This article presents the simulation results of inter-turn short circuits in the stator winding of a permanent magnet synchronous generator (PMSG) dedicated for small hydroelectric power plants. During the calculations, a field–circuit model is used via ANSYS software. The simulations were performed for both a fault-free generator and faulty generator with various degrees of short-circuited turns under various operating conditions. The degree of stator winding damage is modeled by changing the number of shorted turns in one phase. The studied generator has a two-layer stator winding made of winding wire. In addition, it is made of three parallel branches. In this way, a more difficult-to-detect condition is simulated. We analyzed the influences of short-circuit fault on the magnetic field and their impact on generator behavior. The analysis of the obtained results indicates the possibility of using the measurement of the stator current histogram, higher-order harmonics of the stator current, back electromotive force (back EMF), phase current growth, and power factor fluctuations for early detection of an inter-turn short circuit. Full article

Inter-turn short-circuit fault is a common electrical issue in high-speed train traction motors, which can severely degrade motor performance and significantly shorten operational lifespan. Early detection is crucial for ensuring the safety of traction systems. This paper presents a digital twin-based method for diagnosing stator winding inter-turn short-circuit faults in induction motors. First, an advanced rapid-solving algorithm is employed to establish a real-time digital twin model of the motor under healthy conditions. Second, a mathematical model characterizing stator winding faults is developed. Subsequently, fault detection and localization are achieved through analyzing three-phase current residuals between the digital twin model and the actual system. Extensive simulations and experiments demonstrate that the proposed method generates a fault index amplitude approximately 20 times larger than traditional sampling-value-based prediction methods, indicating exceptional sensitivity. The approach is minimally invasive, requiring no additional measurement equipment. Moreover, it maintains diagnostic capability even under motor parameter mismatch conditions, outperforming traditional methods. The proposed method demonstrates distinct advantages for high-speed train traction systems. It enables real-time monitoring and predictive maintenance, effectively reducing operational costs while preventing catastrophic failures. Full article

Three-phase induction motors are widely adopted in industrial systems due to their robustness, ease of maintenance, and simple operation. However, they are prone to various types of faults, notably stator winding faults. Previous research indicates that 20–40% of three-phase induction motor failures are stator-related, with inter-turn short circuits as a leading cause. These faults can pose significant risks to both the motor and connected equipment. Therefore, the early detection of inter-turn short circuit (ITSC) faults is essential to prevent system breakdowns and improve the safety and reliability of industrial operations. This paper presents a comparative investigation of two distinct diagnostic methodologies for the detection of ITSC faults in induction motors. The first methodology is based on a Motor Current Signature Analysis (MCSA) utilizing the short-time Fourier transform (STFT) for the real-time monitoring of fault-related harmonics. The second methodology is centered around the monitoring of the zero-sequence voltage (ZSV). The findings from several experimental tests performed on a 1.1 kW three-phase induction motor across a range of operating conditions highlight the superior performance of the ZSV method with respect to the MCSA-based STFT method in terms of reliability, rapidity, and precision for the diagnosis of ITSC faults. Full article

This work presents a lightweight and practical methodology for detecting inter-turn short-circuit faults in squirrel-cage induction motors under different mechanical load conditions. The proposed approach utilizes a one-dimensional convolutional neural network (1D-CNN) enhanced with residual blocks and trained on differentiated stator current signals obtained under different load mechanical conditions. This preprocessing step enhances fault-related features, enabling improved learning while maintaining the simplicity of a lightweight CNN. The model achieved classification accuracies above 99.16% across all folds in five-fold cross-validation and demonstrated the ability to detect faults involving as few as three short-circuited turns. Comparative experiments with the Multi-Scale 1D-ResNet demonstrate that the proposed method achieves similar or superior performance while significantly reducing training time. These results highlight the model’s suitability for real-time fault detection in embedded and resource-constrained industrial environments. Full article

In this paper, we introduce a health parameter and estimation algorithm to assess the severity of stator turn-to-turn/inter-turn short-circuit (TTSC) faults in wound-rotor synchronous generators (WRSG). Our methodology establishes criteria for evaluating the severity of stator TTSC faults in WRSG and provides a specific solution for estimating both the severity of these faults and the resultant power loss. Our assessment methodology directly reflects the intrinsic impact of stator TTSC faults on the WRSG, offering enhanced efficiency, accuracy, and resilience to interference compared with traditional methods in estimating and gauging the TTSC severity. First, we demonstrate that it is impossible to determine the two fault parameters of the WRSG stator TTSC faults solely based on the voltage and current measurements. Subsequently, we introduce a novel health parameter for the WRSG stator TTSC faults and show that for a given generator and load, the dynamics of voltage and current during these faults as well as the resulting power loss are determined by this health parameter. We then detail the characteristics of the proposed health parameter and criteria for evaluating the severity of the WRSG stator TTSC faults. Furthermore, we present an estimation algorithm that is capable of accurately estimating the health parameter and power loss, demonstrating its minimal estimation error. Finally, we provide a comprehensive set of simulation results, including Monte Carlo results, to validate our proposed methodology and illustrate that our approach offers significant improvements in terms of the efficiency, accuracy, and robustness of the WRSG stator TTSC fault detection and isolation (FDI) over conventional methods. Full article

As a key component of the power system, the good or bad conditions of synchronous machines will directly affect the stable supply of electric energy. The inter-turn short fault of the stator is one of the main dangers to the synchronous machine and is difficult to diagnose. Frequency response analysis has recently been introduced and used for detecting this type of fault; however, the fault degrees and locations cannot be directly recognized by traditional frequency response analysis. Therefore, this study improves the frequency response analysis by combining it with a deep learning model of a multivariate time series transformer. First, the principle of this study is introduced. Second, the frequency response data of short circuit faults are obtained using an artificially simulated experimental platform of a synchronous machine. The deep learning model is then well-trained. Finally, the performance of the proposed method is tested and verified. It concludes that the proposed method has the potential for classifying and diagnosing the inter-turn short circuit of stators in synchronous machines. Full article

Wind energy is a vital pillar of modern sustainable power generation, yet wind turbine generators remain vulnerable to incipient inter-turn short-circuit (ITSC) faults in their stator windings. These faults can cause fluctuations in the output voltage, frequency, and power of wind turbines, eventually leading to overheating, equipment damage, and rising maintenance costs if not detected early. Although significant progress has been made in condition monitoring, the current methods still fall short of the robustness required for early fault diagnosis in complex operational settings. To address this gap, this study presents a novel deep learning framework that involves traditional baseline machine-learning algorithms and advanced deep network architectures to diagnose seven distinct ITSC fault types using signals from current, vibration, and axial magnetic flux sensors. Our approach is rigorously evaluated using metrics such as confusion matrices, accuracy, recall, average precision (AP), mean average precision (mAP), hypothesis testing, and feature visualization. The experimental results demonstrate that deep learning models outperform machine learning algorithms in terms of precision and stability, achieving an mAP of 99.25% in fault identification, with three-phase current signals emerging as the most reliable indicator of generator faults compared to vibration and electromagnetic data. It is recommended to combine three-phase current sensors with deep learning frameworks for the precise identification of various types of incipient ITSC faults. This study offers a robust and efficient pipeline for condition monitoring and ITSC fault diagnosis, enabling the intelligent operation of wind turbines and maintenance of their operating states. Ultimately, it contributes to providing a practical way forward in enhancing turbine reliability and lifespan. Full article

Three-phase induction motors are widely applied in industrial systems due to their durability and efficiency. However, electrical faults such as inter-turn short circuits can compromise performance, leading to unplanned downtime and maintenance costs. Traditional fault detection methods rely on stator current or vibration analysis, each with limitations regarding sensitivity to specific failure modes and dependence on motor power ratings. Despite advancements in non-invasive sensing, challenges remain in balancing fault detection accuracy, computational efficiency, and adaptability to real-world conditions. This study proposes a stray flux-based method for detecting inter-turn short circuits using an externally mounted search coil sensor, eliminating the need for intrusive modifications and enabling fault detection independent of motor power. To account for variations in fault manifestation, the method was evaluated with three different relative positions between the search coil and the faulty winding. Feature extraction and selection are performed using a hybrid strategy combining random forest-based ranking and collinearity filtering, optimizing classification accuracy while reducing computational complexity. Two classification tasks were conducted: binary classification to differentiate between healthy and faulty motors, and multiclass classification to assess fault severity. The method achieved 100% accuracy in binary classification and 99.3% in multiclass classification using the full feature set. Feature reduction to eight attributes resulted in 92.4% and 85.4% accuracy, respectively, demonstrating a trade-off between performance and computational efficiency. The results support the feasibility of deploying stray flux-based fault detection in industrial applications, ensuring a balance between classification reliability, real-time processing, and potential implementation in embedded systems with limited computational resources. Full article

In ship propulsion, accurately diagnosing faults in permanent magnet synchronous motor is essential but challenging due to limitations in the intuitive characterization and feature extraction of fault signals. This study presents an innovative approach to motor fault detection by integrating phase-contrastive current dot patterns with an enhanced residual network, enhancing the diagnostic effect. Initially, the research involves creating a dataset that simulates stator currents. It is achieved through mathematical modeling of two common faults in permanent magnet synchronous motors: inter-turn short circuits and demagnetization. Subsequently, the parameters of the phase-contrastive current dot pattern are optimized using the Hunter-Prey Optimization technique to convert the three-phase stator currents of the motor into grayscale images. Lastly, a residual network, which includes a Squeeze-and-Excitation module, is engineered to boost the identification of crucial fault characteristics. The experimental results show that the proposed method achieves a high accuracy rate of 98.5% in the fault diagnosis task of motors, which can accurately identify the fault information and is significant in enhancing the reliability and safety of ship propulsion systems. Full article

In electric powertrain traction applications, the adopted trend to improve the performance and efficiency of electromechanical power conversion systems is to increase supply voltages and inverter switching frequencies. As a result, electrical machine conductors are subjected to ever-increasing electrical stresses, leading to premature insulation degradation and eventual short-circuits. Winding condition monitoring is crucial to prevent such critical failures. Based on the scientific literature, several methods can be used for early identification of aging. A first solution is to monitor partial discharges. This method requires the use of a specific measurement device and an undisturbed test environment. A second solution is to monitor the inter-turn winding capacitance, which is directly related to the condition of the insulation and can cause a change in the stator impedance behavior. Several approaches can be used to estimate or characterize this impedance behavior. They must be performed on a machine at standstill, which limits their application. In this paper, a new characterization method is proposed to monitor the high-frequency stator impedance evolution of voltage source inverter-fed machines. This method can be applied at any time without removing the machine from its operating environment. The range and accuracy of the proposed frequency characterization depend in particular on the supply voltage level and the bandwidth of the measurement probes. The effects of parameters such as temperature, switching frequency, and DC voltage amplitude on the impedance characteristic were also studied and will be presented. Tests carried out on an automotive traction machine have shown that the first two series and parallel resonances of the high-frequency impedance can be accurately identified using the proposed technique. Therefore, by monitoring these resonances, it is possible to predict the aging rate of the conductor. Full article

Stator faults are one of the common issues in pumped storage generators, significantly impacting their performance and safety. To ensure the safe and stable operation of pumped storage generators, a stator fault diagnosis method based on an improved short-time Fourier transform (STFT)-support vector data description (SVDD) hybrid algorithm is proposed. This method establishes a fault model for inter-turn short circuits in the stator windings of pumped storage generators and analyzes the electrical and magnetic states associated with such faults. Based on the three-phase current signals observed during an inter-turn short circuit fault in the stator windings, the three-phase currents are first converted into two-phase currents using the principle of equal magnetic potential. Then, the STFT is applied to transform the time-domain signals of the stator’s two-phase currents into frequency-domain signals, and the resulting fault current spectrum is input into the improved SVDD network for processing. This ultimately outputs the diagnosis result for inter-turn short circuit faults in the stator windings of the pumped storage generator. Experimental results demonstrate that this method can effectively distinguish between normal and faulty states in pumped storage generators, enabling the diagnosis of inter-turn short circuit faults in stator windings with low cross-entropy loss. Through analysis, under small data sample conditions, the accuracy of the proposed method in this paper can be improved by up to 7.2%. In the presence of strong noise interference, the fault diagnosis accuracy of the proposed method remains above 90%, and compared to conventional methods, the fault diagnosis accuracy can be improved by up to 6.9%. This demonstrates that the proposed method possesses excellent noise robustness and small sample learning ability, making it effective in complex, dynamic, and noisy environments. Full article

An induction motor is an electric machine widely used in various industrial and commercial applications due to its efficiency and simple design. In this regard, a methodology based on the electric phasor analysis of line currents and the variations in the phase angles among these line currents is proposed. The values in degrees of the angles between every pair of line currents were introduced to a fuzzy logic algorithm based on the Mamdani model, developed using the Matlab toolbox for detection and isolation of the inter-turn short-circuit faults on the windings of an induction motor. To carry out the analysis, the induction motor was modified in its stator windings to artificially induce short-circuit faults of different magnitudes. The current signals are acquired in real time using a digital platform developed in the Delphi 7 high-level language communicating with a float point unit Digital Signal Processor (DSP) TMS320F28335 by Texas Instruments. The proposed method not only detects the short circuit faults but also isolates the faulty winding. Full article

Permanent-magnet synchronous motors (PMSMs) have played a key role in recent years in both industrial and commercial applications. Despite their many significant advantages, such as high efficiency, very good dynamics, and high power density, these types of motors are prone to various types of faults. This article proposes a low-cost microcontroller-based system for PMSM stator winding condition monitoring and fault diagnosis. It meets the demand created by the use of more and more low-budget solutions in industrial and commercial applications. A printed circuit board (PCB) has been developed to measure PMSM stator phase currents, which are used as diagnostic signals. The key components of this PCB are LEM’s LESR 6-NP current transducers. The acquisition and processing of diagnostic signals using a low-cost embedded system (NUCLEO-H7A3ZI-Q) with an ARM Cortex-M core is described in detail. A machine learning-driven KNN-based fault diagnostic algorithm is implemented to detect and classify incipient PMSM stator winding faults (interturn short-circuits). The effects of the severity of the fault and the motor operating conditions on the symptom extraction process are also investigated. The results of experimental tests conducted on a 2.5 kW PMSM confirmed the effectiveness of the developed system. Full article

Electric motors play a fundamental role in various industries, and their relevance is strengthened in the context of the energy transition. Having efficient tools and techniques to detect and diagnose faults in electrical machines is crucial, as is providing early alerts to facilitate prompt decision-making. This study proposes indicators based on the magnitude of the space vector stator current for detecting and diagnosing incipient inter-turn short circuits (ITSCs) in induction motors (IMs). The effectiveness of these indicators was evaluated using four machine learning methods previously documented in the literature: random forests (RFs), support vector machines (SVMs), the k-nearest neighbor (kNN), and feedforward and recurrent neural networks (FNNs and RNNs). This assessment was conducted using experimental data. The results were compared with indicators based on discrete wavelet transform (DWT), demonstrating the viability of the proposed approach, which opens up a way of detecting incipient ITSCs in three-phase IMs. Furthermore, utilizing features derived from the magnitude of the spatial vector led to the successful identification of the phase affected by the fault. Full article

The objective of the investigation was to increase the effectiveness of damage detection in the stator of the squirrel-cage induction machine. The analysis aimed to enhance the operational trustworthiness of the squirrel-cage induction machine by employing nonintrusive diagnostic methods based on a current signal and modern artificial intelligence methods. The authors of the study introduced a diagnostic technique for identifying multiphase interturn short circuits of stator winding. These short circuits are one of the most common faults in induction machines. The proposed method focusses on deriving a diagnostic signal from the phase-current waveforms of the machine. The noninvasive nature of the diagnostic technique presented is attributed to the application of the field model of electromagnetic phenomena to determine the diagnostic signal. For this purpose, a field model of a squirrel-cage machine was developed. The waveforms of phase currents obtained from the field model were used as input into an elaborated machine failure neural classifier. A deep neural network was used to develop a neural classifier. The effectiveness of the developed classifier has been experimentally verified, and the obtained results have been presented, concluded, and discussed. The scientific novelty presented in the article is the presentation of research results on the use of a neural classifier to detect damage in all phases of the stator winding at an early stage of its appearance. The features of this type of damage are very difficult to observe in signal waveforms such as a phase current or torque. Full article
