Search Results (60)

This study focuses on a new identification method for moving loads on bridge structures using field-based displacement data from different measurement points on a continuous rigid-frame bridge. A novel approach has been proposed to make use of the area of the absolute field value derived from the displacement influence line of continuous rigid-frame bridges. Considering the potential presence of other nuisance loads (i.e., noise) on the bridge, this method can significantly mitigate the impact of noise by adopting the absolute area method of influence lines. In addition, the new method combines data from various field measurement points to identify the moving loads, which can in turn minimize the influence of measurement errors. To validate the new method, several numerical simulations varying different noises and parameters have been carried out for benchmarking. The results show that our proposed method achieves an outstanding identification accuracy of over 95% for the simulation cases with the disturbance noise amplitude less than 1.0% and the field data with random noise. This new method enables the identification of moving loads on bridges, thereby providing fundamental data for bridge health monitoring and damage detection. This will help improve predictability of the remaining fatigue life of bridge structures. Full article

To address the frequency regulation requirements of hybrid energy storage (HES) in renewable-dominated power grids, this paper proposes an asymmetric droop control strategy based on an improved backpropagation (BP) neural network. First, a simulation model of HES (comprising supercapacitors for the power support and batteries for the energy balance) participating in primary frequency regulation is established, with a stepwise frequency regulation dead zone designed to optimize multi-device coordination. Second, an enhanced Sigmoid activation function (with controllable parameters a, b, m, and n) is introduced to dynamically adjust the power regulation coefficients of energy storage units, achieving co-optimization of frequency stability and State of Charge (SOC). Simulation results demonstrate that under a step load disturbance (0.05 p.u.), the proposed strategy reduces the maximum frequency deviation by 79.47% compared to scenarios without energy storage (from 1.7587 × 10⁻³ to 0.0555 × 10⁻³) and outperforms fixed-droop strategies by 44.33%. During 6-min continuous random disturbances, the root mean square (RMS) of system frequency deviations decreases by 4.91% compared to conventional methods, while SOC fluctuations of supercapacitors and batteries are reduced by 49.28% and 45.49%, respectively. The parameterized asymmetric regulation mechanism significantly extends the lifespan of energy storage devices, offering a novel solution for real-time frequency control in high-renewable penetration grids. Full article

In addition to technological influences, real-world belt and conveyor systems must contend with loading effects characterized primarily by randomness. Evaluating the impact of these effects on system behavior involves the creation of a computational model. In this innovative approach, disturbances are expressed by discretization and round-off errors arising throughout the solution of the controlling equations. Simulations conducted under this model demonstrate that these disturbances have the potential to generate hidden and co-existing attractors. Additionally, they have the potential to initiate shifts between oscillations of varying periods or transitions from regular to chaotic motions. This exploration sheds light on the intricate dynamics and behaviors exhibited by belt and conveyor systems in the face of various disturbances. Full article

Aiming at resolving the problem of stable and efficient operation of integrated green hydrogen production, storage, and supply hydrogen refueling stations at different time scales, this paper proposes a multi-time-scale hierarchical energy management strategy for integrated green hydrogen production, storage, and supply hydrogen refueling station (HFS). The proposed energy management strategy is divided into two layers. The upper layer uses the hourly time scale to optimize the operating power of HFS equipment with the goal of minimizing the typical daily operating cost, and proposes a parameter adaptive particle swarm optimization (PSA-PSO) solution algorithm that introduces Gaussian disturbance and adaptively adjusts the learning factor, inertia weight, and disturbance step size of the algorithm. Compared with traditional optimization algorithms, it can effectively improve the ability to search for the optimal solution. The lower layer uses the minute-level time scale to suppress the randomness of renewable energy power generation and hydrogen load consumption in the operation of HFS. A solution algorithm based on stochastic model predictive control (SMPC) is proposed. The Latin hypercube sampling (LHS) and simultaneous backward reduction methods are used to generate and reduce scenarios to obtain a set of high-probability random variable scenarios and bring them into the MPC to suppress the disturbance of random variables on the system operation. Finally, real operation data of a HFS in southern China are used for example analysis. The results show that the proposed energy management strategy has a good control effect in different typical scenarios. Full article

The integration of new renewable energy sources, such as wind and solar power, is characterized by strong randomness and volatility, which increases the risk of power grid system frequency fluctuations exceeding limits. Traditional thermal power units are unable to frequently respond to frequency regulation signals, necessitating the incorporation of energy storage technologies for primary frequency control. This paper presents a primary frequency control strategy for a flywheel–battery hybrid energy storage system (HESS) based on fuzzy adaptation and state-of-charge (SOC) self-recovery. First, a frequency response system model for primary frequency regulation in flywheel–battery hybrid energy storage was formulated. The frequency regulation command is divided into high-frequency and low-frequency components, which are allocated to the flywheel and the battery, respectively. Fuzzy control and regression functions were employed to adjust and constrain the frequency deviation, frequency deviation rate, and SOC. Subsequently, considering the SOC and frequency deviation of each energy storage component, a SOC self-recovery strategy was proposed. Finally, a simulation analysis was performed using a system benchmark capacity of 600 MW. Under step load disturbance conditions, the proposed strategy reduces the maximum frequency deviation by 10.52% and the steady-state frequency deviation by 8.35% compared with traditional methods. Under random load disturbance conditions, the root mean square (RMS) value of frequency deviation is reduced by 7.34%, and the peak-to-valley difference of frequency decreases by 6.74%. Compared to energy storage without SOC self-recovery, the RMS values of SOC for flywheel storage and battery storage are reduced by 8.79% and 16.68%, respectively. The results demonstrate that the proposed control strategy effectively improves the system’s frequency regulation performance, reduces energy storage output fluctuations, and enhances the SOC self-recovery effect of the HESS. Full article

This paper proposes an intelligent control method based on Soft Actor-Critic (SAC) to address uncertainties faced by flight vehicles during flight. The method effectively reduces aerodynamic loads and enhances the reliability of structural strength under significant wind disturbances. A specific launch vehicle is taken as the research subject, and its dynamic model is established. A deep reinforcement learning (DRL) framework suitable for the attitude control problem is constructed, along with a corresponding training environment. A segmented reward function is designed: the initial stage emphasizes tracking accuracy, the middle stage, with a detrimental effect due to the high-altitude wind region, focuses on load relief, and the final stage gradually resumes following tracking accuracy on the basis of maintaining the effect of load relief. The reward function dynamically switches between stages using a time factor. The improved SAC algorithm is employed to train the agent over multiple epochs, ultimately resulting in an intelligent load relief attitude controller applicable to the launch vehicle. Simulation experiments demonstrate that this method effectively solves the attitude control problem under random wind disturbances, particularly reducing the aerodynamic loads of launch vehicles in the high-altitude wind region. Full article

To address the impact of load variations, external environmental changes, and the tuning of the parameters on Permanent Magnet Synchronous Motors (PMSMs) used in ships, this study proposes an Active Disturbance Rejection Control (ADRC) strategy for PMSMs, optimized by the Quantum-behaved Particle Swarm Optimization (QPSO) algorithm. First, based on the PMSM model, the study addresses the limited disturbance rejection capability of the traditional fal function in the Extended State Observer (ESO) of conventional ADRC. To improve the accuracy of the state observer, the faln function is introduced as a replacement for the traditional fal function. Second, due to the numerous parameters in ADRC, which are difficult to tune, the QPSO algorithm—known for its strong global search capabilities and fast convergence speed—is utilized for parameter optimization. Additionally, the position update formula within the optimization algorithm is revised and optimized. Finally, simulation experiments are conducted using the Matlab/Simulink platform, where practical conditions, such as load fluctuations and random noise, are incorporated. The simulation results demonstrate that, compared to PSO-ADRC control, IPSO-ADRC control, and ICFO-ADRC control, the proposed method offers a superior dynamic response. Specifically, the speed control accuracy is improved by 46.7%, torque ripple is reduced by 50.8%, and harmonic distortion decreases by 23.1%. These results highlight the significant advantages of this method in enhancing system robustness, dynamic response speed, and steady-state accuracy, making it particularly suitable for PMSM control systems in complex dynamic environments, such as those encountered on ships. Full article

The quality of power signals is strongly influenced by nonlinear loads in Electrical Power systems. Representation of electrical signals using different Sparse techniques is an interesting area of research as it moderates the volume of data to be stored. The storage of signals in Sparse form will make data storage easier and more efficient. Earlier studies concentrated on blindly choosing Overcomplete Hybrid Dictionaries (OHDs) for Sparse representation. The effect of different dictionaries in representing electrical signals has also not been reviewed in them. This paper presents an investigation of the effect of various dictionaries and the sparsity constant on the representation of electrical signals. The validation for statements presented in this paper is carried out by representing power signals with diverse power line disturbances like Swell, DC offset, and random oscillation, with the help of various dictionaries in the simulation platform. The Sparse representation of the power signals was generated using the Orthogonal Matching Pursuit algorithm. The resultant Sparse representation was then compared with the original signal. The difference between them was found to be negligible with the help of different metrics. The ratio of the obtained signal from Sparse representation, the original signal (A/R ratio), and the Mean Squared Error were taken as the metrics. The MATLAB platform was used for performing the simulation study. Full article

During the loading process, significant external position disturbances occur in the electro–hydraulic load simulation system. To address these position disturbances and effectively mitigate the impact of uncertainty on system performance, this paper first treats model parameter uncertainty and external disturbances as lumped disturbances. The various states of the servo valve and the pressures within the hydraulic cylinder chambers are then examined. Building on this foundation, the paper proposes a nonlinear multi-mode variable structure independent load port electro–hydraulic load simulation system that is tailored for specific loading conditions. Secondly, in light of the significant motion disturbances present, this paper proposes an integral sliding mode active disturbance rejection composite control strategy that is based on fixed-time convergence. Based on the structure of the active disturbance rejection control framework, the fixed-time integral sliding mode and active disturbance rejection control algorithms are integrated. An extended state observer is designed to accurately estimate the lumped disturbance, effectively compensating for it to achieve precise loading of the independent load port electro–hydraulic load simulation system. The stability of the designed controller is also demonstrated. The results of the simulation research indicate that when the command input is a step signal, the pressure control accuracy under the composite control strategy is 99.94%, 99.86%, and 99.76% for disturbance frequencies of 1 Hz, 3 Hz, and 5 Hz, respectively. Conversely, when the command input is a sinusoidal signal, the pressure control accuracy remains high, measuring 99.94%, 99.8%, and 99.6% under the same disturbance frequencies. Furthermore, the simulation demonstrates that the influence of sensor random noise on the system remains within acceptable limits, highlighting the effective filtering capabilities of the extended state observer. This research establishes a solid foundation for the collaborative control of load ports and the engineering application of the independent load port electro–hydraulic load simulation system. Full article

With the deepening of national efforts toward green energy transformation, the power system is evolving into one characterized by “double high”—a high proportion of new energy integration and a high level of power electronic systems. This results in a more complex system topology, necessitating improvements in various prevention and control measures. Traditional model-based methods for locating power oscillation disturbance sources in power systems are no longer sufficient to meet the operational demands of modern power systems. With the rapid development of wide-area measurement systems (WAMS), there is growing interest in disturbance source localization using system response data. System dynamics provide a wealth of easily extractable data that can accurately reflect the power system’s behavior under normal conditions. This paper proposes a numerical method for locating disturbance sources, combining energy functions with normal distribution identification, based on power oscillation mechanisms and system response data. The method identifies potential disturbance sources, including small random load fluctuations and large forced power oscillations. The innovation lies in the introduction of a 3 Sigma value criterion to pinpoint the disturbance source location, addressing the limitations of traditional energy function methods that require manual intervention. By quantifying the localization of power oscillation disturbance sources, this method significantly improves both efficiency and accuracy. Full article

Aimed at the stability problem of quadrotor Unmanned Aerial Vehicle (UAV) flight attitudes under random airflow disturbance conditions, a robust H-infinity-based dual cascade Model Predictive Control (MPC) attitude control method is proposed. Model Predictive Control itself has the capability to minimize the deviation between the prediction error and the control target by optimizing the control algorithm. The robust H-infinity controller can maintain stability in the face of system model uncertainty and external disturbances. The controller designed in this paper divides the attitude control loop into the following two parts: the angle loop and the angular velocity loop. The angle loop, serving as the main control loop of the attitude control, employs the robust H-infinity controller to process the angle of the quadrotor UAV and then transmits the processed value to the MPC controller. This approach reduces the computational load of the MPC controller. Simultaneously, by optimizing the algorithm, MPC minimizes the prediction error and the deviation from the control target. Simulation experiments confirm that the proposed algorithm improves the stability of the UAV attitude under random airflow disturbance conditions, while also achieving accurate tracking of the UAV’s position. Full article

The hydraulic support face guard system is essential for supporting the exposed coal wall at the working face. However, the hydraulic support face guard system approaching the coal wall may cause impact disturbances, reducing the load-bearing capacity of coal walls. Particularly, the hydraulic support face guard system is characterized by a large turning radius when mining thick coal seams. A strong disturbance and impact on the coal wall may occur if the approaching speed is too fast, leading to issues such as rib spalling. In this paper, a feedforward fuzzy PID displacement velocity compound controller (FFD displacement speed compound controller) is designed. The PID controller, fuzzy PID controller, feedforward PID controller, and FFD displacement speed compound controller are compared in terms of the tracking characteristics of the support system and the impact response of the coal wall, validating the controller’s rationality. The results indicate that the designed FFD displacement speed compound controller has significant advantages. This controller maintains a tracking error range of less than 1% for target displacement with random disturbances in the system, with a response adjustment time that is 34% faster than the PID controller. Furthermore, the tracking error range for target velocity is reduced by 8.4% compared to the feedforward PID controller, reaching 13.8%. Additionally, the impact disturbance of the support system on the coal wall is suppressed by the FFD displacement speed compound controller, reducing the instantaneous contact impact between the support plate and the coal wall by 350 kN. In summary, the FFD compound controller demonstrates excellence in tracking responsiveness and disturbance rejection, enhancing the efficacy of hydraulic supports, and achieving precise control over the impact on the coal wall. Full article

The exhaust gas recirculation (EGR) valve plays an important role in improving engine fuel economy and reducing emissions. In order to improve the positioning accuracy and robustness of the EGR valve under uncertain dynamics and external disturbances, this paper proposes a positioning servo system design for an electromotive (EM) EGR valve based on the Kalman filter. Taking a novel valve driven by a central winding limited angle torque motor (LATM) as the object, we have fully considered the influence of the motor rotor position and load current, as well as the magnetic field saturation and cogging effect, improved the existing LTAM model, and derived accurate torque expression. The parameter uncertainty of the above internal model and the external stochastic disturbance were unified as “total disturbance”, and a Kalman filter-based observer was designed for disturbance estimations and real-time feed-forward compensation. Furthermore, using non-contact magnetic angle measurements to obtain accurate valve position information, a position control model with real-time response and high accuracy was established. Numerous simulated and experimental data show that in the presence of ± 25% plant model parameter fluctuations and random shock-type disturbances, the servo system scheme proposed in this paper achieves a maximum position deviation of 0.3 mm, a repeatability of positioning accuracy after disturbances of 0.01 mm, and a disturbance recovery time of not more than 250 ms. In addition, the above performance is insensitive to the duration of the disturbance, which demonstrates the strong robustness, high accuracy, and excellent dynamic response capability of the proposed design. Full article

This paper investigates the secondary control problem of shipboard microgrids (SMGs) with a high percentage of new energy sources under general noise. Firstly, a polymorphic SMG model is constructed, which enables the software-defined functionality of the control strategy and allows heterogeneous distributed generators (DGs) in AC SMGs to exchange packets of different types. Secondly, due to the presence of highly dynamic and high-power loads in the SMGs, a containment-based distributed secondary control strategy is proposed to improve the flexibility of the DG voltage regulation. Then, considering the complexity and diversity of disturbances during ship navigation, general noise is introduced instead of white noise to describe various disturbances. Furthermore, based on the random differential equations (RDEs), the NOS stability of the proposed strategy is proved using Lyapunov theory, which proves the effectiveness of the containment-based distributed secondary control strategy under general noise. And, the containment error is obtained to prove that the voltage and frequency of the system converge to the convex hull spanned by the virtual leaders, ensuring the high quality of the power supply. Finally, the validity of the proposed containment-based strategy is verified by an AC SMG model with four DGs in three cases. Full article

This paper presents a novel fuzzy-augmented model reference adaptive voltage regulation strategy for the DC–DC buck converters to enhance their resilience against random input variations and load-step transients. The ubiquitous proportional-integral-derivative (PID) controller is employed as the baseline scheme, whose gains are tuned offline via a pre-calibrated linear-quadratic optimization scheme. However, owing to the inefficacy of the fixed-gain PID controller against parametric disturbances, it is retrofitted with a model reference adaptive controller that uses Lyapunov gain adaptation law for the online modification of PID gains. The adaptive controller is also augmented with an auxiliary fuzzy self-regulation system that acts as a superior regulator to dynamically update the adaptation rates of the Lyapunov gain adaptation law as a nonlinear function of the system’s classical error and its normalized acceleration. The proposed fuzzy system utilizes the knowledge of the system’s relative rate to execute better self-regulation of the adaptation rates, which in turn, flexibly steers the adaptability and response speed of the controller as the error conditions change. The propositions above are validated by performing tailored hardware experiments on a low-power DC–DC buck converter prototype. The experimental results validate the improved reference tracking and disturbance rejection ability of the proposed control law compared to the fixed PID controller. Full article
