Article

Optimization Procedure for Computing Sampling Time for Induction Machine Parameter Estimation

Faculty of Electrical Engineering, Computer Science and Information Technology Osijek, J.J.Strossmayer University Osijek, Trpimirova 2B, 3100 Osijek, Croatia
*
Author to whom correspondence should be addressed.
Appl. Sci. 2020, 10(9), 3222; https://doi.org/10.3390/app10093222
Received: 26 March 2020 / Revised: 27 April 2020 / Accepted: 28 April 2020 / Published: 6 May 2020
(This article belongs to the Special Issue Modeling, Design and Control of Electric Machines)
This paper presents a method for selecting the sampling time for induction machine parameter estimation from the machine line start measurements. the metaheuristic optimization method is used to find the optimal Prony exponential series approxiamtion of the line start transient current. From the optimal approximation, poles of the linearized induction machine model are computed and used to determine the optimal sampling time. the results show that sampling frequencies needed for parameter estimation are much lower than 1–15 kHz commonly used today. This reduces the necessary amount of collected data and the computing power needed for the estimation. the optimal sampling time is computed for the simulated and for the measured data. Referenced parameter estimation technique is tested for the measured transient showing benefits of using the optimal sampling time. View Full-Text
Keywords: induction machine; parameter estimation; optimal sampling time; prony series induction machine; parameter estimation; optimal sampling time; prony series
Show Figures

Figure 1
