Search Results (123)

This paper proposes an advanced sensorless control strategy for Permanent Magnet Synchronous Motors (PMSMs) aimed at enhancing dynamic performance, robustness, and reliability while eliminating the need for mechanical sensors. The core contribution lies in a novel hybrid speed regulation framework that combines a terminal sliding mode control scheme with a high-order super-twisting algorithm (HOT-STA-SMC), ensuring finite-time convergence, effective chattering suppression, and strong disturbance rejection under varying operating conditions. For the inner current loop, an Exponential Reaching Law Sliding Mode Controller (ERL-SMC) is implemented to guarantee fast current response and precise current tracking, even in the presence of parameter uncertainties. Furthermore, the conventional Model Reference Adaptive System (MRAS) observer is embedded within the proposed control architecture, resulting in more accurate speed estimation and enhanced stability during load fluctuations. The complete control system is rigorously modeled and tested in MATLAB R2024b/Simulink, capturing the full interaction between machine dynamics, control loops, and observer mechanisms. The simulation results verify that the proposed design achieves superior torque smoothness, minimal current ripples, and fast transient response compared to conventional sensorless methods. By integrating high-order sliding modes with advanced adaptive observation, this work offers a robust and cost-effective solution for high-performance PMSM drives, suitable for demanding applications such as electric vehicles, renewable energy conversion, and industrial motion control. Full article

To address the chattering phenomenon and sensitivity to load disturbances in conventional sliding mode observers (SMO) for sensorless permanent magnet synchronous motor (PMSM) control, this paper proposes a robust sensorless control strategy integrating a fuzzy adaptive SMO with an improved sliding mode speed controller. In the observer design, a continuous hyperbolic tangent function, $tanh \left(ax\right)$, replaces the traditional sign function, while a fuzzy logic controller adaptively tunes the convergence factor a to enhance estimation accuracy and suppress high-frequency chattering. Simultaneously, an adaptive quadrature phase-locked loop (AQPLL) is incorporated to achieve adaptive matching across various operating conditions by updating parameters online, which effectively reduces phase delay and improves the dynamic performance of rotor position and speed estimation. Furthermore, a non-singular terminal sliding mode control (NTSMC) strategy is employed in the outer speed loop with a proposed segmented terminal reaching law. This law ensures rapid response in large-error regions and mitigates steady-state oscillations in small-error regions, thereby strengthening system robustness against load disturbances. The stability of the proposed system is rigorously verified via Lyapunov stability analysis. Simulation and experimental results demonstrate that the proposed approach significantly reduces speed and position estimation errors under varying speeds and sudden load changes compared to the conventional SMO-PI method, while effectively suppressing system chattering to confirm its engineering feasibility. Full article

To address the problem that the maximum error of back-EMF observers increases with an increase in motor speed, based on an extended state observer, this paper designs an angle-compensation strategy based on a proportional–integral controller and an extended state observer, according to the principle that a proportional–integral controller uses an integral link to eliminate steady-state error. After obtaining the back EMF, the proportional–integral phase-locked loop is often used to extract the angle and speed from the observed back EMF. However, this method will produce steady-state errors when the motor is accelerated, and the integration link is prone to overshoot, so it exhibits some defects. Therefore, this paper uses an extended state observer instead of a proportional–integral regulator to build an improved phase-locked loop based on an extended state observer. Full article

Permanent magnet synchronous motors (PMSMs) are widely used in various fields due to their high efficiency and power density. To further enhance reliability and reduce cost and volume, sensorless control techniques have been extensively investigated over the past few decades. This article provides a review of major sensorless control methods, categorizing them into low-speed and high-speed methods. Virtual frequency methods, saliency-based methods, and model-based methods, along with their developments, are analyzed and compared. In addition, application-oriented analysis, implementation insights, as well as the challenges and future development trends are discussed at the end of the article. Full article

This study introduces a sensorless control approach for permanent magnet synchronous motors (PMSMs) that employs an Improved Non-Singular Fast Terminal Sliding Mode Controller (IMNFTSMC) and an Improved Non-Singular Fast Terminal Sliding Mode Observer (IMNFTSMO). The IMNFTSMC employs a novel hybrid reaching law and a continuous piecewise square root switching function to achieve faster convergence and effective chattering reduction over the conventional Sliding Mode Controller (SMC). This design successfully replaces two critical components: the discontinuous constant velocity term (a key component of the traditional SMC reaching law that is a primary source of control chattering in PMSM torque regulation) and the high-gain exponential term (which tends to induce overshoot during transient speed adjustments and degrade steady-state control precision). In the IMNFTSMO, a hybrid approach combining linear and non-singular terminal sliding modes eliminates phase lag associated with low-pass filtering in traditional sliding mode observers, improving rotor position and speed estimation accuracy. Stability of both IMNFTSMC and IMNFTSMO is rigorously proven using Lyapunov stability theory.Validation through extensive simulations and hardware experiments, including challenging zero-speed start, speed stepping, and load disturbance tests, confirms the proposed strategy provides improved dynamic response, effective anti-disturbance capability, and high accuracy for rotor position and speed estimation compared to established benchmark methods, demonstrating its feasibility for mid-to-low speed sensorless PMSM drives. Full article

In electric vehicle and marine propulsion applications, the stable operation of permanent-magnet synchronous motor (PMSM) drive systems relies on accurate rotor position information. Such information is typically obtained from position sensors, which are prone to high temperature, humidity, vibration, and electromagnetic interference, leading to elevated failure rates; moreover, sensor installation introduces additional interfaces and wiring, thereby reducing system reliability. To address these issues, this paper proposes a sensorless control method based on an adaptive full-order sliding-mode observer (SMO). The proposed method employs the SMO output as the observer feedback correction term rather than the estimated back EMF, thereby avoiding substantial high-frequency noise. Furthermore, an S-shaped nonlinear function is designed to replace the conventional switching function, mitigating high-frequency chattering when the system operates in sliding mode; an adaptive sliding-mode gain function is designed, the sliding-mode gain and the boundary-layer thickness are adaptively tuned as a function of motor speed, which effectively enhances the back EMF estimation accuracy over a wide operating-speed range. The effectiveness of the proposed method is validated on a 2.3-kW PMSM experimental platform. Full article

Permanent magnet synchronous motors (PMSMs) are widely preferred in modern applications due to their high efficiency, high torque-to-inertia ratio, high power factor, and rapid dynamic response. Achieving optimal PMSM performance requires precise control, which depends on accurate estimation of motor speed and rotor position. This information is traditionally obtained through sensors such as encoders; however, these devices increase system cost and introduce size and integration constraints, limiting their use in many PMSM-based applications. To overcome these limitations, sensorless control strategies have gained significant attention. Since PMSMs inherently exhibit nonlinear dynamic behavior, accurate modeling of these nonlinearities is essential for reliable sensorless operation. In this study, a Runge–Kutta Extended Kalman Filter (RKEKF) approach is developed and implemented to enhance estimation accuracy for both rotor position and speed. The developed method utilizes the applied stator voltages and measured phase currents to estimate the motor states. Experimental validation was conducted on the dSPACE DS1104 platform under various operating conditions, including forward and reverse rotation, acceleration, low- and high-speed operation, and loaded operation. Furthermore, the performance of the developed RKEKF under load was compared with the conventional Extended Kalman Filter (EKF), demonstrating its improved estimation capability. The real-time feasibility of the developed RKEKF was experimentally verified through execution-time measurements on the dSPACE DS1104 platform, where the conventional EKF and the RKEKF required 47 µs and 55 µs, respectively, confirming that the proposed approach remains suitable for real-time PMSM control while accommodating the additional computational effort associated with Runge–Kutta integration. Full article

Model predictive control (MPC) ensures stable motor operation provided that accurate motor parameters and state information are available. However, in certain environments, direct sensor measurement of rotor position and speed is infeasible, and sensorless methods are required to estimate the rotor position and speed. Sensorless methods utilizing a sliding mode observer (SMO) and a quadrature phase-locked loop (QPLL) are widely adopted, but it may encounter issues such as inaccurate motor parameters and delayed measurement results. To address these challenges, this paper proposes an integrated method that employs a nonlinear extended state observer (NLESO) to reduce observation delays in rotor position estimation. Additionally, a model reference adaptive system (MRAS)-based inductance observer is utilized to correct parameter inaccuracies. This combined approach achieves robust motor control with low delay. Simulation results validate the effectiveness and robustness of the proposed method. Full article

Advancements in ship propulsion technologies are essential for improving the efficiency and reliability of maritime transportation. This study introduces a comprehensive approach that integrates motor design with sensorless control strategies, specifically focusing on Dual Three-Phase Permanent Magnet Vernier Motors (DTP-PMVM) for ship propulsion. The initial section of the paper explores the design of a 5-MW DTP-PMVM using finite element method (FEM) analysis in dual three-phase configurations. The subsequent section presents a novel sensorless control technique employing a Prescribed-time Sliding Mode Observer (PTSMO) for accurate speed and position estimation of the DTP-PMSM, eliminating the need for physical sensors. The proposed observer convergence time is entirely independent of the initial estimation guess and observer gains, allowing for pre-adjustment of the estimation error settling time. Initially, the observer is designed for a DTP-PMVM with fully known model parameters. It is then adapted to accommodate variations and unknown parameters over time, achieving prescribed-time observation. This is accomplished by using an adaptive observer to estimate the unknown parameters of the DTP-PMVM model and a Neural Network (NN) to compensate for the nonlinear effects caused by the model’s unknown terms. The adaptation laws are innovatively modified to ensure the prescribed time convergence of the entire adaptive observer. MATLAB (R2023b) Simulink simulations demonstrate the superior speed-tracking accuracy and robustness of the speed and position observer against model parameter variations, strongly supporting the application of these strategies in real-world maritime propulsion systems. By integrating these advancements, this research not only proposes a more efficient, reliable, and robust propulsion motor design but also demonstrates an effective control strategy that significantly enhances overall system performance, particularly for maritime propulsion applications. Full article

In this paper, the inductance of a sensorless PMSM (Permanent Magnet Synchronous Motor) drive system equipped with a periodic load torque compensator based on a wavelet denoising and least-order observer with time-delay compensation is estimated in real-time. In a sensorless PMSM system with constant load torque, the magnetically saturated inductance value remains constant. This constant inductance error causes minor performance degradation, such as a constant rotor position estimation error and non-optimal torque current, but it does not introduce a speed estimation error. Conversely, in a sensorless PMSM motor system subjected to periodic load torque, the magnetically saturated inductance error fluctuates periodically. This fluctuation leads to periodic variations in both the estimated position error and the speed error, ultimately degrading the load torque compensation performance. This paper applies the maximum energy-to-Shannon entropy criterion for the optimal selection of the mother wavelet in the wavelet transform to remove the motor signal noise and achieve more accurate inductance estimation. Additionally, the coherence and correlation theory is proposed to address the time delay in the least-order observer and improve the time delay. A self-saturation compensation method is also proposed to minimize periodic speed fluctuations and improve control accuracy through inductance parameter estimation. Finally, experiments were conducted on a sensorless PMSM drive system to verify the inductance estimation performance and validate the effectiveness of vibration reduction. Full article

Aiming at the speed chattering problem caused by high-frequency square wave injection in permanent magnet synchronous motors (PMSMs) during low-speed operation (200–500 r/min), this study intends to improve the rotor position estimation accuracy of sensorless control systems as well as the system’s ability to resist harmonic interference and sudden load changes. The goal is to enhance the control performance of traditional control schemes in this scenario and meet the requirement of stable low-speed operation of the motor. First, the study analyzes the harmonic error propagation mechanism of high-frequency square wave injection and finds that the traditional PI phase-locked loop (PI-PLL) is susceptible to high-order harmonic interference during demodulation, which in turn leads to position estimation errors and periodic speed fluctuations. Therefore, the extended state observer phase-locked loop (ESO-PLL) is adopted to replace the traditional PI-PLL. A third-order extended state observer (ESO) is used to uniformly regard the system’s unmodeled dynamics, external load disturbances, and harmonic interference as “total disturbances”, realizing real-time estimation and compensation of disturbances, and quickly suppressing the impacts of harmonic errors and sudden load changes. Meanwhile, a dynamic pole placement strategy for the speed loop is designed to adaptively adjust the controller’s damping ratio and bandwidth parameters according to the motor’s operating states (loaded/unloaded, steady-state/transient): large poles are used in the start-up phase to accelerate response, small poles are switched in the steady-state phase to reduce errors, and a smooth attenuation function is used in the transition phase to achieve stable parameter transition, balancing the system’s dynamic response and steady-state accuracy. In addition, high-frequency square wave voltage signals are injected into the dq axes of the rotating coordinate system, and effective rotor position information is extracted by combining signal demodulation with ESO-PLL to realize decoupling of high-frequency response currents. Verification through MATLAB/Simulink simulation experiments shows that the improved strategy exhibits significant advantages in the low-speed range of 200–300 r/min: in the scenario where the speed transitions from 200 r/min to 300 r/min with sudden load changes, the position estimation curve of ESO-PLL basically overlaps with the actual curve, while the PI-PLL shows obvious deviations; in the start-up and speed switching phases, dynamic pole placement enables the motor to respond quickly without overshoot and no obvious speed fluctuations, whereas the traditional fixed-pole PI control has problems of response lag or overshoot. In conclusion, the “ESO-PLL + dynamic pole placement” cooperative control strategy proposed in this study effectively solves the problems of harmonic interference and load disturbance caused by high-frequency square wave injection in the low-speed range and significantly improves the accuracy and robustness of PMSM sensorless control. This strategy requires no additional hardware cost and achieves performance improvement only through algorithm optimization. It can be directly applied to PMSM control systems that require stable low-speed operation, providing a reliable solution for the promotion of sensorless control technology in low-speed precision fields. Full article

This paper presents a sensorless control strategy for permanent magnet synchronous motor (PMSM) drives in industrial and automotive air compressor applications. The strategy utilizes an adaptive-gain sliding mode observer integrated with a refined back-EMF model to suppress chattering and improve convergence. The proposed approach achieves precise rotor position and speed estimation across a wide operational range without mechanical sensors. It directly addresses the critical needs of reliability, compactness, and resilience in automotive environments. Unlike conventional observers, its originality lies in the enhanced gain structure, enabling accurate and robust sensorless control validated through both simulation and hardware tests. Comprehensive simulation results demonstrate effective performance from 2000 to 8500 rpm, with steady-state speed tracking errors maintained below 0.4% at 2000 rpm and 0.035% at 8500 rpm under rated load. The control methodology exhibits excellent disturbance rejection capabilities, maintaining speed regulation within ±5 rpm under an 80% load disturbance at 8500 rpm while limiting q-axis current ripple to 2.5% of rated values. Experimental validation on a 2.2 kW PMSM-driven compressor test platform confirms stable operation at 4000 rpm with speed fluctuations constrained to 20 rpm (0.5% error) and precise current regulation, maintaining the d-axis current within ±0.07 A. The system demonstrates rapid dynamic response, achieving acceleration from 1320 rpm to 2365 rpm within one second during testing. The results confirm the method’s practical viability for enhancing reliability and reducing maintenance in industrial and automotive compressors systems. Full article

In sensorless control systems of permanent magnet synchronous motors (PMSMs), the traditional linear extended state observer (LESO) is preferred due to its simplicity and ease of implementation. With the development of PMSM sensorless control systems, the requirements for position estimation performance have increased, and thus, traditional LESOs can no longer meet those needs. To address this issue, this article proposes an estimation method based on an integrally compensated-enhanced linear extended state observer (IC-ELESO) and an improved quadrature phase locked loop (IQPLL) with a third-order LESO. In the back electromotive force estimation scheme, by introducing a compensation loop, the proposed IC-ELESO suppresses DC bias and improves position estimation accuracy compared to traditional LESOs. In the position estimation scheme, the IQPLL combines the third-order LESO with a quadrature phase locked loop (QPLL) to eliminate errors introduced by ramp signals. Finally, a PMSM experimental platform is built to conduct a comparative experiment between the method proposed and the traditional LESO, which verifies the feasibility and superiority of the method proposed in this article. Full article

The ISMC+IPLL (Improved Sliding Mode Control method with Improved Phase-Locked Loop) is proposed to reduce the jitter phenomenon of sensorless control for a permanent magnet synchronous motor (PMSM). Through influence analysis for the structure parameters of SMO to PMSM performance, the basis for determining the switching function and forming coefficient of ISMC+IPLL is constructed. Compared with traditional PI control and anti-integral saturation ASR control, the observation behavior of the ISMC+IPLL under step load and step speed is optimized to varying degrees, which effectively weakens the inherent jitter phenomenon of sensorless control for PMSM and provides a theoretical basis for establishing a high-performance control strategy for PMSM in the whole operation stage. Full article

The electrification of agricultural equipment is a critical pathway to address the dual challenges of increasing global food production and ensuring sustainable agricultural development. As the core power unit, the permanent magnet synchronous motor (PMSM) drive system faces severe challenges in achieving high performance, robustness, and reliable control in complex farmland environments characterized by sudden load changes, extreme operating conditions, and strong interference. This paper provides a comprehensive review of key technological advancements in PMSM drive systems for agricultural electrification. First, it analyzes solutions to enhance the reliability of power converters, including high-frequency silicon carbide (SiC)/gallium nitride (GaN) power device packaging, thermal management, and electromagnetic compatibility (EMC) design. Second, it systematically elaborates on high-performance motor control algorithms such as Direct Torque Control (DTC) and Model Predictive Control (MPC) for improving dynamic response; robust control strategies like Sliding Mode Control (SMC) and Active Disturbance Rejection Control (ADRC) for enhancing resilience; and the latest progress in fault-tolerant control architectures incorporating sensorless technology. Furthermore, the paper identifies core challenges in large-scale applications, including environmental adaptability, real-time multi-machine coordination, and high reliability requirements. Innovatively, this review proposes a closed-loop intelligent control paradigm encompassing environmental disturbance prediction, control parameter self-tuning, and actuator dynamic response. This paradigm provides theoretical support for enhancing the autonomous adaptability and operational quality of agricultural machinery in unstructured environments. Finally, future trends involving deep AI integration, collaborative hardware innovation, and agricultural ecosystem construction are outlined. Full article
