With the increasing integration of renewable energy sources into the grid, power quality at the point of common coupling (PCC)—particularly harmonic distortion introduced by power electronic converters—has become a critical concern. This paper presents a rigorous design and evaluation of a three-phase, fifteen-level cascaded H-bridge multilevel inverter (CHB MLI) with an LCL filter, selected for its superior harmonic attenuation, compact size, and cost-effectiveness compared to conventional passive filters. The proposed system employs Phase-Shifted Pulse Width Modulation (PS PWM) for balanced operation and low output distortion. A systematic, reproducible methodology is used to design the LCL filter, which is then tested across a wide range of switching frequencies (1–5 kHz) and grid impedance ratios (X/R = 2–9) in MATLAB/Simulink R2025a. Comprehensive simulations confirm that the filter effectively reduces both voltage and current total harmonic distortion (THD) to levels well below the 5% limit specified by IEEE 519, with optimal performance (0.53% current THD, 0.69% voltage THD) achieved at 3 kHz and X/R ≈ 5.6. The filter demonstrates robust performance regardless of grid conditions, making it a practical and scalable solution for modern renewable energy integration. These results, further supported by parametric validation and clear design guidelines, provide actionable insights for academic research and industrial deployment. Full article

Electromagnetic flowmeters face significant challenges in measuring complex fluids, characterized by weak flow signals and severe noise interference. Conventional solutions, such as dual-frequency rectangular wave excitation, suffer from multiple drawbacks including rich harmonic components, high electromagnetic noise during switching transitions, a propensity for resonance which shortens stabilization time, reduced sampling windows, and complex circuit implementation. Similarly, traditional single-frequency excitation struggles to balance zero stability with the suppression of slurry noise. To address these limitations, this paper proposes a novel converter design based on dual-frequency sinusoidal wave excitation. A pure hardware circuit is used to generate the composite excitation signal, which superimposes low-frequency and high-frequency components. This approach eliminates the need for a master control chip in signal generation, thereby reducing both circuit complexity and computational resource allocation. The signal processing chain employs a technique of “high-order Butterworth separation filtering combined with synchronous demodulation,” effectively suppressing power frequency, orthogonal, and in-phase interference, achieving an improvement in interference rejection by approximately three orders of magnitude (1000×). Experimental results show that the proposed converter featured simplified circuitry, achieved a measurement accuracy of class 0.5, and validated the overall feasibility of the scheme. Full article

Time-Sensitive Networking (TSN), particularly the Time-Aware Shaper (TAS) specified by IEEE 802.1Qbv, is critical for real-time communication in Industrial Sensor Networks (ISNs). However, many TAS scheduling approaches rely on centralized computation and can face scalability bottlenecks in large networks. In addition, global-only schedulers often generate fragmented Gate Control Lists (GCLs) that exceed per-port entry limits on resource-constrained switches, reducing deployability. This paper proposes a two-phase distributed genetic-based algorithm, 2PDGA, for TAS scheduling. Phase I runs a network-level genetic algorithm (GA) to select routing paths and release offsets and construct a conflict-free baseline schedule. Phase II performs per-switch local refinement to merge windows and enforce device-specific GCL caps with lightweight coordination. We evaluate 2PDGA on 1512 configurations (three topologies, 8–20 switches, and guard bands ${\mathsf{\delta }}_{gb}\in \{0, 100, 200\} \mathrm{ns}$). At ${\mathsf{\delta }}_{gb}=0$ ns, 2PDGA achieves 92.9% and 99.8% CAP@8/CAP@16, respectively, compliance while maintaining a median latency of 42.1 $\mathsf{\mu }$s. Phase II reduces the average max-per-port GCL entries by 7.7%. These results indicate improved hardware deployability under strict GCL caps, supporting practical deployment in real-world Industry 4.0 applications. Full article

This study presents a comprehensive performance analysis of four different control strategies, Proportional–Integral (PI), classical Sliding Mode Control (SMC), Super-Twisting SMC (ST-SMC), and Exponential Reaching Law SMC (ERL-SMC), applied to the speed regulation of a Hall-effect sensored Brushless DC (BLDC) motor. A mathematically detailed BLDC motor model, three-phase inverter structure with safe commutation logic, and a high-frequency PWM switching scheme were implemented in the MATLAB/Simulink-2024a environment to provide a realistic simulation framework. The control strategies were evaluated under multiple test scenarios, including variations in supply voltage, mechanical load disturbances, reference speed transitions, and steady-state operation. The comparative results reveal that the classical SMC and PI controllers suffer from significant oscillations, overshoot, and limited disturbance rejection capability, especially during voltage and load transients. The ST-SMC algorithm improves robustness and reduces the chattering effect inherent to first-order SMC but still exhibits noticeable oscillations near the sliding surface. In contrast, the proposed ERL-SMC controller demonstrates superior performance across all scenarios, achieving the lowest steady-state ripple, the shortest settling time, and the most stable transition response while significantly mitigating chattering. These results indicate that ERL-SMC is the most effective and reliable control strategy among the evaluated methods for BLDC speed regulation, which requires high dynamic response and disturbance robustness. The findings of this study contribute to the advancement of SMC-based BLDC motor control, providing a solid foundation for future research that integrates observer-based schemes, adaptive tuning, or real-time hardware implementation. Full article

Electric motor drives with a wide variety of applications are usually derived with inverters, where the inverter switches are always prone to different types of faults. Short circuit faults can rapidly shut down systems, and open-circuit ones can lead to secondary damage if they are not detected and tolerated in time. Due to this fact, in this paper, a novel data-driven fault detection and diagnosis (FDD) method has been proposed to detect and locate all types of inverter switch faults. Three deep learning algorithms, including fully connected neural networks (FCNs), convolutional neural networks (CNNs), and bidirectional long short-term memory (BiLSTM), have been implemented and compared. The BiLSTM network with 98.45% accuracy outperforms the others and can detect all types of faults in less than half a fundamental period under different and variable speeds with the existence of noise. The results show that the proposed method is highly effective and is a great candidate for real-time applications. Full article

High-precision torque regulation is essential to ensure reaction wheel systems meet the stringent attitude control requirements of modern spacecraft. In three-phase half-bridge brushless DC (BLDC) drives, non-ideal back-electromotive force (back-EMF) waveforms cause pronounced conduction interval torque ripple, leading to inaccurate and unstable output torque. To address this problem, this article proposes a composite torque control strategy integrating an Adaptive Nonsingular Fast Terminal Sliding-Mode Observer (ANFTSMO) with an Adaptive Sliding-Mode Controller (ASMC). The ANFTSMO achieves precise back-EMF estimation and electromagnetic torque reconstruction by eliminating singularities, reducing chattering, and adaptively adjusting observer gains. Meanwhile, the ASMC employs an adaptive switching gain function to achieve asymptotic current convergence with suppressed chattering, thereby ensuring accurate current tracking. System stability is verified via Lyapunov analysis. Simulation and experimental results demonstrate that, compared with conventional constant-current control, the torque smoothness and disturbance rejection of the proposed method are improved, enabling precise and stable reaction wheel torque delivery for high-accuracy spacecraft attitude regulation. Full article

During the switch-off process, the contact erosion generated by the AC contactor will seriously affect its performance, thereby directly influencing the normal operation of the power equipment. Therefore, aiming at the problem of contact erosion caused by contact bounce during the switch-on and switch-off period of AC contactors, this paper designed the driving circuits during the switch-on, holding, and switch-off processes. During the switch-on process, DC excitation was used instead of AC excitation to eliminate or reduce the contact bounce. During the holding process, low-voltage DC was used instead of high-voltage AC to save energy and reduce coil losses. During the switch-off process, the contact current was used as the control factor, and the scheme of shunting control was employed to achieve the goal of few or even no arcs. In addition, in order to detect the high voltage and large current signals in the main circuit, the three-phase voltage acquisition circuit and three-phase current acquisition circuit were designed. Therefore, a whole process dynamic control which included the switch-on, holding, and switch-off was formed. Through simulation testing and relevant experimental testing, the results demonstrated the correctness and effectiveness of the designed circuit. Full article

This paper proposes a novel seven-level switched-capacitor multilevel inverter featuring a shared front-end DC-link structure that achieves triple voltage gain with reduced component count. A distinctive feature of this design is its inherent capacitor voltage self-balancing capability, thereby eliminating the need for complex control algorithms typically associated with multilevel converters. Moreover, the topology demonstrates particularly significant advantages in three-phase implementations, where a single DC source, front-end switching devices, and capacitors can be shared across all phases—thus substantially reducing component count and system complexity compared to conventional designs. Additionally, this paper proposes an improved carrier-based modulation strategy for this topology requiring only a single triangular carrier, along with a systematic method for determining optimal capacitance values. Through detailed comparative assessment against state-of-the-art switched-capacitor seven-level inverters, the superior performance characteristics of the proposed topology are clearly demonstrated. Finally, simulation results under various operating conditions are presented and subsequently validated through experimental testing on a laboratory prototype, confirming the practical viability of the proposed solution. Full article

In this paper, we propose a novel concept of a modular, multiport, single-stage, bidirectional, isolated, three-phase AC-DC converter system. This new system is realized using add-ons to a standard voltage source inverter, including both grid-connected AC-DC converters, like PWM rectifiers, and AC-drive DC-AC inverters. The proposed add-on converters provide isolated DC ports and can be installed into existing inverters of the abovementioned types, with no need for any modification of their topology or control system. Moreover, the add-on converters provide a minimum transistor count and high efficiency. The efficiency of the proposed add-on converters can be further improved by switching the type of pulse width modulation (PWM) scheme based on their operating point. The proposed converter system is validated for a power of 20 kW, an output voltage of 500–800 V DC, and a 40 kHz PWM frequency. Full article

The capacity of traditional distribution networks is limited. After large-scale distributed power sources are connected, it is difficult to consume them at the same voltage level, which can lead to transformer reverse overloading and voltage limit violations. Although the unified power flow controller (UPFC) excels in flexible power flow regulation and power quality optimization, existing research on it is mostly focused on the transmission grid, focusing on device topology, power flow control, etc. Fault protection is also targeted at high-voltage and ultra-high-voltage domains and only covers a single overvoltage or overcurrent fault. Research on the protection of the unified power flow controller in a distribution network (D-UPFC) remains scarce. A key challenge is the absence of fault protection schemes that are compatible with the unified power flow controller in a distribution network, which cannot meet the requirements of the distribution network for monitoring and protecting multiple fault types, rapid response, and equipment economy. This paper first designs a protection device centered on the distribution thyristor bypass switch (D-TBS), completes the thyristor selection and transient energy extraction, optimizes the overvoltage protection loop parameter, then builds a three-level coordinated protection architecture, and, finally, verifies through functional and system tests. The results show that the thyristor control unit trigger is reliable and the total overvoltage response delay is 1.08 μs. In the case of a three-phase short-circuit fault in a 600 kVA/10 kV system, the distribution thyristor bypass switch can rapidly reduce the secondary voltage of the series transformer, suppress transient overcurrent, achieve isolation protection of the main equipment, provide a reliable guarantee for the engineering application of the distribution network unified power flow controller, and expand its distribution network application scenarios. Full article

Many methods have been developed for multilevel Space Vector Modulation (SVM), but despite their inherent advantages, all of them have been more complex than the alternative option of using Pulse Width Modulation (PWM) with sinusoidal or modified references. Different axes like g-h at 60° or ja-jb-jc at 120° have been used to simplify the operations to find the three nearest vectors and their duty cycles, but the control signals of multilevel converters are the duty cycles of phases, not the duty cycles of vectors. Moreover, throughout this paper, it was found that local information is not sufficient to compute the duty cycles of the phases: global information should be taken into account to obtain full control on the common mode voltage (CMV), and the selection of the starting vector in the switching sequence is also critical to obtain a balanced CMV. The natural coordinates ab-bc-ca were used in this paper, and a straightforward method is proposed for multilevel SVM: a method that is comparable in complexity to multilevel PWM with modified references and leads to exactly the same control signals. This method can be used as an easy starting point to develop other SVM techniques for multilevel converters. Full article

With the continuous development of the robotics industry, using a single wireless system to charge different types of robots has become a critical issue that urgently needs to be addressed. To solve this problem, in the present work, we propose a single-switch inverter module wireless charging system based on parallel module number frequency modulation to achieve the expected variable voltage output by adjusting the operating frequency and the number of parallel modules, thereby enhancing the interoperability between devices. To meet the charging requirements of lithium batteries, which require constant current (CC) first and constant voltage (CV) thereafter, we first discuss how to implement CC and CV charging modes, then demonstrate that the proposed system can provide the required CC and CV output under various load conditions. Subsequently, a simplified equivalent circuit model to achieve this wireless charging system is proposed and an exact expression for its equivalent input voltage source is provided. Subsequently, based on the analysis of the amplitude–frequency characteristics of voltage gain under the CV mode, we propose the relevant method and program to realize this variable output system, and specifically build a prototype system based on a three-module parallel configuration. Experimental results show that the present prototype system can indeed provide the constant current (CC) and constant voltage (CV) outputs required for lithium battery charging, and the expected variable voltage output achieved by frequency modulation (FM) is verified. Its maximum efficiency can approach 91.3%. Compared with other wireless charging systems with single-switch inverters, this prototype experimental system possesses significant advantages in completing the full charging process of lithium batteries, maintaining stable voltage output during the constant voltage phase, and enabling flexible multi-voltage output. Full article

As a form of long-term asset allocation, pension fund investment necessitates accurate estimation of both asset returns and associated risks over extended time horizons. However, long-term asset returns are significantly influenced by macroeconomic factors, whereas variance-based risk measures cannot account for the directional nature of deviations from expected returns. To address these issues, we propose a novel CVaR-based Black–Litterman model incorporating macroeconomic cycle views (CVaR-BL-MCV) for optimal asset allocation of pension funds. This approach integrates macroeconomic cycle dynamics to quantify their impact on asset returns and utilizes Conditional Value-at-Risk (CVaR) as a coherent measure of downside risk. We employ a Markov-switching model to identify and forecast the phases of economic and monetary cycles. By analyzing the economic cycle with PMI and CPI, economic conditions are categorized into three distinct phases: stable, transitional, and overheating. Similarly, by analyzing the monetary cycle with M2 and SHIBOR, monetary conditions are classified into expansionary and contractionary phases. Based on historical asset return data across these cycles, view matrices are constructed for each cycle state. CVaR is used as the risk measure, and the posterior distribution of the Black–Litterman (BL) model is derived via generalized least squares (GLS), thereby extending the traditional BL framework to a CVaR-based approach. The experimental results demonstrate that the proposed CVaR-BL-MCV model outperforms the benchmark models. When the risk aversion coefficient is 1, 1.5, and 3, the Sharpe ratio of pension asset allocation using the CVaR-BL-MCV model is 21.7%, 18.4%, and 20.5% higher than that of the benchmark models, respectively. Moreover, the BL model incorporating CVaR improves the Sharpe ratio of pension asset allocation by an average of 19.7%, while the BL model with MCV achieves an average improvement of 14.4%. Full article

The phase transitions and switching dynamics of topological polar textures in hafnium oxide (HfO₂)-based cylindrical-shell ferroelectrics are studied using a three-dimensional (3D) phase field model based on the self-consistent solution of the time-dependent Ginzburg–Landau model and Poisson equation. The comprehensive interplays of bulk free energy, gradient energy, depolarization energy, and elastic energy are taken into account. When a cylindrical ferroelectric device is biased under the in-plane radial electric field, there is a size-controlled phase transition between the ferroelectric (FE), antiferroelectric (AFE), and paraelectric (PE) phases, depending on ferroelectric film thickness and cylindrical shell radius. For in-plane polarization textures at the equilibriums, the FE phase has a Néel-like texture with a center-type four-quad domain, the AFE phase has a monodomain texture, and the PE phase has a Bloch-like texture with a vortex four-quad domain. These polarization domain textures are resultant from energy competition and topologically protected by the geometrical confinement. The polarization dynamics from polar states towards equilibriums are analyzed considering the separated contributions of x- and y-components of polarizations that are driven by x-y in-plane electric fields. The emergent topological domains and phase transitions provide guidelines for geometrical engineering of a novel nano-structured ferroelectric device that is different from the planar one, offering new possibilities for multi-functional high-density ferroelectric memory. Full article

Silicon carbide (SiC) three-phase converters are widely adopted in parallel power distribution systems for their high efficiency, yet their performance is challenged by high switching frequency and communication constraints. For the parallel inverter system, problems such as uneven power distribution and circulating current may occur. Therefore, the droop control method was proposed. The droop control method is limited in precise power sharing and circulating current mitigation. To address these issues in the communication-free parallel inverter system, a hybrid droop-enhanced virtual impedance method is proposed. The methodology integrates droop characteristics with frequency-selective virtual impedance compensation, enabling concurrent optimization of power sharing and circulating current suppression. Through simulation, the droop control method and the improved droop control method were compared and analyzed. Finally, the effectiveness of the improved droop control method was verified through experiments. Full article
