Background: Electrocardiogram (ECG) signals are crucial for cardiovascular diagnosis, but their analysis face challenges from noise contamination, compression difficulties due to their non-stationary nature, and the inherent complexity of its morphological components, particularly for low-amplitude P- and T-waves obscured by noise. Methodology: This study proposes a novel, multi-stage framework for ECG signal denoising, compressing, and component decomposition. The proposed framework leverages the sparsity of ECG signal to denoise and compress these signals using autoencoder-driven dictionary (AE-DD) with matching pursuit. In this work, a data-driven dictionary was developed using a regularized autoencoder. Appropriate trained weights along with matching pursuit were used to compress the denoised ECG segments. This study explored different weight regularization techniques: L1- and L2-regularization. Results: The proposed framework achieves remarkable performance in simultaneous ECG denoising, compression, and morphological decomposition. The L1-DAE model delivers superior noise suppression (SNR improvement up to 18.6 dB at
dB input SNR) and near-lossless reconstruction (
). The L1-AE dictionary enables high-fidelity compression (CR = 28:1 ratio,
, PRD = 2.1%), outperforming non-regularized models and traditional dictionaries (DCT/wavelets), while its trained weights naturally decompose into interpretable sub-dictionaries for P-wave, QRS complex, and T-wave enabling precise, label-free analysis of ECG components. Moreover, the learned sub-dictionaries naturally decompose into interpretable P-wave, QRS complex, and T-wave components with high accuracy, yielding strong correlation with the original ECG (
,
, and
, respectively) and very low MSE (
,
, and
, respectively). Conclusions: This study introduces a novel autoencoder-driven framework that simultaneously performs ECG denoising, compression, and morphological decomposition. By leveraging L1-regularized autoencoders with matching pursuit, the method effectively enhances signal quality while enabling direct decomposition of ECG signals into clinically relevant components without additional processing. This unified approach offers significant potential for improving automated ECG analysis and facilitating efficient long-term cardiac monitoring.
