Search Results (37)

Background/Objectives: The achievement of stable and functional occlusal contacts represents a key objective of orthodontic treatment, particularly in growing patients. Evidence comparing the effectiveness of these two modalities in establishing adequate occlusal contacts in growing patients remains limited. This study aimed to evaluate and compare occlusal contact characteristics following clear aligner therapy (CAT) and fixed orthodontic therapy (FAT). Methods: Twenty-four growing patients (<18 years with permanent dentition) were included in the study and divided into two groups: 12 patients treated with fixed appliances and 12 treated with clear aligners. Post-treatment digital dental scans were analyzed to assess occlusal contacts. Contacts were calculated as the minimum distance between upper and lower arches using a color-map analysis. The following outcomes were evaluated: Maximum Contact Point (MCP), occlusal contact surface (OCS, ≤50 μm from MCP), near occlusal contact surface (NOCS, ≤350 μm), half mm (≤0.5 mm), and one mm (≤1 mm). Total occlusal contacts, antero-posterior distribution, left–right asymmetry, and single-tooth contacts were assessed. Results: The FAT group showed higher total occlusal contact values in OCS compared to the CAT group (p < 0.05). Statistical difference was also observed in the antero-posterior ratio, with FAT presenting fewer anterior contacts in OCS, NOCS, half-mm, and one-mm measurements (p < 0.05). No significant differences were found between groups in terms of left–right asymmetry or post-treatment single-tooth contacts, except for the second premolar, which exhibited higher contacts in the FAT group (p < 0.05). Conclusions: Fixed orthodontic treatment is more effective than aligners in achieving adequate occlusal contacts, with differences limited to tight contacts and antero-posterior occlusal distribution. Full article

To address the limitations of traditional analytical modeling in capturing complex surface topographies, this paper presents comprehensive research on the error sensitivity mechanism, loaded tooth contact analysis (LTCA), and load-bearing contact characteristics of curved face gears based on high-precision point cloud modeling. The primary objectives are threefold: (1) to establish a high-fidelity topological reconstruction framework using Non-Uniform Rational B-Splines (NURBS) to bridge the gap between discrete data and finite element analysis (FEA); (2) to reveal the inherent mechanical response and sensitivity mechanism to spatial installation misalignments; and (3) to evaluate the contact performance and transmission error fluctuations under operational loads. Specifically, an analytical discretization method is proposed for point cloud generation, followed by a dual-path validation system integrating “rigid tooth contact analysis (TCA)” and “loaded FEA”. The results demonstrate that the proposed reconstruction achieves a superior accuracy with a Root Mean Square Error (RMSE) of 2.2 × 10⁻³ mm. Furthermore, shaft angle error is identified as the dominant sensitivity factor affecting transmission smoothness and edge contact, exerting a more significant influence than offset and axial errors. Compared with existing research on arc-tooth and helical face gears, this work provides a more robust closed-loop verification for curved profiles, revealing that material elastic deformation increases transmission error amplitude by 10.1% to 17.2%. These insights offer a theoretical reference for the high-precision assembly and tolerance allocation of helicopter transmission systems. Full article

Formed milling is one of the most commonly used methods for machining the helical surfaces of various screw rotors. The profile of a formed cutter is designed according to the profile of the helical surface, which is usually represented by discrete points. The most widely used analytical method is rather complex, and it is easy to obtain singular points. To obtain a reliable cutter profile and simplify the solution procedure, a general numerical method suited for rotors with an arbitrary tooth profile is proposed. The proposed method does not need to establish and solve the complex nonlinear contact equation and can determine the contact point accurately. Firstly, a series of intersection planes that are perpendicular to the revolving axis of the cutter is constructed. The searching of the contact points of the selected tooth curves with each intersection plane is achieved using the subdivision method. By this means, the plane–curve intersection is simplified to a straight line–curve intersection that can easily be solved via Newton iteration. Meanwhile, the machinability related to the profile of the formed cutter can also be analyzed. Two cutter profiles are used to validate the proposed method. The cutter profiles generated by the proposed method are compared with the profiles generated by the analytical method. The results indicate that the accuracy and computational efficiency increase significantly. Furthermore, the proposed method can also be applied to the design of formed grinding wheels. Full article

This paper investigates the design methodologies of pure rolling helical gear pumps with various tooth profiles, based on the active design of meshing lines. The transverse active tooth profile of a pure rolling helical gear end face is composed of various function curves at key control points. The entire transverse tooth profile consists of the active tooth profile and the Hermite curve as the tooth root transition, seamlessly connecting at the designated control points. The tooth surface is created by sweeping the entire transverse tooth profile along the pure rolling contact curves. The fundamental design parameters, tooth profile equations, tooth surface equations, and a two-dimensional fluid model for pure rolling helical gears were established. The pressure pulsation characteristics of pure rolling helical gear pumps and CBB-40 involute spur gear pumps, each with different tooth profiles, were compared under specific working pressures. This comparison encompassed the maximum effective positive and negative pressures within the meshing region, pressure fluctuations at the midpoints of both inlet and outlet pressures, and pressure fluctuations at the rear sections of the inlet and outlet pressures. The results indicated that the proposed pure rolling helical gear pump with a parabolic tooth profile exhibited 42.81% lower effective positive pressure in the meshing region compared to the involute spur gear pump, while the maximum effective negative pressure was approximately 27 times smaller than that of the involute gear pump. Specifically, the pressure pulsations in the middle and rear regions of the inlet and outlet pressure zones were reduced by 33.1%, 6.33%, 57.27%, and 69.61%, respectively, compared to the involute spur gear pump. Full article

Based on the idea of a surface moving frame in differential geometry, a surface envelopment approximation method is proposed for the integrated design of point-contact tooth surfaces. This method utilizes the envelopment characteristic curve of the first tooth surface as the spline curve and adopts the local structure of the second tooth surface along a predesigned contact path as the surface interpolation condition. Through motion transformation described by the motion invariants of the first tooth surface, a conjugate motion space for the second tooth surface is fully defined by the motion invariants of the first tooth surface. This constitutes the basis of the integrated optimization design space and ensures the global optimization and machinability of the tooth surface design method. Using the experimental data of the point meshing tooth surface loading contact, the gap between the two tooth surfaces during no-load meshing is used as the design target parameter to predict and control the shape and size of the contact area under heavy load and further the symmetry requirements of the tooth surface design. Consequently, a variational inequality model for the global optimal design of the point meshing tooth surface is established. Full article

Gear modification, which involves the removal of material from the theoretical surface to improve the contact characteristics of the gear face, is widely applied in gear vibration reduction and noise optimization design. This paper establishes a dynamic model of the straight bevel gear (SBG) transmission system to accurately and efficiently evaluate the effects of different modification strategies on the vibrational characteristics of SBGs. Initially, the time-varying meshing stiffness (TVMS) of standard SBGs was calculated, and methods such as the slicing method and deformation coordination equations were used to calculate the TVMS under tooth profile modification (TPM), Lead crown relief (LCR), and comprehensive modification (CM), which were then validated against finite element method (FEM) calculations. Subsequently, taking into account the impact of time-varying meshing point vectors and the degree of contact overlap, a finite element node dynamic model of the SBG transmission system was established. Finally, by comparing the dynamic characteristics under different modification conditions, the study further elucidates that selecting the appropriate modification method and amount according to different service scenarios is an effective means to suppress gear transmission vibration. This research provides a theoretical basis for the design of gear modification and vibration control for SBGs. Full article

This research aims to investigate the influence of model height employed in the deep drawing of orthodontic aligner sheets on force transmission and aligner thickness. Forty aligner sheets (Zendura FLX) were thermoformed over four models of varying heights (15, 20, 25, and 30 mm). Normal contact force generated on the facial surface of the upper right central incisor (Tooth 11) was measured using pressure-sensitive films. Aligner thickness around Tooth 11 was measured at five points. A digital caliper and a micro-computed tomography (µ-CT) were employed for thickness measurements. The normal contact force exhibited an uneven distribution across the facial surface of Tooth 11. Model 15 displayed the highest force (88.9 ± 23.2 N), while Model 30 exhibited the lowest (45.7 ± 15.8 N). The force distribution was more favorable for bodily movement with Model 15. Thickness measurements revealed substantial thinning of the aligner after thermoforming. This thinning was most pronounced at the incisal edge (50% of the original thickness) and least at the gingivo-facial part (85%). Additionally, there was a progressive reduction in aligner thickness with increasing model height, which was most significant on the facial tooth surfaces. We conclude that the thermoplastic aligner sheets undergo substantial thinning during the thermoforming process, which becomes more pronounced as the height of the model increases. As a result, there is a decrease in both overall and localized force transmission, which could lead to increased tipping by the aligner and a diminished ability to achieve bodily movement. Full article

The aim of this paper was to evaluate the fracture resistance of 3D-printed zirconia occlusal veneers (OVs) of different thicknesses and supported by different abutment materials. Materials and Methods: The standard OV of a natural molar was prepared and digitized using a laboratory 3D scanner. The resulting digital tooth abutment was milled either using cobalt–chromium (CoCr) or a fiber-reinforced composite (FRC). All the abutments were digitized and standardized OVs (30° tilt of all the cusps) designed with 0.4 mm, 0.6 mm, or 0.8 mm wall thicknesses. The OVs were fabricated using either the Programill PM7 milling device (Ivoclar Vivadent, PM) or one of two 3D zirconia printers, Cerafab 7500 (Lithoz, LC) or Zipro-D (AON, ZD). The ZD samples were only tested on CoCr abutments. The completed OVs were luted to their abutments and subjected to artificial aging, consisting of thermocycling and chewing simulation before fracture testing with a steel sphere (d = 8 mm) as an antagonist with three contact points on the occlusal OV surface. Besides the total fracture resistance F_u,tot, the lowest contact force F_u,cont leading to the local fracture of a cusp was of interest. The possible effects of the factors fabrication approach, wall thickness, and abutment material were evaluated using ANOVA (α = 0.05; SPSS Ver.28). Results: The total fracture resistance/contact forces leading to failure ranged from F_u,tot = 416 ± 83 N/F_u,cont = 140 ± 22 N for the 0.4 mm OVs fabricated using LC placed on the FRC abutments to F_u,tot = 3309 ± 394 N (ZD)/F_u,cont = 1206 ± 184 N (PM) for the 0.8 mm thick OVs on the CoCr abutments. All the factors (the fabrication approach, abutment material, and OV wall thickness) had an independent effect on F_u,tot as well as F_u,cont (p < 0.032). In pairwise comparisons for F_u,tot of the OVs luted to the CoCr abutments, the ZD samples statistically outperformed the LC- and PM-fabricated teeth irrespective of the thickness (p < 0.001). Conclusions: Within the limitations of this study, the printed occlusal veneers exhibited comparable fracture resistances to those of the milled variants. However, more resilient abutments (FRC as a simulation of dentine) as well as a thinner wall thickness led to reduced OV fracture resistance, suggesting that 0.4 mm thick zirconia OVs should not be unreservedly used in every clinical situation. Full article

Load-capacity has always been one of the performances that is paid much attention to in the development of bevel gear transmission applications. Consequently, the mathematical model of novel bevel gear with high load-capacity based on geometric elements is proposed in this paper, which could be applied to the aviation, aerospace and other fields. In parallel, the design principle and design method of the novel bevel gear are introduced in detail. Subsequently, the conditions for tooth surface continuity and non-interference are derived. Furthermore, the model of novel bevel gear is established. Finally, the load-bearing characteristics are analyzed, revealing that an increase in the number of contact points could significantly enhance the load capacity of the bevel gear pairs. When the load torque applied to bevel gear II is 100 Nm, the contact pressure endured by the bevel gear pair with five-point contact is decreased by 41.37% compared to the bevel gear pair with single-point contact. When the number of contact points is the same, increasing the distance between the contact points could also reduce the contact stress. This provides strong theoretical support for the application of the bevel gear based on the geometric elements. Full article

Loaded meshing transmission performance optimization has been an increasingly significant target for the design and manufacturing of aerospace spiral bevel gears with low noise and high strength. An innovative data-driven multi-objective optimization (MOO) method is proposed for the loaded meshing transmission performances of aerospace spiral bevel gears. Data-driven tooth surface modeling is first used to obtain a curvature analysis of loaded contact points. An innovative numerical loaded tooth contact analysis (NLTCA) is applied to develop the data-driven relationships of machine tool settings with respect to loaded meshing transmission performance evaluations. Moreover, the MOO function is solved by using an achievement function approach to accurate machine tool settings output, satisfying the prescribed requirements. Finally, numerical examples are given to verify the proposed methodology. The presented approach can serve as a powerful tool to optimize the loaded meshing transmission performances with higher computational accuracy and efficiency than the conventional methods. Full article

An atypical face gear pair with complex transmission motion can be used in intermittent reciprocating mechanisms with more precise transmission and a much higher capacity than conventional mechanisms, such as cams and linkages. In this study, we derive a mathematical equation for the complex tooth surface of this gear pair. We indicate the change in root cutting, top sharpening and the effective width of the tooth surface with different parameters. Additionally, we derive the governing equation for the kinematical characteristics of this eccentric curve-face gear pair with a rigid–flexible coupling system, revealing the continuous intermittent contact principle of this gear type with different parameters. Boundary conditions for the gear pair are proposed, demonstrating that the vibration of the gear pair is more obvious, even at a low velocity. In addition, the critical velocity, which mostly ranges from 300 rpm to 400 rpm, is affected by the stiffness of the frames and the parameters of the tooth surfaces. The interval space and interval time of the intermittent contact system are $\Delta d\le 0.3 mm$ and $\Delta t\le 5.6\times {10}^{-4} s$, with visible surface sliding on the contact area. It is shown that the contact points are firstly concentrated at the outer part of the tooth surface and that the meshing will break off at the first tooth with the minimum inner radius $R_{Gi-\min }$. These theoretical results, which have been verified experimentally, provide theoretical support for further analysis and the better application of this unconventional gear pair. Full article

The restoration of endodontically treated teeth is one of the main challenges of restorative dentistry. The structure of the tooth is a complex assembly in which the materials that make it up, enamel and dentin, have very different mechanical behaviors. Therefore, finding alternative replacement materials for dental crowns in the area of restorative care isa highly significant challenge, since materials such as ceramic and zirconia have very different stress load resistance values. The aim of this study is to assess which material, either ceramic or zirconia, optimizes the behavior of a restored tooth under various typical clinical conditions and the masticatory load. A finite element analysis (FEA) framework is developed for this purpose. The 3D model of the restored tooth is input into the FEA software (Ansys Workbench R23)and meshed into tetrahedral elements. The presence of masticatory forces is considered: in particular, vertical, 45° inclined, and horizontal resultant forces of 280 N are applied on five contact points of the occlusal surface. The numerical results show that the maximum stress developed in the restored tooth including a ceramic crown and subject to axial load is about 39.381 MPa, which is rather close to the 62.32 MPa stress computed for the natural tooth; stresses of about 18 MPa are localized at the roots of both crown materials. In the case of the zirconia crown, the stresses are much higher than those in the ceramic crown, except for the 45° load direction, while, for the horizontal loads, the stress peak in the zirconia crown is almost three times as large as its counterpart in the ceramic crown (i.e., 163.24 MPa vs. 56.114 MPa, respectively). Therefore, the zirconia crown exhibits higher stresses than enamel and ceramic that could increase in the case of parafunctions, such as bruxism. The clinician’s choice between the two materials should be evaluated based on the patient’s medical condition. Full article

This paper presents an ultimate motion methodology of a face-milling spiral bevel gear pair to synthesize the mating tooth surfaces with a predesigned fourth-order motion curve. The methodology is to control some contact points along the contact path in the process of tooth contact analysis via application of an extended local synthesis which permits some transmission errors rather than zero at the concerned contact point. The modified offset motion correction is selected to demonstrate the proposed methodology. Applied torque corresponding to an elastic approach of 0.00635 mm at the mean contact point is calculated and the loaded tooth contact analysis is performed. Numerical results show that the extended local synthesis can effectively control the transmission errors on the predesigned fourth-order motion curve at arbitrarily predesigned contact points along the contact path of the spiral bevel gear pair. The tooth contact pattern for the actual tooth pair is scattered into three segments since the rotational motion of the driven gear at any instant angular position is dependent on the tooth pair with the least transmission error among the three adjacent tooth pairs. The actual tooth contact patterns of the spiral bevel gear pair become continuous when meshing tooth surfaces are elastically deformed. Full article

Crowning is applied to wind turbine gears, including spur gears, to ensure adequate stress distribution and contact localization in wind turbine main gearbox gears to improve the gear performance in the presence of misalignments. Each gear tooth is crowned along the face width using a parabolic curve that graduates from a maximum height at the edges and vanishes at the center of the tooth flank. This crowning transfers the elastohydrodynamic contact problem from a line to a point contact case where the surface curvatures and pressure gradient are considered in both directions of the solution space. A wide range of longitudinal crowning heights is considered in this analysis under heavily loaded teeth for typical large-scale wind turbine gears. Furthermore, the variation in the velocities is considered in the analysis. The full transient elastohydrodynamic point contact solution considers the non-Newtonian oil behavior, where the numerical solution is based on the finite difference method. This work is focused on the evaluation of the effectiveness of teeth’s longitudinal crowning in terms of the consequences on the resulting pressure distribution and the corresponding film thickness. The modification of the tooth flank significantly elevates the film thickness levels over the zones close to the tooth edges without a significant increase in the pressure values. Moreover, the zone close to the tooth edges from both sides, where the pressure is expected to drop to the ambient pressure, is extended as a result of the flank modification. Full article

This study establishes the geometric model of cycloid–pin gear meshing transmission based on the multi-tooth meshing characteristics of the cycloid speed reducer. The calculation and analysis of meshing motion parameters of the cycloid speed reducer are carried out. An integrated calculation flow is presented for solving the question of the loaded tooth contact of the cycloid speed reducer by using the elimination clearance method of gradual contact and the quasi-Hertz contact simulation of the tooth surface under loads. The loaded transmission error is obtained, and both the number of pins participating in the meshing and the contact area of tooth surfaces are determined. Using the regression formula of the wear coefficient, the dynamic wear coefficient is quickly solved on the instantaneous contact line of the tooth surface. Thereby, the wear distribution law of two tooth surfaces appears. The results show that there is a singular point in the wear of the pin teeth, with a maximum wear of 100 μm, that seriously affects the meshing accuracy of the tooth surface and thus affects the accuracy and lifespan of the reducer. Full article
