Understanding how geometry, surface condition, and polarity influence surface flashover is important for improving the reliability of polymeric insulation in high-voltage systems exposed to transient overvoltages. The purpose of this study was to experimentally investigate visible arc path behaviour on polymeric insulators made of polymethyl methacrylate (PMMA), polyvinyl chloride (PVC), and nylon under standard 1.2/50 µs lightning voltage impulses. Cylindrical, concave, and convex profiles were tested in a rod–plane configuration for both positive and negative polarities under clean and sunflower oil- coated surface conditions. Seven arc types were observed. While the visible arc path was governed mainly by geometry and polarity, the electrical breakdown response exhibited material-dependent effects. Positive-polarity oil-coated samples generally exhibited longer time-to-breakdown, while negative-polarity tests produced higher breakdown voltages, and oil often reduced the withstand level. The large variability in time-to-breakdown data indicates that impulse flashover is strongly stochastic and sensitive to small surface or field variations. The findings highlight the need for improving control of surface films, expanding environmental testing, and conducting further modelling to predict flashover behaviour across different insulator designs. Full article

This paper reports on the performance of an optical voltage transducer (MVT) module after undergoing lightning impulse withstand tests. The device was designed to monitor the output voltage of a dedicated capacitive voltage divider (CVD) to facilitate a voltage sensor dedicated for 132-kV high voltage (HV) networks. Hard piezoelectric transducer (PZT) and fiber Bragg grating (FBG) technologies were combined in the module to serve as a voltage-to-strain-to-wavelength converter. The FBG peak wavelength shifts were calibrated against the input voltage to provide precise measurements of the network voltage. The module was subjected to lightning impulse withstand tests as per the requirements of the IEC 60044-7 and IEC 60060-1 standards, and the impact of the lightning impulses on the performance of the MVT module was evaluated based on the accuracy tests performed before and after the lightning impulse tests. The experimental results demonstrated that the MVT module successfully withstood the lightning impulse tests without any disruptive discharges or voltage collapses. The performance of the module was not affected by the lightning impulse tests within the practical constraints of the reference measuring equipment: its amplitude and phase errors remained within the original limits of ±0.1% and ±0.1° at 80–120% of the rated voltage, and below ±4% and ±2° at 2% of the rated voltage, respectively. Full article

With the rapid development of electrified railways in high-altitude regions, section insulators in catenary systems frequently experience gap breakdown and surface flashover under low atmospheric pressure conditions, posing serious threats to safe train operation. This paper investigates the discharge mechanisms of section insulators in high-altitude environments and conducts research on discharge characteristics under extremely non-uniform electric fields, along with structural optimization. First, the physical mechanisms of gap discharge and surface flashover in section insulators are analyzed. A three-dimensional electric field simulation model of the section insulator is established, and numerical analysis is performed to reveal the electric field distribution characteristics. The results indicate that the electric field is predominantly concentrated at the junction between metal electrodes and insulators, as well as at the tip of the arcing horn. The local maximum field strength reaches 3.84 × 10⁵ V/m, exceeding the corona inception field strength of air, which readily induces discharge. Subsequently, power frequency and lightning impulse discharge tests are conducted in both plain region and regions at an altitude of 4300 m. The results show that under high-altitude conditions, the power frequency breakdown voltage decreases by 28%, and the 50% lightning impulse breakdown voltage decreases by 42%. The discharge voltages under standard atmospheric conditions are obtained through correction. Finally, optimization schemes involving arcing horn structural modification and surface coating application are proposed. Adjusting the arcing horn angle to 55° and adding a grading ring structure with a radius of 70 mm reduces the local maximum field strength by 26%. After applying an RTV insulating coating, the field strength at the junction decreases by 35.9%, effectively enhancing the insulation performance of section insulators in high-altitude regions. Full article

To address the stringent insulation safety requirements of modern high-voltage transformers, accurately characterizing the transient electric field is critical. However, a significant problem remains: current engineering models typically rely on static capacitive distributions, failing to capture the dynamic electric field distortion induced by rapid space charge injection under lightning impulses. Therefore, a non-contact spatial electric field measurement method based on the optical Kerr effect was employed to analyze the influence of electrode material, voltage amplitude, and wavefront time. Unlike traditional simulation models that often assume constant mobility and focus solely on the shielding effect, this study reveals a non-monotonic electric field evolution driven by a ‘Static-Dynamic’ mode transition. The proposed model highlights two critical breakthroughs: (1) Mechanism Innovation: It experimentally verifies that charge injection is governed by the ion charge-to-mass ratio rather than just the work function, leading to a newly identified field enhancement phase during the wavefront that overcomes the limitations of capacitive models that underestimate transient stress. (2) Parameter Quantification: Precise spatiotemporal thresholds are established—negative charges traverse the gap within ~200 ns, while positive charges require ~10 μs to reach equilibrium. These findings provide experimentally calibrated time constants for simulation correction and offer new criteria for optimizing electrode materials in UHV transformers to mitigate transient field distortion. Full article

As distribution networks become increasingly intelligent, primary–secondary integrated distribution switches are replacing the traditional electromagnetic type. However, the high degree of integration intensifies inherent electromagnetic compatibility (EMC) challenges. This paper presents a field-circuit hybrid full-wave model to investigate switch characteristics during lightning strikes. A 3D full-wave model of the switch and a distributed parameter circuit model of the connecting lines are coupled via a network parameter matrix. This approach comprehensively accounts for the impacts of transmission lines and structural components on electromagnetic disturbances. Simulation and experimental results reveal that lightning strikes induce high-frequency damped oscillatory waves, primarily caused by traveling wave reflections along overhead lines. The characteristic frequency of disturbance is inversely proportional to the transmission line length. Additionally, internal components significantly influence this frequency; specifically, a larger voltage dividing capacitance in the voltage transformer results in a lower frequency. Model validation was performed using a 20 m transmission line setup. A 75 kV standard lightning impulse was injected into Phase B. At a distance of 500 mm from the voltage transformer, the measured radiated electric field amplitude was 14.12 kV/m (deviation < 5%), and the characteristic frequency was 1.11 MHz (deviation < 20%). These findings offer vital guidance for the lightning protection and EMC design of primary–secondary integrated distribution switches. Full article

To enhance the accuracy and timeliness of field testing for grounding impulse impedance in complex soil environments, this paper addresses the limitations of traditional peak-ratio methods—such as susceptibility to noise interference and the inability to reflect dynamic impedance variations—by proposing an identification method that combines an improved Hanning window with recursive least squares (RLS). During signal preprocessing, an improved Hanning window with adjustable parameters and energy normalization is employed to enhance the main-lobe energy concentration of impulse voltage and current signals while effectively suppressing high-frequency sidelobe leakage. In the parameter estimation stage, a low-order discrete linear model is established and an RLS algorithm with a forgetting factor is introduced to achieve full-time adaptive estimation of impulse impedance. Using a simulated surge test circuit, 18 sets of typical operating conditions with varying inductance and resistance parameters are designed. The same voltage and current data are processed using three processing methods: no windowing, standard Hanning windowing, and improved Hanning windowing. Results show that the average relative error of surge impedance is 9.16% without windowing, the standard Hanning window reduced the error to 3.78%, and the modified Hanning window further decreased the error to approximately 1.51%. Comparative analysis of different forgetting factor settings indicates that a value of approximately λ = 0.98 achieves an optimal trade-off between dynamic tracking capability and steady-state smoothness. The research results demonstrate that the proposed method achieves high identification accuracy for impact impedance and exhibits satisfactory parameter robustness under strong noise and multiple operating conditions, providing a reference for grounding impact characteristic testing and lightning protection design. Full article

An increasing number of different types of dielectric liquids are appearing on the market. This is undoubtedly related to sustainable development goals. This paper presents comparative studies of the lightning impulse breakdown voltage (LIBV) of six dielectric liquids with different chemical compositions: naphthenic uninhibited mineral oil (UMO), naphthenic inhibited mineral oil (IMO), natural ester (NE), synthetic ester (SE), bio-based hydrocarbon (BIO), and an inhibited liquid produced using gas-to-liquids technology (GTL). Tests were conducted in a point-to-sphere electrode configuration with a 5 mm thick pressboard barrier placed between them. This configuration was designed to more closely replicate the actual configuration found in transformers, where the oil channels are separated by pressboard barriers. Tests were performed for two inter-electrode gap distances of 25 mm and 40 mm, and for both lightning impulse voltage polarities. The pressboard barrier was placed so that the distance between point electrode and the barrier was always the same (10 mm). Measurements were performed using the step method. Before measurements began, the pressboard barrier was impregnated with the dielectric liquid being tested. The obtained measurement results were compared with previous studies conducted by the authors, which used a similar electrode system but without the pressboard barrier. The results confirmed that inserting the pressboard barrier between the electrodes effectively inhibits development of discharges and significantly increases the electrical strength of the entire insulation system. Full article

Lightning impulse tests are conducted on distribution equipment to assess whether the insulation level meets factory standards and to identify potential insulation defects. Such tests enhance the safety and stability of distribution network operation. Firstly, in order to address the issue of complex types and diverse structures of distribution network equipment, by using portable lightning impulse generators and adopting the method of automatically generating test reports, the requirements for test sites and test procedures have been simplified. Secondly, the generation and regulation of standard lightning waveforms were analyzed, and the influencing factors were pointed out. Finally, several distribution equipment such as disconnectors were subject to on-site impulse tests in accordance with the standards, and the general process of on-site standard lightning impulse tests was summarized. Full article

High-voltage ceramic insulators are routinely exposed to short-duration overvoltages such as lightning impulses, switching surges, and partial discharges. These events occur on microsecond to millisecond timescales and can produce highly localized thermal spikes that are difficult to measure directly but may compromise long-term material integrity. This paper addresses the estimation of the internal temperature distribution immediately after a lightning impulse by solving a three-dimensional inverse heat conduction problem (IHCP). The forward problem is modeled by the transient heat diffusion equation with constant thermal diffusivity, discretized using the finite element method (FEM). Surface temperature measurements are assumed available from a 12 kV ceramic post insulator and are used to reconstruct the unknown initial condition. To address the ill-posedness of the IHCP, a spatio-temporal regularization framework is introduced and compared against spatial-only regularization. Numerical experiments investigate the effect of measurement time ($T=60$ s, 600 s, and 1800 s), mesh resolution (element sizes of 20 mm, 15 mm, and 10 mm), and measurement noise ($\sigma =1$ K and 5 K). The results show that spatio-temporal regularization significantly improves reconstruction accuracy and robustness to noise, particularly when early-time measurements are available. Moreover, it is observed that mesh refinement enhances accuracy but yields diminishing returns when measurements are delayed. These findings demonstrate the potential of spatio-temporal IHCP methods as a diagnostic tool for the condition monitoring of ceramic insulators subjected to transient electrical stresses. Full article

Lightning is a common cause of failure in high-voltage transmission lines. This paper uses physical models of positive and negative discharges to analyze the differences in discharge characteristics between rod–plane and conductor–tower gaps. It also explores the influence of different tower structures on the discharge process. The simulation results show that negative leaders develop in a stepped manner and progress rapidly, while positive leaders develop continuously and progress more slowly. Under the same lightning impulse voltage level, negative discharges exhibit higher breakdown voltages. The development speed of positive discharges is mainly influenced by the applied voltage, while negative discharges are less affected by the applied voltage. For the same gap distance, the 50% breakdown voltages in the conductor–tower model are significantly higher than those in the rod–plane model for both polarities. Additionally, under shorter gap conditions, negative discharges may not show distinct stepped characteristics. This study provides theoretical guidance and practical references for lightning protection design and engineering applications in high-voltage transmission lines. Full article

In recent years, arresters in 10 kV distribution transformer areas of the Guangdong power grid have exhibited a rising trend of premature failures, posing a serious threat to distribution network reliability. This paper studied the failure causes of arresters through performance tests on failed arresters and through deterioration tests on new arresters and their prorated sections under typical operating stresses. The failed arresters and their internal varistors displayed varying degrees of physical damage and pronounced degradation in electrical performance, characterized by a strong polarity effect on the DC reference voltage (U_1mA), elevated DC leakage current (I_L) and resistive current (i_R), and excessive residual voltage (U_5kV). In the lightning impulse test, varistors primarily showed pinhole-type damage and significant polarity effects on ΔU_1mA. In the AC aging test, ΔU_5kV increased markedly. In the water immersion test, varistors exhibited salt deposits and aluminum electrode blackening, with ΔU_1mA decreasing, while I_L and Δi_R increased significantly. Overall, internal moisture superimposed on other operating stresses was identified as a major internal cause of arrester failure, while pollution flashover of the housing was considered the primary external factor. Corresponding improvement measures in material optimization, testing and inspection, and operation and maintenance are proposed to enhance arrester reliability. Full article

Overvoltages are brief and significant increases in the voltage level in an electrical system. They can be caused by a variety of factors, but the most common are associated with atmospheric discharges (lightning). When lightning strikes a power line, the resulting shock wave can induce surges in electrical equipment that is connected to that line, including transformers. The authors develop an analytical method in order to determine the maximum values of the overvoltages propagating in the transformer windings in case of lightning impulse. It is considered that the transmitted overvoltages consist of an inductive component (magnetic dispersion is neglected, as well as the energy exchange between the capacitances and inductances of the energized winding) and a capacitive component (between the energized winding and the receiving winding; in this case, the emphasis is on the energy exchange between the series capacitance and the inductance of the series winding). The proposed method was applied on a TTUS—ONAN/ONAF 31.5/40 MVA, 110/5/6.6 kV power transformer, and the obtained results were validated by experimental tests. The percentage error between the results obtained by modeling and the results obtained from transformer testing was less than 2%. Full article

In this paper, results of comparative studies on the positive lightning impulse breakdown voltage (LIBV) and accelerating voltage (V_a) of six insulating liquids of different chemical composition are presented. This paper discusses the behavior of uninhibited naphthenic mineral oil (UMO), inhibited naphthenic mineral oil (IMO), natural ester (NE), synthetic ester (SE), and two modern dielectric fluids: bio-based hydrocarbon (BIO) and inhibited liquid produced using Gas-to-Liquids (GTL) technology. Measurements are taken in a point-to-sphere electrode system for two selected gap distances: 25 mm (which is suggested by the IEC 60897 standard) and 40 mm. After analyzing the obtained results, it is noted that positive LIBV does not differ significantly between the tested liquids. Noticeable differences are observed, however, for V_a. The lowest values of this parameter characterize ester liquids, which is consistent with the common knowledge in this field. In addition, the obtained values of LIBV and V_a are used to evaluate the maximum values of electric field intensity through the application of simulations for each specific case based on the finite element method. These simulations confirm that, for a given parameter, maximum electric field stress is on similar level, regardless of the gap distance. This proves that the breakdown and appearance of fast discharges are determined by specific field conditions. Full article

Arresters on electric multiple units (EMUs) usually experience premature aging under a high-frequency voltage and impulse current. In addition, they lead to overheating faults when subjected to the high-frequency overvoltage of electric railways. This research investigates the aging behavior of arresters when subjected to overvoltage and an impact current. An analysis was conducted on the impact of the aging duration at 1 mA and the frequency of overvoltage on a lightning arrester’s outer-layer components. The results show that the 1 mA DC reference voltage of the MOA sheet decreased, and the leakage current significantly increased at a 0.75 DC reference voltage through the aging of high-frequency voltage, and the duration of the applied voltage and the voltage bearing rate had similar effects on the two parameters. After aging, the Co and Bi elements on the surface of zinc oxide decreased and migrated to the depletion layer, resulting in a decrease in the dispersion characteristics of the zinc oxide agglomerate surface. Under the impulse voltage, the thermal stress on the surface of the zinc oxide increased, resulting in the damage to the zinc oxide grains, which aggravated the thermal stress concentration and reduced the performance of the zinc oxide. This study reveals the deterioration mechanism of high-frequency voltage- and impulse current gap-modulated MOA materials and provides a theoretical basis and data support for the development of and monitoring methods for new lightning arresters. Full article

This study examines and compares the breakdown and aging properties of five insulating liquids. Additionally, the influence of different voltage polarities on these properties was analyzed to investigate the effect of aging on polarity behavior under lightning impulse voltage in a semi-uniform field. The results were compared to standardized AC breakdown tests. After 2330 h and 4350 h of aging, changes were observed in key aging indicators such as water content (both absolute and relative), total acid number, and color across all liquids. Viscosity increased by up to 10% in natural esters. Notably, the rise in water content due to aging was concerning only for mineral oil, exceeding 20%. The impact of aging on breakdown voltage varied depending on the voltage type and polarity. Aging had the least effect under negative lightning impulse voltage, while the synthetic ester MIDEL 7131 exhibited the most significant reduction in breakdown voltage under positive lightning impulse voltage, dropping by over 24%, from more than 560 kV to 428 kV. In contrast, mineral oil showed only a 3% decrease. For the other liquids, the most pronounced reduction in breakdown voltage due to aging occurred under AC voltage, with natural esters showing a 17% decline, synthetic esters 26%, and mineral oil experiencing a 38% reduction. Full article
