Special Issue "Instrumented Indentation Test: An Aiding Tool for Materials Science and Industry"

A special issue of Materials (ISSN 1996-1944). This special issue belongs to the section "Materials Simulation and Design".

Deadline for manuscript submissions: 20 December 2022 | Viewed by 9260

Special Issue Editors

Prof. Giovanni Maizza
E-Mail Website
Guest Editor
Politecnico di Torino, Turin, Italy
Interests: instrumented indentation testing; contact mechanics; micro–macro modeling of the multiphysical processing of materials; microstructure design of materials; microstructure–property–process parameter relationships
Prof. Dr. Dongil Kwon
E-Mail Website
Co-Guest Editor
Seoul National University
Interests: instrumented indentation testing; residual stress measurement; reliability assessment

Special Issue Information

Dear Colleagues,

It is believed that the instrumented indentation test (IIT) will revolutionize the industry in the next two decades, while continuing to lead to new elucidations about the nature and behavior of materials. It shares the same mechanical fundamentals as a conventional indentation test (IT), but it also permits a multitude of indentation properties, other than hardness, to be extracted in a quick, easy, and nondestructive manner. As such, it can be used either in offline or online manufacturing processes to assess the final mechanical performances of a part or to optimize the most relevant process parameters. IIT is particularly suitable for additive manufactured products, welded joints, and microelectromechanical devices, which generally lack a standard structural assessment. Although IIT can virtually be performed over nano-, micro- and macrodimensional scales, over the last decade, research into IIT has been dominated by nano-IIT studies, which have had a great impact on the progress of materials science and the thin film and coating industry. However, even greater impacts may be expected in the industrial sectors if macro-IIT comes into play, provided that appropriate guidelines are available. Macro-indentation properties correlate more naturally with the familiar tensile-like properties than nano-IIT ones do; thus, the macro-instrumented indentation test will offer an unprecedent viable nondestructive means of measuring tensile-like elastoplastic properties at a local scale in a wide range of metals and engineering alloys. The primary goal of this Special Issue is to present the recent advances in IIT research, with particular attention to macro-IIT achievements. The secondary goal is to provide comprehensive fundamental knowledge on IIT methodologies along with useful guidelines that are not covered by any available national or international standard, to permit IIT techniques to be exploited in new research and engineering fields.

Prof. Giovanni Maizza
Prof. Dongil Kwon
Guest Editors

Manuscript Submission Information

Manuscripts should be submitted online at www.mdpi.com by registering and logging in to this website. Once you are registered, click here to go to the submission form. Manuscripts can be submitted until the deadline. All submissions that pass pre-check are peer-reviewed. Accepted papers will be published continuously in the journal (as soon as accepted) and will be listed together on the special issue website. Research articles, review articles as well as short communications are invited. For planned papers, a title and short abstract (about 100 words) can be sent to the Editorial Office for announcement on this website.

Submitted manuscripts should not have been published previously, nor be under consideration for publication elsewhere (except conference proceedings papers). All manuscripts are thoroughly refereed through a single-blind peer-review process. A guide for authors and other relevant information for submission of manuscripts is available on the Instructions for Authors page. Materials is an international peer-reviewed open access semimonthly journal published by MDPI.

Please visit the Instructions for Authors page before submitting a manuscript. The Article Processing Charge (APC) for publication in this open access journal is 2300 CHF (Swiss Francs). Submitted papers should be well formatted and use good English. Authors may use MDPI's English editing service prior to publication or during author revisions.

Keywords

  • Instrumented indentation
  • Indentation theory and modeling
  • Residual stress measurement
  • Field-assisted indentation
  • Materials: conventional bulk as well as nanocrystalline and porous metals and alloys
  • similar and dissimilar welded joints
  • Materials behavior: elastoplatic, superplastic, superelastic, recrystallization, creep, anisotropic
  • New in situ and ex situ inspection methodologies aiding materials characterization during indentation

Published Papers (10 papers)

Order results
Result details
Select all
Export citation of selected articles as:

Research

Jump to: Review

Article
Accurate Estimation of Yield Strength and Ultimate Tensile Strength through Instrumented Indentation Testing and Chemical Composition Testing
Materials 2022, 15(3), 832; https://doi.org/10.3390/ma15030832 - 22 Jan 2022
Viewed by 573
Abstract
Federal rule changes governing natural gas pipelines have made non-destructive techniques, such as instrumented indentation testing (IIT), an attractive alternative to destructive tests for verifying properties of steel pipeline segments that lack traceable records. Ongoing work from Pacific Gas and Electric Company’s (PG&E) [...] Read more.
Federal rule changes governing natural gas pipelines have made non-destructive techniques, such as instrumented indentation testing (IIT), an attractive alternative to destructive tests for verifying properties of steel pipeline segments that lack traceable records. Ongoing work from Pacific Gas and Electric Company’s (PG&E) materials verification program indicates that IIT measurements may be enhanced by incorporating chemical composition data. This paper presents data from PG&E’s large-scale IIT program that demonstrates the predictive capabilities of IIT and chemical composition data, with particular emphasis given to differences between ultimate tensile strength (UTS) and yield strength (YS). For this study, over 80 segments of line pipe were evaluated through tensile testing, IIT, and compositional testing by optical emission spectroscopy (OES) and laboratory combustion. IIT measurements of UTS were, generally, in better agreement with destructive tensile data than YS and exhibited about half as much variability as YS measurements on the same sample. The root-mean squared error for IIT measurements of UTS and YS, respectively, were 27 MPa (3.9 ksi) and 43 MPa (6.2 ksi). Next, a machine learning model was trained to estimate YS and UTS by combining IIT with chemical composition data. The agreement between the model’s estimated UTS and tensile UTS values was only slightly better than the IIT-only measurements, with an RMSE of 21 MPa (3.1 ksi). However, the YS estimates showed much greater improvement with an improved RMSE of 27 MPa (3.9 ksi). The experimental, mechanical, and metallurgical factors that contributed to IIT’s ability to consistently determine destructive UTS, and the differences in its interaction with composition as compared to YS, are discussed herein. Full article
Show Figures

Figure 1

Article
Pop-In Identification in Nanoindentation Curves with Deep Learning Algorithms
Materials 2021, 14(22), 7027; https://doi.org/10.3390/ma14227027 - 19 Nov 2021
Viewed by 532
Abstract
High–speed nanoindentation rapidly generates large datasets, opening the door for advanced data analysis methods such as the resources available in artificial intelligence. The present study addresses the problem of differentiating load–displacement curves presenting pop-in, slope changes, or instabilities from curves exhibiting a typical [...] Read more.
High–speed nanoindentation rapidly generates large datasets, opening the door for advanced data analysis methods such as the resources available in artificial intelligence. The present study addresses the problem of differentiating load–displacement curves presenting pop-in, slope changes, or instabilities from curves exhibiting a typical loading path in large nanoindentation datasets. Classification of the curves was achieved with a deep learning model, specifically, a convolutional neural network (CNN) model implemented in Python using TensorFlow and Keras libraries. Load–displacement curves (with pop-in and without pop-in) from various materials were input to train and validate the model. The curves were converted into square matrices (50 × 50) and then used as inputs for the CNN model. The model successfully differentiated between pop-in and non-pop-in curves with approximately 93% accuracy in the training and validation datasets, indicating that the risk of overfitting the model was negligible. These results confirmed that artificial intelligence and computer vision models represent a powerful tool for analyzing nanoindentation data. Full article
Show Figures

Figure 1

Article
Instrumented Nanoindentation Tests Applied to Bulk Metallic Materials: From Calibration Issue to Pile-Up Phenomena
Materials 2021, 14(21), 6360; https://doi.org/10.3390/ma14216360 - 24 Oct 2021
Viewed by 452
Abstract
Instrumented nanoindentation tests have reached an effective level of theoretical and practical knowledge to become an interesting and useful tool for determining hardness, H, and local elasticity (reduced Young’s modulus), Er, of a variety of materials, from coatings and thin [...] Read more.
Instrumented nanoindentation tests have reached an effective level of theoretical and practical knowledge to become an interesting and useful tool for determining hardness, H, and local elasticity (reduced Young’s modulus), Er, of a variety of materials, from coatings and thin films to bulk metallic materials. Nanoindentation instruments are equipped with analysis software for raw data for hardness and reduced Young’s modulus evaluation, generally based on the Oliver and Pharr analysis method. On the other hand, it is widely known and recognized that prior data acquisition, a tip-dependent calibration procedure of compliance, and area function are needed. With this in view, an accurate and sound calibration protocol is here reported. Hardness and local elastic modulus is measured on different bulk metallic materials, showing the distinctive strengths of using nanoindentation. Finally, a local elastic-plastic phenomenon mostly induced by the nanoindentation tip on ductile metallic material (i.e., pile-up) is also reported and modelled. This manuscript is thus intended to favor and account for the importance of using the instrumented nanoindentation tests for H and Er measurements of metallic materials. Full article
Show Figures

Figure 1

Article
Indentation Modulus, Indentation Work and Creep of Metals and Alloys at the Macro-Scale Level: Experimental Insights into the Use of a Primary Vickers Hardness Standard Machine
Materials 2021, 14(11), 2912; https://doi.org/10.3390/ma14112912 - 28 May 2021
Cited by 3 | Viewed by 826
Abstract
In this work, the experimental method and the calculation model for the determination of indentation moduli, indentation work, and indentation creep of metallic materials, by means of macroscale-level forces provided by a primary hardness standard machine at the National Institute of Metrological Research [...] Read more.
In this work, the experimental method and the calculation model for the determination of indentation moduli, indentation work, and indentation creep of metallic materials, by means of macroscale-level forces provided by a primary hardness standard machine at the National Institute of Metrological Research (INRIM) at the at room temperature were described. Indentation moduli were accurately determined from measurements of indentation load, displacement, contact stiffness and hardness indentation imaging and from the slope of the indentation unloading curve by applying the Doerner-Nix linear model; indentation work, representing the mechanical work spent during the force application of the indentation procedure, was determined by calculating the areas under the loading–unloading indentation curve, through fitting experimental data with a polynomial law. Measurements were performed with a pyramidal indenter (Vickers test). The applied force was provided by a deadweight machine, and the related displacement was measured by a laser interferometric system. Applied forces and the occurring indentation depths were simultaneously measured: the resulting loading–unloading indentation curve was achieved. Illustrative tests were performed on metals and alloy samples. Discussion and comments on the suitability of the proposed method and analysis were reported. Full article
Show Figures

Figure 1

Article
Application of Macro-Instrumented Indentation Test for Superficial Residual Stress and Mechanical Properties Measurement for HY Steel Welded T-Joints
Materials 2021, 14(8), 2061; https://doi.org/10.3390/ma14082061 - 19 Apr 2021
Cited by 6 | Viewed by 899
Abstract
HY-80 and HY-100 steels, widely used in constructing large ocean vessels and submarine hulls, contain mixed microstructures of tempered bainite and martensite and provide high tensile strength and toughness. Weld integrity in HY steels has been studied to verify and optimize welding conditions. [...] Read more.
HY-80 and HY-100 steels, widely used in constructing large ocean vessels and submarine hulls, contain mixed microstructures of tempered bainite and martensite and provide high tensile strength and toughness. Weld integrity in HY steels has been studied to verify and optimize welding conditions. In this study, the T-joint weld coupons, HY80 and HY100, were fabricated from HY-80 and HY-100 steel plates with a thickness of 30 mm as base metals by submerged-arc welding. Flux-cored arc welding was performed on an additional welding coupon consisting of HY-100 to evaluate the effect of repair welds (HY100RP). Microstructures in the heat-affected zones (HAZ) were thoroughly analyzed by optical observation. Instrumented indentation testing, taking advantage of local characterization, was applied to assess the yield strength and the residual stress of the HAZ and base regions. The maximum hardness over 400 HV was found in the HAZ due to the high volume fraction of untempered martensite microstructure. The yield strength of the weld coupons was evaluated by indentation testing, and the results showed good agreement with the uniaxial tensile test (within 10% range). The three coupons showed similar indentation residual stress profiles on the top and bottom surfaces. The stress distribution of the HY100 coupon was comparable to the results from X-ray diffraction. HY100RP demonstrated increased tensile residual stress compared to the as-welded coupon due to the effect of the repair weld (323 and 103 MPa on the top and bottom surfaces). This study verifies the wide applicability of indentation testing in evaluating yield strength and residual stress. Full article
Show Figures

Figure 1

Article
Flat-Top Cylinder Indenter for Mechanical Characterization: A Report of Industrial Applications
Materials 2021, 14(7), 1742; https://doi.org/10.3390/ma14071742 - 01 Apr 2021
Cited by 1 | Viewed by 573
Abstract
FIMEC (flat-top cylinder indenter for mechanical characterisation) is an instrumented indentation test employing a cylindrical punch. It has been used to determine the mechanical properties of metallic materials in several applications of industrial interest. This work briefly describes the technique and the theory [...] Read more.
FIMEC (flat-top cylinder indenter for mechanical characterisation) is an instrumented indentation test employing a cylindrical punch. It has been used to determine the mechanical properties of metallic materials in several applications of industrial interest. This work briefly describes the technique and the theory of indentation with a flat-ended punch. The flat indentation of metals has been investigated through experimental tests, and an equation has been derived to calculate the yield stress from the experimental data in deep indentation. The approach is supported by many data on various metals and alloys. Some selected case studies are presented in the paper: (i) crank manufacturing through pin squeeze casting; (ii) the evaluation of the local mechanical properties in a carter of complex geometry; (iii) the qualification of Al billets for extrusion; (iv) stress–relaxation tests on CuCrZr heat sinks; (v) the characterization of thick W coatings on CuCrZr alloy; (vi) the measure of the local mechanical properties of the molten-zone (MZ) and the heat-affected zone (HAZ) in welded joints. The case studies demonstrate the great versatility of the FIMEC test which provides information not available by employing conventional experimental techniques such as tensile, bending, and hardness tests. On the basis of theoretical knowledge and large amount of experimental data, FIMEC has become a mature technique for application on a large scale in industrial practice. Full article
Show Figures

Figure 1

Article
Correlation Between the Indentation Properties and Microstructure of Dissimilar Capacitor Discharge Welded WC-Co/High-Speed Steel Joints
Materials 2020, 13(11), 2657; https://doi.org/10.3390/ma13112657 - 11 Jun 2020
Cited by 8 | Viewed by 897
Abstract
The welding of cemented carbide to tool steel is a challenging task, of scientific and industrial relevance, as it combines the high level of hardness of cemented carbide with the high level of fracture toughness of steel, while reducing the shaping cost and [...] Read more.
The welding of cemented carbide to tool steel is a challenging task, of scientific and industrial relevance, as it combines the high level of hardness of cemented carbide with the high level of fracture toughness of steel, while reducing the shaping cost and extending the application versatility, as its tribological, toughness, thermal and chemical properties can be optimally harmonised. The already existing joining technologies often impart either insufficient toughness or poor high-temperature strength to a joint to withstand the ever-increasing severe service condition demands. In this paper, a novel capacitor discharge welding (CDW) process is investigated for the case of a butt-joint between a tungsten carbide-cobalt (WC-Co) composite rod and an AISI M35 high-speed steel (HSS) rod. The latter was shaped with a conical-ended projection to promote a high current concentration and heat at the welding zone. CDW functions by combining a direct current (DC) electric current pulse and external uniaxial pressure after a preloading step, in which only uniaxial pressure is applied. The relatively high heating and cooling rates promote a thin layer of a characteristic ultrafine microstructure that combines high strength and toughness. Morphological analysis showed that the CDW process: (a) forms a sound and net shaped joint, (b) preserves the sub-micrometric grain structure of the original WC-Co composite base materials, via a transitional layer, (c) refines the microstructure of the original martensite of the HSS base material, and (d) results in an improved corrosion resistance across a 1-mm thick layer near the weld interface on the steel side. A nano-indentation test survey determined: (e) no hardness deterioration on the HSS side of the weld zone, although (f) a slight decrease in hardness was observed across the transitional layer on the composite side. Furthermore, (g) an indication of toughness of the joint was perceived as the size of the crack induced by processing the residual stress after sample preparation was unaltered. Full article
Show Figures

Graphical abstract

Article
Nano-Indentation Properties of Tungsten Carbide-Cobalt Composites as a Function of Tungsten Carbide Crystal Orientation
Materials 2020, 13(9), 2137; https://doi.org/10.3390/ma13092137 - 05 May 2020
Cited by 5 | Viewed by 1595
Abstract
Tungsten carbide-cobalt (WC-Co) composites are a class of advanced materials that have unique properties, such as wear resistance, hardness, strength, fracture-toughness and both high temperature and chemical stability. It is well known that the local indentation properties (i.e., nano- and micro-hardness) of the [...] Read more.
Tungsten carbide-cobalt (WC-Co) composites are a class of advanced materials that have unique properties, such as wear resistance, hardness, strength, fracture-toughness and both high temperature and chemical stability. It is well known that the local indentation properties (i.e., nano- and micro-hardness) of the single crystal WC particles dispersed in such composite materials are highly anisotropic. In this paper, the nanoindentation response of the WC grains of a compact, full-density, sintered WC-10Co composite material has been investigated as a function of the crystal orientation. Our nanoindentation survey has shown that the nanohardness was distributed according to a bimodal function. This function was post-processed using the unique features of the finite mixture modelling theory. The combination of electron backscattered diffraction (EBSD) and statistical analysis has made it possible to identify the orientation of the WC crystal and the distinct association of the inherent nanoindentation properties, even for a small set (67) of nanoindentations. The proposed approach has proved to be faster than the already existing ones and just as reliable, and it has confirmed the previous findings concerning the relationship between crystal orientation and indentation properties, but with a significant reduction of the experimental data. Full article
Show Figures

Figure 1

Article
Relationship of Stiffness-Based Indentation Properties Using Continuous-Stiffness-Measurement Method
Materials 2020, 13(1), 97; https://doi.org/10.3390/ma13010097 - 24 Dec 2019
Cited by 4 | Viewed by 1046
Abstract
The determination of elastic modulus (E) and hardness (H) relies on the accuracy of the contact area under the indenter tip, but this parameter cannot be explicitly measured during the nanoindentation process. This work presents a new approach that [...] Read more.
The determination of elastic modulus (E) and hardness (H) relies on the accuracy of the contact area under the indenter tip, but this parameter cannot be explicitly measured during the nanoindentation process. This work presents a new approach that can derive the elastic modulus (E) and contact depth (hc) based on measured experiment stiffness using the continuous-stiffness-measurement (CSM) method. To achieve this, an inverse algorithm is proposed by incorporating a set of stiffness-based relationship functions that are derived from combining the dimensional analysis approach and computational simulation. This proposed solution considers both the sink-in and pile-up contact profiles; therefore, it provides a more accurate solution when compared to a conventional method that only considers the sink-in contact profile. While the proposed solution is sensitive to Poisson’s ratio (ν) and the equivalent indentation conical angle (θ), it is not affected by material plasticity, including yield strength (σy) and work hardening (n) for the investigated range of 0.001 < σy/E < 0.5. The proposed stiffness-based approach can be used to consistently derive elastic modulus and hardness by using stiffness and the load-and-unload curve measured by the continuous-stiffness-measurement (CSM) method. Full article
Show Figures
