Sensors, Volume 20, Issue 9 (May-1 2020) – 310 articles

  • Issues are regarded as officially published after their release is announced to the table of contents alert mailing list.
  • You may sign up for e-mail alerts to receive table of contents of newly released issues.
  • PDF is the official format for papers published in both, html and pdf forms. To view the papers in pdf format, click on the "PDF Full-text" link, and use the free Adobe Readerexternal link to open them.
Cover Story (view full-size image) This article presents the development of a stretchable sensor network for real-time distributed [...] Read more.
Order results
Result details
Select all
Export citation of selected articles as:
Open AccessArticle
High Precision Positioning with Multi-Camera Setups: Adaptive Kalman Fusion Algorithm for Fiducial Markers
Sensors 2020, 20(9), 2746; https://doi.org/10.3390/s20092746 - 11 May 2020
Viewed by 477
Abstract
The paper addresses the problem of fusing the measurements from multiple cameras in order to estimate the position of fiducial markers. The objectives are to increase the precision and to extend the working area of the system. The proposed fusion method employs an [...] Read more.
The paper addresses the problem of fusing the measurements from multiple cameras in order to estimate the position of fiducial markers. The objectives are to increase the precision and to extend the working area of the system. The proposed fusion method employs an adaptive Kalman algorithm which is used for calibrating the setup of cameras as well as for estimating the pose of the marker. Special measures are taken in order to mitigate the effect of the measurement noise. The proposed method is further tested in different scenarios using a Monte Carlo simulation, whose qualitative precision results are determined and compared. The solution is designed for specific positioning and alignment tasks in physics experiments, but also, has a degree of generality that makes it suitable for a wider range of applications. Full article
Show Figures

Graphical abstract

Open AccessReview
Photoacoustic-Based Gas Sensing: A Review
Sensors 2020, 20(9), 2745; https://doi.org/10.3390/s20092745 - 11 May 2020
Viewed by 458
Abstract
The use of the photoacoustic effect to gauge the concentration of gases is an attractive alternative in the realm of optical detection methods. Even though the effect has been applied for gas sensing for almost a century, its potential for ultra-sensitive and miniaturized [...] Read more.
The use of the photoacoustic effect to gauge the concentration of gases is an attractive alternative in the realm of optical detection methods. Even though the effect has been applied for gas sensing for almost a century, its potential for ultra-sensitive and miniaturized devices is still not fully explored. This review article revisits two fundamentally different setups commonly used to build photoacoustic-based gas sensors and presents some distinguished results in terms of sensitivity, ultra-low detection limits, and miniaturization. The review contrasts the two setups in terms of the respective possibilities to tune the selectivity, sensitivity, and potential for miniaturization. Full article
(This article belongs to the Special Issue Optical Spectroscopy, Sensing, and Imaging from UV to THz Range)
Show Figures

Graphical abstract

Open AccessArticle
Compressive Sensing Approach to Harmonics Detection in the Ship Electrical Network
Sensors 2020, 20(9), 2744; https://doi.org/10.3390/s20092744 - 11 May 2020
Viewed by 349
Abstract
The contribution of this paper is to show the opportunities for using the compressive sensing (CS) technique for detecting harmonics in a frequency sparse signal. The signal in a ship’s electrical network, polluted by harmonic distortions, can be modeled as a superposition of [...] Read more.
The contribution of this paper is to show the opportunities for using the compressive sensing (CS) technique for detecting harmonics in a frequency sparse signal. The signal in a ship’s electrical network, polluted by harmonic distortions, can be modeled as a superposition of a small number of sinusoids and the discrete Fourier transform (DFT) basis forms its sparse domain. According to the theory of CS, a signal may be reconstructed from under-sampled incoherent linear measurements. This paper highlights the use of the discrete Radon transform (DRT) techniques in the CS scheme. In the reconstruction algorithm section, a fast algorithm based on the inverse DRT is presented, in which a few randomly sampled projections of the input signal are used to correctly reconstruct the original signal. However, DRT requires a very large set of measurements that can defeat the purpose of compressive data acquisition. To acquire the wideband data below the Nyquist frequency, the K-rank-order filter is applied in the sparse transform domain to extract the most significant components and accelerate the convergence of the solution. While most CS research efforts focus on random Gaussian measurements, the Bernoulli matrix with different values of the probability of ones is applied in the presented algorithm. Preliminary results of numerical simulation confirm the effectiveness of the algorithm used, but also indicate its limitations. A significant advantage of the proposed approach is the speed of analysis, which uses fast Fourier transform (FFT) and inverse FFT (IFFT) algorithms widely available in programming environments. Moreover, the data processing algorithm is quite simple, and therefore memory usage and burden of the data processing load are relatively low. Full article
Show Figures

Figure 1

Open AccessArticle
Deep Color Transfer for Color-Plus-Mono Dual Cameras
Sensors 2020, 20(9), 2743; https://doi.org/10.3390/s20092743 - 11 May 2020
Viewed by 373
Abstract
A few approaches have studied image fusion using color-plus-mono dual cameras to improve the image quality in low-light shooting. Among them, the color transfer approach, which transfers the color information of a color image to a mono image, is considered to be promising [...] Read more.
A few approaches have studied image fusion using color-plus-mono dual cameras to improve the image quality in low-light shooting. Among them, the color transfer approach, which transfers the color information of a color image to a mono image, is considered to be promising for obtaining improved images with less noise and more detail. However, the color transfer algorithms rely heavily on appropriate color hints from a given color image. Unreliable color hints caused by errors in stereo matching of a color-plus-mono image pair can generate various visual artifacts in the final fused image. This study proposes a novel color transfer method that seeks reliable color hints from a color image and colorizes a corresponding mono image with reliable color hints that are based on a deep learning model. Specifically, a color-hint-based mask generation algorithm is developed to obtain reliable color hints. It removes unreliable color pixels using a reliability map computed by the binocular just-noticeable-difference model. In addition, a deep colorization network that utilizes structural information is proposed for solving the color bleeding artifact problem. The experimental results demonstrate that the proposed method provides better results than the existing image fusion algorithms for dual cameras. Full article
(This article belongs to the Section Optical Sensors)
Show Figures

Figure 1

Open AccessArticle
Lead-Wire-Resistance Compensation Technique Using a Single Zener Diode for Two-Wire Resistance Temperature Detectors (RTDs)
Sensors 2020, 20(9), 2742; https://doi.org/10.3390/s20092742 - 11 May 2020
Viewed by 307
Abstract
In remote measurement systems, the lead wire resistance of the resistance sensor will produce a large measurement error. In order to ensure the accuracy of remote measurement, a novel lead-wire-resistance compensation technique is proposed, which is suitable for a two-wire resistance temperature detector. [...] Read more.
In remote measurement systems, the lead wire resistance of the resistance sensor will produce a large measurement error. In order to ensure the accuracy of remote measurement, a novel lead-wire-resistance compensation technique is proposed, which is suitable for a two-wire resistance temperature detector. By connecting a zener diode in parallel with the resistance temperature detector (RTD) and an interface circuit specially designed for it, the lead-wire-resistance value can be accurately measured by virtue of the constant voltage characteristic of the zener diode when reverse breakdown occurs, and compensation can thereby be made when calculating the resistance of RTD. Through simulation verification and practical circuit testing, when the sensor resistance is in 848–2120 Ω scope and the lead wire resistance is less than 50 Ω, the proposed technology can ensure the measuring error of the sensor resistance within ±1 Ω and the temperature measurement error within ±0.3 °C for RTDs performing 1000 Ω at 0 °C. Therefore, this method is able to accurately compensate the measurement error caused by the lead wire resistance in two-wire RTDsand is suitable for most applications. Full article
(This article belongs to the Section Remote Sensors)
Show Figures

Figure 1

Open AccessArticle
Development of Novel Real-Time Radiation Systems Using 4-Channel Sensors
Sensors 2020, 20(9), 2741; https://doi.org/10.3390/s20092741 - 11 May 2020
Viewed by 290
Abstract
Radiation-related tissue injuries after medical radiation procedures, such as fluoroscopically guided intervention (FGI), have been reported in patients. Real-time monitoring of medical radiation exposure administered to patients during FGI is important to avoid such tissue injuries. In our previous study, we reported a [...] Read more.
Radiation-related tissue injuries after medical radiation procedures, such as fluoroscopically guided intervention (FGI), have been reported in patients. Real-time monitoring of medical radiation exposure administered to patients during FGI is important to avoid such tissue injuries. In our previous study, we reported a novel (prototype) real-time radiation system for FGI. However, the prototype sensor indicated low sensitivity to radiation exposure from the side and back, although it had high-quality fundamental characteristics. Therefore, we developed a novel 4-channel sensor with modified shape and size than the previous sensor, and evaluated the basic performance (i.e., measured the energy, dose linearity, dose rate, and angular dependence) of the novel and previous sensors. Both sensors of our real-time dosimeter system demonstrated the low energy dependence, excellent dose linearity (R2 = 1.0000), and good dose rate dependence (i.e., within 5% statistical difference). Besides, the sensitivity of 0° ± 180° in the horizontal and vertical directions was almost 100% sensitivity for the new sensor, which significantly improved the angular dependence. Moreover, the novel dosimeter exerted less influence on X-ray images (fluoroscopy) than other sensors because of modifying a small shape and size. Therefore, the developed dosimeter system is expected to be useful for measuring the exposure of patients to radiation doses during FGI procedures. Full article
(This article belongs to the Special Issue Radiation-Hardened Sensors, Circuits and Systems)
Show Figures

Figure 1

Open AccessArticle
Using Complexity-Identical Human- and Machine-Directed Utterances to Investigate Addressee Detection for Spoken Dialogue Systems
Sensors 2020, 20(9), 2740; https://doi.org/10.3390/s20092740 - 11 May 2020
Viewed by 343
Abstract
Human-machine addressee detection (H-M AD) is a modern paralinguistics and dialogue challenge that arises in multiparty conversations between several people and a spoken dialogue system (SDS) since the users may also talk to each other and even to themselves while interacting with the [...] Read more.
Human-machine addressee detection (H-M AD) is a modern paralinguistics and dialogue challenge that arises in multiparty conversations between several people and a spoken dialogue system (SDS) since the users may also talk to each other and even to themselves while interacting with the system. The SDS is supposed to determine whether it is being addressed or not. All existing studies on acoustic H-M AD were conducted on corpora designed in such a way that a human addressee and a machine played different dialogue roles. This peculiarity influences speakers’ behaviour and increases vocal differences between human- and machine-directed utterances. In the present study, we consider the Restaurant Booking Corpus (RBC) that consists of complexity-identical human- and machine-directed phone calls and allows us to eliminate most of the factors influencing speakers’ behaviour implicitly. The only remaining factor is the speakers’ explicit awareness of their interlocutor (technical system or human being). Although complexity-identical H-M AD is essentially more challenging than the classical one, we managed to achieve significant improvements using data augmentation (unweighted average recall (UAR) = 0.628) over native listeners (UAR = 0.596) and a baseline classifier presented by the RBC developers (UAR = 0.539). Full article
(This article belongs to the Special Issue Multimodal Sensing for Understanding Behavior and Personality)
Show Figures

Figure 1

Open AccessArticle
An Efficient Data-Hiding Scheme Based on Multidimensional Mini-SuDoKu
Sensors 2020, 20(9), 2739; https://doi.org/10.3390/s20092739 - 11 May 2020
Viewed by 299
Abstract
The massive Internet of Things (IoT) connecting various types of intelligent sensors for goods tracking in logistics, environmental monitoring and smart grid management is a crucial future ICT. High-end security and low power consumption are major requirements in scaling up the IoT. In [...] Read more.
The massive Internet of Things (IoT) connecting various types of intelligent sensors for goods tracking in logistics, environmental monitoring and smart grid management is a crucial future ICT. High-end security and low power consumption are major requirements in scaling up the IoT. In this research, we propose an efficient data-hiding scheme to deal with the security problems and power saving issues of multimedia communication among IoT devises. Data hiding is the practice of hiding secret data into cover images in order to conceal and prevent secret data from being intercepted by malicious attackers. One of the established research streams of data-hiding methods is based on reference matrices (RM). In this study, we propose an efficient data-hiding scheme based on multidimensional mini-SuDoKu RM. The proposed RM possesses high complexity and can effectively improve the security of data hiding. In addition, this study also defines a range locator function which can significantly improve the embedding efficiency of multidimensional RM. Experimental results show that our data-hiding scheme can not only obtain better image quality, but also achieve higher embedding capacity than other related schemes. Full article
Show Figures

Figure 1

Open AccessArticle
A Rapid and Sensitive Salmonella Biosensor Based on Viscoelastic Inertial Microfluidics
Sensors 2020, 20(9), 2738; https://doi.org/10.3390/s20092738 - 11 May 2020
Viewed by 338
Abstract
Salmonella is a main cause of foodborne illnesses and rapid screening of Salmonella is the key to prevent Salmonella outbreaks, however available detection methods either require a long time, or need complex pretreatment, or have low sensitivity. In this study, a microfluidic biosensor [...] Read more.
Salmonella is a main cause of foodborne illnesses and rapid screening of Salmonella is the key to prevent Salmonella outbreaks, however available detection methods either require a long time, or need complex pretreatment, or have low sensitivity. In this study, a microfluidic biosensor was developed for Salmonella detection using viscoelastic inertial microfluidics for separating magnetic bacteria from unbound magnetic nanoparticles (MNPs) and enzyme catalytic colorimetry for amplifying biological signals. The polyclonal antibodies and horseradish peroxidase (HRP) modified MNPs were first used to specifically capture Salmonella to form magnetic HRP-bacteria. Both magnetic HRP-bacteria and unbound MNPs were magnetically separated from background and resuspended in viscoelastic polyvinylpyrrolidone solution as sample flow. When sample flow was injected with polyvinylpyrrolidone sheath flow into a T-shaped microchannel, larger-sized magnetic HRP-bacteria could penetrate the sample flow, however smaller-sized MNPs remained in the sample flow due to weaker inertial lift force and elastic lift force, resulting in continuous-flow separation of magnetic HRP-bacteria. Finally, magnetic HRP-bacteria were collected and concentrated to catalyze tetramethyl benzidine, and absorbance was measured to determine the bacteria. This biosensor was able to detect Salmonella as low as 30 CFU/mL in 1 h and featured the advantages of shorter time due to a one-step immunoreaction, easier extension due to only one antibody and one label, and lower cost due to less expensive materials. Full article
(This article belongs to the Special Issue Magnetic Sensing/Functionalized Devices and Applications)
Show Figures

Figure 1

Open AccessArticle
Explora: Interactive Querying of Multidimensional Data in the Context of Smart Cities
Sensors 2020, 20(9), 2737; https://doi.org/10.3390/s20092737 - 11 May 2020
Viewed by 489
Abstract
Citizen engagement is one of the key factors for smart city initiatives to remain sustainable over time. This in turn entails providing citizens and other relevant stakeholders with the latest data and tools that enable them to derive insights that add value to [...] Read more.
Citizen engagement is one of the key factors for smart city initiatives to remain sustainable over time. This in turn entails providing citizens and other relevant stakeholders with the latest data and tools that enable them to derive insights that add value to their day-to-day life. The massive volume of data being constantly produced in these smart city environments makes satisfying this requirement particularly challenging. This paper introduces Explora, a generic framework for serving interactive low-latency requests, typical of visual exploratory applications on spatiotemporal data, which leverages the stream processing for deriving—on ingestion time—synopsis data structures that concisely capture the spatial and temporal trends and dynamics of the sensed variables and serve as compacted data sets to provide fast (approximate) answers to visual queries on smart city data. The experimental evaluation conducted on proof-of-concept implementations of Explora, based on traditional database and distributed data processing setups, accounts for a decrease of up to 2 orders of magnitude in query latency compared to queries running on the base raw data at the expense of less than 10% query accuracy and 30% data footprint. The implementation of the framework on real smart city data along with the obtained experimental results prove the feasibility of the proposed approach. Full article
(This article belongs to the Special Issue Air Quality and Sensor Networks)
Show Figures

Figure 1

Open AccessArticle
A PCB Alignment System Using RST Template Matching with CUDA on Embedded GPU Board
Sensors 2020, 20(9), 2736; https://doi.org/10.3390/s20092736 - 11 May 2020
Viewed by 277
Abstract
The fiducial-marks-based alignment process is one of the most critical steps in printed circuit board (PCB) manufacturing. In the alignment process, a machine vision technique is used to detect the fiducial marks and then adjust the position of the vision system in such [...] Read more.
The fiducial-marks-based alignment process is one of the most critical steps in printed circuit board (PCB) manufacturing. In the alignment process, a machine vision technique is used to detect the fiducial marks and then adjust the position of the vision system in such a way that it is aligned with the PCB. The present study proposed an embedded PCB alignment system, in which a rotation, scale and translation (RST) template-matching algorithm was employed to locate the marks on the PCB surface. The coordinates and angles of the detected marks were then compared with the reference values which were set by users, and the difference between them was used to adjust the position of the vision system accordingly. To improve the positioning accuracy, the angle and location matching process was performed in refinement processes. To overcome the matching time, in the present study we accelerated the rotation matching by eliminating the weak features in the scanning process and converting the normalized cross correlation (NCC) formula to a sum of products. Moreover, the scanning time was reduced by implementing the entire RST process in parallel on threads of a graphics processing unit (GPU) by applying hash functions to find refined positions in the refinement matching process. The experimental results showed that the resulting matching time was around 32× faster than that achieved on a conventional central processing unit (CPU) for a test image size of 1280 × 960 pixels. Furthermore, the precision of the alignment process achieved a considerable result with a tolerance of 36.4 μm. Full article
Show Figures

Figure 1

Open AccessArticle
Array Diagnosis and DOA Estimation for Coprime Array under Sensor Failures
Sensors 2020, 20(9), 2735; https://doi.org/10.3390/s20092735 - 11 May 2020
Viewed by 285
Abstract
A coprime array of N sensors can achieve O ( N 2 ) degrees of freedom (DOFs) by possessing a uniform linear array segment of size O ( N 2 ) in the difference coarray. However, the structure of difference coarray is sensitive [...] Read more.
A coprime array of N sensors can achieve O ( N 2 ) degrees of freedom (DOFs) by possessing a uniform linear array segment of size O ( N 2 ) in the difference coarray. However, the structure of difference coarray is sensitive to sensor failures. Once the sensor fails, the impact of failure sensors on the coarray structure may decrease the DOFs and cause direction finding failure. Therefore, the direction of arrival (DOA) estimation of coprime arrays with sensor failures is a significant but challenging topic for investigation. Driven by the need for remedial measures, an efficient detection strategy is developed to diagnose the coprime array. Furthermore, based on the difference coarray, we divide the sensor failures into two scenarios. For redundant sensor failure scenarios, the structure of difference coarray remains unchanged, and the coarray MUSIC (CO-MUSIC) algorithm is applied for DOA estimation. For non-redundant sensor failure scenarios, the consecutive lags of the difference coarray will contain holes, which hinder the application of CO-MUSIC. We employ Singular Value Thresholding (SVT) algorithm to fill the holes with covariance matrix reconstruction. Specifically, the covariance matrix is reconstructed into a matrix with zero elements, and the SVT algorithm is employed to perform matrix completion, thereby filling the holes. Finally, we employ root-MUSIC for DOA estimation. Simulation results verify the effectiveness of the proposed methods. Full article
Show Figures

Figure 1

Open AccessArticle
Identification of Risk Factors Associated with Obesity and Overweight—A Machine Learning Overview
Sensors 2020, 20(9), 2734; https://doi.org/10.3390/s20092734 - 11 May 2020
Viewed by 528
Abstract
Social determining factors such as the adverse influence of globalization, supermarket growth, fast unplanned urbanization, sedentary lifestyle, economy, and social position slowly develop behavioral risk factors in humans. Behavioral risk factors such as unhealthy habits, improper diet, and physical inactivity lead to physiological [...] Read more.
Social determining factors such as the adverse influence of globalization, supermarket growth, fast unplanned urbanization, sedentary lifestyle, economy, and social position slowly develop behavioral risk factors in humans. Behavioral risk factors such as unhealthy habits, improper diet, and physical inactivity lead to physiological risks, and “obesity/overweight” is one of the consequences. “Obesity and overweight” are one of the major lifestyle diseases that leads to other health conditions, such as cardiovascular diseases (CVDs), chronic obstructive pulmonary disease (COPD), cancer, diabetes type II, hypertension, and depression. It is not restricted within the age and socio-economic background of human beings. The “World Health Organization” (WHO) has anticipated that 30% of global death will be caused by lifestyle diseases by 2030 and it can be prevented with the appropriate identification of associated risk factors and behavioral intervention plans. Health behavior change should be given priority to avoid life-threatening damages. The primary purpose of this study is not to present a risk prediction model but to provide a review of various machine learning (ML) methods and their execution using available sample health data in a public repository related to lifestyle diseases, such as obesity, CVDs, and diabetes type II. In this study, we targeted people, both male and female, in the age group of >20 and <60, excluding pregnancy and genetic factors. This paper qualifies as a tutorial article on how to use different ML methods to identify potential risk factors of obesity/overweight. Although institutions such as “Center for Disease Control and Prevention (CDC)” and “National Institute for Clinical Excellence (NICE)” guidelines work to understand the cause and consequences of overweight/obesity, we aimed to utilize the potential of data science to assess the correlated risk factors of obesity/overweight after analyzing the existing datasets available in “Kaggle” and “University of California, Irvine (UCI) database”, and to check how the potential risk factors are changing with the change in body-energy imbalance with data-visualization techniques and regression analysis. Analyzing existing obesity/overweight related data using machine learning algorithms did not produce any brand-new risk factors, but it helped us to understand: (a) how are identified risk factors related to weight change and how do we visualize it? (b) what will be the nature of the data (potential monitorable risk factors) to be collected over time to develop our intended eCoach system for the promotion of a healthy lifestyle targeting “obesity and overweight” as a study case in the future? (c) why have we used the existing “Kaggle” and “UCI” datasets for our preliminary study? (d) which classification and regression models are performing better with a corresponding limited volume of the dataset following performance metrics? Full article
(This article belongs to the Section Intelligent Sensors)
Show Figures

Figure 1

Open AccessArticle
Identifying Informal Settlements Using Contourlet Assisted Deep Learning
Sensors 2020, 20(9), 2733; https://doi.org/10.3390/s20092733 - 11 May 2020
Viewed by 423
Abstract
As the global urban population grows due to the influx of migrants from rural areas, many cities in developing countries face the emergence and proliferation of unplanned and informal settlements. However, even though the rise of unplanned development influences planning and management of [...] Read more.
As the global urban population grows due to the influx of migrants from rural areas, many cities in developing countries face the emergence and proliferation of unplanned and informal settlements. However, even though the rise of unplanned development influences planning and management of residential land-use, reliable and detailed information about these areas is often scarce. While formal settlements in urban areas are easily mapped due to their distinct features, this does not hold true for informal settlements because of their microstructure, instability, and variability of shape and texture. Therefore, detecting and mapping these areas remains a challenging task. This research will contribute to the development of tools to identify such informal built-up areas by using an integrated approach of multiscale deep learning. The authors propose a composite architecture for semantic segmentation using the U-net architecture aided by information obtained from a multiscale contourlet transform. This work also analyzes the effects of wavelet and contourlet decompositions in the U-net architecture. The performance was evaluated in terms of precision, recall, F-score, mean intersection over union, and overall accuracy. It was found that the proposed method has better class-discriminating power as compared to existing methods and has an overall classification accuracy of 94.9–95.7%. Full article
(This article belongs to the Special Issue Artificial Intelligence for 3D Big Spatial Data Processing)
Show Figures

Figure 1

Open AccessArticle
Examination of Multi-Receiver GPS/EGNOS Positioning with Kalman Filtering and Validation Based on CORS Stations
Sensors 2020, 20(9), 2732; https://doi.org/10.3390/s20092732 - 11 May 2020
Viewed by 321
Abstract
This paper presents the concept of precise navigation based on SBAS technology and CORS stations. In a kinematic test, three rover Global Positioning System (GPS) receivers, properly spaced relatively to each other, were used in order to estimate reliable and redundant GPS/EGNOS positions. [...] Read more.
This paper presents the concept of precise navigation based on SBAS technology and CORS stations. In a kinematic test, three rover Global Positioning System (GPS) receivers, properly spaced relatively to each other, were used in order to estimate reliable and redundant GPS/EGNOS positions. Next, the Kalman filter was employed to give the final solution. It was proven that EGNOS positioning allows to obtain an accuracy in the range of about 0.5–1.5 m. The proposed solution involving the use of three mobile receivers and Kalman filtering allowed to reduce the 3D error to a level below 0.3 m. Such an accuracy was achieved using only GPS L1 code observations and EGNOS corrections. Additionally, a reliable monitoring of quality of GPS/EGNOS positioning in the test area based on CORS stations was presented. Full article
(This article belongs to the Special Issue GNSS Sensors in Aerial Navigation)
Show Figures

Figure 1

Open AccessArticle
3DLRA: An RFID 3D Indoor Localization Method Based on Deep Learning
Sensors 2020, 20(9), 2731; https://doi.org/10.3390/s20092731 - 11 May 2020
Viewed by 333
Abstract
As the core supporting technology of the Internet of Things, Radio Frequency Identification (RFID) technology is rapidly popularized in the fields of intelligent transportation, logistics management, industrial automation, and the like, and has great development potential due to its fast and efficient data [...] Read more.
As the core supporting technology of the Internet of Things, Radio Frequency Identification (RFID) technology is rapidly popularized in the fields of intelligent transportation, logistics management, industrial automation, and the like, and has great development potential due to its fast and efficient data collection ability. RFID technology is widely used in the field of indoor localization, in which three-dimensional location can obtain more real and specific target location information. Aiming at the existing three-dimensional location scheme based on RFID, this paper proposes a new three-dimensional localization method based on deep learning: combining RFID absolute location with relative location, analyzing the variation characteristics of the received signal strength (RSSI) and Phase, further mining data characteristics by deep learning, and applying the method to the smart library scene. The experimental results show that the method has a higher location accuracy and better system stability. Full article
(This article belongs to the Section Sensor Networks)
Show Figures

Figure 1

Open AccessArticle
Wavelet-Like Transform to Optimize the Order of an Autoregressive Neural Network Model to Predict the Dissolved Gas Concentration in Power Transformer Oil from Sensor Data
Sensors 2020, 20(9), 2730; https://doi.org/10.3390/s20092730 - 11 May 2020
Viewed by 305
Abstract
Dissolved gas analysis (DGA) is one of the most important methods to analyze fault in power transformers. In general, DGA is applied in monitoring systems based upon an autoregressive model; the current value of a time series is regressed on past values of [...] Read more.
Dissolved gas analysis (DGA) is one of the most important methods to analyze fault in power transformers. In general, DGA is applied in monitoring systems based upon an autoregressive model; the current value of a time series is regressed on past values of the same series, as well as present and past values of some exogenous variables. The main difficulty is to decide the order of the autoregressive model; this means determining the number of past values to be used. This study proposes a wavelet-like transform to optimize the order of the variables in a nonlinear autoregressive neural network to predict the in oil dissolved gas concentration (DGC) from sensor data. Daubechies wavelets of different lengths are used to create representations with different time delays of ten DGC, which are then subjected to a procedure based on principal components analysis (PCA) and Pearson’s correlation to find out the order of an autoregressive model. The representations with optimal time delays for each DGC are applied as input in a multi-layer perceptron (MLP) network with backpropagation algorithm to predict the gas at the present and future times. This approach produces better results than choosing the same time delay for all inputs, as usual. The forecasts reached an average mean absolute percentage error (MAPE) of 5.763%, 1.525%, 1.831%, 2.869%, and 5.069% for C2H2, C2H6, C2H4, CH4, and H2, respectively. Full article
(This article belongs to the Special Issue Artificial Intelligence and Sensors)
Show Figures

Figure 1

Open AccessReview
Radiation Effects on Long Period Fiber Gratings: A Review
Sensors 2020, 20(9), 2729; https://doi.org/10.3390/s20092729 - 11 May 2020
Viewed by 395
Abstract
Over the last years, fiber optic sensors have been increasingly applied for applications in environments with a high level of radiation as an alternative to electrical sensors, due to their: high immunity, high multiplexing and long-distance monitoring capability. In order to assess the [...] Read more.
Over the last years, fiber optic sensors have been increasingly applied for applications in environments with a high level of radiation as an alternative to electrical sensors, due to their: high immunity, high multiplexing and long-distance monitoring capability. In order to assess the feasibility of their use, investigations on optical materials and fiber optic sensors have been focusing on their response depending on radiation type, absorbed dose, dose rate, temperature and so on. In this context, this paper presents a comprehensive review of the results achieved over the last twenty years concerning the irradiation of in-fiber Long Period Gratings (LPGs). The topic is approached from the point of view of the optical engineers engaged in the design, development and testing of these devices, by focusing the attention on the fiber type, grating fabrication technique and properties, irradiation parameters and performed analysis. The aim is to provide a detailed review concerning the state of the art and to outline the future research trends. Full article
(This article belongs to the Special Issue Long Period Fiber Grating Based Sensors and Components)
Show Figures

Figure 1

Open AccessArticle
Street-Scale Analysis of Population Exposure to Light Pollution Based on Remote Sensing and Mobile Big Data—Shenzhen City as a Case
Sensors 2020, 20(9), 2728; https://doi.org/10.3390/s20092728 - 11 May 2020
Viewed by 299
Abstract
Most studies on light pollution are based on light intensity retrieved from nighttime light (NTL) remote sensing with less consideration of the population factors. Furthermore, the coarse spatial resolution of traditional NTL remote sensing data limits the refined applications in current smart city [...] Read more.
Most studies on light pollution are based on light intensity retrieved from nighttime light (NTL) remote sensing with less consideration of the population factors. Furthermore, the coarse spatial resolution of traditional NTL remote sensing data limits the refined applications in current smart city studies. In order to analyze the influence of light pollution on populated areas, this study proposes an index named population exposure to light pollution (PELP) and conducts a street-scale analysis to illustrate spatial variation of PELP among residential areas in cites. By taking Shenzhen city as a case, multi-source data were combined including high resolution NTL remote sensing data from the Luojia 1-01 satellite sensor, high-precision mobile big data for visualizing human activities and population distribution as well as point of interest (POI) data. Results show that the main influenced areas of light pollution are concentrated in the downtown and core areas of newly expanded areas with obvious deviation corrected like traditional serious light polluted regions (e.g., ports). In comparison, commercial–residential mixed areas and village-in-city show a high level of PELP. The proposed method better presents the extent of population exposure to light pollution at a fine-grid scale and the regional difference between different types of residential areas in a city. Full article
(This article belongs to the Special Issue Distributed and Remote Sensing of the Urban Environment)
Show Figures

Figure 1

Open AccessArticle
A Bluetooth-Low-Energy-Based Detection and Warning System for Vulnerable Road Users in the Blind Spot of Vehicles
Sensors 2020, 20(9), 2727; https://doi.org/10.3390/s20092727 - 11 May 2020
Viewed by 451
Abstract
Blind spot road accidents are a frequently occurring problem. Every year, several deaths are caused by this phenomenon, even though a lot of money is invested in raising awareness and in the development of prevention systems. In this paper, a blind spot detection [...] Read more.
Blind spot road accidents are a frequently occurring problem. Every year, several deaths are caused by this phenomenon, even though a lot of money is invested in raising awareness and in the development of prevention systems. In this paper, a blind spot detection and warning system is proposed, relying on Received Signal Strength Indicator (RSSI) measurements and Bluetooth Low Energy (BLE) wireless communication. The received RSSI samples are threshold-filtered, after which a weighted average is computed with a sliding window filter. The technique is validated by simulations and measurements. Finally, the strength of the proposed system is demonstrated with real-life measurements. Full article
(This article belongs to the Special Issue Wearable Electronic Sensors)
Show Figures

Figure 1

Open AccessArticle
A Smart Sensor-Based Measurement System for Advanced Bee Hive Monitoring
Sensors 2020, 20(9), 2726; https://doi.org/10.3390/s20092726 - 10 May 2020
Viewed by 459
Abstract
The widespread decline of honey bee (Apis mellifera L.) colonies registered in recent years has raised great attention to the need of gathering deeper knowledge about this phenomenon, by observing the colonies’ activity to identify possible causes, and design corresponding countermeasures. In [...] Read more.
The widespread decline of honey bee (Apis mellifera L.) colonies registered in recent years has raised great attention to the need of gathering deeper knowledge about this phenomenon, by observing the colonies’ activity to identify possible causes, and design corresponding countermeasures. In fact, honey bees have well-known positive effects on both the environment and human life, and their preservation becomes critical not only for ecological reasons, but also for the social and economic development of rural communities. Smart sensor systems are being developed for real-time and long-term measurement of relevant parameters related to beehive conditions, such as the hive weight, sounds emitted by the bees, temperature, humidity, and CO 2 inside the beehive, as well as weather conditions outside. This paper presents a multisensor platform designed to measure the aforementioned parameters from beehives deployed in the field, and shows how the fusion of different sensor measurements may provide insights on the status of the colony, its interaction with the surrounding environment, and the influence of climatic conditions. Full article
(This article belongs to the Special Issue Metrology for Agriculture and Forestry 2019)
Show Figures

Figure 1

Open AccessArticle
A Distributed Oracle Using Intel SGX for Blockchain-Based IoT Applications
Sensors 2020, 20(9), 2725; https://doi.org/10.3390/s20092725 - 10 May 2020
Viewed by 509
Abstract
A blockchain oracle problem is a problem that defines a mechanism for how to safely bring external data to the blockchain. Although there have been various research efforts to solve this problem, existing solutions are limited in that they do not support either [...] Read more.
A blockchain oracle problem is a problem that defines a mechanism for how to safely bring external data to the blockchain. Although there have been various research efforts to solve this problem, existing solutions are limited in that they do not support either data availability or data integrity. Furthermore, no solution has been proposed to minimize the response time when an oracle server is malicious or overloaded. This paper proposes a distributed oracle using Intel Software Guard Extensions (SGX). The proposed approach uses multiple oracle servers to support data availability. It also supports data integrity using Intel SGX and Transport Layer Security (TLS) communication. The reputation system, which favors oracle servers with short response times, minimizes the average response time even if some of the oracle servers are malicious. The benchmarking results show that the response time of the proposed approach with 3 oracle servers is only 14% slower than a centralized oracle called Town-crier and scales well even if the number of oracle servers is increased up to 9. The reputation system is also evaluated, and its feasibility is analyzed using various experiments. Full article
(This article belongs to the Special Issue Blockchains in the Era of Smart Sensors)
Show Figures

Figure 1

Open AccessArticle
A Proposed Method to Assess the Mechanical Properties of Treadmill Surfaces
Sensors 2020, 20(9), 2724; https://doi.org/10.3390/s20092724 - 10 May 2020
Viewed by 1069
Abstract
The aim of this study was to define a reliable and sensitive test method for assessing Shock Absorption (SA), Vertical Deformation (VD), and Energy Restitution (ER) in treadmill surfaces. A total of 42 treadmills belonging to four different models were included in the [...] Read more.
The aim of this study was to define a reliable and sensitive test method for assessing Shock Absorption (SA), Vertical Deformation (VD), and Energy Restitution (ER) in treadmill surfaces. A total of 42 treadmills belonging to four different models were included in the study: (a) Technogym Jog700 Excite (n = 10), (b) Technogym Artis Run (n = 12), (c) LifeFitness Integrity Series 97T (n = 11), and (d) LifeFitness Integrity Series DX (n = 9). An advanced artificial athlete (AAA) device was used to assess SA, VD, and ER at three different locations along the longitudinal axis of each treadmill and in the support area of the athletes’ feet. For each location, our results show that the error assumed when performing one impact with the AAA instead of three (SA ≤ |0.1|%, VD ≤ |0.0| mm, and ER ≤ |0.2|%) is lower than the smallest changes that can be detected by the measuring device (SA = 0.4%, VD = 0.2 mm, and ER = 0.9%). Also, our results show the ability of the test method to detect meaningful differences between locations once the one-impact criterium is adopted, since absolute minimum differences between zones (SA: |0.6|%, VD: |0.3| mm, and ER: |1.2|%) were above the uncertainty of the measuring device. Therefore, performing a single impact with the AAA in each of the three locations described in this study can be considered a representative and reliable method for assessing SA, VD, and ER in treadmill surfaces. Full article
Show Figures

Figure 1

Open AccessArticle
Effective and Efficient Pretreatment of Polyimide Substrates by Capacitively Coupled Plasma for Coating the Composites of Tetracycline-Imprinted Polymers and Quantum Dots: Comparison with Chemical Pretreatment
Sensors 2020, 20(9), 2723; https://doi.org/10.3390/s20092723 - 10 May 2020
Viewed by 342
Abstract
Composites of tetracycline (Tc)-imprinted polymethacrylates and quantum dots have been coated on chemically pretreated polyimide substrates (PIs) as fluorescent sensors. In this study, PIs were pretreated by capacitively coupled plasma (CCP) before coating the same composites on them. For the first time, to [...] Read more.
Composites of tetracycline (Tc)-imprinted polymethacrylates and quantum dots have been coated on chemically pretreated polyimide substrates (PIs) as fluorescent sensors. In this study, PIs were pretreated by capacitively coupled plasma (CCP) before coating the same composites on them. For the first time, to fabricate sensors by plasma modification of PIs, the CCP conditions, including plasma gas, flow rate, radio frequency generation power, and duration time, the fabrication details, including coating, baking, and stripping steps, and the sample loading process were optimized to perform a linear decrease in fluorescent intensity with Tc concentrations in the range of 5.0–3000 μM (R2 = 0.9995) with a limit of detection of 0.2 μM (S/N = 3, relative standard deviation (RSD) = 2.2%). The selectivity of the stripped PIs was evaluated by the imprinting factors (IFs) for Tc (IF = 7.2), other Tc analogues (IF = 3.4–5.3), and steroids (IF ≈ 1) and by the recoveries of 5.0 μM Tc from bovine serum albumin at 300 μg∙mL−1 (98%, RSD = 3.2%), fetal bovine serum at 1.5 ppt (98%, RSD = 2.8%), and liquid milk (94.5%, RSD = 5.3%). The superiority of the present plasma-treated-based sensor over the previous chemically-treated one in fabrication efficiency and detection effectiveness was clear. Full article
(This article belongs to the Special Issue Molecularly Imprinted Polymer Sensing Platforms)
Show Figures

Graphical abstract

Open AccessArticle
A Novel Chemical Gas Vapor Sensor Based on Photoluminescence Enhancement of Rugate Porous Silicon Filters
Sensors 2020, 20(9), 2722; https://doi.org/10.3390/s20092722 - 10 May 2020
Viewed by 359
Abstract
In this study, an innovative rugate filter configuration porous silicon (PSi) with enhanced photoluminescence intensity was fabricated. The fabricated PSi exhibited dual optical properties with both sharp optical reflectivity and sharp photoluminescence (PL), and it was developed for use in organic vapor sensing. [...] Read more.
In this study, an innovative rugate filter configuration porous silicon (PSi) with enhanced photoluminescence intensity was fabricated. The fabricated PSi exhibited dual optical properties with both sharp optical reflectivity and sharp photoluminescence (PL), and it was developed for use in organic vapor sensing. When the wavelength of the resonance peak from the rugate PSi filters is engineered to overlap with the emission band of the PL from the PSi quantum dots, the PL intensity is amplified, thus reducing the full width at half maximum (FWHM) of the PL band from 154 nm to 22 nm. The rugate PSi filters samples were fabricated by electrochemical etching of highly doped n-type silicon under illumination. The etching solution consisted of a 1:1 volume mixture of 48% hydrofluoric acid and absolute ethanol and photoluminescent rugate PSi filter was fabricated by etching while using a periodic sinusoidal wave current with 10 cycles. The obtained samples were characterized by scanning electron microscopy (SEM), and both reflection redshift and PL quenching were measured under exposure to organic vapors. The reflection redshift and PL quenching were both affected by the vapor pressure and dipole moment of the organic species. Full article
Show Figures

Graphical abstract

Open AccessArticle
Convolutional Neural Networks for Image-Based Corn Kernel Detection and Counting
Sensors 2020, 20(9), 2721; https://doi.org/10.3390/s20092721 - 10 May 2020
Viewed by 449
Abstract
Precise in-season corn grain yield estimates enable farmers to make real-time accurate harvest and grain marketing decisions minimizing possible losses of profitability. A well developed corn ear can have up to 800 kernels, but manually counting the kernels on an ear of corn [...] Read more.
Precise in-season corn grain yield estimates enable farmers to make real-time accurate harvest and grain marketing decisions minimizing possible losses of profitability. A well developed corn ear can have up to 800 kernels, but manually counting the kernels on an ear of corn is labor-intensive, time consuming and prone to human error. From an algorithmic perspective, the detection of the kernels from a single corn ear image is challenging due to the large number of kernels at different angles and very small distance among the kernels. In this paper, we propose a kernel detection and counting method based on a sliding window approach. The proposed method detects and counts all corn kernels in a single corn ear image taken in uncontrolled lighting conditions. The sliding window approach uses a convolutional neural network (CNN) for kernel detection. Then, a non-maximum suppression (NMS) is applied to remove overlapping detections. Finally, windows that are classified as kernel are passed to another CNN regression model for finding the ( x , y ) coordinates of the center of kernel image patches. Our experiments indicate that the proposed method can successfully detect the corn kernels with a low detection error and is also able to detect kernels on a batch of corn ears positioned at different angles. Full article
(This article belongs to the Section Intelligent Sensors)
Show Figures

Figure 1

Open AccessArticle
Experimental Investigation of Optimal Relay Position for Magneto-Inductive Wireless Sensor Networks
Sensors 2020, 20(9), 2720; https://doi.org/10.3390/s20092720 - 10 May 2020
Viewed by 367
Abstract
Magneto-inductive (MI) waveguide technology is often proposed to increase the MI communication distance without adding significant cost and power consumption to the wireless sensor network. The idea is to add intermediate relaying nodes between transmitter (Tx) and receiver (Rx) to relay the information [...] Read more.
Magneto-inductive (MI) waveguide technology is often proposed to increase the MI communication distance without adding significant cost and power consumption to the wireless sensor network. The idea is to add intermediate relaying nodes between transmitter (Tx) and receiver (Rx) to relay the information from Tx to Rx. Our study of MI wave-guides has realized that adding a relay node improves the communication distance, however, the performance is greatly dependent on the position of the relaying node in the network. We therefore, in this work have investigated the effect of placement of a relay node and have determined the optimal relay position. We have performed various sets of experiments to thoroughly understand the behavior and identified three main regions: (a) for region 1, when the distance between Tx and Rx is equal or less than the diameter of the coils ( d 2 r ), the optimal relay position is close to Tx, (b) for region 2, when the distance between Tx and Rx is greater than diameter of the coils but less than twice the diameter ( 2 r < d < 4 r ), the optimal relay position lies in the center of Tx and Rx, and (c) for region 3, when the distance between the Tx and Rx is equal or greater than twice the diameter of the coils ( d 4 r ), the optimal relay position is close to Rx. Full article
(This article belongs to the Special Issue Underwater Sensor Networks)
Show Figures

Figure 1

Open AccessArticle
Towards the Development of a 3-D Biochip for the Detection of Hepatitis C Virus
Sensors 2020, 20(9), 2719; https://doi.org/10.3390/s20092719 - 10 May 2020
Viewed by 378
Abstract
The early diagnostics of hepatitis C virus (HCV) infections is currently one of the most highly demanded medical tasks. This study is devoted to the development of biochips (microarrays) that can be applied for the detection of HCV. The analytical platforms of suggested [...] Read more.
The early diagnostics of hepatitis C virus (HCV) infections is currently one of the most highly demanded medical tasks. This study is devoted to the development of biochips (microarrays) that can be applied for the detection of HCV. The analytical platforms of suggested devices were based on macroporous poly(glycidyl methacrylate-co-di(ethylene glycol) dimethacrylate) monolithic material. The biochips were obtained by the covalent immobilization of specific probes spotted onto the surface of macroporous monolithic platforms. Using the developed biochips, different variants of bioassay were investigated. This study was carried out using hepatitis C virus-mimetic particles (VMPs) representing polymer nanoparticles with a size close to HCV and bearing surface virus antigen (E2 protein). At the first step, the main parameters of bioassay were optimized. Additionally, the dissociation constants were calculated for the pairs “ligand–receptor” and “antigen–antibody” formed at the surface of biochips. As a result of this study, the analysis of VMPs in model buffer solution and human blood plasma was carried out in a format of direct and “sandwich” approaches. It was found that bioassay efficacy appeared to be similar for both the model medium and real biological fluid. Finally, limit of detection (LOD), limit of quantification (LOQ), spot-to-spot and biochip-to-biochip reproducibility for the developed systems were evaluated. Full article
(This article belongs to the Special Issue Immunoassays and Biosensors)
Show Figures

Figure 1

Open AccessArticle
Research on Focal Length Measurement Scheme of Self-Collimating Optical Instrument Based on Double Grating
Sensors 2020, 20(9), 2718; https://doi.org/10.3390/s20092718 - 10 May 2020
Viewed by 391
Abstract
In this paper, we propose a scheme for measuring the focal length of a collimating optical instrument. First, a mathematical model for measuring the focal length of a collimator with double gratings is derived based on the moiré fringe formula and the principles [...] Read more.
In this paper, we propose a scheme for measuring the focal length of a collimating optical instrument. First, a mathematical model for measuring the focal length of a collimator with double gratings is derived based on the moiré fringe formula and the principles of geometric optics. Mathematical simulation shows that a slight difference in the focal length of two collimators has an important influence on the imaging law of moiré fringes. Our solution has a good resolution ability for focal length differences within 5‰, especially in the small angle range below 4°. Thus, the focal length of collimators can be measured by the amplification of the slight difference. Further, owing to the relative reference measurement, the measurement resolution at the symmetrical position of focal length is poor. Then, in the designed experiment, a corresponding moiré image at different angles is acquired using collimators with known focal length. The experimental results indicate that the root mean square error (RMSE) of the collimator corresponding to grating angles of 2°–4° is better than 4.7‰, indicating an ideal measurement accuracy of the proposed scheme. This work demonstrates that our proposed scheme can achieve an ideal accuracy in the measurement of a symmetrical optical path. Full article
(This article belongs to the Section Optical Sensors)
Show Figures

Figure 1

Open AccessArticle
A Strictly Unsupervised Deep Learning Method for HEp-2 Cell Image Classification
Sensors 2020, 20(9), 2717; https://doi.org/10.3390/s20092717 - 09 May 2020
Viewed by 444
Abstract
Classifying the images that portray the Human Epithelial cells of type 2 (HEp-2) represents one of the most important steps in the diagnosis procedure of autoimmune diseases. Performing this classification manually represents an extremely complicated task due to the heterogeneity of these cellular [...] Read more.
Classifying the images that portray the Human Epithelial cells of type 2 (HEp-2) represents one of the most important steps in the diagnosis procedure of autoimmune diseases. Performing this classification manually represents an extremely complicated task due to the heterogeneity of these cellular images. Hence, an automated classification scheme appears to be necessary. However, the majority of the available methods prefer to utilize the supervised learning approach for this problem. The need for thousands of images labelled manually can represent a difficulty with this approach. The first contribution of this work is to demonstrate that classifying HEp-2 cell images can also be done using the unsupervised learning paradigm. Unlike the majority of the existing methods, we propose here a deep learning scheme that performs both the feature extraction and the cells’ discrimination through an end-to-end unsupervised paradigm. We propose the use of a deep convolutional autoencoder (DCAE) that performs feature extraction via an encoding–decoding scheme. At the same time, we embed in the network a clustering layer whose purpose is to automatically discriminate, during the feature learning process, the latent representations produced by the DCAE. Furthermore, we investigate how the quality of the network’s reconstruction can affect the quality of the produced representations. We have investigated the effectiveness of our method on some benchmark datasets and we demonstrate here that the unsupervised learning, when done properly, performs at the same level as the actual supervised learning-based state-of-the-art methods in terms of accuracy. Full article
(This article belongs to the Special Issue Machine Learning for Biomedical Imaging and Sensing)
Show Figures

Figure 1

Previous Issue
Next Issue
Back to TopTop
