Zinc oxide (ZnO) is currently one of the most significant wide-bandgap semiconductor materials, attracting extensive research across diverse fields including materials science, chemistry, physics, medicine, electronics, and power engineering. Its exceptional properties, such as high optical transparency, high electron mobility, chemical stability, and compatibility with low-cost fabrication techniques, have established ZnO as a versatile material with immense application potential. A critical application for ZnO is its role as a transparent conducting oxide (TCO) in modern optoelectronic and photovoltaic devices, as well as in sensors, transparent electronics, and spintronics. To meet the requirements of these advanced applications, precise control over the structural, optical, and electrical properties of ZnO thin films is essential. This is effectively achieved through the selection of specific synthesis methods and intentional modification techniques, such as doping. This review provides a comprehensive overview of the synthesis and modification of ZnO thin films, with a particular focus on how various dopants influence their fundamental characteristics. The work discusses a range of deposition techniques, including physical vapor deposition (PVD), chemical vapor deposition (CVD), atomic layer deposition (ALD), sol–gel methods, spray pyrolysis, and other solution-based approaches. The novelty of this review lies in its comparative analysis of different doping strategies combined with various thin-film deposition techniques, highlighting how specific synthesis routes influence dopant incorporation and ultimately determine functional properties. Furthermore, recent advances in tailoring ZnO thin films are summarized, alongside the identification of key challenges and future research directions. Ultimately, this work aims to provide researchers with a systematic perspective on the synthesis–structure–property relationships in doped ZnO thin films to support the development of optimized materials for next-generation electronic and optoelectronic devices. This review, thus, serves as a comprehensive reference for researchers and engineers seeking to optimize the functionality of ZnO-based thin films for emerging technological applications. Full article

In this study, the indium (In) composition in amorphous indium gallium zinc oxide (a-IGZO) thin films was systematically varied from 33% to 84% using a sol–gel process. Subsequently, aluminum/IGZO/aluminum (Al/IGZO/Al) metal–semiconductor–metal (MSM) UV photodetectors were fabricated to investigate the influence of composition on the structural, optical, and photoelectric properties. The results indicate that all films maintain an amorphous structure despite the increasing In content, while the ratio of oxygen vacancies, O_vac/(M-O + O_vac), rises from 36% to 52%. Concurrently, the optical bandgap decreases from 2.92 eV to 2.32 eV. Under a bias of 20 V, the dark current increases from 2.11 × 10⁻⁹ A to 1.90 × 10⁻⁵ A as the In content rises. When illuminated by a 360 nm LED with a power density of 8.6 mW/cm², the device with 60% In exhibits a photocurrent-to-dark-current ratio of approximately 10⁴, a responsivity of 19.45 A/W, and a specific detectivity of 8.19 × 10¹² Jones. The response time and recovery time of this device are 39.8 s and 577.4 s, respectively. These findings reveal a competitive relationship between enhanced optical absorption and defect generation induced by In composition, providing valuable guidance for the performance optimization of a-IGZO UV photodetectors through compositional engineering. Full article

X-ray techniques provide powerful, non-destructive tools for structural characterization in semiconductor manufacturing and advanced packaging. Their strong penetration capability and sensitivity to multiple contrast mechanisms enable the investigation of lattice structure, strain, defects, interfaces, and elemental distribution across a wide range of length scales. As semiconductor devices evolve toward three-dimensional architectures and heterogeneous integration, there is an increasing demand for characterization approaches capable of probing complex, buried, and multi-scale structures in a consistent manner. In this review, we present a systematic overview of X-ray characterization techniques for advanced semiconductor systems, including diffraction-based methods, small-angle scattering, computed tomography, X-ray fluorescence, and spectroscopic approaches. These techniques are discussed in terms of the type of structural, morphological, and compositional information they provide, their applicable length scales, and their strengths and limitations in addressing key challenges such as thin films, high-aspect-ratio structures, buried interfaces, and full wafers. Particular attention is given to the complementary nature of different X-ray modalities and their roles in addressing practical metrology problems. The limitations associated with resolution, model dependence, and data interpretation are also outlined. Finally, emerging opportunities in laboratory X-ray sources, synchrotron-based methods, and integrated characterization strategies are briefly discussed. This review aims to provide a unified perspective for understanding and integrating X-ray techniques, offering insights into their roles in addressing the growing complexity of next-generation semiconductor devices. Full article

Wide-bandgap (WBG) semiconductors are propelling a paradigm shift in advanced power electronics, offering functionality that includes higher-switching-frequency operation with improved efficiency and power density possibilities. Gallium nitride (GaN) exhibits unique material properties that correspond to device parameters beneficial for achieving an improved performance compared to its counterparts. The inception of GaN power semiconductor devices has enabled advanced power electronics to realize efficient and compact power converters. However, the current rating of the devices is constrained, and paralleling of the devices is vital to realize high-currentrated power modules. Furthermore, paralleling of the devices can provide improved cooling results in high-power-density systems. This paper presents a comprehensive review study of the paralleling of GaN devices to discuss the different challenges associated with paralleling. One of the fundamental challenges is associated with the design of a structure for paralleling GaN devices. The parallel device structure consequently impacts the parasitics of the device, which limit the operating switching frequency and thermo-mechanical aspects. Furthermore, power loop inductance, gate loop inductance asymmetry, common-source inductance, gate inductance trace length mismatch, and different challenges lead to design trade-offs and efforts to optimize the design by realizing an appropriate trade-off, considering low-inductance packaging along with thermal strategies, and considering a parallel circuit layout and structure. Considering the recent research trends and studies related to the design of parallel GaN devices, this paper presents future perspectives anticipating the realization of an improved parallel GaN device structure. Full article

High-power-density LEDs can achieve many functions that are difficult for traditional light sources and conventional LEDs to realize, pushing the semiconductor lighting technology chain to a new level. Increasing the number of chips is an effective approach to improving the light output capability of LED devices. In this study, five high-power-density LED devices with different chip numbers (4, 9, 16, 25, and 64 chips) were fabricated using the same blue LED chips, and the effects of chip number on the light output capability, spatial light distribution characteristics, and spatially correlated color temperature distribution characteristics of high-power-density LED devices were systematically investigated. The temperature distribution characteristics of the internal chips were further analyzed in combination with infrared thermal imaging results. The results show that increasing the chip number significantly enhances the total light output capability of the device; however, due to the influence of thermal coupling among chips, the saturation current and saturated luminous intensity of devices with different chip numbers are not proportional to the chip number. Increasing the number of chips in the device does not alter the intrinsic spatial emission pattern. Under optical saturation conditions, the luminous intensity distribution curves of all five devices exhibit Lambertian spatial light distribution characteristics. In terms of correlated color temperature, the CCT of all devices increases with increasing current per chip, and devices with more chips exhibit higher CCT values and a faster increasing trend. The spatial CCT distribution results show that the correlated color temperature of the device reaches its maximum in the normal direction, decreases with increasing testing angle, and exhibits good spatial symmetry. The thermal imaging results show that devices with more chips exhibit higher average chip temperatures and a relatively more uniform temperature distribution, which improves the spatial CCT uniformity of the device to some extent. Full article

Some windowless semiconductor photodiodes can detect not only photons but also charged particles, cover a wide spectral range including a part of the ionizing radiation region and, thus, play important roles for synchrotron radiation experiments. To understand the spectral, angular and polarizing properties of semiconductor photodiodes, complex amplitude coefficients of transmittance or reflectance are calculated based on rigorous formulation using Fresnel equations with complex optical constants of the composing materials, whose validity was verified by comparison with experiments. Concrete examples of the behavior on the complex plane are shown as a function of complex optical constants, film thickness, angle of incidence and the wavelength. The results show that the optical properties of the layered system are sensitive to its layer thickness, the angle of incidence and the wavelength in the ultraviolet region where optical indices of the composing materials steeply change. It has been shown that oblique incidence photodiodes are useful as polarization-sensitive devices, and that the graphical technique using the amplitude coefficients expressed on the complex plane is effective and powerful to search for optimal conditions for complex optical constants, film thickness and/or angle of incidence. Full article

The accelerating adoption of electric vehicles (EVs) is driving the demand for next-generation wide-bandgap (WBG) power devices that can deliver high efficiency, high power density, and robust operation under stringent electrical and thermal stress. Gallium nitride (GaN) high-electron-mobility transistors (HEMTs) have emerged as a leading WBG technology due to their high breakdown voltage, ultrafast switching capability, and low conduction and switching losses relative to silicon devices, enabling high-performance EV power converters such as on-board chargers, DC-DC converters, and traction inverters. This review provides a comprehensive device-level assessment of GaN HEMTs, emphasizing advanced device architectures, state-of-the-art discrete transistors, and their implications for high-frequency, high-efficiency power conversion. Critical performance and reliability challenges, including current collapse, self-heating, and gate degradation, are analyzed in the context of their physical mechanisms and operational behavior under realistic conditions such as elevated junction temperatures, high switching frequencies, and dynamic load profiles. Furthermore, emerging opportunities in ultra-wide-bandgap semiconductor technologies beyond GaN are discussed, providing insights to guide the design, optimization, and robust integration of WBG devices into next-generation EV power electronic systems. Full article

Ohmic contact resistance is a persistent and increasingly dominant bottleneck limiting the practical performance of wide-bandgap (WBG) and ultrawide-bandgap (UWBG) power semiconductor devices. This review provides a comprehensive and comparative treatment of specific contact resistivity (${\rho }_c$) phenomena across five material systems—4H-SiC, GaN, β-Ga₂O₃, AlN/AlGaN, and diamond—spanning fundamental contact physics, characterization methodology, material-specific state of the art, device context, and advanced engineering strategies. A semi-empirical scaling analysis establishes that the minimum achievable ${\rho }_c$ increases by approximately one order of magnitude per 0.8–1.0 eV increase in bandgap, arising from the interplay of Fermi-level pinning, increasing carrier effective mass, and decreasing achievable near-surface doping concentration. The best demonstrated ${\rho }_c$ values range from ~3 × 10⁻⁸ Ω·cm² for GaN epitaxially regrown contacts to ~8 × 10⁻⁵ Ω·cm² for direct AlN metallization. The transition from alloyed to regrown contacts in GaN—delivering two orders of magnitude improvement—is identified as the paradigm model for UWBG contact development, with β-Ga₂O₃ most immediately positioned to follow this trajectory. Key challenges include the absence of p-type doping in β-Ga₂O₃, near-complete Fermi-level pinning in AlN, and the unsolved shallow-donor problem in diamond. Recommendations for standardized ${\rho }_c$ measurement protocols and priority research directions are presented. Full article

Single-crystal 4H-SiC, as a wide-bandgap semiconductor material, has become a key substrate for high-power electronics and radio frequency devices due to its outstanding characteristics such as high-voltage tolerance, high-temperature stability, high-frequency efficiency and low loss. However, its inherent properties of high hardness and low fracture toughness also pose severe challenges to the ultra-precision processing of wafer substrates. In this study, through molecular dynamics methods, the influence of diamond abrasive grains with different sharpness on the processing of 4H-SiC at different grinding speeds was simulated, with a focus on analyzing its surface morphology, material removal behavior and subsurface damage characteristics. The structural evolution of 4H-SiC workpieces and diamond abrasive grains was identified through the radial distribution function, and the dynamic changes in temperature and stress during processing were further investigated to clarify the mechanism of abrasive wear and graphitization phenomena. The results show that regular octahedral abrasive grains with higher sharpness have better material removal efficiency, but they also cause more significant subsurface damage. Increasing the grinding speed helps to reduce the depth of subsurface damage. In addition, high temperature and high stress are the key factors leading to the transformation of diamond into graphite. Even under low-speed grinding conditions, the edges of the abrasive grains may still undergo graphitization due to stress concentration. The above findings have theoretical significance for an in-depth understanding of the material removal mechanism of 4H-SiC nano-grinding, and can also provide an important reference for the development of high-performance grinding wheels for SiC grinding. Full article

Mixed-halide perovskite solar cells with the composition Cs_0.1(MA_0.17FA_0.83)_0.9Pb(I_0.83Br_0.17)₃ were fabricated obtaining solar cells as glass/ITO/SnO₂/triple-cation perovskite/HTL/Au, and subsequently used as photoanodes for efficient solar-driven water splitting by attaching commercial catalytic nickel foils to the Au back-contact pads of solar cells. To enable operation in alkaline media, the devices were encapsulated using commercial PET–EVA multilayer films, providing an effective barrier while leaving the Ni foils exposed as the electrochemically active interface. Two operating configurations were investigated and compared: (i) an outside configuration, where the perovskite device powered the external electrochemical cell, and (ii) an immersed configuration, in which the encapsulated perovskite solar cell was directly integrated, together with the Ni catalyst, into the electrolyte. In both configurations, the onset potential for the oxygen evolution reaction shifted from ~1.32 V vs. RHE, when the Ni electrode was not powered by the perovskite solar cell, to ~0.34 V vs. RHE, when the perovskite device powered the Ni foil for both immersed and outside configurations. The immersed configuration delivered the highest performance, achieving a maximum Applied Bias Photon-to-Current Efficiency of ~20% under AM 1.5 G illumination (100 mW cm⁻²), among the highest values reported for perovskite-based photoanodes. Importantly, the enhanced performance does not arise from changes in catalyst composition or direct semiconductor–electrolyte interaction, but from improved photovoltage delivery and reduced resistive losses enabled by the integrated device architecture. These results demonstrate that device architecture is a key factor in controlling photovoltage utilization and charge-transfer kinetics, providing a viable strategy for efficient and scalable perovskite-based photoelectrochemical systems. Full article

Two-dimensional materials have broad application prospects in the field of optoelectronic devices. As a next-generation power electronic device, AlN materials have obvious advantages in power processing, and their monolayer structure has excellent optoelectronic properties, which is of great significance for the study of 2D AlN monolayers. Properties such as electronic and optical properties of metal-adsorbed AlN (M-AlN) systems have been systematically investigated using density functional theory from first principles. The results of the energy bands of the M-AlN system indicate that the adsorption of Al, Li, Ag, Au, Bi, Cr, Mn, Na, Pb, Sn, Ti, and K metals makes the monolayer AlN magnetic, the incorporation of two metals, Al and Li, is the transition of the monolayer AlN from a semiconductor to a semi-metal, and the introduction of K metal makes the monolayer AlN transition from a semiconductor to a metal. The work function of the M-AlN system shows that the introduction of the metal reduces the work function of the monolayer AlN, especially for K-AlN, which is reduced by 56.12% compared to the monolayer AlN. In addition, the results of the optical absorption spectra of the M-AlN system revealed that the introduction of the metals made the monolayer AlN exhibit high absorption peaks in the visible and near-infrared regions; in particular, the intensity of the absorption peaks of the Ti-AlN system at 557.8 nm reached 7.4 × 10⁴ cm⁻¹ and the intensity of the absorption peaks of the K-AlN system at 1109.3 nm reached 1.01 × 10⁵ cm⁻¹. This indicates that the introduction of Ti and K metal atoms enhances the absorption properties of monolayer AlN in the visible and near-infrared regions. Finally, the time-domain finite difference using spherical metal nanoparticles is used to excite the localized surface plasmon resonance, and the results show a small area of strong electric field around the electric field hotspot of Cr and Li particles, and a good concentration of the electric field strength in the x and y directions. In summary, the system of metal atoms adsorbed on AlN will be favorable for the design of spintronics, field-emitting devices and solar photovoltaic devices. Full article

Over the past two decades, organic semiconductors have attracted significant research interest due to their advantageous features, including low-cost fabrication, lightweight properties, and portability, for photonic device applications. In this study, nickel sulfide doped with cobalt $(\mathrm{N}\mathrm{i}\mathrm{S}/\mathrm{C}\mathrm{o})$ nanocomposites were successfully synthesized via a wet-chemical processing technique and used as a dopant in the active layer of thin-film organic solar cells (TFOSCs). The poly(3-hexylthiophene) (P3HT) and [6,6]-phenyl-C61-butyric acid methyl ester (PC61BM) blend was used as the active layer in this investigation. The devices were fabricated with $\mathrm{N}\mathrm{i}\mathrm{S}/\mathrm{C}\mathrm{o}$ nanocomposites at 1 wt%, 2 wt%, and 3 wt% in the active layer to determine the optimal dopant concentration. However, the experimental evidence clearly showed that the solar cell’s performance depends on the concentration of the $\mathrm{N}\mathrm{i}\mathrm{S}/\mathrm{C}\mathrm{o}$ nanocomposites. As a result, the highest power conversion efficiency (PCE) recorded in this experimental work was 6.11% at a 1% doping concentration, compared with 2.48% for the pristine reference device under AM 1.5G illumination (100 mW/cm²) in ambient conditions. The optical and electrical properties of the active layers are found to be strongly influenced by the inclusion of $\mathrm{N}\mathrm{i}\mathrm{S}/\mathrm{C}\mathrm{o}$ nanocomposites in the medium. However, the device doped with 1 wt% $\mathrm{N}\mathrm{i}\mathrm{S}/\mathrm{C}\mathrm{o}$ nanocomposite exhibits the highest absorption intensity, consistent with the better performance observed in this study, which can be attributed to the localized surface plasmon resonance (LSPR) effect. The optical and morphological characteristics of the synthesized $\mathrm{N}\mathrm{i}\mathrm{S}/\mathrm{C}\mathrm{o}$ nanocomposites were comprehensively analyzed using high-resolution transmission electron microscopy (HRTEM), high-resolution scanning electron microscopy (HRSEM), and additional complementary techniques. Full article

To satisfy the requirements of voltage support and fault-current limitation for electric-vehicle (EV) charging stations connected to weak distribution networks, an increasing number of charging infrastructures are adopting grid-forming (GFM) converters and vehicle-to-grid (V2G) control strategies. Under AC short-circuit faults and voltage-sag conditions, limiting the fault current injected by the converter is essential to reduce overcurrent risk to power semiconductor devices. For this, an adaptive virtual-impedance-based low-voltage ride-through (LVRT) method is proposed for GFM converters in EV charging stations. First, an overcurrent grading criterion is constructed based on real-time current measurements. In the moderate-overcurrent region, an adaptive virtual reactance is introduced to achieve soft current limiting. In the severe-overcurrent region, hard current limiting is implemented by further increasing the virtual reactance and blocking overcurrent bridge arm. In addition, a virtual-reactance recovery mechanism is designed to ensure smooth post-fault restoration. Based on an RCP + HIL platform, experiments are conducted to validate the proposed fault current-limiting method. Experiment results demonstrate that the proposed method can rapidly suppress fault current, maintain voltage-support capability, and shorten post-fault restoration time. Full article

Wide bandgap (WBG) semiconductors such as gallium nitride (GaN) and silicon carbide (SiC) have revolutionized modern power electronics by enabling devices that operate at higher voltages, temperatures, and switching frequencies than their silicon counterparts. This paper reviews the material properties, device architectures, fabrication techniques, and thermal management strategies that underpin the performance of GaN and SiC technologies. We highlight key trade-offs between GaN and SiC in terms of voltage blocking capability, switching efficiency, and thermal robustness and discussed their application in electric vehicles, renewable energy systems, and power converters. Market adoption trends and manufacturing challenges are also analyzed, with attention to cost-performance dynamics and packaging innovations. Finally, we address the critical role of thermal boundary resistance and emerging reliability solutions, providing a perspective on the future trajectory of WBG device research and commercialization. Full article

Junction spectroscopy techniques (JSTs) are powerful tools for investigating electrically active defects in semiconductors. Originally developed to study point-like defects in bulk semiconductors, JSTs have since been extended to increasingly complex systems, providing valuable insights into defect energetics and interactions. This review paper outlines the fundamental principles of JSTs and critically examines their application to emerging materials, such as perovskite solar cells and two-dimensional (2D) materials. By highlighting both the capabilities and limitations of JSTs in these non-classical systems, the review demonstrates their continued relevance and important role in advancing next-generation semiconductor materials and devices. Full article
