Eco-Concrete in High Temperatures
Abstract
:1. Introduction
Temperature | Phase Changes |
---|---|
30–120 °C | Release of evaporable water, increase in vapor pressure. |
>300 °C | Expulsion of chemically bound water. |
>500 °C | Water capillary and gel pores water discharge. Pore volume rapid increase and changes in the pores system from isolated closed to interconnected network. |
2. Fire Resistance of OPC Concretes with Supplementary Cementitious Materials (SCMs)
2.1. Ground Granulated Blast-Furnace Slag (GGBFS) Concrete
Temperature | Phase Changes |
---|---|
>200 °C | Evaporation of free, mass loss, better mechanical properties by temperature-induced gel formation. |
>300 °C | Strength increase, formation of gel, decreasing porosity [55]. |
>500 °C | Strength loss due to gel crystallization, loss of strength performance. |
>800 °C | The continued dehydration of calcium silicate hydrates (C-S-H) and the partial decomposition of carbonate. |
>1200 °C | Decomposition of C-S-H, formation of ß-C2S and C3S, akermanite, merwinite, and gehlenite in the sodium sulfate-activated GGBFSs [56]. |
2.2. Fly Ash (FA) Concrete
2.3. Calcium Sulfoaluminate Concrete (CSA)
3. Fire Resistance of Concretes Based on Alkali-Activated Binder Systems
4. Test Setups
4.1. Small-Scale Tests
4.2. Large-Scale Tests
5. Effects of Selected Factors
5.1. Effects of Aggegrates
5.2. Effects of Fibers
5.3. Effects of Cooling Regime
5.4. Heat Transfer Characteristic and Thermal Conductivity
6. Discussion
7. Conclusions
8. Future Research
- Nanoscale research to fully understand the mechanism of influence of elevated temperatures on an eco-concrete element;
- An investigation about heating and the cooling rate and its influence on ecological and sustainable concrete performance. In addition, the postfire behavior of eco-concrete must be studied more profoundly;
- A proper approach and methodology to formulate a user-friendly concrete mix design with a minimized presence of hazardous materials and alkali solutions which can withstand high temperatures;
- Evidence that admixtures do not change the concrete properties under elevated temperatures;
- The bonding properties of different materials, such as reinforcement, in ecological concrete;
- A standardized method and methodology to carry out small-scale testing of specimens;
- Large-scale fire tests on ecological concrete. It remains unknown how the extremal factors such as the shape of the structure, wind, snow, applied loads, additional elements located in concrete structures, and fire-extinguishing systems (passive and active) could disturb the properties and overall performance of concrete elements;
- A developed and classified database of sustainable concrete components and possible configurations;
- A database, building codes, fire regulations, design and material approach, and user standards in a variety of scenarios, situations, and timelines;
- A life-cycle assessment analysis and a determination of the potential reusage of recycled concrete to minimalize the volume of waste;
- Digitalization, collaborations, and open access combined with artificial intelligences.
