Sensors, Volume 20, Issue 11 (June-1 2020) – 328 articles

  • Issues are regarded as officially published after their release is announced to the table of contents alert mailing list.
  • You may sign up for e-mail alerts to receive table of contents of newly released issues.
  • PDF is the official format for papers published in both, html and pdf forms. To view the papers in pdf format, click on the "PDF Full-text" link, and use the free Adobe Readerexternal link to open them.
Cover Story (view full-size image) The detection of ultrafine particulates produced by combustion engines and other sources is of [...] Read more.
Order results
Result details
Select all
Export citation of selected articles as:
Open AccessArticle
A Non-linear Model Predictive Control Based on Grey-Wolf Optimization Using Least-Square Support Vector Machine for Product Concentration Control in l-Lysine Fermentation
Sensors 2020, 20(11), 3335; https://doi.org/10.3390/s20113335 - 11 Jun 2020
Viewed by 501
Abstract
l-Lysine is produced by a complex non-linear fermentation process. A non-linear model predictive control (NMPC) scheme is proposed to control product concentration in real time for enhancing production. However, product concentration cannot be directly measured in real time. Least-square support vector machine [...] Read more.
l-Lysine is produced by a complex non-linear fermentation process. A non-linear model predictive control (NMPC) scheme is proposed to control product concentration in real time for enhancing production. However, product concentration cannot be directly measured in real time. Least-square support vector machine (LSSVM) is used to predict product concentration in real time. Grey-Wolf Optimization (GWO) algorithm is used to optimize the key model parameters (penalty factor and kernel width) of LSSVM for increasing its prediction accuracy (GWO-LSSVM). The proposed optimal prediction model is used as a process model in the non-linear model predictive control to predict product concentration. GWO is also used to solve the non-convex optimization problem in non-linear model predictive control (GWO-NMPC) for calculating optimal future inputs. The proposed GWO-based prediction model (GWO-LSSVM) and non-linear model predictive control (GWO-NMPC) are compared with the Particle Swarm Optimization (PSO)-based prediction model (PSO-LSSVM) and non-linear model predictive control (PSO-NMPC) to validate their effectiveness. The comparative results show that the prediction accuracy, adaptability, real-time tracking ability, overall error and control precision of GWO-based predictive control is better compared to PSO-based predictive control. Full article
(This article belongs to the Section Intelligent Sensors)
Show Figures

Figure 1

Open AccessArticle
Multi-Camera Vehicle Tracking Using Edge Computing and Low-Power Communication
Sensors 2020, 20(11), 3334; https://doi.org/10.3390/s20113334 - 11 Jun 2020
Viewed by 441
Abstract
Typical approaches to visual vehicle tracking across large area require several cameras and complex algorithms to detect, identify and track the vehicle route. Due to memory requirements, computational complexity and hardware constrains, the video images are transmitted to a dedicated workstation equipped with [...] Read more.
Typical approaches to visual vehicle tracking across large area require several cameras and complex algorithms to detect, identify and track the vehicle route. Due to memory requirements, computational complexity and hardware constrains, the video images are transmitted to a dedicated workstation equipped with powerful graphic processing units. However, this requires large volumes of data to be transmitted and may raise privacy issues. This paper presents a dedicated deep learning detection and tracking algorithms that can be run directly on the camera’s embedded system. This method significantly reduces the stream of data from the cameras, reduces the required communication bandwidth and expands the range of communication technologies to use. Consequently, it allows to use short-range radio communication to transmit vehicle-related information directly between the cameras, and implement the multi-camera tracking directly in the cameras. The proposed solution includes detection and tracking algorithms, and a dedicated low-power short-range communication for multi-target multi-camera tracking systems that can be applied in parking and intersection scenarios. System components were evaluated in various scenarios including different environmental and weather conditions. Full article
Show Figures

Figure 1

Open AccessArticle
Low Temperature Adhesive Bonding-Based Fabrication of an Air-Borne Flexible Piezoelectric Micromachined Ultrasonic Transducer
by Wei Liu and Dawei Wu
Sensors 2020, 20(11), 3333; https://doi.org/10.3390/s20113333 - 11 Jun 2020
Viewed by 416
Abstract
This paper presents the development of a flexible piezoelectric micromachined ultrasonic transducer (PMUT) that can conform to flat, concave, and convex surfaces and work in air. The PMUT consists of an Ag-coated polyvinylidene fluoride (PVDF) film mounted onto a laser-manipulated polymer substrate. A [...] Read more.
This paper presents the development of a flexible piezoelectric micromachined ultrasonic transducer (PMUT) that can conform to flat, concave, and convex surfaces and work in air. The PMUT consists of an Ag-coated polyvinylidene fluoride (PVDF) film mounted onto a laser-manipulated polymer substrate. A low temperature (<100 °C) adhesive bonding technique is adopted in the fabrication process. Finite element analysis (FEA) is implemented to confirm the capability of predicting the resonant frequency of composite diaphragms and optimizing the device. The manufactured PMUT exhibits a center frequency of 198 kHz with a wide operational bandwidth. Its acoustic performance is demonstrated by transmitting and receiving ultrasound in air on curved surface. The conclusions from this study indicate the proposed PMUT has great potential in ultrasonic and wearable devices applications. Full article
(This article belongs to the Section Electronic Sensors)
Show Figures

Graphical abstract

Open AccessLetter
Estimation of the Intrinsic Power Efficiency in Magnetoelectric Laminates Using Temperature Measurements
Sensors 2020, 20(11), 3332; https://doi.org/10.3390/s20113332 - 11 Jun 2020
Viewed by 386
Abstract
Magnetoelectric (ME) power efficiency is a more important property than the ME voltage or the current coefficients for power conversion applications. This paper introduces an analytical model that describes the relation between the external magnetic field and the power efficiency in layered ME [...] Read more.
Magnetoelectric (ME) power efficiency is a more important property than the ME voltage or the current coefficients for power conversion applications. This paper introduces an analytical model that describes the relation between the external magnetic field and the power efficiency in layered ME composites. It is a two-phase model. The first fragment establishes the expression between the magnetic field strength and the temperature increase within an operating period. It uses a magneto-elasto-electric equivalent circuit model that was developed by Dong et al. Following previous investigations; the main loss source is the mechanical power dissipation. The second fragment links the power efficiency and the temperature increase in a heat-balanced system. This method is generally used by researchers in the piezoelectric field. The analytical model and the experimental data shows that the decrease of the power efficiency in a laminated composite is between 5% and 10% for a power density of 10 W/in3 (0.61 W/cm3) to 30 W/in3 (1.83 W/cm3). The failure mechanism/process of ME composites under high power density can be estimated/monitored by the proposed method for ME composites in practical applications. Full article
(This article belongs to the Special Issue Magnetoelectric Sensors: Theory, Design and Application)
Show Figures

Figure 1

Open AccessArticle
Photon Counting LIDAR Based on True Random Coding
Sensors 2020, 20(11), 3331; https://doi.org/10.3390/s20113331 - 11 Jun 2020
Viewed by 408
Abstract
In this paper, a true random coding photon counting LIDAR is described, in which a Gm-APD (Geiger mode avalanche photodiode) acts as the true random sequence signal generator. The true random coding method not only improves the anti-crosstalk capability of the system, but [...] Read more.
In this paper, a true random coding photon counting LIDAR is described, in which a Gm-APD (Geiger mode avalanche photodiode) acts as the true random sequence signal generator. The true random coding method not only improves the anti-crosstalk capability of the system, but also greatly reduces the 1-bit missed detection caused by the limited Gm-APD count rate. The experiment verifies the feasibility of the true random sequence used in a photon counting LIDAR ranging system, and a simple and intuitive evaluation model of true random sequence autocorrelation is proposed. Finally, the influence of system parameters (mean echo photon number, mean pulse count density, sequence length, mean noise count) on detection probability is explored. In general, this paper proves that the true random code photon counting LIDAR is an effective target detection method, and provides a new idea for the research of an anti-crosstalk LIDAR system. Full article
(This article belongs to the Section Optical Sensors)
Show Figures

Figure 1

Open AccessArticle
Trust Based Multipath QoS Routing Protocol for Mission-Critical Data Transmission in Tactical Ad-Hoc Networks
Sensors 2020, 20(11), 3330; https://doi.org/10.3390/s20113330 - 11 Jun 2020
Viewed by 344
Abstract
In tactical ad-hoc networks, the importance of various tactical sensors and mission-critical data is increasing owing to their role in determining a tactical situation and ensuring the viability of soldiers. In particular, the reliability of mission-critical data has to be ensured for accurate [...] Read more.
In tactical ad-hoc networks, the importance of various tactical sensors and mission-critical data is increasing owing to their role in determining a tactical situation and ensuring the viability of soldiers. In particular, the reliability of mission-critical data has to be ensured for accurate situation determination and decision making. However, managing the network and trustworthiness in an environment where malicious nodes exist and a large amount of mission-critical data occur is a challenging issue. To solve these issues, a routing protocol is needed that can effectively detect malicious nodes and ensure the reliability and quality of service (QoS) of mission-critical data. In this paper, we propose a trust-based multipath QoS routing protocol (called MC_TQR) for tactical ad-hoc networks that can detect malicious nodes and satisfy the requirements of mission-critical data. The proposed scheme is verified using an OPNET simulator, and the results confirm the improved network performance when compared with existing schemes. Full article
(This article belongs to the Special Issue Security and Privacy in Wireless Sensor Network)
Show Figures

Figure 1

Open AccessArticle
Floating-Gate MOS Transistor with Dynamic Biasing as a Radiation Sensor
Sensors 2020, 20(11), 3329; https://doi.org/10.3390/s20113329 - 11 Jun 2020
Viewed by 392
Abstract
This paper describes the possibility of using an Electrically Programmable Analog Device (EPAD) as a gamma radiation sensor. Zero-biased EPAD has the lowest fading and the highest sensitivity in the 300 Gy dose range. Dynamic bias of the control gate during irradiation was [...] Read more.
This paper describes the possibility of using an Electrically Programmable Analog Device (EPAD) as a gamma radiation sensor. Zero-biased EPAD has the lowest fading and the highest sensitivity in the 300 Gy dose range. Dynamic bias of the control gate during irradiation was presented for the first time; this method achieved higher sensitivity compared to static-biased EPADs and better linear dependence. Due to the degradation of the transfer characteristics of EPAD during irradiation, a function of the safe operation area has been found that determines the maximum voltage at the control gate for the desired dose, which will not lead to degradation of the transistor. Using an energy band diagram, it was explained why the zero-biased EPAD has higher sensitivity than the static-biased EPAD. Full article
(This article belongs to the Section Physical Sensors)
Show Figures

Figure 1

Open AccessArticle
Creating the Internet of Augmented Things: An Open-Source Framework to Make IoT Devices and Augmented and Mixed Reality Systems Talk to Each Other
Sensors 2020, 20(11), 3328; https://doi.org/10.3390/s20113328 - 11 Jun 2020
Viewed by 522
Abstract
Augmented Reality (AR) and Mixed Reality (MR) devices have evolved significantly in the last years, providing immersive AR/MR experiences that allow users to interact with virtual elements placed on the real-world. However, to make AR/MR devices reach their full potential, it is necessary [...] Read more.
Augmented Reality (AR) and Mixed Reality (MR) devices have evolved significantly in the last years, providing immersive AR/MR experiences that allow users to interact with virtual elements placed on the real-world. However, to make AR/MR devices reach their full potential, it is necessary to go further and let them collaborate with the physical elements around them, including the objects that belong to the Internet of Things (IoT). Unfortunately, AR/MR and IoT devices usually make use of heterogeneous technologies that complicate their intercommunication. Moreover, the implementation of the intercommunication mechanisms requires involving specialized developers with have experience on the necessary technologies. To tackle such problems, this article proposes the use of a framework that makes it easy to integrate AR/MR and IoT devices, allowing them to communicate dynamically and in real time. The presented AR/MR-IoT framework makes use of standard and open-source protocols and tools like MQTT, HTTPS or Node-RED. After detailing the inner workings of the framework, it is illustrated its potential through a practical use case: a smart power socket that can be monitored and controlled through Microsoft HoloLens AR/MR glasses. The performance of such a practical use case is evaluated and it is demonstrated that the proposed framework, under normal operation conditions, enables to respond in less than 100 ms to interaction and data update requests. Full article
Show Figures

Figure 1

Open AccessArticle
A New Label-Free and Contactless Bio-Tomographic Imaging with Miniaturized Capacitively-Coupled Spectroscopy Measurements
Sensors 2020, 20(11), 3327; https://doi.org/10.3390/s20113327 - 11 Jun 2020
Viewed by 402
Abstract
A new bio-imaging method has been developed by introducing an experimental verification of capacitively coupled resistivity imaging in a small scale. This paper focuses on the 2D circular array imaging sensor as well as a 3D planar array imaging sensor with spectroscopic measurements [...] Read more.
A new bio-imaging method has been developed by introducing an experimental verification of capacitively coupled resistivity imaging in a small scale. This paper focuses on the 2D circular array imaging sensor as well as a 3D planar array imaging sensor with spectroscopic measurements in a wide range from low frequency to radiofrequency. Both these two setups are well suited for standard containers used in cell and culture biological studies, allowing for fully non-invasive testing. This is true as the capacitive based imaging sensor can extract dielectric spectroscopic images from the sample without direct contact with the medium. The paper shows the concept by deriving a wide range of spectroscopic information from biological test samples. We drive both spectra of electrical conductivity and the change rate of electrical conductivity with frequency as a piece of fundamentally important information. The high-frequency excitation allows the interrogation of critical properties that arise from the cell nucleus. Full article
Show Figures

Figure 1

Open AccessLetter
Ultrasensitive Surface Plasmon Resonance Biosensor Using Blue Phosphorus–Graphene Architecture
Sensors 2020, 20(11), 3326; https://doi.org/10.3390/s20113326 - 11 Jun 2020
Viewed by 426
Abstract
This study theoretically proposed a novel surface plasmon resonance biosensor by incorporating emerging two dimensional material blue phosphorus and graphene layers with plasmonic gold film. The excellent performances employed for biosensing can be realized by accurately tuning the thickness of gold film and [...] Read more.
This study theoretically proposed a novel surface plasmon resonance biosensor by incorporating emerging two dimensional material blue phosphorus and graphene layers with plasmonic gold film. The excellent performances employed for biosensing can be realized by accurately tuning the thickness of gold film and the number of blue phosphorus interlayer. Our proposed plasmonic biosensor architecture designed by phase modulation is much superior to angular modulation, providing 4 orders of magnitude sensitivity enhancement. In addition, the optimized stacked configuration is 42 nm Au film/2-layer blue phosphorus /4-layer graphene, which can produce the sharpest differential phase of 176.7661 degrees and darkest minimum reflectivity as low as 5.3787 × 10−6. For a tiny variation in local refractive index of 0.0012 RIU (RIU, refractive index unit) due to the binding interactions of aromatic biomolecules, our proposed biosensor can provide an ultrahigh detection sensitivity up to 1.4731 × 105 °/RIU, highly promising for performing ultrasensitive biosensing application. Full article
Show Figures

Figure 1

Open AccessArticle
Investigation of the Effect of Process Parameters on Bone Grinding Performance Based on On-Line Measurement of Temperature and Force Sensors
Sensors 2020, 20(11), 3325; https://doi.org/10.3390/s20113325 - 11 Jun 2020
Viewed by 349
Abstract
This study investigates the effect of process parameters on neurosurgical bone grinding performance using a miniature surgical diamond wheel. Bone grinding is an important procedure in the expanded endonasal approach for removing the cranial bone and access to the skull base tumor via [...] Read more.
This study investigates the effect of process parameters on neurosurgical bone grinding performance using a miniature surgical diamond wheel. Bone grinding is an important procedure in the expanded endonasal approach for removing the cranial bone and access to the skull base tumor via nasal corridor. Heat and force are generated during the grinding process, which may cause thermal and mechanical damage to the adjacent tissues. This study investigates the effect of grinding process parameters (including the depth of cut, feed rate, and spindle speed) on the bone grinding performance using temperature and force measurement sensors in order to optimize the grinding process. An orthogonal experimental design with a standard orthogonal array, L9 (33), is selected with each parameter in three levels. The experimental results have been statistically analyzed using the range and variance analysis methods in order to determine the importance order of the process parameters. The results indicate that the effect of the cutting depth on the grinding temperature and normal force is the largest, while the effect of the spindle speed on the tangential force is the largest. A high spindle speed would make the temperature rise to a certain extent; however, it significantly reduces the grinding force. At a certain spindle speed, a lower depth of cut and feed rate help to reduce the grinding temperature and force. Full article
(This article belongs to the Special Issue Temperature Sensors 2019)
Show Figures

Figure 1

Open AccessArticle
Quality Assessment of the Neural Algorithms on the Example of EIT-UST Hybrid Tomography
Sensors 2020, 20(11), 3324; https://doi.org/10.3390/s20113324 - 11 Jun 2020
Viewed by 316
Abstract
The paper presents the results of research on the hybrid industrial tomograph electrical impedance tomography (EIT) and ultrasonic tomography (UST) (EIT-UST), operating on the basis of electrical and ultrasonic data. The emphasis of the research was placed on the algorithmic domain. However, it [...] Read more.
The paper presents the results of research on the hybrid industrial tomograph electrical impedance tomography (EIT) and ultrasonic tomography (UST) (EIT-UST), operating on the basis of electrical and ultrasonic data. The emphasis of the research was placed on the algorithmic domain. However, it should be emphasized that all hardware components of the hybrid tomograph, including electronics, sensors and transducers, have been designed and mostly made in the Netrix S.A. laboratory. The test object was a tank filled with water with several dozen percent concentration. As part of the study, the original multiple neural networks system was trained, the characteristic feature of which is the generation of each of the individual pixels of the tomographic image, using an independent artificial neural network (ANN), with the input vector for all ANNs being the same. Despite the same measurement vector, each of the ANNs generates its own independent output value for a given tomogram pixel, because, during training, the networks get their respective weights and biases. During the tests, the results of three tomographic methods were compared: EIT, UST and EIT-UST hybrid. The results confirm that the use of heterogeneous tomographic systems (hybrids) increases the reliability of reconstruction in various measuring cases, which is used to solve quality problems in managing production processes. Full article
Show Figures

Figure 1

Open AccessArticle
Low-Profile Slotted Metamaterial Antenna Based on Bi Slot Microstrip Patch for 5G Application
Sensors 2020, 20(11), 3323; https://doi.org/10.3390/s20113323 - 11 Jun 2020
Viewed by 391
Abstract
A low-profile high-directivity, and double-negative (DNG) metamaterial-loaded antenna with a slotted patch is proposed for the 5G application. The radiated slotted arm as a V shape has been extended to provide a low-profile feature with a two-isometric view square patch structure, which accelerates [...] Read more.
A low-profile high-directivity, and double-negative (DNG) metamaterial-loaded antenna with a slotted patch is proposed for the 5G application. The radiated slotted arm as a V shape has been extended to provide a low-profile feature with a two-isometric view square patch structure, which accelerates the electromagnetic (EM) resonance. Besides, the tapered patch with two vertically split parabolic horns and the unit cell metamaterial expedite achieve more directive radiation. Two adjacent splits with meta units enhance the surface current to modify the actual electric current, which is induced by a substrate-isolated EM field. As a result, the slotted antenna shows a 7.14 dBi realized gain with 80% radiation efficiency, which is quite significant. The operation bandwidth is 4.27–4.40 GHz, and characteristic impedance approximately remains the same (50 Ω) to give a VSWR (voltage Standing wave ratio) of less than 2, which is ideal for the expected application field. The overall size of the antenna is 60 × 40 × 1.52 mm. Hence, it has potential for future 5G applications, like Internet of Things (IoT), healthcare systems, smart homes, etc. Full article
(This article belongs to the Special Issue Metamaterial Technology in Electromagnetic Sensing Application)
Show Figures

Figure 1

Open AccessReview
Sensor-to-Segment Calibration Methodologies for Lower-Body Kinematic Analysis with Inertial Sensors: A Systematic Review
Sensors 2020, 20(11), 3322; https://doi.org/10.3390/s20113322 - 11 Jun 2020
Viewed by 433
Abstract
Kinematic analysis is indispensable to understanding and characterizing human locomotion. Thanks to the development of inertial sensors based on microelectronics systems, human kinematic analysis in an ecological environment is made possible. An important issue in human kinematic analyses with inertial sensors is the [...] Read more.
Kinematic analysis is indispensable to understanding and characterizing human locomotion. Thanks to the development of inertial sensors based on microelectronics systems, human kinematic analysis in an ecological environment is made possible. An important issue in human kinematic analyses with inertial sensors is the necessity of defining the orientation of the inertial sensor coordinate system relative to its underlying segment coordinate system, which is referred to sensor-to-segment calibration. Over the last decade, we have seen an increase of proposals for this purpose. The aim of this review is to highlight the different proposals made for lower-body segments. Three different databases were screened: PubMed, Science Direct and IEEE Xplore. One reviewer performed the selection of the different studies and data extraction. Fifty-five studies were included. Four different types of calibration method could be identified in the articles: the manual, static, functional, and anatomical methods. The mathematical approach to obtain the segment axis and the calibration evaluation were extracted from the selected articles. Given the number of propositions and the diversity of references used to evaluate the methods, it is difficult today to form a conclusion about the most suitable. To conclude, comparative studies are required to validate calibration methods in different circumstances. Full article
(This article belongs to the Special Issue Human and Animal Motion Tracking Using Inertial Sensors)
Show Figures

Figure 1

Open AccessArticle
Fluorescence Anisotropy Sensor Comprising a Dual Hollow-Core Antiresonant Fiber Polarization Beam Splitter
Sensors 2020, 20(11), 3321; https://doi.org/10.3390/s20113321 - 11 Jun 2020
Viewed by 352
Abstract
Fluorescence anisotropy imaging and sensing is a widely recognized method for studying molecular orientation and mobility. However, introducing this technique to in vivo systems is a challenging task, especially when one considers multiphoton excitation methods. Past two decades have brought a possible solution [...] Read more.
Fluorescence anisotropy imaging and sensing is a widely recognized method for studying molecular orientation and mobility. However, introducing this technique to in vivo systems is a challenging task, especially when one considers multiphoton excitation methods. Past two decades have brought a possible solution to this issue in the form of hollow-core antiresonant fibers (HC-ARFs). The continuous development of their fabrication technology has resulted in the appearance of more and more sophisticated structures. One of the most promising concepts concerns dual hollow-core antiresonant fibers (DHC-ARFs), which can be used to split and combine optical signals, effectively working as optical fiber couplers. In this paper, the design of a fluorescence anisotropy sensor based on a DHC-ARF structure is presented. The main purpose of the proposed DHC-ARF is multiphoton-excited fluorescence spectroscopy; however, other applications are also possible. Full article
Show Figures

Graphical abstract

Open AccessArticle
Data Description Technique-Based Islanding Classification for Single-Phase Grid-Connected Photovoltaic System
Sensors 2020, 20(11), 3320; https://doi.org/10.3390/s20113320 - 11 Jun 2020
Viewed by 683
Abstract
This paper develops an islanding classification mechanism to overcome the problems of non-detection zones in conventional islanding detection mechanisms. This process is achieved by adapting the support vector-based data description technique with Gaussian radial basis function kernels for islanding and non-islanding events in [...] Read more.
This paper develops an islanding classification mechanism to overcome the problems of non-detection zones in conventional islanding detection mechanisms. This process is achieved by adapting the support vector-based data description technique with Gaussian radial basis function kernels for islanding and non-islanding events in single phase grid-connected photovoltaic (PV) systems. To overcome the non-detection zone, excess and deficit power imbalance conditions are considered for different loading conditions. These imbalances are characterized by the voltage dip scenario and were subjected to feature extraction for training with the machine learning technique. This is experimentally realized by training the machine learning classifier with different events on a 5   kW grid-connected system. Using the concept of detection and false alarm rates, the performance of the trained classifier is tested for multiple faults and power imbalance conditions. The results showed the effective operation of the classifier with a detection rate of 99.2% and a false alarm rate of 0.2%. Full article
(This article belongs to the Special Issue Photovoltaic Sensor and Applications)
Show Figures

Figure 1

Open AccessArticle
Low-Cost Automated Vectors and Modular Environmental Sensors for Plant Phenotyping
Sensors 2020, 20(11), 3319; https://doi.org/10.3390/s20113319 - 11 Jun 2020
Viewed by 712
Abstract
High-throughput plant phenotyping in controlled environments (growth chambers and glasshouses) is often delivered via large, expensive installations, leading to limited access and the increased relevance of “affordable phenotyping” solutions. We present two robot vectors for automated plant phenotyping under controlled conditions. Using 3D-printed [...] Read more.
High-throughput plant phenotyping in controlled environments (growth chambers and glasshouses) is often delivered via large, expensive installations, leading to limited access and the increased relevance of “affordable phenotyping” solutions. We present two robot vectors for automated plant phenotyping under controlled conditions. Using 3D-printed components and readily-available hardware and electronic components, these designs are inexpensive, flexible and easily modified to multiple tasks. We present a design for a thermal imaging robot for high-precision time-lapse imaging of canopies and a Plate Imager for high-throughput phenotyping of roots and shoots of plants grown on media plates. Phenotyping in controlled conditions requires multi-position spatial and temporal monitoring of environmental conditions. We also present a low-cost sensor platform for environmental monitoring based on inexpensive sensors, microcontrollers and internet-of-things (IoT) protocols. Full article
(This article belongs to the Special Issue Low-Cost Sensors and Vectors for Plant Phenotyping)
Show Figures

Figure 1

Open AccessArticle
A Multi-Module Fixed Inclinometer for Continuous Monitoring of Landslides: Design, Development, and Laboratory Testing
Sensors 2020, 20(11), 3318; https://doi.org/10.3390/s20113318 - 10 Jun 2020
Viewed by 479
Abstract
Continuous monitoring of landslides is of basic importance for understanding their behavior, defining their 3D geometry, and providing a basis for early warning purposes. While a number of instrumentations can be used for tracking surface displacement, only automatic or fixed multi-module inclinometers can [...] Read more.
Continuous monitoring of landslides is of basic importance for understanding their behavior, defining their 3D geometry, and providing a basis for early warning purposes. While a number of instrumentations can be used for tracking surface displacement, only automatic or fixed multi-module inclinometers can be used for continuous monitoring of displacement at depth, providing valuable information for landslide geometry reconstruction. Since these instruments are very expensive, thus rarely used, a low-cost and multi-module fixed inclinometer for continuous landslide monitoring has been developed. In this paper, the electronics of the system, including sensor characteristics and optimization, controlling software, and structure are presented. For system development, a single module prototype was first developed and tested in the field to ensure sufficient measuring performance. Subsequently, the multi-module system was designed, assembled, and tested in controlled conditions. Test results indicate the good performance of the system with a displacement measuring accuracy of 0.37% of the length of the inclinometer chain. The linearity test indicates the high linearity of the measures, especially in the range ±20°, which is the typical operating range of such kinds of instrumentations. The thermal efficiency test indicates the high efficiency of the system in preventing measuring errors caused by thermal drifting. Full article
(This article belongs to the Section Physical Sensors)
Show Figures

Figure 1

Open AccessArticle
Connectivity on Underwater MI-Assisted Acoustic Cooperative MIMO Networks
Sensors 2020, 20(11), 3317; https://doi.org/10.3390/s20113317 - 10 Jun 2020
Viewed by 412
Abstract
In traditional underwater wireless sensor networks (UWSNs), it is difficult to establish reliable communication links as the acoustic wave experiences severe multipath effect, channel fading, and ambient noise. Recently, with the assistance of magnetic induction (MI) technique, cooperative multi-input-multi-output (MIMO) is utilized in [...] Read more.
In traditional underwater wireless sensor networks (UWSNs), it is difficult to establish reliable communication links as the acoustic wave experiences severe multipath effect, channel fading, and ambient noise. Recently, with the assistance of magnetic induction (MI) technique, cooperative multi-input-multi-output (MIMO) is utilized in UWSNs to enable the reliable long range underwater communication. Compared with the acoustic-based UWSNs, the UWSNs adopting MI-assisted acoustic cooperative MIMO are referred to as heterogeneous UWSNs, which are able to significantly improve the effective cover space and network throughput. Due to the complex channel characteristics and the heterogeneous architecture, the connectivity of underwater MI-assisted acoustic cooperative MIMO networks is much more complicated than that of acoustic-based UWSNs. In this paper, a mathematical model is proposed to analyze the connectivity of the networks, which considers the effects of channel characteristics, system parameters, and synchronization errors. The lower and upper bounds of the connectivity probability are also derived, which provide guidelines for the design and deployment of underwater MI-assisted acoustic cooperative MIMO networks. Monte Carlo simulations were performed, and the results validate the accuracy of the proposed model. Full article
(This article belongs to the Special Issue Underwater Wireless Sensing and Wireless Sensor Networks)
Show Figures

Figure 1

Open AccessArticle
A Calibration Procedure for Field and UAV-Based Uncooled Thermal Infrared Instruments
Sensors 2020, 20(11), 3316; https://doi.org/10.3390/s20113316 - 10 Jun 2020
Viewed by 795
Abstract
Thermal infrared cameras provide unique information on surface temperature that can benefit a range of environmental, industrial and agricultural applications. However, the use of uncooled thermal cameras for field and unmanned aerial vehicle (UAV) based data collection is often hampered by vignette effects, [...] Read more.
Thermal infrared cameras provide unique information on surface temperature that can benefit a range of environmental, industrial and agricultural applications. However, the use of uncooled thermal cameras for field and unmanned aerial vehicle (UAV) based data collection is often hampered by vignette effects, sensor drift, ambient temperature influences and measurement bias. Here, we develop and apply an ambient temperature-dependent radiometric calibration function that is evaluated against three thermal infrared sensors (Apogee SI-11(Apogee Electronics, Santa Monica, CA, USA), FLIR A655sc (FLIR Systems, Wilsonville, OR, USA), TeAx 640 (TeAx Technology, Wilnsdorf, Germany)). Upon calibration, all systems demonstrated significant improvement in measured surface temperatures when compared against a temperature modulated black body target. The laboratory calibration process used a series of calibrated resistance temperature detectors to measure the temperature of a black body at different ambient temperatures to derive calibration equations for the thermal data acquired by the three sensors. As a point-collecting device, the Apogee sensor was corrected for sensor bias and ambient temperature influences. For the 2D thermal cameras, each pixel was calibrated independently, with results showing that measurement bias and vignette effects were greatly reduced for the FLIR A655sc (from a root mean squared error (RMSE) of 6.219 to 0.815 degrees Celsius (℃)) and TeAx 640 (from an RMSE of 3.438 to 1.013 ℃) cameras. This relatively straightforward approach for the radiometric calibration of infrared thermal sensors can enable more accurate surface temperature retrievals to support field and UAV-based data collection efforts. Full article
(This article belongs to the Section Physical Sensors)
Show Figures

Graphical abstract

Open AccessArticle
A Genetic Algorithm Procedure for the Automatic Updating of FEM Based on Ambient Vibration Tests
Sensors 2020, 20(11), 3315; https://doi.org/10.3390/s20113315 - 10 Jun 2020
Viewed by 594
Abstract
The dynamic identification of the modal parameters of a structure, in order to gain control of its functionality under operating conditions, is currently under discussion from a scientific and technical point of views. The experimental observations obtained through structural health monitoring (SHM) are [...] Read more.
The dynamic identification of the modal parameters of a structure, in order to gain control of its functionality under operating conditions, is currently under discussion from a scientific and technical point of views. The experimental observations obtained through structural health monitoring (SHM) are a useful calibration reference of numerical models (NMs). In this paper, the procedures for the identification of modal parameters in historical bell towers using a stochastic subspace identification (SSI) algorithm are presented. Then, NMs are manually calibrated on the identification’s results. Finally, the applicability of a genetic algorithm for the automatic calibration of the elastic parameters is considered with the aim of searching for the properties of the autochthonous material, in order to reduce modelling error following the model assurance criterion (MAC). In this regard, several material values on the same model are examined to see how to approach the evolution and the distribution of these features, comparing the characterization proposed by the genetic algorithm with the results considered by the manual iterative procedure. Full article
(This article belongs to the Special Issue Sensors for Cultural Heritage Monitoring)
Show Figures

Figure 1

Open AccessArticle
Quick and Sensitive Detection of Water Using Galvanic-Coupled Arrays with a Submicron Gap for the Advanced Prediction of Dew Condensation
Sensors 2020, 20(11), 3314; https://doi.org/10.3390/s20113314 - 10 Jun 2020
Viewed by 371
Abstract
We have demonstrated a highly sensitive moisture sensor that can detect water molecules, in addition to water droplets, and therefore, can predict dew condensation with high accuracy and high speed before the formation of water droplets, showing a better performance than a commercial [...] Read more.
We have demonstrated a highly sensitive moisture sensor that can detect water molecules, in addition to water droplets, and therefore, can predict dew condensation with high accuracy and high speed before the formation of water droplets, showing a better performance than a commercial hygrometer. Additionally, the dependence of the output response from the sensor on factors, such as the cooling rate of the sensor’s surface and the vapor pressure in the chamber, that affect the performance of the moisture sensor has been clarified. The output response showed a clear dependence on the variation in cooling rate, as well as the vapor pressure. The higher the cooling rate and vapor pressure, the higher the output response. The output response showed a linear response to the change in the above-mentioned parameters. The higher sensitivity and accuracy of the moisture sensor, as a function of the physical parameters, such as cooling rates, vapor pressure, enables the sensor to perform in advanced detection applications. The sensor can be modified to the actual target regarding the surface nature and the heat capacity of the target object, making it more suitable for wide applications. Full article
(This article belongs to the Section Physical Sensors)
Show Figures

Graphical abstract

Open AccessArticle
Optimized Performance Parameters for Nighttime Multispectral Satellite Imagery to Analyze Lightings in Urban Areas
Sensors 2020, 20(11), 3313; https://doi.org/10.3390/s20113313 - 10 Jun 2020
Viewed by 412
Abstract
Contrary to its daytime counterpart, nighttime visible and near infrared (VIS/NIR) satellite imagery is limited in both spectral and spatial resolution. Nevertheless, the relevance of such systems is unquestioned with applications to, e.g., examine urban areas, derive light pollution, and estimate energy consumption. [...] Read more.
Contrary to its daytime counterpart, nighttime visible and near infrared (VIS/NIR) satellite imagery is limited in both spectral and spatial resolution. Nevertheless, the relevance of such systems is unquestioned with applications to, e.g., examine urban areas, derive light pollution, and estimate energy consumption. To determine optimal spectral bands together with required radiometric and spatial resolution, at-sensor radiances are simulated based on combinations of lamp spectra with typical luminances according to lighting standards, surface reflectances, and radiative transfers for the consideration of atmospheric effects. Various band combinations are evaluated for their ability to differentiate between lighting types and to estimate the important lighting parameters: efficacy to produce visible light, percentage of emissions attributable to the blue part of the spectrum, and assessment of the perceived color of radiation sources. The selected bands are located in the green, blue, yellow-orange, near infrared, and red parts of the spectrum and include one panchromatic band. However, these nighttime bands tailored to artificial light emissions differ significantly from the typical daytime bands focusing on surface reflectances. Compared to existing or proposed nighttime or daytime satellites, the recommended characteristics improve, e.g., classification of lighting types by >10%. The simulations illustrate the feasible improvements in nocturnal VIS/NIR remote sensing which will lead to advanced applications. Full article
(This article belongs to the Section Optical Sensors)
Show Figures

Figure 1

Open AccessArticle
Marker-Based Movement Analysis of Human Body Parts in Therapeutic Procedure
Sensors 2020, 20(11), 3312; https://doi.org/10.3390/s20113312 - 10 Jun 2020
Viewed by 445
Abstract
Movement analysis of human body parts is momentous in several applications including clinical diagnosis and rehabilitation programs. The objective of this research is to present a low-cost 3D visual tracking system to analyze the movement of various body parts during therapeutic procedures. Specifically, [...] Read more.
Movement analysis of human body parts is momentous in several applications including clinical diagnosis and rehabilitation programs. The objective of this research is to present a low-cost 3D visual tracking system to analyze the movement of various body parts during therapeutic procedures. Specifically, a marker based motion tracking system is proposed in this paper to capture the movement information in home-based rehabilitation. Different color markers are attached to the desired joints’ locations and they are detected and tracked in the video to encode their motion information. The availability of this motion information of different body parts during the therapy can be exploited to achieve more accurate results with better clinical insight, which in turn can help improve the therapeutic decision making. The proposed framework is an automated and inexpensive motion tracking system with execution speed close to real time. The performance of the proposed method is evaluated on a dataset of 10 patients using two challenging matrices that measure the average accuracy by estimating the joints’ locations and rotations. The experimental evaluation and its comparison with the existing state-of-the-art techniques reveals the efficiency of the proposed method. Full article
(This article belongs to the Special Issue Multimodal Sensing for Understanding Behavior and Personality)
Show Figures

Figure 1

Open AccessArticle
Statistical Analysis of Bistatic Radar Ground Clutter for Different German Rural Environments
Sensors 2020, 20(11), 3311; https://doi.org/10.3390/s20113311 - 10 Jun 2020
Viewed by 388
Abstract
This article presents the statistical analysis of bistatic radar rural ground clutter for different terrain types under low grazing angles. Compared to most state-of-the-art analysis, we present country-specific clutter analysis for subgroups of rural environments rather than for the rural environment as a [...] Read more.
This article presents the statistical analysis of bistatic radar rural ground clutter for different terrain types under low grazing angles. Compared to most state-of-the-art analysis, we present country-specific clutter analysis for subgroups of rural environments rather than for the rural environment as a whole. Therefore, the rural environment analysis is divided into four dominant subgroup terrain types, namely fields with low vegetation, fields with high vegetation, plantations of small trees and forest environments representing a typical rural German environment. We will present the results for both the summer and the winter vegetation. Therefore, bistatic measurement campaigns have been carried out during the summer 2019 and the winter of 2019/20 in the aforementioned four different rural terrain types. The measurements were performed in the radar relevant X-band at a center frequency of 8.85 GHz and over a bandwidth of 100 MHz according to available transmit permission. The distinction of the rural terrain into different subgroups enables a more precise and accurate clutter analysis and modeling of the statistical properties as will be shown in the presented results. The statistical properties are derived from the calculated clutter amplitudes probability density functions and corresponding cumulative distribution functions for each of the four terrain types and the corresponding season. The data basis for the clutter analysis are the processed range-Doppler maps from the bistatic radar measurements. According to the authors’ current knowledge, a similar investigation based on real bistatic radar measurement data with the division into terrain subgroups has not yet been carried out and published for a German rural environment. Full article
(This article belongs to the Section Remote Sensors)
Show Figures

Figure 1

Open AccessArticle
A Comprehensive Study of the Microclimate-Induced Conservation Risks in Hypogeal Sites: The Mithraeum of the Baths of Caracalla (Rome)
Sensors 2020, 20(11), 3310; https://doi.org/10.3390/s20113310 - 10 Jun 2020
Viewed by 386
Abstract
The peculiar microclimate inside cultural hypogeal sites needs to be carefully investigated. This study presents a methodology that aimed at providing a user-friendly assessment of the frequently occurring hazards in such sites. A Risk Index was specifically defined as the percentage of time [...] Read more.
The peculiar microclimate inside cultural hypogeal sites needs to be carefully investigated. This study presents a methodology that aimed at providing a user-friendly assessment of the frequently occurring hazards in such sites. A Risk Index was specifically defined as the percentage of time for which the hygrothermal values lie in ranges that are considered to be hazardous for conservation. An environmental monitoring campaign that was conducted over the past ten years inside the Mithraeum of the Baths of Caracalla (Rome) allowed for us to study the deterioration before and after a maintenance intervention. The general microclimate assessment and the specific conservation risk assessment were both carried out. The former made it possible to investigate the influence of the outdoor weather conditions on the indoor climate and estimate condensation and evaporation responsible for salts crystallisation/dissolution and bio-colonisation. The latter took hygrothermal conditions that were close to wall surfaces to analyse the data distribution on diagrams with critical curves of deliquescence salts, mould germination, and growth. The intervention mitigated the risk of efflorescence thanks to reduced evaporation, while promoting the risk of bioproliferation due to increased condensation. The Risk Index provided a quantitative measure of the individual risks and their synergism towards a more comprehensive understanding of the microclimate-induced risks. Full article
(This article belongs to the Special Issue Sensors for Cultural Heritage Monitoring)
Show Figures

Figure 1

Open AccessArticle
Automotive Lidar Modelling Approach Based on Material Properties and Lidar Capabilities
Sensors 2020, 20(11), 3309; https://doi.org/10.3390/s20113309 - 10 Jun 2020
Viewed by 371
Abstract
Development and validation of reliable environment perception systems for automated driving functions requires the extension of conventional physical test drives with simulations in virtual test environments. In such a virtual test environment, a perception sensor is replaced by a sensor model. A major [...] Read more.
Development and validation of reliable environment perception systems for automated driving functions requires the extension of conventional physical test drives with simulations in virtual test environments. In such a virtual test environment, a perception sensor is replaced by a sensor model. A major challenge for state-of-the-art sensor models is to represent the large variety of material properties of the surrounding objects in a realistic manner. Since lidar sensors are considered to play an essential role for upcoming automated vehicles, this paper presents a new lidar modelling approach that takes material properties and corresponding lidar capabilities into account. The considered material property is the incidence angle dependent reflectance of the illuminated material in the infrared spectrum and the considered lidar property its capability to detect a material with a certain reflectance up to a certain range. A new material classification for lidar modelling in the automotive context is suggested, distinguishing between 7 material classes and 23 subclasses. To measure angle dependent reflectance in the infrared spectrum, a new measurement device based on a time of flight camera is introduced and calibrated using Lambertian targets with defined reflectance values at 10 % , 50 % , and 95 % . Reflectance measurements of 9 material subclasses are presented and 488 spectra from the NASA ECOSTRESS library are considered to evaluate the new measurement device. The parametrisation of the lidar capabilities is illustrated by presenting a lidar measurement campaign with a new Infineon lidar prototype and relevant data from 12 common lidar types. Full article
(This article belongs to the Special Issue LiDAR for Autonomous Vehicles)
Show Figures

Figure 1

Open AccessArticle
Local Bearing Estimation for a Swarm of Low-Cost Miniature Robots
Sensors 2020, 20(11), 3308; https://doi.org/10.3390/s20113308 - 10 Jun 2020
Viewed by 371
Abstract
Swarm robotics focuses on decentralised control of large numbers of simple robots with limited capabilities. Decentralised control in a swarm system requires a reliable communication link between the individuals that is able to provide linear and angular distances between the individuals—Range & [...] Read more.
Swarm robotics focuses on decentralised control of large numbers of simple robots with limited capabilities. Decentralised control in a swarm system requires a reliable communication link between the individuals that is able to provide linear and angular distances between the individuals—Range & Bearing. This study presents the development of an open-source, low-cost communication module which can be attached to miniature sized robots; e.g., Mona. In this study, we only focused on bearing estimation to mathematically model the bearings of neighbouring robots through systematic experiments using real robots. In addition, the model parameters were optimised using a genetic algorithm to provide a reliable and precise model that can be applied for all robots in a swarm. For further investigation and improvement of the system, an additional layer of optimisation on the hardware layout was implemented. The results from the optimisation suggested a new arrangement of the sensors with slight angular displacements on the developed board. The precision of bearing was significantly improved by optimising in both software level and re-arrangement of the sensors’ positions on the hardware layout. Full article
(This article belongs to the Special Issue Advanced Sensing and Control for Mobile Robotic Systems)
Show Figures

Figure 1

Open AccessArticle
Sensitivity Analysis of Sensors in a Hydraulic Condition Monitoring System Using CNN Models
Sensors 2020, 20(11), 3307; https://doi.org/10.3390/s20113307 - 10 Jun 2020
Viewed by 424
Abstract
Condition monitoring (CM) is a useful application in industry 4.0, where the machine’s health is controlled by computational intelligence methods. Data-driven models, especially from the field of deep learning, are efficient solutions for the analysis of time series sensor data due to their [...] Read more.
Condition monitoring (CM) is a useful application in industry 4.0, where the machine’s health is controlled by computational intelligence methods. Data-driven models, especially from the field of deep learning, are efficient solutions for the analysis of time series sensor data due to their ability to recognize patterns in high dimensional data and to track the temporal evolution of the signal. Despite the excellent performance of deep learning models in many applications, additional requirements regarding the interpretability of machine learning models are getting relevant. In this work, we present a study on the sensitivity of sensors in a deep learning based CM system providing high-level information about the relevance of the sensors. Several convolutional neural networks (CNN) have been constructed from a multisensory dataset for the prediction of different degradation states in a hydraulic system. An attribution analysis of the input features provided insights about the contribution of each sensor in the prediction of the classifier. Relevant sensors were identified, and CNN models built on the selected sensors resulted equal in prediction quality to the original models. The information about the relevance of sensors is useful for the system’s design to decide timely on the required sensors. Full article
(This article belongs to the Section Intelligent Sensors)
Show Figures

Graphical abstract

Open AccessLetter
Computationally Efficient Cooperative Dynamic Range-Only SLAM Based on Sum of Gaussian Filter
Sensors 2020, 20(11), 3306; https://doi.org/10.3390/s20113306 - 10 Jun 2020
Viewed by 362
Abstract
A cooperative dynamic range-only simultaneous localization and mapping (CDRO-SLAM) algorithm based on the sum of Gaussian (SoG) filter was recently introduced. The main characteristics of the CDRO-SLAM are (i) the integration of inter-node ranges as well as usual direct robot-node ranges to improve [...] Read more.
A cooperative dynamic range-only simultaneous localization and mapping (CDRO-SLAM) algorithm based on the sum of Gaussian (SoG) filter was recently introduced. The main characteristics of the CDRO-SLAM are (i) the integration of inter-node ranges as well as usual direct robot-node ranges to improve the convergence rate and localization accuracy and (ii) the tracking of any moving nodes under dynamic environments by resetting and updating the SoG variables. In this paper, an efficient implementation of the CDRO-SLAM (eCDRO-SLAM) is proposed to mitigate the high computational burden of the CDRO-SLAM due to the inter-node measurements. Furthermore, a thorough computational analysis is presented, which reveals that the computational efficiency of the eCDRO-SLAM is significantly improved over the CDRO-SLAM. The performance of the proposed eCDRO-SLAM is compared with those of several conventional RO-SLAM algorithms and the results show that the proposed efficient algorithm has a faster convergence rate and a similar map estimation error regardless of the map size. Accordingly, the proposed eCDRO-SLAM can be utilized in various RO-SLAM applications. Full article
Show Figures

Figure 1

Previous Issue
Next Issue
Back to TopTop
