growing in popularity. Initially introduced for military purposes, over the past few years, UAVs and related technologies have successfully transitioned to a whole new range of civilian applications such as delivery, logistics, surveillance, entertainment, and so forth. They have opened new possibilities such as allowing operation in otherwise difficult or hazardous areas, for instance. For all applications, one foremost concern is the selection of the paths and trajectories of UAVs, and at the same time, UAVs control comes with many challenges, as they have limited energy, limited load capacity and are vulnerable to difficult weather conditions. Generally, efficiently operating a drone can be mathematically formalized as a path optimization problem under some constraints. This shares some commonalities with similar problems that have been extensively studied in the context of urban vehicles and it is only natural that the recent literature has extended the latter to fit aerial vehicle constraints. The knowledge of such problems, their formulation, the resolution methods proposed—through the variants induced specifically by UAVs features—are of interest for practitioners for any UAV application. Hence, in this study, we propose a review of existing literature devoted to such UAV path optimization problems, focusing specifically on the sub-class of problems that consider the mobility on a macroscopic scale. These are related to the two existing general classic ones—the Traveling Salesman Problem and the Vehicle Routing Problem. We analyze the recent literature that adapted the problems to the UAV context, provide an extensive classification and taxonomy of their problems and their formulation and also give a synthetic overview of the resolution techniques, performance metrics and obtained numerical results. Full article
(This article belongs to the Special Issue UAS Navigation and Orientation)
Open AccessArticle
Wing Design, Fabrication, and Analysis for an X-Wing Flapping-Wing Micro Air Vehicle
Drones 2019, 3(3), 65; https://doi.org/10.3390/drones3030065 - 20 Aug 2019
Viewed by 379
Abstract
Flapping-wing Micro Air Vehicles (FW-MAVs), inspired by small insects, have limitless potential to be capable of performing tasks in urban and indoor environments. Through the process of mimicking insect flight, however, there are a lot of challenges for successful flight of these vehicles, [...] Read more.
Flapping-wing Micro Air Vehicles (FW-MAVs), inspired by small insects, have limitless potential to be capable of performing tasks in urban and indoor environments. Through the process of mimicking insect flight, however, there are a lot of challenges for successful flight of these vehicles, which include their design, fabrication, control, and propulsion. To this end, this paper investigates the wing design and fabrication of an X-wing FW-MAV and analyzes its performance in terms of thrust generation. It was designed and developed using a systematic approach. Two pairs of wings were fabricated with a traditional cut-and-glue method and an advanced vacuum mold method. The FW-MAV is equipped with inexpensive and tiny avionics, such as the smallest Arduino controller board, a remote-control receiver, standard sensors, servos, a motor, and a 1-cell battery. Thrust measurement was conducted to compare the performance of different wings at full throttle. Overall, this FW-MAV produces maximum vertical thrust at a pitch angle of 10 degrees. The wing having stiffeners and manufactured using the vacuum mold produces the highest thrust among the tested wings. Full article
(This article belongs to the Special Issue Bio-Inspired Drones)
Show Figures

Figure 1

Open AccessArticle
Comparing sUAS Photogrammetrically-Derived Point Clouds with GNSS Measurements and Terrestrial Laser Scanning for Topographic Mapping
Drones 2019, 3(3), 64; https://doi.org/10.3390/drones3030064 - 16 Aug 2019
Viewed by 330
Abstract
Interest in small unmanned aircraft systems (sUAS) for topographic mapping has significantly grown in recent years, driven in part by technological advancements that have made it possible to survey small- to medium-sized areas quickly and at low cost using sUAS aerial photography and [...] Read more.
Interest in small unmanned aircraft systems (sUAS) for topographic mapping has significantly grown in recent years, driven in part by technological advancements that have made it possible to survey small- to medium-sized areas quickly and at low cost using sUAS aerial photography and digital photogrammetry. Although this approach can produce dense point clouds of topographic measurements, they have not been tested extensively to provide insights on accuracy levels for topographic mapping. This case study examines the accuracy of a sUAS-derived point cloud of a parking lot located at the Citizens Bank Arena (CBA) in Ontario, California, by comparing it to ground control points (GCPs) measured using global navigation satellite system (GNSS) data corrected with real-time kinematic (RTK) and to data from a terrestrial laser scanning (TLS) survey. We intentionally chose a flat surface due to the prevalence of flat scenes in sUAS mapping and the challenges they pose for accurately deriving vertical measurements. When the GNSS-RTK survey was compared to the sUAS point cloud, the residuals were found to be on average 18 mm and −20 mm for the horizontal and vertical components. Furthermore, when the sUAS point cloud was compared to the TLS point cloud, the average difference observed in the vertical component was 2 mm with a standard deviation of 31 mm. These results indicate that sUAS imagery can produce point clouds comparable to traditional topographic mapping methods and support other studies showing that sUAS photogrammetry provides a cost-effective, safe, efficient, and accurate solution for topographic mapping. Full article
Show Figures

Figure 1

Open AccessArticle
Multi-Sensor Assessment of the Effects of Varying Processing Parameters on UAS Product Accuracy and Quality
Drones 2019, 3(3), 63; https://doi.org/10.3390/drones3030063 - 15 Aug 2019
Viewed by 466
Abstract
There is a growing demand for the collection of ultra-high spatial resolution imagery using unmanned aerial systems (UASs). UASs are a cost-effective solution for data collection on small scales and can fly at much lower altitudes, thus yielding spatial resolutions not previously achievable [...] Read more.
There is a growing demand for the collection of ultra-high spatial resolution imagery using unmanned aerial systems (UASs). UASs are a cost-effective solution for data collection on small scales and can fly at much lower altitudes, thus yielding spatial resolutions not previously achievable with manned aircraft or satellites. The use of commercially available software for image processing has also become commonplace due to the relative ease at which imagery can be processed and the minimal knowledge of traditional photogrammetric processes required by users. Commercially available software such as AgiSoft Photoscan and Pix4Dmapper Pro are capable of generating the high-quality data that are in demand for environmental remote sensing applications. We quantitatively assess the implications of processing parameter decision-making on UAS product accuracy and quality for orthomosaic and digital surface models for RGB and multispectral imagery. We iterated 40 processing workflows by incrementally varying two key processing parameters in Pix4Dmapper Pro, and conclude that maximizing for the highest intermediate parameters may not always translate into effective final products. We also show that multispectral imagery can effectively be leveraged to derive three-dimensional models of higher quality despite the lower resolution of sensors when compared to RGB imagery, reducing time in the field and the need for multiple flights over the same area when collecting multispectral data is a priority. We conclude that when users plan to use the highest processing parameter values, to ensure quality end-products it is important to increase initial flight coverage in advance. Full article
Show Figures

Figure 1

Open AccessArticle
Morpho–Sedimentary Monitoring in a Coastal Area, from 1D to 2.5D, Using Airborne Drone Imagery
Drones 2019, 3(3), 62; https://doi.org/10.3390/drones3030062 - 14 Aug 2019
Viewed by 331
Abstract
Coastal areas are among the most endangered places in the world, due to their exposure to both marine and terrestrial hazards. Coastal areas host more than two-thirds of the world’s population, and will become increasingly affected by global changes, in particular, rising sea [...] Read more.
Coastal areas are among the most endangered places in the world, due to their exposure to both marine and terrestrial hazards. Coastal areas host more than two-thirds of the world’s population, and will become increasingly affected by global changes, in particular, rising sea levels. Monitoring and protecting the coastlines have impelled scientists to develop adequate tools and methods to spatially monitor morpho-sedimentary coastal areas. This paper presents the capabilities of the aerial drone, as an “all-in-one” technology, to drive accurate morpho-sedimentary investigations in 1D, 2D and 2.5D at very high resolution. Our results show that drone-related fine-resolution, high accuracies and point density outperform the state-of-the-science manned airborne passive and active methods for shoreline position tracking, digital elevation model as well as point cloud creation. We further discuss the reduced costs per acquisition campaign, the increased spatial and temporal resolution, and demonstrate the potentialities to carry out diachronic and volumetric analyses, bringing new perspectives for coastal scientists and managers. Full article
Show Figures

Figure 1

Open AccessArticle
Comparing Filtering Techniques for Removing Vegetation from UAV-Based Photogrammetric Point Clouds
Drones 2019, 3(3), 61; https://doi.org/10.3390/drones3030061 - 30 Jul 2019
Viewed by 712
Abstract
Digital Elevation Models (DEMs) are 3D representations of the Earth’s surface and have numerous applications in geomorphology, hydrology and ecology. Structure-from-Motion (SfM) photogrammetry using photographs obtained by unmanned aerial vehicles (UAVs) have been increasingly used for obtaining high resolution DEMs. These DEMs are [...] Read more.
Digital Elevation Models (DEMs) are 3D representations of the Earth’s surface and have numerous applications in geomorphology, hydrology and ecology. Structure-from-Motion (SfM) photogrammetry using photographs obtained by unmanned aerial vehicles (UAVs) have been increasingly used for obtaining high resolution DEMs. These DEMs are interpolated from point clouds representing entire landscapes, including points of terrain, vegetation and infrastructure. Up to date, there has not been any study clearly comparing different algorithms for filtering of vegetation. The objective in this study was, therefore, to assess the performance of various vegetation filter algorithms for SfM-obtained point clouds. The comparison was done for a Mediterranean area in Murcia, Spain with heterogeneous vegetation cover. The filter methods that were compared were: color-based filtering using an excessive greenness vegetation index (VI), Triangulated Irregular Networks (TIN) densification from LAStools, the standard method in Agisoft Photoscan (PS), iterative surface lowering (ISL), and a combination of iterative surface lowering and the VI method (ISL_VI). Results showed that for bare areas there was little to no difference between the filtering methods, which is to be expected because there is little to no vegetation present to filter. For areas with shrubs and trees, the ISL_VI and TIN method performed best. These results show that different filtering techniques have various degrees of success in different use cases. A default filter in commercial software such as Photoscan may not always be the best way to remove unwanted vegetation from a point cloud, but instead alternative methods such as a TIN densification algorithm should be used to obtain a vegetation-less Digital Terrain Model (DTM). Full article
Show Figures

Figure 1

Open AccessArticle
Using Object-Oriented Classification for Coastal Management in the East Central Coast of Florida: A Quantitative Comparison between UAV, Satellite, and Aerial Data
Drones 2019, 3(3), 60; https://doi.org/10.3390/drones3030060 - 27 Jul 2019
Cited by 2 | Viewed by 550
Abstract
High resolution mapping of coastal habitats is invaluable for resource inventory, change detection, and inventory of aquaculture applications. However, coastal areas, especially the interior of mangroves, are often difficult to access. An Unmanned Aerial Vehicle (UAV), equipped with a multispectral sensor, affords an [...] Read more.
High resolution mapping of coastal habitats is invaluable for resource inventory, change detection, and inventory of aquaculture applications. However, coastal areas, especially the interior of mangroves, are often difficult to access. An Unmanned Aerial Vehicle (UAV), equipped with a multispectral sensor, affords an opportunity to improve upon satellite imagery for coastal management because of the very high spatial resolution, multispectral capability, and opportunity to collect real-time observations. Despite the recent and rapid development of UAV mapping applications, few articles have quantitatively compared how much improvement there is of UAV multispectral mapping methods compared to more conventional remote sensing data such as satellite imagery. The objective of this paper is to quantitatively demonstrate the improvements of a multispectral UAV mapping technique for higher resolution images used for advanced mapping and assessing coastal land cover. We performed multispectral UAV mapping fieldwork trials over Indian River Lagoon along the central Atlantic coast of Florida. Ground Control Points (GCPs) were collected to generate a rigorous geo-referenced dataset of UAV imagery and support comparison to geo-referenced satellite and aerial imagery. Multi-spectral satellite imagery (Sentinel-2) was also acquired to map land cover for the same region. NDVI and object-oriented classification methods were used for comparison between UAV and satellite mapping capabilities. Compared with aerial images acquired from Florida Department of Environmental Protection, the UAV multi-spectral mapping method used in this study provided advanced information of the physical conditions of the study area, an improved land feature delineation, and a significantly better mapping product than satellite imagery with coarser resolution. The study demonstrates a replicable UAV multi-spectral mapping method useful for study sites that lack high quality data. Full article
Show Figures

Figure 1

Open AccessReview
Review: Using Unmanned Aerial Vehicles (UAVs) as Mobile Sensing Platforms (MSPs) for Disaster Response, Civil Security and Public Safety
Drones 2019, 3(3), 59; https://doi.org/10.3390/drones3030059 - 25 Jul 2019
Cited by 1 | Viewed by 494
Abstract
The use of UAVs in areas ranging from agriculture over urban services to entertainment or simply as a hobby has rapidly grown over the last years. Regarding serious/commercial applications, UAVs have been considered in the literature, especially as mobile sensing/actuation platforms (i.e., as [...] Read more.
The use of UAVs in areas ranging from agriculture over urban services to entertainment or simply as a hobby has rapidly grown over the last years. Regarding serious/commercial applications, UAVs have been considered in the literature, especially as mobile sensing/actuation platforms (i.e., as a delivery platform for an increasingly wide range of sensors and actuators). With regard to timely, cost-effective and very rich data acquisition, both, NEC Research as well as TNO are pursuing investigations into the use of UAVs and swarms of UAVs for scenarios where high-resolution requirements, prohibiting environments or tight time constraints render traditional approaches ineffective. In this review article, we provide a brief overview of safety and security-focused application areas that we identified as main targets for industrial and commercial projects, especially in the context of intelligent autonomous systems and autonomous/semi-autonomously operating swarms. We discuss a number of challenges related to the deployment of UAVs in general and to their deployment within the identified application areas in particular. As such, this article is meant to serve as a review and overview of the literature and the state-of-the-art, but also to offer an outlook over our possible (near-term) future work and the challenges that we will face there. Full article
Show Figures

Figure 1

Open AccessArticle
Drones Chasing Drones: Reinforcement Learning and Deep Search Area Proposal
Drones 2019, 3(3), 58; https://doi.org/10.3390/drones3030058 - 16 Jul 2019
Viewed by 532
Abstract
Unmanned aerial vehicles (UAVs) are very popular and increasingly used in different applications. Today, the use of multiple UAVs and UAV swarms are attracting more interest from the research community, leading to the exploration of topics such as UAV cooperation, multi-drone autonomous navigation, [...] Read more.
Unmanned aerial vehicles (UAVs) are very popular and increasingly used in different applications. Today, the use of multiple UAVs and UAV swarms are attracting more interest from the research community, leading to the exploration of topics such as UAV cooperation, multi-drone autonomous navigation, etc. In this work, we propose two approaches for UAV pursuit-evasion. The first approach uses deep reinforcement learning to predict the actions to apply to the follower UAV to keep track of the target UAV. The second approach uses a deep object detector and a search area proposal (SAP) to predict the position of the target UAV in the next frame for tracking purposes. The two approaches are promising and lead to a higher tracking accuracy with an intersection over union (IoU) above the selected threshold. We also show that the deep SAP-based approach improves the detection of distant objects that cover small areas in the image. The efficiency of the proposed algorithms is demonstrated in outdoor tracking scenarios using real UAVs. Full article
Show Figures

Figure 1

Open AccessArticle
Drone Geologic Mapping of an Active Sand and Gravel Quarry, Desoto County, Mississippi
Drones 2019, 3(3), 57; https://doi.org/10.3390/drones3030057 - 15 Jul 2019
Viewed by 381
Abstract
Aerial drone photography of an active pit within a sand and gravel quarry in DeSoto County, Mississippi, was conducted to better understand the Upland Complex, which is a high-level Pliocene terrace of the Mississippi River. The Upland Complex is of great interest economically, [...] Read more.
Aerial drone photography of an active pit within a sand and gravel quarry in DeSoto County, Mississippi, was conducted to better understand the Upland Complex, which is a high-level Pliocene terrace of the Mississippi River. The Upland Complex is of great interest economically, as it is the primary source of sand and gravel for Memphis, Tennessee and the surrounding region. The pit dimensions were approximately 820 ft (250 m) by 655 ft (200 m) and 79-ft (24 m) deep upon completion of the mining. Eight 3-D models of the pit were made at different times to illustrate the mining progression. Oblique and horizontal stereo aerial photography of the highwalls was conducted to produce 3-D models and high-resolution photomosaics of the highwalls for geologic mapping and interpretation. The mapped highwall geology included Pliocene Mississippi River bars consisting of sand, sand and gravel, and gravel ranging in thickness from 2 ft (0.6 m) to 32.8 ft (10 m), with variable cross-bed dip directions suggesting a meandering river environment of deposition. Pleistocene loess overlies the Pliocene sediment. The highwalls also revealed northerly-striking late Pliocene or Pleistocene tectonic folding, faulting, and probable earthquake liquefaction in northwestern Mississippi, where no Pliocene or Quaternary tectonic deformation had previously been reported. This study demonstrated Drone aerial photography as a quick, low cost, and safe means to study poorly accessible open-pit mining and to help understand the geology of the lower Mississippi River Valley. Full article
Show Figures

Figure 1

Open AccessArticle
Impact of Rotor–Airframe Orientation on the Aerodynamic and Aeroacoustic Characteristics of Small Unmanned Aerial Systems
Drones 2019, 3(3), 56; https://doi.org/10.3390/drones3030056 - 12 Jul 2019
Viewed by 430
Abstract
With the rapid increase in the number of multi-rotor small unmanned aerial systems (sUAS) in recent years and a plethora of possible applications, the aerodynamic and aeroacoustic characteristics of these vehicles become very important issues. Due to the limited research on the aerodynamic [...] Read more.
With the rapid increase in the number of multi-rotor small unmanned aerial systems (sUAS) in recent years and a plethora of possible applications, the aerodynamic and aeroacoustic characteristics of these vehicles become very important issues. Due to the limited research on the aerodynamic and aeroacoustic characteristics of sUAS which include an airframe or support arm, this paper presents a comprehensive analysis of the flow and acoustic features with the inclusion of said geometry. The influence of rotor orientation—either mounted above or below the airframe—was comprehensively studied through experimental and computational analyses. Detailed experimental investigations—including particle image velocimetry (PIV), pressure transducer readings, and acoustic measurements—were employed to assess the aerodynamic and acoustic characteristics of a rotor–airframe system used on typical multirotor sUAS. The results from the computational methodology were also compared to those from the experiment to assess accuracy and possible benefits. Full article
Show Figures

Figure 1

Open AccessArticle
Illumination Geometry and Flying Height Influence Surface Reflectance and NDVI Derived from Multispectral UAS Imagery
Drones 2019, 3(3), 55; https://doi.org/10.3390/drones3030055 - 08 Jul 2019
Viewed by 536
Abstract
Small unmanned aerial systems (UAS) have allowed the mapping of vegetation at very high spatial resolution, but a lack of standardisation has led to uncertainties regarding data quality. For reflectance measurements and vegetation indices (Vis) to be comparable between sites and over time, [...] Read more.
Small unmanned aerial systems (UAS) have allowed the mapping of vegetation at very high spatial resolution, but a lack of standardisation has led to uncertainties regarding data quality. For reflectance measurements and vegetation indices (Vis) to be comparable between sites and over time, careful flight planning and robust radiometric calibration procedures are required. Two sources of uncertainty that have received little attention until recently are illumination geometry and the effect of flying height. This study developed methods to quantify and visualise these effects in imagery from the Parrot Sequoia, a UAV-mounted multispectral sensor. Change in illumination geometry over one day (14 May 2018) had visible effects on both individual images and orthomosaics. Average near-infrared (NIR) reflectance and NDVI in regions of interest were slightly lower around solar noon, and the contrast between shadowed and well-illuminated areas increased over the day in all multispectral bands. Per-pixel differences in NDVI maps were spatially variable, and much larger than average differences in some areas. Results relating to flying height were inconclusive, though small increases in NIR reflectance with height were observed over a black sailcloth tarp. These results underline the need to consider illumination geometry when carrying out UAS vegetation surveys. Full article
Show Figures

Figure 1

Open AccessArticle
Using Unmanned Aerial Systems (UAS) and Object-Based Image Analysis (OBIA) for Measuring Plant-Soil Feedback Effects on Crop Productivity
Drones 2019, 3(3), 54; https://doi.org/10.3390/drones3030054 - 30 Jun 2019
Viewed by 717
Abstract
Unmanned aerial system (UAS) acquired high-resolution optical imagery and object-based image analysis (OBIA) techniques have the potential to provide spatial crop productivity information. In general, plant-soil feedback (PSF) field studies are time-consuming and laborious which constrain the scale at which these studies can [...] Read more.
Unmanned aerial system (UAS) acquired high-resolution optical imagery and object-based image analysis (OBIA) techniques have the potential to provide spatial crop productivity information. In general, plant-soil feedback (PSF) field studies are time-consuming and laborious which constrain the scale at which these studies can be performed. Development of non-destructive methodologies is needed to enable research under actual field conditions and at realistic spatial and temporal scales. In this study, the influence of six winter cover crop (WCC) treatments (monocultures Raphanus sativus, Lolium perenne, Trifolium repens, Vicia sativa and two species mixtures) on the productivity of succeeding endive (Cichorium endivia) summer crop was investigated by estimating crop volume. A three-dimensional surface and terrain model were photogrammetrically reconstructed from UAS imagery, acquired on 1 July 2015 in Wageningen, the Netherlands. Multi-resolution image segmentation (MIRS) and template matching algorithms were used in an integrated workflow to detect individual crops (accuracy = 99.8%) and delineate C. endivia crop covered area (accuracy = 85.4%). Mean crop area (R = 0.61) and crop volume (R = 0.71) estimates had strong positive correlations with in situ measured dry biomass. Productivity differences resulting from the WCC treatments were greater for estimated crop volume in comparison to in situ biomass, the legacy of Raphanus was most beneficial for estimated crop volume. The perennial ryegrass L. perenne treatment resulted in a significantly lower production of C. endivia. The developed workflow has potential for PSF studies as well as precision farming due to its flexibility and scalability. Our findings provide insight into the potential of UAS for determining crop productivity on a large scale. Full article
(This article belongs to the Special Issue UAV/Drones for Agriculture and Forestry)
Show Figures

Figure 1

Open AccessArticle
Seed and Seedling Detection Using Unmanned Aerial Vehicles and Automated Image Classification in the Monitoring of Ecological Recovery
Drones 2019, 3(3), 53; https://doi.org/10.3390/drones3030053 - 28 Jun 2019
Viewed by 584
Abstract
Monitoring is a crucial component of ecological recovery projects, yet it can be challenging to achieve at scale and during the formative stages of plant establishment. The monitoring of seeds and seedlings, which represent extremely vulnerable stages in the plant life cycle, is [...] Read more.
Monitoring is a crucial component of ecological recovery projects, yet it can be challenging to achieve at scale and during the formative stages of plant establishment. The monitoring of seeds and seedlings, which represent extremely vulnerable stages in the plant life cycle, is particularly challenging due to their diminutive size and lack of distinctive morphological characteristics. Counting and classifying seedlings to species level can be time-consuming and extremely difficult, and there is a need for technological approaches offering restoration practitioners with fine-resolution, rapid and scalable plant-based monitoring solutions. Unmanned aerial vehicles (UAVs) offer a novel approach to seed and seedling monitoring, as the combination of high-resolution sensors and low flight altitudes allow for the detection and monitoring of small objects, even in challenging terrain and in remote areas. This study utilized low-altitude UAV imagery and an automated object-based image analysis software to detect and count target seeds and seedlings from a matrix of non-target grasses across a variety of substrates reflective of local restoration substrates. Automated classification of target seeds and target seedlings was achieved at accuracies exceeding 90% and 80%, respectively, although the classification accuracy decreased with increasing flight altitude (i.e., decreasing image resolution) and increasing background surface complexity (increasing percentage cover of non-target grasses and substrate surface texture). Results represent the first empirical evidence that small objects such as seeds and seedlings can be classified from complex ecological backgrounds using automated processes from UAV-imagery with high levels of accuracy. We suggest that this novel application of UAV use in ecological monitoring offers restoration practitioners an excellent tool for rapid, reliable and non-destructive early restoration trajectory assessment. Full article
Show Figures

Figure 1

Open AccessArticle
An Evaluation of the Delivery of Medicines Using Drones
Drones 2019, 3(3), 52; https://doi.org/10.3390/drones3030052 - 27 Jun 2019
Viewed by 570
Abstract
This study tests the impact of drone transportation on the quality of a medicine. Modelling the critical process parameters of drone flight, the effects of temperature and vibration on insulin were investigated using the pharmacopoeia methods. The medicine, Actrapid, (3.5 mg/mL of insulin), [...] Read more.
This study tests the impact of drone transportation on the quality of a medicine. Modelling the critical process parameters of drone flight, the effects of temperature and vibration on insulin were investigated using the pharmacopoeia methods. The medicine, Actrapid, (3.5 mg/mL of insulin), was flown by a quad-rotor drone. Insulin stored between −20 and 40 °C for 30 mins, and subjected to vibration (0–40 Hz, 25 °C, 30 mins) passed the pharmacopeia tests. Dynamic light scattering identified the active tetrameric and hexameric forms of insulin post testing. Vibration frequencies during drone flight were between 0.1 and 3.4 Hz. There was no evidence of visible insulin aggregates following the drone transportation. The differences in UV absorbance readings between flown Actrapid and controls were insignificant (p = 0.89). No adverse impact of drone transport on insulin was observed. This study provides supporting evidence that drone transportation of medicinal products containing insulin is feasible. The authors recommend that when considering the drone delivery of medicines five tests need to be applied. These tests must determine the safe flight time and range, the quality of the medicine post flight, the onboard conditions experienced by the medicine, the security of the drone supply chain and the effect of drone failure on both the medicine and the environment. Full article
Show Figures

Graphical abstract
