Research

Open AccessArticle

Robust Intelligent Tracking Control Technique for Single-Phase SPWM Inverters

by

,

,

and

Processes 2023, 11(1), 13; https://doi.org/10.3390/pr11010013 - 21 Dec 2022

Viewed by 478

Abstract

This paper presents a robust intelligent tracking-control technique which is subsequently applied to single-phase SPWM inverters. The proposed technique mixes advanced sliding mode control (ASMC) with grey-Markov model (GMM). The advanced sliding mode control allows the system state to converge quickly to the [...] Read more.

This paper presents a robust intelligent tracking-control technique which is subsequently applied to single-phase SPWM inverters. The proposed technique mixes advanced sliding mode control (ASMC) with grey-Markov model (GMM). The advanced sliding mode control allows the system state to converge quickly to the origin in a limited amount of time. Unfortunately, a chattering problem frequently occurs when the inverter suffers drastically from highly nonlinear or internal parameters changes. The large power losses and high harmonic distortion emerge in the inverter output. The role that the grey-Markov model plays is to reduce the chattering of the ASMC during system uncertainty overestimation, or to reduce the steady-state error caused by underestimation of system uncertainty. In conjunction with the GMM and the ASMC, fast transient response, low distortion of the sinusoidal output-voltage and reduced chattering can be obtained. Simulation results of the proposed single-phase SPWM inverter are carried out in MATLAB/Simulink. The experimental results have been validated through digital signal processors, enabling the single-phase SPWM inverter output to effectively improve the transient tracking speed and steady-state performance. Full article

(This article belongs to the Special Issue Application of Power Electronics Technologies in Power System)

► Show Figures

Figure 1

Open AccessArticle

Swing Steadiness Regulation of Electric Vehicles with Improved Neural Network PID Algorithm

by

Dongfang Song

,

Hong Ji

and

Kang Li

Processes 2022, 10(10), 2106; https://doi.org/10.3390/pr10102106 - 17 Oct 2022

Viewed by 528

Abstract

With the intensification of global environmental pollution and the energy crisis, the new energy EV industry is developing rapidly, and FWID-EV is a popular direction for future vehicle development. For the sake of improving the swing regulate steadiness and safety of EV, the [...] Read more.

With the intensification of global environmental pollution and the energy crisis, the new energy EV industry is developing rapidly, and FWID-EV is a popular direction for future vehicle development. For the sake of improving the swing regulate steadiness and safety of EV, the study uses a particle swarm algorithm to optimize and improve the BP neural network PID, and designs an EV steering regulator to regulate the transverse swing torque and slip rate of EV to improve the safety and steadiness of EV steering. The research results display that the maximum value of the transverse swing angular velocity of the regulation algorithm is 0.156 rad/s, that the car slip rate is controlled within 0.046, and the steadiness is high, and that the maximum values of the car torque under the double shift line and snake conditions are 100 N-m and 179.4 N-m, respectively, which can effectively avoid the danger caused by steering. This demonstrates that the improved neural network PID regulator can effectively distribute the steering torque of the EV and improve the steering steadiness and safety of the EV while maintaining the driving dynamics. The use of the improved neural network PID algorithm to achieve the steering steadiness regulation of EV is of great significance to improve the safety of new energy EV, and helps to promote the widespread use of new energy EV. Full article

(This article belongs to the Special Issue Application of Power Electronics Technologies in Power System)

► Show Figures

Figure 1

Open AccessFeature PaperArticle

Reptile Search Algorithm (RSA)-Based Selective Harmonic Elimination Technique in Packed E-Cell (PEC-9) Inverter

by

,

,

,

and

Processes 2022, 10(8), 1615; https://doi.org/10.3390/pr10081615 - 16 Aug 2022

Cited by 2 | Viewed by 1089

Abstract

The multilevel inverters (MLIs) are capable of handling large quantities of power and generating high-quality output voltages. Consequently, the size of the filters is reduced, and the circuitry is simplified. As a result, they have a diverse range of uses in the industrial [...] Read more.

The multilevel inverters (MLIs) are capable of handling large quantities of power and generating high-quality output voltages. Consequently, the size of the filters is reduced, and the circuitry is simplified. As a result, they have a diverse range of uses in the industrial sector, especially in smart grids. The input voltage boosting feature is required to utilize the MLI with renewable energy. In addition, a large number of components are required to attain higher output voltage levels, which increases the cost of the circuit and weight. A variety of MLI topologies have been identified to reduce losses, device quantity, and device ratings. The selective harmonic elimination (SHE) approaches reduce distinct lower order harmonics by computing the ideal switching angles. This research presents a nine–level Packed E–Cell (PEC–9) inverter that uses selective harmonic elimination to eliminate total harmonic distortion. In order to calculate the best switching angle, the reptile search algorithm (RSA) is implemented in this paper, a nature–inspired metaheuristic algorithm inspired by the hunting behavior of the crocodile. The hunting behavior of crocodiles is implemented in two main steps: the first is encircling, which is accomplished by belly walking or high walking, and the second is hunting, which is accomplished by hunting cooperation or hunting coordination. In this technique, nonlinear transcendental equations have been solved. The simulation was run in the MATLAB R2021b software environment. The simulation results suggest that the RSA outperforms the other metaheuristic algorithms. Furthermore, the simulation result was validated on a hardware setup using DSP–TMS320F28379D in the laboratory. Full article

(This article belongs to the Special Issue Application of Power Electronics Technologies in Power System)

► Show Figures

Figure 1

Open AccessArticle

A Multifunctional, Non-Constant Current Charger Based on a Dual-Switching, Bidirectional Flyback Converter

by

,

,

,

and

Processes 2022, 10(8), 1522; https://doi.org/10.3390/pr10081522 - 02 Aug 2022

Viewed by 648

Abstract

This study implements a multifunctional charger based on a dual-switching, bidirectional flyback converter (DSBFC). The proposed charger adopts seven charging methods, including the incremental-current charging, constant-voltage (CV) charging, constant-current (CC) charging, pulse-current (PC) charging, triangular-current (TC) charging, sinusoidal-current (SC) charging, and positive/negative pulse-current [...] Read more.

This study implements a multifunctional charger based on a dual-switching, bidirectional flyback converter (DSBFC). The proposed charger adopts seven charging methods, including the incremental-current charging, constant-voltage (CV) charging, constant-current (CC) charging, pulse-current (PC) charging, triangular-current (TC) charging, sinusoidal-current (SC) charging, and positive/negative pulse-current (Reflex) charging methods. The charging process of a lithium-ion battery is divided into three stages: an initial term, a mid-term, and a final term. In the initial term, the incremental-current charging method is used in the initial term of charging for a soft start and to inhibit an increase in temperature. In the mid-term, five charging methods, including CC, PC, TC, SC, and Reflex-current charging, are used for charging. The CV charging method prevents overcharging the lithium-ion battery in the final term. Based on our experimental results, this study compares the four charging methods (PC, TC, SC, and Reflex-current) with the CC charging method to verify their improvement of the charging speed and increase in temperature in the mid-term. The charging speeds increased by 14.38%, 14.04%, 16.36%, and 27.27%, respectively, and the rise in temperature decreased by 37.8%, 40.5%, 48.6%, and 13.51%, respectively; all performed better than the CC charging method. Finally, users can adjust the charging method of the proposed DSBFC according to the needs of batteries so as to achieve excellent performance. Full article

(This article belongs to the Special Issue Application of Power Electronics Technologies in Power System)

► Show Figures

Figure 1

Open AccessArticle

A Novel SLOPDM Solar Maximum Power Point Tracking Control Strategy for the Solar Photovoltaic Power System

by

,

,

,

and

Processes 2022, 10(8), 1452; https://doi.org/10.3390/pr10081452 - 25 Jul 2022

Viewed by 685

Abstract

This study proposes a novel maximum power point tracking (MPPT) control strategy for the solar photovoltaic power system (SPPS). The proposed system adopts two solar photovoltaic modules of 430 W, which are connected to a boost converter and an MPPT controller, since the [...] Read more.

This study proposes a novel maximum power point tracking (MPPT) control strategy for the solar photovoltaic power system (SPPS). The proposed system adopts two solar photovoltaic modules of 430 W, which are connected to a boost converter and an MPPT controller, since the traditional MPPT algorithm (such as perturbation and observation [P&O] algorithm) can hardly reach maximum power point (MPP) under low irradiance level and partial shading conditions (PSC), which leads to the low efficiency of the SPPS. The speed of light optical path difference measurement (SLOPDM) MPPT control strategy has been developed in this study to overcome this problem. The estimation of the optical path angle difference is used as the basis for the proposed control strategy. This is done by determining the relationship between the optical path angle difference, solar photovoltaic power impedance R_spv and load R_o, and then calculating the duty cycle corresponding to the MPP, which then drives the boost converter to capture the MPP. The experimental results verify the proposed system, which shows the efficiency comparison between the SLOPDM MPPT algorithm, solar angle and horizon (SAH) algorithm, and P&O algorithm under PSC and uniform irradiance conditions (UIC) at irradiance levels of 700 W/m² and 65 W/m². It is evident from the comparison that the efficiency of the SLOPDM MPPT algorithm is 99% under both conditions, which is higher than the SAH and P&O algorithms. The SLOPDM MPPT algorithm can precisely, rapidly, and stably be operated at MPP. The contribution of this study is that the proposed MPPT control strategy can help achieve the high−performance of SPPS without changing the hardware circuit design and requiring any additional solar power meter. This reduces the cost and the complexity of the system significantly. Full article

(This article belongs to the Special Issue Application of Power Electronics Technologies in Power System)

► Show Figures

Figure 1

Open AccessEditor’s ChoiceArticle

A Novel MPPT Heating Control Strategy Applied to the Induction Heating System

by

Yu-Lin Lee

,

Chang-Hua Lin

and

Hwa-Dong Liu

Processes 2022, 10(6), 1151; https://doi.org/10.3390/pr10061151 - 08 Jun 2022

Cited by 2 | Viewed by 857

Abstract

This study proposes an induction heating system with maximum power-point tracking (MPPT) control strategy. The system architecture adopts a 1.3 kW full-bridge series resonant circuit with a step-down transformer and adjusts the operating frequency by a microcontroller unit to improve the heating efficiency. [...] Read more.

This study proposes an induction heating system with maximum power-point tracking (MPPT) control strategy. The system architecture adopts a 1.3 kW full-bridge series resonant circuit with a step-down transformer and adjusts the operating frequency by a microcontroller unit to improve the heating efficiency. Secondly, the proposed MPPT control strategy based on induction heating uses the relationship between the operating frequency and the system heating temperature to find the operating frequency corresponding to the maximum power point (MPP) quickly. Then, an additional hill-climbing algorithm adjusting the duty cycle is applied to reach the duty cycle corresponding to the MPP. Under the simulation and actual experimental measurement, the traditional control strategy has 76% and 68% at 500 and 750 degrees, respectively, and it takes 320 s for the system to reach 750 degrees. By contrast, the proposed MPPT control strategy achieves 96% efficiency when the system heating temperature is 500 and 750 degrees, and it only takes 120 s to reach the system heating temperature to 750 degrees. The contribution of this study is that the traditional full-bridge series resonant converter is implemented for the proposed induction heating system, where the proposed MPPT control strategy applied to the proposed induction heating system significantly has high efficiency, high stability, and high heating speed advantages, which can be accurately controlled. Full article

(This article belongs to the Special Issue Application of Power Electronics Technologies in Power System)

► Show Figures

Figure 1

Open AccessArticle

Improving the Dynamic Performance of a Variable Speed DFIG for Energy Conversion Purposes Using an Effective Control System

by

Mahmoud A. Mossa

,

Mahmoud K. Abdelhamid

,

Ahmed A. Hassan

and

Nicola Bianchi

Processes 2022, 10(3), 456; https://doi.org/10.3390/pr10030456 - 24 Feb 2022

Cited by 5 | Viewed by 733

Abstract

The present paper aims to introduce an effective control system which enhances the dynamics of a doubly fed induction generator (DFIG) operating at fixed and variable speeds. To visualize the effectiveness of the formulated control algorithm, the performance of the DFIG is evaluated [...] Read more.

The present paper aims to introduce an effective control system which enhances the dynamics of a doubly fed induction generator (DFIG) operating at fixed and variable speeds. To visualize the effectiveness of the formulated control algorithm, the performance of the DFIG is evaluated using other control techniques as well. Each control algorithm is primarily described by showing its operation principles and how it is adapted to manage the DFIG’s operation. The main used control strategies are stator voltage-oriented control (SVOC), model predictive current control (MPCC), model predictive direct torque control (MPDTC), and the formulated predictive voltage control (PVC) algorithm. A detailed comparison is performed between the controllers’ performances, through which the advantages and shortcomings of each method are outlined, and finally, the most effective technique is identified amongst them. The obtained results reveal that the proposed PVC approach possesses multiple advantages such as a faster dynamic response and simpler control structure when compared with SVOC and a faster dynamic response, reduced ripples, and reduced computational burdens when compared with the MPCC and MPDTC approaches. In addition, the robustness of the proposed PVC scheme is confirmed by performing extensive performance evaluation tests considering the parameters’ variation. Full article

(This article belongs to the Special Issue Application of Power Electronics Technologies in Power System)

► Show Figures

Figure 1

Open AccessArticle

Novel Global-MPPT Control Strategy Considering the Variation in the Photovoltaic Module Output Power and Loads for Solar Power Systems

by

,

,

,

,

,

,

and

Processes 2022, 10(2), 367; https://doi.org/10.3390/pr10020367 - 14 Feb 2022

Cited by 5 | Viewed by 1385

Abstract

This research proposed a novel global maximum power point tracking (global-MPPT) algorithm. The proposed algorithm eliminates the perturbation and observation (P&O) technique disturbance problem that the power point will be stuck at the local peak power point under a partial shading condition (PSC). [...] Read more.

This research proposed a novel global maximum power point tracking (global-MPPT) algorithm. The proposed algorithm eliminates the perturbation and observation (P&O) technique disturbance problem that the power point will be stuck at the local peak power point under a partial shading condition (PSC). The proposed global-MPPT algorithm detects the photovoltaic module (PV-M) environment irradiance level by the relationship between the output power and voltage of the PV-M. In the proposed algorithm, the important parameter w is determined by the PV-M output power and irradiance level, which is also the compensation parameter that corresponds to the relationship of temperature. The proposed global-MPPT algorithm is aimed to predict the best duty cycle of the global-MPPT based on the irradiance level, parameter w, PV-M output voltage, and load, and then achieve the maximum power point (MPP) quickly and accurately. The measurement results under UIC and PSC verify that the proposed global-MPPT technique performs better than the particle swarm optimization (PSO) and P&O techniques. This research contributes to the proposed method that can find the global-MPP in time based on the irradiance level, temperature, and load. Full article

(This article belongs to the Special Issue Application of Power Electronics Technologies in Power System)

► Show Figures

Figure 1

Open AccessArticle

A Novel Photovoltaic Module Quick Regulate MPPT Algorithm for Uniform Irradiation and Partial Shading Conditions

by

,

,

and

Processes 2021, 9(12), 2213; https://doi.org/10.3390/pr9122213 - 08 Dec 2021

Cited by 5 | Viewed by 1476

Abstract

This study proposed a new photovoltaic module quick regulate (PVM-QR) maximum power point tracking (MPPT) algorithm, which can eliminate the disturbance problem of the hill-climbing (HC) algorithm, especially under low irradiance level and partial shading conditions (PSC). This proposed algorithm has the advantage [...] Read more.

This study proposed a new photovoltaic module quick regulate (PVM-QR) maximum power point tracking (MPPT) algorithm, which can eliminate the disturbance problem of the hill-climbing (HC) algorithm, especially under low irradiance level and partial shading conditions (PSC). This proposed algorithm has the advantage that it only uses the detection photovoltaic module (PVM) impedance and the open-circuit voltage to simply and quickly calculate the PVM temperature, the irradiance level, and then the key factor parameter u. To achieve the MPPT quickly and accurately, this proposed algorithm is developed for the prediction of the best MPPT duty cycle based on the irradiance level, parameter u, and load. This study verified the proposed MPPT by the measurement results, where the HC algorithm MPPT has 95% efficiency at 0.55 kW/m² but diverges at 0.2 kW/m² under uniform irradiation conditions (UIC), and the proposed MPPT algorithm has an improved efficiency (99%) under the same conditions. Moreover, the proposed MPPT algorithm has 99% efficiency under PSC, while the HC algorithm MPPT’s efficiency is 66%. This study implemented a simple-design circuit with the proposed MPPT algorithm for UIC and PSC, where the actual experiment results can also verify that the proposed algorithm performs better than the HC algorithm. Full article

(This article belongs to the Special Issue Application of Power Electronics Technologies in Power System)

► Show Figures

Figure 1

Open AccessArticle

Optimal Quick-Response Variable Structure Control for Highly Efficient Single-Phase Sine-Wave Inverters

by

,

,

,

,

,

and

Processes 2021, 9(12), 2132; https://doi.org/10.3390/pr9122132 - 25 Nov 2021

Viewed by 932

Abstract

This paper puts forward an optimal quick-response variable structure control with a single-phase sine-wave inverter application, which keeps harmonic distortion as low as possible under various conditions of loading. Our proposed solution gives an improvement in architecture in which a quick-response variable structure [...] Read more.

This paper puts forward an optimal quick-response variable structure control with a single-phase sine-wave inverter application, which keeps harmonic distortion as low as possible under various conditions of loading. Our proposed solution gives an improvement in architecture in which a quick-response variable structure control (QRVSC) is combined with a brain storm optimization (BSO) algorithm. Notwithstanding the intrinsic resilience of a typical VSC with respect to changes in plant parameters and loading disruptions, the system state convergence towards zero normally proceeds at an infinitely long-time asymptotically, and chattering behavior frequently takes place. The QRVSC for ensuring speedy limited-time convergence with the system state to the balancing point is devised, whilst the BSO will be employed to appropriately regulate the parametric gains in the QRVSC for the elimination of chattering phenomena. From the mix of both a QRVSC together with a BSO, a low total harmonic distortion (THD) as well as a high dynamic response across different types of loading is generated by a closed-loop inverter. The proposed solution is implemented on a practicable single-phase sine-wave inverter under the control of a TI DSP (Texas Instruments Digital Signal Processor). It has experimentally shown the simulation findings as well as the mathematical theoretical analysis, displaying that both quick transient reaction as well as stable performance could be obtained. The proposed solution successfully inhibits voltage harmonics in compliance with IEEE 519-2014’s stringent standard of limiting THD values to less than 5%. Full article

(This article belongs to the Special Issue Application of Power Electronics Technologies in Power System)

► Show Figures

Figure 1

Open AccessArticle

Equivalent Circuit Establishments of a GaN High-Electron-Mobility Transistor and 635 nm Laser Diode for a Short-Pulsed Rising Current Simulation

by

Kai-Jun Pai

and

Chang-Hua Lin

Processes 2021, 9(11), 1975; https://doi.org/10.3390/pr9111975 - 04 Nov 2021

Cited by 1 | Viewed by 1157

Abstract

In this paper, a dynamic operational linear regulator (DOLR) based on a GaN high-electron-mobility transistor (HEMT) and wide-bandwidth operational amplifier was developed and implemented. The driving current could be regulated and controlled by the DOLR for 632 nm laser diodes. The constant-current mode [...] Read more.

In this paper, a dynamic operational linear regulator (DOLR) based on a GaN high-electron-mobility transistor (HEMT) and wide-bandwidth operational amplifier was developed and implemented. The driving current could be regulated and controlled by the DOLR for 632 nm laser diodes. The constant-current mode for the continuous-wave laser and the pulse-width modulation (PWM) mode for the short-pulsed laser were realizable using this DOLR. This study focused on the rising-edge time change on the laser driving current when the DOLR was operated under the high-frequency PWM mode, because the parasitic components on the GaN HEMT, laser diodes, printed circuit board, and power wires could influence the current’s dynamic behavior. Therefore, the equivalent circuit models of the laser diode and GaN HEMT were applied to establish a DOLR simulation circuit in order to observe the rising-edge time change on the laser driving current. A DOLR prototype was achieved, and so experimental waveform measurements could be implemented to verify the DOLR simulation and operation. Full article

(This article belongs to the Special Issue Application of Power Electronics Technologies in Power System)

► Show Figures

Figure 1

Open AccessArticle

Design and Validation of a Reduced Switching Components Step-Up Multilevel Inverter (RSCS-MLI)

by

,

,

,

,

,

and

Processes 2021, 9(11), 1948; https://doi.org/10.3390/pr9111948 - 29 Oct 2021

Cited by 2 | Viewed by 1335

Abstract

A reduced switching components step-up multilevel inverter (RSCS-MLI) is presented in the paper. The basic circuit of the proposed MLI can produce 11 levels in the output voltage with a reduced number of switching components. The other features of the proposed circuit include [...] Read more.

A reduced switching components step-up multilevel inverter (RSCS-MLI) is presented in the paper. The basic circuit of the proposed MLI can produce 11 levels in the output voltage with a reduced number of switching components. The other features of the proposed circuit include a low value of voltage stresses and the inherent generation of the voltage levels pertaining to the negative half without the requirement of an H-bridge. Fundamental frequency switching technique, also known as Nearest Level Control (NLC) technique, is implemented in the proposed topology for generating the switching signals. The experimental total harmonic distortion (THD) in the output voltage comes out to be 9.4% for modulation index equal to 1. Based on different parameters, a comparative study has been shown in the paper, which makes the claim of the proposed MLI stronger. An experimental setup is prepared to carry out the hardware implementation of the proposed structure and monitor its performance under dynamic load conditions, which is also used to verify the simulation results. Power loss analysis, carried out by using PLECS software, helps us to gain insight into different losses occurring while operating the inverter. The different results are explained and analyzed in the paper. Full article

(This article belongs to the Special Issue Application of Power Electronics Technologies in Power System)

► Show Figures

Figure 1

Open AccessArticle

Modified SPWM Control for a Single-Stage Differential Boost Inverter Applied in a BESS

by

,

,

,

and

Processes 2021, 9(11), 1861; https://doi.org/10.3390/pr9111861 - 20 Oct 2021

Viewed by 1149

Abstract

This study aims to implement a single-stage differential boost inverter (SSDBI) applied in a single-stage battery energy storage system (BESS) topology that can supply power from a lower-voltage battery module to an alternating current (AC) load. Compared with the common two-stage topology, which [...] Read more.

This study aims to implement a single-stage differential boost inverter (SSDBI) applied in a single-stage battery energy storage system (BESS) topology that can supply power from a lower-voltage battery module to an alternating current (AC) load. Compared with the common two-stage topology, which has a two-stage converter and higher-voltage battery module array, the single-stage topology can reduce the number of cells and components and improve the power density. In addition, a modified sinusoidal pulse-width modulation (SPWM) control was proposed to reduce the control complexity of the SSDBI while improving the total harmonic distortion (THD) of the inverter. The modified SPWM control can reduce the duty ratio of the SSDBI and the stress on the components in order to improve the AC voltage output waveform and reduce the THD. Full article

(This article belongs to the Special Issue Application of Power Electronics Technologies in Power System)

► Show Figures

Figure 1

Open AccessArticle

Bidirectional Resonant Converter for DC Microgrid Applications

by

Bor-Ren Lin

Processes 2021, 9(9), 1664; https://doi.org/10.3390/pr9091664 - 15 Sep 2021

Cited by 2 | Viewed by 1078

Abstract

A bidirectional resonant converter is presented and verified in this paper for an electric vehicle battery charger/discharger system. The presented circuit can achieve forward and backward power operation, low switching losses on active devices, and wide output voltage operation. The circuit structure of [...] Read more.

A bidirectional resonant converter is presented and verified in this paper for an electric vehicle battery charger/discharger system. The presented circuit can achieve forward and backward power operation, low switching losses on active devices, and wide output voltage operation. The circuit structure of the presented converter includes two resonant circuits on the primary and secondary sides of an isolated transformer. The frequency modulation approach is adopted to control the studied circuit. Owing to the resonant circuit characteristic, active devices for both forward (battery charge) and backward (battery discharge) power operation can be turned on at zero voltage switching. In order to implement a universal battery charger for different kinds of electric vehicle applications, the DC converter is demanded to have a wide output voltage range capability. The topology morphing between a full bridge resonant circuit and half bridge resonant circuit is selected to obtain high- and low-output voltage range operations so that the 200–500 V output voltage range is realized in the presented resonant converter. Compared to the conventional bidirectional converters, the proposed can be operated under a wide voltage range operation. In the end, a 1 kW laboratory prototype circuit is built, and experiments are provided to demonstrate the validity and performance of the presented bidirectional resonant converter. Full article

(This article belongs to the Special Issue Application of Power Electronics Technologies in Power System)

► Show Figures

Figure 1

Open AccessEditor’s ChoiceArticle

Photovoltaic Module Fault Detection Based on a Convolutional Neural Network

by

,

,

,

and

Processes 2021, 9(9), 1635; https://doi.org/10.3390/pr9091635 - 10 Sep 2021

Cited by 5 | Viewed by 1593

Abstract

With the rapid development of solar energy, the photovoltaic (PV) module fault detection plays an important role in knowing how to enhance the reliability of the solar photovoltaic system and knowing the fault type when a system problem occurs. Therefore, this paper proposed [...] Read more.

With the rapid development of solar energy, the photovoltaic (PV) module fault detection plays an important role in knowing how to enhance the reliability of the solar photovoltaic system and knowing the fault type when a system problem occurs. Therefore, this paper proposed the hybrid algorithm of chaos synchronization detection method (CSDM) with convolutional neural network (CNN) for studying PV module fault detection. Four common PV module states were discussed, including the normal PV module, module breakage, module contact defectiveness and module bypass diode failure. First of all, the defects in 16 pieces of 20W monocrystalline silicon PV modules were preprocessed, and there were four pieces of each fault state. When the signal generator delivered high frequency voltage to the PV module, the original signal was measured and captured by the NI PXI-5105 high-speed data acquisition system (DAS) and was calculated by CSDM, to establish the chaos dynamic error map as the image feature of fault diagnosis. Finally, the CNN was employed for diagnosing the fault state of the PV module. The findings show that after entering 400 random fault data (100 data for each fault) into the proposed method for recognition, the recognition accuracy rate of the proposed method was as high as 99.5%, which is better than the traditional ENN algorithm that had a recognition rate of 86.75%. In addition, the advantage of the proposed algorithm is that the mass original measured data can be reduced by CSDM, the subtle changes in the output signals are captured effectively and displayed in images, and the PV module fault state is accurately recognized by CNN. Full article

(This article belongs to the Special Issue Application of Power Electronics Technologies in Power System)

► Show Figures

Figure 1

Open AccessArticle

Comprehensive Analysis of IPT v/s CPT for Wireless EV Charging and Effect of Capacitor Plate Shape and Foreign Particle on CPT

by

,

,

,

,

,

,

and

Processes 2021, 9(9), 1619; https://doi.org/10.3390/pr9091619 - 08 Sep 2021

Cited by 6 | Viewed by 1916

Abstract

In this paper, the analysis and discussion are presented for two prominent types of wireless charging, namely inductive power transfer (IPT) and capacitive power transfer (CPT). The paper presents a comparative analysis between CPT and IPT. A comparison between different geometries of plates [...] Read more.

In this paper, the analysis and discussion are presented for two prominent types of wireless charging, namely inductive power transfer (IPT) and capacitive power transfer (CPT). The paper presents a comparative analysis between CPT and IPT. A comparison between different geometries of plates used in CPT is performed and it is shown that rectangular-shaped plates have the best power transfer efficiency. The effect of foreign particles between the capacitor plates of a single-module as well as a double-module CPT system on capacitance and energy transfer density are also investigated in the paper. The case of ceramic coating on the capacitor plates and its effects on the capacitance and energy transfer density with varying thickness are analyzed and presented. Different naturally occurring particles such as water, sand and wet sand have been simulated between the capacitor plates of the CPT system and their respective impact on power transfer is analyzed and the simulation results are demonstrated. Full article

(This article belongs to the Special Issue Application of Power Electronics Technologies in Power System)

► Show Figures

Figure 1

Open AccessArticle

Compensation of Voltage Sags and Swells Using Dynamic Voltage Restorer Based on Bi-Directional H-Bridge AC/AC Converter

by

,

,

and

Processes 2021, 9(9), 1541; https://doi.org/10.3390/pr9091541 - 30 Aug 2021

Cited by 2 | Viewed by 1620

Abstract

In this paper, the compensation of voltage sags and swells using a dynamic voltage restorer (DVR) based on a bi-directional AC/AC converter is presented for stabilizing single-phase AC line voltage. The H-bridge AC/AC converter with bi-directional switches and without bulk capacitor is adopted [...] Read more.

In this paper, the compensation of voltage sags and swells using a dynamic voltage restorer (DVR) based on a bi-directional AC/AC converter is presented for stabilizing single-phase AC line voltage. The H-bridge AC/AC converter with bi-directional switches and without bulk capacitor is adopted as the power topology of the proposed system. The proposed novel topology of DVR is adopted to compensate both voltage sag and swell conditions. Additionally, the power factor is closed to unity because a bulk capacitor is not required. The inner and outer loop control is proposed to improve the response with gain scaling; gain control is adopted to reduce the overshoot. Finally, a 2 kVA prototype has been implemented to verify the performance and accuracy of the control method for the DVR system. The peak efficiency of the system is up to 94%, and it can compensate 50% voltage swells and 25% voltage sags. Full article

(This article belongs to the Special Issue Application of Power Electronics Technologies in Power System)

► Show Figures

Figure 1

Open AccessArticle

New Control Scheme for Solar Power Systems under Varying Solar Radiation and Partial Shading Conditions

by

,

,

and

Processes 2021, 9(8), 1359; https://doi.org/10.3390/pr9081359 - 02 Aug 2021

Cited by 3 | Viewed by 1567

Abstract

The traditional perturbation and observation (P&O) maximum power point tracking (MPPT) algorithm of a structure is simple and low-cost. However, the P&O algorithm is prone to divergence under solar radiation when the latter varies rapidly and the P&O algorithm cannot track the maximum [...] Read more.

The traditional perturbation and observation (P&O) maximum power point tracking (MPPT) algorithm of a structure is simple and low-cost. However, the P&O algorithm is prone to divergence under solar radiation when the latter varies rapidly and the P&O algorithm cannot track the maximum power point (MPP) under partial shading conditions (PSCs). This study proposes an algorithm from the P&O algorithm combined with the solar radiation value detection scheme, where the solar radiation value detection is based on the solar photovoltaic (SPV) module equivalent conductance threshold control (CTC). While the proposed algorithm can immediately judge solar radiation, it also has suitable control strategies to achieve the high efficiency of MPPT especially for the rapid change in solar radiation and PSCs. In the actual test of the proposed algorithm and the P&O algorithm, the MPPT efficiency of the proposed algorithm could reach 99% under solar radiation, which varies rapidly, and under PSCs. However, in the P&O algorithm, the MPPT efficiency was 96% under solar radiation, which varies rapidly, while the MPPT efficiency was only 80% under PSCs. Furthermore, in verifying the experimental results, the proposed algorithm’s performance was higher than the P&O algorithm. Full article

(This article belongs to the Special Issue Application of Power Electronics Technologies in Power System)

► Show Figures

Figure 1

Open AccessArticle

Bridgeless Isolated AC LED Driver

by

Yeu-Torng Yau

,

Kuo-Ing Hwu

and

Chao-Wei Wang

Processes 2021, 9(7), 1173; https://doi.org/10.3390/pr9071173 - 06 Jul 2021

Viewed by 926

Abstract

A novel bridgeless isolated AC LED driver is developed, which improves LED utilization and application flexibility due to a coupled inductor inserted between the bidirectional switch and the LED module without any output electrolytic capacitor. By reducing the turns ratio of the coupled [...] Read more.

A novel bridgeless isolated AC LED driver is developed, which improves LED utilization and application flexibility due to a coupled inductor inserted between the bidirectional switch and the LED module without any output electrolytic capacitor. By reducing the turns ratio of the coupled inductor, the voltage across the secondary side will be decreased so as to lessen the voltage across the LED strings and hence reduce the number of LEDs, thereby making the load design of the AC LED driver more flexible. It is noted that the coupled inductor plays a role of not only galvanic isolation but also inductor behavior as well as transformer behavior. Therefore, during the turn-on period of the bidirectional switch, the coupled inductor can transfer the energy to one LED string and store the energy simultaneously, whereas during the turn-off period of the bidirectional switch, the coupled inductor can release the stored energy to the other LED string. That is, two LED strings are conducted over a pulse-width-modulated (PWM) period for any half-cycle, implying that LED utilization is upgraded. As for LED dimming, it is realized by directly tuning the control signal for the bidirectional switch without any dimming circuit. Eventually, the basic operating principles and theoretical deductions are given along with some experimental results provided to verify the effectiveness of the proposed AC LED driver topology. Full article

(This article belongs to the Special Issue Application of Power Electronics Technologies in Power System)

► Show Figures

Figure 1

Open AccessArticle

Novel High-Efficiency High Step-Up DC–DC Converter with Soft Switching and Low Component Voltage Stress for Photovoltaic System

by

Yu-En Wu

and

Jyun-Wei Wang

Processes 2021, 9(7), 1112; https://doi.org/10.3390/pr9071112 - 25 Jun 2021

Cited by 3 | Viewed by 1187

Abstract

This study developed a novel, high-efficiency, high step-up DC–DC converter for photovoltaic (PV) systems. The converter can step-up the low output voltage of PV modules to the voltage level of the inverter and is used to feed into the grid. The converter can [...] Read more.

This study developed a novel, high-efficiency, high step-up DC–DC converter for photovoltaic (PV) systems. The converter can step-up the low output voltage of PV modules to the voltage level of the inverter and is used to feed into the grid. The converter can achieve a high step-up voltage through its architecture consisting of a three-winding coupled inductor common iron core on the low-voltage side and a half-wave voltage doubler circuit on the high-voltage side. The leakage inductance energy generated by the coupling inductor during the conversion process can be recovered by the capacitor on the low-voltage side to reduce the voltage surge on the power switch, which gives the power switch of the circuit a soft-switching effect. In addition, the half-wave voltage doubler circuit on the high-voltage side can recover the leakage inductance energy of the tertiary side and increase the output voltage. The advantages of the circuit are low loss, high efficiency, high conversion ratio, and low component voltage stress. Finally, a 500-W high step-up converter was experimentally tested to verify the feasibility and practicability of the proposed architecture. The results revealed that the highest efficiency of the circuit is 98%. Full article

(This article belongs to the Special Issue Application of Power Electronics Technologies in Power System)

► Show Figures

Figure 1

Open AccessArticle

Analysis of a PWM Converter with Less Current Ripple, Wide Voltage Operation and Zero-Voltage Switching

by

Bor-Ren Lin

and

Yi-Hao Peng

Processes 2021, 9(4), 580; https://doi.org/10.3390/pr9040580 - 26 Mar 2021

Viewed by 1105

Abstract

This paper studies and implements a power converter to have less current ripple output and wide voltage input operation. A three-leg converter with different primary turns is presented on its high-voltage side to extend the input voltage range. The current doubler rectification circuit [...] Read more.

This paper studies and implements a power converter to have less current ripple output and wide voltage input operation. A three-leg converter with different primary turns is presented on its high-voltage side to extend the input voltage range. The current doubler rectification circuit is adopted on the output side to have low current ripple capability. From the switching states of the three-leg converter, the presented circuit has two equivalent sub-circuits under different input voltage ranges (V_in = 120–270 V or 270–600 V). The general phase-shift pulse-width modulation is employed to control the presented converter so that power devices can be turned on at zero voltage in order to reduce switching loss. Compared to two-stage circuit topologies with a wide voltage input operation, the presented converter has the benefits of simple circuit structure, easy control algorithm using a general integrated circuit or digital controller, and less components. The performance of the presented circuit is confirmed and validated by an 800 W laboratory prototype. Full article

(This article belongs to the Special Issue Application of Power Electronics Technologies in Power System)

► Show Figures

Figure 1

Open AccessArticle

Analysis of a Series‑Parallel Resonant Converter for DC Microgrid Applications

by

Bor-Ren Lin

Processes 2021, 9(3), 542; https://doi.org/10.3390/pr9030542 - 18 Mar 2021

Cited by 8 | Viewed by 1787

Abstract

An input-series output-parallel soft switching resonant circuit with balance input voltage and primary-side current is studied and implemented for direct current (DC) microgrid system applications. Two resonant circuits are connected with input-series and output-parallel structure to have the advantages of low voltage stresses [...] Read more.

An input-series output-parallel soft switching resonant circuit with balance input voltage and primary-side current is studied and implemented for direct current (DC) microgrid system applications. Two resonant circuits are connected with input-series and output-parallel structure to have the advantages of low voltage stresses on active devices and low current stresses on power diodes. A balance capacitor is adopted on high voltage side to balance two input capacitor voltages. The LLC (inductor–inductor–capacitor) resonant circuit cells are employed in the converter to have soft switching operation for power semiconductors. The magnetic coupling component is adopted on the primary-side to automatically realize current balance of the two resonant circuits. In the end, a laboratory hardware circuit is built and tested. Experiments demonstrate and prove the validity of the resonant converter. Full article

(This article belongs to the Special Issue Application of Power Electronics Technologies in Power System)

► Show Figures

Figure 1
