Two-Dimensional (2D) Materials: Applications, Performance and Future Trends

A special issue of Applied Sciences (ISSN 2076-3417). This special issue belongs to the section "Materials Science and Engineering".

Deadline for manuscript submissions: closed (20 September 2024) | Viewed by 4459

Special Issue Editor


E-Mail Website
Guest Editor
Center for Terahertz Waves and College of Precision Instrument and Optoelectronics Engineering, Tianjin University, Tianjin 300072, China
Interests: 2D materials; nano-optoelectronics; wafer-scale synthesis

Special Issue Information

Dear Colleagues,

Since the discovery of graphene in 2004, two-dimensional (2D) materials have attracted considerable attention in the past decade. The atomically thin thickness and van der Waals (vdWs) interaction between adjacent layers endow 2D materials with unique layer-dependent electrical, optical, and mechanical properties. With the rapid expansion of 2D groups in recent years, 2D materials have been applied in various fields, such as electronics, optoelectronics, biomedicine, catalysis, and energy storage. Compared to conventional materials, 2D devices not only possess a small size and tunable features but also exhibit remarkable performance and potential to develop real applications. This Special Issue of Applied Sciences aims to present original articles on the applications, performance, and future trends of 2D materials, providing a platform to share ideas and improve the investigation of the development of practical 2D devices. Both original research and review articles are welcomed in this issue.

Dr. Zhibin Yang
Guest Editor

Manuscript Submission Information

Manuscripts should be submitted online at www.mdpi.com by registering and logging in to this website. Once you are registered, click here to go to the submission form. Manuscripts can be submitted until the deadline. All submissions that pass pre-check are peer-reviewed. Accepted papers will be published continuously in the journal (as soon as accepted) and will be listed together on the special issue website. Research articles, review articles as well as short communications are invited. For planned papers, a title and short abstract (about 100 words) can be sent to the Editorial Office for announcement on this website.

Submitted manuscripts should not have been published previously, nor be under consideration for publication elsewhere (except conference proceedings papers). All manuscripts are thoroughly refereed through a single-blind peer-review process. A guide for authors and other relevant information for submission of manuscripts is available on the Instructions for Authors page. Applied Sciences is an international peer-reviewed open access semimonthly journal published by MDPI.

Please visit the Instructions for Authors page before submitting a manuscript. The Article Processing Charge (APC) for publication in this open access journal is 2400 CHF (Swiss Francs). Submitted papers should be well formatted and use good English. Authors may use MDPI's English editing service prior to publication or during author revisions.

Keywords

  • 2D materials
  • nanotechnology
  • electronic devices
  • optoelectronic applications
  • energy storage
  • wafer-scale synthesis

Benefits of Publishing in a Special Issue

  • Ease of navigation: Grouping papers by topic helps scholars navigate broad scope journals more efficiently.
  • Greater discoverability: Special Issues support the reach and impact of scientific research. Articles in Special Issues are more discoverable and cited more frequently.
  • Expansion of research network: Special Issues facilitate connections among authors, fostering scientific collaborations.
  • External promotion: Articles in Special Issues are often promoted through the journal's social media, increasing their visibility.
  • e-Book format: Special Issues with more than 10 articles can be published as dedicated e-books, ensuring wide and rapid dissemination.

Further information on MDPI's Special Issue polices can be found here.

Published Papers (4 papers)

Order results
Result details
Select all
Export citation of selected articles as:

Research

Jump to: Review

12 pages, 2833 KiB
Article
Strain-Controlled Electronic and Magnetic Properties of Janus Nitride MXene Monolayer MnCrNO2
by Wentao Yue, Jun Shan, Runxian Jiao, Lichuan Zhang, Yuanping Chen and Dong Hao
Appl. Sci. 2024, 14(18), 8427; https://doi.org/10.3390/app14188427 - 19 Sep 2024
Viewed by 296
Abstract
Two-dimensional (2D) van der Waals (vdW) magnetic materials show potential for the advancement of high-density, energy-efficient electronic and spintronic applications in future memory and computation. Here, by using first-principles density functional theory (DFT) calculations, we predict a new 2D Janus nitride MXene MnCrNO [...] Read more.
Two-dimensional (2D) van der Waals (vdW) magnetic materials show potential for the advancement of high-density, energy-efficient electronic and spintronic applications in future memory and computation. Here, by using first-principles density functional theory (DFT) calculations, we predict a new 2D Janus nitride MXene MnCrNO2 monolayer. Our results suggest that the optimized MnCrNO2 monolayer possesses a hexagonal structure and exhibits good dynamical stability. The intrinsic monolayer MnCrNO2 exhibits semiconductive properties and adopts a ferromagnetic ground state with an out-of-plane easy axis. It can sustain strain effects within a wide range of strains from −10% to +8%, as indicated by the phonon dispersion spectra. Under the biaxial tensile strain, a remarkable decrease in the bandgap of the MnCrNO2 is induced, which is attributed to the distinct roles played by Mn and Cr in the VBM or CBM bands. Furthermore, when the compressive strain reaches approximately −8%, the magnetic anisotropy undergoes a transition from an out-of-plane easy axis to an in-plane easy axis. This change is mainly influenced by the efficient hybridization of the d orbitals, particularly in Mn atoms. Our study of the Janus MXene MnCrNO2 monolayer indicates its potential as a promising candidate for innovative electronic and spintronic devices; this potential is expected to create interest in its synthesis. Full article
Show Figures

Figure 1

17 pages, 6083 KiB
Article
Floquet Modification of the Bandgaps and Energy Spectrum in Flat-Band Pseudospin-1 Dirac Materials
by Andrii Iurov, Michael Mattis, Liubov Zhemchuzhna, Godfrey Gumbs and Danhong Huang
Appl. Sci. 2024, 14(14), 6027; https://doi.org/10.3390/app14146027 - 10 Jul 2024
Viewed by 688
Abstract
In this paper, we investigate the so-called electronic dressed states, a unified quasiparticle resulting from the interaction between electrons in a two-dimensional material with an off-resonance optical dressing field. If the frequency of this field is much larger than all characteristic energies in [...] Read more.
In this paper, we investigate the so-called electronic dressed states, a unified quasiparticle resulting from the interaction between electrons in a two-dimensional material with an off-resonance optical dressing field. If the frequency of this field is much larger than all characteristic energies in the system, such as the Fermi energy or bandgap(s), the electronic band structure is affected by radiation so that some important properties of the electron dispersions could be modified in a way desirable for practical applications. For example, circularly polarized light can be used to vary the bandgap of Dirac materials: it opens a gap in graphene and other metallic and semimetallic lattices, or it modifies the magnitude of an existing gap. This will either enhance or reduce a gap, depending on its initial value as well as properties of a host material. Here, we consider gapped dice and Lieb lattices as samples, and we put forward a full theoretical model to reveal how these electronic states are deformed by elliptically-polarized irradiation with a focus on the generation and modification of a bandgap. Full article
Show Figures

Figure 1

13 pages, 5130 KiB
Article
Characterization of Monovacancy Defects in Vanadium Diselenide Monolayer: A DFT Study
by Andrey A. Kistanov
Appl. Sci. 2024, 14(3), 1205; https://doi.org/10.3390/app14031205 - 31 Jan 2024
Viewed by 1040
Abstract
Defects are an integral part of the structure of various two-dimensional materials (2D), including 2D transition-metal dichalcogenides. These defects usually govern their electronic properties. In this work, simulations based on the density functional theory are employed for a comprehensive characterization of typical point [...] Read more.
Defects are an integral part of the structure of various two-dimensional materials (2D), including 2D transition-metal dichalcogenides. These defects usually govern their electronic properties. In this work, simulations based on the density functional theory are employed for a comprehensive characterization of typical point defects in the T–VSe2 and H–VSe2 monolayers. Specifically, Se and V monovacancy defects are studied. The formation of monovacancies in T–VSe2 and H–VSe2 monolayers are found to be less favorable than in other common transition-metal dichalcogenides. Meanwhile, Se and V monovacancy defects tune the electronic structure of the T–VSe2 and H–VSe2 monolayers significantly. The scanning tunneling microscopy simulated images obtained could facilitate the detection of monovacancies in T–VSe2 and H–VSe2 monolayers in experiments. Full article
Show Figures

Figure 1

Review

Jump to: Research

17 pages, 3930 KiB
Review
Recent Progress in Synthesis and Photonic Applications of Two-Dimensional Bismuthene
by Haoran Li and Zhibin Yang
Appl. Sci. 2023, 13(12), 6885; https://doi.org/10.3390/app13126885 - 6 Jun 2023
Cited by 3 | Viewed by 1935
Abstract
The emergence of phosphorene has generated significant interest in 2D group VA nanomaterials. Among this group, bismuthene exhibits layer-dependent direct bandgaps, high carrier mobility, and topological insulator properties because of its unique structure and ultrathin nature, distinguishing it as a promising candidate for [...] Read more.
The emergence of phosphorene has generated significant interest in 2D group VA nanomaterials. Among this group, bismuthene exhibits layer-dependent direct bandgaps, high carrier mobility, and topological insulator properties because of its unique structure and ultrathin nature, distinguishing it as a promising candidate for photonic applications. Particularly, its outstanding stability in air makes bismuthene more advantageous than phosphorene for practical applications. Here, we provide a comprehensive review of recent advances regarding 2D bismuth by focusing on the aspects of methods of synthesis and photonic applications. First, the structure and fundamental properties of bismuthene are described, referring to its crystallinity and band structures, as well as to its nonlinear optical properties. Subsequently, the common synthesis methods for 2D bismuth are summarized, including both top-down and bottom-up approaches. Then, potential photonic applications based on 2D bismuth, involving nonlinear photonic devices, photocatalyst, and photodetectors, are illustrated. The performance, mechanisms, and features of the devices are discussed. Finally, the review is summarized and some challenges and future outlooks in this field are addressed. Full article
Show Figures

Figure 1
