A New Three-Dimension Deceptive Scene Generation against Single-Pass Multibaseline InSAR Based on Multiple Transponders

State Key Laboratory of Complex Electromagnetic Environment Effects on Electronics and Information System, National University of Defense Technology, Changsha 410073, China
*
Author to whom correspondence should be addressed.
Sensors 2020, 20(4), 1053; https://doi.org/10.3390/s20041053 (registering DOI)
Received: 10 January 2020 / Revised: 12 February 2020 / Accepted: 13 February 2020 / Published: 15 February 2020
(This article belongs to the Section Remote Sensors, Control, and Telemetry)
The interferometry synthetic aperture radar (InSAR) deceptive jamming method utilizing two synergetic transponders can generate a false three-dimension (3D) scene in a single baseline InSAR image. However, such deceptive capability could be reduced by the multibaseline InSAR system. To obtain effective deception on multibaseline InSAR, a novel deceptive scene generation method jointly employing multiple transponders is proposed. It only demands that each transponder is modulated with a complex coefficient when generating a false point. The complex modulation coefficient can be offline calculated according to the deceptive point coordinate by solving a matrix. Besides, the complex modulation coefficient can be combined with the deceptive scene template, and thus a large 3D deceptive scene is able to be created quickly in the multibaseline InSAR image by using the fast two-dimension (2D) SAR deceptive scene generation algorithm. As long as the number of transponders is not less than the number of antennas of the multibaseline InSAR system, this proposed method is effective. The effectiveness of the proposed method is validated by computer simulations. View Full-Text
Keywords: synthetic aperture radar (SAR); interferometric synthetic aperture radar (InSAR); deceptive scene; multibaseline; multiple transponders synthetic aperture radar (SAR); interferometric synthetic aperture radar (InSAR); deceptive scene; multibaseline; multiple transponders
Show Figures

Figure 1

MDPI and ACS Style

Ji, P.; Dai, D.; Xing, S.; Pang, B. A New Three-Dimension Deceptive Scene Generation against Single-Pass Multibaseline InSAR Based on Multiple Transponders. Sensors 2020, 20, 1053.
