Search Results (23)

Search Parameters:
Keywords = rear wing aerodynamics

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
47 pages, 11612 KB
Article
Experimental and Numerical Investigation of an Integrated Fan-Driven Co-Flow Jet System for a High-Performance Automotive Rear Wing
by Marco Robert Herberg, Guglielmo Luca Bambino, Stefano De Pinto, Giuseppe Pascazio and Marco Donato de Tullio
Fluids 2026, 11(6), 161; https://doi.org/10.3390/fluids11060161 - 22 Jun 2026
Viewed by 166
Abstract
This study investigates the application of the Co-Flow Jet (CFJ) active flow-control methodology to an automotive rear wing through a combined CFD and experimental campaign conducted on a modified McLaren 765LT. The work evaluates the aerodynamic response, energy performance, and practical integration of [...] Read more.
This study investigates the application of the Co-Flow Jet (CFJ) active flow-control methodology to an automotive rear wing through a combined CFD and experimental campaign conducted on a modified McLaren 765LT. The work evaluates the aerodynamic response, energy performance, and practical integration of embedded Co-Flow systems under representative on-track conditions. An extensive CFD design campaign assessed multiple Co-Flow architectures, from which three representative configurations incorporating embedded ducted axial fans were selected for experimental testing. The results indicate that aerodynamic performance is strongly influenced by the interaction between momentum injection, vehicle conditions, and duct architecture. The most effective configuration achieved drag reductions of up to 9% together with downforce increases of approximately 15% under highly loaded conditions, significantly exceeding the repeatability levels of the measurements. The efficiency analysis further showed that, under selected operating conditions, the aerodynamic benefits obtained from the Co-Flow system can exceed the electrical power required by the actuation system. However, increased mass-flow capability alone was not found to guarantee improved aerodynamic performance or efficiency. The results demonstrate the successful integration and operation of a fan-driven Co-Flow system on a production-based vehicle and highlight the importance of momentum injection level and duct design. The findings should be interpreted within the scope of the investigated vehicle and operating envelope. Due to confidentiality constraints, part of the absolute aerodynamic data could not be disclosed, and the results are therefore presented primarily as relative variations. Full article
Show Figures

Figure 1

22 pages, 16377 KB
Article
Effects of Wheel-Ground Conditions on Racing Car Aerodynamics Under Ride-Height-Related Attitude Variations
by Xiaojing Ma, Jie Li, Kun Zhang, Yi Zou and Matteo Massaro
Appl. Sci. 2026, 16(2), 874; https://doi.org/10.3390/app16020874 - 14 Jan 2026
Viewed by 1608
Abstract
In racing cars, a low ride height is crucial for inverted wings and ground-effect systems to function effectively, significantly enhancing aerodynamic performance but also increasing sensitivity to pitch and roll variations. However, the specific impact of wheel-ground conditions on racing cars under ride-height-related [...] Read more.
In racing cars, a low ride height is crucial for inverted wings and ground-effect systems to function effectively, significantly enhancing aerodynamic performance but also increasing sensitivity to pitch and roll variations. However, the specific impact of wheel-ground conditions on racing cars under ride-height-related attitude variations has not received attention. This study employed numerical simulations (compared with wind tunnel test data) to investigate these effects on racecar aerodynamic characteristics, analyzing three specific wheel-ground combinations: moving ground with rotating wheels (MR), moving ground with stationary wheels (MS), and stationary ground with stationary wheels (SS). A systematic analysis was conducted on aerodynamic changes associated with wheel-plane total pressure coefficient differences, upper-lower surface pressure coefficient variations, and front-rear axle aerodynamic force distributions, elucidating individual component contributions to overall performance changes induced by wheel-ground alterations. Results indicate that wheel conditions, especially rear wheels and their localized interactions with the diffuser-equipped body predominantly influence drag. In contrast, ground conditions primarily affect the body and front wing to alter downforce, with induced drag variations further amplifying total drag differences. Moreover, ground conditions’ impact on the front wing is modulated by vehicle attitude, resulting in either increased or decreased front wing downforce and thus altering aerodynamic balance. These insights highlight that ride-height related attitudes are critical variables when evaluating combined wheel-ground effects, and while wheel rotation is significant, the aerodynamic force and balance changes induced by ground conditions (as modulated by attitude) warrant greater attention. This understanding provides valuable guidance for racecar aerodynamic design. Full article
(This article belongs to the Section Fluid Science and Technology)
Show Figures

Figure 1

23 pages, 5673 KB
Article
Numerical Investigation of a Morphing Wing Section Controlled by Piezoelectric Patches
by Mario Rosario Chiarelli, Vincenzo Binante, Salvatore Bonomo, Stefano Botturi, Luca Giani, Jan Kunzmann, Aniello Cozzolino and Diego Giuseppe Romano
Actuators 2025, 14(10), 499; https://doi.org/10.3390/act14100499 - 15 Oct 2025
Cited by 3 | Viewed by 1964
Abstract
One of the tasks of the FutureWings project, funded by the European Commission within the 7th framework, was to numerically validate the mechanical behavior of a wing whose deflections had to be controlled via a suitable distribution of piezoelectric patches. Starting from a [...] Read more.
One of the tasks of the FutureWings project, funded by the European Commission within the 7th framework, was to numerically validate the mechanical behavior of a wing whose deflections had to be controlled via a suitable distribution of piezoelectric patches. Starting from a reference geometry (a NACA 0012 airfoil), wing profiles were implemented and analyzed using the fluid–structure interaction analysis technique. The wing section was designed with a morphing profile in which both the front and rear parts self-deform via piezoelectric patches that serve actuators glued to the skin of the profile. A Macro Fiber Composite (MFC) was used as the piezoelectric actuator. Aeroelastic analyses were performed at low Mach numbers under the sea-level flight condition. Analysis of the technical solution was based on an examination of the aerodynamic coefficients and polar curves of the profile, as the control voltage of the patches can vary. The results were compared with those available in the literature. As a preliminary step, this work contributes to examining the current technical possibilities of this technology relating to the application of piezoelectric patches as actuators in the field of aerostructures. Full article
(This article belongs to the Special Issue Aerospace Mechanisms and Actuation—Second Edition)
Show Figures

Figure 1

25 pages, 21107 KB
Article
CFD Aerodynamic Analysis of Tandem Tilt-Wing UAVs in Cruise Flight and Tilt Transition Flight
by Bin Xiang, Guoquan Tao, Long Jin, Jizheng Zhang and Jialin Chen
Drones 2025, 9(8), 522; https://doi.org/10.3390/drones9080522 - 24 Jul 2025
Cited by 7 | Viewed by 3170
Abstract
The tandem tilt-wing UAV features an advanced aerodynamic layout design and is regarded as a solution for small-scale urban air mobility. However, the tandem wing configuration exhibits complex aerodynamic interactions between the front and rear wings during cruise flight and the wing tilt [...] Read more.
The tandem tilt-wing UAV features an advanced aerodynamic layout design and is regarded as a solution for small-scale urban air mobility. However, the tandem wing configuration exhibits complex aerodynamic interactions between the front and rear wings during cruise flight and the wing tilt transition process. The objective of this paper is to investigate the aerodynamic coupling characteristics between the front and rear wings of the tandem tilt-wing UAV under level flight and tilt transition conditions while also assessing the influence of the propellers on the aircraft’s aerodynamic performance. Through CFD numerical analysis, the aerodynamic characteristics of various aircraft components are examined at different angles of attack and wing tilt angles, and the underlying reasons for the observed differences and variations are explored. The results indicate that, during level flight, the aerodynamic interference between the wings is primarily dominated by the detrimental influence of the front wing on the rear wing. During the tilt transition process, mutual interactions between the front and rear wings occur as wing tilt angle changes, leading to more drastic variations in lift coefficients and increased control difficulty. However, the propeller’s effect contributes to smoother changes in lift and drag, thereby enhancing aircraft stability. Full article
(This article belongs to the Section Drone Design and Development)
Show Figures

Figure 1

18 pages, 13241 KB
Article
Experimental Investigation of Aerodynamic Interaction in Non-Parallel Tandem Dual-Rotor Systems for Tiltrotor UAV
by He Zhu, Yuhao Du, Hong Nie, Zhiyang Xin and Xi Geng
Drones 2025, 9(5), 374; https://doi.org/10.3390/drones9050374 - 15 May 2025
Cited by 7 | Viewed by 2669
Abstract
The distributed electric tilt-rotor Unmanned Aerial Vehicle (UAV) combines the vertical take-off and landing (VTOL) capability of helicopters with the high-speed cruise performance of fixed-wing aircraft, offering a transformative solution for Urban Air Mobility (UAM). However, aerodynamic interference between rotors is a new [...] Read more.
The distributed electric tilt-rotor Unmanned Aerial Vehicle (UAV) combines the vertical take-off and landing (VTOL) capability of helicopters with the high-speed cruise performance of fixed-wing aircraft, offering a transformative solution for Urban Air Mobility (UAM). However, aerodynamic interference between rotors is a new challenge to improving their flight efficiency, especially the dynamic interactions during the transition phase of non-parallel tandem dual-rotor systems, which require in-depth investigation. This study focuses on the aerodynamic performance evolution of the tilt-rotor system during asynchronous transition processes, with an emphasis on quantifying the influence of rotor tilt angles. A customized experimental platform was developed to investigate a counter-rotating dual-rotor model with fixed axial separation. Key performance metrics, including thrust, torque, and power, were systematically measured at various tilt angles (0–90°) and rotational speeds (1500–3500 RPM). The aerodynamic coupling mechanisms between the front and rear rotor disks were analyzed. The experimental results indicate that the relative tilt angle of the dual rotors significantly affects aerodynamic interference between the rotors. In the forward tilt mode, the thrust of the aft rotor recovers when the tilt angle reaches 45°, while in the aft tilt mode, it requires a tilt angle of 75°. By optimizing the tilt configuration, the aerodynamic performance loss of the aft rotor due to rotor-to-rotor aerodynamic interference can be effectively mitigated. This study provides important insights for the aerodynamic performance optimization and transition control strategies of the distributed electric tilt-rotor UAV. Full article
(This article belongs to the Special Issue Dynamics Modeling and Conceptual Design of UAVs)
Show Figures

Figure 1

28 pages, 19837 KB
Article
Computational Fluid Dynamics (CFD)-Enhanced Dynamic Derivative Engineering Calculation Method of Tandem-Wing Unmanned Aerial Vehicles (UAVs)
by Bobo Ye, Juan Li, Jie Li, Chang Liu, Ziyi Wang and Yachao Yang
Drones 2025, 9(4), 231; https://doi.org/10.3390/drones9040231 - 21 Mar 2025
Cited by 1 | Viewed by 2905
Abstract
Dynamic derivatives are critical for evaluating an aircraft’s aerodynamic characteristics, dynamic modeling, and control system design during the design phase. However, due to the multiple iterations of the design phase, a method for calculating dynamic derivatives that balances computational efficiency and accuracy is [...] Read more.
Dynamic derivatives are critical for evaluating an aircraft’s aerodynamic characteristics, dynamic modeling, and control system design during the design phase. However, due to the multiple iterations of the design phase, a method for calculating dynamic derivatives that balances computational efficiency and accuracy is required. This work presents a CFD-enhanced engineering calculation method (CEHM) for calculating tandem-wing UAVs’ dynamic derivatives. A coupling-effect-driven estimation strategy is proposed to incorporate the contribution of the rear wing to the longitudinal dynamic derivatives, and it accounts for the aerodynamic coupling effects between the front and rear wings. To enhance the accuracy of the dynamic derivative calculations, we put forward a dynamic derivative-correction mechanism based on the CFD method. It achieves three types of parameters from the static derivative CFD simulations to enhance accuracy, including parameters for aerodynamic force coefficient fitting, the dynamic pressure ratio, and the upwash and downwash gradients. The CEHM method is applied to compute the dynamic derivatives of the SULA90 tandem-wing UAV, with results compared to those obtained from the traditional engineering estimation tools (XFLR5 and OpenVSP). The simulation experiment results show that the proposed method not only calculates the acceleration derivatives but also provides higher calculation accuracy. To further validate the method’s effectiveness, open-loop model verifications were conducted using field flight test data of the SULA90. The field flight test results show that the CEHM method’s predicted results align closely with the measured flight data. The proposed method calculates dynamic derivatives in seconds, balancing accuracy and computational cost, making it highly suitable for tandem-wing aircraft during the design phase. Furthermore, this approach is generalizable and can be applied to other aircraft configurations. Full article
Show Figures

Figure 1

9 pages, 11334 KB
Proceeding Paper
The Aerodynamic Design of a Compliant Morphing Flap for Next-Generation Hybrid Electric Regional Aircraft
by Francesco Antonio D’Aniello, Pietro Catalano, Domenico Quagliarella and Mauro Minervino
Eng. Proc. 2025, 90(1), 13; https://doi.org/10.3390/engproc2025090013 - 11 Mar 2025
Cited by 2 | Viewed by 1494
Abstract
The focus of this paper is on some of the activities performed by CIRA under the framework of the HERWINGT project (Hybrid Electric Regional Wing Integration Novel Wing Technologies) supported by the Clean Aviation Joint Undertaking and funded by the European Union. The [...] Read more.
The focus of this paper is on some of the activities performed by CIRA under the framework of the HERWINGT project (Hybrid Electric Regional Wing Integration Novel Wing Technologies) supported by the Clean Aviation Joint Undertaking and funded by the European Union. The aim of the project is to design an innovative wing suitable for future hybrid electric regional aircraft (HER) that will contribute to the overall target of reducing fuel burn, CO2, and other GHG emissions by improving aerodynamic efficiency and reducing weight. The aerodynamic design of a high-lift system of wings in the form of a compliant morphing flap is presented in this paper. A morphing flap was designed through CIRA’s in-house-developed evolutionary optimization software employing the SU2 open source RANS flow solver. The required performances can be achieved by a configuration equipped with both flap and droop noses, with flow control applied to mitigate the separation occurring over the rear upper region of the wing section. This has become particularly important for landing performances. Analyses were conducted for a 2D wing section. Requirements for the flow control system in terms of mass flow and maximum extension of the separated region were formulated. Full article
Show Figures

Figure 1

24 pages, 21088 KB
Article
Transonic Aerodynamic Performance Analysis of a CRM Joined-Wing Configuration
by Paul Hanman, Yufeng Yao and Abdessalem Bouferrouk
Fluids 2025, 10(2), 27; https://doi.org/10.3390/fluids10020027 - 25 Jan 2025
Viewed by 3976
Abstract
This study examines the aerodynamic performance of a joined-wing (JW) aircraft design based on the NASA Common Research Model (CRM), aiming to assess its potential for efficient commercial transport or cargo aircraft at transonic speed (Mach 0.85). The CRM wing, optimised for transonic [...] Read more.
This study examines the aerodynamic performance of a joined-wing (JW) aircraft design based on the NASA Common Research Model (CRM), aiming to assess its potential for efficient commercial transport or cargo aircraft at transonic speed (Mach 0.85). The CRM wing, optimised for transonic flight, was transformed into a JW design featuring a high-aspect-ratio main wing. An initial parametric study using the vortex lattice minimum drag panel method identified viable designs. The selected JW configuration, comprising front and rear wings joined by a vertical fin, was analysed using ANSYS Fluent to understand flow interactions and aerodynamic performance. At an angle of attack (AoA) of −1°, the JW design achieved a peak lift-to-drag ratio (L/D) of 17.45, close to the CRM’s peak L/D of 19.64 at 2°, demonstrating competitive efficiency. The JW’s L/D exceeded the CRM’s between AoA −3° and 0.8°, but the CRM performed better above 0.8°, with differences decreasing at a higher AoA. Based on induced drag alone, the JW outperformed the CRM across AoA −3° to 8°, but flow complications restricted its L/D advantage to a small, low AoA range. A strong shock on the vertical fin’s inboard side due to high incoming flow speed delayed shock formation on the main wing near the joint. Optimising the vertical fin shape slightly improved L/D, suggesting potential for further enhancements or that other design factors significantly affect JW performance. This study provides insights into JW aerodynamics at transonic speeds, revealing its potential benefits and challenges compared to the CRM design. Full article
(This article belongs to the Special Issue Drag Reduction in Turbulent Flows, 2nd Edition)
Show Figures

Figure 1

18 pages, 12089 KB
Article
A Study on the Aerodynamic Impact of Rotors on Fixed Wings During the Transition Phase in Compound-Wing UAVs
by Longjin Ai, Haiting Xia, Jianting Yang, Ying He, Weibo Tang, Minglong Fan and Jinwu Xiang
Aerospace 2024, 11(11), 945; https://doi.org/10.3390/aerospace11110945 - 15 Nov 2024
Cited by 6 | Viewed by 2300
Abstract
Compound-wing unmanned aerial vehicles (UAVs) are highly valued for their performance. However, during the transition from vertical take-off to the cruise phase, the rotor wake can be coupled with the fixed wing. In this study, the aerodynamic effects of a DJI 9450 rotor [...] Read more.
Compound-wing unmanned aerial vehicles (UAVs) are highly valued for their performance. However, during the transition from vertical take-off to the cruise phase, the rotor wake can be coupled with the fixed wing. In this study, the aerodynamic effects of a DJI 9450 rotor on a NACA2415 fixed wing during transition were investigated using the computational fluid dynamics (CFD) method. The rotor-to-wing distances (R/L = 0.25, 0.5, and 0.9) were varied to analyze their impact on aerodynamic performance. The results show that increasing the distance between the front rotor and the fixed wing enhances the lift and drag of the fixed wing, while increasing the distance between the rear rotor and the fixed wing decreases the lift and drag of the fixed wing. During the rotor’s rotation, the fluctuation in the lift and drag of the fixed wing changes periodically due to the rotor wake, and the smaller the distance between the rotor and the fixed wing, the larger the fluctuation. When R/L = 0.25, the fluctuation of the fixed wing is minimized. Compound-wing UAVs with rotors mounted at R/L = 0.25 during the design stage can improve the flight stability during the transition phase in UAVs. Full article
(This article belongs to the Section Aeronautics)
Show Figures

Figure 1

23 pages, 22829 KB
Article
A Physics- and Data-Driven Study on the Ground Effect on the Propulsive Performance of Tandem Flapping Wings
by Ningyu Duan, Chao Wang, Jianyou Zhou, Pan Jia and Zheng Zhong
Aerospace 2024, 11(11), 904; https://doi.org/10.3390/aerospace11110904 - 3 Nov 2024
Cited by 4 | Viewed by 3543
Abstract
In this paper, we present a physics- and data-driven study on the ground effect on the propulsive performance of tandem flapping wings. With numerical simulations, the impact of the ground effect on the aerodynamic force, energy consumption, and efficiency is analyzed, revealing a [...] Read more.
In this paper, we present a physics- and data-driven study on the ground effect on the propulsive performance of tandem flapping wings. With numerical simulations, the impact of the ground effect on the aerodynamic force, energy consumption, and efficiency is analyzed, revealing a unique coupling effect between the ground effect and the wing–wing interference. It is found that, for smaller phase differences between the front and rear wings, the thrust is higher, and the boosting effect due to the ground on the rear wing (maximum of 12.33%) is lower than that on a single wing (maximum of 43.83%) For a larger phase difference, a lower thrust is observed, and it is also found that the boosting effect on the rear wing is above that on a single wing. Further, based on the bidirectional gate recurrent units (BiGRUs) time-series neural network, a surrogate model is further developed to predict the unsteady aerodynamic characteristics of tandem flapping wings under the ground effect. The surrogate model exhibits high predictive precision for aerodynamic forces, energy consumption, and efficiency. On the test set, the relative errors of the time-averaged values range from −4% to 2%, while the root mean squared error of the transient values is less than 0.1. Meanwhile, it should be pointed out that the established surrogate model also demonstrates strong generalization capability. The findings contribute to a comprehensive understanding of the ground effect mechanism and provide valuable insights for the aerodynamic design of tandem flapping-wing air vehicles operating near the ground. Full article
(This article belongs to the Section Aeronautics)
Show Figures

Figure 1

14 pages, 6782 KB
Article
Aerodynamic Performance Assessment of Distributed Electric Propulsion after the Wing Trailing Edge
by Yao Lei and Xiangzheng Zhao
Appl. Sci. 2024, 14(1), 280; https://doi.org/10.3390/app14010280 - 28 Dec 2023
Cited by 2 | Viewed by 3293
Abstract
Distributed electric propulsion (DEP) with four propellers distributed along the rear edge of the wing (pusher DEP configuration) promote aerodynamic interactions to a higher level. To study the aerodynamic performance of DEP with the rear wing through simulations and experiments, the multi-reference frame [...] Read more.
Distributed electric propulsion (DEP) with four propellers distributed along the rear edge of the wing (pusher DEP configuration) promote aerodynamic interactions to a higher level. To study the aerodynamic performance of DEP with the rear wing through simulations and experiments, the multi-reference frame (MRF) with sliding grid is combined with wind tunnel tests. The obtained results demonstrate that the lift and drag of DEP increase with the angle of attack (AoA) and are related to the relative position of the propellers and wing. The propeller has no significant effect on the lift of the wing, and the lift and the AoA remain linear when the AoA is less than 16°. By contrast, the lift coefficient is much higher than the baseline (isolated wing), and the lift is greatly improved with the increasing drag when the AoA is greater than 16°. This is because the flow around the wing of the pusher configuration remains attached due to the suction of the inflow of the propeller on the trailing edge vortex. In addition, the acceleration effect on the free flow improves the kinetic energy of the airflow, which effectively delays the separation of the airflow in the slipstream region. Full article
(This article belongs to the Special Issue Application of Aerodynamics in Aerospace)
Show Figures

Figure 1

27 pages, 5869 KB
Article
On the Benefits of Active Aerodynamics on Energy Recuperation in Hybrid and Fully Electric Vehicles
by Petar Georgiev, Giovanni De Filippis, Patrick Gruber and Aldo Sorniotti
Energies 2023, 16(15), 5843; https://doi.org/10.3390/en16155843 - 7 Aug 2023
Cited by 7 | Viewed by 5869
Abstract
In track-oriented road cars with electric powertrains, the ability to recuperate energy during track driving is significantly affected by the frequent interventions of the antilock braking system (ABS), which usually severely limits the regenerative torque level because of functional safety considerations. In high-performance [...] Read more.
In track-oriented road cars with electric powertrains, the ability to recuperate energy during track driving is significantly affected by the frequent interventions of the antilock braking system (ABS), which usually severely limits the regenerative torque level because of functional safety considerations. In high-performance vehicles, when controlling an active rear wing to maximize brake regeneration, it is unclear whether it is preferable to maximize drag by positioning the wing into its stall position, to maximize downforce, or to impose an intermediate aerodynamic setup. To maximize energy recuperation during braking from high speeds, this paper presents a novel integrated open-loop strategy to control: (i) the orientation of an active rear wing; (ii) the front-to-total brake force distribution; and (iii) the blending between regenerative and friction braking. For the case study wing and vehicle setup, the results show that the optimal wing positions for maximum regeneration and maximum deceleration coincide for most of the vehicle operating envelope. In fact, the wing position that maximizes drag by causing stall brings up to 37% increased energy recuperation over a passive wing during a braking maneuver from 300 km/h to 50 km/h by preventing the ABS intervention, despite achieving higher deceleration and a 2% shorter stopping distance. Furthermore, the maximum drag position also reduces the longitudinal tire slip power losses, which, for example, results in a 0.4% recuperated energy increase when braking from 300 km/h to 50 km/h in high tire–road friction conditions at a deceleration close to the limit of the vehicle with passive aerodynamics, i.e., without ABS interventions. Full article
(This article belongs to the Section E: Electric Vehicles)
Show Figures

Figure 1

26 pages, 59698 KB
Article
Potential Propulsive and Aerodynamic Benefits of a New Aircraft Concept: A Low-Speed Experimental Study
by Pedro D. Bravo-Mosquera, Hernán D. Cerón-Muñoz and Fernando M. Catalano
Aerospace 2023, 10(7), 651; https://doi.org/10.3390/aerospace10070651 - 20 Jul 2023
Cited by 12 | Viewed by 6928
Abstract
The aerodynamic design of a new aircraft concept was investigated through subsonic wind-tunnel testing using 1:28-scale powered models. The aircraft configuration integrates a box-wing layout with engines located at the rear part of the fuselage. Measurements involved a back-to-back comparison between two aircraft [...] Read more.
The aerodynamic design of a new aircraft concept was investigated through subsonic wind-tunnel testing using 1:28-scale powered models. The aircraft configuration integrates a box-wing layout with engines located at the rear part of the fuselage. Measurements involved a back-to-back comparison between two aircraft models: a podded version whose engines were assembled on pylons and a boundary-layer ingestion (BLI) version that provided several system-level benefits. The flowfield was investigated through the power balance method and a variety of pressure flowfield and inlet flow distortion metrics. The results proved that the BLI configuration enhances the propulsive efficiency by reducing both the electrical power coefficient and the kinetic energy waste due to lower jet velocities. Furthermore, there was a reduction of the total pressure recovery due to pressure gradients inside the duct, thereby causing high distortion. Overall, this research highlights the importance of wind-tunnel testing to bring any aerodynamic technology to a sufficient level of maturity and to enable future new aircraft concepts. Full article
(This article belongs to the Special Issue Flight Dynamics, Control & Simulation)
Show Figures

Figure 1

17 pages, 5711 KB
Article
Experimental Study of Vertical Tail Model Flow Control Based on Oscillating Jet
by Xingyu Cao, Hao Dong, Yunsong Gu, Keming Cheng and Fan Zhang
Appl. Sci. 2023, 13(2), 786; https://doi.org/10.3390/app13020786 - 5 Jan 2023
Cited by 7 | Viewed by 2717
Abstract
In this paper, wind tunnel experiments are conducted to study the control law and mechanism of oscillating jet flow control to improve the aerodynamic characteristics of the vertical tail when a civil aircraft encounters left side gust or significant crosswind during takeoff and [...] Read more.
In this paper, wind tunnel experiments are conducted to study the control law and mechanism of oscillating jet flow control to improve the aerodynamic characteristics of the vertical tail when a civil aircraft encounters left side gust or significant crosswind during takeoff and landing. We measured the vertical tail scaling model’s aerodynamics, spatial flow field, and surface pressure when the Reynolds number was 2.12 × 105. The maximum momentum coefficient of the oscillating jet actuator reaches 0.332%. In addition, we studied the flow control effect of the three-dimensional vertical tail scaled model in different spanwise positions. The experimental results show that the oscillating jet at the rear edge of the stabilizer can significantly increase the lateral force of the vertical tail, and the increment of the lateral force can reach 36.5% under the worst condition of the negative side slip angle of the vertical tail. We can improve the lateral force coefficient of the vertical tail model by applying flow control alone at different spanwise locations. The wing root’s control effect and the vertical tail’s middle section are better than the wing tip’s. The oscillating jet can effectively restrain the flow separation on the rudder. In addition, the input of a high-energy jet “ejects” the mainstream, which increases the flow velocity at the side of the vertical tail actuator. It increases the circulation of the vertical tail. The oscillating jet flow control technology can effectively improve the vertical tail’s steering efficiency and increase the vertical tail’s lateral force, which is of great significance in improving the safety and economy of civil aircraft. Full article
Show Figures

Figure 1

28 pages, 12102 KB
Article
Influence of Aerodynamic Interaction on Performance of Contrarotating Propeller/Wing System
by Zhitao Zhang, Changchuan Xie, Kunhui Huang and Chao Yang
Aerospace 2022, 9(12), 813; https://doi.org/10.3390/aerospace9120813 - 10 Dec 2022
Cited by 6 | Viewed by 2985
Abstract
This paper gives a quantitative account of the influence of slipstream on the aerodynamic performance of a contrarotating propeller (CRP)/wing system, and compares it with the CRP and clean wing. To accurately evaluate the complex aerodynamic interaction, the unsteady Reynolds-averaged Navier–Stokes approach using [...] Read more.
This paper gives a quantitative account of the influence of slipstream on the aerodynamic performance of a contrarotating propeller (CRP)/wing system, and compares it with the CRP and clean wing. To accurately evaluate the complex aerodynamic interaction, the unsteady Reynolds-averaged Navier–Stokes approach using the sliding mesh method is performed at a typical freestream velocity of 30 m/s. Four different critical parameters, including the freestream angle of attack (AoA), axial spacing between the front propeller (FP) and rear propeller (RP), number of blades, and rotational speed, are considered in the present work. The results show that the thrust coefficient, power coefficient, and propulsion efficiency of the CRP/wing system change sharply and the difference in amplitude between adjacent waves is large. In particular, the propeller slipstream has a significant impact on the lift–drag performance of the wing in the case of a nonzero AoA. The presence of a wing also increases the efficiency of propulsion due to the recovery of vortices. In the case of a small axial spacing, the thrust coefficient value of the FP is significantly smaller than that of the RP. However, when the axial spacing exceeds a certain value, the opposite relationship is obtained. When the rotational speed increases from 3695 RPM to 8867 RPM, the lift coefficient and drag coefficient of the wing gradually increase. Full article
(This article belongs to the Section Aeronautics)
Show Figures

Figure 1
