Optimization of Flow and Mixing in a Venturi Tube Mixer with a Two-Step Method Using Numerical Simulation

by
Zhenxin Tang
1,
Fenglei Huang
2,
Zixiong Yao
1,
Ziqi Cai
1,*,
Xin Ma
1,
Zhipeng Li
1 and
Zhengming Gao
1
1
State Key Laboratory of Chemical Resource Engineering, School of Chemical Engineering, Beijing University of Chemical Technology, Beijing 100029, China
2
China National Bluestar (Group) Co., Ltd., Beijing 100029, China
*
Author to whom correspondence should be addressed.
Processes 2023, 11(4), 1083; https://doi.org/10.3390/pr11041083
Submission received: 14 February 2023 / Revised: 26 March 2023 / Accepted: 29 March 2023 / Published: 3 April 2023
(This article belongs to the Special Issue Chemical Process Modelling and Simulation)
Browse Figures
Versions Notes

Abstract

To achieve efficient mixing in a Venturi tube mixer (VTM), an optimization with a two-step method for this mixing device based on a Venturi tube (VT) was carried out using numerical simulation. Firstly, the effects of the structural parameters on the flow in VT were revealed, and the optimized configuration was determined for the following VTM. Subsequently, by introducing a jetting tube, the suction capacity, energy consumption and mixing quality were used to evaluate the performance of VTM under various configurations and operating conditions. According to the effects of the structural parameters on the mixing quality of VTM, an empirical formula for mixing quality with structural parameters was proposed. Finally, an optimized VTM was proposed. This work can provide a valid suggestion for the design and optimization of such a mixing device.
Keywords: Venturi tube mixer; mixing; flow; numerical simulation Venturi tube mixer; mixing; flow; numerical simulation
