Universality of Droplet Impingement: Low-to-High Viscosities and Surface Tensions

and
1
Advanced Thermal and Fluid Energy System, Division of Industrial Fundamentals, Faculty of Advanced Science and Technology, Kumamoto University, 2-39-1, Kurokami, Chuo-ku, Kumamoto-shi, Kumamoto 860-8555, Japan
2
Department of Nuclear Engineering, Kyoto University, C3-d2S06, Kyoto Daigaku-Katsura, Nishikyo-ku, Kyoto 615-8540, Japan
*
Author to whom correspondence should be addressed.

Abstract

When a droplet impinges on a solid surface, its kinetic energy is mainly converted to capillary energy and viscous dissipation energy, the ratio of which depends on the wettability of the target surface and the liquid properties. Currently, there is no experimental or theoretical evidence that suggests which types of liquids exhibit the capillary energy-dominated impingement behavior. In this paper, we reported the droplet impingement behavior for a wide range of liquid viscosities, surface tensions and target surface wettabilities. Then, we showed that a recently developed energy balance equation for the droplet impingement behavior can be universally employed for predicting the maximum spreading contact area diameter of a droplet for Newtonian liquids in deposition process by modelling the droplet surface deformation. Subsequently, applicability limitations of recent existing models are discussed. The newly developed model demonstrated that the capillary energy-dominated impingement behavior can be observed at considerably low viscosities of liquid droplets such as that of the superfluid of liquid helium.
