Search Results (89)

Existing ground-slotted coplanar waveguide (CPW) spoof surface plasmon polariton (SSPP) low-pass filters (LPFs) remain constrained by the difficulty of achieving a wide stopband while maintaining a compact size, as well as by undesired radiation leakage arising from their open-aperture slot configuration. To address these issues, a grounded coplanar waveguide spoof surface plasmon polariton (GCPW-SSPP) low-pass filter based on a multi-arm star-shaped slot (MASS) loading topology is proposed. An equivalent-circuit interpretation and full-wave dispersion analysis show that the multi-arm slots introduce enhanced distributed reactive loading, thereby lowering the asymptotic frequency and enabling compact SSPP implementations. The near-field characteristics further demonstrate tighter electromagnetic confinement, as reflected by an approximately 48% reduction in the electric-field confinement width along the z-direction. To alleviate the trade-off between miniaturization and wide-stopband performance in cascaded SSPP LPFs, the single-cell S-parameters of the proposed topology are investigated. A single MASS unit exhibits a sharp cutoff and a deep transmission notch, allowing a wide stopband to be obtained with fewer cascaded cells. Radiation characteristics are subsequently quantified by a loss-decomposition method, and the MASS topology is found to suppress the radiation leakage of open-aperture ground-slotted structures, yielding a maximum radiation-loss reduction of approximately 75%. To validate the design methodology, a MASS-loaded GCPW-SSPP LPF is designed, fabricated, and measured. The measured results are in good agreement with the simulated ones, confirming the effectiveness of the proposed scheme. By simultaneously achieving a wide stopband, compact size, and suppressed radiation leakage, the proposed filter offers a promising low-interference filtering solution for highly integrated microwave and RF front-end systems. Full article

This paper presents the fabrication and experimental characterization of a 316L stainless-steel WR-90 waveguide horn antenna manufactured using selective laser melting (SLM) and operating across the X-band (8.2–12.4 GHz). The antenna is designed based on standard WR-90 waveguide theory and incorporates a coaxial-to-waveguide transition and a flared radiating aperture to achieve stable aperture-based radiation. Full-wave electromagnetic simulations are performed to establish baseline impedance, radiation pattern, and gain performance prior to fabrication. The SLM-fabricated prototype is evaluated through reflection coefficient, radiation pattern, and realized gain measurements conducted in an anechoic chamber. Measured results confirm stable impedance matching across the entire band, with |S₁₁| below −10 dB and a minimum of −22.34 dB near 10.1 GHz. The radiation patterns closely follow simulation predictions, with half-power beamwidth deviations below 4%. The realized gain increases from 11.2 dBi to 15.8 dBi across the band, with simulation–measurement deviation decreasing to within 0.5 dB above 10 GHz. Rather than focusing on antenna design novelty, this work employs a standardized WR-90 horn antenna as a benchmark structure to isolate fabrication-induced effects. A quantitative performance analysis is introduced by converting the gain deviation into an equivalent efficiency reduction, providing a practical framework for evaluating fabrication-induced electromagnetic degradation in SLM-fabricated waveguide components. Full article

This research presents a lens-based light collection system that integrates a handmade glass conical waveguide (GCW) with a single silica multimodal optical fiber (SMMF) and a concentrator Fresnel lens (FL). The GCW functions as a secondary optical element (SOE), effectively expanding the fiber’s receptive area and enabling efficient coupling of concentrated light. Calibrated ray-tracing simulations confirm that the complete FL + GCW + SMMF configuration maintains low transmission losses, thereby validating efficient coupling into the SMMF. Experimental results demonstrated a maximum net optical efficiency of 41% at an FL numerical aperture (NA) of 0.08, with GCW transmission reaching 60% and splice losses to the SMMF around 34%. With a luminous flux input of 155 lumens, the system delivered up to 63 lumens at the fiber output. Importantly, the FL + GCW + SMMF configuration combines reproducible fabrication, straightforward assembly, and reliable characterization, establishing a scalable pathway for daylight harvesting. The major contribution of this work is the demonstration that a simple, manufacturable GCW can substantially expand the effective collection area of multimodal fibers while preserving low optical losses, thereby bridging practical design with efficient energy transfer for sustainable photonics applications. Full article

A novel wideband 1-bit reconfigurable transmitarray (RTA) is proposed, which is based on a substrate-integrated cavity-backed patch (SCIBP) element. The RTA element consists of a pair of SCIBP antennas, achieving wideband operational capability through the optimization of dielectric substrate thickness. To suppress surface-wave propagation between adjacent RTA elements, a substrate-integrated waveguide (SIW) is designed to function as a metallic isolation wall. A 180° phase shift is realized by dynamically manipulating p-i-n diodes embedded within the SCIBP antenna structure. When the dielectric substrate thickness is increased from 6 mm to 10 mm, the 3 dB transmission bandwidth is expanded from 10% to 33.6%. The simulation results confirm that the proposed element realizes a 3 dB transmission bandwidth of 33.6%. A prototype RTA with 100 elements is designed, fabricated, and measured. The prototype achieves a peak gain of 16.6 dBi at 4.6 GHz, accompanied by an aperture efficiency of 17.2% and a 3 dB gain bandwidth of 18.9%. Furthermore, measured scanned beams illustrate that the proposed RTA possesses good beamscanning performance. Owing to its many advantages, such as wideband operation, lightweight design, low cost, simple structure, and easy fabrication, it is particularly suitable for application in intelligent communication systems and radar systems. Full article

The terahertz (THz) band offers ultra-wide bandwidth for next-generation high-speed wireless communication systems. However, achieving compact, high-gain, and beam-symmetric THz antennas remains challenging due to fabrication and propagation constraints. This paper presents a simulation-based design and optimization of a stacked substrate-integrated waveguide (SIW) pyramidal horn antenna achieving equal half-power beamwidths (HPBWs) in both E- and H-planes. The design employs vertically stacked SIW layers coupled through optimized slot apertures to ensure dominant TE₁₀ mode propagation with minimal reflection. Using full-wave electromagnetic simulations, the effects of layer number, dielectric loading, amplitude tapering, and phase distribution are systematically analyzed. The optimized five-layer configuration exhibits 10 dBi gain, 41° HPBW, and sidelobe levels around −3.2 dB at 210 GHz. This framework aims to develop high-performance, beam-symmetric THz SIW antennas compatible with standard LTCC/PCB technologies. Full article

High-Intensity Radiated Fields (HIRFs) can cause severe interference to airborne GNSS equipment. This paper builds a CST model based on the real structure and evaluates shielding effectiveness (SE) with respect to frequency, material, polarization, angle of incidence, and aperture; anechoic-chamber tests combined with the DO-160G compliance method (Section 20, Class G) are then conducted, and this integrated scheme: (1) validates the simulation’s effectiveness and confirms the HIRF coupling risk; (2) reveals the GNSS failure mechanism—C/N₀ decrease → DOP increase → loss of lock. Subsequently, an equation-based mechanism framework (cavity modes, slot/aperture coupling, waveguide-below-cutoff, thickness attenuation) is proposed, together with an effective-dimension correction, by which a single-point calibration can predict the remaining resonances. Accordingly, mechanism-aligned design strategies are provided (aperture control and honeycomb windows, geometric detuning and local absorbers, high-permeability inserts, multi-polarization and multi-directional protection), achieving predictable, verifiable, and quantifiable improvements in SE. Full article

We present a compact dielectric lens integrated at the aperture of a WR90 rectangular waveguide, achieved using polytetrafluoroethylene (PTFE). This innovative configuration enables, for the first time in the X- and Ku-bands, the direct generation of a subwavelength electromagnetic jet from a guided structure. The beam exhibits the hallmark features of an electromagnetic jet: strong near-field focusing, a subwavelength beam width surpassing the diffraction limit, and a quasi-planar wavefront sustained over a propagation distance of about $2\lambda$. The lens design was systematically optimized, and its performance was assessed through full-wave finite element simulations and experimentally validated on a fabricated prototype. Excellent agreement between the simulation and measurement confirms the robustness of the approach. Beyond its simplicity and low cost, this solution achieves state-of-the-art focusing performance compared to free-space and guided-wave alternatives. It offers strong potential for applications in high-resolution imaging, precision sensing, and material characterization, particularly in opaque or highly lossy environments. Full article

Waveguide-integrated metasurfaces offer a promising platform for ultracompact on-chip optical systems, enabling applications such as fluorescence sensing, holography, and near-eye displays. In particular, integrated achromatic metalenses that couple guided modes to free-space radiation are highly desirable for single-molecule fluorescence sensing, where high numerical aperture (NA), efficient light focusing, and consistent focal volume overlap across excitation and emission wavelengths are critical. However, designing integrated high-NA metalenses with multi-wavelength operation remains fundamentally challenging due to the wavelength-dependent propagation of guided modes. Here, we present an inverse design framework that simultaneously optimizes the geometries and positions of silicon nitride nanofins atop a slab waveguide to achieve diffraction-limited focusing at three wavelengths with unity NA. The resulting metalens outperforms conventional segmented designs in focusing efficiency and sidelobe suppression, particularly at wavelengths corresponding to the excitation and emission bands of the model fluorophore Alexa Fluor 647. Numerical analysis shows that the design yields a high molecule detection efficiency suitable for epi-fluorescence single-molecule sensing. This work highlights the potential of inverse-designed metalenses as a versatile on-chip platform for advanced applications in fluorescence spectroscopy, augmented reality, or optical trapping. Full article

High-gradient accelerating radio frequency (RF) ] cavities are currently being developed in several national laboratories for applications in high-energy physics. Ultra-high accelerating gradients, reaching up to the GV/m range, can be achieved using ultra-compact accelerating structures operating in the sub-terahertz (sub-THz) regime. However, accurately measuring the key RF parameters of such compact structures presents significant experimental challenges, and even minor inaccuracies can lead to substantial errors. Additionally, RF simulations for these cavities often require extensive computational resources. Among the most critical parameters to determine is the reflection coefficient. To provide a fast and accurate analytical estimation, we have developed an electromagnetic theory describing the coupling between a resonant cavity and an RF waveguide. This approach is based on Bethe’s small-aperture polarization method, further developed by Collin. An exact analytical expression for the reflection coefficient is presented, formulated as a function of the physical parameters of the cavity waveguide system and applicable to arbitrary geometries, materials, and frequencies. Full article

A passive time reversal method with a metamodel (PTR-MM) is proposed to improve underwater source localization under ocean conditions. PTR-MM eliminates model mismatch errors by replacing the conventional sound propagation model with a Kriging metamodel. This metamodel is optimally constructed based on measured sound field data. The method combines a metamodel with a passive time reversal (PTR) process to generate a focused sound field whose intensity peaks correspond to source positions. In numerical simulations using the KRAKEN model in a range-independent waveguide, PTR-MM accurately localizes single and multiple sources, is insensitive to mismatches in key environmental parameters, and maintains unbiased performance down to −20 dB signal-to-noise ratios (SNRs). Experimental validation on the SWellEx-96 Event S5 dataset confirms that PTR-MM outperforms conventional PTR in both single- and dual-source localizations, achieving most mean absolute percentage errors (MAPEs) below 10% when trained and tested in consistent environments. Further studies reveal that localization accuracy depends primarily on signal quality, array aperture, and element spacing, rather than on source frequency. However, PTR-MM performance degrades if the metamodel is trained in an environment that differs from the test conditions. The above findings demonstrate the potential of combining PTR with a metamodel for robust and real-time localization. Full article

Acoustic temperature measurement (ATM) and sound source localization (SSL) are two important applications of acoustic sensors. The development of novel acoustic sensors capable of both ATM and SSL is an innovative research topic with great interest. In this work, an acoustic Fabry-Perot resonance detector (AFPRD) and its cross-shaped array were designed and fabricated, and the passive ATM function of the AFPRD and the SSL capability of the AFPRD array were simulated and experimentally verified. The AFPRD consists of an acoustic waveguide and a microphone with its head inserted into the waveguide, which can significantly enhance the microphone’s sensitivity via the FP resonance effect. As a result, the frequency response curve of AFPRD can be easily measured using weak ambient white noise. Based on the measured frequency response curve, the linear relationship between the resonant frequency and the resonant mode order of the AFPRD can be determined, the slope of which can be used to calculate the ambient sound velocity and air temperature. The AFPRD array was prepared by using four bent acoustic waveguides to expand the array aperture, which combined with the multiple signal classification (MUSIC) algorithm can be used for distant multi-target localization. The SSL accuracy can be improved by substituting the sound speed measured in real time into the MUSIC algorithm. The AFPRD’s passive ATM function was verified in an anechoic room with white noise as low as 17 dB, and the ATM accuracy reached 0.4 °C. The SSL function of the AFPRD array was demonstrated in the outdoor environment, and the SSL error of the acoustic target with a sound pressure of 35 mPa was less than 1.2°. The findings open up a new avenue for the development of multifunctional acoustic detection devices and systems. Full article

Extended coprime sparse array (ECSA) has been widely used in signal processing, which realizes direction-of-arrival (DOA) estimation with fewer sensors. Accordingly, via spatial smoothing technique, an augmented sample covariance matrix was constructed. Then, the MUltiple SIgnal Classification (MUSIC) algorithm was applied in DOA estimation with higher-resolution ability, which is comparable to that of a uniform full array sharing the same aperture. As far as the application of underwater bottom-mounted horizontal ECSA, due to the property of multipath arrival, the estimated source bearing lies in between the true source bearing and the broadside direction of ECSA. Basically, for the problem of identifying a specific target in the presence of interferers, with regard to both bearing resolution performance and corresponding estimation accuracy, a relationship with the true source positions was established. It was proven that the MUSIC algorithm suffers from an intrinsic error, which is driven by energy-dominant modes in the waveguide. Based on the multimode phenomenon, this paper reveals the influence of source position, especially the angular arrangement. Additionally, on the premise of successful target resolution, reference sound speed substitution was carried out to achieve improved bearing estimation accuracy. The results are herein demonstrated with both numerical simulation and experimental data. Full article

This paper proposes a mechanically reconfigurable multi-polarization antenna based on a 3D-printed anisotropic dielectric polarizer, offering wide bandwidth, high gain, and extremely low cost. The working mechanism of the dielectric polarizer is analyzed, demonstrating its ability to efficiently convert linear polarization (LP) to circular polarization (CP) over a wide frequency range. Furthermore, the polarizer exhibits subwavelength characteristics. For a given duty cycle, its phase response depends only on the height and is independent of the aperture size. This property enables miniaturized and customized designs of the polarizer’s aperture size. Subsequently, the polarizer is placed above a Ku band waveguide and standard horn antennas. The results show that by rotating the dielectric polarizer and adjusting the positions of the antennas, right-handed CP (RHCP), left-handed CP (LHCP), and dual LP radiation switching can be achieved in the 12.4–18.0 GHz band, verifying the quad-polarization reconfigurability. Additionally, the polarizer significantly enhances the gain of the waveguide antenna by approximately 9.5 dB. Furthermore, due to the low-cost 3D printing material, the manufacturing cost of the polarizer is exceptionally low, making it suitable for applications such as anechoic chamber measurements and wireless communications. Finally, the measurement results further validate the accuracy of the simulations. Full article

This paper presents the design of a high-isolation directional coupler for X-band applications, utilizing substrate-integrated waveguide (SIW) technology. The coupler features a simple structure, compact size, and ease of integration with other planar circuits. Typically, the S-parameters of a directional coupler are determined by the dimensions of the SIW and the aperture (or hole) of the coupler. In this study, we introduce additional via lines to modify the SIW and the coupler aperture, aiming to achieve high isolation. First, two via lines are embedded in the center, converging into two central vias that form the coupler’s aperture. The power ratio within the coupler is controlled by adjusting the width of the aperture and the overall width of the SIW. Specifically, the width of the SIW at the aperture position is affected by adding vias on the two outer sides of the SIW. By incorporating these vias, we can effectively manage the power distribution across the four ports while ensuring sufficient isolation among them. The proposed design achieves an insertion loss of 3.3 dB, a coupling factor of 6 dB, and an isolation factor of 28.6 dB at 10 GHz. The experimental results demonstrate that the coupler maintains $S_{41}$ less than −20 dB over a 30% fractional bandwidth, ranging from 8.6 GHz to 11.6 GHz. Full article

Landslides present a significant global hazard, resulting in substantial socioeconomic losses and casualties each year. Traditional monitoring approaches, such as geodetic, geotechnical, and geophysical methods, have limitations in providing early warning capabilities due to their inability to detect precursory subsurface deformations. In contrast, the acoustic emission (AE) technique emerges as a promising alternative, capable of capturing the elastic wave signals generated by stress-induced deformation and micro-damage within soil and rock masses during the early stages of slope instability. This paper provides a comprehensive review of the fundamental principles, instrumentation, and field applications of the AE method for landslide monitoring and early warning. Comparative analyses demonstrate that AE outperforms conventional techniques, with laboratory studies establishing clear linear relationships between cumulative AE event rates and slope displacement velocities. These relationships have enabled the classification of stability conditions into “essentially stable”, “marginally stable”, “unstable”, and “rapidly deforming” categories with high accuracy. Field implementations using embedded waveguides have successfully monitored active landslides, with AE event rates linearly correlating with real-time displacement measurements. Furthermore, the integration of AE with other techniques, such as synthetic aperture radar (SAR) and pore pressure monitoring, has enhanced the comprehensive characterization of subsurface failure mechanisms. Despite the challenges posed by high attenuation in geological materials, ongoing advancements in sensor technologies, data acquisition systems, and signal processing techniques are addressing these limitations, paving the way for the widespread adoption of AE-based early warning systems. This review highlights the significant potential of the AE technique in revolutionizing landslide monitoring and forecasting capabilities to mitigate the devastating impacts of these natural disasters. Full article
