A novel assembled integral multi-ribbed composite floor system consisting of precast panels and a cast in situ topping has previously been validated through full-scale one-way and two-way slab experiments. Although the global load capacity of the system was initially verified, the experiments reveal that the concrete-to-concrete interfacial behavior between the precast panel and the cast in situ topping is a critical factor governing internal force redistribution and its post-cracking performance. To uncover the governing interfacial mechanism, this study develops a refined three-dimensional nonlinear finite element model using a coupled cohesive–frictional interface interaction, where a surface-based cohesive interaction captures the initial interfacial debonding and a penalty-based Coulomb friction model describes the subsequent shear-slip behavior. The model reproduces the cracking patterns, load-deflection relationship, and failure modes, with the relative error of load capacity, initial stiffness and crack load all less than 15%. Parametric analyses further indicate that the interfacial shear-transfer mechanism governs post-cracking stress redistribution across the multi-ribbed section, preventing premature delamination and ensuring efficient mobilization of the section’s flexural resistance. To effectively restrain this interfacial slip, an improved shear-key configuration is proposed to activate an enhanced mechanical interlocking mechanism. Numerical results confirm that the improved configuration effectively suppresses macro-sliding and redistributes local stress concentrations, thereby enhancing the structural integrity and flexural efficiency of precast composite floor systems. Full article

This study proposes a deep-notched precast concrete slab system with post-cast connections for modular construction, aiming to improve on-site assembly efficiency while maintaining flexural continuity. A total of 22 full-scale slab specimens, including monolithic cast-in-place slabs and precast slabs with different notch depths, anchorage lengths, reinforcement diameters, and notch geometries, were tested under positive and negative bending conditions. The experimental results showed that, for the investigated reinforcement layout and loading conditions, the connected slabs with adequate anchorage achieved approximately 85% and 95% of the flexural capacity of the corresponding cast-in-place slabs under positive and negative bending, respectively. Anchorage length was found to be a key factor governing failure mode and load-transfer efficiency, while reinforcement diameter had a significant influence on ultimate capacity. Within the tested range, notch depth and notch geometry showed comparatively limited effects on flexural capacity, although their influence should be interpreted in relation to the adopted reinforcement arrangement and anchorage conditions. Finite element models based on the concrete damage plasticity approach were developed to interpret the load-transfer mechanism and parameter sensitivity. The models predicted the ultimate load with acceptable accuracy, while larger discrepancies were observed in some displacement estimates because of the simplification of interface behavior, bond-slip response, and local cracking. The experimental and numerical results indicate that load transfer across the joint was mainly achieved through reinforcement bridging, whereas the contribution of concrete bonding at the joint was limited under the investigated conditions. Based on these findings, a modified analytical model was proposed to predict the ultimate flexural capacity of the connected slabs. The model showed reasonable agreement with the test results for specimens with adequate anchorage. The proposed connection provides a feasible detailing solution for precast concrete slab connections in modular construction, but its application should be limited to configurations with comparable reinforcement layout, anchorage conditions, material properties, and monotonic bending behavior. Full article

Protective reinforced-concrete (RC) elements designed to resist contact blast loading must reconcile high energy dissipation with material and weight efficiency. This study examines HollowHex, an RC slab architecture in which periodic hexagonal cellular voids redistribute blast-induced stresses along inclined web-walls through a Vierendeel-type framing action. A full-factorial design of experiments across web thickness, charge mass, and hexagonal cell radius was carried out with Abaqus/Explicit using a concrete-damaged-plasticity model and mass-dependent Friedlander overpressure histories calibrated to UFC 3-340-02 scaled-distance relations. A six-level mesh-convergence study with three independent fine-mesh verification runs established the residual mesh effect as regime-dependent, bounded within approximately 13% in the elastic and severe-damage regimes and approximately 18% in the transition regime. Ten surrogate-model families—linear, polynomial, kernel, ensemble, and multilayer-perceptron—were benchmarked under leave-one-out, 5-fold, and 7-fold cross-validation. The best models achieved out-of-sample R² = 0.96 for peak displacement and R² = 0.93 for a continuous damage volume ratio (DVR), with train-to-validation gaps of only 0.03 and 0.06, indicating genuine generalization on the small dataset. A direct identical-condition comparison against circular-hollow slabs of matched void area shows blast-equivalent performance across the elastic, transition, and severe damage regimes (peak displacements within 2%, damage volume ratios within 7%), positioning the hexagonal architecture as a blast penalty-free alternative whose selection can be driven by non-blast criteria. A cross-validated parametric design heatmap is provided as a screening tool within the verified envelope. The uniform loading idealization is cross-checked against the spatially resolved CONWEP model, conservative on peak displacement by a factor of approximately 3.5, while approximately damage-equivalent and the constitutive model is validated at the damage level against documented contact-explosion tests through coupled FEM–SPH simulation. The findings position HollowHex not as a universally superior geometry but as a quantitatively beneficial alternative within the service/transition design range of greatest practical interest for blast protection. Full article

Office buildings accumulate embodied carbon not only during construction but repeatedly throughout operation, driven by tenant improvements (TI). In contexts where regulatory and supply-chain constraints limit full design-for-disassembly, this paper explores partial decoupling of a dry slab system within the high-churn zone of a Seoul office. Two area-normalised indicators are introduced—cumulative intervention area ($A_{\mathrm{cum}}$) and Reconfiguration Carbon Intensity (RCI)—defined on the structural slab/panel boundary to complement the mass-weighted Circularity Index (CI). The indicators are demonstrated on a 17-storey Seoul office over 60 years across three scenarios: a wet composite baseline (S1), full-dry CLT (S2), and a hybrid placing CLT within the high-churn zone (S3). S3 reduces RCI by approximately 45% relative to the wet baseline, capturing 71.7% of the full-decoupling benefit while converting only 11.5% of the floor area to CLT—a benefit-to-conversion ratio of $6.2\times$. Both shares are fixed by the floor-plate geometry, so this ratio is a consequence of the high-churn zone’s concentration rather than an independent empirical finding. A joint-uncertainty stress test confirms that S3 outcomes lie entirely below S1 across plausible parameter ranges. A placement test compares three configurations of the same floor that differ only in CLT placement location relative to the high-churn zone. Mass-weighted CI cannot distinguish these configurations, whereas RCI ranges from no reduction to the full hybrid benefit depending on placement—isolating the diagnostic value of the use-phase indicator. Hybrid zone-scale decoupling offers a feasible pathway for use-phase decarbonisation without committing to full-floor dry construction. Full article

Foamed concrete has been used to construct lightweight embankments as a substitute for conventional fills, aiming to promote its engineering application in soft-soil regions. However, the dynamic response and safety mechanism of foamed concrete embankments during vehicle collision are not yet fully understood. In this paper, the safety performance of lightweight foamed concrete embankments under vehicle–guardrail collision and the optimal design of the guardrail foundation are investigated from the perspectives of lateral displacement and stress distribution. Through static uniaxial compression tests, the stress–strain curves, compressive strength, elastic modulus, and statistical variability of foamed concrete with six different mix proportions were obtained. On this basis, a coupled finite element model of the vehicle–guardrail–lightweight embankment system was established (the guardrail and its foundation were modeled using a linear elastic constitutive model, the embankment using a crushable foam model, and the vehicle using a 1.5 t passenger car model validated by full-scale crash tests). According to the passenger car impact conditions specified in current Chinese regulations (velocity 100 km/h, angle 20°), the peak lateral displacement and peak principal stress of the lightweight embankment were analyzed for four foundation base slab lengths (L₀, 1.1 L₀, 1.2 L₀, 1.3 L₀). The results show that increasing the base slab length effectively reduces lateral displacement and stress concentration. Increasing the length by 10–20% reduces the peak lateral displacement by up to 68%, and the peak principal stress remains far below the material strength. From the perspectives of structural stability and cost-effectiveness, a 10–20% increase in the base slab length is recommended. The ratio of the peak principal stress to the material strength can serve as a criterion for evaluating the safety margin and assessing the rationality of the foundation design. This study provides quantitative evidence for optimizing the guardrail foundation base slab length to enhance the collision safety of lightweight foamed concrete embankments, and the proposed design range offers a cost-effective reference for practical engineering applications in soft-soil regions. Full article

Night ventilation coupled with thermal mass is an effective means of reducing overheating in passive buildings. Successful systems require a high airflow rate coupled with enhanced convective heat transfer to the thermal mass. This work presents results for enhanced convection when the primary thermal mass is in the ceiling. Such mass distribution occurs, for example, in multi-story apartments in developing economies. Experimental results are measured in a scale model of a typical room. The original contribution is the use of upward-directed ventilation at an angle of 30° to 40° from a window located at a typical distance below the ceiling. At scaled air change rates of 4.9 air changes per hour, the measured convective heat transfer coefficient at the ceiling was 7.7 W/m² K. In contrast, when air flowed horizontally from the window, the heat transfer coefficient was 3.5 W/m² K or less, indicating that substantial improvement was gained by directing airflow toward the ceiling. To link the experimental results to an application in a full-size building, an approximate model is presented to estimate the impact of directed night ventilation on the thermal mass (specifically the concrete slab ceiling) and room air temperatures. Coupling angled flow with nighttime ventilation, the ceiling slab and peak daytime air temperature can be reduced by 5 °C compared to horizontal ventilation from a window at conventional height. These results have enabled collaborators in Gujarat, India, to launch tests in a full-scale home serving a low-income community without access to air conditioning. Full article

The application of ultra-high performance concrete (UHPC) in the hogging moment region significantly enhances the crack resistance of concrete slabs of composite girders with integrated piers, while also providing economic benefits. To investigate the crack resistance performance and develop a calculation method for crack width in hogging moment region of steel–UHPC–normal concrete (NC) composite girders, a full-scale bending test was conducted. Based on the test results, the post-cracking residual tensile strength of UHPC was determined according to the energy equivalence principle. A calculation method for reinforcement stress incorporating the tensile contribution of UHPC at a cracked section was proposed and then the applicability for current design codes for crack width calculation was evaluated. For the UHPC–NC interface, a corresponding crack width calculation method was developed. The results indicate that cracks initiated on the surface of the NC layer beneath the UHPC overlay at the cantilever root. Then cracks developed in sequence at the top surface of the UHPC layer cantilever root, the UHPC–NC interface, and the mid-plane of the girder-to-pier joint. Ultimately, UHPC cracks exhibited a “numerous and closely spaced” distribution, whereas NC cracks were “few and widely spaced.” When the residual tensile strength of UHPC at cracked section was considered, the mean value and average coefficient of variation in the ratios of calculated to measured reinforcement stresses for different sections were 1.07 and 0.10, respectively, which can be further used for crack width calculation. The mean ratios of code-predicted to measured UHPC crack widths for different sections using the Chinese code, French code, and European code were 1.10, 0.98, and 1.13, respectively, with corresponding average coefficients of variation of 0.25, 0.33, and 0.28; the Chinese code is recommended for UHPC crack width prediction. For the UHPC–NC interface, an expression for crack width calculation was derived using the comprehensive theory, and the mean ratio of calculated to measured values and the coefficient of variation were 1.08 and 0.18, respectively, demonstrating good predictive accuracy. Full article

Urban stormwater is often viewed as a drainage problem rather than a local water resource, even in areas where runoff capture could simultaneously reduce flooding and promote the reuse of non-potable water. This study develops, installs, and field-tests a decentralized, school-scale stormwater harvesting system that relocates permeable concrete, transforming it from a passive infiltration surface into a purpose-built capture and pretreatment interface. The system integrates a 3 m × 3 m permeable concrete slab with load-bearing sections, an impermeable underlayer to ensure controlled flow, a double-compartment sump for staged sedimentation and hydraulic damping, sequential filtration with sand/gravel and activated carbon, and a 5000 L storage tank. The prototype was implemented at CETis 105 in Querétaro, Mexico, and evaluated during its commissioning and operation in the 2023 rainy season. Field operations demonstrated reduced ponding in the catchment area and a reliable flow of runoff to the pretreatment units. In the sump compartments, apparent color decreased from 221 to 59 Pt-Co, turbidity from 46.8 to 12.9 NTU, and COD from approximately 30–35 to 15–18 mg·L⁻¹, corresponding to approximate pretreatment reductions of 73.3%, 72.4%, and 40–57%, respectively, before post-filtration. Conversely, the elevated pH, electrical conductivity, and total dissolved solids indicated interaction with fresh cementitious materials and dissolved ionic residues during initial operation, highlighting the need for curing, initial washing, and post-filtration verification before declaring compliance with reuse requirements. Therefore, the results support the feasibility of the proposed configuration as a decentralized, low-infrastructure architecture for localized runoff control and pretreatment, while confirming that full reuse validation still requires microbiological and post-filtration evaluation. The study provides a field-proven system design adaptable to school campuses and similar institutional environments for distributed stormwater management and non-potable water storage. Full article

This study combines theoretical analysis with experimental investigation to examine the hysteretic behavior and seismic mechanisms of self-centering timber frames incorporating reinforced concrete slabs through tests on two full-scale comparative specimens. One specimen was constructed with a floor slab, while the other was designed without a slab, and both were subjected to low-cycle reversed loading under identical test conditions. The seismic performance of the two specimens was comparatively evaluated in terms of hysteresis curves, load-carrying capacity, stiffness degradation, and energy dissipation capacity. The experimental results indicate that, under the adopted test configuration, the presence of the slab increases the initial stiffness of the frame by 81.25% and enhances its load-carrying capacity. In addition, prior to concrete cracking, the slab improves the energy dissipation efficiency through composite action. The slab also reduces the rate of post-tensioning loss by approximately 12.5%, indicating its beneficial role in mitigating such loss. Overall, this study provides both theoretical and experimental support for the quantitative evaluation of slab effects in self-centering timber frames. Full article

In this study, an on-site installation type track slab using glass fiber-reinforced polymer (GFRP) reinforcing bars was developed and analyzed for its structural response to high-speed train loading. Concrete track slabs have the most severe deterioration in track circuit characteristic values due to the conduction influence of existing steel bars. Therefore, a track slab applying an insulator and lightweight GFRP reinforcement by replacing the existing steel bar was proposed from a design perspective. In order to present the validity of the proposed method, a full-size specimen was manufactured and a structural performance test was conducted, and the results were compared and verified through three-dimensional numerical analysis. The results showed that the new orbital slab applying the GFRP reinforcement has satisfactory insulation and provides sufficient structural performance that can replace the existing steel bar. Full article

This study investigates tension-induced stress in Cross-tensioned Concrete Pavement (CTCP) during sequential tensioning. An integrated approach combining full-scale field testing and finite element analysis was employed. A field test was conducted to capture the stress distribution throughout the complete tensioning process, and a finite element model was subsequently developed and validated against measured strains. The results indicate that the maximum tensile stress (approximately 1.35 MPa) consistently occurs at the corner of the nearest anchorage zone, which can be completely offset by the compressive stress generated from subsequent tensioning operations. The concept of “prestress effect zone” is proposed to characterize the influence region of each tensioning sequence. In CTCP, the extent of this zone is expected to be influenced by the characteristics of the applied prestress force, including tendon angle, spacing, and magnitude. Based on the distinct tension-induced stress distribution characteristics along the slab, three zones are identified: tensile increase region, tensile stability region, and tensile decrease region, enabling clearer investigation of tension-induced stress. The observed superposition of tensile stresses during sequential tensioning operations highlights the importance of analyzing the development of tension-induced stress throughout the tensioning process, providing essential guidance for anchorage zone design and construction procedures. Full article

Steel–concrete composite beams are widely used in building and bridge engineering; however, the impact response of Steel–Coarse Aggregate–Ultra-High Performance Concrete (Steel–CA–UHPC) composite beams remains insufficiently quantified, and no beam-specific dynamic capacity formula is available. To address this gap, companion static testing and drop-weight impact tests were performed on full-scale simply supported steel–CA–UHPC composite beams under single and repeated impacts, followed by development of a strain-rate-dependent dynamic increase factor (DIF) model and a capacity prediction framework. The companion static specimen reached 448 kN, whereas the 5 m impact cases produced peak forces of 930.0–940.4 kN, corresponding to 2.08–2.10 times the static level, with the initial peak forming within 1.0–1.1 ms. Dynamic failure was marked by rapid mid-span cracking of the CA–UHPC slab and brittle shear fracture of studs, while repeated impacts mainly accelerated cumulative damage before the final high-energy strike. Static–dynamic displacement comparison further revealed much more abrupt deformation concentration under impact loading. A revised static capacity formula reduced the prediction error from 4.46% for the code-based method and 1.00% for the literature model to 0.74%. Combined with the fitted DIF–strain-rate relation, the proposed framework reproduced the measured dynamic capacities with errors of −4.63% to 9.75%. The study provides member-level evidence and a practical DIF-based method for evaluating the impact resistance of steel–CA–UHPC composite beams. Full article

This study explores the structural safety, mechanical response and optimal construction parameters of the Horizontal Directional Drilling (HDD) technology applied in airport rigid pavements novelly for navigation lighting renovation. This study adopts a combined research method of three-dimensional finite element modeling (FEM) and field tests (full-scale 4C and 4E class airport runway sections). The reliability of the model is verified by the measured data using a Heavy Weight Deflectometer (HWD). The effects of drilling depth, drilling position and typical aircraft loads on the stress and deformation at the bottom of the pavement slab are systematically analyzed. Then, drilling, grouting and non-destructive testing are carried out in the field full-scale test section to investigate the change in pavement bearing capacities. The results show that minimized influence on the mechanical properties of the pavement can be achieved by using 15 cm drilling depths at either slab center or joints. The pavement stiffness slightly decreases by a maximum of 18.9% after drilling. According to the field grouting test, the Impulse Stiffness Modulus (ISM) of most measuring points can be recovered to the original level before drilling. The use of a 10 cm diameter HDD driller meets the structural safety requirements of airport pavements. The HDD technology induces minimized pavement damage and influence on the bearing capacity of the airport runway structure compared with traditional construction technologies, highlighting its advantages in airfield navigation lighting renovations. Full article

A methodology was developed to evaluate the behavior of reinforced concrete slabs used in temporary traffic bridge systems installed over uncured cement concrete pavement sections using highly scaled-down experimental reinforced concrete slabs. A full-scale reinforced concrete slab was first designed and its behavior, such as strain and deflection, was numerically analyzed. A small-scale reinforced concrete slab was then designed considering a dimensional reduction ratio of 1/6. When using this reduction ratio, there is no actual reduced size steel bar, so the smallest size steel bar available must be used for placement. Therefore, numerical analyses were performed to design the steel bar arrangement of the small-scale slab so that the same behavior as that of the full-scale slab occurred. To conduct experiments, small-scale experimental slabs were fabricated according to the design. Since the size of coarse aggregates must be reduced in concrete used for small-scale slabs, specimens using the concrete mix design for full-scale slabs were also produced and the compressive strengths were compared to confirm that the strengths were the same. Next, a study was conducted on the selection of strain gauges that can be used in small-scale slab experiments, and a method for installing displacement gauges to accurately measure slab deflection was also designed. Based on this series of basic studies, load tests were performed to measure the strains and deflections of small-scale slabs. Comparing the measured behavior of the small-scale slab with the numerical analysis results, it was confirmed that the same behavior was observed. Therefore, the experimental results and numerical analysis results of the small-scale slab were consistent, and the numerical analysis results of the small-scale slab and the full-scale slab were identical, proving that the experimental results of the full-scale slab can be inferred through experiments using the small-scale slab. This study confirmed that if small-scale slabs are designed and manufactured to appropriately reflect the characteristics of full-scale slabs, even though the process is challenging, the behavior of full-scale slabs can be approximately determined through experiments using small-scale slabs. Full article

The need for reliable software for data acquisition, processing and communication with laboratory instruments, as well as for extending laboratory findings to real-scale structures, is imperative. In this context, ReplicaXLite is presented: an open-source software framework designed to facilitate and organize structural experimental testing on seismic tables. The software enables the creation of digital twin models and real-time sensor data recording. Furthermore, it allows for the processing, storage and visualization of results within a graphical interface. It features two primary modes of operation: (a) via terminal with specific Application Programming Interfaces (APIs) and (b) via a Graphical User Interface (GUI), adapting to the user’s expertise level. The software lies on top of open-source libraries like OpenSeesPy and opstool. It supports many material types, such as concrete, steel, fibers and composites, among others. Models produced by ReplicaXLite demonstrate strong agreement with experimental data across varying structural configurations. For both acceleration and displacement, the framework yielded satisfactory accuracy at the top slab with mean envelope correlations ranging from 0.91 to 0.97 and mean Pearson correlations generally between 0.83 and 0.95 for varying seismic intensities (0.1 g to 1.4 g). The numerical framework successfully captured global stiffness degradation, with Normalized Root Mean Square Errors (NRMSE) well-constrained between 2.3% and 7.9% across both acceleration and displacement response metrics. The architecture allows for the one-click execution of custom user codes, providing full access to the source code and the ability to perform live toolkit modifications via the “app.” terminal variable. Finally, it provides mid-simulation modification of the mass and elements of the model. Full article
