Search Results (39)

Search Parameters:
Keywords = worm gear

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
18 pages, 3569 KiB
Article
The Influence of Carbon Nanotube Additives on the Efficiency and Vibrations of Worm Gears
by Milan Bukvić, Aleksandar Vencl, Saša Milojević, Aleksandar Skulić, Sandra Gajević and Blaža Stojanović
Lubricants 2025, 13(8), 327; https://doi.org/10.3390/lubricants13080327 - 26 Jul 2025
Viewed by 251
Abstract
Worm gears are used in various mechanical constructions, especially in heavy industrial plants, where they are exposed to high operating loads, large torques, and high temperatures, particularly in conditions where it is necessary for the input and output shafts to be at an [...] Read more.
Worm gears are used in various mechanical constructions, especially in heavy industrial plants, where they are exposed to high operating loads, large torques, and high temperatures, particularly in conditions where it is necessary for the input and output shafts to be at an angle of 90°. Regarding tribological optimization, the application of carbon nanotube in lubricants can lead to significant improvements in the performance characteristics of worm gears, both in terms of increasing efficiency and reducing the coefficient of friction and wear, as well as minimizing mechanical losses, noise, and vibrations. The objective of this study is for the research results, through the use of oil with varying percentages of carbon nanotube additives (CNTs), to contribute to the optimization of worm gears by improving efficiency, extending service life, and reducing vibrations—both within the gearbox itself and within the industrial facility where it is applied. The research methodology involved laboratory testing of a worm gear using lubricants with varying concentrations of carbon nanotube. During the experiment, measurements of efficiency, vibrations, and noise levels were conducted in order to determine the impact of these additives on the operational performance of the gear system. The main contribution of this research is reflected in the experimental confirmation that the use of lubricants with optimized concentrations of carbon nanotube significantly enhances the operational performance of worm gears by increasing efficiency and reducing vibrations and noise, thereby enabling tribological optimization that contributes to improved reliability, extended service life, and enhanced workplace ergonomics under demanding industrial conditions. Furthermore, experimental investigations have shown that the efficiency of the gearbox increases from an initial value of 0.42–0.65, which represents an increase of 54%, the vibrations of the worm gear decrease from an initial value of 5.83–2.56 mm/s2, which represents an decrease of 56%, while the noise was reduced from 87.5 to 77.2 dB, which represents an decrease of 12% with the increasing percentage of carbon nanotube additives in the lubricant, up to a maximum value of 1%. However, beyond this experimentally determined threshold, a decrease in the efficiency of the tested worm gearbox, as well as an increase in noise and vibration levels was recorded. Full article
(This article belongs to the Special Issue Friction–Vibration Interactions)
Show Figures

Figure 1

16 pages, 3808 KiB
Article
Mechanical Design, Control, and Laboratory Test of a Two-Degrees-of-Freedom Elbow Prosthesis
by Ramsés Hernández-Cerero, Juan Alejandro Flores-Campos, José Juan Mojica-Martínez, Adolfo Angel Casarez-Duran, Luis Angel Guerrero-Hernández and Christopher René Torres-SanMiguel
Bioengineering 2025, 12(7), 695; https://doi.org/10.3390/bioengineering12070695 - 25 Jun 2025
Viewed by 384
Abstract
This study presents the design and experimental testing of a two-degrees-of-freedom (2DOF) elbow prosthesis prototype designed to replicate the movement patterns of a native or normal human elbow. Two methods of the control of the prosthesis, namely, the proportional–integral–derivative method (PID; a well-established [...] Read more.
This study presents the design and experimental testing of a two-degrees-of-freedom (2DOF) elbow prosthesis prototype designed to replicate the movement patterns of a native or normal human elbow. Two methods of the control of the prosthesis, namely, the proportional–integral–derivative method (PID; a well-established method) and a combination of sliding mode control with a time base generator strategy (SMC + TBG; an advanced method), were compared on the basis of various performance metrics of the prosthesis, as obtained in laboratory tests. Among these metrics were the angular displacement and velocity as a function of time. The mechanical design combined 3D-printed components with custom-designed joints, featuring a worm gear transmission with a crown gear for flexion–extension, enhanced by torsional springs, and a pinion gear with a crown gear for pronation–supination and control. Sensors for voltage and current data acquisition enabled real-time monitoring and control. The prosthesis was tested in the laboratory with a range of motion of 100–120° for flexion–extension, 50° for supination, and 75° for pronation, demonstrating the adaptability of the actuators and validating their autonomy through battery-powered operation. The results showed that control using SMC + TBG resulted in biomimetic patterns for angular displacement and angular velocity of the prosthesis, whereas control using PID did not. Thus, the prosthesis with control provided using an SMC + TBG strategy may have been promised for use by people who have undergone transhumeral amputation. Full article
(This article belongs to the Special Issue Joint Biomechanics and Implant Design)
Show Figures

Figure 1

20 pages, 6458 KiB
Article
Research on Curvature Interference Characteristics of Conical Surface Enveloping Cylindrical Worm–Face Worm Gear Drive
by Shibo Mu, Xingwei Sun, Zhixu Dong, Heran Yang, Yin Liu, Weifeng Zhang, Sheng Qu, Hongxun Zhao and Yaping Zhao
Appl. Sci. 2025, 15(11), 6298; https://doi.org/10.3390/app15116298 - 3 Jun 2025
Viewed by 445
Abstract
This study proposes the use of Physics-Informed Neural Networks (PINNs) to further advance the curvature interference analysis method. The nonlinear equation system encountered in determining the curvature interference limit line is embedded into the PINN loss function, thereby enabling the solution of high-dimensional, [...] Read more.
This study proposes the use of Physics-Informed Neural Networks (PINNs) to further advance the curvature interference analysis method. The nonlinear equation system encountered in determining the curvature interference limit line is embedded into the PINN loss function, thereby enabling the solution of high-dimensional, nonlinear equations. Computational results demonstrate that the PINN model achieves a solution accuracy on the order of 10−13 when solving multidimensional nonlinear systems, which is comparable to the classical Fsolve algorithm. The curvature interference analysis reveals the presence of two curvature interference boundary lines, although they rarely extend to the worm gear tooth surface. A study on the influence of design parameters on the interference boundaries indicates that the axial installation distance has the greatest impact. Inadequate axial spacing causes the interference limit line to shift toward the inner end of the worm gear, significantly increasing the risk of interference in that region. The proposed curvature interference analysis method based on PINNs can be extended to other types of gear drives. It also lays the foundation for future work on establishing both forward and inverse mappings between design parameters and curvature interference using PINNs. Full article
(This article belongs to the Section Mechanical Engineering)
Show Figures

Figure 1

20 pages, 8510 KiB
Article
Study on the Wear Performance of Spiroid Worm Drive with Steel–Steel Meshing
by Yan Chen, Yun Pu and Yonghong Chen
Machines 2025, 13(3), 205; https://doi.org/10.3390/machines13030205 - 28 Feb 2025
Cited by 1 | Viewed by 632
Abstract
Worm drive belongs to the inclined plane transmission principle, and there is severe wear on the conjugate tooth surface. To reveal the wear mechanism and realize steel–steel meshing in the spiroid worm drive, the meshing performance model of conjugate tooth surface is established [...] Read more.
Worm drive belongs to the inclined plane transmission principle, and there is severe wear on the conjugate tooth surface. To reveal the wear mechanism and realize steel–steel meshing in the spiroid worm drive, the meshing performance model of conjugate tooth surface is established based on differential geometry theory and gear meshing principle, and the wear performance model is inferred by the Archard model and microscopic meshing performance. The wear performance of conjugate tooth surface is analyzed through the digital calculation, the pin-disk friction, and wear testing, as well as the spiroid worm drive prototype performance testing. The results show that there are good lubrication and anti-wear characteristics between the conjugate tooth surfaces, the wear amount on the right flank is twice that of the left flank, the wear depth at the loaded flank of the spiroid gear surface is smaller than that at the unloaded flank, as well as the feasibility of steel–steel meshing in worm drive has been confirmed. Full article
(This article belongs to the Section Machine Design and Theory)
Show Figures

Figure 1

30 pages, 3329 KiB
Article
Multi-Objective Remanufacturing Processing Scheme Design and Optimization Considering Carbon Emissions
by Yangkun Liu, Guangdong Tian, Xuesong Zhang and Zhigang Jiang
Symmetry 2025, 17(2), 266; https://doi.org/10.3390/sym17020266 - 10 Feb 2025
Cited by 1 | Viewed by 839
Abstract
In the face of escalating environmental degradation and dwindling resources, the imperatives of prioritizing environmental protection, and conserving resources have come sharply into focus. Therefore, remanufacturing processing, as the core of remanufacturing, becomes a key step in solving the above problems. However, with [...] Read more.
In the face of escalating environmental degradation and dwindling resources, the imperatives of prioritizing environmental protection, and conserving resources have come sharply into focus. Therefore, remanufacturing processing, as the core of remanufacturing, becomes a key step in solving the above problems. However, with the increasing number of failing products and the advent of Industry 5.0, there is a heightened request for remanufacturing in the context of environmental protection. In response to these shortcomings, this study introduces a novel remanufacturing process planning model to address these gaps. Firstly, the failure characteristics of the used parts are extracted by the fault tree method, and the failure characteristics matrix is established by the numerical coding method. This matrix includes both symmetry and asymmetry, thereby reflecting each attribute of each failure feature, and the remanufacturing process is expeditiously generated. Secondly, a multi-objective optimization model is devised, encompassing the factors of time, cost, energy consumption, and carbon emission. This model integrates considerations of failure patterns inherent in used parts and components, alongside the energy consumption and carbon emissions entailed in the remanufacturing process. To address this complex optimization model, an improved teaching–learning-based optimization (TLBO) algorithm is introduced. This algorithm amalgamates Pareto and elite retention strategies, complemented by local search techniques, bolstering its efficacy in addressing the complexities of the proposed model. Finally, the validity of the model is demonstrated by means of a single worm gear. The proposed algorithm is compared with NSGA-III, MPSO, and MOGWO to demonstrate the superiority of the algorithm in solving the proposed model. Full article
Show Figures

Figure 1

15 pages, 15889 KiB
Article
Slewing and Active Vibration Control of a Flexible Single-Link Manipulator
by Dae W. Kim, Moon K. Kwak, Soo-Min Kim and Brian F. Feeny
Actuators 2025, 14(2), 43; https://doi.org/10.3390/act14020043 - 22 Jan 2025
Cited by 1 | Viewed by 940
Abstract
This study focuses on the slewing and vibration suppression of flexible single-link manipulators. While extensive research has been conducted on such systems, few studies have experimentally validated their theoretical models. To address this gap, an experimental setup is developed, connecting the flexible link [...] Read more.
This study focuses on the slewing and vibration suppression of flexible single-link manipulators. While extensive research has been conducted on such systems, few studies have experimentally validated their theoretical models. To address this gap, an experimental setup is developed, connecting the flexible link to a zero-backlash worm gear and further attaching it to the rotor shaft of the AC servomotor. The worm gear’s characteristics isolate the link’s vibrations from the rotor’s angular motion, enabling independent design of the vibration controller and slewing control. This approach facilitates simultaneous accurate trajectory tracking and vibration suppression. An active vibration control algorithm is implemented based on an accurate dynamic model. This research encompasses dynamic modeling, slewing control, and vibration control for the system. Theoretical predictions are compared with experimental results to validate both the theoretical model and the proposed vibration control algorithm. Full article
(This article belongs to the Special Issue Nonlinear Active Vibration Control)
Show Figures

Figure 1

20 pages, 1327 KiB
Article
Generalization Process of the Integrated Mathematical Model Created for the Development of the Production Geometry of Complicated Surfaces
by Zsuzsa Balajti
Symmetry 2024, 16(12), 1618; https://doi.org/10.3390/sym16121618 - 6 Dec 2024
Cited by 1 | Viewed by 878
Abstract
Computer modelling of technical constructions is increasingly carried out using software that includes more detailed knowledge, which requires an increase in the level as well as an expansion of the scope of the geometric knowledge. A significant part of motion transmission mechanisms are [...] Read more.
Computer modelling of technical constructions is increasingly carried out using software that includes more detailed knowledge, which requires an increase in the level as well as an expansion of the scope of the geometric knowledge. A significant part of motion transmission mechanisms are worm drive pairs, for which the separation of the parts dealing with the theoretical and practical problems found in the literature can be experienced in numerous instances. Due to the different technical features, in many cases the helical surfaces are not designed and manufactured in a geometrically correct way, or the best solution is not the compulsory chosen. The geometric model describing the production process of the worm surfaces provides the basis for examining the deviation between the surface mathematically determined by the designer and the surface produced. An integrated mathematical kinematic model was developed for the production geometrical analysis of the elements of cylindrical and conical worm gear drive pairs for machining with a traditional thread grinding machine, which causes a serious pitch fluctuating error among several other problems in the case of machining the conical worm. Modelling of the production process of surfaces and the simultaneous study of the manufacturing errors is basically performed with the toolbox of descriptive geometry, including the use of the projective invariants. Knowing the inheritance of the invariants of projective geometry, the aim was the mathematical generalization of the integrated model and the creation of a projective relationship between the reference surfaces of conical and cylindrical spiral surfaces. As a result, the improved constructive geometric model was created, in which the method of analytically creating the projective geometric relationship between the reference surfaces of conical and cylindrical helicoid surfaces has been described for the first time in this article. This procedure is considered the most important result of the present article. Another significance of the further development presented is that during production of the conical helicoid surface, the thread pitch fluctuation has been eliminated. The results obtained, consisting of an improved geometric model, lead to a new geometry of the technological environment regarding the relative position of the cutting tool and the workpiece as well as the relative motion between them. Full article
(This article belongs to the Section Mathematics)
Show Figures

Figure 1

19 pages, 28273 KiB
Article
Research on the Principle and Suppression Method of Micro-Vibration Generation in a Spatial Optoelectronic Mechanism
by Bo Gao, Hongtao Yang, Weining Chen, Hao Wang, Zimiao Qi and Yang Liu
Machines 2024, 12(12), 857; https://doi.org/10.3390/machines12120857 - 27 Nov 2024
Viewed by 703
Abstract
This paper designs a spatial photoelectric scanning mechanism that utilizes the large transmission ratio and reverses the self-locking performance of worm gears and gears. The institution uses a stepper motor to drive the worm gear component, thereby driving the worm gear to drive [...] Read more.
This paper designs a spatial photoelectric scanning mechanism that utilizes the large transmission ratio and reverses the self-locking performance of worm gears and gears. The institution uses a stepper motor to drive the worm gear component, thereby driving the worm gear to drive the alarm camera for spatial alarm imaging work. The stepper motor provides the driving force for motion, and, simultaneously, the alarm camera image can be compared with the star map to achieve position feedback. Therefore, this mechanism can achieve closed-loop control without angle measuring devices, achieving the lightweight design of the photoelectric scanning mechanism. Although this driving mechanism has many advantages, due to the micro-vibration formed by the gear backlash between teeth during the operation of the worm gear and worm, micro-vibrations are generated in the system, which can interfere with satellites with high precision requirements and affect their normal operation. This paper analyzes and experimentally verifies the principle of micro-vibrations in the worm gear and worm movement mechanism, and takes a certain photoelectric scanning turntable as an example to suppress micro-vibrations. The micro-vibration momentum level has been reduced from 7 N (at its peak) to 3.5 N (at its peak), with the number of targets increased by 50%, resulting in an effective suppression effect. Full article
(This article belongs to the Section Machine Design and Theory)
Show Figures

Figure 1

18 pages, 16366 KiB
Article
Investigation of Effect of Surface Modification by Electropolishing on Tribological Behaviour of Worm Gear Pairs
by Robert Mašović, Suzana Jakovljević, Ivan Čular, Daniel Miler and Dragan Žeželj
Lubricants 2024, 12(12), 408; https://doi.org/10.3390/lubricants12120408 - 24 Nov 2024
Viewed by 1171
Abstract
Electropolishing using a high-current density results in a pitting phenomenon, producing a surface texture distinguished by many pits. Apart from the change in surface topography, electropolishing forms an oxide surface layer characterized by beneficial tribological properties. This paper introduces surface texturing in worm [...] Read more.
Electropolishing using a high-current density results in a pitting phenomenon, producing a surface texture distinguished by many pits. Apart from the change in surface topography, electropolishing forms an oxide surface layer characterized by beneficial tribological properties. This paper introduces surface texturing in worm gear pairs by electropolishing a 16MnCr5 steel worm surface. Electropolishing produces surface pits 1 μm to 5 μm deep and 20 to 100 μm in diameter. The material characterization of 16MnCr5 steel is compared against the electropolished 16MnCr5 steel based on microstructure, hardness, surface topography and chemical composition. Experimental tests with worm pairs employing electropolished worms are conducted, and the results are compared to conventional worm pairs with ground steel worms. Electropolished worms show up to 5.2% higher efficiency ratings than ground ones and contribute to better running-in of worm gear pairs. Moreover, electropolished worms can reliably support full contact patterns and prevent scuffing due to improved lubrication conditions resulting from the produced surface texture and oxide surface layer. Based on the obtained results, electropolishing presents a promising method for surface texturing and modification in machine elements characterized by highly loaded non-conformal contacts and complex geometry. Full article
(This article belongs to the Special Issue Mechanical Tribology and Surface Technology)
Show Figures

Figure 1

17 pages, 6606 KiB
Article
An Attempt to Establish a Mathematical Model for an Unconventional Worm Gear with Bearings
by Simion Haragâș, Roland Ninacs, Ovidiu Buiga, Lucian Tudose, Alexandru Haragâș, Ioana Monica Sas-Boca and Felicia Aurora Cristea
Appl. Sci. 2024, 14(23), 10833; https://doi.org/10.3390/app142310833 - 22 Nov 2024
Viewed by 1322
Abstract
The aim of this paper is to develop a mathematical model for an unconventional worm gear consisting of a globoid worm and a worm wheel where the teeth are bearings. Using rolling elements such the teeth of the worm wheel (ball bearings) transforms [...] Read more.
The aim of this paper is to develop a mathematical model for an unconventional worm gear consisting of a globoid worm and a worm wheel where the teeth are bearings. Using rolling elements such the teeth of the worm wheel (ball bearings) transforms the sliding friction to rolling friction during the process of worm gear meshing, improving power. The geometry of the component elements of the gear is analyzed in correlation with its kinematics. After the creation of the mathematical model, it is validated both analytically (through complex graphic representations) and experimentally (by creating, for a particular case, the 3D model and the concrete physical model (prototype) of the gear through 3D printing). Full article
(This article belongs to the Special Issue Machine Tools, Advanced Manufacturing and Precision Manufacturing)
Show Figures

Figure 1

22 pages, 15722 KiB
Article
Mathematical Modeling and Generating Method of Hourglass Worm Gear Hob’s Rake Face Based on a Rotating Paraboloid Surface
by Yupeng Li, Jie Yang, Run Gu, Zhijiang Chen and Chunming Xia
Machines 2024, 12(11), 770; https://doi.org/10.3390/machines12110770 - 1 Nov 2024
Cited by 1 | Viewed by 1353
Abstract
The rake angles on both sides of the cutting edges of the hourglass worm gear hob significantly influence its cutting performance, which, in turn, plays a decisive role in the surface quality of the machined worm wheel. To balance the rake angles along [...] Read more.
The rake angles on both sides of the cutting edges of the hourglass worm gear hob significantly influence its cutting performance, which, in turn, plays a decisive role in the surface quality of the machined worm wheel. To balance the rake angles along the tooth height direction of each hob tooth and enhance the overall cutting performance of the hob, this paper proposes a method that utilizes a rotating paraboloid surface to generate the helical rake face of the hourglass worm gear hob. First, the conjugate condition equations for the rake face generated by the rotating paraboloid surface are derived. A mathematical model for the helical rake face of planar double-enveloping hourglass worm gear hob is established. This study explores the influence of two machining parameters on the rake angle, specifically the milling drive ratio coefficient k and the geometric parameter of a parabolic milling cutter p. Through a systematic analysis of the variations in rake angle at the dividing toroidal surface and along the tooth height direction, the optimal parameter values were identified as k = 0.9115 and p = 0.6834. The results show that, after optimization, the hob rake angle range is around ±4.7°, with a maximum rake angle difference of 6.3072° along the tooth height direction, and the rake angles on both sides of the teeth are more balanced. The structure of the rake face is more reasonable, reflecting the feasibility of rotating paraboloid tools for forming tools in the machining of complex surfaces. Full article
(This article belongs to the Section Machine Design and Theory)
Show Figures

Figure 1

20 pages, 7107 KiB
Article
Design, Experiments, and Path Planning for a Lightweight 3D Minimally Actuated Serial Robot with a Mobile Actuator
by Or Bitton, Avi Cohen and David Zarrouk
Appl. Sci. 2024, 14(18), 8204; https://doi.org/10.3390/app14188204 - 12 Sep 2024
Viewed by 1354
Abstract
This paper presents a novel three-dimensional (3D) minimally actuated serial robot (MASR) and its unique kinematic analysis. Unlike traditional robots, the 3D MASR features a passive arm devoid of wires or motors, comprising passive rotational and prismatic joints. A single mobile actuator (MA) [...] Read more.
This paper presents a novel three-dimensional (3D) minimally actuated serial robot (MASR) and its unique kinematic analysis. Unlike traditional robots, the 3D MASR features a passive arm devoid of wires or motors, comprising passive rotational and prismatic joints. A single mobile actuator (MA) traverses the arm, engages designated joints for operation, and locks them in place with a worm gear setup. A gripper is attached to the MA, enabling object transportation along the arm, reducing joint actuation, and optimizing task completion time. Our key contributions include the mechanical design, and in particular the robot’s passive joints with their automated actuation mechanism, and a novel optimization algorithm leveraging neural networks (NNs) to minimize task completion time through advanced kinematic analysis. Experiments with a physical prototype of the 3D MASR demonstrate its major advantages: it is remarkably lightweight (2.3 kg for a 1 m long arm and a 1 kg payload) compared to similar robots; it is highly modular (five joints R and P actuated by a single MA); and part replacement is effortless due to the absence of wiring along the arm. These features are visually depicted in the accompanying video. Full article
Show Figures

Figure 1

24 pages, 12878 KiB
Article
Design and Testing of an Inter-Toothed, Self-Propelled Digger for Deep-Rhizome Chinese Herbal Medicines
by Peng Wu, Wei Sun, Hucun Wang, Luhai Zhang and Petru A. Simionescu
Agronomy 2024, 14(9), 2024; https://doi.org/10.3390/agronomy14092024 - 5 Sep 2024
Cited by 3 | Viewed by 1311
Abstract
To address the challenges of digging deep-rhizome Chinese herbal medicines in northwest China’s hilly terrain, including difficulty, incompleteness, and herb damage, a specialized self-propelled digger with interlocking teeth has been developed. Designed for complex topography, small fields, and resistant soil, this digger provides [...] Read more.
To address the challenges of digging deep-rhizome Chinese herbal medicines in northwest China’s hilly terrain, including difficulty, incompleteness, and herb damage, a specialized self-propelled digger with interlocking teeth has been developed. Designed for complex topography, small fields, and resistant soil, this digger provides an efficient and precise alternative to traditional methods. The prototype features in-place reverse differential steering, 360-degree digging capability, and minimized root and soil damage to promote future planting. Key components, including the digging mechanism, vibratory system, crawler chassis, hydraulic transmission system, and worm gear rotary hydraulic reducer, were analyzed and optimized through theoretical, graphical, and simulation studies using RecurDyn. Field tests demonstrated the digger’s effectiveness, achieving depths exceeding 600 mm with minimal herb damage and loss. The digger successfully navigated steep slopes and operated within noise regulations, surpassing industry standards, with less than 1.4% herb damage and a loss rate under 3%. The digger was capable of ascending gradients over 20° with driver noise levels below 92 dB. This innovative solution offers a valuable reference for developing specialized diggers for harvesting traditional Chinese medicinal materials in challenging conditions. Full article
(This article belongs to the Section Precision and Digital Agriculture)
Show Figures

Figure 1

13 pages, 9651 KiB
Article
Design and Fatigue Life Analysis of the Rope-Clamping Drive Mechanism in a Knotter
by Jianjun Yin, Zefu Chen, Shiyu Lv, Han Wu, Yansu Gao and Luning Wu
Agriculture 2024, 14(8), 1254; https://doi.org/10.3390/agriculture14081254 - 30 Jul 2024
Cited by 2 | Viewed by 1459
Abstract
A knotter is a core component for the automatic bundling of agricultural materials, and a knotter with double-fluted discs is one type. Currently, the research on knotters with double-fluted discs has gradually transitioned from structural design to reliability optimization. To address rope-clamping failures [...] Read more.
A knotter is a core component for the automatic bundling of agricultural materials, and a knotter with double-fluted discs is one type. Currently, the research on knotters with double-fluted discs has gradually transitioned from structural design to reliability optimization. To address rope-clamping failures in the rope-clamping drive mechanisms in knotters, the specific failure position of the rope-clamping mechanism and the failure causes were analyzed first. The redesign of the rope-clamping drive mechanism in knotters with double synclastic fluted discs was proposed, including structure optimization and 3D modeling using the GearTrax/KISSsoft and SolidWorks software. A virtual prototype model of a knotter with a flexible rope was established by combining ANSYS with the ADAMS software. A rigid–flexible coupling dynamic simulation of the knotter was carried out using ADAMS, and the simulation results were used as the data input for the ANSYS nCode DesignLife module for the fatigue life simulation of the weak parts (the worm shaft) of the knotter. The operation test results for the rope-clamping drive mechanism indicate that the redesigned rope-clamping drive mechanism is reliable in transmission, with a rope-clamping success rate of 100%. The actual operation times for the worm shaft exceed the minimum fatigue life obtained through joint simulation. The applied joint simulation method has high simulation accuracy. Full article
Show Figures

Figure 1

16 pages, 7940 KiB
Article
Design and Characteristic Research on Variable Displacement Mechanism of Two-Dimensional (2D) Bivariable Pump
by Tong Xing, Xu Ji, Zeri Yang and Jian Ruan
Energies 2024, 17(7), 1725; https://doi.org/10.3390/en17071725 - 3 Apr 2024
Cited by 1 | Viewed by 1291
Abstract
In a hydraulic system, a micro variable pump is required to be high pressure and high speed, and this work presents a new type of 2D bivariable pump structure in which the worm gear and worm mechanism are used to rotate the cylinder [...] Read more.
In a hydraulic system, a micro variable pump is required to be high pressure and high speed, and this work presents a new type of 2D bivariable pump structure in which the worm gear and worm mechanism are used to rotate the cylinder block to change the flow distribution state of the cylinder window and the piston groove to change the displacement of the 2D pump. The flow–pressure mathematical model of the 2D variable pump is established to analyze the relationship between pump displacement and the pump cylinder rotation angle and the effects of variable displacement on pump pressure characteristics, flow characteristics, and volume efficiency in Matlab. During the experiment, we tested the change in the corresponding pump output flow when the cylinder rotation angle is 0~12°, which verifies the correctness of the variable calculation model. The experimental results indicate that the volume efficiency and mechanical efficiency of the single-piston 2D pump are reduced to different degrees after variable displacement, the volume efficiency is reduced by approximately 3% at most, and the mechanical efficiency is reduced by approximately 5% at most. Full article
Show Figures

Figure 1
