Sensors, Volume 21, Issue 8 (April-2 2021) – 119 articles

  • Issues are regarded as officially published after their release is announced to the table of contents alert mailing list.
  • You may sign up for e-mail alerts to receive table of contents of newly released issues.
  • PDF is the official format for papers published in both, html and pdf forms. To view the papers in pdf format, click on the "PDF Full-text" link, and use the free Adobe Readerexternal link to open them.
Order results
Result details
Select all
Export citation of selected articles as:
Open AccessArticle
Improved Direction-of-Arrival Estimation of an Acoustic Source Using Support Vector Regression and Signal Correlation
Sensors 2021, 21(8), 2692; https://doi.org/10.3390/s21082692 (registering DOI) - 11 Apr 2021
Viewed by 1
Abstract
The direction-of-arrival (DoA) estimation of an acoustic source can be estimated with a uniform linear array using classical techniques such as generalized cross-correlation, beamforming, subspace techniques, etc. However, these methods require a search in the angular space and also have a higher angular [...] Read more.
The direction-of-arrival (DoA) estimation of an acoustic source can be estimated with a uniform linear array using classical techniques such as generalized cross-correlation, beamforming, subspace techniques, etc. However, these methods require a search in the angular space and also have a higher angular error at the end-fire. In this paper, we propose the use of regression techniques to improve the results of DoA estimation at all angles including the end-fire. The proposed methodology employs curve-fitting on the received multi-channel microphone signals, which when applied in tandem with support vector regression (SVR) provides a better estimation of DoA as compared to the conventional techniques and other polynomial regression techniques. A multilevel regression technique is also proposed, which further improves the estimation accuracy at the end-fire. This multilevel regression technique employs the use of linear regression over the results obtained from SVR. The techniques employed here yielded an overall 63% improvement over the classical generalized cross-correlation technique. Full article
(This article belongs to the Section Electronic Sensors)
Show Figures

Figure 1

Open AccessArticle
Unsupervised Monocular Depth Estimation for Colonoscope System Using Feedback Network
Sensors 2021, 21(8), 2691; https://doi.org/10.3390/s21082691 (registering DOI) - 11 Apr 2021
Viewed by 35
Abstract
A colonoscopy is a medical examination used to check disease or abnormalities in the large intestine. If necessary, polyps or adenomas would be removed through the scope during a colonoscopy. Colorectal cancer can be prevented through this. However, the polyp detection rate differs [...] Read more.
A colonoscopy is a medical examination used to check disease or abnormalities in the large intestine. If necessary, polyps or adenomas would be removed through the scope during a colonoscopy. Colorectal cancer can be prevented through this. However, the polyp detection rate differs depending on the condition and skill level of the endoscopist. Even some endoscopists have a 90% chance of missing an adenoma. Artificial intelligence and robot technologies for colonoscopy are being studied to compensate for these problems. In this study, we propose a self-supervised monocular depth estimation using spatiotemporal consistency in the colon environment. It is our contribution to propose a loss function for reconstruction errors between adjacent predicted depths and a depth feedback network that uses predicted depth information of the previous frame to predict the depth of the next frame. We performed quantitative and qualitative evaluation of our approach, and the proposed FBNet (depth FeedBack Network) outperformed state-of-the-art results for unsupervised depth estimation on the UCL datasets. Full article
(This article belongs to the Section Biomedical Sensors)
Open AccessArticle
Efficient Transmit Antenna Subset Selection for Multiuser Space–Time Line Code Systems
Sensors 2021, 21(8), 2690; https://doi.org/10.3390/s21082690 (registering DOI) - 11 Apr 2021
Viewed by 45
Abstract
Abstract: We consider the problem of the efficient transmit antenna subset (TAS) selection for maximizing the signal-to-interference-plus-noise ratio (SINR) of multiuser space–time line code (MU–STLC) systems [...] Full article
(This article belongs to the Special Issue Multi-Antenna Techniques for 5G and beyond 5G Communications)
Open AccessReview
Soft Grippers for Automatic Crop Harvesting: A Review
Sensors 2021, 21(8), 2689; https://doi.org/10.3390/s21082689 (registering DOI) - 11 Apr 2021
Viewed by 52
Abstract
Agriculture 4.0 is transforming farming livelihoods thanks to the development and adoption of technologies such as artificial intelligence, the Internet of Things and robotics, traditionally used in other productive sectors. Soft robotics and soft grippers in particular are promising approaches to lead to [...] Read more.
Agriculture 4.0 is transforming farming livelihoods thanks to the development and adoption of technologies such as artificial intelligence, the Internet of Things and robotics, traditionally used in other productive sectors. Soft robotics and soft grippers in particular are promising approaches to lead to new solutions in this field due to the need to meet hygiene and manipulation requirements in unstructured environments and in operation with delicate products. This review aims to provide an in-depth look at soft end-effectors for agricultural applications, with a special emphasis on robotic harvesting. To that end, the current state of automatic picking tasks for several crops is analysed, identifying which of them lack automatic solutions, and which methods are commonly used based on the botanical characteristics of the fruits. The latest advances in the design and implementation of soft grippers are also presented and discussed, studying the properties of their materials, their manufacturing processes, the gripping technologies and the proposed control methods. Finally, the challenges that have to be overcome to boost its definitive implementation in the real world are highlighted. Therefore, this review intends to serve as a guide for those researchers working in the field of soft robotics for Agriculture 4.0, and more specifically, in the design of soft grippers for fruit harvesting robots. Full article
(This article belongs to the Special Issue Sensors and Robotics for Digital Agriculture)
Open AccessCommunication
CPW Fed Compact UWB 4-Element MIMO Antenna with High Isolation
Sensors 2021, 21(8), 2688; https://doi.org/10.3390/s21082688 (registering DOI) - 11 Apr 2021
Viewed by 62
Abstract
In the paper, an extremely compact multiple-input-multiple-output (MIMO) antenna is proposed for portable wireless ultrawideband (UWB) applications. The proposed prototype consists of four monopole antenna elements, which are placed perpendicularly to achieve polarization diversity. In addition, the mutual coupling between antenna elements is [...] Read more.
In the paper, an extremely compact multiple-input-multiple-output (MIMO) antenna is proposed for portable wireless ultrawideband (UWB) applications. The proposed prototype consists of four monopole antenna elements, which are placed perpendicularly to achieve polarization diversity. In addition, the mutual coupling between antenna elements is suppressed by designing the gap between the radiation element and the ground plane. Moreover, a matching stub has been connected to the feedline to ensure impedance matching in high frequency. Both simulated and measured results indicate that the proposed antenna has a bandwidth of 3–20 GHz, with a high isolation better than 17 dB. In addition, the designed MIMO antenna offers excellent radiation characteristics and stable gain over the whole working band. The envelope correlation coefficient (ECC) is less than 0.1, which shows that the antenna can meet the polarization diversity characteristics well. Full article
(This article belongs to the Special Issue Antenna Technologies for Millimeter and Terahertz Sensing)
Open AccessArticle
Measurement of Underwater Acoustic Energy Radiated by Single Raindrops
Sensors 2021, 21(8), 2687; https://doi.org/10.3390/s21082687 (registering DOI) - 11 Apr 2021
Viewed by 103
Abstract
Underwater noise produced by rainfall is an important component of underwater ambient noise. For example, the existence of rainfall noise causes strong disturbances to sonar performance. The underwater noise produced by a single raindrop is the basis of rainfall noise. Therefore, it is [...] Read more.
Underwater noise produced by rainfall is an important component of underwater ambient noise. For example, the existence of rainfall noise causes strong disturbances to sonar performance. The underwater noise produced by a single raindrop is the basis of rainfall noise. Therefore, it is necessary to study the associated underwater noise when drops strike the water surface. Previous research focused primarily on the sound pressure and frequency spectrum of underwater noise from single raindrops, but the study on its sound energy is insufficient. The purpose of this paper is to propose a method for predicting the acoustic energy generated by raindrops of any diameter. Here, a formula was derived to calculate the underwater sound energy radiated by single raindrops based on a dipole radiation pattern. A series of experiments were conducted to measure the underwater sound energy in a 15 m × 9 m × 6 m reverberation tank filled with tap water. The analysis of the acoustic energy characteristics and conversion efficiency from kinetic to acoustic energy helped develop the model to predict the average underwater sound energy radiated by single raindrops. Using this model, the total underwater sound energy of all raindrops during a rainfall event can be predicted based on the drop size distribution. Full article
(This article belongs to the Section Physical Sensors)
Show Figures

Figure 1

Open AccessArticle
P4G2Go: A Privacy-Preserving Scheme for Roaming Energy Consumers of the Smart Grid-to-Go
Sensors 2021, 21(8), 2686; https://doi.org/10.3390/s21082686 (registering DOI) - 11 Apr 2021
Viewed by 116
Abstract
Due to its flexibility in terms of charging and billing, the smart grid is an enabler of many innovative energy consumption scenarios. One such example is when a landlord rents their property for a specific period to tenants. Then the electricity bill could [...] Read more.
Due to its flexibility in terms of charging and billing, the smart grid is an enabler of many innovative energy consumption scenarios. One such example is when a landlord rents their property for a specific period to tenants. Then the electricity bill could be redirected from the landlord’s utility to the tenant’s utility. This novel scenario of the smart grid ecosystem, defined in this paper as Grid-to-Go (G2Go), promotes a green economy and can drive rent reductions. However, it also creates critical privacy issues, since utilities may be able to track the tenant’s activities. This paper presents P4G2Go, a novel privacy-preserving scheme that provides strong security and privacy assertions for roaming consumers against honest but curious entities of the smart grid. At the heart of P4G2Go lies the Idemix cryptographic protocol suite, which utilizes anonymous credentials and provides unlinkability of the consumer activities. Our scheme is complemented by the MASKER protocol, used to protect the consumption readings, and the FIDO2 protocol for strong and passwordless authentication. We have implemented the main components of P4G2Go, to quantitatively assess its performance. Finally, we reason about its security and privacy properties, proving that P4G2Go achieves to fulfill the relevant objectives. Full article
(This article belongs to the Special Issue Cybersecurity and Privacy-Preserving in Modern Smart Grid)
Open AccessArticle
TTAS: Trusted Token Authentication Service of Securing SCADA Network in Energy Management System for Industrial Internet of Things
Sensors 2021, 21(8), 2685; https://doi.org/10.3390/s21082685 (registering DOI) - 11 Apr 2021
Viewed by 125
Abstract
The vigorous development of the Industrial Internet of Things brings the advanced connection function of the new generation of industrial automation and control systems. The Supervisory Control and Data Acquisition (SCADA) network is converted into an open and highly interconnected network, where the [...] Read more.
The vigorous development of the Industrial Internet of Things brings the advanced connection function of the new generation of industrial automation and control systems. The Supervisory Control and Data Acquisition (SCADA) network is converted into an open and highly interconnected network, where the equipment connections between industrial electronic devices are integrated with a SCADA system through a Modbus protocol. As SCADA and Modbus are easily used for control and monitoring, the interconnection and operational efficiency between systems are highly improved; however, such connectivity inevitably exposes the system to the open network environment. There are many network security threats and vulnerabilities in a SCADA network system. Especially in the era of the Industrial Internet of Things, any security vulnerability of an industrial system may cause serious property losses. Therefore, this paper proposes an encryption and verification mechanism based on the trusted token authentication service and Transport Layer Security (TLS) protocol to prevent attackers from physical attacks. Experimentally, this paper deployed and verified the system in an actual field of energy management system. According to the experimental results, the security defense architecture proposed in this paper can effectively improve security and is compatible with the actual field system. Full article
(This article belongs to the Special Issue Securing the Industrial Internet of Things)
Open AccessArticle
Distributed Urban Platooning towards High Flexibility, Adaptability, and Stability
Sensors 2021, 21(8), 2684; https://doi.org/10.3390/s21082684 (registering DOI) - 10 Apr 2021
Viewed by 214
Abstract
Vehicle platooning reduces the safety distance between vehicles and the travel time of vehicles so that it leads to an increase in road capacity and to saving fuel consumption. In Europe, many projects for vehicle platooning are being actively developed, but mostly focus [...] Read more.
Vehicle platooning reduces the safety distance between vehicles and the travel time of vehicles so that it leads to an increase in road capacity and to saving fuel consumption. In Europe, many projects for vehicle platooning are being actively developed, but mostly focus on truck platooning on the highway with a simpler topology than that of the urban road. When an existing vehicle platoon is applied to urban roads, many challenges are more complicated to address than highways. They include complex topology, various routes, traffic signals, intersections, frequent lane change, and communication interference depending on a higher vehicle density. To address these challenges, we propose a distributed urban platooning protocol (DUPP) that enables high mobility and maximizes flexibility for driving vehicles to conduct urban platooning in a decentralized manner. DUPP has simple procedures to perform platooning maneuvers and does not require explicit conforming for the completion of platooning maneuvers. Since DUPP mainly operates on a service channel, it does not cause negative side effects on the exchange of basic safety messages on a control channel. Moreover, DUPP does not generate any data propagation delay due to contention-based channel access since it guarantees sequential data transmission opportunities for urban platooning vehicles. Finally, to address a problem of the broadcast storm while vehicles notify detected road events, DUPP performs forwarder selection using an analytic hierarchy process. The performance of the proposed DUPP is compared with that of ENSEMBLE which is the latest European platooning project in terms of the travel time of vehicles, the lifetime of an urban platoon, the success ratio of a designed maneuver, the external cost and the periodicity of the urban platooning-related transmissions, the adaptability of an urban platoon, and the forwarder selection ratio for each vehicle. The results of the performance evaluation demonstrate that the proposed DUPP is well suited to dynamic urban environments by maintaining a vehicle platoon as stable as possible after DUPP flexibly and quickly forms a vehicle platoon without the support of a centralized node. Full article
(This article belongs to the Special Issue Advanced Sensing and Control for Connected and Automated Vehicles)
Open AccessArticle
Rapid Detection of Salmonella typhimurium in Drinking Water by a White Light Reflectance Spectroscopy Immunosensor
Sensors 2021, 21(8), 2683; https://doi.org/10.3390/s21082683 (registering DOI) - 10 Apr 2021
Viewed by 215
Abstract
Biosensors represent an attractive approach for fast bacteria detection. Here, we present an optical biosensor for the detection of Salmonella typhimurium lipopolysaccharide (LPS) and Salmonella bacteria in drinking water, based on white light reflectance spectroscopy. The sensor chip consisted of a Si die [...] Read more.
Biosensors represent an attractive approach for fast bacteria detection. Here, we present an optical biosensor for the detection of Salmonella typhimurium lipopolysaccharide (LPS) and Salmonella bacteria in drinking water, based on white light reflectance spectroscopy. The sensor chip consisted of a Si die with a thin SiO2 layer on top that was transformed into a biosensor through the immobilization of Salmonella LPS. The optical setup included a reflection probe with seven 200 μm fibers, a visible and near-infrared light source, and a spectrometer. The six fibers at the reflection probe circumference were coupled with the light source and illuminated the biosensor chip vertically, whereas the central fiber collected the reflected light and guided it to the spectrometer. A competitive immunoassay configuration was adopted for the analysis. Accordingly, a mixture of LPS or bacteria solution, pre-incubated for 15 min, with an anti-Salmonella LPS antibody was pumped over the chip followed by biotinylated secondary antibody and streptavidin for signal enhancement. The binding of the free anti-Salmonella antibody to chip-immobilized LPS led to a shift of the reflectance spectrum that was inversely related to the analyte concentration (LPS or bacteria) in the calibrators or samples. The total assay duration was 15 min, and the detection limits achieved were 4 ng/mL for LPS and 320 CFU/mL for bacteria. Taking into account the low detection limits, the short analysis time, and the small size of the chip and instrumentation employed, the proposed immunosensor could find wide application for bacteria detection in drinking water. Full article
(This article belongs to the Special Issue Recent Advances in Immunosensors and Biosensors)
Open AccessArticle
Robust Principal Component Thermography for Defect Detection in Composites
Sensors 2021, 21(8), 2682; https://doi.org/10.3390/s21082682 (registering DOI) - 10 Apr 2021
Viewed by 161
Abstract
Pulsed Thermography (PT) data are usually affected by noise and as such most of the research effort in the last few years has been directed towards the development of advanced signal processing methods to improve defect detection. Among the numerous techniques that have [...] Read more.
Pulsed Thermography (PT) data are usually affected by noise and as such most of the research effort in the last few years has been directed towards the development of advanced signal processing methods to improve defect detection. Among the numerous techniques that have been proposed, principal component thermography (PCT)—based on principal component analysis (PCA)—is one of the most effective in terms of defect contrast enhancement and data compression. However, it is well-known that PCA can be significantly affected in the presence of corrupted data (e.g., noise and outliers). Robust PCA (RPCA) has been recently proposed as an alternative statistical method that handles noisy data more properly by decomposing the input data into a low-rank matrix and a sparse matrix. We propose to process PT data by RPCA instead of PCA in order to improve defect detectability. The performance of the resulting approach, Robust Principal Component Thermography (RPCT)—based on RPCA, was evaluated with respect to PCT—based on PCA, using a CFRP sample containing artificially produced defects. We compared results quantitatively based on two metrics, Contrast-to-Noise Ratio (CNR), for defect detection capabilities, and the Jaccard similarity coefficient, for defect segmentation potential. CNR results were on average 40% higher for RPCT than for PCT, and the Jaccard index was slightly higher for RPCT (0.7395) than for PCT (0.7010). In terms of computational time, however, PCT was 11.5 times faster than RPCT. Further investigations are needed to assess RPCT performance on a wider range of materials and to optimize computational time. Full article
(This article belongs to the Special Issue Sensors: 20th Anniversary)
Open AccessArticle
Spectrum Based Power Management for Congested IoT Networks
Sensors 2021, 21(8), 2681; https://doi.org/10.3390/s21082681 (registering DOI) - 10 Apr 2021
Viewed by 200
Abstract
With constantly increasing demand in connected society Internet of Things (IoT) network is frequently becoming congested. IoT sensor devices lose more power while transmitting data through congested IoT networks. Currently, in most scenarios, the distributed IoT devices in use have no effective spectrum [...] Read more.
With constantly increasing demand in connected society Internet of Things (IoT) network is frequently becoming congested. IoT sensor devices lose more power while transmitting data through congested IoT networks. Currently, in most scenarios, the distributed IoT devices in use have no effective spectrum based power management, and have no guarantee of a long term battery life while transmitting data through congested IoT networks. This puts user information at risk, which could lead to loss of important information in communication. In this paper, we studied the extra power consumed due to retransmission of IoT data packet and bad communication channel management in a congested IoT network. We propose a spectrum based power management solution that scans channel conditions when needed and utilizes the lowest congested channel for IoT packet routing. It also effectively measured power consumed in idle, connected, paging and synchronization status of a standard IoT device in a congested IoT network. In our proposed solution, a Freescale Freedom Development Board (FREDEVPLA) is used for managing channel related parameters. While supervising the congestion level and coordinating channel allocation at the FREDEVPLA level, our system configures MAC and Physical layer of IoT devices such that it provides the outstanding power utilization based on the operating network in connected mode compared to the basic IoT standard. A model has been set up and tested using freescale launchpads. Test data show that battery life of IoT devices using proposed spectrum based power management increases by at least 30% more than non-spectrum based power management methods embedded within IoT devices itself. Finally, we compared our results with the basic IoT standard, IEEE802.15.4. Furthermore, the proposed system saves lot of memory for IoT devices, improves overall IoT network performance, and above all, decrease the risk of losing data packets in communication. The detail analysis in this paper also opens up multiple avenues for further research in future use of channel scanning by FREDEVPLA board. Full article
(This article belongs to the Special Issue Distributed Sensor Networks: Development and Applications)
Open AccessArticle
Design of a Wideband Tonpilz Transducer Comprising Non-Uniform Piezoceramic Stacks with Equivalent Circuits
Sensors 2021, 21(8), 2680; https://doi.org/10.3390/s21082680 (registering DOI) - 10 Apr 2021
Viewed by 171
Abstract
Tonpilz transducers are desirable for their superior performance in underwater target detection and communication applications. Several design schemes to widen their bandwidth have been reported, but these schemes often involve a complex structure or arrangement of additional components. In this study, a simple [...] Read more.
Tonpilz transducers are desirable for their superior performance in underwater target detection and communication applications. Several design schemes to widen their bandwidth have been reported, but these schemes often involve a complex structure or arrangement of additional components. In this study, a simple design is proposed to improve the bandwidth of a multimode Tonpilz transducer by using a non-uniform drive section that consists of piezoelectric stacks of various thicknesses. The efficacy of the design is illustrated with a multimode Tonpilz transducer having three lead zirconate titanate (PZT) stacks of different thicknesses. A new equivalent circuit was developed to analyze the frequency response of the transducer incorporating the non-uniform drive section and was used for rigorous analysis of the effects of varying the position and thickness of the non-uniform stacks on the transmitting characteristics of the transducer. The validity of the design was verified through the fabrication and characterization of a prototype multimode Tonpilz transducer. The developed structure can be readily extended to an arbitrary number of stacks in the Tonpilz transducer with any number of PZT disks in each stack. Full article
(This article belongs to the Section Physical Sensors)
Open AccessArticle
Real-Time and Efficient Traffic Information Acquisition via Pavement Vibration IoT Monitoring System
Sensors 2021, 21(8), 2679; https://doi.org/10.3390/s21082679 (registering DOI) - 10 Apr 2021
Viewed by 196
Abstract
Traditional road-embedded monitoring systems for traffic monitoring have the disadvantages of a short life, high energy consumption and data redundancy, resulting in insufficient durability and high cost. In order to improve the durability and efficiency of the road-embedded monitoring system, a pavement vibration [...] Read more.
Traditional road-embedded monitoring systems for traffic monitoring have the disadvantages of a short life, high energy consumption and data redundancy, resulting in insufficient durability and high cost. In order to improve the durability and efficiency of the road-embedded monitoring system, a pavement vibration monitoring system is developed based on the Internet of things (IoT). The system includes multi-acceleration sensing nodes, a gateway, and a cloud platform. The key design principles and technologies of each part of the system are proposed, which provides valuable experience for the application of IoT monitoring technology in road infrastructures. Characterized by low power consumption, distributed computing, and high extensibility properties, the pavement vibration IoT monitoring system can realize the monitoring, transmission, and analysis of pavement vibration signal, and acquires the real-time traffic information. This road-embedded system improves the intellectual capacity of road infrastructure and is conducive to the construction of a new generation of smart roads. Full article
(This article belongs to the Special Issue Piezoelectric Energy Harvesting Sensors and Their Applications)
Open AccessArticle
Spatial Memory in a Spiking Neural Network with Robot Embodiment
Sensors 2021, 21(8), 2678; https://doi.org/10.3390/s21082678 (registering DOI) - 10 Apr 2021
Viewed by 175
Abstract
Cognitive maps and spatial memory are fundamental paradigms of brain functioning. Here, we present a spiking neural network (SNN) capable of generating an internal representation of the external environment and implementing spatial memory. The SNN initially has a non-specific architecture, which is then [...] Read more.
Cognitive maps and spatial memory are fundamental paradigms of brain functioning. Here, we present a spiking neural network (SNN) capable of generating an internal representation of the external environment and implementing spatial memory. The SNN initially has a non-specific architecture, which is then shaped by Hebbian-type synaptic plasticity. The network receives stimuli at specific loci, while the memory retrieval operates as a functional SNN response in the form of population bursts. The SNN function is explored through its embodiment in a robot moving in an arena with safe and dangerous zones. We propose a measure of the global network memory using the synaptic vector field approach to validate results and calculate information characteristics, including learning curves. We show that after training, the SNN can effectively control the robot’s cognitive behavior, allowing it to avoid dangerous regions in the arena. However, the learning is not perfect. The robot eventually visits dangerous areas. Such behavior, also observed in animals, enables relearning in time-evolving environments. If a dangerous zone moves into another place, the SNN remaps positive and negative areas, allowing escaping the catastrophic interference phenomenon known for some AI architectures. Thus, the robot adapts to changing world. Full article
(This article belongs to the Special Issue Robotic Control Based on Neuromorphic Approaches and Hardware)
Show Figures

Figure 1

Open AccessArticle
Design and Analysis of an Intelligent Toilet Wheelchair Based on Planar 2DOF Parallel Mechanism with Coupling Branch Chains
Sensors 2021, 21(8), 2677; https://doi.org/10.3390/s21082677 (registering DOI) - 10 Apr 2021
Viewed by 174
Abstract
Due to the fixed size of the structure or the possibility of only simple manual adjustment, the traditional toilet wheelchair cannot easily be adapted to the size of the user or the toilet. In this paper, a planar two-degree-of-freedom parallel mechanism with coupling [...] Read more.
Due to the fixed size of the structure or the possibility of only simple manual adjustment, the traditional toilet wheelchair cannot easily be adapted to the size of the user or the toilet. In this paper, a planar two-degree-of-freedom parallel mechanism with coupling branch chains is proposed to enable both seat height adjustment and body posture adjustment of a toilet chair, solving the problems of posture adaptability between the user and the machine, and height matching in the process of using the wheelchair-assisted toilet. The model of the parallel mechanism was designed after analyzing the general rules of posture transformation in the human body before and after the toilet process, and the dimensions of each linkage were then determined according to the constraint conditions. By analyzing the degree of freedom, kinematics, workspace, singularity and position of the center of gravity, the rationality of the design was ensured. The weighted average function was used to find the optimal fixed point of the horizontal moving slider, and the actual trajectory at the end of the single driving mode was close to the ideal trajectory. The experimental results show that the adjustable seat height range is 290~550 mm and the adjustable angle range is 0~90°, which can enable disabled people to use the toilet independently. Full article
(This article belongs to the Special Issue Autonomous Robots in Healthcare Applications)
Open AccessCommunication
Liquid Level Detection in Standard Capacity Measures with Machine Vision
Sensors 2021, 21(8), 2676; https://doi.org/10.3390/s21082676 (registering DOI) - 10 Apr 2021
Viewed by 167
Abstract
Capacity measures are commonly used volume standards for testing measuring systems for liquids other than water. Manual readings from the measuring scale can often be difficult due to the location of the capacity measure or to the nature of the measured liquid. This [...] Read more.
Capacity measures are commonly used volume standards for testing measuring systems for liquids other than water. Manual readings from the measuring scale can often be difficult due to the location of the capacity measure or to the nature of the measured liquid. This article focuses on the automation of this procedure by using a single camera machine vision system. A camera positioned perpendicular to the transparent neck captures the image of the liquid meniscus and the measuring scale. The volume reading is determined with the user-defined software in the LabVIEW programming environment, which carries out the image preprocessing, detection of the scale marks and the liquid level, correction of lens distortion and parallax effects and final unit conversions. The realized measuring system for liquid level detection in standard capacity measures is tested and validated by comparing the automated measurement results with those taken by the operators. The results confirm the appropriateness of the presented measuring system for the field of legal metrology. Full article
(This article belongs to the Section Intelligent Sensors)
Show Figures

Figure 1

Open AccessArticle
Semantic Cardiac Segmentation in Chest CT Images Using K-Means Clustering and the Mathematical Morphology Method
Sensors 2021, 21(8), 2675; https://doi.org/10.3390/s21082675 (registering DOI) - 10 Apr 2021
Viewed by 151
Abstract
Whole cardiac segmentation in chest CT images is important to identify functional abnormalities that occur in cardiovascular diseases, such as coronary artery disease (CAD) detection. However, manual efforts are time-consuming and labor intensive. Additionally, labeling the ground truth for cardiac segmentation requires the [...] Read more.
Whole cardiac segmentation in chest CT images is important to identify functional abnormalities that occur in cardiovascular diseases, such as coronary artery disease (CAD) detection. However, manual efforts are time-consuming and labor intensive. Additionally, labeling the ground truth for cardiac segmentation requires the extensive manual annotation of images by the radiologist. Due to the difficulty in obtaining the annotated data and the required expertise as an annotator, an unsupervised approach is proposed. In this paper, we introduce a semantic whole-heart segmentation combining K-Means clustering as a threshold criterion of the mean-thresholding method and mathematical morphology method as a threshold shifting enhancer. The experiment was conducted on 500 subjects in two cases: (1) 56 slices per volume containing full heart scans, and (2) 30 slices per volume containing about half of the top of heart scans before the liver appears. In both cases, the results showed an average silhouette score of the K-Means method of 0.4130. Additionally, the experiment on 56 slices per volume achieved an overall accuracy (OA) and mean intersection over union (mIoU) of 34.90% and 41.26%, respectively,; while the performance for the first 30 slices per volume achieved an OA and mIoU of 55.10% and 71.46%, respectively. Full article
(This article belongs to the Special Issue Computer Vision and Machine Learning for Medical Imaging System)
Open AccessCommunication
Design of a Microwave Power Detection System in the 5G-Communication Frequency Band
Sensors 2021, 21(8), 2674; https://doi.org/10.3390/s21082674 (registering DOI) - 10 Apr 2021
Viewed by 135
Abstract
At present, the proposed microwave power detection systems cannot provide a high dynamic detection range and measurement sensitivity at the same time. Additionally, the frequency band of these detection systems cannot cover the 5G-communication frequency band. In this work, a novel microwave power [...] Read more.
At present, the proposed microwave power detection systems cannot provide a high dynamic detection range and measurement sensitivity at the same time. Additionally, the frequency band of these detection systems cannot cover the 5G-communication frequency band. In this work, a novel microwave power detection system is proposed to measure the power of the 5G-communication frequency band. The detection system is composed of a signal receiving module, a power detection module and a data processing module. Experiments show that the detection frequency band of this system ranges from 1.4 GHz to 5.3 GHz, the dynamic measurement range is 70 dB, the minimum detection power is −68 dBm, and the sensitivity is 22.3 mV/dBm. Compared with other detection systems, the performance of this detection system in the 5G-communication frequency band is significantly improved. Therefore, this microwave power detection system has certain reference significance and application value in the microwave signal detection of 5G communication systems. Full article
(This article belongs to the Special Issue Advanced Interface Circuits for Sensor Systems)
Show Figures

Figure 1

Open AccessArticle
Optimization-Based Online Initialization and Calibration of Monocular Visual-Inertial Odometry Considering Spatial-Temporal Constraints
Sensors 2021, 21(8), 2673; https://doi.org/10.3390/s21082673 (registering DOI) - 10 Apr 2021
Viewed by 145
Abstract
The online system state initialization and simultaneous spatial-temporal calibration are critical for monocular Visual-Inertial Odometry (VIO) since these parameters are either not well provided or even unknown. Although impressive performance has been achieved, most of the existing methods are designed for filter-based VIOs. [...] Read more.
The online system state initialization and simultaneous spatial-temporal calibration are critical for monocular Visual-Inertial Odometry (VIO) since these parameters are either not well provided or even unknown. Although impressive performance has been achieved, most of the existing methods are designed for filter-based VIOs. For the optimization-based VIOs, there is not much online spatial-temporal calibration method in the literature. In this paper, we propose an optimization-based online initialization and spatial-temporal calibration method for VIO. The method does not need any prior knowledge about spatial and temporal configurations. It estimates the initial states of metric-scale, velocity, gravity, Inertial Measurement Unit (IMU) biases, and calibrates the coordinate transformation and time offsets between the camera and IMU sensors. The work routine of the method is as follows. First, it uses a time offset model and two short-term motion interpolation algorithms to align and interpolate the camera and IMU measurement data. Then, the aligned and interpolated results are sent to an incremental estimator to estimate the initial states and the spatial–temporal parameters. After that, a bundle adjustment is additionally included to improve the accuracy of the estimated results. Experiments using both synthetic and public datasets are performed to examine the performance of the proposed method. The results show that both the initial states and the spatial-temporal parameters can be well estimated. The method outperforms other contemporary methods used for comparison. Full article
(This article belongs to the Special Issue Inertial Sensor-Based Biomechanical Analysis)
Show Figures

Figure 1

Open AccessArticle
Comparison of Self-Reported and Device-Based Measured Physical Activity Using Measures of Stability, Reliability, and Validity in Adults and Children
Sensors 2021, 21(8), 2672; https://doi.org/10.3390/s21082672 (registering DOI) - 10 Apr 2021
Viewed by 158
Abstract
Quantification of physical activity (PA) depends on the type of measurement and analysis method making it difficult to compare adherence to PA guidelines. Therefore, test-retest reliability, validity, and stability for self-reported (i.e., questionnaire and diary) and device-based measured (i.e., accelerometry with 10/60 s [...] Read more.
Quantification of physical activity (PA) depends on the type of measurement and analysis method making it difficult to compare adherence to PA guidelines. Therefore, test-retest reliability, validity, and stability for self-reported (i.e., questionnaire and diary) and device-based measured (i.e., accelerometry with 10/60 s epochs) PA was compared in 32 adults and 32 children from the SMARTFAMILY study to examine if differences in these measurement tools are systematic. PA was collected during two separate measurement weeks and the relationship for each quality criteria was analyzed using Spearman correlation. Results showed the highest PA values for questionnaires followed by 10-s and 60-s epochs measured by accelerometers. Levels of PA were lowest when measured by diary. Only accelerometry demonstrated reliable, valid, and stable results for the two measurement weeks, the questionnaire yielded mixed results and the diary showed only a few significant correlations. Overall, higher correlations for the quality criteria were found for moderate than for vigorous PA and the results differed between children and adults. Since the differences were not found to be systematic, the choice of measurement tools should be carefully considered by anyone working with PA outcomes, especially if vigorous PA is the parameter of interest. Full article
(This article belongs to the Special Issue Sensor-Based Information for Personalized Exercise and Training)
Show Figures

Figure 1

Open AccessCommunication
Electrochemical DNA Biosensor That Detects Early Celiac Disease Autoantibodies
Sensors 2021, 21(8), 2671; https://doi.org/10.3390/s21082671 (registering DOI) - 10 Apr 2021
Viewed by 222
Abstract
Although it is estimated that more than one million Americans have celiac disease (CD), it remains challenging to diagnose. CD, an autoimmune and inflammatory response following the ingestion of gluten-containing foods, has symptoms overlapping with other diseases and requires invasive diagnostics. The gold [...] Read more.
Although it is estimated that more than one million Americans have celiac disease (CD), it remains challenging to diagnose. CD, an autoimmune and inflammatory response following the ingestion of gluten-containing foods, has symptoms overlapping with other diseases and requires invasive diagnostics. The gold standard for CD diagnosis involves serologic blood tests followed by invasive confirmatory biopsies. Here, we propose a less invasive method using an electrochemical DNA (E-DNA) biosensor for CD-specific autoantibodies (AABs) circulating in blood. In our approach, CD-specific AABs bind a synthetic neoepitope, causing a conformational change in the biosensor, as well as a change in the environment of an attached redox reporter, producing a measurable current reduction. We assessed the biosensor’s ability to detect CD-specific patient-derived AABs in physiological buffer as well as buffer supplemented with bovine serum. Our biosensor was able to detect AABs in a dose-dependent manner; increased signal change correlated with increased AAB concentration with an apparent dissociation constant of 0.09 ± 0.03 units/mL of AABs. Furthermore, we found our biosensor to be target-specific, with minimal off-target binding of multiple unrelated biomarkers. Future efforts aimed at increasing sensitivity in complex media may build upon the biosensor design presented here to further improve CD AAB detection and CD diagnostic tools. Full article
(This article belongs to the Section Biosensors)
Show Figures

Figure 1

Open AccessArticle
Towards Tracking of Deep Brain Stimulation Electrodes Using an Integrated Magnetometer
Sensors 2021, 21(8), 2670; https://doi.org/10.3390/s21082670 (registering DOI) - 10 Apr 2021
Viewed by 208
Abstract
This paper presents a tracking system using magnetometers, possibly integrable in a deep brain stimulation (DBS) electrode. DBS is a treatment for movement disorders where the position of the implant is of prime importance. Positioning challenges during the surgery could be addressed thanks [...] Read more.
This paper presents a tracking system using magnetometers, possibly integrable in a deep brain stimulation (DBS) electrode. DBS is a treatment for movement disorders where the position of the implant is of prime importance. Positioning challenges during the surgery could be addressed thanks to a magnetic tracking. The system proposed in this paper, complementary to existing procedures, has been designed to bridge preoperative clinical imaging with DBS surgery, allowing the surgeon to increase his/her control on the implantation trajectory. Here the magnetic source required for tracking consists of three coils, and is experimentally mapped. This mapping has been performed with an in-house three-dimensional magnetic camera. The system demonstrates how magnetometers integrated directly at the tip of a DBS electrode, might improve treatment by monitoring the position during and after the surgery. The three-dimensional operation without line of sight has been demonstrated using a reference obtained with magnetic resonance imaging (MRI) of a simplified brain model. We observed experimentally a mean absolute error of 1.35 mm and an Euclidean error of 3.07 mm. Several areas of improvement to target errors below 1 mm are also discussed. Full article
Show Figures

Figure 1

Open AccessCommunication
Designing Mid-Infrared Gold-Based Plasmonic Slot Waveguides for CO2-Sensing Applications
Sensors 2021, 21(8), 2669; https://doi.org/10.3390/s21082669 (registering DOI) - 10 Apr 2021
Viewed by 189
Abstract
Plasmonic slot waveguides have attracted much attention due to the possibility of high light confinement, although they suffer from relatively high propagation loss originating from the presence of a metal. Although the tightly confined light in a small gap leads to a high [...] Read more.
Plasmonic slot waveguides have attracted much attention due to the possibility of high light confinement, although they suffer from relatively high propagation loss originating from the presence of a metal. Although the tightly confined light in a small gap leads to a high confinement factor, which is crucial for sensing applications, the use of plasmonic guiding at the same time results in a low propagation length. Therefore, the consideration of a trade-off between the confinement factor and the propagation length is essential to optimize the waveguide geometries. Using silicon nitride as a platform as one of the most common material systems, we have investigated free-standing and asymmetric gold-based plasmonic slot waveguides designed for sensing applications. A new figure of merit (FOM) is introduced to optimize the waveguide geometries for a wavelength of 4.26 µm corresponding to the absorption peak of CO2, aiming at the enhancement of the confinement factor and propagation length simultaneously. For the free-standing structure, the achieved FOM is 274.6 corresponding to approximately 42% and 868 µm for confinement factor and propagation length, respectively. The FOM for the asymmetric structure shows a value of 70.1 which corresponds to 36% and 264 µm for confinement factor and propagation length, respectively. Full article
(This article belongs to the Special Issue Mid-Infrared Sensors and Applications)
Show Figures

Figure 1

Open AccessArticle
Load Resistance Optimization of a Magnetically Coupled Two-Degree-Of-Freedom Bistable Energy Harvester Considering Third-Harmonic Distortion in Forced Oscillation
Sensors 2021, 21(8), 2668; https://doi.org/10.3390/s21082668 (registering DOI) - 10 Apr 2021
Viewed by 172
Abstract
In this study, the external load resistance of a magnetically coupled two-degree-of-freedom bistable energy harvester (2-DOF MCBEH) was optimized to maximize the harvested power output, considering the third-harmonic distortion in forced response. First, the nonlinear dynamic analysis was performed to investigate the characteristics [...] Read more.
In this study, the external load resistance of a magnetically coupled two-degree-of-freedom bistable energy harvester (2-DOF MCBEH) was optimized to maximize the harvested power output, considering the third-harmonic distortion in forced response. First, the nonlinear dynamic analysis was performed to investigate the characteristics of the large-amplitude interwell motions of the 2-DOF MCBEH. From the analysis results, it was found that the third-harmonic distortion occurs in the interwell motion of the 2-DOF MCBEH system due to the nonlinear magnetic coupling between the beams. Thus, in this study, the third-harmonic distortion was considered in the optimization process of the external load resistance of the 2-DOF MCBEH, which is different from the process of conventional impedance matching techniques suitable for linear systems. The optimal load resistances were estimated for harmonic and swept-sine excitations by using the proposed method, and all the results of the power outputs were in excellent agreements with the numerically optimized results. Furthermore, the associated power outputs were compared with the power outputs obtained by using the conventional impedance matching technique. The results of the power outputs are discussed in terms of the improvement in energy harvesting performance. Full article
(This article belongs to the Collection Energy Harvesting Sensors)
Show Figures

Figure 1

Open AccessReview
A Systematic Review of Commercial Smart Gloves: Current Status and Applications
Sensors 2021, 21(8), 2667; https://doi.org/10.3390/s21082667 (registering DOI) - 10 Apr 2021
Viewed by 180
Abstract
Smart gloves have been under development during the last 40 years to support human-computer interaction based on hand and finger movement. Despite the many devoted efforts and the multiple advances in related areas, these devices have not become mainstream yet. Nevertheless, during recent [...] Read more.
Smart gloves have been under development during the last 40 years to support human-computer interaction based on hand and finger movement. Despite the many devoted efforts and the multiple advances in related areas, these devices have not become mainstream yet. Nevertheless, during recent years, new devices with improved features have appeared, being used for research purposes too. This paper provides a review of current commercial smart gloves focusing on three main capabilities: (i) hand and finger pose estimation and motion tracking, (ii) kinesthetic feedback, and (iii) tactile feedback. For the first capability, a detailed reference model of the hand and finger basic movements (known as degrees of freedom) is proposed. Based on the PRISMA guidelines for systematic reviews for the period 2015–2021, 24 commercial smart gloves have been identified, while many others have been discarded because they did not meet the inclusion criteria: currently active commercial and fully portable smart gloves providing some of the three main capabilities for the whole hand. The paper reviews the technologies involved, main applications and it discusses about the current state of development. Reference models to support end users and researchers comparing and selecting the most appropriate devices are identified as a key need. Full article
(This article belongs to the Special Issue Applications of Body Worn Sensors and Wearables)
Open AccessReview
Non-Technical Skill Assessment and Mental Load Evaluation in Robot-Assisted Minimally Invasive Surgery
Sensors 2021, 21(8), 2666; https://doi.org/10.3390/s21082666 (registering DOI) - 10 Apr 2021
Viewed by 209
Abstract
BACKGROUND: Sensor technologies and data collection practices are changing and improving quality metrics across various domains. Surgical skill assessment in Robot-Assisted Minimally Invasive Surgery (RAMIS) is essential for training and quality assurance. The mental workload on the surgeon (such as time criticality, task [...] Read more.
BACKGROUND: Sensor technologies and data collection practices are changing and improving quality metrics across various domains. Surgical skill assessment in Robot-Assisted Minimally Invasive Surgery (RAMIS) is essential for training and quality assurance. The mental workload on the surgeon (such as time criticality, task complexity, distractions) and non-technical surgical skills (including situational awareness, decision making, stress resilience, communication, leadership) may directly influence the clinical outcome of the surgery. METHODS: A literature search in PubMed, Scopus and PsycNet databases was conducted for relevant scientific publications. The standard PRISMA method was followed to filter the search results, including non-technical skill assessment and mental/cognitive load and workload estimation in RAMIS. Publications related to traditional manual Minimally Invasive Surgery were excluded, and also the usability studies on the surgical tools were not assessed. RESULTS: 50 relevant publications were identified for non-technical skill assessment and mental load and workload estimation in the domain of RAMIS. The identified assessment techniques ranged from self-rating questionnaires and expert ratings to autonomous techniques, citing their most important benefits and disadvantages. CONCLUSIONS: Despite the systematic research, only a limited number of articles was found, indicating that non-technical skill and mental load assessment in RAMIS is not a well-studied area. Workload assessment and soft skill measurement do not constitute part of the regular clinical training and practice yet. Meanwhile, the importance of the research domain is clear based on the publicly available surgical error statistics. Questionnaires and expert-rating techniques are widely employed in traditional surgical skill assessment; nevertheless, recent technological development in sensors and Internet of Things-type devices show that skill assessment approaches in RAMIS can be much more profound employing automated solutions. Measurements and especially big data type analysis may introduce more objectivity and transparency to this critical domain as well. SIGNIFICANCE: Non-technical skill assessment and mental load evaluation in Robot-Assisted Minimally Invasive Surgery is not a well-studied area yet; while the importance of this domain from the clinical outcome’s point of view is clearly indicated by the available surgical error statistics. Full article
(This article belongs to the Special Issue Medical Robotics)
Open AccessArticle
Self-Powered Point-Of-Care Device for Galvanic Cell-Based Sample Concentration Measurement
Sensors 2021, 21(8), 2665; https://doi.org/10.3390/s21082665 (registering DOI) - 10 Apr 2021
Viewed by 158
Abstract
A novel self-powered point-of-care low-power electronics approach for galvanic cell-based sample concentration measurement is presented. The electronic system harvests and senses at the same time from the single cell. The system implements a solution that is suitable in those scenarios where extreme low [...] Read more.
A novel self-powered point-of-care low-power electronics approach for galvanic cell-based sample concentration measurement is presented. The electronic system harvests and senses at the same time from the single cell. The system implements a solution that is suitable in those scenarios where extreme low power is generated from the fuel cell. The proposed approach implements a capacitive-based method to perform a non-linear sweep voltammetry to the cell, but without the need to implement a potentiostat amplifier for that purpose. It provides a digital-user readable result without the need for external non-self-powered devices or instruments compared with other solutions. The system conception was validated for a particular case. The scenario consisted of the measurement of a NaCl solution as the electrolyte, which was related to the conductivity of the sample. The electronic reader continuously measured the current with a transfer function gain of 1.012V/mA. The overall system exhibited a maximum coefficient of variation of 6.1, which was an improvement compared with the state-of-the-art. The proof of concept of this electronics system was validated with a maximum power consumption of 5.8W using commercial-off-the-self parts. Full article
(This article belongs to the Special Issue Self-Powered Sensor)
Open AccessArticle
Autonomous Marine Robot Based on AI Recognition for Permanent Surveillance in Marine Protected Areas
Sensors 2021, 21(8), 2664; https://doi.org/10.3390/s21082664 (registering DOI) - 10 Apr 2021
Viewed by 237
Abstract
The world’s oceans are one of the most valuable sources of biodiversity and resources on the planet, although there are areas where the marine ecosystem is threatened by human activities. Marine protected areas (MPAs) are distinctive spaces protected by law due to their [...] Read more.
The world’s oceans are one of the most valuable sources of biodiversity and resources on the planet, although there are areas where the marine ecosystem is threatened by human activities. Marine protected areas (MPAs) are distinctive spaces protected by law due to their unique characteristics, such as being the habitat of endangered marine species. Even with this protection, there are still illegal activities such as poaching or anchoring that threaten the survival of different marine species. In this context, we propose an autonomous surface vehicle (ASV) model system for the surveillance of marine areas by detecting and recognizing vessels through artificial intelligence (AI)-based image recognition services, in search of those carrying out illegal activities. Cloud and edge AI computing technologies were used for computer vision. These technologies have proven to be accurate and reliable in detecting shapes and objects for which they have been trained. Azure edge and cloud vision services offer the best option in terms of accuracy for this task. Due to the lack of 4G and 5G coverage in offshore marine environments, it is necessary to use radio links with a coastal base station to ensure communications, which may result in a high response time due to the high latency involved. The analysis of on-board images may not be sufficiently accurate; therefore, we proposed a smart algorithm for autonomy optimization by selecting the proper AI technology according to the current scenario (SAAO) capable of selecting the best AI source for the current scenario in real time, according to the required recognition accuracy or low latency. The SAAO optimizes the execution, efficiency, risk reduction, and results of each stage of the surveillance mission, taking appropriate decisions by selecting either cloud or edge vision models without human intervention. Full article
(This article belongs to the Special Issue Intelligent Sensing Systems for Vehicle)
Open AccessArticle
Ultra-Low-Power Wide Range Backscatter Communication Using Cellular Generated Carrier
Sensors 2021, 21(8), 2663; https://doi.org/10.3390/s21082663 (registering DOI) - 10 Apr 2021
Viewed by 199
Abstract
With the popularization of Internet-of-things (IoT) and wireless communication systems, a diverse set of applications in smart cities are emerging to improve the city-life. These applications usually require a large coverage area and minimal operation and maintenance cost. To this end, the recently [...] Read more.
With the popularization of Internet-of-things (IoT) and wireless communication systems, a diverse set of applications in smart cities are emerging to improve the city-life. These applications usually require a large coverage area and minimal operation and maintenance cost. To this end, the recently emerging backscatter communication (BC) is gaining interest in both industry and academia as a new communication paradigm that provides high energy efficient communications that may even work in a battery-less mode and, thus, it is well suited for smart city applications. However, the coverage of BC in urban area deployments is not available, and the feasibility of its utilization for smart city applications is not known. In this article, we present a comprehensive coverage study of a practical cellular carrier-based BC system for indoor and outdoor scenarios in a downtown area of a Helsinki city. In particular, we evaluate the coverage outage performance of different low-power and wide area technologies, i.e., long range (LoRa) backscatter, arrow band-Internet of Things (NB-IoT), and Bluetooth low energy (BLE) based BC at different frequencies of operation. To do so, we carry out a comprehensive campaign of simulations while using a sophisticated three-dimensional (3D) ray tracing (RT) tool, ITU outdoor model, and 3rd generation partnership project (3GPP) indoor hotspot model. This study also covers the energy harvesting aspects of backscatter device, and it highlights the importance of future backscatter devices with high energy harvesting efficiency. The simulation results and discussion provided in this article will be helpful in understanding the coverage aspects of practical backscatter communication system in a smart city environment. Full article
(This article belongs to the Special Issue Wireless Sensor Networks and IoT for Smart Cities)
Previous Issue
Back to TopTop
