Search Results (16)

Measuring the three-dimensional (3D) concentration of the ubiquitous intermediate OH* across combustion systems, spanning carbon-based fuels to zero-carbon alternatives such as H₂ and NH₃, provides vital insights into flame topology, reaction pathways, and emission formation mechanisms. Optical imaging methods have attracted vital interests due to non-intrusiveness in the combustion process. However, achieving accurate 3D concentration of OH* via imaging in non-axisymmetric flames remains challenging. This work presents a near-ultraviolet (NUV) volumetric emission tomography-based OH* measuring method that integrates a three-layer OH* imaging model, a calibration procedure utilizing narrow-band NUV radiometry, and a threshold-constrained Local Filtered Back-Projection Simultaneous Algebraic Reconstruction Technique (LFBP-SART) algorithm. When applied to a non-axisymmetric Bunsen flame, the method reveals multiple small flame structures matching the fairing pattern in the reconstructed 3D OH* field, with a maximum OH* molar concentration of approximately 0.04 mol/m³ and an overall relative uncertainty of about 8.7%. Given its straightforward requirements, this technique is considered adaptable to other free radicals. Full article

Unbonded flexible risers are key components in offshore oil and gas production, enabling safe hydrocarbon transport under extreme deepwater conditions. The pressure armour (PA) layer is the primary metallic layer, which is designed to resist internal pressure; however, its complex helical geometry poses significant modelling challenges. This study presents a comprehensive numerical and analytical investigation of the burst behaviour of the PA layer under internal pressure. Three FE modelling strategies are developed and compared with theoretical predictions: a simplified axisymmetric 2D model, a fully detailed 3D helical model, and an efficient periodic boundary condition (PBC) model. The proposed PBC-based approach offers a practical balance between accuracy and efficiency, providing an effective tool for parametric analysis and design optimisation of flexible risers. Full article

A three-dimensional (3-D) Multi-Layers Method (MLM) of an extension of the axisymmetric version has been developed to compute non-axisymmetric tokamak plasma equilibria with a separatrix. Conventional axisymmetric tokamak control codes cannot simulate non-axisymmetric effects, while stellarator equilibrium solvers such as VMEC do not include the effects of conducting structures. Moreover, VMEC cannot obtain equilibria with separatrices since it uses magnetic coordinates. The 3-D MLM removes these limitations by using a deformable circuit model of a magnetic confinement system. Plasma is modeled by multiple current layers coinciding with magnetic surfaces, and equilibria are obtained as solutions of a variational problem of a free energy functional with current sources. Validations of equilibrium solutions against a stellarator vacuum field and a VMEC solution for a small non-axisymmetric tokamak show good agreement in magnetic configurations, pressure profile, and plasma current. By incorporating conducting structures and extension to dynamic simulations, the 3-D MLM establishes a method for simulating tokamak plasma control under non-axisymmetric magnetic fields. Full article

The presented article is about the axisymmetric deformation of an annular one-dimensional hexagonal piezoelectric quasicrystal actuator/sensor with different configurations, analyzed by the three-dimensional theory of piezoelectricity coupled with phonon and phason fields. The state space method is utilized to recast the basic equations of one-dimensional hexagonal piezoelectric quasicrystals into the transfer matrix form, and the state space equations of a laminated annular piezoelectric quasicrystal actuator/sensor are obtained. By virtue of the finite Hankel transform, the ordinary differential equations with constant coefficients for an annular quasicrystal actuator/sensor with a generalized elastic simple support boundary condition are derived. Subsequently, the propagator matrix method and inverse Hankel transform are used together to achieve the exact axisymmetric solution for the annular one-dimensional hexagonal piezoelectric quasicrystal actuator/sensor. Numerical illustrations are presented to investigate the influences of the thickness-to-span ratio on a single-layer annular piezoelectric quasicrystal actuator/sensor subjected to different top surface loads, and the effect of material parameters is also presented. Afterward, the present model is applied to compare the performance of different piezoelectric quasicrystal actuator/sensor configurations: the quasicrystal multilayer, quasicrystal unimorph, and quasicrystal bimorph. Full article

This paper presents selected results of theoretical and experimental research into the manufacture of axisymmetric bimetallic components using three-tool skew rolling technology. In the tests, it was assumed that the outer layer would be a material intended for heat treatment. However, low-carbon steel was used for the core. Experimental investigations were carried out in an innovative CNC skew rolling mill. Tests were carried out at different technological parameters of the process. In addition, the geometric parameters of the billet and the way it was heated were analyzed in relation to the quality of the resulting weld between the two materials. The quality of the weld was assessed based on metallographic observation and on strength tests (shear method). On the other hand, theoretical studies were based on numerical modeling (FEM). The numerical analysis made it possible to determine the distribution of temperature, deformation and stress in the rolling bimetallic component. The results obtained indicated that it is possible to produce bimetallic materials from the proposed steel grades. In addition, a significant effect of the method of heating the billet in the chamber furnace on the microstructure in the joining zone and the shear strength was found. There was an increase in Rc strength of about 35% when using oxidation protection. The results indicated better strength when the billet is rolling with a smaller outer layer thickness (about 50 MPa). This was confirmed by the results obtained from the FEM analysis, which indicated higher values of plastic strain and the occurrence of higher compressive stresses in the near-surface zones of the rolled bimetallic forging, both of which facilitate the welding process. From the temperature distribution (in the range of (600–1200) °C) obtained during the rolling of the bimetal forging, it can be seen that contact with cold tools does not affect the temperature in the welding zone. Full article

Soil–structure interaction (SSI) leads to a modification in the dynamic properties of structure, but due to the complexity of analysis, it is traditionally assumed in seismic designs that the structure is fixed-supported on the ground, which brings about potential risks to the seismic performances of structure. The study works on the possibility of SSI having detrimental effects by comparing the dynamic responses of the SSI system to a fixed-base structure, and presents charts for an evaluation of the system frequency of SSI for the purpose of engineering practice. In order to reveal the physical nature, the SSI model is reduced to its simplest form, consisting of a SDOF oscillator, a three-dimensional rectangular foundation, and a multi-layered half-space. The energy dissipation in the soil is achieved by foundation impedances and the substructure method. Previously, the foundation impedances are usually acquired by two-dimensional or axisymmetric three-dimensional models in uniform half-space to avoid the high cost of the more realistic, fully 3D models, while a high-precision indirect boundary element method is employed, combined with the non-singular Green’s functions of distributed loads to calculate the foundation impedances. Although SSI dampens the peak amplitude of structure response in the frequency domain, case studies on four buildings’ responses to 42 earthquakes in the time history show a possibility of 15–20% that SSI amplifies the dynamic responses of structures, such as the maximum and the mean values in the time history, depending on the properties of the structures and the site, as well as the frequency component of incident waves. Full article

In this paper, the electrothermal coupling model of metal oxide resistive random access memory (RRAM) is analyzed by using a 2D axisymmetrical structure in COMSOL Multiphysics simulation software. The RRAM structure is a Ti/HfO₂/ZrO₂/Pt bilayer structure, and the SET and RESET processes of Ti/HfO₂/ZrO₂/Pt are verified and analyzed. It is found that the width and thickness of CF1 (the conductive filament of the HfO₂ layer), CF2 (the conductive filament of the ZrO₂ layer), and resistive dielectric layers affect the electrical performance of the device. Under the condition of the width ratio of conductive filament to transition layer (6:14) and the thickness ratio of HfO₂ to ZrO₂ (7.5:7.5), Ti/HfO₂/ZrO₂/Pt has stable high and low resistance states. On this basis, the comparison of three commonly used RRAM metal top electrode materials (Ti, Pt, and Al) shows that the resistance switching ratio of the Ti electrode is the highest at about 11.67. Finally, combining the optimal conductive filament size and the optimal top electrode material, the I-V hysteresis loop was obtained, and the switching ratio R_off/R_on = 10.46 was calculated. Therefore, in this paper, a perfect RRAM model is established, the resistance mechanism is explained and analyzed, and the optimal geometrical size and electrode material for the hysteresis characteristics of the Ti/HfO₂/ZrO₂/Pt structure are found. Full article

The characterization of silicon carbide (SiC) by specific electrical atomic force microscopy (AFM) modes is highly appreciated for revealing its structure and properties at a nanoscale. However, during the conductive AFM (C-AFM) measurements, the strong electric field that builds up around and below the AFM conductive tip in ambient atmosphere may lead to a direct anodic oxidation of the SiC surface due to the formation of a water nanomeniscus. In this paper, the underlying effects of the anodization are experimentally investigated for SiC multilayers with different doping levels by studying gradual SiC epitaxial-doped layers with nitrogen (N) from 5 × 10¹⁷ to 10¹⁹ at/cm³. The presence of the water nanomeniscus is probed by the AFM and analyzed with the force–distance curve when a negative bias is applied to the AFM tip. From the water meniscus breakup distance measured without and with polarization, the water meniscus volume is increased by a factor of three under polarization. AFM experimental results are supported by electrostatic modeling to study oxide growth. By taking into account the presence of the water nanomeniscus, the surface oxide layer and the SiC doping level, a 2D-axisymmetric finite element model is developed to calculate the electric field distribution nearby the tip contact and the current distributions at the nanocontact. The results demonstrate that the anodization occurred for the conductive regime in which the current depends strongly to the doping; its threshold value is 7 × 10¹⁸ at/cm³ for anodization. Finally, the characterization of a classical planar SiC-MOSFET by C-AFM is examined. Results reveal the local oxidation mechanism of the SiC material at the surface of the MOSFET structure. AFM topographies after successive C-AFM measurements show that the local oxide created by anodization is located on both sides of the MOS channel; these areas are the locations of the highly n-type-doped zones. A selective wet chemical etching confirms that the oxide induced by local anodic oxidation is a SiOCH layer. Full article

The analysis of the dynamic process of winding destabilization under sudden short-circuit conditions is of great importance to accurately assess the short-circuit resistance of power transformers. Based on magneto-solid coupling, an axisymmetric model of the transformer and a 3D multilayer model of the transformer considering the support components are established, respectively, and the short-circuit electromagnetic force (EF) is simulated by using the finite element method. It is concluded that the middle layer of the winding is subjected to the larger radial EF, while the axial EF has a greater effect on the layers at both ends. Moreover, the impression of the preload force, aging temperatures, and the area share of spacers on the vibration and deformation of windings are studied under short-circuit conditions. The overall distribution of plastic strain and residual stress in the winding is symmetrical, and the maximum values occur in the lower region of the middle of the winding. Finally, considering the material properties of disks and insulating components, the cumulative effect of plastic deformation under multiple successive short-circuit shocks is calculated. Compared with the traditional axisymmetric model of transformer, the three-dimensional multilayer model of the transformer established in this paper is more suitable for the actual winding structure and the obtained results are more accurate. Full article

This paper follows up on a series of reference papers that inspired MDPI’s Topic “Stochastic Geomechanics: From Experimentation to Forward Modeling”, where global and local deformation effects on sand specimens are fully described from high-resolution boundary displacement fields, as supported by a comprehensive experimental database (which includes varying degrees of specimen’s heterogeneity) that is available to the scientific community for further study. This paper presents an elasto-plastic comparative analysis of different finite element models reproducing different sand specimen heterogeneity configurations as follows: loose, dense, and half-dense half-loose specimens. The experimental conditions for these specimens’ heterogeneity configurations were simulated with an axisymmetric finite element model. To characterize the stress-strain response obtained from the experiments, an elasto-plastic constitutive model with strain-hardening and softening laws was adopted to reproduce the sand specimens’ mechanistic response. An expert-based calibration of the numerical models accounted for both global and local effects by making use of global observations captured by the triaxial point sensors (i.e., axial force and displacement) and by local observations captured by 3D digital image correlation analysis (i.e., 3D boundary displacement fields). Results show that predictions of the proposed numerical models are in good agreement with the experimental observations, both global and local responses. The combined use of global and local observations to calibrate sand triaxial specimens sets the basis for a more comprehensive parameterization process. For the first model set, three experiments were assumed with homogeneous materials. While both dense and loose models showed good agreement with the experiments, the displacement field prediction of the half-dense half-loose layered model identified limitations in reproducing heterogeneous configurations. Afterward, the second set compared and analyzed the half-dense half-loose layered models by implementing a heterogeneous model, showing significantly better model predictions (i.e., after the implementation of the heterogeneous model, which accounts for a transition zone between the upper and lower segments). Full article

This review discusses a simple family of models capable of simulating tropical cyclone life cycles, including intensification, the formation of the axisymmetric version of boundary layer shocks, and the development of an eyewall. Four models are discussed, all of which are axisymmetric, f-plane, three-layer models. All four models have the same parameterizations of convective mass flux and air–sea interaction, but differ in their formulations of the radial and tangential equations of motion, i.e., they have different dry dynamical cores. The most complete model is the primitive equation (PE) model, which uses the unapproximated momentum equations for each of the three layers. The simplest is the gradient balanced (GB) model, which replaces the three radial momentum equations with gradient balance relations and replaces the boundary layer tangential wind equation with a diagnostic equation that is essentially a high Rossby number version of the local Ekman balance. Numerical integrations of the boundary layer equations confirm that the PE model can produce boundary layer shocks, while the GB model cannot. To better understand these differences in GB and PE dynamics, we also consider two hybrid balanced models (HB1 and HB2), which differ from GB only in their treatment of the boundary layer momentum equations. Because their boundary layer dynamics is more accurate than GB, both HB1 and HB2 can produce results more similar to the PE model, if they are solved in an appropriate manner. Full article

The theory of vertical pile vibration is the essential basis for pile integrity determination and dynamic analysis. The pile vibration characteristics are inevitably affected when the surrounding soil is frozen due to the low environmental temperature. Therefore, the investigation of pile vibration considering the surrounding soil as a saturated frozen porous medium is of great importance. In this paper, an analytical model for vertical pile vibration was established by employing the theory of composite saturated porous media, that is, by simplifying the upper frozen soil layer as a homogeneous isotropic saturated frozen porous medium and the foundation soil beneath the pile as an elastic half-space subjected to the motion of a rigid disk. By employing the integral transform and variable separation method, analytical solutions for the proposed model were derived under the three-dimensional axisymmetric condition. The analytical model and its solutions were verified by comparing them with the existing solutions for an end-bearing pile embedded in a homogeneously frozen soil layer as well as for a saturated half-space. A parametric study was conducted by utilizing the proposed solutions, and the results indicated that the pile bottom stiffness, the freezing temperature, the shear modulus of the unfrozen soil, etc., had a significant influence on the dynamic responses of the vertical pile vibration in both the frequency and the time domains. Full article

Considering grid requirements of high Reynolds flow, wall-modeled large eddy simulation (WMLES) and detached eddy simulation (DES) have become the main methods to deal with near-wall turbulence. However, the flow separation phenomenon is a challenge. Three typical separated flows, including flow over a cylinder at $R{e}_D$ = 3900 based on the cylinder diameter, flow over a wall-mounted hump at $R{e}_c$ = 9.36 × 10⁵ based on the hump length, and transonic flow over an axisymmetric bump with shock-induced separation at $R{e}_c$ = 2.763 × 10⁶ based on the bump length, are used to verify WMLES, shear stress transport k-$\omega$ DES (SST-DES), and Spalart–Allmaras DES (SA-DES) methods in OpenFOAM. The three flows are increasingly challenging, namely laminar boundary layer separation, turbulent boundary layer separation, and turbulent boundary layer separation under shock interference. The results show that WMLES, SST-DES, and SA-DES methods in OpenFOAM can easily predict the separation position and wake characteristics in the flow around the cylinder, but they rely on the grid scale and turbulent inflow to accurately simulate the latter two flows. The grid requirements of Larsson et al. ($\left(\delta /\Delta x,\delta /\Delta y,\delta /\Delta z\right)\approx (12,50,20)$) are the basis for simulating turbulent boundary layers upstream of flow separation. A finer mesh ($\left(\delta /\Delta x,\delta /\Delta y,\delta /\Delta z\right)\approx (40,75,40)$) is required to accurately predict the separation and reattachment. The WMLES method is more sensitive to grid scales than the SA-DES method and fails to obtain flow separation under a coarser grid, while SST-DES method can only describe the vortices generated by the separating shear layer, but not within the turbulent boundary layer, and overestimates the separation-reattachment zone based on the grid system in this paper. Full article

Cold Spray additive manufacturing (CSAM) is an emerging technique to fabricate freestanding objects by depositing solid-state layers of materials. Thanks to its remarkable deposition rate and maneuverability, it can be tailored to manufacturing intricate geometries in aerospace industries. In comparison to other additive manufacturing techniques, it is the processing speed, solid-state deposition, and the cost that make CSAM unique. In this study, CSAM process was modeled for a system comprised of a high-pressure cold spray gun with axial powder injection. To represent the flow structure around the already built objects and the deposited layers of CSAM, three walls with different profiles are placed on a flat substrate. In this work, the gas-particle behaviors are studied at the vicinity of these non-axisymmetric objects that can be generalized to more complex geometries and the applications of CSAM. The model is 3D and aluminum and copper powders were used for the feedstock. The particles’ conditions upon impact, such as particles’ footprint and normal impact velocities are studied. The numerical results show that the deviation of particles which is caused by the supersonic flow inside the nozzle and the shock waves outside the nozzle defines the accuracy of the deposition. Furthermore, the results manifest the particle’s material and size have a significant influence on the acquired velocities and trajectories of the particles, and consequently on the resolution of the process. It is found that the profile of the deposited layers has some effects on the gas flow near the substrate which plays a role in the dispersion of fine particles. Full article

The hybrid nanofluid under the influence of magnetohydrodynamics (MHD) is a new interest in the industrial sector due to its applications, such as in solar water heating and scraped surface heat exchangers. Thus, the present study accentuates the analysis of an unsteady three-dimensional MHD non-axisymmetric Homann stagnation point flow of a hybrid Al₂O₃-Cu/H₂O nanofluid with stability analysis. By employing suitable similarity transformations, the governing mathematical model in the form of the partial differential equations are simplified into a system of ordinary differential equations. The simplified mathematical model is then solved numerically by the Matlab solver bvp4c function. This solving approach was proficient in generating more than one solution when good initial guesses were provided. The numerical results presented significant influences on the rate of heat transfer and fluid flow characteristics of a hybrid nanofluid. The rate of heat transfer and the trend of the skin friction coefficient improve with the increment of the nanoparticles’ concentration and the magnetic parameter; however, they deteriorate when the unsteadiness parameter increases. In contrast, the ratio of the escalation of the ambient fluid strain rate to the plate was able to adjourn the boundary layer separation. The dual solutions (first and second solutions) are obtainable when the surface of the sheet shrunk. A stability analysis is carried out to justify the stability of the dual solutions, and hence the first solution is seen as physically reliable and stable, while the second solution is unstable. Full article
