Micromachines, Volume 12, Issue 6 (June 2021) – 142 articles

Cover Story (view full-size image): Resonant micro/nanoelectromechanical systems (MEMS/NEMS) with on-chip integrated excitation and readout components and exquisite gravimetric sensitivities have significantly advanced bio/chemical sensor technologies in the past two decades. Great effort has been made to tackle the challenges of operating resonant mass sensors in viscous media, and, as such, rapid detection of various trace analytes in gas and liquid phases, such as hazardous chemical vapors, pollutant gases, and biological species, has been achieved, which impacts public security, food safety, environmental monitoring, and human healthcare. View this paper
  • Issues are regarded as officially published after their release is announced to the table of contents alert mailing list.
  • You may sign up for e-mail alerts to receive table of contents of newly released issues.
  • PDF is the official format for papers published in both, html and pdf forms. To view the papers in pdf format, click on the "PDF Full-text" link, and use the free Adobe Reader to open them.
Order results
Result details
Section
Select all
Export citation of selected articles as:
22 pages, 7539 KiB
Article
Development of a Novel 2-DOF Rotary–Linear Piezoelectric Actuator Operating under Hybrid Bending–Radial Vibration Mode
by Andrius Čeponis, Dalius Mažeika and Daiva Makutėnienė
Micromachines 2021, 12(6), 728; https://doi.org/10.3390/mi12060728 - 21 Jun 2021
Cited by 5 | Viewed by 2424
Abstract
The paper presents a numerical and experimental investigation of a novel two degrees of freedom (2-DOF) piezoelectric actuator that can generate rotary motion of the sphere-shaped rotor as well as induce planar motion of the flat stage. The actuator has a small size [...] Read more.
The paper presents a numerical and experimental investigation of a novel two degrees of freedom (2-DOF) piezoelectric actuator that can generate rotary motion of the sphere-shaped rotor as well as induce planar motion of the flat stage. The actuator has a small size and simple design and can be integrated into a printed circuit board (PCB). The application field of the actuator is small-dimensional and high-precision positioning systems. The piezoelectric actuator comprises three rectangular bimorph plates joined with arcs and arranged by an angle of 120 degrees. A high-stiffness rod is glued on the top surface of each bimorph plate and is used to rotate the rotor or move flat stage employing contact friction force. Three U-shaped structures are used for the actuator clamping. 2-DOF rotational or planar movement is obtained by applying a harmonic or asymmetric electrical signal. The operation principle of the actuator is based on the superposition of the B20 out-of-plane bending mode of the bimorph plates and the B03 radial vibration mode of the ring. Design optimization has been performed to maximize amplitudes of contact point vibration. A prototype of the actuator was made, and a maximum rotation speed of 795.15 RPM was achieved while preload of 546.03 mN was applied. The linear velocity of 36.45 mm/s was obtained at the same preload force. Resolution measurement showed that the actuator can achieve an angular resolution of 17.48 µrad and a linear resolution of 2.75 µm. Full article
Show Figures

Figure 1

9 pages, 3229 KiB
Article
Microfluidics Integration into Low-Noise Multi-Electrode Arrays
by Mafalda Ribeiro, Pamela Ali, Benjamin Metcalfe, Despina Moschou and Paulo R. F. Rocha
Micromachines 2021, 12(6), 727; https://doi.org/10.3390/mi12060727 - 20 Jun 2021
Cited by 5 | Viewed by 3316
Abstract
Organ-on-Chip technology is commonly used as a tool to replace animal testing in drug development. Cells or tissues are cultured on a microchip to replicate organ-level functions, where measurements of the electrical activity can be taken to understand how the cell populations react [...] Read more.
Organ-on-Chip technology is commonly used as a tool to replace animal testing in drug development. Cells or tissues are cultured on a microchip to replicate organ-level functions, where measurements of the electrical activity can be taken to understand how the cell populations react to different drugs. Microfluidic structures are integrated in these devices to replicate more closely an in vivo microenvironment. Research has provided proof of principle that more accurate replications of the microenvironment result in better micro-physiological behaviour, which in turn results in a higher predictive power. This work shows a transition from a no-flow (static) multi-electrode array (MEA) to a continuous-flow (dynamic) MEA, assuring a continuous and homogeneous transfer of an electrolyte solution across the measurement chamber. The process through which the microfluidic system was designed, simulated, and fabricated is described, and electrical characterisation of the whole structure under static solution and a continuous flow rate of 80 µL/min was performed. The latter reveals minimal background disturbance, with a background noise below 30 µVpp for all flow rates and areas. This microfluidic MEA, therefore, opens new avenues for more accurate and long-term recordings in Organ-on-Chip systems. Full article
(This article belongs to the Special Issue Lab-on-PCB Devices)
Show Figures

Figure 1

20 pages, 3805 KiB
Article
Microrheometer for Biofluidic Analysis: Electronic Detection of the Fluid-Front Advancement
by Lourdes Méndez-Mora, Maria Cabello-Fusarés, Josep Ferré-Torres, Carla Riera-Llobet, Samantha Lopez, Claudia Trejo-Soto, Tomas Alarcón and Aurora Hernandez-Machado
Micromachines 2021, 12(6), 726; https://doi.org/10.3390/mi12060726 - 20 Jun 2021
Cited by 9 | Viewed by 3174
Abstract
The motivation for this study was to develop a microdevice for the precise rheological characterization of biofluids, especially blood. The method presented was based on the principles of rheometry and fluid mechanics at the microscale. Traditional rheometers require a considerable amount of space, [...] Read more.
The motivation for this study was to develop a microdevice for the precise rheological characterization of biofluids, especially blood. The method presented was based on the principles of rheometry and fluid mechanics at the microscale. Traditional rheometers require a considerable amount of space, are expensive, and require a large volume of sample. A mathematical model was developed that, combined with a proper experimental model, allowed us to characterize the viscosity of Newtonian and non-Newtonian fluids at different shear rates. The technology presented here is the basis of a point-of-care device capable of describing the nonlinear rheology of biofluids by the fluid/air interface front velocity characterization through a microchannel. The proposed microrheometer uses a small amount of sample to deliver fast and accurate results, without needing a large laboratory space. Blood samples from healthy donors at distinct hematocrit percentages were the non-Newtonian fluid selected for the study. Water and plasma were employed as testing Newtonian fluids for validation of the system. The viscosity results obtained for the Newtonian and non-Newtonian fluids were consistent with pertinent studies cited in this paper. In addition, the results achieved using the proposed method allowed distinguishing between blood samples with different characteristics. Full article
(This article belongs to the Section A:Physics)
Show Figures

Graphical abstract

10 pages, 4246 KiB
Article
Implantable Optrode Array for Optogenetic Modulation and Electrical Neural Recording
by Saeyeong Jeon, Youjin Lee, Daeho Ryu, Yoon Kyung Cho, Yena Lee, Sang Beom Jun and Chang-Hyeon Ji
Micromachines 2021, 12(6), 725; https://doi.org/10.3390/mi12060725 - 19 Jun 2021
Cited by 6 | Viewed by 3192
Abstract
During the last decade, optogenetics has become an essential tool for neuroscience research due to its unrivaled feature of cell-type-specific neuromodulation. There have been several technological advances in light delivery devices. Among them, the combination of optogenetics and electrophysiology provides an opportunity for [...] Read more.
During the last decade, optogenetics has become an essential tool for neuroscience research due to its unrivaled feature of cell-type-specific neuromodulation. There have been several technological advances in light delivery devices. Among them, the combination of optogenetics and electrophysiology provides an opportunity for facilitating optogenetic approaches. In this study, a novel design of an optrode array was proposed for realizing optical modulation and electrophysiological recording. A 4 × 4 optrode array and five-channel recording electrodes were assembled as a disposable part, while a reusable part comprised an LED (light-emitting diode) source and a power line. After the characterization of the intensity of the light delivered at the fiber tips, in vivo animal experiment was performed with transgenic mice expressing channelrhodopsin, showing the effectiveness of optical activation and neural recording. Full article
(This article belongs to the Special Issue Implantable Neural Interfaces)
Show Figures

Figure 1

29 pages, 3950 KiB
Review
The Recent Progress of MEMS/NEMS Resonators
by Lei Wei, Xuebao Kuai, Yidi Bao, Jiangtao Wei, Liangliang Yang, Peishuai Song, Mingliang Zhang, Fuhua Yang and Xiaodong Wang
Micromachines 2021, 12(6), 724; https://doi.org/10.3390/mi12060724 - 19 Jun 2021
Cited by 44 | Viewed by 8828
Abstract
MEMS/NEMS resonators are widely studied in biological detection, physical sensing, and quantum coupling. This paper reviews the latest research progress of MEMS/NEMS resonators with different structures. The resonance performance, new test method, and manufacturing process of single or double-clamped resonators, and their applications [...] Read more.
MEMS/NEMS resonators are widely studied in biological detection, physical sensing, and quantum coupling. This paper reviews the latest research progress of MEMS/NEMS resonators with different structures. The resonance performance, new test method, and manufacturing process of single or double-clamped resonators, and their applications in mass sensing, micromechanical thermal analysis, quantum detection, and oscillators are introduced in detail. The material properties, resonance mode, and application in different fields such as gyroscope of the hemispherical structure, microdisk structure, drum resonator are reviewed. Furthermore, the working principles and sensing methods of the surface acoustic wave and bulk acoustic wave resonators and their new applications such as humidity sensing and fast spin control are discussed. The structure and resonance performance of tuning forks are summarized. This article aims to classify resonators according to different structures and summarize the working principles, resonance performance, and applications. Full article
Show Figures

Figure 1

13 pages, 3283 KiB
Article
Fabrication of Multi-Layered Microspheres Based on Phase Separation for Drug Delivery
by He Xia, Ang Li, Jia Man, Jianyong Li and Jianfeng Li
Micromachines 2021, 12(6), 723; https://doi.org/10.3390/mi12060723 - 19 Jun 2021
Cited by 8 | Viewed by 3783
Abstract
In this work, we used a co-flow microfluidic device with an injection and a collection tube to generate droplets with different layers due to phase separation. The phase separation system consisted of poly(ethylene glycol) diacrylate 700 (PEGDA 700), PEGDA 250, and sodium alginate [...] Read more.
In this work, we used a co-flow microfluidic device with an injection and a collection tube to generate droplets with different layers due to phase separation. The phase separation system consisted of poly(ethylene glycol) diacrylate 700 (PEGDA 700), PEGDA 250, and sodium alginate aqueous solution. When the mixture droplets formed in the outer phase, PEGDA 700 in the droplets would transfer into the outer aqueous solution, while PEGDA 250 still stayed in the initial droplet, breaking the miscibility equilibrium of the mixture and triggering the phase separation. As the phase separation proceeded, new cores emerged in the droplets, gradually forming the second and third layers. Emulsion droplets with different layers were polymerized under ultraviolet (UV) irradiation at different stages of phase separation to obtain microspheres. Microspheres with different layers showed various release behaviors in simulated gastric fluid (SGF) and simulated intestinal fluid (SIF). The release rate decreased with the increase in the number of layers, which showed a potential application in sustained drug release. Full article
(This article belongs to the Special Issue Droplet-Based Microfluidic Devices)
Show Figures

Figure 1

8 pages, 3711 KiB
Article
Amplitude Control Method of Magnetic Flux Vertical Modulation Structure for TMR Magnetic Sensor Based on Harmonic Component of Modulated Signal
by Junsheng Zhang, Mengchun Pan, Qingfa Du, Jiafei Hu, Kun Sun, Yang Yu, Xinmiao Zhang and Huihui Luo
Micromachines 2021, 12(6), 722; https://doi.org/10.3390/mi12060722 - 19 Jun 2021
Cited by 2 | Viewed by 2070
Abstract
Magnetic flux vertical modulation method based on piezoelectric resonance can reduce the 1/f noise of tunnel magnetoresistance (TMR) magnetic sensor and significantly improves the low-frequency magnetic field detectivity. However, the amplitude variation of the modulation structure will lead to the instability of [...] Read more.
Magnetic flux vertical modulation method based on piezoelectric resonance can reduce the 1/f noise of tunnel magnetoresistance (TMR) magnetic sensor and significantly improves the low-frequency magnetic field detectivity. However, the amplitude variation of the modulation structure will lead to the instability of the sensor output. In order to improve the amplitude stability of the modulation structure, an amplitude control method based on the amplitude ratio of the first and second harmonic components of the modulated signal was proposed. Compared with the piezoelectric or capacitive feedback method, this method does not require an independent amplitude conversion circuit, and has the advantages of simple structure, high control efficiency and strong anti-interference ability. The experimental results showed that the amplitude and temperature drift of the modulated structure was significantly suppressed, which is of great significance for enhancing the adaptability of the TMR magnetic sensor to the application environments. Full article
Show Figures

Figure 1

11 pages, 8021 KiB
Article
Double-Quantum-Well AlGaN/GaN Field Effect Transistors with Top and Back Gates: Electrical and Noise Characteristics
by Maksym Dub, Pavlo Sai, Maciej Sakowicz, Lukasz Janicki, Dmytro B. But, Paweł Prystawko, Grzegorz Cywiński, Wojciech Knap and Sergey Rumyantsev
Micromachines 2021, 12(6), 721; https://doi.org/10.3390/mi12060721 - 19 Jun 2021
Cited by 3 | Viewed by 3058
Abstract
AlGaN/GaN fin-shaped and large-area grating gate transistors with two layers of two-dimensional electron gas and a back gate were fabricated and studied experimentally. The back gate allowed reducing the subthreshold leakage current, improving the subthreshold slope and adjusting the threshold voltage. At a [...] Read more.
AlGaN/GaN fin-shaped and large-area grating gate transistors with two layers of two-dimensional electron gas and a back gate were fabricated and studied experimentally. The back gate allowed reducing the subthreshold leakage current, improving the subthreshold slope and adjusting the threshold voltage. At a certain back gate voltage, transistors operated as normally-off devices. Grating gate transistors with a high gate area demonstrated little subthreshold leakage current, which could be further reduced by the back gate. The low frequency noise measurements indicated identical noise properties and the same trap density responsible for noise when the transistors were controlled by either top or back gates. This result was explained by the tunneling of electrons to the traps in AlGaN as the main noise mechanism. The trap density extracted from the noise measurements was similar or less than that reported in the majority of publications on regular AlGaN/GaN transistors. Full article
(This article belongs to the Special Issue GaN-Based Semiconductor Devices)
Show Figures

Figure 1

9 pages, 1768 KiB
Article
Advanced Neural Interface toward Bioelectronic Medicine Enabled by Micro-Patterned Shape Memory Polymer
by Youngjun Cho, Heejae Shin, Jaeu Park and Sanghoon Lee
Micromachines 2021, 12(6), 720; https://doi.org/10.3390/mi12060720 - 19 Jun 2021
Cited by 7 | Viewed by 3212
Abstract
Recently, methods for the treatment of chronic diseases and disorders through the modulation of peripheral and autonomic nerves have been proposed. To investigate various treatment methods and results, experiments are being conducted on animals such as rabbits and rat. However the diameter of [...] Read more.
Recently, methods for the treatment of chronic diseases and disorders through the modulation of peripheral and autonomic nerves have been proposed. To investigate various treatment methods and results, experiments are being conducted on animals such as rabbits and rat. However the diameter of the targeted nerves is small (several hundred μm) and it is difficult to modulate small nerves. Therefore, a neural interface that is stable, easy to implant into small nerves, and is biocompatible is required. Here, to develop an advanced neural interface, a thiol-ene/acrylate-based shape memory polymer (SMP) was fabricated with a double clip design. This micro-patterned design is able to be implanted on a small branch of the sciatic nerve, as well as the parasympathetic pelvic nerve, using the shape memory effect (SME) near body temperature. Additionally, the IrO2 coated neural interface was implanted on the common peroneal nerve in order to perform electrical stimulation and electroneurography (ENG) recording. The results demonstrate that the proposed neural interface can be used for the modulation of the peripheral nerve, including the autonomic nerve, towards bioelectronic medicine. Full article
(This article belongs to the Special Issue Neural (Nerve) Electrode)
Show Figures

Figure 1

27 pages, 4129 KiB
Review
Gold–Carbon Nanocomposites for Environmental Contaminant Sensing
by Shahrooz Rahmati, William Doherty, Arman Amani Babadi, Muhamad Syamim Akmal Che Mansor, Nurhidayatullaili Muhd Julkapli, Volker Hessel and Kostya (Ken) Ostrikov
Micromachines 2021, 12(6), 719; https://doi.org/10.3390/mi12060719 - 19 Jun 2021
Cited by 13 | Viewed by 3150
Abstract
The environmental crisis, due to the rapid growth of the world population and globalisation, is a serious concern of this century. Nanoscience and nanotechnology play an important role in addressing a wide range of environmental issues with innovative and successful solutions. Identification and [...] Read more.
The environmental crisis, due to the rapid growth of the world population and globalisation, is a serious concern of this century. Nanoscience and nanotechnology play an important role in addressing a wide range of environmental issues with innovative and successful solutions. Identification and control of emerging chemical contaminants have received substantial interest in recent years. As a result, there is a need for reliable and rapid analytical tools capable of performing sample analysis with high sensitivity, broad selectivity, desired stability, and minimal sample handling for the detection, degradation, and removal of hazardous contaminants. In this review, various gold–carbon nanocomposites-based sensors/biosensors that have been developed thus far are explored. The electrochemical platforms, synthesis, diverse applications, and effective monitoring of environmental pollutants are investigated comparatively. Full article
(This article belongs to the Special Issue Feature Papers of Micromachines in Engineering and Technology 2021)
Show Figures

Figure 1

8 pages, 3890 KiB
Article
Stretchable Strain Sensor with Controllable Negative Resistance Sensitivity Coefficient Based on Patterned Carbon Nanotubes/Silicone Rubber Composites
by Rong Dong and Jianbing Xie
Micromachines 2021, 12(6), 716; https://doi.org/10.3390/mi12060716 - 19 Jun 2021
Cited by 6 | Viewed by 2741
Abstract
In this paper, stretchable strain sensors with a controllable negative resistance sensitivity coefficient are firstly proposed. In order to realize the sensor with a negative resistance sensitivity coefficient, a stretchable stress sensor with sandwich structure is designed in this paper. Carbon nanotubes are [...] Read more.
In this paper, stretchable strain sensors with a controllable negative resistance sensitivity coefficient are firstly proposed. In order to realize the sensor with a negative resistance sensitivity coefficient, a stretchable stress sensor with sandwich structure is designed in this paper. Carbon nanotubes are added between two layers of silica gel. When the sensor is stretched, carbon nanotubes will be squeezed at the same time, so the sensor will show a resistance sensitivity coefficient that the resistance becomes smaller after stretching. First, nanomaterials are coated on soft elastomer, then a layer of silica gel is wrapped on the outside of the nanomaterials. In this way, similar to sandwich biscuits, a stretchable strain sensor with controllable negative resistance sensitivity coefficient has been obtained. Because the carbon nanotubes are wrapped between two layers of silica gel, when the silica gel is stretched, the carbon nanotubes will be squeezed longitudinally, which increases their density and resistance. Thus, a stretchable strain sensor with negative resistance sensitivity coefficient can be realized, and the resistivity can be controlled and adjusted from 12.7 Ω·m to 403.2 Ω·m. The sensor can be used for various tensile testing such as human motion monitoring, which can effectively expand the application range of conventional tensile strain sensor. Full article
(This article belongs to the Special Issue Smart Devices and Systems for Vibration Sensing and Energy Harvesting)
Show Figures

Figure 1

17 pages, 5293 KiB
Article
An Intelligent Combined Visual Navigation Brain Model/GPS/MEMS–INS/ADSFCF Method to Develop Vehicle Independent Guidance Solutions
by Heba G. Mohamed, Hatem A. Khater and Karim H. Moussa
Micromachines 2021, 12(6), 718; https://doi.org/10.3390/mi12060718 - 18 Jun 2021
Cited by 7 | Viewed by 2479
Abstract
This paper presents an integrated navigation system that can function more efficiently than an inertial navigation system (INS), the results of which are not precise enough because of drifts caused by accelerometers. The paper’s proposed approach depends primarily on integrating micro-electrical-mechanical system (MEMS)-INS [...] Read more.
This paper presents an integrated navigation system that can function more efficiently than an inertial navigation system (INS), the results of which are not precise enough because of drifts caused by accelerometers. The paper’s proposed approach depends primarily on integrating micro-electrical-mechanical system (MEMS)-INS smartphone integrated sensors, the Global Positioning System (GPS), and the visual navigation brain model (VNBM) to enhance navigation in bad weather conditions. The recommended integrated navigation model, using an adaptive DFS combined filter, has been well studied and tested under severe climate conditions on reference trajectories. This integrated technique can easily detect and disable less accurate reference sources (GPS or VNBM) and activate a more accurate one. According to the results, the proposed integrated data fusion algorithm offers a reliable solution for errors in the previous strategies. Furthermore, compared to the pure MEMS–INS method, the proposed system reduces navigational errors by approximately 93.76 percent, whereas the conventional centralized Kalman filter technique reduces such errors by 82.23 percent. Full article
(This article belongs to the Section E:Engineering and Technology)
Show Figures

Figure 1

14 pages, 5775 KiB
Article
Influence of Bubbles Causing Cavitation on Spool Oscillation of a Direct Drive Servovalve
by Pengda Ren, Bin Wang, Wei Zhang and Zhigang Xie
Micromachines 2021, 12(6), 717; https://doi.org/10.3390/mi12060717 - 18 Jun 2021
Cited by 4 | Viewed by 2322
Abstract
A direct drive servovalve has some inherent benefits over its conventional counterparts, but also has better reliability and output power. However, due to the rigid connection between the spool and the motor, which takes the place of interstage drive-by fluid, the spool oscillation [...] Read more.
A direct drive servovalve has some inherent benefits over its conventional counterparts, but also has better reliability and output power. However, due to the rigid connection between the spool and the motor, which takes the place of interstage drive-by fluid, the spool oscillation is a long-standing unsolved problem. In order to study the oscillation mechanism and the influencing factors, a double-circuit direct drive servovalve was numerically simulated. An oil return valve cavity was concentrated on as the main flow domain and was used to analyze the fluid flow characteristics. Local cavitation fraction and surface average cavitation fraction were defined to evaluate the cavitation situation. The periodic growth process of bubbles in the valve cavity was obtained. The numerical results show that bubbles in the oil return valve cavity changes, although the occurrence, evolution, and collapse stages were certain. The intensity of pressure pulsation caused by bubble variation is highly related to the bubbles causing the cavitation, which suggests a workable way to inhibit the spool oscillation. Full article
(This article belongs to the Special Issue Microbubble and Nanobubble Dynamics)
Show Figures

Figure 1

18 pages, 3116 KiB
Article
Experimental Validation of a Novel Generator of Gas Mixtures Based on Axial Gas Pulses Coupled to a Micromixer
by Florian Noël, Claire Trocquet, Christophe A. Serra and Stéphane Le Calvé
Micromachines 2021, 12(6), 715; https://doi.org/10.3390/mi12060715 - 18 Jun 2021
Cited by 2 | Viewed by 2198
Abstract
In this work, a novel generator of gas mixtures previously numerically investigated and based on axial gas pulses coupled to a micromixer has been conceived, manufactured, and validated. Standard gaseous pollutant mixtures and pure nitrogen or pure air were introduced in a microdevice [...] Read more.
In this work, a novel generator of gas mixtures previously numerically investigated and based on axial gas pulses coupled to a micromixer has been conceived, manufactured, and validated. Standard gaseous pollutant mixtures and pure nitrogen or pure air were introduced in a microdevice designed to generate alternating axial gas pulses which were downstream homogenized by means of a multi-stage modular micromixer. The dilution, and therefore the final pollutant concentration, was controlled by two parameters: the ratio between the times of each of the two gas pulses and the partial pressure of the pollutant(s) mixture added to the device. The gas mixture generator was coupled to an analyzer to monitor the concentration of aromatic pollutants. The response time was optimized to be lower than 2 min in accordance with the analytical instrument. The quantity of pollutants measured at the micromixer’s outlet increased linearly with the expected gas concentration of 3.7–100 ppb generated by this novel microfluidic generator and fitted perfectly with those obtained by a reference gas dilution bench. At 5 ppb, the precision on the concentration generated is close to that obtained with the conventional gas mixing bench, i.e., around 10%. Full article
(This article belongs to the Special Issue MEMS and Microfluidic Devices for Analytical Chemistry and Biosensing)
Show Figures

Figure 1

14 pages, 974 KiB
Review
A Review on Analytical Modeling for Collapse Mode Capacitive Micromachined Ultrasonic Transducer of the Collapse Voltage and the Static Membrane Deflections
by JiuJiang Wang, Xin Liu, YuanYu Yu, Yao Li, ChingHsiang Cheng, Shuang Zhang, PengUn Mak, MangI Vai and SioHang Pun
Micromachines 2021, 12(6), 714; https://doi.org/10.3390/mi12060714 - 18 Jun 2021
Cited by 7 | Viewed by 3161
Abstract
Analytical modeling of capacitive micromachined ultrasonic transducer (CMUT) is one of the commonly used modeling methods and has the advantages of intuitive understanding of the physics of CMUTs and convergent when modeling of collapse mode CMUT. This review article summarizes analytical modeling of [...] Read more.
Analytical modeling of capacitive micromachined ultrasonic transducer (CMUT) is one of the commonly used modeling methods and has the advantages of intuitive understanding of the physics of CMUTs and convergent when modeling of collapse mode CMUT. This review article summarizes analytical modeling of the collapse voltage and shows that the collapse voltage of a CMUT correlates with the effective gap height and the electrode area. There are analytical expressions for the collapse voltage. Modeling of the membrane deflections are characterized by governing equations from Timoshenko, von Kármán equations and the 2D plate equation, and solved by various methods such as Galerkin’s method and perturbation method. Analytical expressions from Timoshenko’s equation can be used for small deflections, while analytical expression from von Kármán equations can be used for both small and large deflections. Full article
(This article belongs to the Section E:Engineering and Technology)
Show Figures

Figure 1

12 pages, 3614 KiB
Article
Dual-Emission Fluorescence Probe Based on CdTe Quantum Dots and Rhodamine B for Visual Detection of Mercury and Its Logic Gate Behavior
by Yuefeng Gao, Sai Xu, Zhijian Liu, Kezhen Yu and Xinxiang Pan
Micromachines 2021, 12(6), 713; https://doi.org/10.3390/mi12060713 - 18 Jun 2021
Cited by 8 | Viewed by 2459
Abstract
It is urgent that a convenient and sensitive technique of detecting Hg2+ be developed because of its toxicity. Conventional fluorescence analysis works with a single fluorescence probe, and it often suffers from signal fluctuations which are influenced by external factors. In this [...] Read more.
It is urgent that a convenient and sensitive technique of detecting Hg2+ be developed because of its toxicity. Conventional fluorescence analysis works with a single fluorescence probe, and it often suffers from signal fluctuations which are influenced by external factors. In this research, a novel dual-emission probe assembled through utilizing CdTe quantum dots (QDs) and rhodamine B was designed to detect Hg2+ visually. Only the emission of CdTe QDs was quenched after adding Hg2+ in the dual-emission probe, which caused an intensity ratio change of the two different emission wavelengths and hence facilitated the visual detection of Hg2+. Compared to single emission QDs-based probe, a better linear relationship was shown between the variation of fluorescence intensity and the concentration of Hg2+, and the limit of detection (LOD) was found to be11.4 nM in the range of 0–2.6 μM. Interestingly, the intensity of the probe containing Hg2+ could be recovered in presence of glutathione (GSH) due to the stronger binding affinity of Hg2+ towards GSH than that towards CdTe QDs. Based on this phenomenon, an IMPLICATION logic gate using Hg2+/GSH as inputs and the fluorescence signal of QDs as an output was constructed. Full article
Show Figures

Figure 1

17 pages, 12567 KiB
Article
Experimental Study of the Deposition of Magnetic Particles on the Walls of Microchannels
by Sylvana Varela, Antonio Rivas, Anton Vernet and Jordi Pallarès
Micromachines 2021, 12(6), 712; https://doi.org/10.3390/mi12060712 - 17 Jun 2021
Cited by 2 | Viewed by 1856
Abstract
This study analyzes experimentally the deposition of magnetic beads on the walls of a square microchannel by the action of a nearby cubical magnet. The deposition has been studied for different magnetic bead sizes, flow rates, magnetic conditions and with solutions of magnetic [...] Read more.
This study analyzes experimentally the deposition of magnetic beads on the walls of a square microchannel by the action of a nearby cubical magnet. The deposition has been studied for different magnetic bead sizes, flow rates, magnetic conditions and with solutions of magnetic and non-magnetic particles. Images of the time evolution of the deposition under the different conditions have been analyzed to determine the spatial distribution of the accumulation and the growth rate of the depositions. It has been found that the way in which the magnetic beads are deposited on the walls of the microchannel depends strongly on their size and the magnetic configuration. The accumulation of the major part of particles is on the wall closest to the magnet and, depending on the size of the particles, near the magnet leading and trailing edges or near the center of the magnet. The experiments with magnetic and non-magnetic particles revealed the screening effect of the non-magnetic particles on the deposition. In this case, the non-magnetic particles displace the deposition toward the region near the center of the magnet and near the trailing edge. Full article
(This article belongs to the Special Issue Microfluids in Microchannels)
Show Figures

Figure 1

26 pages, 13128 KiB
Article
An Investigation into Accumulative Difference Mechanism in Time and Space for Material Removal in Micro-EDM Milling
by Qi Jing, Yongbin Zhang, Lingbao Kong, Min Xu and Fang Ji
Micromachines 2021, 12(6), 711; https://doi.org/10.3390/mi12060711 - 17 Jun 2021
Cited by 7 | Viewed by 2321
Abstract
In micro-electrical discharge machining (micro-EDM) milling, the cross-section of the microgroove machine is frequently not an ideal rectangle. For instance, there are arc shapes on the bottom and corners, and the sidewall is not steep. The theoretical explanation for this phenomenon is still [...] Read more.
In micro-electrical discharge machining (micro-EDM) milling, the cross-section of the microgroove machine is frequently not an ideal rectangle. For instance, there are arc shapes on the bottom and corners, and the sidewall is not steep. The theoretical explanation for this phenomenon is still lacking. In addition to the tip discharge effect, the essential reason is that there is an accumulative difference in time and space during the shape change process of a tool electrode and the microstructure formation on a workpiece. The process parameters are critical influencing factors that determine this accumulative difference. Therefore, the accumulative difference mechanism in time and space is investigated in this paper, and then a theoretical model is developed to simulate the micro-EDM milling process with a straight-line single path. The simulation results for a cylindrical electrode at the two rotational speeds of 0 (nonrotating) and 300 rpm are compared, while the results for a cylindrical electrode and a square electrode at a rotation speed of 0 are also compared to verify that different process parameters generate accumulative differences in the time and space of material removal. Finally, micro-EDM milling experiments are carried out to verify the simulation model. The maximum mean relative deviation between the microgroove profiles of simulation results and those of experiments is 11.09%, and the profile shapes of simulations and experiments have a good consistency. A comparative experiment between a cylindrical electrode and a hollow electrode is also performed, which further verifies the mechanism revealed in the study. Furthermore, the cross-section profile of a microgroove can be effectively controlled by adjusting the process parameters when utilising these accumulative differences through fabricating a microgroove with a V-shaped cross-section by a square electrode and a microgroove with a semi-circular cross-section by a cylindrical electrode. This research provides theoretical guidance for solving the problems of the machining accuracy of detail features in micro-EDM milling, for instance, to machine a microgroove with an ideal rectangular cross-section. Full article
Show Figures

Figure 1

15 pages, 6705 KiB
Article
Medical Applications of Diode Lasers: Pulsed versus Continuous Wave (cw) Regime
by Michał Michalik, Jacek Szymańczyk, Michał Stajnke, Tomasz Ochrymiuk and Adam Cenian
Micromachines 2021, 12(6), 710; https://doi.org/10.3390/mi12060710 - 17 Jun 2021
Cited by 17 | Viewed by 4378
Abstract
The paper deals with the medical application of diode-lasers. A short review of medical therapies is presented, taking into account the wavelength applied, continuous wave (cw) or pulsed regimes, and their therapeutic effects. Special attention was paid to the laryngological application of a [...] Read more.
The paper deals with the medical application of diode-lasers. A short review of medical therapies is presented, taking into account the wavelength applied, continuous wave (cw) or pulsed regimes, and their therapeutic effects. Special attention was paid to the laryngological application of a pulsed diode laser with wavelength 810 nm, and dermatologic applications of a 975 nm laser working at cw and pulsed mode. The efficacy of the laser procedures and a comparison of the pulsed and cw regimes is presented and discussed. Full article
Show Figures

Figure 1

8 pages, 1859 KiB
Article
On the Modeling of the Donor/Acceptor Compensation Ratio in Carbon-Doped GaN to Univocally Reproduce Breakdown Voltage and Current Collapse in Lateral GaN Power HEMTs
by Nicolò Zagni, Alessandro Chini, Francesco Maria Puglisi, Paolo Pavan and Giovanni Verzellesi
Micromachines 2021, 12(6), 709; https://doi.org/10.3390/mi12060709 - 16 Jun 2021
Cited by 13 | Viewed by 2667
Abstract
The intentional doping of lateral GaN power high electron mobility transistors (HEMTs) with carbon (C) impurities is a common technique to reduce buffer conductivity and increase breakdown voltage. Due to the introduction of trap levels in the GaN bandgap, it is well known [...] Read more.
The intentional doping of lateral GaN power high electron mobility transistors (HEMTs) with carbon (C) impurities is a common technique to reduce buffer conductivity and increase breakdown voltage. Due to the introduction of trap levels in the GaN bandgap, it is well known that these impurities give rise to dispersion, leading to the so-called “current collapse” as a collateral effect. Moreover, first-principles calculations and experimental evidence point out that C introduces trap levels of both acceptor and donor types. Here, we report on the modeling of the donor/acceptor compensation ratio (CR), that is, the ratio between the density of donors and acceptors associated with C doping, to consistently and univocally reproduce experimental breakdown voltage (VBD) and current-collapse magnitude (ΔICC). By means of calibrated numerical device simulations, we confirm that ΔICC is controlled by the effective trap concentration (i.e., the difference between the acceptor and donor densities), but we show that it is the total trap concentration (i.e., the sum of acceptor and donor densities) that determines VBD, such that a significant CR of at least 50% (depending on the technology) must be assumed to explain both phenomena quantitatively. The results presented in this work contribute to clarifying several previous reports, and are helpful to device engineers interested in modeling C-doped lateral GaN power HEMTs. Full article
Show Figures

Figure 1

23 pages, 8176 KiB
Article
Design and Analysis of a Radio-Frequency Moisture Sensor for Grain Based on the Difference Method
by Zhongxu Chen, Wenfu Wu, Jianpeng Dou, Zhe Liu, Kai Chen and Yan Xu
Micromachines 2021, 12(6), 708; https://doi.org/10.3390/mi12060708 - 16 Jun 2021
Cited by 8 | Viewed by 2508
Abstract
Grain moisture is one of the key indexes of grain quality, and acquiring an accurate moisture value is critical for grain storage security. However, the sensors used in the traditional methods for testing grain moisture are based on capacitance, microwave, or radio-frequency methods [...] Read more.
Grain moisture is one of the key indexes of grain quality, and acquiring an accurate moisture value is critical for grain storage security. However, the sensors used in the traditional methods for testing grain moisture are based on capacitance, microwave, or radio-frequency methods and still exhibit low accuracy and instability because they are susceptible to the temperature, moisture, and micro gas flow of the air in the granary. In this study, we employed a new design for a radio-frequency moisture sensor for grain. The structure of the sensor is based on the difference method and consists of two parallel probe units. These units are at different distances to the tested grain, resulting in different sensitivities in the moisture measurements. Through a phase difference operation on the test signals, the disturbance variable was reduced. The specific size of the two parallel probes was confirmed by calculation and simulation using High Frequency Structure Simulator (HFSS) software. The simulated and measured parameters of a prototype sensor agreed well. The linear relationship yielded a correlation coefficient of 0.9904, and the average error of the moisture testing was within ±0.3% under the conditions where the VSWR (voltage standing wave ratio) value and return losses were 1.5896 and −20 dB, respectively, at a measured central frequency of 100 MHz. The results indicate that the performance of the sensor was excellent. Full article
Show Figures

Figure 1

12 pages, 4484 KiB
Article
Scratch Behaviour of Bulk Silicon Nitride Ceramics
by Xiaolan Xiao, Jiayun Deng, Qiang Xiong, Qiusheng Yan, Zhengtao Wu and Huatay Lin
Micromachines 2021, 12(6), 707; https://doi.org/10.3390/mi12060707 - 16 Jun 2021
Cited by 8 | Viewed by 2308
Abstract
Si3N4 ceramic is generally recognized as being difficult to machine due to its hardness and brittleness. It is necessary to control the normal load applied and the machined depth of the abrasive particles in order to eliminate surface/subsurface damage and [...] Read more.
Si3N4 ceramic is generally recognized as being difficult to machine due to its hardness and brittleness. It is necessary to control the normal load applied and the machined depth of the abrasive particles in order to eliminate surface/subsurface damage and defects during the grinding or polishing. In this study, scratch experiments were conducted on the polished surface of Si3N4 specimens to investigate the brittle–ductile transformation and the evolution of material removal mechanisms. In addition, the cracking behaviour of Si3N4 ceramic was characterized by indentation tests. The Vickers indentation produced cracks that exhibited good developmental integrity and geometric symmetry. The results indicate that the scratch track can be divided into three stages: the ductile regime, the brittle–ductile coexisting stage, and the brittle fracture regime. The critical loads and the corresponding penetration depths of cracking occurrence in Si3N4 were recorded. The material removal of Si3N4 ceramic was primary attributed to ductile regime removal when the load was less than 9.8 N. Microcrack initiation on the subsurface was observed when the penetration depth of the scratch tip reached 8 μm or the depth of the indentation tip reached 3.2 μm. Microcracks expanded rapidly as the load was further increased, resulting in a brittle fracture of the Si3N4 ceramic. Full article
Show Figures

Figure 1

19 pages, 1190 KiB
Article
Geometric Methods for Efficient Planar Swimming of Copepod Nauplii
by Corey Shanbrom, Jonas Balisacan, George Wilkens and Monique Chyba
Micromachines 2021, 12(6), 706; https://doi.org/10.3390/mi12060706 - 16 Jun 2021
Cited by 1 | Viewed by 2058
Abstract
Copepod nauplii are larval crustaceans with important ecological functions. Due to their small size, they experience an environment of low Reynolds number within their aquatic habitat. Here we provide a mathematical model of a swimming copepod nauplius with two legs moving in a [...] Read more.
Copepod nauplii are larval crustaceans with important ecological functions. Due to their small size, they experience an environment of low Reynolds number within their aquatic habitat. Here we provide a mathematical model of a swimming copepod nauplius with two legs moving in a plane. This model allows for both rotation and two-dimensional displacement by the periodic deformation of the swimmer’s body. The system is studied from the framework of optimal control theory, with a simple cost function designed to approximate the mechanical energy expended by the copepod. We find that this model is sufficiently realistic to recreate behavior similar to those of observed copepod nauplii, yet much of the mathematical analysis is tractable. In particular, we show that the system is controllable, but there exist singular configurations where the degree of non-holonomy is non-generic. We also partially characterize the abnormal extremals and provide explicit examples of families of abnormal curves. Finally, we numerically simulate normal extremals and observe some interesting and surprising phenomena. Full article
(This article belongs to the Special Issue Advances in Microswimmers)
Show Figures

Figure 1

11 pages, 2518 KiB
Article
Achieving Triply Periodic Minimal Surface Thin-Walled Structures by Micro Laser Powder Bed Fusion Process
by Shuo Qu, Junhao Ding and Xu Song
Micromachines 2021, 12(6), 705; https://doi.org/10.3390/mi12060705 - 16 Jun 2021
Cited by 25 | Viewed by 4170
Abstract
Recently, triply periodic minimal surface (TPMS) lattice structures have been increasingly employed in many applications, such as lightweighting and heat transfer, and they are enabled by the maturation of additive manufacturing technology, i.e., laser powder bed fusion (LPBF). When the shell-based TPMS structure’s [...] Read more.
Recently, triply periodic minimal surface (TPMS) lattice structures have been increasingly employed in many applications, such as lightweighting and heat transfer, and they are enabled by the maturation of additive manufacturing technology, i.e., laser powder bed fusion (LPBF). When the shell-based TPMS structure’s thickness decreases, higher porosity and a larger surface-to-volume ratio can be achieved, which results in an improvement in the properties of the lattice structures. Micro LPBF, which combines finer laser beam, smaller powder, and thinner powder layer, is employed in this work to fabricate the thin-walled structures (TWS) of TPMS lattice by stainless steel 316 L (SS316L). Utilizing this system, the optimal parameters for printing TPMS-TWS are explored in terms of densification, smoothness, limitation of thickness, and dimensional accuracy. Cube samples with 99.7% relative density and a roughness value of 2.1 μm are printed by using the energy density of 100 J/mm3. Moreover, a thin (100 μm thickness) wall structure can be fabricated through optimizing parameters. Finally, the TWS samples with various TPMS structures are manufactured to compare their heat dissipation capability. As a result, TWS sample of TPMS lattice exhibits a larger temperature gradient in the vertical direction compared to the benchmark sample. The steady-state temperature of the sample base presents a 7 K decrease via introducing TWS. Full article
Show Figures

Figure 1

24 pages, 4552 KiB
Review
A Brief Review on Additive Manufacturing of Polymeric Composites and Nanocomposites
by Vahid Monfared, Hamid Reza Bakhsheshi-Rad, Seeram Ramakrishna, Mahmood Razzaghi and Filippo Berto
Micromachines 2021, 12(6), 704; https://doi.org/10.3390/mi12060704 - 16 Jun 2021
Cited by 24 | Viewed by 5798
Abstract
In this research article, a mini-review study is performed on the additive manufacturing (AM) of the polymeric matrix composites (PMCs) and nanocomposites. In this regard, some methods for manufacturing and important and applied results are briefly introduced and presented. AM of polymeric matrix [...] Read more.
In this research article, a mini-review study is performed on the additive manufacturing (AM) of the polymeric matrix composites (PMCs) and nanocomposites. In this regard, some methods for manufacturing and important and applied results are briefly introduced and presented. AM of polymeric matrix composites and nanocomposites has attracted great attention and is emerging as it can make extensively customized parts with appreciably modified and improved mechanical properties compared to the unreinforced polymer materials. However, some matters must be addressed containing reduced bonding of reinforcement and matrix, the slip between reinforcement and matrix, lower creep strength, void configurations, high-speed crack propagation, obstruction because of filler inclusion, enhanced curing time, simulation and modeling, and the cost of manufacturing. In this review, some selected and significant results regarding AM or three-dimensional (3D) printing of polymeric matrix composites and nanocomposites are summarized and discuss. In addition, this article discusses the difficulties in preparing composite feedstock filaments and printing issues with nanocomposites and short and continuous fiber composites. It is discussed how to print various thermoplastic composites ranging from amorphous to crystalline polymers. In addition, the analytical and numerical models used for simulating AM, including the Fused deposition modeling (FDM) printing process and estimating the mechanical properties of printed parts, are explained in detail. Particle, fiber, and nanomaterial-reinforced polymer composites are highlighted for their performance. Finally, key limitations are identified in order to stimulate further 3D printing research in the future. Full article
Show Figures

Graphical abstract

14 pages, 2163 KiB
Review
Random Telegraph Noise in 3D NAND Flash Memories
by Alessandro S. Spinelli, Gerardo Malavena, Andrea L. Lacaita and Christian Monzio Compagnoni
Micromachines 2021, 12(6), 703; https://doi.org/10.3390/mi12060703 - 16 Jun 2021
Cited by 9 | Viewed by 4809
Abstract
In this paper, we review the phenomenology of random telegraph noise (RTN) in 3D NAND Flash arrays. The main features of such arrays resulting from their mainstream integration scheme are first discussed, pointing out the relevant role played by the polycrystalline nature of [...] Read more.
In this paper, we review the phenomenology of random telegraph noise (RTN) in 3D NAND Flash arrays. The main features of such arrays resulting from their mainstream integration scheme are first discussed, pointing out the relevant role played by the polycrystalline nature of the string silicon channels on current transport. Starting from that, experimental data for RTN in 3D arrays are presented and explained via theoretical and simulation models. The attention is drawn, in particular, to the changes in the RTN dependences on the array working conditions that resulted from the transition from planar to 3D architectures. Such changes are explained by considering the impact of highly-defective grain boundaries on percolative current transport in cell channels in combination with the localized nature of the RTN traps. Full article
(This article belongs to the Special Issue Flash Memory Devices)
Show Figures

Figure 1

27 pages, 8040 KiB
Article
Spark Analysis Based on the CNN-GRU Model for WEDM Process
by Changhong Liu, Xingxin Yang, Shaohu Peng, Yongjun Zhang, Lingxi Peng and Ray Y. Zhong
Micromachines 2021, 12(6), 702; https://doi.org/10.3390/mi12060702 - 16 Jun 2021
Cited by 6 | Viewed by 2802
Abstract
Wire electrical discharge machining (WEDM), widely used to fabricate micro and precision parts in manufacturing industry, is a nontraditional machining method using discharge energy which is transformed into thermal energy to efficiently remove materials. A great amount of research has been conducted based [...] Read more.
Wire electrical discharge machining (WEDM), widely used to fabricate micro and precision parts in manufacturing industry, is a nontraditional machining method using discharge energy which is transformed into thermal energy to efficiently remove materials. A great amount of research has been conducted based on pulse characteristics. However, the spark image-based approach has little research reported. This paper proposes a discharge spark image-based approach. A model is introduced to predict the discharge status using spark image features through a synchronous high-speed image and waveform acquisition system. First, the relationship between the spark image features (e.g., area, energy, energy density, distribution, etc.) and discharge status is explored by a set of experiments). Traditional methods have claimed that pulse waveform of “short” status is related to the status of non-machining while through our research, it is concluded that this is not always true by conducting experiments based on the spark images. Second, a deep learning model based on Convolution neural network (CNN) and Gated recurrent unit (GRU) is proposed to predict the discharge status. A time series of spark image features extracted by CNN form a 3D feature space is used to predict the discharge status through GRU. Moreover, a quantitative labeling method of machining state is proposed to improve the stability of the model. Due the effective features and the quantitative labeling method, the proposed approach achieves better predict result comparing with the single GRU model. Full article
(This article belongs to the Section E:Engineering and Technology)
Show Figures

Figure 1

14 pages, 4065 KiB
Article
A Gravity-Triggered Liquid Metal Patch Antenna with Reconfigurable Frequency
by Peng Qin, Guan-Long Huang, Jia-Jun Liang, Qian-Yu Wang, Jun-Heng Fu, Xi-Yu Zhu, Tian-Ying Liu, Lin Gui, Jing Liu and Zhong-Shan Deng
Micromachines 2021, 12(6), 701; https://doi.org/10.3390/mi12060701 - 16 Jun 2021
Cited by 10 | Viewed by 3253
Abstract
In this paper, a gravity-triggered liquid metal microstrip patch antenna with reconfigurable frequency is proposed with experimental verification. In this work, the substrate of the antenna is quickly obtained through three-dimensional (3D) printing technology. Non-toxic EGaIn alloy is filled into the resin substrate [...] Read more.
In this paper, a gravity-triggered liquid metal microstrip patch antenna with reconfigurable frequency is proposed with experimental verification. In this work, the substrate of the antenna is quickly obtained through three-dimensional (3D) printing technology. Non-toxic EGaIn alloy is filled into the resin substrate as a radiation patch, and the NaOH solution is used to remove the oxide film of EGaIn. In this configuration, the liquid metal inside the antenna can be flexibly flowed and deformed with different rotation angles due to the gravity to realize different working states. To validate the conception, the reflection coefficients and radiation patterns of the prototyped antenna are then measured, from which it can be observed that the measured results closely follow the simulations. The antenna can obtain a wide operating bandwidth of 3.69–4.95 GHz, which coverage over a range of frequencies suitable for various channels of the 5th generation (5G) mobile networks. The principle of gravitational driving can be applied to the design of reconfigurable antennas for other types of liquid metals. Full article
Show Figures

Figure 1

23 pages, 24801 KiB
Article
Secure Air Traffic Control at the Hub of Multiplexing on the Centrifugo-Pneumatic Lab-on-a-Disc Platform
by Jens Ducrée
Micromachines 2021, 12(6), 700; https://doi.org/10.3390/mi12060700 - 15 Jun 2021
Cited by 9 | Viewed by 3134
Abstract
Fluidic larger-scale integration (LSI) resides at the heart of comprehensive sample-to-answer automation and parallelization of assay panels for frequent and ubiquitous bioanalytical testing in decentralized point-of-use/point-of-care settings. This paper develops a novel “digital twin” strategy with an emphasis on rotational, centrifugo-pneumatic flow control. [...] Read more.
Fluidic larger-scale integration (LSI) resides at the heart of comprehensive sample-to-answer automation and parallelization of assay panels for frequent and ubiquitous bioanalytical testing in decentralized point-of-use/point-of-care settings. This paper develops a novel “digital twin” strategy with an emphasis on rotational, centrifugo-pneumatic flow control. The underlying model systematically connects retention rates of rotationally actuated valves as a key element of LSI to experimental input parameters; for the first time, the concept of band widths in frequency space as the decisive quantity characterizing operational robustness is introduced, a set of quantitative performance metrics guiding algorithmic optimization of disc layouts is defined, and the engineering principles of advanced, logical flow control and timing are elucidated. Overall, the digital twin enables efficient design for automating multiplexed bioassay protocols on such “Lab-on-a-Disc” (LoaD) systems featuring high packing density, reliability, configurability, modularity, and manufacturability to eventually minimize cost, time, and risk of development and production. Full article
(This article belongs to the Special Issue Lab-on-a-Disk)
Show Figures

Figure 1

13 pages, 2320 KiB
Article
MEMS-Based Electrochemical Seismometer with a Sensing Unit Integrating Four Electrodes
by Wenjie Qi, Chao Xu, Bowen Liu, Xu She, Tian Liang, Deyong Chen, Junbo Wang and Jian Chen
Micromachines 2021, 12(6), 699; https://doi.org/10.3390/mi12060699 - 15 Jun 2021
Cited by 6 | Viewed by 2432
Abstract
This paper presents a new process to fabricate a sensing unit of electrochemical seismometers using only one silicon–glass–silicon bonded wafer. By integrating four electrodes on one silicon–glass–silicon bonded wafer, the consistency of the developed sensing unit was greatly improved, benefiting from the high [...] Read more.
This paper presents a new process to fabricate a sensing unit of electrochemical seismometers using only one silicon–glass–silicon bonded wafer. By integrating four electrodes on one silicon–glass–silicon bonded wafer, the consistency of the developed sensing unit was greatly improved, benefiting from the high alignment accuracy. Parameter designs and simulations were carried out based on this sensing unit, which indicated that the sensitivities of the developed electrochemical seismometer decreased with the decrease in the number of flow holes in the sensing unit, and the initial stabilization time decreased gradually with the decrease in the thickness of the glass layer. Based on experimental results of four devices, the peak sensitivity was quantified as 5345.45 ± 43.78 V/(m/s) at 2 Hz, which proved high consistency of the fabricated electrochemical seismometer. In terms of the responses to random ground motions, high consistencies between the developed electrochemical seismometer and the commercial counterpart of CME6011 (R-sensors, Moscow, Russia) were found, where the developed electrochemical seismometer produced comparable noise levels to those of CME6011. These results validated the performance of the device and it may function as an effective tool for a variety of applications. Full article
Show Figures

Figure 1

Previous Issue
Next Issue
Back to TopTop
