Microporous Block Copolymers Modified with Cu(II)-Coordinated Polyethylene Oxide-Substituted Silicas for Analytical Sensors

,
,
,
,
,
and
1
Technology of Synthetic Rubber Department, Kazan National Research Technological University, Karl Marx str., 68, 420015 Kazan, Russia
2
Material Science and Technology of Materials Department, Kazan State Power Engineering University, Krasnoselskaya str., 51, 420066 Kazan, Russia
*
Authors to whom correspondence should be addressed.

Abstract

The influence of stable-to-self-condensation Cu(II)-coordinated polyoxyethylene-substituted silicas (ASiP-Cu-0.5) on the synthesis of microporous block copolymers (OBCs) whose structural feature is the existence of coplanar polyisocyanate blocks of acetal nature (O-polyisocyanates) and a flexible-chain component of amphiphilic nature was studied. The use of ASiP-Cu-0.5 increased the yield of O-polyisocyanate blocks and the microphase separation of OBC. The resulting OBCs turned out to be effective sorbents for the analytical reagents PAN and PHENAZO, which, being in the micropore cavity, interacted with copper(II) and magnesium ions. To reduce the thickness of the selective OBC layer ten-fold and simplify the technology for obtaining analytical test systems, polyethylene terephthalate was used as a substrate for applying OBC. It was found that the increased sensitivity of the resulting test systems was due to the fact that in thin reaction layers, the efficiency of the formation of O-polyisocyanate blocks noticeably increased.
