Minerals

Research

16 pages, 15762 KiB

Open AccessFeature PaperEditor’s ChoiceArticle

Unravelling the Deformation of Paleoproterozoic Marbles and Zn-Pb Ore Bodies by Combining 3D-Photogeology and Hyperspectral Data (Black Angel Mine, Central West Greenland)

by Pierpaolo Guarnieri, Sam T. Thiele, Nigel Baker, Erik V. Sørensen, Moritz Kirsch, Sandra Lorenz, Diogo Rosa, Gabriel Unger and Robert Zimmermann

Minerals 2022, 12(7), 800; https://doi.org/10.3390/min12070800 - 23 Jun 2022

Cited by 6 | Viewed by 3063

Abstract

The Black Angel Zn-Pb ore deposit is hosted in folded Paleoproterozoic marbles of the Mârmorilik Formation. It is exposed in the southern part of the steep and inaccessible alpine terrain of the Rinkian Orogen, in central West Greenland. Drill-core data integrated with 3D-photogeology [...] Read more.

The Black Angel Zn-Pb ore deposit is hosted in folded Paleoproterozoic marbles of the Mârmorilik Formation. It is exposed in the southern part of the steep and inaccessible alpine terrain of the Rinkian Orogen, in central West Greenland. Drill-core data integrated with 3D-photogeology and hyperspectral imagery of the rock face allow us to identify stratigraphic units and extract structural information that contains the geological setting of this important deposit. The integrated stratigraphy distinguishes chemical/mineralogical contrast within lithologies dominated by minerals that are difficult to distinguish with the naked eye, with a similar color of dolomitic and scapolite-rich marbles and calcitic, graphite-rich marbles. These results strengthen our understanding of the deformation style in the marbles and allow a subdivision between evaporite-carbonate platform facies and carbonate slope facies. Ore formation appears to have been mainly controlled by stratigraphy, with mineralizing fluids accumulating within permeable carbonate platform facies underneath carbonate slope facies and shales as cap rock. Later, folding and shearing were responsible for the remobilization and improvement of ore grades along the axial planes of shear folds. The contact between dolomitic scapolite-rich and calcitic graphite-rich marbles probably represents a direct stratigraphic marker, recognizable in the drill-cores, to be addressed for further 3D-modeling and exploration in this area. Full article

(This article belongs to the Special Issue 3D-Modelling of Crustal Structures and Mineral Deposit Systems)

► Show Figures

Figure 1

13 pages, 3116 KiB

Open AccessArticle

Atomic Model of Gold Adsorption onto the Pyrite Surface with DFT Study

by Chunlin Liu, Yongbing Li, Qi Cheng and Yang Zhao

Minerals 2022, 12(3), 387; https://doi.org/10.3390/min12030387 - 21 Mar 2022

Cited by 6 | Viewed by 2985

Abstract

Adsorption mineralization of gold is an important mineralization mechanism under epigenetic and low temperature conditions. In this paper, a plane-wave pseudopotential method based on density functional theory (DFT) is used to explore the adsorption mechanism of gold on the surface of pyrite. Among [...] Read more.

Adsorption mineralization of gold is an important mineralization mechanism under epigenetic and low temperature conditions. In this paper, a plane-wave pseudopotential method based on density functional theory (DFT) is used to explore the adsorption mechanism of gold on the surface of pyrite. Among the three surfaces of pyrite, the surface energies of (100), (111), and (210) surfaces are 1.0508, 1.5337, and 1.8255 J∙m², respectively, and the (100) surface is the most stable surface in the thermodynamic state. The adsorption capacities of gold atoms under different surfaces are (210) (−2.68 eV) > (111) (−1.67 eV) > (100) (−0.84 eV). Mulliken analysis indicates that charge transfer occurs after the adsorption of gold atoms onto the surface of pyrite (210), and gold and iron atoms are oxidized with the reduction of sulfur atoms. The density of states (PDOS) analysis shows that the 5d orbital on the Fermi energy level of the iron atom is active and the adsorption capacity is greater than that of the sulfur atom, and adsorption is formed between the gold atom, which leads to the gold being able to be stably deposited on the surface of pyrite (210). Full article

(This article belongs to the Special Issue 3D-Modelling of Crustal Structures and Mineral Deposit Systems)

► Show Figures

Figure 1

16 pages, 1291 KiB

Open AccessArticle

Informed Local Smoothing in 3D Implicit Geological Modeling

by Jan von Harten, Miguel de la Varga, Michael Hillier and Florian Wellmann

Minerals 2021, 11(11), 1281; https://doi.org/10.3390/min11111281 - 18 Nov 2021

Cited by 10 | Viewed by 2801

Abstract

Geological models are commonly used to represent geological structures in 3D space. A wide range of methods exists to create these models, with much scientific work focusing recently on implicit representation methods, which perform an interpolation of a three-dimensional field where the relevant [...] Read more.

Geological models are commonly used to represent geological structures in 3D space. A wide range of methods exists to create these models, with much scientific work focusing recently on implicit representation methods, which perform an interpolation of a three-dimensional field where the relevant boundaries are then isosurfaces in this field. However, this method has well-known problems with inhomogeneous data distributions: if regions with densely sampled data points exist, modeling artifacts are common. We present here an approach to overcome this deficiency through a combination of an implicit interpolation algorithm with a local smoothing approach. The approach is based on the concepts of nugget effect and filtered kriging known from conventional geostatistics. It reduces the impact of regularly occurring modeling artifacts that result from data uncertainty and data configuration and additionally aims to improve model robustness for scale-dependent fit-for-purpose modeling. Local smoothing can either be manually adjusted, inferred from quantified uncertainties associated with input data or derived automatically from data configuration. The application for different datasets with varying configuration and noise is presented for a low complexity geologic model. The results show that the approach enables a reduction of artifacts, but may require a careful choice of parameter settings for very inhomogeneous data sets. Full article

(This article belongs to the Special Issue 3D-Modelling of Crustal Structures and Mineral Deposit Systems)

► Show Figures

Figure 1

15 pages, 3928 KiB

Open AccessArticle

Local Dynamic Updating Method of Orebody Model Based on Mesh Reconstruction and Mesh Deformation

by Zhaopeng Li, Deyun Zhong, Zhaohao Wu, Liguan Wang and Qiwang Tang

Minerals 2021, 11(11), 1232; https://doi.org/10.3390/min11111232 - 6 Nov 2021

Cited by 2 | Viewed by 1964

Abstract

In this paper, to update the orebody model based on the given interpreted geological information, we present a local dynamic updating method of the orebody model that allows the interactive construction of the constraint deformation conditions and the dynamic updating of the mesh [...] Read more.

In this paper, to update the orebody model based on the given interpreted geological information, we present a local dynamic updating method of the orebody model that allows the interactive construction of the constraint deformation conditions and the dynamic updating of the mesh model. The rules for constructing deformation constraints based on the control polylines are discussed. Because only part of the model is updated, the updated mesh is effective and the overall quality is satisfactory. Our main contribution is that we propose a local dynamic updating method for the orebody model based on mesh reconstruction and mesh deformation. This method can automatically update a given 3D orebody model based on a set of unordered geological interpretation lines. Moreover, we implement a deformation neighborhood region search method based on the specified ring radius and a local constrained mesh deformation algorithm for the orebody model. Finally, we test the method and show the model update results with real geological datasets, which proves that this method is effective for the local updating of orebody models. Full article

(This article belongs to the Special Issue 3D-Modelling of Crustal Structures and Mineral Deposit Systems)

► Show Figures

Figure 1

36 pages, 14512 KiB

Open AccessArticle

Insights and Lessons from 3D Geological and Geophysical Modeling of Mineralized Terranes in Tasmania

by Daniel Bombardieri, Mark Duffett, Andrew McNeill, Matthew Cracknell and Anya Reading

Minerals 2021, 11(11), 1195; https://doi.org/10.3390/min11111195 - 27 Oct 2021

Cited by 2 | Viewed by 3794

Abstract

Over the last two decades, Mineral Resources Tasmania has been developing regional 3D geological and geophysical models for prospective terranes at a range of scales and extents as part of its suite of precompetitive geoscience products. These have evolved in conjunction with developments [...] Read more.

Over the last two decades, Mineral Resources Tasmania has been developing regional 3D geological and geophysical models for prospective terranes at a range of scales and extents as part of its suite of precompetitive geoscience products. These have evolved in conjunction with developments in 3D modeling technology over that time. Commencing with a jurisdiction-wide 3D model in 2002, subsequent modeling projects have explored a range of approaches to the development of 3D models as a vehicle for the better synthesis and understanding of controls on ore-forming processes and prospectivity. These models are built on high-quality potential field data sets. Assignment of bulk properties derived from previous well-constrained geophysical modeling and an extensive rock property database has enabled the identification of anomalous features that have been targeted for follow-up mineral exploration. An aspect of this effort has been the generation of uncertainty estimates for model features. Our experience is that this process can be hindered by models that are too large or too detailed to be interrogated easily, especially when modeling techniques do not readily permit significant geometric changes. The most effective 3D modeling workflow for insights into mineral exploration is that which facilitates the rapid hypothesis testing of a wide range of scenarios whilst satisfying the constraints of observed data. Full article

(This article belongs to the Special Issue 3D-Modelling of Crustal Structures and Mineral Deposit Systems)

► Show Figures

Figure 1

17 pages, 12235 KiB

Open AccessArticle

Three-Dimensional Anisotropic Inversions for Time-Domain Airborne Electromagnetic Data

by Yang Su, Changchun Yin, Yunhe Liu, Xiuyan Ren, Bo Zhang and Bin Xiong

Minerals 2021, 11(2), 218; https://doi.org/10.3390/min11020218 - 20 Feb 2021

Cited by 4 | Viewed by 2562

Abstract

Rocks and ores in nature usually appear macro-anisotropic, especially in sedimentary areas with strong layering. This anisotropy will lead to false interpretation of electromagnetic (EM) data when inverted under the assumption of an isotropic earth. However, the time-domain (TD) airborne EM (AEM) inversion [...] Read more.

Rocks and ores in nature usually appear macro-anisotropic, especially in sedimentary areas with strong layering. This anisotropy will lead to false interpretation of electromagnetic (EM) data when inverted under the assumption of an isotropic earth. However, the time-domain (TD) airborne EM (AEM) inversion for an anisotropic model has not attracted much attention. To get reasonable inversion results from TD AEM data, we present in this paper the forward modeling and inversion methods based on a triaxial anisotropic model. We apply three-dimensional (3D) finite-difference on the secondary scattered electric field equation to calculate the frequency-domain (FD) EM responses, then we use the inverse Fourier transform and waveform convolution to obtain TD responses. For the regularized inversion, we calculate directly the sensitivities with respect to three diagonal conductivities and then use the Gauss–Newton (GN) optimization scheme to recover model parameters. To speed up the computation and to reduce the memory requirement, we adopt the moving footprint concept and separate the whole model into a series of small sub-models for the inversion. Finally, we compare our anisotropic inversion scheme with the isotropic one using both synthetic and field data. Numerical experiments show that the anisotropic inversion has inherent advantages over the isotropic ones, we can get more reasonable results for the anisotropic earth structures. Full article

(This article belongs to the Special Issue 3D-Modelling of Crustal Structures and Mineral Deposit Systems)

► Show Figures

Figure 1

21 pages, 12179 KiB

Open AccessArticle

3D Geological Model of the Touro Cu Deposit, A World-Class Mafic-Siliciclastic VMS Deposit in the NW of the Iberian Peninsula

by Mónica Arias, Pablo Nuñez, Daniel Arias, Pablo Gumiel, Cesar Castañón, Jorge Fuertes-Blanco and Agustin Martin-Izard

Minerals 2021, 11(1), 85; https://doi.org/10.3390/min11010085 - 16 Jan 2021

Cited by 8 | Viewed by 4100

Abstract

The Touro volcanogenic massive sulfide (VMS) deposit is located in the NW of the Iberian Variscan massif in the Galicia-Trás-os-Montes Zone, an amalgamation of several allochthonous terrains. The Órdenes complex is the most extensive of the allochthone complexes, and amphibolites and paragneisses host [...] Read more.

The Touro volcanogenic massive sulfide (VMS) deposit is located in the NW of the Iberian Variscan massif in the Galicia-Trás-os-Montes Zone, an amalgamation of several allochthonous terrains. The Órdenes complex is the most extensive of the allochthone complexes, and amphibolites and paragneisses host the deposit, characterized as being massive or semimassive (stringers) sulfides, mostly made up of pyrrhotite and chalcopyrite. The total resources are 103 Mt, containing 0.41% copper. A 3D model of the different orebodies and host rocks was generated using data from 1090 drill core logs. The model revealed that the structure of the area is a N–S-trending antiform. The orebodies crop out in the limbs and in the hinge zone. The mineralized structures are mostly tabular, up to 100 m in thickness and subhorizontal. Based on the petrography, geochemistry and the 3D model, the Touro deposit is classified as a VMS of the mafic-siliciclastic type formed in an Ordovician back-arc setting, which was buried and metamorphosed in Middle Devonian. Full article

(This article belongs to the Special Issue 3D-Modelling of Crustal Structures and Mineral Deposit Systems)

► Show Figures

Figure 1

22 pages, 6354 KiB

Open AccessArticle

Implicit Geomodelling of the Merensky and UG2 Reefs of the Bushveld Complex from Open-Source Data: Implications for the Complex’s Structural History

by Ben Stoch, Ian James Basson and Jodie A. Miller

Minerals 2020, 10(11), 975; https://doi.org/10.3390/min10110975 - 1 Nov 2020

Cited by 3 | Viewed by 4837

Abstract

The Bushveld Complex (BC) is the world’s largest source of platinum group metals. Extensive studies on the complex have focused on its geochemistry, magma and platinum group mineral genesis, mineral characterization and intrusion mechanisms. However, relatively little work has been undertaken on the [...] Read more.

The Bushveld Complex (BC) is the world’s largest source of platinum group metals. Extensive studies on the complex have focused on its geochemistry, magma and platinum group mineral genesis, mineral characterization and intrusion mechanisms. However, relatively little work has been undertaken on the overall 3D geometry of the complex, which detracts from the adequate contextualization of such studies. Furthermore, the absence of a broader 3D model of the complex does not permit the identification of structural trends and mineralization patterns. This contribution details the construction of 3D implicitly-modelled Merensky and UG2 Reefs across the Rustenburg Layered Suite of the BC, using Seequent’s Leapfrog software. Multiple open-source and public-domain data sources and modelling workflows were explored to account for disparities in data resolution, data spacing and clustering, and the resolution of model outputs. Key outcomes are (1) a representative, fully-implicit, dynamic geological model of the Merensky and UG2 Reefs over the main chamber of the BC; (2) identification of modelled features that augment the current understanding of the BC’s kinematic history and cumulative deformation; and (3) identification and analysis of subtle geometrical trends and patterns, such as inter-reef spacing and modelled depths, as well as structural domains that may not have been apparent from numerous, more focused or isolated petrological or geochemical studies. It is anticipated that this baseline 3D model will form the foundation for future, possibly localized, dynamic updates as further information becomes available. The addition of proprietary (viz., non-open-source) data, such as 2D seismic sections and 3D seismic surveys, would enhance the overall resolution and quality of such a model and resulting interpretations. Full article

(This article belongs to the Special Issue 3D-Modelling of Crustal Structures and Mineral Deposit Systems)

► Show Figures

Figure 1
