Search Results (55)

Search Parameters:
Keywords = capacitance mismatching

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
16 pages, 2022 KB
Article
Impedance Mismatch Mechanism and Matching Network Design of Incident End in Single-Core Cable Fault Location of IT System
by Yanming Han, Qingfeng Wang, Jianqiong Zhang and Xiangqiang Li
World Electr. Veh. J. 2026, 17(1), 20; https://doi.org/10.3390/wevj17010020 - 31 Dec 2025
Viewed by 340
Abstract
The reliability of the Medium-Voltage Direct-Current (MVDC) power supply system is crucial for train operation, as it powers control, communication, and other critical onboard systems. Accurately locating insulation faults within this system can significantly reduce troubleshooting difficulty and prevent major operational losses. This [...] Read more.
The reliability of the Medium-Voltage Direct-Current (MVDC) power supply system is crucial for train operation, as it powers control, communication, and other critical onboard systems. Accurately locating insulation faults within this system can significantly reduce troubleshooting difficulty and prevent major operational losses. This study addresses a key challenge in applying Time-Domain Reflectometry (TDR) for fault location in single-core cables of IT systems: the incident-end impedance mismatch caused by the variable characteristic impedance of such cables, which fluctuates with installation distance from a ground plane. First, the mechanism through which this mismatch attenuates the primary fault reflection and generates secondary reflections is theoretically modeled. A resistive-capacitive (RC) coupling network is then designed to achieve bidirectional impedance matching between the test equipment and the cable under test while maintaining essential DC isolation. Simulation and experimental results demonstrate that the proposed network effectively mitigates the mismatch issue. In experiments, it increased the proportion of the primary reflected wave entering the receiver by over 30 percentage points and suppressed the secondary reflection by approximately 80%. These improvements enhance waveform clarity and signal strength, directly leading to more accurate fault location. The proposed solution, validated in a railway context, also holds significant potential for improving insulation fault diagnosis in analogous high-voltage cable applications, such as electric vehicle powertrains. Full article
(This article belongs to the Section Vehicle Management)
Show Figures

Figure 1

19 pages, 6390 KB
Article
Design of a Bandgap Reference with a High PSRR and Strong Load-Driving Capability
by Meng Li, Lei Guo, Bin Liu, Lin Qi, Binghui He, Yu Cao and Jian Ren
Micromachines 2026, 17(1), 50; https://doi.org/10.3390/mi17010050 - 30 Dec 2025
Viewed by 1250
Abstract
This paper introduces an enhanced bandgap reference (BGR) design, addressing the shortcomings of traditional circuits, such as significant temperature drift, limited power-supply rejection, and inadequate load-driving capacity. The proposed design incorporates a symmetric folded common-emitter–common-base BJT amplifier with MOS-assisted biasing, employed in the [...] Read more.
This paper introduces an enhanced bandgap reference (BGR) design, addressing the shortcomings of traditional circuits, such as significant temperature drift, limited power-supply rejection, and inadequate load-driving capacity. The proposed design incorporates a symmetric folded common-emitter–common-base BJT amplifier with MOS-assisted biasing, employed in the proposed BGR, enforcing branch voltage symmetry to effectively suppress intrinsic offset caused by structural mismatch. By reducing the amplifier input offset, the circuit achieves improved reference voltage stability, a lower temperature coefficient (TC), and an enhanced power-supply rejection ratio (PSRR). Additionally, a negative-feedback adaptive current-adjustment driver is implemented to dynamically adjust the output current in response to real-time load changes. This method bolsters the load-driving capability and maintains a stable reference output across varying load conditions. The circuit was simulated using a 0.18 μm BCD process, revealing that with a 3.3 V supply voltage, the BGR produces a stable output voltage of 2.5 V, with a TC of 2.372×106 °C−1. The simulated PSRR is −114.2 dB at DC and −62.07 dB at 1 kHz. Moreover, under a 3.3 V supply, sweeping the load capacitance from 0.1 μF to 100 μF demonstrates that the reference voltage remains consistently regulated at 2.5 V, confirming its excellent load tolerance and output stability. Full article
(This article belongs to the Section D1: Semiconductor Devices)
Show Figures

Figure 1

23 pages, 2630 KB
Article
RMLP-Cap: An End-to-End Parasitic Capacitance Extraction Flow Based on ResMLP
by Xinya Zhou, Jiacheng Zhang, Bin Li, Wenchao Liu, Zhaohui Wu and Bing Lu
Electronics 2026, 15(1), 36; https://doi.org/10.3390/electronics15010036 - 22 Dec 2025
Viewed by 287
Abstract
With continued transistor scaling and increasing interconnect density in very large-scale integration (VLSI) circuits, the parasitic capacitance of interconnect has become a major contributor to circuit delay and signal integrity degradation. Fast and accurate parasitic capacitance extraction is therefore essential in the back-end-of-line [...] Read more.
With continued transistor scaling and increasing interconnect density in very large-scale integration (VLSI) circuits, the parasitic capacitance of interconnect has become a major contributor to circuit delay and signal integrity degradation. Fast and accurate parasitic capacitance extraction is therefore essential in the back-end-of-line (BEOL) stage. Currently, 2.5D parasitic capacitance extraction flow based on the pattern matching method is widely used by commercial tools, which still suffer from lengthy pattern library construction, cross-section preprocessing, pattern mismatch, and poor accuracy for small capacitance extraction. To overcome these limitations, this work proposes an end-to-end parasitic capacitance extraction workflow, named residual multilayer perceptron interconnect parasitic capacitance extraction (RMLP-Cap), which leverages a residual multilayer perceptron (ResMLP) to enhance traditional workflow. RMLP-Cap integrates parasitic extraction (PEX) window acquisition, pattern definition, feature extraction, dataset generation, ResMLP model training, and capacitance aggregation into a unified flow. Experimental results show that RMLP-Cap can automatically define and model complex 2D patterns with 100% matching accuracy. Compared with a field solver based on the boundary element method (BEM), the ResMLP model achieves an average relative error below 0.9%, a standard deviation under 0.2%, and less than 0.5% error for small capacitances, while providing a 900% speed improvement for extraction speed. Full article
(This article belongs to the Section Microelectronics)
Show Figures

Figure 1

19 pages, 1802 KB
Article
Technique for Sub-mHz Low-Frequency Corner in Capacitively Coupled Instrumentation Amplifiers
by Miguel Barrales-Romero, José Luis Valtierra, Esteban Tlelo-Cuautle and Alejandro Díaz-Sánchez
Electronics 2025, 14(24), 4963; https://doi.org/10.3390/electronics14244963 - 18 Dec 2025
Viewed by 1357
Abstract
This work introduces a tunable technique to push the low-frequency corner (fL) of capacitively coupled instrumentation amplifiers (CCIAs) to the sub-mHz range for emerging biosensing applications. The proposed approach combines Complementary Transimpedance Boosting (CTB) to limit the DC feedback current [...] Read more.
This work introduces a tunable technique to push the low-frequency corner (fL) of capacitively coupled instrumentation amplifiers (CCIAs) to the sub-mHz range for emerging biosensing applications. The proposed approach combines Complementary Transimpedance Boosting (CTB) to limit the DC feedback current and segmented duty-cycled resistors (SDR) for tunable resistance. The CTB-SDR technique achieves a stable effective post-layout pseudo-resistance of 535.8 TΩ, equivalent to fL=660 μHz while occupying 0.062 mm2 in a 180 nm process. According to JESD91 standards, it shows a standard deviation of 0.19 mHz under post-layout Monte Carlo + process analysis, 1.1% spread under voltage variations (±5.56% VDD) and 6.2% under temperature variations (20 °C, 27 °C, and 60 °C). In addition, duty-cycling calibration can compensate for worst-case process corner variations and mismatch-induced feedback instability. Full article
Show Figures

Figure 1

14 pages, 2495 KB
Article
Research on a Feedthrough Suppression Scheme for MEMS Gyroscopes Based on Mixed-Frequency Excitation Signals
by Xuhui Chen, Zhenzhen Pei, Chenchao Zhu, Jiaye Hu, Hongjie Lei, Yidian Wang and Hongsheng Li
Micromachines 2025, 16(10), 1120; https://doi.org/10.3390/mi16101120 - 30 Sep 2025
Cited by 1 | Viewed by 3178
Abstract
Feedthrough interference is inevitably introduced in MEMS gyroscopes due to non-ideal factors such as circuit layout design and fabrication processes, exerting non-negligible impacts on gyroscope performance. This study proposes a feedthrough suppression scheme for MEMS gyroscopes based on mixed-frequency excitation signals. Leveraging the [...] Read more.
Feedthrough interference is inevitably introduced in MEMS gyroscopes due to non-ideal factors such as circuit layout design and fabrication processes, exerting non-negligible impacts on gyroscope performance. This study proposes a feedthrough suppression scheme for MEMS gyroscopes based on mixed-frequency excitation signals. Leveraging the quadratic relationship between excitation voltage and electrostatic force in capacitive resonators, the resonator is excited with a modulated signal at a non-resonant frequency while sensing vibration signals at the resonant frequency. This approach achieves linear excitation without requiring backend demodulation circuits, effectively separating desired signals from feedthrough interference in the frequency domain. A mixed-frequency excitation-based measurement and control system for MEMS gyroscopes is constructed. The influence of mismatch phenomena under non-ideal conditions on the control system is analyzed with corresponding solutions provided. Simulations and experiments validate the scheme’s effectiveness, demonstrating feedthrough suppression through both amplitude-frequency characteristics and scale factor perspectives. Test results confirm the scheme eliminates the zero introduced by feedthrough interference in the gyroscope’s amplitude-frequency response curve and reduces force-to-rebalanced detection scale factor fluctuations caused by frequency split variations by a factor of 21. Under this scheme, the gyroscope achieves zero-bias stability of 0.3118 °/h and angle random walk of 0.2443 °/h/√Hz. Full article
Show Figures

Figure 1

14 pages, 20112 KB
Article
Design and Simulation Test of Non-Contact Voltage Sensor
by Haojie Peng, Hongwei Liu, Kuo Shang, Gaoyue Li and Liping Zhao
Sensors 2025, 25(10), 3118; https://doi.org/10.3390/s25103118 - 15 May 2025
Cited by 1 | Viewed by 1322
Abstract
The miniaturization of sensors and non-contact measurement techniques is currently at the forefront of smart grid development. This paper proposes a miniature voltage sensor whose size is significantly reduced while maintaining large bandwidth and high linearity. To minimize the impact of environmental factors [...] Read more.
The miniaturization of sensors and non-contact measurement techniques is currently at the forefront of smart grid development. This paper proposes a miniature voltage sensor whose size is significantly reduced while maintaining large bandwidth and high linearity. To minimize the impact of environmental factors on measurement accuracy, a differential structure is utilized to optimize the sensor. The sensor is designed with a dual-channel measurement mode for both high-frequency and power-frequency signals, addressing issues of signal refraction and reflection due to impedance mismatch. COMSOL Multiphysics 6.2 is employed to simulate the sensor’s structural design and placement. Moreover, the experimental analysis of key parameters, such as parallel resistance and capacitance, identifies the optimal parameter combination for low-voltage distribution lines and cables of 10 kV and below. Experiments show that the voltage sensor’s bandwidth ranges from 30 Hz–200 kHz when measured through a frequency response analyzer. Finally, through the measurement carried out on the overhead line and cable, we evaluate the linearity of the sensor according to the experimental data. Specifically, the nonlinear errors of the voltage measurement for the overhead line and cable are 0.62% and 0.57%, respectively. Full article
(This article belongs to the Section Physical Sensors)
Show Figures

Figure 1

22 pages, 6398 KB
Article
A Novel Optimization Method of the DS-LCC Compensation Topology to Reduce the Sensitivity of the Load-Independent Constant Current Output Characteristics to the Component Parametric Deviation
by Xuze Zhang, Jingang Li and Xiangqian Tong
Electronics 2025, 14(8), 1536; https://doi.org/10.3390/electronics14081536 - 10 Apr 2025
Viewed by 574
Abstract
For the double-sided inductor–capacitor–capacitor (DS-LCC) compensation topology, the parametric deviation of compensation elements results in the mismatch between the resonant frequency and operating frequency. Furthermore, this mismatch leads to the loss of the load-independent constant output characteristics. Therefore, an innovative design approach based [...] Read more.
For the double-sided inductor–capacitor–capacitor (DS-LCC) compensation topology, the parametric deviation of compensation elements results in the mismatch between the resonant frequency and operating frequency. Furthermore, this mismatch leads to the loss of the load-independent constant output characteristics. Therefore, an innovative design approach based on the reduction in the capacitance ratio is proposed to attain the load-independent constant current under the parametric deviation. With the presented method, simply by reducing the compensation capacitor ratio, the load-independent constant current output characteristics can be preserved, and fluctuations in the transmission gain caused by the parametric deviation are minimized. This implies that when the constant transmission gain is achieved by the frequency modulation (FM) control, the required FM range can be reduced. Finally, from the experimental results, in the load range of 3 Ω to 33 Ω, compared to the high capacitance ratio, the load-independent constant current characteristics can be maintained at the low capacitance ratio. In addition, without parametric deviation, the transmission efficiencies at different capacitance ratios are basically the same at 93.5% and 94.2%, respectively. However, the transmission efficiencies under different parametric deviations at the low capacitance ratio are 87.4% and 84.9%, but only 73.9% and 68.2% at the high capacitance ratio. Full article
Show Figures

Figure 1

21 pages, 4593 KB
Article
High-Efficiency, Low-Loss, and Wideband 5.8 GHz Energy Harvester Designed Using TSMC 65 nm Process for IoT Self-Powered Nodes
by Hebah Rabah, Lutfi Albasha, Hasan Mir, Nasir Quadir and Syed Zahid Abbas
Energies 2025, 18(4), 862; https://doi.org/10.3390/en18040862 - 12 Feb 2025
Cited by 2 | Viewed by 2122
Abstract
Energy harvesting systems are becoming increasingly vital for sustainable power supply in Internet of Things (IoT) applications. These systems involve capturing and converting energy from environmental sources into electrical power. This paper presents a high-efficiency 5.8 GHz energy harvester for powering such devices, [...] Read more.
Energy harvesting systems are becoming increasingly vital for sustainable power supply in Internet of Things (IoT) applications. These systems involve capturing and converting energy from environmental sources into electrical power. This paper presents a high-efficiency 5.8 GHz energy harvester for powering such devices, designed in a 65 nm pure CMOS process. The proposed design utilizes a metal-oxide-semiconductor field-effect-transistor-based Dickson charge pump energy harvester for high-frequency energy conversion. Simulation results are presented and discussed on the post-layout verified and extracted circuits with matching implemented to emulate the real-world testing scenarios. The design addresses challenges specific to high-frequency operation, including parasitic capacitances, frequency-dependent leakage currents, and impedance mismatches, ensuring optimal performance at higher frequencies. The evaluation focuses on key metrics such as output voltage and power conversion efficiency (PCE), with the harvester demonstrating an output voltage of 2.88 V and an efficiency of 82.94%. Full article
(This article belongs to the Special Issue Energy, Electrical and Power Engineering: 3rd Edition)
Show Figures

Figure 1

14 pages, 882 KB
Article
An 11-Bit Single-Slope/Successive Approximation Register Analog-to-Digital Converters with On-Chip Fine Step Range Calibration for CMOS Image Sensors
by Seong-Jun Byun, Jee-Taeck Seo, Tae-Hyun Kim, Jeong-Hun Lee, Young-Kyu Kim and Kwang-Hyun Baek
Electronics 2025, 14(1), 83; https://doi.org/10.3390/electronics14010083 - 27 Dec 2024
Cited by 2 | Viewed by 1762
Abstract
This paper presents a novel high-precision 11-bit single-slope/successive approximation register analog-to-digital converter (SS/SAR ADC) architecture specifically designed for CMOS image sensors (CISs). The proposed design solves critical challenges in conventional ADCs by utilizing only two reference voltages, thereby minimizing voltage mismatch and completely [...] Read more.
This paper presents a novel high-precision 11-bit single-slope/successive approximation register analog-to-digital converter (SS/SAR ADC) architecture specifically designed for CMOS image sensors (CISs). The proposed design solves critical challenges in conventional ADCs by utilizing only two reference voltages, thereby minimizing voltage mismatch and completely eliminating the need for complex switch arrays. This unique approach reduces the transistor count by 64 per column ADC, significantly enhancing area efficiency and circuit simplicity. Furthermore, a groundbreaking on-chip fine step range calibration technique is introduced to mitigate the impact of parasitic capacitance, ensuring the precise alignment between coarse and fine steps and achieving exceptional linearity. Fabricated using a 0.18-µm CMOS process, the ADC demonstrates superior performance metrics, including a differential nonlinearity (DNL) of −1/+1.86 LSB, an integral nonlinearity (INL) of −2.74/+2.79 LSB, an effective number of bits (ENOB) of 8.3 bits, and a signal-to-noise and distortion ratio (SNDR) of 51.77 dB. Operating at 240 kS/s with a power consumption of 22.16 µW, the ADC achieves an outstanding figure-of-merit (FOMW) of 0.291 pJ/step. These results demonstrate the proposed architecture’s potential as a transformative solution for high-speed, energy-efficient CIS applications. Full article
(This article belongs to the Section Circuit and Signal Processing)
Show Figures

Figure 1

14 pages, 7528 KB
Article
A Power-Efficient 16-bit 1-MS/s Successive Approximation Register Analog-to-Digital Converter with Digital Calibration in 0.18 μm Complementary Metal Oxide Semiconductor
by Xinyuan He, Weifeng Qiao, Xinpeng Xing and Haigang Feng
J. Low Power Electron. Appl. 2024, 14(2), 32; https://doi.org/10.3390/jlpea14020032 - 4 Jun 2024
Cited by 2 | Viewed by 3185
Abstract
A power-efficient 16-bit 1-MS/s successive approximation register (SAR) analog-to-digital converter (ADC) is presented in this paper. High-bit sampling makes the bridge capacitance in the digital-to-analog converter (DAC) a unit one, eliminating fractional capacitance mismatch. The high-precision comparator is composed of a four-stage preamplifier [...] Read more.
A power-efficient 16-bit 1-MS/s successive approximation register (SAR) analog-to-digital converter (ADC) is presented in this paper. High-bit sampling makes the bridge capacitance in the digital-to-analog converter (DAC) a unit one, eliminating fractional capacitance mismatch. The high-precision comparator is composed of a four-stage preamplifier and a strong-arm latch, with auto-zeroing used to mitigate input offset further. Digital foreground calibration based on low-bit weight is implemented to correct DAC capacitance mismatch. The post-layout simulation results show that the core ADC achieves 95.61 dB SNDR and 105.1 dB SFDR with calibration, consuming 5.4 mW power under a 3.3 V supply voltage, corresponding to a Schreier figure of merit (FoM) of 175.3 dB. The ADC core area is 1.06 mm2 in the 180 nm CMOS technology. Full article
(This article belongs to the Special Issue Analog/Mixed-Signal Integrated Circuit Design)
Show Figures

Figure 1

13 pages, 2559 KB
Article
Effects of Diffusion Barrier Layers on the Performance of Lattice-Mismatched Metamorphic In0.83Ga0.17As Photodetectors
by Zhejing Jiao, Tianyu Guo, Gaoyu Zhou, Yi Gu, Bowen Liu, Yizhen Yu, Chunlei Yu, Yingjie Ma, Tao Li and Xue Li
Electronics 2024, 13(7), 1339; https://doi.org/10.3390/electronics13071339 - 2 Apr 2024
Viewed by 2183
Abstract
In the planar-type InGaAs photodetector (PD) structure, a diffusion barrier has the effect of modifying the zinc diffusion profile in the interface between the cap and the absorption layer to improve device performance. In this work, an n-type In0.83Ga0.17As [...] Read more.
In the planar-type InGaAs photodetector (PD) structure, a diffusion barrier has the effect of modifying the zinc diffusion profile in the interface between the cap and the absorption layer to improve device performance. In this work, an n-type In0.83Ga0.17As diffusion barrier layer (DBL) is employed between the In0.83Al0.17As cap layer and the low-doped In0.83Ga0.17As absorption layer of a lattice-mismatched metamorphic In0.83Ga0.17As PD. The device performance of the In0.83Ga0.17As PDs in terms of dark current, quantum efficiency, and capacitance were simulated and compared to experimental results. The effects of the thickness and doping concentration of the DBL on PD performance were analyzed and shown to be optimized at both 300 K and 200 K. Based on the simulation results, the electron concentration of the DBL is recommended to be 3×10165×1016 cm−3 and a thickness of 0.1 μm is suggested. Full article
(This article belongs to the Special Issue Feature Papers in Semiconductor Devices)
Show Figures

Figure 1

20 pages, 1549 KB
Article
A Tunable Foreground Self-Calibration Scheme for Split Successive-Approximation Register Analog-to-Digital Converter
by Joonsung Park, Jiwon Lee, Jacob A. Abraham and Byoungho Kim
Electronics 2024, 13(4), 755; https://doi.org/10.3390/electronics13040755 - 13 Feb 2024
Viewed by 1876
Abstract
The capacitor mismatch among diverse defects caused by variations in the manufacturing process significantly affects the linearity of the capacitor array used to implement the capacitive digital-to-analog converter (CDAC) in the successive-approximation register (SAR) analog-to-digital converter (ADC). Accordingly, the linearity of the SAR [...] Read more.
The capacitor mismatch among diverse defects caused by variations in the manufacturing process significantly affects the linearity of the capacitor array used to implement the capacitive digital-to-analog converter (CDAC) in the successive-approximation register (SAR) analog-to-digital converter (ADC). Accordingly, the linearity of the SAR ADC is limited by that of capacitor array, resulting in serious yield loss. This paper proposes an efficient foreground self-calibration technique to enhance the linearity of the SAR ADCs by mitigating the capacitor mismatch based on the split ADC architecture along with variable capacitors. In this work, two ADC channels (i.e., ADC1 and ADC2) for the split ADC architecture include their capacitive DACs (CDACs) whose binary-weighted capacitor arrays consist of variable capacitors. A charge-sharing SAR ADC is used for each ADC channel. In the normal operation mode, their digital outputs are averaged to be the final ADC output, as in a conventional split ADC. In the calibration mode, every single binary-weighted capacitor for the two ADCs is sequentially calibrated by making parallel or/and antiparallel connection among two or thee capacitors from the two channels. For instance, because the capacitors of the CDACs ideally exhibit the binary-weighted relation as Cn=2×Cn1, the variable capacitor Cn of ADC1 can be updated to be closest to the sum of Cn1 of ADC1 and Cn1 of ADC2 for the calibration. For the process, the two capacitor arrays of the two ADCs can be reconfigured to be connected to each other, so that the Cn of ADC1 can be connected with two of the Cn1 of ADC1 and ADC2 in antiparallel. The two voltages at the top and the bottom plates of the CDAC are compared by a comparator of ADC1, and the comparison results are used to update Cn. This process is iterated, until Cn is in agreement with the sum of two of Cn1. Finally, all the capacitors can be calibrated in this way to have the binary-weighted relation. The simulation results based on the proposed work with a split SAR ADC model verified that the proposed technique can be practically used, by showing that the total harmonic distortion and the signal-to-noise-and-distortion ratio were enhanced by 21.8 dB and 6.4 dB, respectively. Full article
(This article belongs to the Special Issue Feature Papers in Circuit and Signal Processing)
Show Figures

Figure 1

19 pages, 7518 KB
Article
A Multidisciplinary Approach toward CMOS Capacitive Sensor Array for Droplet Analysis
by Hamed Osouli Tabrizi, Saghi Forouhi, Tayebeh Azadmousavi and Ebrahim Ghafar-Zadeh
Micromachines 2024, 15(2), 232; https://doi.org/10.3390/mi15020232 - 1 Feb 2024
Cited by 5 | Viewed by 2267
Abstract
This paper introduces an innovative method for the analysis of alcohol–water droplets on a CMOS capacitive sensor, leveraging the controlled thermal behavior of the droplets. Using this sensing method, the capacitive sensor measures the total time of evaporation (ToE), which can be influenced [...] Read more.
This paper introduces an innovative method for the analysis of alcohol–water droplets on a CMOS capacitive sensor, leveraging the controlled thermal behavior of the droplets. Using this sensing method, the capacitive sensor measures the total time of evaporation (ToE), which can be influenced by the droplet volume, temperature, and chemical composition. We explored this sensing method by introducing binary mixtures of water and ethanol or methanol across a range of concentrations (0–100%, with 10% increments). The experimental results indicate that while the capacitive sensor is effective in measuring both the total ToE and dielectric properties, a higher dynamic range and resolution are observed in the former. Additionally, an array of sensing electrodes successfully monitors the droplet–sensor surface interaction. However practical considerations such as the creation of parasitic capacitance due to mismatch, arise from the large sensing area in the proposed capacitive sensors and other similar devices. In this paper, we discuss this non-ideality and propose a solution. Also, this paper showcases the benefits of utilizing a CMOS capacitive sensing method for accurately measuring ToE. Full article
(This article belongs to the Section B:Biology and Biomedicine)
Show Figures

Figure 1

15 pages, 6720 KB
Article
A 10–20 GHz 6-Bit High-Accuracy Digital Step Attenuator with Low Insertion Loss in 0.15 µm GaAs p-HEMT Technology
by Ding He, Zhentao Yu, Jie Chen, Kaiyuan Du, Zhiqiang Zhu, Pu Cheng and Cheng Tan
Micromachines 2024, 15(1), 84; https://doi.org/10.3390/mi15010084 - 30 Dec 2023
Cited by 1 | Viewed by 3068
Abstract
In a beamforming circuit for a modern broadband phased-array system, high accuracy and compactness have received sufficient attention as they are directly related to side lobe level and fabrication cost, respectively. In order to meet the low phase error required, this paper proposed [...] Read more.
In a beamforming circuit for a modern broadband phased-array system, high accuracy and compactness have received sufficient attention as they are directly related to side lobe level and fabrication cost, respectively. In order to meet the low phase error required, this paper proposed an ultra-broadband 6-bit digital step switched-type attenuator (STA) with capacitive/inductive compensation networks. Compared to the conventional methods, the proposed technique employs an improved simplified T-structure with capacitive compensation networks, which simultaneously achieves low insertion loss and high-accuracy amplitude/phase control. In addition, on-chip level shifting circuit is integrated to avoid complex control schemes. The strategy of prioritizing return loss is adopted to alleviate the performance degradation caused by impedance mismatch after cascade. As a proof-of-principle demonstration, a wideband 6-bit STA with core area of only 0.5 mm × 1.8 mm was designed via 0.15-micrometer GaAs pHEMT technology. It exhibits ultra-broadband operation with a 31.5 dB amplitude tuning range and a 0.5 dB tuning step. The insertion loss of the reference state is 4–5.3 dB. The return loss is better than 15 dB for all the 64 states. The RMS amplitude and phase errors are less than 0.2 dB and 2° over the 10 to 20 GHz. Full article
(This article belongs to the Special Issue Recent Advances in Microwave Components and Devices, 2nd Edition)
Show Figures

Figure 1

16 pages, 8015 KB
Article
Pulse Width Modulation-Controlled Switching Impedance for Wireless Power Transfer
by Bole Ma, Lin Chai, Jianghua Lu and Shixiong Sun
Energies 2023, 16(24), 8103; https://doi.org/10.3390/en16248103 - 16 Dec 2023
Cited by 1 | Viewed by 2052
Abstract
The exceptional performance of the wireless power transfer (WPT) system hinges on its resonant state. However, the capacitance drift caused by manufacturing tolerance and temperature will result in a state of detuning. In this manuscript, a PWM-controlled switched impedance (PCSI) topology that can [...] Read more.
The exceptional performance of the wireless power transfer (WPT) system hinges on its resonant state. However, the capacitance drift caused by manufacturing tolerance and temperature will result in a state of detuning. In this manuscript, a PWM-controlled switched impedance (PCSI) topology that can express inductive and capacitive is proposed to eliminate line mismatches resulting from the above factors. Firstly, the PCSI topology is introduced, and its placement is determined based on the characteristics of the inductor–capacitor–capacitor series (LCC-S) network. Secondly, the working principle of the proposed topology is introduced. Finally, the simulation and experimental results show that the system could be restored to its resonant state by adjusting the PCSI topology. Under different values of resonant capacitors, the PCSI topology enhances the output power of the system by 40 W~150 W compared to the previous state, and the efficiency is increased by 9~13%. Full article
(This article belongs to the Section F: Electrical Engineering)
Show Figures

Figure 1
