The global energy crisis demands efficient electricity production solutions, especially for isolated communities where hydraulic energy can be harnessed sustainably. This paper presents a case study analyzing the efficiency of a 13,330 kW hydrogenerator, consisting of a bulb-type hydro-aggregate using the calorimetric method—a viable alternative when testing at nominal load is not feasible due to technical limitations. The method involves measuring the thermal energy absorbed by the cooling water under three operating conditions: no-load unexcited, no-load excited, and symmetric three-phase short-circuit. Measurements followed IEC standards and were conducted with high-precision instruments for temperature, flow, voltage, and current. The results quantify mechanical, ventilation, iron, and copper losses, as well as additional losses via radiation and convection. Thermal analysis revealed significant heat accumulation in the rotor and stator windings, indicating the need for improved cooling solutions. The calorimetric method enables efficiency evaluation without interrupting generator operation, offering a valuable tool for diagnostics, predictive maintenance, and informed decisions on modernization. Furthermore, integrating an intelligent operational control system could enhance efficiency and improve the quality of the supplied energy, supporting long-term sustainability in hydroelectric power generation. Full article

In recent years, with the advancement of renewable energy technologies, hydropower has assumed an increasingly important regulatory and balancing role in the power system. It plays an important role in grid frequency stability. This requires a faster response speed and superior disturbance immunity of the hydropower regulation system. The characteristics of active disturbance rejection control (ADRC) make it suitable for solving these kinds of nonlinearities, oscillations, and disturbances of hydro-generating units. The traditional ADRC has a complex structure and a large amount of parameter adjustments. In this paper, an improved ADRC based on a generalized differentiator is proposed, and the control loop consists of only the proportional and integrator. The parameters to be adjusted are reduced to two. The structure of the traditional ADRC is simplified. In several types of typical linear systems, the improved ADRC can harvest almost the same dynamic performance as the traditional ADRC. After applying the improved method to the simulation of a hydraulic turbine speed control system, a satisfactory response speed, superior anti-interference ability, and robustness are obtained. Full article

To address the escalating demand for power grid load regulation, pumped storage power stations must frequently switch between operational modes. As a key component of such stations, the pump turbine has seen extensive research on its steady-state flow behavior. However, the intricate dynamics of its transient flow have not yet been thoroughly examined. Notably, the no-load condition represents a quintessential transient state, the instability of which poses challenges for grid integration. Under certain extreme conditions, this could result in the impairment of the unit’s elements, interruption of its functioning, and endangerment of the security of the power station’s output as well as the stability of the power network’s operations. Thus, investigating the flow characteristics of pump turbines under no-load conditions is of significant practical importance. This paper focuses on the transient flow characteristics of a Weifang hydro-generator unit under no-load conditions, exploring the internal unsteady flow features and their underlying mechanisms. The study reveals that under no-load conditions, the runner channel is obstructed by a multitude of vortices, disrupting the normal pressure gradient within the runner and resulting in substantial hydraulic losses. Within the draft tube, a substantial reverse flow zone is present, predominantly along the walls. This irregular flow pattern within the tube generates a potent, stochastic pressure fluctuation. In addition to the interference frequencies of dynamic and static origins, the pressure pulsation frequency at each measurement point also encompasses a substantial portion of low-frequency, high-amplitude components. Full article

The shaft system, transferring the kinetic energy of water flow into electrical energy, is the most critical component in hydropower plants. Installation deviations of the shaft system for a giant hydro-generator unit can have significant impacts on its dynamic characteristics and overall performance. In this investigation, a three-dimensional geometry of the shaft system of an operating hydro-generator unit prototype with a rated power of 1 GW is established. Then, the calculation model of the shaft system is generated accordingly with tetrahedral and hexahedral elements. By applying different boundary conditions, the finite-element method is used to analyze the influences of installation deviations, including shaft radial misalignment and angular misalignment, on the dynamic characteristics of the shaft system. The calculation results reveal that the installation deviations change the natural frequencies, critical speeds, and mode shapes of the shaft system to a certain degree. The natural frequencies of the backward precession motion with installation deviations are reduced by 23% and 38% for the rated speed and the maximum runaway speed. Furthermore, for the forward precession motion, they increased by 30% and 48%, respectively. The critical speeds for the shaft system with radial and angular deviations are 3.2% and 3% larger than the critical speed of the shaft system without any mounting deviations. The radial and angular installation deviations below the maximum permissible values will not result in the structural performance degradation of the 1 GW hydro-generator shaft system. The conclusion drawn in this research can be used as a valuable reference for installing other rotating machinery. Full article

We suggest a new method of localization of partial discharges in high-power electrical systems. Ozone in a hydrogenerator is produced by chemical reactions induced by partial discharges in the stator region. The transport of ozone in an operating hydrogenerator is analyzed using a computational fluid dynamics model. The main aim of this work is to evaluate the ozone distribution in the generator radiators. Ozone sources are introduced into the stator model in different positions to analyze their effect on the measured values at the sensing points of radiators. Our results demonstrate a possibility of localization of partial discharges in hydrogenerator stator bars by ozone emission. Full article

In this paper, a three-dimensional turbulent fluid dynamics numerical model of a 311 MVA full hydroelectric power plant unit is made, using the finite element method, to study and understand the ozone transport mechanisms inside the enclosured electric machine structure. In the real world, ozone is produced by partial discharges related to faults on stator bars. In order to analyse ozone transport from localised sources, a 3D fluid dynamic model of a complete hydrogenerator in operation is developed and presented for the first time. The model has a high level of geometric detail. Furthermore, a new proposal to simplify the modelling of radiators is implemented and validated. The modelled structure is based on a Campos Novos hydrogenerator electric machine and it consists of 378 coil-type stator bars made of copper covered by mica and, more externally, by a semiconductor coating layer. Other parts are also represented, including the stator core and air directors made of stainless steel, copper radiators, the rotor with its epoxy surface, and the concrete floor and concrete external walls. In the fluid dynamics model, a finite element mesh was designed to represent the air regions inside the hydrogenerator and the material surfaces that react with ozone (with their respective reaction rates), where the airflow and ozone transport are modelled using the Navier–Stokes equations and the mass conservation law. Partial discharge sources are represented by ozone sources with prismatic shapes, placed on surfaces of stator bars. Ozone concentrations have been calculated inside and around the generator machine. The rotor radius is 3.8075 m and its rotation frequency is 200 RPM. Radial air velocity due to interpole ventilation is also considered (2.2 m/s, as experimentally verified in loco. The radial velocity in the vicinity of the radiators is 3 m/s. It has been concluded that the ozone transport profile is influenced by the source positioning on the stator bars in such a way that source pinpointing is possible and it depends on determining the local and global maxima areas of ozone concentration at the radiators. Full article

With the rapid development of artificial intelligence, machine vision and other information technologies in the construction of smart power plants, the requirements of power plants for the state monitoring of hydro-generator units (HGU) are becoming higher and higher. Based on this, this paper applies YOLOv5 to the state monitoring scenario of HGU, and proposes a method for rotor speed measurement (RSM) and operating state identification (OSI) of HGUs based on the YOLOv5. The proposed method is applied to the actual RSM and OSI of HGUs. The experimental results show that the Precision and Recall of the proposed method for rotor image are 99.5% and 100%, respectively. Compared with the traditional methods, the online image monitoring based on machine vision not only realizes high-precision RSM and the real-time and accurate determination of operating states, but also realizes video image monitoring of the rotor, the operation trend prediction of the rotor and the early warning of abnormal operating states, so that staff can find the hidden dangers in time and ensure the safe operation of the HGU. Full article

In the presented scientific work, the basic design versions of the thrust bearings of Hydrogenerators are considered. The main causes of emergencies in the thrust bearing unit of a high-power Hydrogenerator are considered. The main requirements for the operation of thrust bearings are submitted. Cause-and-effect relationships of emerging and development of defects are established. Existing methods for calculating the stressed state of a thrust bearing in the classical formulation for a stationary mode of operation are considered. The main features of the operation of the thrust bearing unit are investigated in relation to the features of the sliding bearings. The calculation of the elastic chambers of the hydraulic thrust bearing in a three-dimensional formulation is carried out, taking into account the physical properties of the oil, the material of the chambers and distribution of the acting loads. It is shown that the applied designs of Join Stock Company “Ukrainian Energy Machines” can be used in high-power Hydrogenerators. Full article

Hydropower generation is clean, pollution-free, and renewable, and has good social and economic benefits, so it is given priority for development throughout the world. The capacity of hydropower stations is increasing to 1000 MW from 700 MW. As the p value on the bearing reaches a new height, coupled with the original risk of easy damage, the thrust bearing faces new technical challenges. Maglev technology is studied and applied to a large vertical-shaft hydro-generator set to solve the bearing problem. The maglev device is designed, and the working principle is expounded, using active-control repulsive-suspension technology. The levitation-force addition and the torque cancellation are realized by controlling the frequency of the excitation power supply. The dynamic mathematical models of levitation force and torque are derived. Combined with the design and theoretical analysis, the vector-control strategy is developed and the simulation analysis is completed. According to the results, the controller is improved to enhance the response performance. Finally, a control experiment is carried out on the prototype, and the results verify the effectiveness of the design and control strategy. Full article

The hydraulic turbine governing system (HTGS) is a complex nonlinear system that regulates the rotational speed and power of a hydro-generator set. In this work, an incremental form of an HTGS nonlinear model was established and the Takagi–Sugeno (T-S) fuzzy linearization and mixed H₂/H_∞ robust control theory was applied to the design of an HTGS controller. A T-S fuzzy H₂/H_∞ controller for an HTGS based on modified hybrid particle swarm optimization and gravitational search algorithm integrated with chaotic maps (CPSOGSA) is proposed in this paper. The T-S fuzzy model of an HTGS that integrates multiple-state space equations was established by linearizing numerous equilibrium points. The linear matrix inequality (LMI) toolbox in MATLAB was used to solve the mixed H₂/H_∞ feedback coefficients using the CPSOGSA intelligent algorithm to optimize the weighting matrix in the process so that each mixed H₂/H_∞ feedback coefficients in the fuzzy control were optimized under the constraints to improve the performance of the controller. The simulation results show that this method allows the HTGS to perform well in suppressing system frequency deviations. In addition, the robustness of the method to system parameter variations is also verified. Full article

Changes in climate patterns not only affect precipitation and precipitation patterns, but also cause the spatiotemporal redistribution of precipitation and runoff, affecting hydrogeneration in turn. Based on the coupling relationship between the Coupled Model Intercomparison Project 5 (CMIP5) climate change model and surface runoff in China, a database of China’s major hydropower stations was constructed in this study and the Water Evaluation and Planning model was applied to analyze the impacts of climate change on hydropower generation in China by region and basin under the Representative Concentration Pathway (RCP)4.5 and RCP8.5 scenarios. During the forecast period, national power generation compared with base year first decreased in the 2030s and then increased in the 2070s, while a risk of excessive hydropower generation was concentrated in the southwestern provinces, Yangtze River Basin, and giant hydropower stations. During the 2030s, hydropower generation may face a risk of electricity generation decrease which will limit its contribution to the Nationally Determined Contribution target. Full article

During the operation of each machine, there are dynamic effects causing vibrations. Such a device is also an experimental horizontal drilling stand with aggregates, i.e., a direct current motor (DC), a pump, and a hydro-generator. During their operation, unwanted vibration acceleration signals are generated. It is clear that the accompanying vibration signal carries integrating information about the current state of the drilling rig. Vibration signal processing methods for the time and frequency domains were used. The results of time-domain processing showed significant differences in time waveforms, statistical characteristics, and auto-correlation functions. The auto-correlation function pointed to the periodicity and dependence of the vibrational signal samples. Based on the acquired knowledge, the signals were classified, and a strong source of vibration was determined. Noise is superimposed on the harmonic components of the signals. Amplitude and power spectra were constructed in the frequency domain. Dominant frequencies were identified for each investigated mode in the operating mode. Power spectra removed less significant frequencies and focused on the dominant ones. Time-frequency spectrograms revealed significantly higher frequency bands. The proposed methods can be implemented in diagnosing the operation of the machine and aggregates, determining the source of the greatest vibrations, wear of parts of the equipment such as the drill bit, and recognition of the overall condition of the equipment. Full article

The Ethiopia energy mix is dominated by hydro-generation, which is largely reliant on water resources and their availability. This article aims to examine the impacts of severe drought on electric power generation by developing a Drought Scenario. OSeMOSYS (an open source energy modelling tool) was used to perform the analyses. The results were then compared with an existing reference scenario called “New Policy Scenario”. The study looked at how power generation and CO₂ emissions would be altered in the future if reservoir capacity was halved due to drought. Taking this into account, the renewable energy share decreased from its 90% in 2050 to 81% in 2065, which had been 98% to 89% in the case of New Policy Scenario. In another case, CO₂ emissions also increased from 0.42 Mt CO₂ in 2015 to 7.3 Mt CO₂ in 2065, a 3.3 Mt CO₂ increase as compared to the New Scenario. The results showed how a prolonged period of drought would reduce the river flows and lead to an energy transition that may necessitate the installation of other concurrent alternative power plants. The study suggested ways to approach energy mix, particularly for countries with hydro-dominated power generation and those experiencing drought. Full article

From the breakdown of the Kaplan rotor of a hydrogenerator unit and the monitored data collected during its operation before such a failure, this work presents a post-occurrence data analysis in which a previously developed hybrid method based on unsupervised machine learning techniques is applied to detect and diagnose failure before a unit shutdown. In addition to demonstrating the efficiency and capacity of the developed method in an application with real data, the conducted analysis seeks to shed light on the events that occurred at the considered hydroelectric power plant, helping to understand the failure mode evolution and outcome. The results of the fault detection and diagnosis process clearly demonstrated how the evolution of failure modes took place in the analyzed equipment. The detection of potential failures far in advance would support adequate maintenance planning and mitigating actions that could prevent unit breakdown and the consequent damage and financial losses. Full article

As we move towards electrical networks with a growing presence of renewable generation, the representation of the electrical components becomes more important. In hydro-dominated power systems, modelling the forbidden zones of hydro plants becomes increasingly challenging as the number of plants increases. Such zones are ranges of generation that either should be avoided or are altogether unreachable. However, because representing the forbidden zones introduces a substantial computational burden, hydrothermal unit-commitment problems (HTUC) for large systems are usually formulated ignoring the forbidden zones. Nonetheless, this simplification may demand adjustments to the solution of the HTUC, because the generation of the hydro stations may fall in forbidden zones. In practice, the adjustments are usually performed based on the experience of system operators and, then, can be far from an optimal correction. In this paper, we study the impact of explicitly representing the hydro-generation forbidden zones in a large-scale system with more than 7000 buses, 10,000 lines, and 700 hydro units. Our findings show that the simplified model that is current used can deviate significantly from the model with forbidden zones, both in terms of the generation of hydro plants, as well as the generation of thermal plants and the system marginal costs. Full article
