Search Results (1,543)

Voltage supraharmonics present in the electrical grid can trigger chain reactions in grid-connected household and industrial power supplies equipped with Power Factor Correction (PFC). A single source of voltage supraharmonics may significantly increase the current in switching devices with PFC, leading to higher-amplitude disturbances throughout the electrical network. When addressing issues in a real low-voltage (LV) grid, it was observed that activation of a single device emitting supraharmonics caused oscillating currents across all feeders connected to the transformer’s busbars, matching the frequency of the supraharmonic source. To investigate this phenomenon further, the grid voltage containing supraharmonics was replicated in a controlled laboratory environment and used to supply various power electronic devices. The laboratory results closely mirrored those observed in the field. Supraharmonics present in the supply voltage caused current oscillations in the power electronic devices at the same frequency. Moreover, the amplitude of the observed current oscillations increased with the amplitude of the injected supply voltage supraharmonics. In some cases, the root mean square (RMS) value of the current drawn by the power electronic devices doubled, indicating a substantial impact on device behaviour and potential implications for grid stability and energy efficiency. Full article

This work presents a low-power photoplethysmography (PPG) readout integrated circuit (IC) that achieves a wide dynamic range (DR) through the direct integration of a voltage-controlled oscillator (VCO)-based quantizer into the photodiode driver. Conventional PPG readout circuits rely on either transimpedance amplifier (TIA) or light-to-digital converter (LDC) topologies, both of which require auxiliary DC suppression loops. These additional loops not only raise power consumption but also limit the achievable DR. The proposed design eliminates the need for such circuits by embedding a linear regulator with a mirroring scale calibrator and a time-domain quantizer. The quantizer provides first-order noise shaping, enabling accurate extraction of the AC PPG signal while the regulator directly handles the large DC current component. Post-layout simulations show that the proposed readout achieves a signal-to-noise-and-distortion ratio (SNDR) of 40.0 dB at 10 µA DC current while consuming only 0.80 µW from a 2.5 V supply. The circuit demonstrates excellent stability across process–voltage–temperature (PVT) corners and maintains high accuracy over a wide DC current range. These features, combined with a compact silicon area of 0.725 mm² using TSMC 250 nm bipolar–CMOS–DMOS (BCD) process, make the proposed IC an attractive candidate for next-generation wearable and biomedical sensing platforms. Full article

The accurate estimation of parameters in dynamical systems stands for an open key research issue in modeling, control, and fault diagnosis. The presence of noise in input and output signals poses a serious challenge for accurate real-time dynamical system parameter estimation. This paper proposes a new robust algebraic parameter estimation methodology for integer-order dynamical systems that explicitly incorporates the signal filtering dynamics within the estimator structure and enhances noise attenuation through fractional differentiation in frequency domain. The introduced estimation methodology is valid for Liouville-type fractional derivatives and can be applied to estimate online the parameters of differentially flat, oscillating or vibrating systems of multiple degrees of freedom. The parametric estimation can be thus implemented for a wide class of oscillating or vibrating, nth-order dynamical systems under noise influence in measurement and control signals. Positive values are considered for the inertia, stiffness, and viscous damping parameters of vibrating systems. Parameter identification can be also used for development of actuators and control technology. In this sense, validation of the algebraic parameter estimation is performed to identify parameters of a differentially flat, permanent-magnet direct-current motor actuator. Parameter estimation for both open-loop and closed-loop control scenarios using experimental data is examined. Experimental results demonstrate that the new parameter estimation methodology combining signal filtering dynamics and fractional calculus outperforms other conventional methods under presence of significant noise in measurements. Full article

A precision bandgap reference (BGR) is an essential building block in modern analog and mixed-signal systems, as it provides stable and predictable current and voltage references required for reliable operation across process, voltage, and temperature variations. However, one of the key challenges in conventional BGR circuits is their sensitivity to resistance variations, which directly impacts the accuracy of bias currents. Even small changes in resistance can lead to significant current mismatch between the core branches of the circuit, thereby degrading output stability and limiting the precision of the overall system. This degradation is particularly problematic in high-performance applications such as data converters, oscillators, and low-power biasing networks, where robust current matching is critical. To address this limitation, this work proposes a resistance-compensated BGR architecture that incorporates an auxiliary trimming network and a compensation branch. The trimming network senses variations in resistance and generates a control bias proportional to the deviation, while the compensation branch injects a corrective current into the output stage. By dynamically balancing the mismatch introduced by resistor spread, the proposed architecture effectively restores current stability across process corners. This method achieves reduction in the current variation across resistance corners from 21% to 3% in worst-case corners (±3%). This approach offers enhancement of current mismatches in analog systems in which robust current is essential. Full article

The increasing integration of renewable energy has led to power systems characterized by a high penetration of renewable energy sources (RES) and power electronic devices (PEDs). However, wide-band oscillation phenomena caused by RES grid integration have emerged and propagated through transmission networks. Notably, large-scale renewable energy bases located in remote areas are typically connected to the main grid via long-distance AC transmission lines. These lines exhibit an inter-harmonic amplification effect, which may exacerbate the propagation and amplification of wide-band oscillations, posing significant risks to bulk power-grid stability. This paper establishes impedance models of long-distance AC transmission lines and asynchronous motors under wide-band oscillation frequencies, and derives equivalent line parameters mathematically to reveal the oscillation amplification problem of long-distance renewable energy oscillation transmission through AC transmission lines. A transfer coefficient is defined to quantify inter-harmonic current amplification. A single-machine-load model is developed in MATLAB/Simulink to validate the proposed model. Furthermore, the influence of line parameters on oscillation amplification is analyzed, and a suppression strategy is proposed. This study provides valuable insights for the parameter design of long-distance transmission lines in renewable energy integration scenarios, as it helps mitigate potential inter-harmonic amplification risks by reducing the peak values of the transfer coefficient. Full article

In the current energy landscape, power quality (PQ) emerges as a critical concern. Even when there is no fault on a line, PQ issues are common in all power networks since 90% of power systems’ loads are variable or inductive in nature. Variable loads cannot be avoided; hence, PQ concerns such as voltage swelling and sag will always arise. Voltage sag is one of the main issues within a distribution network, resulting in financial losses for the utility company and the customer. The Dynamic Voltage Restorer (DVR) effectively addresses voltage sags and minimizes total harmonic distortion (THD) in the distribution network. This paper proposed a novel control strategy to increase the PQ in a system. A Frilled Lizard Optimization-optimized fuzzy PI controller is proposed in this work to control the inverter. This proposed method improves the DVR’s ability to correct voltage sag and reduce total harmonic distortion as soon as possible. The PI control scheme is utilized initially to reduce the oscillations and remove the steady-state error. To increase the tendency rate of the error to zero, the PI method is applied to a fuzzy logic-based compensatory stage. The proposed approach is validated using pro-type models, as well as mathematical and Simulink modelling. In the Results Section, the performance of the proposed controllers with the DVR is tabulated and compared with other DVR controller schemes described in other research papers. Full article

Community Earth System Model-Large Ensemble (CESM-LE) simulations are used to partition the Surface Air Temperature (SAT) trends over East Asia into the contribution of external forcing factors and internal variability. In the historical period (1966–2005), the summer SAT trends display a considerable diversity (≤−2 °C to ≥2 °C) across the 35 member ensembles, while under the RCP8.5 scenario, the region is mostly dominated by a strong warming trend (~1.5–2.5 °C/51 years) and touches the ~4 °C mark by the end of the 21st century. In the historical period, the warming is prominent over the Yangtze River basin of China, while under the RCP8.5 scenario, the warming pattern shifts northward towards Mongolia. In the historical period, the Signal-to-Noise Ratio (SNR) is less than 1, while it is higher than 4 under the RCP8.5 scenario, which indicates that, in the early period, internal variability overrides the forced response and vice versa under the RCP8.5 scenario. In addition, over much of the East Asian region, the chances of cooling are relatively high in the historical period, which partially counteracted the warming trend due to external forcing factors. In contrast, under the RCP8.5 scenario, the chances of warming reach ~100% over East Asia due to contributions from the external forcing factors. The novel aspect of the current study is that, in the negative phase (from the mid-1960s to ~2000), the Atlantic Multidecadal Oscillation (AMO) accounts for ~70–80% of the cooling trend or the SAT variability over East Asia, and thereafter, natural variability exhibits a slow increasing trend in the future. However, the contribution of external forcing factors increases from ~55% in 2000 to 95% in 2075 at a rate much faster than natural variability, which is primarily due to increasing downward solar radiation fluxes and albedo feedback on SAT over East Asia. Full article

Microgrids have emerged as a crucial solution for addressing environmental concerns, such as reducing greenhouse gas emissions and enhancing energy sustainability. By incorporating renewable energy sources like solar and wind, microgrids improve energy efficiency and offer a cleaner alternative to conventional power grids. Among various microgrid architectures, DC microgrids are gaining significant attention due to their higher efficiency, reduced reactive power losses, and direct compatibility with renewable energy sources and energy storage systems. However, DC microgrids face stability challenges, particularly due to the presence of constant power loads (CPLs), which exhibit negative incremental impedance characteristics. These loads can destabilize the system, leading to oscillations and performance degradation. This paper explores various control strategies designed to enhance the stability and dynamic response of DC microgrids, with a particular focus on interleaved boost converters (IBCs) interfaced with CPLs. Traditional control methods, including proportional–integral (PI) and sliding mode control (SMC), have shown limitations in handling dynamic variations and disturbances. To overcome these challenges, this paper proposes a novel RST-based control strategy for IBCs, offering improved stability, adaptability, and disturbance rejection. The efficacy of the RST controller is validated through extensive simulations tests, demonstrating competitive performance in maintaining DC bus voltage regulation and current distribution. Key performance indicators demonstrate competitive performance, including settling times below 40 ms for voltage transients, overshoot limited to ±2%, minimal voltage deviation from the reference, and precise current sharing between interleaved phases. The findings contribute to advancing the stability and efficiency of DC microgrids, facilitating their broader adoption in modern energy systems. Full article

Accurately simulating immiscible counter-current flow is crucial for applications from geological ${\mathrm{CO}}_2$ storage to shale gas production, yet it remains a major challenge for conventional pore network models (PNMs), which are unable to handle the numerical instability of opposing flows. To address this critical gap, we developed a novel dynamic PNM that incorporates a ‘transition state’ algorithm. This method successfully eliminates the spurious meniscus oscillations that hinder traditional models, enabling robust simulation of the complete counter-current process. Using this model, we quantify the profound impact of pore structure on flow efficiency. Our results demonstrate that increasing the pore size distribution uniformity (Weibull shape factor k from 0.5 to 3.0) extends the persistence of continuous air outflow pathways by more than six-fold (from 359 to over 2300 simulation steps). This leads to a quantifiable increase in the initial fluid exchange rate by nearly 10 times (from ${10}^{-11}$ to ${10}^{-10}$${\mathrm{m}}^3$/s) and a reduction in final residual air saturation by 53% (from 0.91 to 0.43). This work provides a tool for predicting and optimizing counter-current flow efficiency in subsurface engineering applications. Full article

Due to the “low damping” characteristics of the DC distribution system, the traditional passive scheme is not suitable for DC fault detection and positioning. Therefore, this paper proposes an active injection fault identification method suitable for DC feeder line under single-pole grounding faults. Based on the high controllability of converters, this method uses the oscillation circuit characteristics of the DC side single-pole grounding fault to superimpose the harmonics of fixed frequency into the converter modulated wave, and derives the selection principles of harmonic amplitude and frequency. After the fault, the positive and negative current signals are extracted from the feeder lines, and the zero-mode current components are extracted by the Karrenbauer transformation and band-pass filter, the current phases are compared to achieve the fault feeder line selection. According to simulation verification, the power quality of the actively injected harmonics is within the standard range under the condition of global injection, and the single-pole grounding faults in each feeder line can be identified. Full article

A ring-oscillator based voltage-controlled oscillator (VCO) architecture with reduced frequency drift across temperature and process variations is presented in this paper. The frequency stability is achieved through two dedicated compensation techniques: a temperature compensation circuit that generates a proportional-to-absolute-temperature (PTAT) current to mitigate frequency shifts due to temperature changes, and a process compensation circuit that dynamically adjusts the frequency based on detected process corners. The proposed design is implemented in a 22 nm CMOS technology with a 0.8 V supply voltage and targets a nominal oscillation frequency of 2.5 GHz. The post-layout simulation results demonstrate a significant improvement in frequency stability, reducing temperature-induced frequency drift from 23.9% to a range of 5.4% over the −40 °C to 125 °C temperature range for the typical corner. Combining temperature and process compensation, the frequency drift is improved from 47.3% to better than 7.2%. The VCO also achieves a phase noise value about −80 dBc/Hz at a 1 MHz offset with an average power consumption of 380 µW, including the tuning mechanism and the compensation circuits. Full article

The widespread presence of security patterns in modern anti-forgery systems has given rise to an urgent need for reliable smartphone authentication. However, persistent recognition inaccuracies occur because of the inherent degradation of patterns during smartphone capture. These acquisition-related artifacts are manifested as both spectral distortions in high-frequency components and structural corruption in the spatial domain, which essentially limit current verification systems. This paper addresses these two challenges through four key innovative aspects: (1) It introduces a chromatic-adaptive coupled oscillation mechanism to reduce noise. (2) It develops a DFT-domain processing pipeline. This pipeline includes micro-feature degradation modeling to detect high-frequency pattern elements and directional energy concentration for characterizing motion blur. (3) It utilizes complementary spatial-domain constraints. These involve brightness variation for local consistency and edge gradients for local sharpness, which are jointly optimized by combining maximum a posteriori estimation and maximum likelihood estimation. (4) It proposes an adaptive graph-based partitioning strategy. This strategy enables spatially variant kernel estimation, while maintaining computational efficiency. Experimental results showed that our method achieved excellent performance in terms of deblurring effectiveness, runtime, and recognition accuracy. This achievement enables near real-time processing on smartphones, without sacrificing restoration quality, even under difficult blurring conditions. Full article

Control valves are widely applied in nuclear power, offshore oil/gas extraction, and chemical engineering, but suffer from issues like pressure oscillation, flow control accuracy degradation, and motor overload due to unstable fluid loads (e.g., nuclear reactions in power plants and complex marine climates). This paper proposes a dual-motor redundant compensation method to address these challenges. The core lies in a control strategy where a single main motor drives the valve under normal conditions, while a redundant motor intervenes when load torque exceeds a preset threshold—calculated via the valve core’s fluid load model. By introducing excess load torque as positive feedback to the current loop, the method coordinates torque output between the two motors. AMESim and Matlab/Simulink joint simulations compare single-motor non-compensation, single-motor compensation, and dual-motor schemes. Results show that under inlet pressure step changes, the dual-motor compensation scheme shortens the stabilization time of the valve’s controlled variable by 40%, reduces overshoot by 65%, and decreases motor torque fluctuation by 50%. This redundant design enhances fault tolerance, providing a novel approach for reliability enhancement of deep-sea oil/gas control valves. Full article

While humanity stands at a critical point—one future leading toward sustainability, equity, and resilience, the other toward escalating conflicts, ecological collapse, and irreversible loss—climate change emerges as one of the most urgent challenges of the 21st century. The Global South, specifically the northwestern South American region, lacks model confidence and reports on current climatic conditions due to gaps in historical data. This study, therefore, presents temperature and precipitation trends in the highest city on the equator, Quito, Ecuador, from 2004–2024. Six different districts were analyzed for maximum, average, and minimum temperatures, as well as cumulative precipitation, in terms of monthly and annual statistics, using Seasonal-Trend Decomposition. Over the past two decades, this Andean city has warmed by an average of +0.95 °C, with minimum temperatures rising at rates twice the global urban average of extreme urban heat islands (+2.47 °C), while precipitation has nearly doubled in rapidly developing parts of the city. These profound changes, shaped by urban expansion, El Niño–Southern Oscillation variability, and climate change, demand urgent adaptation in water management, urban planning, and climate resilience strategies, as well as comparative studies with rural Ecuador to differentiate local vs. regional climate signatures. Full article

The rapid evolution of modern power systems, driven by the large-scale integration of renewable energy sources and the emergence of smart grids, presents new challenges in maintaining grid stability, power quality, and control reliability. As critical interfacing elements, three-phase pulse width modulation (PWM) converters must now ensure resilient and efficient operation under increasingly adverse and dynamic grid conditions. This paper proposes an adaptive neural network-based virtual flux (VF) estimator for sensorless predictive direct power control (PDPC) of PWM converters under nonideal grid voltage conditions. The proposed estimator is realized using an adaptive linear neuron (ADALINE) configured as a quadrature signal generator, offering robustness against grid voltage disturbances such as voltage unbalance, DC offset and harmonic distortion. In parallel, a PDPC scheme based on the extended pq theory is developed to reject active-power oscillations and to maintain near-sinusoidal grid currents under unbalanced conditions. The resulting VF-based PDPC (VF-PDPC) strategy is validated via real-time simulations on the OPAL-RT platform. Comparative analysis confirms that the ADALINE-based estimator surpasses conventional VF estimation techniques. Moreover, the VF-PDPC achieves superior performance over conventional PDPC and extended pq theory-based PDPC strategies, both of which rely on physical voltage sensors, confirming its robustness and effectiveness under non-ideal grid conditions. Full article
