Search Results (27)

This paper presents a Class E zero-voltage soft-switching (ZVS) resonant inverter integrated with a CLC filter and a digital resonant frequency tracking technique for driving a piezoelectric ceramic transducer (PZT) in ultrasonic cleaning applications. A digital signal processor (DSP) is used to dynamically monitor and adjust the operating frequency in response to slight variations in the cleaning load, employing a phase-locked loop (PLL) control scheme. The proposed method ensures that the inverter maintains ZVS operation across a frequency range from 30.0 kHz to 34.0 kHz, thereby improving energy efficiency and reducing switching losses. The system is capable of delivering a stable power output of 100 W. Both the simulation and experimental results validate the effectiveness of the proposed technique, demonstrating improved performance under varying load conditions. The combination of CLC filtering and frequency tracking offers a compact and robust solution suitable for ultrasonic cleaner systems and similar resonant-load applications. Full article

In order to enhance the performance of 112 Gb/s polarization-multiplexed quadrature phase-shift keying (PM-QPSK) coherent optical receivers, a novel digital signal processing (DSP) framework is presented in this study. The suggested method combines cutting-edge signal processing techniques to address important constraints in long-distance, high data rate coherent systems. The framework uses overlap frequency domain equalization (OFDE) for chromatic dispersion (CD) compensation, which offers a cheaper computational cost and higher dispersion control precision than traditional time-domain equalization. An adaptive carrier phase recovery (CPR) technique based on mean-squared differential phase (MSDP) estimation is incorporated to manage phase noise induced by cross-phase modulation (XPM), providing dependable correction under a variety of operating situations. When combined, these techniques significantly increase Q factor performance, and optimum systems can handle transmission distances of up to 2400 km. The suggested DSP approach improves phase stability and dispersion tolerance even in the presence of nonlinear impairments, making it a viable and effective choice for contemporary coherent optical networks. The framework’s competitiveness was evaluated by comparing it against the most recent, cutting-edge DSP methods that were released after 2021. These included CPR systems that were based on kernels, transformers, and machine learning. The findings show that although AI-driven approaches had the highest absolute Q factors, they also required a large amount of computing power. On the other hand, the suggested OFDE in conjunction with adaptive CPR achieved Q factors of up to 11.7 dB over extended distances with a significantly reduced DSP effort, striking a good balance between performance and complexity. Its appropriateness for scalable, long-haul 112 Gb/s PM-QPSK systems is confirmed by a complexity versus performance trade-off analysis, providing a workable and efficient substitute for more resource-intensive alternatives. Full article

High-performance UPS inverters prevent IoT devices from power outages, thus protecting critical data. This paper suggests an intelligent, robust control technique with closed-loop voltage sensing for UPS (uninterruptible power supply) inverters in IoT (internet of things) devices. The suggested control technique synthesizes a modified gray fast variable structure sliding mode control (MGFVSSMC) together with a neural network (NN). The MGFVSSMC allows system states to speedily converge towards the equilibrium within a shorter time while eliminating the problems of chattering and steady-state errors. The MGFVSSMC may experience state prediction errors when the UPS inverter is subjected to external highly nonlinear loads or internal parameters changing drastically. This results in high harmonic distortion and inferior dynamic response of the inverter output, affecting the guarding of the IoT device. An NN by means of a learning mechanism is employed to properly compensate for the prediction error of the MGFVSSMC, achieving a high-performance UPS inverter. The suggested control technique operates with one voltage sensing, which can yield fast transience and low inverter output-voltage distortion. Both simulations and digital signal processing (DSP) implementation results demonstrate the effectiveness of the suggested control technique under a variety of load conditions. Full article

Solar energy is considered the major source of clean and ubiquitous renewable energy available on various scales in electric grids. In addition, solar energy is harnessed in various electronic devices to charge the batteries and power electronic equipment. Due to its ubiquitous nature, the corresponding market for solar-charged small-scale batteries is growing fast. The most important part to make the technology feasible is a portable battery charger and the associated controllers to automate battery charging. The charger should consider the case of charging to be convenient for the user and minimize battery degradation. However, the issue of slow charging and premature battery life loss plagues current industry standards or innovative battery technologies. In this paper, a new pulse charging technique is proposed that obviates battery deterioration and minimizes the overall charging loss. The solar-powered battery charger is prototyped and executed as a practical, versatile, and compact photovoltaic charge controller at cut rates. With the aid of sensor fusion, the charge controller is disconnected and reconnects the battery during battery overcharging and deep discharging conditions using sensors with relays. The laboratory model is tested using a less expensive PV panel, battery, and digital signal processor (DSP) controller. The charging behavior of the solar-powered PWM charge controller is studied compared with that of the constant voltage–constant current (CV–CC) method. The proposed method is pertinent for minimizing energy issues in impoverished places at a reasonable price. Full article

This article describes the study and digital implementation of a system onboard a TMS 3208F28335 ^® DSP for vector control of the bearing motor speed with four poles split winding with 250 W of power. Smart techniques: ANFIS and Neural Networks were investigated and computationally implemented to evaluate the bearing motor performance under the following conditions: operating as an estimator of uncertain parameters and as a speed controller. Therefore, the MATLAB program and its toolbox were used for the simulations and the parameter adjustments involving the structure ANFIS (Adaptive-Network-Based Fuzzy Inference System) and simulations with the Neural Network. The simulated results showed a good performance for the two techniques applied differently: the estimator and a speed controller using both a model of the induction motor operating as a bearing motor. The experimental part for velocity vector control uses three control loops: current, radial position, and speed, where the configurations of the peripherals, that is, the interfaces or drivers for driving the bearing motor. Full article

This research aims to propose a comprehensive simulation and implementation methodology for LFM (Linear Frequency Modulated) Radar Signal Processing and its application, using digital signal processing techniques on the DSP Starter Kit (DSK) 6713 board. The motivation behind this study is to develop control software based on MATLAB R14 and SIMULINK to model various system software tasks, including detection, A/D conversion, Fast Fourier Transform (FFT), modulation, accumulation, decision-making, and target detection. The simulations are categorized into two groups: ideal beat frequency and parameterized beat frequency. We introduce several important terminologies for consideration, including pulse compression, SNR, matched filter, Doppler effect, and more. The use of real-time data exchange (RTDX) will facilitate the generation of input data and enable real-time calculations for outputs, leading to the creation of machine code for the DSP chip. This process aims to ensure data verification calculations and enhance the credibility and performance of the proposed methodology. By conducting thorough simulations, verification, and practical testing, the study demonstrates the satisfactory credibility and performance of the developed method. Using this research, we aim to contribute to the advancement of LFM Radar Signal Processing and enable its efficient implementation using digital signal processing techniques on the DSP Starter Kit (DSK) 6713 board. Full article

This article proposes a Distributed-control Architecture (D-CA) and an operation sequence with start-up strategies for a Digital Signal Processor (DSP)-based Solid-State Transformer (SST). Although various control techniques for SSTs have been reported in earlier studies, there is still a lack of research covering comprehensive content, including hierarchical control architectures and operation sequences with start-ups considering the implementation of DSPs. Therefore, this article addresses the following factors of SST. First, the D-CA is described for the design of the hierarchy between control boards. With the D-CA, because sub-boards are in charge of their corresponding DC-link voltage balancing control individually, the computational burden on the master board can be reduced. Second, the operation sequence of the SST system is explained based on the SST with D-CA. The step of DC-link voltage balance is considered throughout the entire operation sequence for safe driving. Furthermore, the PWM start-up strategies for a Cascade H-bridge Multilevel (CHM) converter and Dual Active Bridge (DAB) converter are proposed to prevent switching pulse errors caused by DSP operating characteristics. These start-up strategies reduce the current surges. The validity of the proposed D-CA and operation sequence with start-up strategies are verified by experimental results. Full article

The abrupt transfer from grid-connected (GC) to stand-alone (SA) operation modes is one of the major issues that may threaten the stability of a distributed generation (DG) system. Furthermore, if the islanding mode happens, it is vital to take into consideration the load voltages or load current waveforms as soon as feasible. This paper develops an advanced control technique based on a super-twisting sliding mode controller (ST-SMC) for a three-phase inverter operating in both the GC and SA modes. This control scheme is proposed to ensure a smooth transition from the GC to SA mode and enhance the load voltage waveforms under the islanding mode. In addition, to minimize the operational costs of the system and the complexity of the studied model, a digital Luenberger observer (DLO) with a proper design is adopted for estimating the inverter-side current. The control scheme of the whole system switches between a current control mode during the GC mode and a voltage control mode during the SA mode. The super-twisting control algorithm is applied to the outer voltage control loop involved in the cascaded voltage/current control scheme in the SA mode. Simulation tests of a three-phase inverter are performed for the purpose of assessing the suggested control performance by using the PowerSim (PSIM) software and comparing it with a classical PI controller. Furthermore, a processor-in-the-loop (PIL) implementation in a DSP board TMS32F28335 while debugging is conducted using code composer studio 6.2.0. The obtained results show efficient control properties, such as a smooth transition among the microgrid (MG) operating modes, as well as effectiveness and robustness during both the GC and SA operation modes. Full article

Power system disruptions can be categorized as issues with the quality of electricity brought on by voltage sags, lightning strikes, and other system-related interferences. The static transfer switch (STS) has recently emerged as the most important technology for electric power transmission, distribution, and control systems to manage power supply during power system disruption issues, particularly in cost-effectively supplying power to critical loads and sensitive loads without interruption. In this paper, for the switching between the two AC sources during the voltage disruptions issue with low transfer time, a smart static transfer switch (SSTS) based on a digital switching algorithm and Triac semiconductor switch is proposed and experimentally tested. A digital switching algorithm based on online AC voltage sensing and zero-crossing detection is proposed and implemented inside a DSP MCU. The printed circuit board (PCB) of the proposed SSTS is designed and manufactured for the experimental performance investigation with different AC input voltage conditions. A comparative study based on the advantages and disadvantages of the proposed SSTS system with the previous works is also presented. A smart static transfer switch with a transition time of less than one cycle and a digital protection technique during fault conditions is obtained in this work. Full article

The main purpose of this study was to develop a photovoltaic module array (PVMA) and an energy storage system (ESS) with charging and discharging control for batteries to apply in grid power supply regulation of high proportions of renewable energy. To control the flow of energy at the DC load and charge/discharge the battery uniformly, this work adapted a bidirectional buck–boost soft-switching converter and the maximum power point tracking (MPPT) technique of the photovoltaic module array. First, a boost converter is used with the perturb and observe (P&O) method, so that the photovoltaic module array can work at the maximum power point (MPP) at any time. When the output power of the photovoltaic module array is greater than the load power, the excess power is used to charge the battery; on the contrary, if the output power of the photovoltaic module array is lower than the load power, the battery discharges for auxiliary power supply. This makes the voltage of the DC link maintain a constant value. The monitoring circuit sends the voltage and current signals to the TMS320F2809 digital signal processor (DSP) produced by Texas Instruments to control the battery charging/discharging voltage and current. The photovoltaic module array works at the MPP to improve the performance of the overall energy storage system. Finally, the actual test result shows that the soft-switching converter used in this work, when compared to the hard-switching converter, can improve efficiency by nearly 4% when the load power is above 125 W. When the photovoltaic power generation system operation is between 150 W and 400 W, the proposed uniform charging and discharging architecture can rapidly reach uniformity. Full article

Multilevel inverters are a type of power electronic circuit that converts direct current (DC) to alternating current (AC) for use in high-voltage and high-power applications. Many recent studies on multilevel inverters have used field-programmable gate arrays (FPGAs) as a switching controller device to overcome the limitations of microcontrollers or DSPs, such as limited sampling rate, low execution speed, and a limited number of IO pins. However, the design techniques of most existing FPGA-based switching controllers require large amounts of memory (RAM) for storage of sampled data points as well as complex controller architectures to generate the output gating pulses. Therefore, in this paper, we propose two types of FPGA-based digital switching controllers, namely selective harmonic elimination (SHE) and sinusoidal pulse width modulation (SPWM), for a 21-level multilevel inverter. Both switching controllers were designed with minimal hardware complexity and logic utilisation. The designed SHE switching controller mainly consists of a four-bit finite state machine (FSM) and a 13-bit counter, while the SPWM switching controller employs a simple iterative CORDIC algorithm with a small amount of data storage requirement, a six-bit up-down counter, and a few adders. Initially, both digital switching controllers (SHE and SPWM) were designed using the hardware description language (HDL) in Verilog codes and functionally verified using the developed testbenches. The designed digital switching controllers were then synthesised and downloaded to the Intel FPGA (DE2-115) board for real-time verification purposes. For system-level verification, both switching controllers were tested on five cascaded H-Bridge circuits for a 21-level multilevel inverter model using the HDL co-simulation method in MATLAB Simulink. From the synthesised logic gates, it was found that the designed SHE and SPWM switching controllers require only 186 and 369 logic elements (LEs), respectively, which is less than 1% of the total LEs in an FPGA (Cyclone IV E) chip. The execution speed of the SHE switching controller implemented in the FPGA (Cyclone IV E) chip was found to be a maximum of 99.97% faster when compared with the microcontroller (PIC16F877A). The THD percentage of the 21-level SHE digital switching controller (3.91%) was found to be 37% less than that of the SPWM digital switching controller (6.17%). In conclusion, the proposed simplified design architectures of SHE and SPWM digital switching controllers have been proven to not only require minimal logic resources, achieve high processing speeds, and function correctly when tested on a real-time FPGA board, but also generate the desired 21-level stepped sine-wave output voltage (±360 V_PP) at a frequency of 50 Hz with low THD percentages when tested on a 21-level cascaded H-Bridge multilevel inverter model. Full article

Lithium-ion (Li-ion) batteries play a substantial role in portable consumer electronics, electric vehicles and large power energy storage systems. For Li-ion batteries, developing an optimal charging algorithm that simultaneously takes rises in charging time and charging temperature into account is essential. In this paper, a model predictive control-based charging algorithm is proposed. This study uses the Thevenin equivalent circuit battery and transforms it into the state-space equation to develop the model predictive controller. The usage of such models in the battery optimal control context has an edge due to its low computational cost, enabling the realization of the proposed technique using a low-cost Digital Signal Processor (DSP). Compared with the widely employed constant current-constant voltage charging method, the proposed charging technique can improve the charging time and the average temperature by 3.25% and 0.76%, respectively. Full article

A digital control scheme for GaN transistor-based totem pole power factor correction (PFC) is proposed in this paper. At the zero crossing, the totem pole PFC has a discontinuous conduction mode (DCM) current section because of its driving method and circuit structure. In the DCM current section, when a typical synchronous switching technique is applied, the inductor current is reduced to less than zero, thereby reducing efficiency. Moreover, because of the nature of the circuit, power may be transferred in reverse. To prevent this, a new synchronous switch technique using the cycle by cycle (CBC) trip function of the digital signal processor (DSP) is proposed. This proposed technique turns off the synchronization switch according to the set DCM level. Consequently, even at a low DCM level, the inductor current is clamped to zero, enabling stable synchronous switching. Full article

In recent years, there has been a desire to improve electricity generation and consumption, to reach sustainability. Technological solutions today allow a rational use of electricity with good overall performance. Traditionally, from production to distribution, electrical energy is AC-supported for compatibility reasons and easy voltage level transformation. However, nowadays most electric loads need DC power to work properly. A single high-efficiency central AC-DC power converter may be advantageous in eliminating several less efficient AC-DC embedded converters, distributed all over a residential area. This paper presents a new single-phase AC-DC converter using one active bridge (most isolated topologies are based on the dual active bridge concept) and a high-frequency isolation transformer with low-value non-electrolytic capacitors, together with its control system design. The converter can be introduced into future low-voltage DC microgrids for residential buildings, as an alternative to several embedded AC-DC converters. Non-linear control techniques (sliding mode control and the Lyapunov direct method) are employed to guarantee stability in the output DC low voltage with near unity power factor compensation in the AC grid. The designed converter and controllers were simulated using Matlab/Simulink and tested in a lab experimental prototype using digital signal processing (DSP) to evaluate system performance. Full article

A position observer and a predictive controller for sensorless synchronous-reluctance-motor (SynRM) drive systems are investigated in this paper. The rotor position observer, based on motor parameters, and stator currents and voltages, was designed and implemented to compute the rotor position. A pole-assignment technique was used to provide similar converging rates of the position observer, even when operated at different speeds. Furthermore, a predictive controller was designed to enhance performance. A digital-signal processor (DSP), TMS-320F-28335, was used as a computation tool. Several simulated results are provided and compared with the measured results. The measured results showed that the implemented predictive controller sensorless SynRM drive system could be adjusted from 30 to 1800 rpm with satisfactory performance, including quicker and better tracking responses, and a lower speed drop than that of a proportional-integral (PI) controller. Full article
