Chips, Volume 4, Issue 2 (June 2025) – 14 articles

  • Issues are regarded as officially published after their release is announced to the table of contents alert mailing list.
  • You may sign up for e-mail alerts to receive table of contents of newly released issues.
  • PDF is the official format for papers published in both, html and pdf forms. To view the papers in pdf format, click on the "PDF Full-text" link, and use the free Adobe Reader to open them.
Order results
Result details
Select all
Export citation of selected articles as:
15 pages, 11933 KiB
Article
Extension of Quasi-Load Insensitive Generalized Class-E Doherty Operation with Complex Load Trajectories
by Mehdi Otmani, Ayssar Serhan, Jean-Daniel Arnould, Estelle Lauga-Larroze, Pascal Reynier and Alexandre Giry
Chips 2025, 4(2), 26; https://doi.org/10.3390/chips4020026 - 13 May 2025
Viewed by 221
Abstract
This paper extends the quasi-load insensitive (QLI) Class-E Doherty power amplifier (PA) design methodology to address Doherty PA combiners with complex load impedance trajectories. Additionally, the QLI operation is analyzed for generalized class-E output matching networks with input series inductors and finite DC-feed [...] Read more.
This paper extends the quasi-load insensitive (QLI) Class-E Doherty power amplifier (PA) design methodology to address Doherty PA combiners with complex load impedance trajectories. Additionally, the QLI operation is analyzed for generalized class-E output matching networks with input series inductors and finite DC-feed inductors. We demonstrate that the QLI class-E Doherty operation can be achieved for various Doherty combiners by selecting the appropriate combination of class-E outputs matching network resonance factors and input series inductances. Moreover, a modified class-E output network is proposed to overcome the frequency limitation that might be caused by the class-E network resonance factor choice. To validate the proposed methodology, two 40 W Doherty PAs are designed and simulated using commercial GaN HEMT transistors achieving more than 70% efficiency over a 6 dB output power back-off at 3.8 GHz. Full article
(This article belongs to the Special Issue New Research in Microelectronics and Electronics)
Show Figures

Figure 1

14 pages, 434 KiB
Article
High-Speed Adaptive Waveform Generation System for Multi-Material Surface Printing
by Qiuming Luo, Yanming Lei, Kunzhong Wu and Xuan Wei
Chips 2025, 4(2), 25; https://doi.org/10.3390/chips4020025 - 12 May 2025
Viewed by 171
Abstract
This paper presents an FPGA-based configurable drive waveform generation system for industrial inkjet printheads, targeting the need for real-time adaptability in printing across heterogeneous materials. The system adopts a three-array waveform description method, enabling flexible configuration and precise generation of drive waveforms with [...] Read more.
This paper presents an FPGA-based configurable drive waveform generation system for industrial inkjet printheads, targeting the need for real-time adaptability in printing across heterogeneous materials. The system adopts a three-array waveform description method, enabling flexible configuration and precise generation of drive waveforms with adjustable geometry, segment duration, and voltage levels. Through a modular and parameterized design, the system supports rapid waveform switching during column-wise printing without interrupting the printing process, addressing the challenges posed by varying ink absorption characteristics across different substrates. Experimental results demonstrate the system’s capability to achieve smooth waveform transitions within an interval of 830 µs between columns, with data loading times as low as 4 µs. This efficient performance ensures seamless operation and high flexibility. The proposed approach significantly reduces the hardware cost and improves printing efficiency, offering a scalable and robust solution for next-generation industrial inkjet applications involving complex and dynamic material surfaces. Full article
(This article belongs to the Special Issue New Research in Microelectronics and Electronics)
Show Figures

Figure 1

12 pages, 345 KiB
Article
NeuroAdaptiveNet: A Reconfigurable FPGA-Based Neural Network System with Dynamic Model Selection
by Achraf El Bouazzaoui, Omar Mouhib and Abdelkader Hadjoudja
Chips 2025, 4(2), 24; https://doi.org/10.3390/chips4020024 - 8 May 2025
Viewed by 195
Abstract
This paper presents NeuroAdaptiveNet, an FPGA-based neural network framework that dynamically self-adjusts its architectural configurations in real time to maximize performance across diverse datasets. The core innovation is a Dynamic Classifier Selection mechanism, which harnesses the k-Nearest Centroid algorithm to identify the most [...] Read more.
This paper presents NeuroAdaptiveNet, an FPGA-based neural network framework that dynamically self-adjusts its architectural configurations in real time to maximize performance across diverse datasets. The core innovation is a Dynamic Classifier Selection mechanism, which harnesses the k-Nearest Centroid algorithm to identify the most competent neural network model for each incoming data sample. By adaptively selecting the most suitable model configuration, NeuroAdaptiveNet achieves significantly improved classification accuracy and optimized resource usage compared to conventional, statically configured neural networks. Experimental results on four datasets demonstrate that NeuroAdaptiveNet can reduce FPGA resource utilization by as much as 52.85%, increase classification accuracy by 4.31%, and lower power consumption by up to 24.5%. These gains illustrate the clear advantage of real-time, per-input reconfiguration over static designs. These advantages are particularly crucial for edge computing and embedded applications, where computational constraints and energy efficiency are paramount. The ability of NeuroAdaptiveNet to tailor its neural network parameters and architecture on a per-input basis paves the way for more efficient and accurate AI solutions in resource-constrained environments. Full article
Show Figures

Figure 1

19 pages, 6692 KiB
Article
Design and Hardware Implementation of a Highly Flexible PRNG System for NIST-Validated Pseudorandom Sequences
by María de Lourdes Rivas Becerra, Juan José Raygoza Panduro, Edwin Christian Becerra Alvarez, Susana Ortega Cisneros and José Luis González Vidal
Chips 2025, 4(2), 23; https://doi.org/10.3390/chips4020023 - 7 May 2025
Viewed by 110
Abstract
This work presents the design of a system of a highly flexible pseudorandom number generator system (PRNG) incorporating both conventional and neuro-generators. The system integrates four internal generators with different conditions to produce new output sequences with adequate bits distribution and complexity. Two [...] Read more.
This work presents the design of a system of a highly flexible pseudorandom number generator system (PRNG) incorporating both conventional and neuro-generators. The system integrates four internal generators with different conditions to produce new output sequences with adequate bits distribution and complexity. Two generators function at a frequency of 100 MHz with adjustable frequency settings, while two neuro-generators employ impulse neurons with distinct behaviours at 4 kHz, also modifiable. The proposed system meets 12 statistical randomness standards based on NIST’s (National Institute of Standards and Technology of U. S.) test suite, including the Frequency test, Binary Matrix Rank test, Linear Complexity test, and Random Excursion test, among others. Each resulted in a P-value greater than 0.01, confirming the pseudo-randomness of the generated sequences. The system is implemented on a reconfigurable device FPGA (Field Programmable Gate Array), with a low occupancy percentage, demonstrating its feasibility for various applications. Full article
Show Figures

Figure 1

16 pages, 10956 KiB
Article
A Novel Reconfigurable Gate-Biasing Technique for Extending Dynamic Range in CMOS RF-DC Rectifiers Targeting RFEH Applications
by Yi Joe Low, Yi Chen Lee, Wen Xun Lian and Harikrishnan Ramiah
Chips 2025, 4(2), 22; https://doi.org/10.3390/chips4020022 - 6 May 2025
Viewed by 231
Abstract
This paper presents a novel fully integrated radio frequency (RF) rectifier tailored for a wide power dynamic range (PDR) with multiband adaptability to efficiently convert AC RF power into DC power. The proposed rectifier utilizes the strength of interstage gate biasing to achieve [...] Read more.
This paper presents a novel fully integrated radio frequency (RF) rectifier tailored for a wide power dynamic range (PDR) with multiband adaptability to efficiently convert AC RF power into DC power. The proposed rectifier utilizes the strength of interstage gate biasing to achieve high power conversion efficiency (PCE) across a broad range of input power levels. Through its reconfigurable mode, the circuit seamlessly transitions between a low-power path and high-power path to ensure optimal performance across a wide PDR. Simulated using CMOS 65 nm technology, the post-layout assessment reveals a peak PCE of 48.8% at 900 MHz and 46.4% at 1800 MHz, with an extensive PDR of 20 dB for PCE exceeding 20% at both frequencies. Full article
Show Figures

Figure 1

14 pages, 6551 KiB
Article
Design Analysis of a Modified Current-Reuse Low-Power Wideband Single-Ended CMOS LNA
by Farshad Shirani Bidabadi, Mahalingam Nagarajan, Thangarasu Bharatha Kumar and Yeo Kiat Seng
Chips 2025, 4(2), 21; https://doi.org/10.3390/chips4020021 - 6 May 2025
Viewed by 213
Abstract
This paper presents the design analysis of a low-power wideband single-ended CMOS low-noise amplifier (LNA). The proposed topology is based on a modified current- reuse circuit, in which two-stage common-source (CS) amplifiers consume the same DC current and are isolated from each other [...] Read more.
This paper presents the design analysis of a low-power wideband single-ended CMOS low-noise amplifier (LNA). The proposed topology is based on a modified current- reuse circuit, in which two-stage common-source (CS) amplifiers consume the same DC current and are isolated from each other by large MIMCAPs, which results in good performance with low power consumption. The proposed circuit achieves a bandwidth of 2.5 GHz, suitable for several wireless communication standards such as GSM, WLAN, and Bluetooth. In the first stage, a current-reuse circuit with shunt feedback is used to satisfy input impedance matching and signal amplification with minimal noise injection. A common source (CS) with a source follower circuit forms the second stage to improve the noise figure (NF), harmonic distortion, and output impedance matching. The proposed LNA is designed in 65 nm CMOS technology and covers a frequency range of 0.17–2.68 GHz. The proposed LNA achieves a maximum gain of 17.24 dB, a minimum NF of 2.67 dB, a maximum IIP3 of −14.9 dBm, and input and output return losses of less than −10 dB. The power consumption of the proposed LNA is 3.52 mW from a 1 V power supply, and the core area is 0.3 mm2. Full article
(This article belongs to the Special Issue IC Design Techniques for Power/Energy-Constrained Applications)
Show Figures

Figure 1

15 pages, 12762 KiB
Review
Advanced Doherty Power Amplifier Architectures for 5G Handset Applications: A Comprehensive Review of Linearity, Back-Off Efficiency, Bandwidth, and Thermal Management
by Shihai He and Huan Chen
Chips 2025, 4(2), 20; https://doi.org/10.3390/chips4020020 - 6 May 2025
Viewed by 342
Abstract
This paper presents a comprehensive review of GaAs HBT-based Doherty power amplifiers (DPAs) targeting 5G New Radio (NR) handset applications. Focusing on the critical challenges of linearity enhancement, back-off efficiency improvement, bandwidth extension under low-voltage (3.4 V) operation, and chip thermal management, the [...] Read more.
This paper presents a comprehensive review of GaAs HBT-based Doherty power amplifiers (DPAs) targeting 5G New Radio (NR) handset applications. Focusing on the critical challenges of linearity enhancement, back-off efficiency improvement, bandwidth extension under low-voltage (3.4 V) operation, and chip thermal management, the authors analyze state-of-the-art DPAs published in recent years. Key innovations including dynamic power division technique, third order intermodulation (IM3) cancellation technology, and compact output combiners are comparatively studied. Using 5G NR signals, the critical performance of the latest reported PA such as maximum linear power, back-off efficiency, bandwidth, and operating voltage are quantitatively investigated. The measurement results demonstrated that the best performance in recent DPAs achieved high linear power of 31 dBm with 34% PAE and 30 dBm with 31% PAE at the N78 and N77 bands, respectively. The corresponding adjacent channel leakage ratios (ACLRs) were lower than −36.5 dBc without digital pre-distortion (DPD). This review provides a comprehensive understanding of the latest advancements and future directions in highly efficient and linear DPA designs for 5G handset front-end modules. Full article
(This article belongs to the Special Issue IC Design Techniques for Power/Energy-Constrained Applications)
Show Figures

Figure 1

30 pages, 2809 KiB
Review
A Survey on Computing-in-Memory (CiM) and Emerging Nonvolatile Memory (NVM) Simulators
by John Taylor Maurer, Ahmed Mamdouh Mohamed Ahmed, Parsa Khorrami, Sabrina Hassan Moon and Dayane Alfenas Reis
Chips 2025, 4(2), 19; https://doi.org/10.3390/chips4020019 - 3 May 2025
Viewed by 278
Abstract
Modern computer applications have become highly data-intensive, giving rise to an increase in data traffic between the processor and memory units. Computing-in-Memory (CiM) has shown great promise as a solution to this aptly named von Neumann bottleneck problem by enabling computation within the [...] Read more.
Modern computer applications have become highly data-intensive, giving rise to an increase in data traffic between the processor and memory units. Computing-in-Memory (CiM) has shown great promise as a solution to this aptly named von Neumann bottleneck problem by enabling computation within the memory unit and thus reducing data traffic. Many simulation tools in the literature have been proposed to enable the design space exploration (DSE) of these novel computer architectures as researchers are in need of these tools to test their designs prior to fabrication. This paper presents a collection of classical nonvolatile memory (NVM) and CiM simulation tools to showcase their capabilities, as presented in their respective analyses. We provide an in-depth overview of DSE, emerging NVM device technologies, and popular CiM architectures. We organize the simulation tools by design-level scopes with respect to their focus on the devices, circuits, architectures, systems/algorithms, and applications they support. We conclude this work by identifying the gaps within the simulation space. Full article
(This article belongs to the Special Issue Magnetoresistive Random-Access Memory (MRAM): Present and Future)
Show Figures

Figure 1

30 pages, 8304 KiB
Article
Design of a Linear Floating Active Resistor with Low Temperature Coefficient
by Yu Liu and Pak Kwong Chan
Chips 2025, 4(2), 18; https://doi.org/10.3390/chips4020018 - 14 Apr 2025
Viewed by 278
Abstract
This paper presents the design and implementation of a linear, stable, low-power and PVT insensitive floating active resistor, which is realized using TSMC 40 nm CMOS process technology. By incorporating the automatic tuning circuit, this work has achieved improved performance metrics, which include [...] Read more.
This paper presents the design and implementation of a linear, stable, low-power and PVT insensitive floating active resistor, which is realized using TSMC 40 nm CMOS process technology. By incorporating the automatic tuning circuit, this work has achieved improved performance metrics, which include low process sensitivity, reduced temperature coefficient, and good linearity. Monte Carlo (MC) simulations are conducted to evaluate the active resistor’s performance under variations in temperature, process, and supply voltage. The proposed design has demonstrated an average resistance process sensitivity of 0.64%, a temperature coefficient (T.C.) of 57 ppm/°C across −25 °C to 85 °C, and a linearity figure of merit (FOM) of 2.4 × 10−2 V−1 with a resistance close to MΩ level. It can achieve a linear resistance tuning range of 430.5 kΩ to 1.714 MΩ. The typical power consumption of a single active resistor is 0.25 µW at 2.1 V bootstrapped supply voltage through a Dickson charge pump (DCP) circuit using a DC input of 1 V. These results have confirmed that the proposed active resistor can function as a robust and efficient resistor for low-voltage integrated circuits and systems. Full article
(This article belongs to the Special Issue IC Design Techniques for Power/Energy-Constrained Applications)
Show Figures

Figure 1

22 pages, 3837 KiB
Article
TDM Test Scheduler and TAM Optimization Toolkit: An Integrated Framework for Test Processes of DVFS-Based SoCs with Multiple Voltage Islands
by Fotios Vartziotis
Chips 2025, 4(2), 17; https://doi.org/10.3390/chips4020017 - 11 Apr 2025
Viewed by 175
Abstract
The TDM Test Scheduler and TAM Optimization Toolkit is a novel, integrated, and user-friendly solution designed for engineers, researchers, and instructors working in the field of manufacturing tests. It effectively supports test planning for multicore, DVFS-based SoCs with multiple voltage islands, offering optimized [...] Read more.
The TDM Test Scheduler and TAM Optimization Toolkit is a novel, integrated, and user-friendly solution designed for engineers, researchers, and instructors working in the field of manufacturing tests. It effectively supports test planning for multicore, DVFS-based SoCs with multiple voltage islands, offering optimized solutions that minimize test costs while ensuring compliance with power and thermal constraints. The toolkit provides (a) a high-level language (HLL) for the intuitive representation of test processes, along with a smart syntax and logic checker for verification; (b) an advanced compilation and execution environment featuring two computationally efficient Time-Division Multiplexing (TDM)-specialized solvers; (c) a sophisticated Test Access Mechanism (TAM) optimization framework; (d) a customized visualization environment capable of depicting and animating power- and thermal-annotated test schedules; (e) a versatile testbed for educational and research activities. Full article
Show Figures

Figure 1

11 pages, 2173 KiB
Article
Optical Frequency Comb-Based 256-QAM WDM Coherent System with Digital Signal Processing Algorithm
by Babar Ali, Ghulam Murtaza, Hafiz Muhammad Bilal, Tariq Mahmood, Muhammad Rashid and Zaib Ullah
Chips 2025, 4(2), 16; https://doi.org/10.3390/chips4020016 - 10 Apr 2025
Viewed by 310
Abstract
This work presents a cost-effective optical frequency comb generator (CEOFCG) solution for generating multiple, equally spaced carriers in wavelength-division-multiplexing coherent optical fiber communication systems (WDM-COFCS). It enables the replacement of multiple laser sources with a single continuous-wave laser, eliminating the need for additional [...] Read more.
This work presents a cost-effective optical frequency comb generator (CEOFCG) solution for generating multiple, equally spaced carriers in wavelength-division-multiplexing coherent optical fiber communication systems (WDM-COFCS). It enables the replacement of multiple laser sources with a single continuous-wave laser, eliminating the need for additional amplification and filtering setups. The CEOFCG provides stable multicarrier spacing, broad phase coherence, and compatibility with advanced modulation formats, enhancing the performance of WDM-COFCS. Digital signal processing (DSP) techniques, including digital filtering, detection, and impairment compensation, contribute to high transmission and spectral efficiency (SE). The results demonstrate the potential of CEOFCG in achieving cost reduction, complexity reduction, high SE, and optimal utilization of optical fiber bandwidth, particularly in higher-order QAM-based COFCS. Full article
Show Figures

Figure 1

29 pages, 3607 KiB
Article
The Quest for Efficient ASCON Implementations: A Comprehensive Review of Implementation Strategies and Challenges
by Mattia Mirigaldi, Valeria Piscopo, Maurizio Martina and Guido Masera
Chips 2025, 4(2), 15; https://doi.org/10.3390/chips4020015 - 7 Apr 2025
Viewed by 570
Abstract
The rapid growth of the Internet of Things (IoT) has significantly expanded the deployment of resource-constrained devices, introducing new security and privacy challenges. To address these concerns, the National Institute of Standards and Technology (NIST) concluded a multi-year effort by announcing ASCON as [...] Read more.
The rapid growth of the Internet of Things (IoT) has significantly expanded the deployment of resource-constrained devices, introducing new security and privacy challenges. To address these concerns, the National Institute of Standards and Technology (NIST) concluded a multi-year effort by announcing ASCON as the new lightweight cryptography standard in 2023. ASCON’s cipher suite includes both Authenticated Encryption with Associated Data (AEAD) and hashing functions, ensuring authenticity, confidentiality, and broad applicability. Since its standardization, there has been a significant research effort focused on enhancing ASCON’s performance under diverse application constraints as well as assessing its vulnerability to advanced side-channel attacks. This study offers a comprehensive overview of current ASCON hardware implementations on FPGA and ASIC platforms, examining key design trade-offs. Additionally, it examines the latest side-channel attacks on ASCON were examined. These attacks exploited weaknesses in the hardware implementations rather than in the algorithm itself. Being highly efficient, they could breach both unprotected and protected implementations. This survey also reviews the proposed countermeasures against these powerful attacks and analyzes how their associated overhead conflicts with the performance demands of real-world ASCON applications. The synthesis of these findings offers clear guidelines for designers seeking to implement ASCON. At the same time, areas requiring further investigation are identified. As ASCON sees ever more widespread deployment, this review serves as a reference for understanding the current state of research and guiding future developments toward efficient and secure implementations. Full article
Show Figures

Figure 1

18 pages, 481 KiB
Article
Adaptive and Passage-Based Fault-Tolerant Routing Methods for Three-Dimensional Mesh NoCs
by Yota Kurokawa and Masaru Fukushi
Chips 2025, 4(2), 14; https://doi.org/10.3390/chips4020014 - 6 Apr 2025
Viewed by 226
Abstract
This paper proposes novel two fault-tolerant routing methods for a 3D mesh network-on-chip (NoC). The existing method proposed by Boppana et al. combines two routing methods, minimal fully adaptive routing and fault-tolerant routing, for faulty region detouring. However, in the latter fault-tolerant routing, [...] Read more.
This paper proposes novel two fault-tolerant routing methods for a 3D mesh network-on-chip (NoC). The existing method proposed by Boppana et al. combines two routing methods, minimal fully adaptive routing and fault-tolerant routing, for faulty region detouring. However, in the latter fault-tolerant routing, a detour direction is statically defined for each faulty region. Due to the long detour path and the use of eight virtual channels, this method has the problems of high communication latency and a large hardware overhead. To solve these problems, the first proposed method allows adaptive detours for faulty regions, and the second proposed method allows the passage of them. The simulation results show that, compared with the existing method, the second proposed method enables us to reduce the latency by about 30% and improve the throughput by about 3.1% with half of the virtual channels. Full article
(This article belongs to the Topic Theory and Applications of High Performance Computing)
Show Figures

Figure 1

16 pages, 1318 KiB
Article
Optimised Extension of an Ultra-Low-Power RISC-V Processor to Support Lightweight Neural Network Models
by Qiankun Liu and Sam Amiri
Chips 2025, 4(2), 13; https://doi.org/10.3390/chips4020013 - 3 Apr 2025
Viewed by 543
Abstract
With the increasing demand for efficient deep learning models in resource-constrained environments, Binary Neural Networks (BNNs) have emerged as a promising solution due to their ability to significantly reduce computational complexity while maintaining accuracy. Their integration into embedded and edge computing systems is [...] Read more.
With the increasing demand for efficient deep learning models in resource-constrained environments, Binary Neural Networks (BNNs) have emerged as a promising solution due to their ability to significantly reduce computational complexity while maintaining accuracy. Their integration into embedded and edge computing systems is essential for enabling real-time AI applications in areas such as autonomous systems, industrial automation, and intelligent security. Deploying BNN on FPGA using RISC-V, rather than directly deploying the model on FPGA, sacrifices detection speed but, in general, reduces power consumption and on-chip resource usage. The AI-extended RISC-V core is capable of handling tasks beyond BNN inference, providing greater flexibility. This work utilises the lightweight Zero-Riscy core to deploy a BNN on FPGA. Three custom instructions are proposed for convolution, pooling, and fully connected layers, integrating XNOR, POPCOUNT, and threshold operations. This reduces the number of instructions required per task, thereby decreasing the frequency of interactions between Zero-Riscy and the instruction memory. The proposed solution is evaluated on two case studies: MNIST dataset classification and an intrusion detection system (IDS) for in-vehicle networks. The results show that for MNIST inference, the hardware resources required are only 9% of those used by state-of-the-art solutions, though with a slight reduction in speed. For IDS-based inference, power consumption is reduced to just 13% of the original, while resource usage is only 20% of the original. Although some speed is sacrificed, the system still meets real-time monitoring requirements. Full article
(This article belongs to the Special Issue IC Design Techniques for Power/Energy-Constrained Applications)
Show Figures

Figure 1
