Large-scale grid integration of renewable generation is facilitated by resource abundance and advancements in power electronics. The high penetration of power electronics-based devices reduces system inertia, threatening grid stability. The Virtual Synchronous Generator (VSG) provides an effective solution. However, when the grid is unbalanced, problems such as unbalanced output current, overcurrent, and power fluctuations occur. Thus, a VSG power–current collaborative control strategy based on improved second-order generalized integrator (SOGI) is proposed. Firstly, the generation of power fluctuation and unbalanced current in VSG output under an unbalanced power grid is analyzed. Secondly, to suppress the DC component and high-order harmonics, an improved SOGI method is proposed for positive and negative sequence separation by introducing a difference node and adding an extra SOGI module on the basis of the traditional SOGI. To achieve the collaborative control of active/reactive power constant and current balance, a correlation coefficient μ is introduced and a unified equation is constructed. To prevent overcurrent during fault, virtual impedance and reactive power reference are introduced. Simulations have verified the effectiveness of the proposed method. It shows superiority in effective sequence separation, smooth power–current collaborative control, and safe operation without overcurrent. Full article

This paper proposes the development of an IEC 61850-compliant platform that is readily programmable and deployable for future digital twin applications. Given the compatibility between IEC-61850 and digital twin concepts, a focused case study was conducted involving the robust development of a Raspberry Pi platform with protection relay functionality using the open-source libIEC61850 library. Leveraging IEC-61850’s object-oriented data modelling, the relay can be represented by fully consistent virtual and physical models, providing an essential foundation for accurate digital twin instantiation. The relay implementation supports high-speed Sampled Value (SV) subscription, real-time RMS calculations, IEC Standard Inverse overcurrent trip behaviour according to IEC-60255, and Generic Object-Oriented Substation Event (GOOSE) publishing. Further integration includes setting group functionality for dynamic parameter switching, report control blocks for MMS client–server monitoring, and GOOSE subscription to simulate backup relay protection behaviour with peer trip messages. A staged development methodology was used to iteratively develop features from simple to complex. At the end of each stage, the functionality of the added features was verified before proceeding to the next stage. The integration of the Raspberry Pi into Curtin’s IEC = 61,850 digital substation was undertaken to verify interoperability between IEDs, a key outcome relevant to large-scale digital twin systems. The experimental results confirm GOOSE transmission times below 4 ms, tight adherence to trip-time curves, and performance under higher network traffic. Such measured RMS and trip-time errors fall well within industry and IEC limits, confirming the reliability of the relay logic. The takeaways from this case study establish a high-performing, standardised foundation for a digital twin system that requires fast, bidirectional communication between a virtual and a physical system. Full article

The widespread integration of inverter-based distributed generators (IIDGs) severely limits the adaptability of conventional three-step overcurrent protection in distribution networks (DNs). To address weak rural infrastructure and incomplete post-fault data, this paper proposes a dynamic adaptive current protection strategy for active distribution networks (ADNs) against two-phase short-circuit faults (TPSCFs), using local sequence components. First, we derive analytical expressions for positive/negative-sequence current/voltage at feeder outlet protection devices during TPSCFs, analyzing how the IIDG fault output affects these components. Based on this, an adaptive scheme is developed using only local measurements, with feeder head voltage/current sequence components as criteria. Leveraging line impedance and topology, the scheme ensures selective, accurate fault section identification under incomplete measurements, requiring only feeder head sequence data. A high-IIDG-penetration DN model is built in PSCAD/EMTDC, and TPSCFs under various conditions are simulated. Results show the scheme provides rapid, reliable full-line protection for TPSCFs in IIDG-penetrated ADNs, enhancing protection effectiveness. Full article

The rapid rise of inverter-based resources (IBRs) such as solar, wind, and battery energy storage is transforming power grids and creating new challenges for protection. Unlike synchronous generators, many IBRs are interfaced through grid-following (GFL) inverters that operate as controlled current sources and rely on an external voltage reference, resulting in fault responses that are current-limited and controller-shaped. These characteristics reduce fault current magnitude and can undermine conventional protection schemes. In contrast, emerging grid-forming (GFM) inverters behave as voltage sources that establish local voltage and frequency, offering improved disturbance support but still transitioning to current-limited operation under severe faults. This review summarizes GFL versus GFM operating principles and deployments, compares their behavior under balanced and unbalanced faults, and evaluates protection impacts using a protection-relevant taxonomy supported by illustrative electromagnetic transient (EMT) case studies. Key challenges, including underreach/overreach of impedance-based elements, reduced overcurrent sensitivity, and directional misoperation, are identified. Mitigation options are discussed, spanning adaptive/supervised relaying, communication-assisted and differential protection, and inverter-side fault current shaping and GFM integration. The implications of IEEE 1547-2018 and IEEE 2800-2022 are reviewed to clarify ride-through and support requirements that constrain protection design in high-IBR systems. Full article

This study proposes a hybrid forecast-enabled adaptive crowbar coordination strategy to enhance low-voltage ride-through (LVRT) performance of doubly fed induction generator (DFIG) wind turbines. A unified electro-mechanical model in the αβ/dq frames with dual closed-loop control for rotor- and grid-side converters is built in MATLAB/Simulink (R2018b), and LVRT constraints on current safety and DC-link energy are explicitly formulated, yielding an engineering crowbar-resistance range of 0.4–0.8 p.u. On the forecasting side, a CEEMDAN-based decomposition–modeling–reconstruction pipeline is adopted: high- and mid-frequency components are predicted by a dual-stream Informer–LSTM, while low-frequency components are modeled by XGBoost. Using six months of wind-farm data, the hybrid forecaster achieves best or tied-best MSE, RMSE, MAE, and R² compared with five representative baselines. Forecasted power, ramp rate, and residual-based uncertainty are mapped to overcurrent and DC-link overvoltage risk indices, which adapt crowbar triggering, holding, and release in coordination with converter control. In a 9 MW three-phase deep-sag scenario, the strategy confines DC-link voltage within ±3% of nominal, shortens re-synchronization from ≈0.35 s to ≈0.15 s, reduces rotor-current peaks by ≈5.1%, and raises the reactive-support peak to 1.7 Mvar, thereby improving LVRT safety margins and grid-friendliness without hardware modification. Full article

In electrical networks, the coordination and selectivity of protective devices are key to improving reliability and ensuring operational safety. Protections play a fundamental role in maintaining system stability and detecting faults within the power system. This study presents an optimized genetic algorithm (OGA) as a method to optimize the configurations of overcurrent protections in high voltage distribution systems. The OGA obtained the best results in all tested systems, demonstrating its effectiveness in coordinating protections according to IEC 60255-151:2009. In addition, simulations performed with the integration of Python and PowerFactory DigSILENT software validated the correct coordination of the protections, showing that the OGA not only optimizes response times, but also guarantees greater selectivity and reliability in the protection of the electrical system in an efficient way. Full article

This paper presents the simultaneous maximization of speed and sensitivity in the Optimal Coordination of Directional Over-Current Protections (OC-DOCP), considering that maximum selectivity is maintained in all solutions. Only these three desirable features of the protection system were considered in the multi-objective approach; thus, the problem can be simply formulated as the weighted sum of speed and sensitivity as goals to be maximized, and the Pareto frontiers correlating speed and sensitivity are easily found in this way. These Pareto frontiers had not been shown in the literature about this topic, and they properly show the compromise solutions for the optimal solutions (i.e., speed improvements imply sensitivity deterioration while sensitivity improvements imply speed degradation). The simplest OC-DOCP formulation, applied to a well-known sample system, is taken as an example to show the Pareto frontiers for different time–current curve types. Another OC-DOCP formulation, which considers different topologies and their probability of occurrence, is also solved and the corresponding Pareto frontiers are also shown. The main findings of this work are the following: (a) in general, the results show that the variation in the speed in the Pareto frontier is more notorious for the less inverse curve types, whose optimal solutions are slower; (b) in the case of extremely inverse curves, the optimal solutions are faster and the effect of changes in sensitivity on the protection speed is very low in the Pareto frontiers; (c) it is also herein shown that the knowledge of this topic is also useful to solve some possible cases of unfeasibility related to the upper bound of time dial settings. Full article

When offshore wind power is connected to a grid via Modular multilevel converter-based High Voltage Direct Current (MMC-HVDC), the sending-end alternating current (AC) system is susceptible to asymmetrical faults. These faults lead to overcurrent surges, voltage drops, and second harmonic circulating currents, which seriously threaten the safe operation of the system. To quickly suppress fault current surges, achieve precise control of system variables, and improve fault ride-through capability, this study proposes a collaborative control strategy. This strategy integrates generalized virtual impedance current limiting, positive- and negative-sequence collaborative feedforward control, and model-predictive control-based suppression of arm energy and circulating currents. The positive- and negative-sequence components of the voltage and current are quickly separated by extending and decoupling the decoupled double synchronous reference frame phase-locked loop (DDSRF-PLL). A generalized virtual impedance with low positive-sequence impedance and high negative-sequence impedance was designed to achieve rapid current limiting. Simultaneously, negative-sequence current feedforward compensation and positive-sequence voltage adaptive support are introduced to suppress dynamic fluctuations. Finally, an arm energy and circulating current prediction model based on model predictive control (MPC) is established, and the second harmonic circulating currents are precisely suppressed through rolling optimization. Simulation results based on PSCAD/EMTDC show that the proposed control strategy can effectively suppress the negative-sequence current, significantly improve voltage stability, and greatly reduce the peak fault current. It significantly enhances the fault ride-through capability and operational reliability of offshore wind power MMC-HVDC-connected systems and holds significant potential for engineering applications. Full article

This paper proposes a reliable control strategy for dual induction motor drives using a five-leg inverter (FLI). Since the FLI has the structural characteristic where both motors share a common leg, the current of the common leg can flow at twice the magnitude of the other leg currents. To prevent this overcurrent, this paper proposes a reliable integrated control strategy for both normal and open-circuit fault conditions in the FLI. Under normal conditions, overcurrent can occur when the phase and frequency of the current for both motors are distinct; therefore, the angle controller and current limitation prevent overcurrent. In contrast, an open-circuit fault in the FLI can cause overcurrent due to altered current paths. To ensure a safe shutdown, identifying the specific location of the faulty switch is essential. Therefore, fault diagnosis is required using the stator currents. Once the fault is located, a fault-tolerant method is applied to safely stop the motors, considering both the fault location and the rated current of the common leg. Consequently, the proposed system enables reliable operation of dual induction motor drives under various conditions. The experimental results verify the effectiveness of the proposed system. Full article

Grid-forming (GFM) converters are promising for renewable energy integration, but their overcurrent limitation during grid faults remains a critical challenge. Existing overcurrent-limiting strategies were primarily developed for two-level converters and are often inadequate for Modular Multilevel Converters (MMCs). By overlooking the MMC’s unique topology and internal physical constraints, these conventional methods compromise both operational safety and grid support capabilities. Thus, this paper proposes a dynamic asymmetric overcurrent-limiting strategy for grid-forming MMCs that considers multiple physical constraints. The proposed strategy establishes a dynamic asymmetric overcurrent boundary based on three core physical constraints: capacitor voltage ripple, capacitor voltage peak, and the modulation signal. This boundary accurately defines the converter’s true safe operating area under arbitrary operating conditions. To address the complexity of the boundary’s analytical form for real-time application, an offline-trained neural network is introduced as a high-precision function approximator to efficiently and accurately reproduce this dynamic asymmetric boundary. The effectiveness of the proposed strategy is verified by hardware-in-the-loop experiments. Experimental results demonstrate that the proposed strategy reduces the capacitor voltage ripple by 30.7% and maintains the modulation signal safely within the linear range, significantly enhancing both system safety and fault ride-through performance. Full article

The capacity of traditional distribution networks is limited. After large-scale distributed power sources are connected, it is difficult to consume them at the same voltage level, which can lead to transformer reverse overloading and voltage limit violations. Although the unified power flow controller (UPFC) excels in flexible power flow regulation and power quality optimization, existing research on it is mostly focused on the transmission grid, focusing on device topology, power flow control, etc. Fault protection is also targeted at high-voltage and ultra-high-voltage domains and only covers a single overvoltage or overcurrent fault. Research on the protection of the unified power flow controller in a distribution network (D-UPFC) remains scarce. A key challenge is the absence of fault protection schemes that are compatible with the unified power flow controller in a distribution network, which cannot meet the requirements of the distribution network for monitoring and protecting multiple fault types, rapid response, and equipment economy. This paper first designs a protection device centered on the distribution thyristor bypass switch (D-TBS), completes the thyristor selection and transient energy extraction, optimizes the overvoltage protection loop parameter, then builds a three-level coordinated protection architecture, and, finally, verifies through functional and system tests. The results show that the thyristor control unit trigger is reliable and the total overvoltage response delay is 1.08 μs. In the case of a three-phase short-circuit fault in a 600 kVA/10 kV system, the distribution thyristor bypass switch can rapidly reduce the secondary voltage of the series transformer, suppress transient overcurrent, achieve isolation protection of the main equipment, provide a reliable guarantee for the engineering application of the distribution network unified power flow controller, and expand its distribution network application scenarios. Full article

The high penetration of distributed photovoltaics (PV) into distribution networks alters the system’s short-circuit current characteristics, posing risks of maloperation and failure-to-operate to conventional inverse-time overcurrent protection. Based on an equivalent model of distributed PV during faults, this paper analyzes its impact on the protection characteristics of traditional distribution networks. With protection selectivity and the physical constraints of protection devices as conditions, an optimization model for inverse-time overcurrent protection is established, aiming to minimize the total operation time. To enhance the solution capability for this complex optimization problem, the standard Osprey Optimization Algorithm (OOA) is improved through the incorporation of three strategies: arccosine chaotic mapping for population initialization, a nonlinear convergence factor to balance global and local search, and a dynamic spiral search strategy combining mechanisms from the Whale and Marine Predators algorithms. Based on this improved algorithm, an optimized protection scheme for distribution networks with distributed PV is proposed. Simulations conducted in PSCAD/EMTDC (V4.6.2) and MATLAB (R2023b) verify that the proposed method effectively prevents protection maloperation and failure-to-operate under both fault current contribution and extraction scenarios of PV, while also reducing the overall relay operation time. Full article

With the rapid development of new energy, high-proportion new energy power systems have significantly reduced inertia and voltage support capacity, facing severe stability challenges. Virtual Synchronous Generator (VSG) control, which simulates the inertia and voltage source characteristics of traditional synchronous generators, enables friendly grid connection of new energy converters and has become a key technology for large-scale new energy applications. This paper addresses two key issues in low-voltage ride through (LVRT) of grid-forming converters under VSG control: (1) converter overcurrent suppression during LVRT; (2) reduced reactive power support due to retaining voltage-reactive power droop control during faults. It proposes an adaptive virtual impedance-based overcurrent suppression method and a frozen reactive power–voltage droop-based reactive support method. Based on the converter’s mathematical model, a DIgSILENT/PowerFactory simulation model is built. Time-domain simulations verify the converter’s operating characteristics and the improved LVRT strategy’s effect, providing theoretical and technical support for large-scale applications of grid-forming converters. Full article

The use of advanced switching technologies, including hybrid and fully semiconductor-based circuit breakers, enables a significant reduction in the prospective short-circuit current. This enhances the level of circuit protection by minimizing thermal and electrodynamic stresses. One of the available solutions is a hybrid DC circuit breaker employing the forced commutation method, in which a counter-current generator is incorporated into the auxiliary branch. Increasing requirements not only for short-circuit protection reliability but also for operational flexibility impose the need to configure DC breakers for parallel operation. This paper presents an analysis of the performance of forced-commutation circuit breakers connected in parallel with another identical device, as well as with a conventional fast magnetic blow-out breaker. To prevent unintended and undesired tripping, the influence of counter-current generator parameters on the overcurrent protection response was investigated. In the analyzed configuration, the applied hybrid DC breaker limits the expected short-circuit current from approximately 45 kA to 5 kA within about 2 ms. Full article

Guaranteeing the effective coordination of directional overcurrent relays (DOCRs) within microgrids (MGs) is a complex nonlinear problem due to bidirectional power flows, varying fault current levels, and the need for adaptive operation across multiple grid configurations. To address this challenge, this paper proposes a hybrid matheuristic approach combining a Biased Random-Key Genetic Algorithm (BRKGA) with Mixed-Integer Linear Programming (MILP). This formulation treats the selection of relay characteristic curves as a decision variable, allowing for simultaneous optimization of time multiplier settings (TMS), plug setting multipliers (PSM), and curve types. The BRKGA handles the global search, while the embedded MILP decoder performs exact optimization under fixed conditions. The proposed BRKGA–MILP method was tested on the IEC benchmark microgrid under multiple operating modes. Compared with conventional MILP-based coordination, it achieved up to 18.31% reduction in total relay operating times (11.81% on average) while maintaining proper coordination time intervals (CTI). Relative to previous heuristic and hybrid approaches, the method improved protection speed by up to 14.87%. These results indicate that the proposed framework effectively enhances coordination performance in adaptive microgrid protection, particularly under bidirectional power flows and varying fault current levels. Full article
