Search Results (108)

In many IIoT-based yard operations, accurately identifying the spatial position of containers is becoming increasingly relevant as operators try to automate stacking and retrieval processes by technologies like Container Spatial Localization (CSL). Despite this automation in IIoT, RTK-GPS–based container stacker positioning frequently lacks precision, which causes disruptions in stacking and reduces efficiency in space utilisation. Though it offers placement precision accurately up to 3 cm, this is still insufficient in high-volume Yard Management Systems (YMS). Consequently, this yields to variable container orientation, waste of usable space, increased man input is required in handling goods, and potential automated system failures. This research proposes a novel methodology that combines conventional RTK-GPS measurements with angular information captured from a BHI-260AP–based spreader sensor, allowing the system to correct container placement errors arising from orientation rather than only from positioning. In addition to the spatial positioning problem, we found that continuous IIoT operation raises concerns regarding energy use, particularly when micro-controllers remain active throughout the task cycle. As a solution, this integrates a dynamic task scheduling approach that puts the device in sleep modes whenever computation is not required. In our experiments, this strategy improved overall power efficiency by 34.44%, which makes long automated operation more practical. Full article

Steer-by-wire (SBW) systems in wheel-steering vehicles enhance maneuverability by eliminating mechanical linkages. However, they are susceptible to delays between steering input and pinion response, which can compromise control precision and safety. To mitigate these delays, we developed a machine learning-based compensation method employing a hybrid architecture of convolutional neural networks (CNNs) and gated recurrent units (GRUs) to predict and adjust pinion behavior in real time. The model was trained using experimental data collected from a four-wheel steering test platform, including steering angle inputs, motor signals, and pinion position feedback. By learning the relationship between steering commands and rack force, the model enables dynamic delay correction under both nominal and fault conditions. The system is implemented on an NXP microcontroller and validated through experimental testing, and compared with other hybrid model configurations for performance evaluation. The results demonstrate that the CNN–GRU approach reduces the average steering delay to 3 ms, outperforming conventional PID tuning methods while maintaining high accuracy and system stability. Full article

Cattle behavior is closely related to their health status, and monitoring cattle behavior using intelligent devices can assist herders in achieving precise and scientific livestock management. Current behavior recognition algorithms are typically executed on server platforms, resulting in increased power consumption due to data transmission from edge devices and hindering real-time computation. An edge-based cattle behavior recognition method via Graph Neural Network (GNN) compression is proposed in this paper. Firstly, this paper proposes a wearable device that integrates data acquisition and model inference. This device achieves low-power edge inference function through a high-performance embedded microcontroller. Secondly, a sequential residual model tailored for single-frame data based on Inertial Measurement Unit (IMU) and displacement information is proposed. The model incrementally extracts deep features through two Residual Blocks (Resblocks), enabling effective cattle behavior classification. Finally, a compression method based on GNNs is introduced to adapt edge devices’ limited storage and computational resources. The method adopts GNNs as the backbone of the Actor–Critic model to autonomously search for an optimal pruning strategy under Floating-Point Operations (FLOPs) constraints. The experimental results demonstrate the effectiveness of the proposed method in cattle behavior classification. Moreover, enabling real-time inference on edge devices significantly reduces computational latency and power consumption, thereby highlighting the proposed method’s advantages for low-power, long-term operation. Full article

Manual window cleaning in high-rise urban buildings is labor-intensive, risky, and resource-inefficient. This study addresses these challenges by investigating a resource-aware mechatronic architecture through the design, development, and experimental validation of a modular Automated Window Cleaning System (AWCS). Unlike conventional open-loop solutions, the AWCS integrates mechanical scrubbing with a closed-loop fluid management system, featuring precise dispensing and vacuum-assisted recovery. The system is governed by a deterministic finite state machine implemented on an ESP32 microcontroller, enabling low-latency IoT connectivity and autonomous operation. Two implementation variants—integrated and retrofit—were validated to ensure structural adaptability. Experimental results across 30 cycles demonstrate a cleaning efficiency of ~2 min/m², a water consumption of <150 mL/m² (representing a >95% reduction compared to manual methods), and an optical cleaning efficacy of 96.9% ± 1.4%. Safety protocols were substantiated through a calculated mechanical safety factor of 6.12 for retrofit applications. This research establishes the AWCS as a sustainable, safe, and scalable solution for autonomous building maintenance, contributing to the advancement of resource-circular domestic robotics and smart home automation. Full article

As Battery Management Systems (BMSs) continue to expand in both scale and capacity, conventional state-of-charge (SOC) estimation methods—such as Coulomb counting and model-based observers—face increasing challenges in meeting the requirements for cell-level precision, scalability, and adaptability under aging and operating variability. To address these limitations, this study integrates a Deep Neural Network (DNN)–based estimation framework into a node-level BMS architecture, enabling edge-side computation at each individual battery cell. The proposed architecture adopts a decentralized node-level structure with distributed parameter synchronization, in which each BMS node independently performs SOC estimation using shared model parameters. Global battery characteristics are learned through offline training and subsequently synchronized to all nodes, ensuring estimation consistency across large battery arrays while avoiding centralized online computation. This design enhances system scalability and deployment flexibility, particularly in high-voltage battery strings with isolated measurement requirements. The proposed DNN framework consists of two identical functional modules: an offline training module and a real-time estimation module. The training module operates on high-performance computing platforms—such as in-vehicle microcontrollers during idle periods or charging-station servers—using historical charge–discharge data to extract and update battery characteristic parameters. These parameters are then transferred to the real-time estimation chip for adaptive SOC inference. The decentralized BMS node chip integrates preprocessing circuits, a momentum-based optimizer, a first-derivative sigmoid unit, and a weight update module. The design is implemented using the TSMC 40 nm CMOS process and verified on a Xilinx Virtex-5 FPGA. Experimental results using real BMW i3 battery data demonstrate a Root Mean Square Error (RMSE) of 1.853%, with an estimation error range of [4.324%, −4.346%]. Full article

This study outlines the design and evaluation of a biomimetic robotic hand tailored for Human–Robot Interaction (HRI), focusing on improvements in tactile fidelity driven by material choice. Thermoplastic polyurethane (TPU) was selected over polylactic acid (PLA) based on its reported elastomeric characteristics and mechanical compliance described in prior literature. Rather than directly matching human skin properties, TPU was perceived as providing a softer and more comfortable tactile interaction compared to rigid PLA. The robotic hand was anatomically reconstructed from an open-source model and integrated with AX-12A and MG90S actuators to simplify wiring and enhance motion precision. A custom PCB, built around an ATmega2560 microcontroller, enables real-time communication with ROS-based upper-level control systems. Angular displacement analysis of repeated gesture motions confirmed the high repeatability and consistency of the system. A repeated-measures user study involving 47 participants was conducted to compare the PLA- and TPU-based prototypes during interactive tasks such as handshakes and gesture commands. The TPU hand received significantly higher ratings in tactile realism, grip satisfaction, and perceived responsiveness (p < 0.05). Qualitative feedback further supported its superior emotional acceptance and comfort. These findings indicate that incorporating TPU in robotic hand design not only enhances mechanical performance but also plays a vital role in promoting emotionally engaging and natural human–robot interactions, making it a promising approach for affective HRI applications. Full article

This article presents the design, fabrication, and experimental validation of a centimeter-scale autonomous robot that achieves bidirectional locomotion and trajectory control through 3D-printed resonators actuated by piezoelectricity and integrated with miniature legs. Building on previous works that employed piezoelectric bimorphs, the proposed system replaces them with custom-designed 3D-printed resonant plates that exploit the excitation of standing waves (SW) to generate motion. Each resonator is equipped with strategically positioned passive legs that convert vibratory energy into effective thrust, enabling both linear and rotational movement. A differential drive configuration, implemented through two independently actuated resonators, allows precise guidance and the execution of complex trajectories. The robot integrates onboard control electronics consisting of a microcontroller and inertial sensors, which enable closed-loop trajectory correction via a PD controller and allow autonomous navigation. The experimental results demonstrate high-precision motion control, achieving linear displacement speeds of 8.87 mm/s and a maximum angular velocity of 37.88°/s, while maintaining low power consumption and a compact form factor. Furthermore, the evaluation using the mean absolute error (MAE) yielded a value of 0.83° in trajectory tracking. This work advances the field of robotics and automatic control at the insect scale by integrating efficient piezoelectric actuation, additive manufacturing, and embedded sensing into a single autonomous platform capable of agile and programmable locomotion. Full article

With the growing number of applications in embedded systems—such as IoT modules, smart sensors, and wearable devices—there is an increasing demand for fast and accurate computations on resource-constrained platforms. In this paper, we present a new method for computing n-th roots in floating-point arithmetic based on an initial estimate generated by a “magic constant,” followed by one or two iterations of a modified Newton–Raphson or Householder algorithm. For cubic and quartic roots, we provide C implementations operating in single-precision floating-point format. The proposed algorithms are evaluated in terms of maximum relative error and execution time on selected microcontrollers. They exhibit high accuracy and noticeably reduced computation time. For example, our methods for computing cubic roots outperform the standard library function cbrtf() in both speed and precision. The results may be useful in a variety of fields, including biomedical and biophysical applications, statistical analysis, and real-time image and signal processing. Full article

Silicon nanowire (SiNW) photodetectors exhibit high sensitivity for natural light detection but suffer from significant performance degradation due to thermal interference. To overcome this limitation, this paper presents a high-performance, CMOS-compatible SiNW array natural light photodetector with monolithic integration of an on-chip temperature sensor and an embedded intelligent compensation system. The device, fabricated via microfabrication techniques, features a dual-array architecture that enables simultaneous acquisition of optical and thermal signals, thereby simplifying peripheral circuitry. To achieve high-precision decoupling of the optical and thermal signals, we propose a hybrid temperature compensation algorithm that combines Particle Swarm Optimization (PSO) with a Back Propagation (BP) neural network. The PSO algorithm optimizes the initial weights and thresholds of the BP network, effectively preventing the network from getting trapped in local minima and accelerating the training process. Experimental results demonstrate that the proposed PSO-BP model achieves superior compensation accuracy and a significantly faster convergence rate compared to the traditional BP network. Furthermore, the optimized model was successfully implemented on an STM32 microcontroller. This embedded implementation validates the feasibility of real-time, high-accuracy temperature compensation, significantly enhancing the stability and reliability of the photodetector across a wide temperature range. This work provides a viable strategy for developing highly stable and integrated optical sensing systems. Full article

To meet the demand for online monitoring of acetylene (C₂H₂) in transformer oil, a high-sensitivity detection system based on photoacoustic spectroscopy (PAS) is presented. The system integrates custom-designed modules for signal acquisition, phase-sensitive detection, and data processing, centered around a high-performance microcontroller. A full-wave lock-in amplification-based phase-sensitive detection circuit enables precise extraction of nV-level photoacoustic signals. Finite element simulations of the resonant photoacoustic cell in COMSOL 6.2 were conducted to optimize the structural configuration and sensor placement, achieving maximum acoustic response. Calibration experiments confirmed excellent system performance, demonstrating a linear response (R² > 0.99) over the 0.5–20 ppm range and a practical detection limit of 0.1 ppm. Comparative evaluations against conventional dissolved gas analysis (DGA) equipment verify the system’s sensitivity, stability, and temporal resolution, demonstrating its potential as a high-sensitivity and reliable solution for transformer fault gas diagnostics. Full article

Multi-sensor systems require precise time synchronization for accurate data fusion. However, currently prevalent software time synchronization methods often rely on clocks provided by the Global Navigation Satellite System (GNSS), which may not offer high accuracy and can be easily affected by issues with GNSS signals. To address this limitation, this study introduces a novel laser pulse-driven time synchronization (LPTS) method in our custom-developed Light Detecting and Ranging (LiDAR) system. The LPTS method uses electrical pulses, synchronized with laser beams as the time synchronization source, driving the Micro-Controller Unit (MCU) timer within the control system to count with a timing accuracy of 0.1 $\mathsf{\mu }$s and to timestamp the data from the Positioning and Orientation System (POS) unit or laser scanner unit. By employing interpolation techniques, the POS and laser scanner data are precisely synchronized with laser pulses, ensuring strict correlation through their timestamps. In this article, the working principles and experimental methods of both traditional time synchronization (TRTS) and LPTS methods are discussed. We have implemented both methods on experimental platforms, and the results demonstrate that the LPTS method circumvents the dependency on external time references for inter-sensor alignment and minimizes the impact of laser jitter stemming from third-party time references, without requiring additional hardware. Moreover, it elevates the internal time synchronization resolution to 0.1 $\mathsf{\mu }$s and significantly improves relative timing precision. Full article

The proliferation of power converters in modern energy production systems has led to increased harmonic content due to the commutation of active switching devices. This increase in harmonics contributes to lower system efficiency, reduced power factor, and consequently, a higher reactive power requirement. To address these issues, this paper presents both simulation and experimental results of various control strategies implemented on Parallel Voltage Source Inverters (PVSI) for harmonic mitigation. The proposed control strategies are categorized into direct and indirect control methods. The direct control techniques implemented include the instantaneous power method (PQ), the synchronous algorithm (DQ), the maximum principle method (MAX), the algorithm based on synchronization of current with the voltage positive-sequence component (SEC-POZ), and two methods employing the separating polluting components approach using a band-stop filter and a low-pass filter. The main innovation in these active power filter (APF) control strategies, compared to traditional or existing technologies, is the real-time digital implementation on high-speed platforms, specifically FPGAs. Unlike slower microcontroller-based systems with limited processing capabilities, FPGA-based implementations allow parallel processing and high-speed computation, enabling the execution of complex control algorithms with minimal latency. Additionally, the enhanced reference current generation achieved through the seven applied methods provides precise harmonic compensation under highly distorted and nonlinear load conditions. Another key advancement is the integration with Smart Grid functionalities, allowing IoT connectivity and remote diagnostics, which enhances system monitoring and operational flexibility. Following validation on an experimental test bench, these algorithms were implemented and tested on industrial APF prototypes powered by a standardized three-phase network supply. All control strategies demonstrated an effective reduction in total harmonic distortion (THD) and improvement in power factor. Experimental findings were used to provide recommendations for choosing the most effective control solution, focusing on minimizing THD and enhancing system performance. Full article

Atrial fibrillation (AF) is the most common type of heart rhythm disorder worldwide. Early recognition of brief episodes of atrial fibrillation can provide important diagnostic information and lead to prompt treatment. AF is mainly characterized by an irregular heartbeat. Today, many personal devices such as smartphones, smartwatches, smart rings, or small wearable medical devices can detect heart rhythm. Sensors can acquire different types of heart-related signals and extract the sequence of inter-beat intervals, i.e., the instantaneous heart rate. Various algorithms, some of which are very complex and require significant computational resources, are used to recognize AF based on inter-beat intervals (RR). This study aims to verify the possibility of using neural networks algorithms directly on a microcontroller connected to sensors for AF detection. Sequences of 25, 50, and 100 RR were extracted from a public database of electrocardiographic signals with annotated episodes of atrial fibrillation. A custom 1D convolutional neural network (1D-CNN) was designed and then validated via a 5-fold subject-wise split cross-validation scheme. In each fold, the model was tested on a set of 3 randomly selected subjects, which had not previously been used for training, to ensure a subject-independent evaluation of model performance. Across all folds, all models achieved high and stable performance, with test accuracies of 0.963 ± 0.031, 0.976 ± 0.022, and 0.980 ± 0.023, respectively, for models using 25 RR, 50 RR, and 100 RR sequences. Precision, recall, F1-score, and AUC-ROC exhibited similarly high performance, confirming robust generalization across unseen subjects. Performance systematically improved with longer RR windows, indicating that richer temporal context enhances discrimination of AF rhythm irregularities. A complete Edge AI prototype integrating a low-power ECG analog front-end, an ARM Cortex M7 microcontroller and an IoT transmitting module was utilized for realistic tests. Inferencing time, peak RAM usage, flash usage and current absorption were measured. The results obtained show the possibility of using neural network algorithms directly on microcontrollers for real-time AF recognition with very low power consumption. The prototype is also capable of sending the suspicious ECG trace to the cloud for final validation by a physician. The proposed methodology can be used for personal screening not only with ECG signals but with any other signal that reproduces the sequence of heartbeats (e.g., photoplethysmographic, pulse oximetric, pressure, accelerometric, etc.). Full article

This paper presents an electromagnetic levitation system that stabilizes a magnetic body using an array of electromagnets controlled by a Hall-effect sensor array and TinyML-based position detection. Departing from conventional optical tracking methods, the proposed design combines finite-element-optimized electromagnets with a microcontroller-optimized neural network that processes sensor data to predict the levitated object’s position with 0.0263–0.0381 mm mean absolute error. The system employs both quantized and full-precision implementations of a supervised multi-output regression model trained on spatially sampled data (40 × 40 × 15 mm volume at 5 mm intervals). Comprehensive benchmarking demonstrates stable operation at 850–1000 Hz control frequencies, matching optical systems’ performance while eliminating their cost and complexity. The integrated solution performs real-time position detection and current calculation entirely on-board, requiring no external tracking devices or high-performance computing. By achieving sub 30 μm accuracy with standard microcontrollers and minimal hardware, this work validates machine learning as a viable alternative to optical position detection in magnetic levitation systems, reducing implementation barriers for research and industrial applications. The complete system design, including electromagnetic array characterization, neural network architecture selection, and real-time implementation challenges, is presented alongside performance comparisons with conventional approaches. Full article

Typical fertilizer applicators are often restricted in performance due to non-uniformity in distribution, required labor and time intensiveness, high discharge rate, chemical input wastage, and fostering weed proliferation. To address this gap in production agriculture, an automated variable-rate fertilizer applicator was developed for the cotton crop that is based on deep learning-initiated electronic control unit (ECU). The applicator comprises (a) plant recognition unit (PRU) to capture and predict presence (or absence) of cotton plants using the YOLOv7 recognition model deployed on-board Raspberry Pi microprocessor (Wale, UK), and relay decision to a microcontroller; (b) an ECU to control stepper motor of fertilizer metering unit as per received cotton-detection signal from the PRU; and (c) fertilizer metering unit that delivers precisely metered granular fertilizer to the targeted cotton plant when corresponding stepper motor is triggered by the microcontroller. The trials were conducted in the laboratory on a custom testbed using artificial cotton plants, with the camera positioned 0.21 m ahead of the discharge tube and 16 cm above the plants. The system was evaluated at forward speeds ranging from 0.2 to 1.0 km/h under lighting levels of 3000, 5000, and 7000 lux to simulate varying illumination conditions in the field. Precision, recall, F1-score, and mAP of the plant recognition model were determined as 1.00 at 0.669 confidence, 0.97 at 0.000 confidence, 0.87 at 0.151 confidence, and 0.906 at 0.5 confidence, respectively. The mean absolute percent error (MAPE) of 6.15% and 9.1%, and mean absolute deviation (MAD) of 0.81 g/plant and 1.20 g/plant, on application of urea and Diammonium Phosphate (DAP), were observed, respectively. The statistical analysis showed no significant effect of the forward speed of the conveying system on fertilizer application rate (p > 0.05), thereby offering a uniform application throughout, independent of the forward speed. The developed fertilizer applicator enhances precision in site-specific applications, minimizes fertilizer wastage, and reduces labor requirements. Eventually, this fertilizer applicator placed the fertilizer near targeted plants as per the recommended dosage. Full article
