“If one could ever prove the existence of gravitational waves, the processes responsible for their generation would probably be much more curious and interesting than even the waves themselves.” (Gustav Mie, 1868–1957). The discovery of gravitational waves has opened new windows on astrophysics, cosmology and physics beyond the Standard Model (BSM). Measurements by the LIGO, Virgo and KAGRA Collaborations of stellar–mass binaries and neutron star mergers have shown that gravitational waves travel at close to the velocity of light and constrain BSM possibilities, such as a graviton mass and Lorentz violation in gravitational wave propagation. Follow-up measurements of neutron star mergers have provided evidence for the production of heavy elements, possibly including some essential for human life. The gravitational waves in the nanoHz range observed by Pulsar Timing Arrays (PTAs) may have been emitted by supermassive black hole binaries, but might also have originated from BSM cosmological scenarios such as cosmic strings, or phase transitions in the early Universe. The answer to the question in the title may be provided by gravitational-wave detectors at higher frequencies, such as LISA and atom interferometers. KCL-PH-TH/2024-05. Full article

As the primary electronic payload of laser interferometry system for space gravitational wave detection, the core function of the phasemeter is ultra-high precision phase measurement. According to the principle of laser heterodyne interferometry and the requirement of 1 pm ranging accuracy of the phasemeter, the phase measurement noise should reach 2π μrad/Hz^1/2@(0.1 mHz–1 Hz). The heterodyne interference signal first passes through the quadrant photoelectric detector (QPD) to achieve photoelectric conversion, then passes through the analog-to-digital converter (ADC) to achieve analog and digital conversion, and finally passes through the digital phase-locked loop (DPLL) for phase locking. The sampling timing jitter of the heterodyne interference signal caused by the ADC is the main noise affecting the phase measurement performance and must be suppressed. This paper proposes a sampling timing jitter noise suppression system (STJNSS), which can set system parameters for high-frequency signals used for inter-satellite clock noise transmission, the system clock of the phasemeter, and the pilot frequency for suppressing ADC sampling timing jitter noise, meeting the needs of the current major space gravitational wave detection plans. The experimental results after the integration of SJNSS and the phase meter show that the phase measurement noise of the heterodyne interferometer signal reaches 2π μrad/Hz^1/2@(0.1 mHz–1 Hz), which meets the requirements of space gravitational wave missions. Full article

The dominant low-light object detectors face the following spectral trilemma: (1) the loss of high-frequency structural details during denoising, (2) the amplification of low-frequency illumination distortion, and (3) cross-band interference in multi-scale features. To resolve these intertwined challenges, we present UMFNet—a frequency-guided detection framework that unifies adaptive frequency distillation with inter-band attention coordination. Our technical breakthroughs manifest through three key innovations: (1) a frequency-adaptive fusion (FAF) module employing learnable wavelet kernels (16–64 decomposition basis) with dynamic SNR-gated thresholding, achieving an 89.7% photon utilization rate in ≤1 lux conditions—2.4× higher than fixed-basis approaches; (2) a spatial-channel coordinated attention (SCCA) mechanism with dual-domain nonlinear gating that reduces high-frequency hallucination by 37% through parametric phase alignment (verified via gradient direction alignment coefficient ${\rho }_G$ = 0.93); (3) a spectral perception loss combining the frequency-weighted structural similarity index measure (SSIM) with gradient-aware focal modulation, enforcing physics-constrained feature recovery. Extensive validation demonstrates UMFNet’s leadership: 73.1% mAP@50 on EXDark (+6.4% over YOLOv8 baseline), 58.7% on DarkFace (+3.1% over GLARE), and 40.2% on thermal FLIR ADAS (+9.7% improvement). This work pioneers a new paradigm for precision-critical vision systems in photon-starved environments. Full article

Wideband radar is becoming increasingly significant in modern radar systems. However, traditional monopulse angle estimation techniques are not suitable for wideband targets exhibiting range extension effects. To address this, we explore the angle estimation problem for wideband Linear Frequency-Modulated (LFM) signals and propose a new monopulse angle estimation algorithm tailored for range-spread targets. In this paper, the phase of the highest energy scatterer is used as the reference to compensate for the phases of other scatterers. The compensated scatterers are then accumulated for energy focusing. Finally, the angle of the energy-focused signal is estimated using the sum-and-difference amplitude comparison method. The proposed method can effectively focus the scatterers’ energy. Moreover, since the echo of a range-spread target can be regarded as the sum of sinusoids with different frequencies, scatterer energy focusing can effectively improve the performance of the detector. To further demonstrate the practicality of the proposed angle estimation method, it is combined with the detector to evaluate its performance. Simulation results comparing the proposed method with other approaches validate its effectiveness and demonstrate that it achieves a lower signal-to-noise ratio (SNR) threshold and higher angular accuracy. Through the proposed method, tracking and imaging can be achieved entirely within the wideband radar framework. The proposed method can also be extended to other sensor systems, advancing the development of sensor technologies. Full article

This paper presents a combined theoretical and experimental method for noise suppression in the repetition frequency (f_r) locking of erbium-doped fiber optical frequency combs (OFCs). This study proposed a novel mathematical model to bridge the noise relationship of f_r between the free-running and locked modes, and analyzed this relationship from two perspectives: the additional phase noise and the frequency stability. In addition, to integrate theoretical modeling with experimental validation, this study designed f_r locking strategy that uses a phase-locked loop (PLL) with PFD + PIID (a phase frequency detector and a proportional, first-order integer, second-order integer, first-order differential controller). Under synchronization of the f_r with a microwave reference (REF), this study achieved OFC additional frequency stabilities of 2.81 × 10⁻¹⁵@1 s and 8.08 × 10⁻¹⁹@10,000 s at 200 MHz fundamental frequency locking and 4.25 × 10⁻¹⁶@1 s and 1.91 × 10⁻¹⁹@10,000 s at 1200 MHz harmonic locking. The simulated and experimental results are in good agreement, confirming the consistency of the theoretical model and experiment. This work provides a reliable theoretical model that can be used to predict stability for OFC locking and significantly improves the additional frequency stability of OFCs. Full article

Microwave sources based on ultrastable lasers and optical frequency combs (OFCs) exhibit ultralow phase noise and ultrahigh-frequency stability, which are important for many applications. Herein, we present a microwave source that is phase-locked to an ultrastable continuous-wave laser, with a relative frequency instability of 7 × ${10}^{-16}$ at 1 s. An Er:fiber-based OFC and an optic-to-electronic converter with low residual noise are employed to confer optical frequency stability on the 9.6 GHz microwave signal. Instead of using the normal cascaded Mach–Zehnder interferometer method, we developed a microwave regeneration method for converting optical pulses into microwave signals to further suppress the additional noise in the optic-to-electronic conversion process. The microwave regeneration method employs an optical-to-microwave phase detector based on a fiber-based Sagnac loop to produce the error signal between a 9.6 GHz dielectric resonator oscillator (DRO) and the OFC. The 9.6 GHz microwave (48th harmonic of the comb’s repetition rate) signal with the frequency stability of the ultrastable laser was achieved using a DRO that was phase-locked to the optical comb. Preliminary evaluations showed that the frequency instability of the frequency synthesizer from the optical to the 9.6 GHz microwave signal was approximately 2 × ${10}^{-15}$ at 1 s, the phase noise was $-106$ dBc Hz⁻¹ at 1 Hz, and the timing noise was approximately 9 as Hz^−1/2 (phase noise approx. $-125$ dBc Hz⁻¹). The 9.6 GHz signal from the photonic microwave source exhibited a short-term relative frequency instability of 2.1 × ${10}^{-15}$ at 1 s, which is 1.5 times better than the previous results. Full article

Microwave phase detectors (MPDs) are key components of instantaneous frequency measurement (IFM) receivers and phase interferometer direction finding (PIF-DF) receivers. In conventional analyses, there is seldom a major quantitative discussion of MPD characterization when multiple signals arrive at the same time, which is often the case in complex and noisy electromagnetic environments. We have reanalyzed the characteristics of MPDs with respect to filter effects acting on more than two RF signals and differential amplifiers, which are not considered in conventional analyses. First, a step-by-step mathematical model of the signal flow is developed, which creates a cross term between the two signals and naturally introduces intermodulation effects. Second, the new response characteristics of the MPD are evaluated by simulation. Finally, the intermodulation effects of zero-forcing and extreme-forcing were found simultaneously in the crosspoint frequency and near-frequency regions of multiple signals, which led to significant deviations and errors in the output of the MPD. This effect may have significant implications for IFM and PIF-DF receivers. Full article

Sea surface target detectors are often interfered by various complex sea surface factors such as sea clutter. Especially when the signal-to-clutter ratio (SCR) is low, it is difficult to achieve high-performance detection. This paper proposes a triple-channel network model for maritime target detection based on the method of multi-modal data fusion. This method comprehensively improves the traditional multi-channel inputs by extracting highly complementary multi-modal features from radar echoes, namely, time-frequency image, phase sequence and correlation coefficient sequence. Appropriate networks are selected to construct a triple-channel network according to the internal data structure of each feature. The three features are utilized as the input of each network channel. To reduce the coupling between multi-channel data, the SE block is introduced to optimize the feature vectors of the channel dimension and improve the data fusion strategy. The detection results are output by the false alarm control unit according to the given probability of false alarm (PFA). The experiments on the IPIX datasets verify that the performance of the proposed detector is better than the existing detectors in dealing with complex ocean scenes. Full article

This article reports a 110.2 MHz ultra-low-power phase-locked loop (PLL) for MEMS timing/frequency reference oscillator applications. It utilizes a 6.89 MHz MEMS-based oscillator as an input reference. An ultra-low-power, high-resolution phase-frequency detector (PFD) is utilized to achieve low-noise performance. Eliminating the reset feedback path used in conventional PFDs leads to dead/blind zone-free phase characteristics, which are crucial for low-noise applications within a wide operating frequency range. The PFD operates up to 2.5 GHz and achieves a linear resolution of 100 ps input time difference ($\Delta t_{in}$), without the need for any additional calibration circuits. The linearity of the proposed PFD is tested over a phase difference corresponding to aa $\Delta t_{in}$ ranging from 100 ps to 50 ns. At a 1 V supply voltage, it shows an error of <±1.6% with a resolution of 100 ps and a frequency-normalized power consumption ($P_n$) of 0.106 pW/Hz. The PLL is designed and fabricated using a TSMC 65 nm CMOS process instrument and interfaced with the MEMS-based oscillator. The system reports phase noises of −106.21 dBc/Hz and −135.36 dBc/Hz at 1 kHz and 1 MHz offsets, respectively. It consumes 6.709 $\mathsf{\mu }$W at a 1 V supply and occupies an active CMOS area of 0.1095 mm². Full article

An extreme step-down ratio buck converter is proposed using a double step-down (DSD) buck converter architecture and a single time-based current mode PWM controller able to generate two non-overlapping control signal phases. Current sampling for two inductors is implemented with a multiplexer and a pair of VCOs only, which treats the two inductors as one inductor operating at double the frequency. This is achieved without the use of any large external passive components in the controller while remaining stable. The type-II time-based controller uses a VCO, a frequency difference phase adder (FDPA), and a phase detector, generating a control signal with fully integrated components with minimum area. FDPA for proportional control also significantly limits the signal delay of the high gain controller, allowing the use of time-based control technique at <10 MHz, which improves converter efficiency. The proposed time-based current mode controller DSD buck converter is simulated in 130 nm BCD technology operating at 1 MHz for 10 V to 1 V conversion. The simulated peak efficiency is 82.2% at 0.4 A, and recovers from a 1.8 A loading and unloading current step in 5.75 $\mathrm{\mu }$s and 9.9 $\mathrm{\mu }$s, respectively. Full article

This paper introduces a novel contactless single-chip detector that utilizes impedance-to-digital conversion technology to measure impedance in the microfluidic channel or capillary format analytical device. The detector is designed to operate similarly to capacitively coupled contactless conductivity detectors for capillary electrophoresis or chromatography but with the added capability of performing frequency sweeps up to 200 kHz. At each recorded data point, impedance and phase-shift data can be extracted, which can be used to generate impedance versus frequency plots, or phase-shift versus frequency plots. Real and imaginary parts can also be calculated from the data, allowing for the generation of Nyquist diagrams. This detector represents the first of its kind in the contactless conductivity class to provide spectrum-type data, as demonstrated in capillary electrophoresis experiments. Full article

The integration of satellite-borne and ground-based global lightning location networks offers a better perspective to study lightning processes and their evolutionary characteristics within thunderstorm clouds, thereby bolstering the predictive capabilities for severe weather phenomena. Currently, the satellite-borne network is in the preliminary testing phase with a single satellite. The geographic locations of single-satellite detection events primarily rely on synchronous information from coincident ground-based network events; this method is called synchronous locating (SCL). However, variations in detection-frequency bands and system capabilities prevent this method from accurately locating more than a mere 10% of events. To address this limitation, this paper introduces a cluster-analysis-based strategy, utilizing the observations from the Worldwide Lightning Location Network (WWLLN), termed the cluster analysis locating (CAL) method. The CAL method’s performance, influenced by the density-based spatial clustering of applications with noise (DBSCAN), the K-means, and the mean shift algorithms, is examined. Subsequently, an advanced version, mean shift denoised (MSDN)-CAL, is proposed, demonstrating marked improvements in location accuracy and reliability over the other CAL methods. The satellite-borne wideband electromagnetic pulse detector (WEMPD), orbiting at an altitude of approximately 500 km with a 97.5° inclination, captured 1061 strong electromagnetic pulses (EMPs). Among these, trans-ionospheric single pulses (TISPs) and trans-ionospheric pulse pairs (TIPPs) constituted 21.30% and 78.70%, respectively. Using the MSDN-CAL method successfully determines the geographic locations for 81.15% (861 out of 1061) of the events. This success rate represents an approximate eightfold enhancement over the SCL method. The arithmetic mean, geometric mean, and standard deviation of the two-dimensional range deviation of the locating results between the MSDN-CAL method versus the WWLLN-SCL (or the Guangdong-Hong Kong-Macao Lightning Location System (GHMLLS)-SCL) method are 51.06 (176.26) km, 16.17 (92.53) km, and 100.95 (174.79) km, respectively. Furthermore, it has been possible to estimate the occurrence altitudes for 81.92% (684 out of 835) of the TIPP events. The altitude deviations, as determined by comparing them with the GHMLLS-SCL method’s locating results, exhibit an arithmetic mean of 2.08 km, a geometric mean of 1.30 km, and a standard deviation of 2.26 km. The outcomes of this research establish a foundation for deeper investigation into the origins of various event types, their seasonal variations, and their geographical distribution patterns. Moreover, they pave the way for utilizing a single satellite to measure global surface reflectance, thus contributing valuable data for meteorological and atmospheric studies. Full article

Fourier ptychography (FP) can break through the limitations of existing optical systems with a single aperture and realize large field-of-view (FOV) and high-resolution (HR) imaging simultaneously by aperture synthesis in the frequency domain. The method has potential applications for remote sensing and space-based imaging. However, the aperture stop of the imaging system was generally set to be much smaller than the system with an adjustable diaphragm, so it failed to make full use of the imaging capability of the system. In this paper, a reflective remote FP with full aperture is proposed, and the optical aperture of the camera is set to be the maximum according to the sample-matching condition, which can further improve the imaging resolution by exploring the whole capability of the system. Firstly, the physical model of the remote FP is established using oblique illumination of a convergent spherical wave. Then, the sampling characteristics of the low-resolution (LR) intensity image are analyzed. Assuming diffraction-limited imaging, the size of the aperture of the optical system needs to match the sampling of the detector. An experimental setup with an imaging distance of 2.4 m is built, and a series of LR images is collected by moving the camera for the diffused samples, including the USAF resolution test target and the banknote, where the diameter of the single aperture is set to the maximum to match the size of the CCD pixel under the practical minimum F^# of the camera of 2.8. The high-resolution image is reconstructed by applying the iterative phase retrieval algorithm. The experimental results show that the reconstructed resolution is improved to 2.5×. This verifies that remote FP with full aperture can effectively improve the imaging resolution using only the present single-aperture optical system. Full article

Fluorescence lifetime imaging microscopy is sensitive to molecular interactions and environments. In homo-dyne frequency-domain fluorescence lifetime imaging microscopy, images of fluorescence objects are acquired at different phase settings of the detector. The detected intensity as a function of detector phase is a sinusoidal function that is sensitive to the lifetime of the fluorescent species. In this paper, the theory of phase-sensitive fluorescence image correlation spectroscopy is described. In this version of lifetime imaging, image correlation spectroscopy analysis (i.e., spatial autocorrelation) is applied to successive fluorescence images acquired at different phase settings of the detector. Simulations of different types of lifetime distributions reveal that the phase-dependent density of fluorescent objects is dependent on the heterogeneity of lifetimes present in the objects. We provide an example of this analysis workflow to a cervical cancer cell stained with a fluorescent membrane probe. Full article

The Spaceborne Global Lightning Location Network (SGLLN) serves the purpose of identifying transient lightning events occurring beneath the ionosphere, playing a significant role in detecting and warning of disaster weather events. To ensure the effective functioning of the wideband electromagnetic pulse detector, which is a crucial component of the SGLLN, it must be tested and verified with specific signals. However, the inherent randomness and unpredictability of lightning occurrences pose challenges to this requirement. Consequently, a high-power electromagnetic pulse radiation system with a 20 m aperture reflector is designed. This system is capable of emitting nanosecond electromagnetic pulse signals under pre-set spatial and temporal conditions, providing a controlled environment for assessing the detection capabilities of SGLLN. In the design phase, an exponentially TEM feed antenna has been designed firstly based on the principle of high-gain radiation. The feed antenna adopts a pulser-integrated design to mitigate insulation risks, and it is equipped with an asymmetric protective loading to reduce reflected energy by 85.7%. Moreover, an innovative assessment method for gain loss, based on the principle of Love’s equivalence, is proposed to quantify the impact of feed antenna on the radiation field. During the experimental phase, a specialized E-field sensor is used in the far-field experiment at a distance of 400 m. The measurements indicate that at this distance, the signal has a peak field strength of 2.2 kV/m, a rise time of 1.9 ns, and a pulse half-width of 2.5 ns. Additionally, the beamwidth in the time domain is less than 10°. At an altitude of 500 km, the spaceborne detector records a signal with a peak field strength of approximately 10 mV/m. Particularly, this signal transformed into a nonlinear frequency-modulated signal in the microsecond range across its frequency spectrum, which is consistent with the law of radio wave propagation in the ionosphere. This study offers a stable and robust radiation source for verifying spaceborne detectors and establishes an empirical foundation for investigating the impact of the ionosphere on signal propagation characteristics. Full article
