Automotive-grade GaN power switches have recently been made available in the market from a growing number of semiconductor suppliers. The exploitation of this technology enables the development of very efficient power converters operating at much higher switching frequencies with respect to components implemented with silicon power devices. Thus, a new generation of automotive power components with an increased power density is expected to replace silicon-based products in the development of higher-performance electric and hybrid vehicles. 650 V GaN-on-silicon power switches are particularly suitable for the development of 3–7 kW on-board battery chargers (OBCs) for electric cars and motorcycles with a 400 V nominal voltage battery pack. This paper describes the design and implementation of a 6.6 kW OBC for electric vehicles using automotive-grade, 650 V, 25 mΩ, discrete GaN switches. The OBC allows bi-directional power flow, since it is composed of a bridgeless, interleaved, totem-pole PFC AC/DC active front end, followed by a dual active bridge (DAB) DC-DC converter. The OBC can operate from a single-phase 90–264 Vrms AC grid to a 200–450 V high-voltage (HV) battery and also integrates an auxiliary 1 kW DC-DC converter to connect the HV battery to the 12 V battery of the vehicle. The auxiliary DC-DC converter is a center-tapped phase-shifted full-bridge (PSFB) converter with synchronous rectification. At the low-voltage side of the auxiliary converter, 100 V GaN power switches are used. The entire OBC is liquid-cooled. The first prototype of the OBC exhibited a 96% efficiency and 2.2 kW/L power density (including the cooling system) at a 60 °C ambient temperature. Full article

In recent years, the trend in power electronics has been toward high-efficiency and high-power-density converters. Additionally, this trend has allowed electric vehicles to accommodate larger batteries, which necessitate bi-directional capabilities not only for driving but also for vehicle to grid (V2G), etc. This article proposes a comparative analysis of GaN-based bi-directional topologies, namely the dual active bridge (DAB) converter and the CLLC converter. To ensure a fair analysis of the proposed topologies, prototypes with the same target of efficiency above 97.5% and a power density of 5.5 kW/L have been constructed. This research can support the adoption of 10.9 kW bi-directional topologies in GaN-based on-board chargers (OBCs) for EVs. Full article

This study focuses on the transformation of Jaguar XJ40 vehicles to electric power, with the main equipment being a permanent-magnet synchronous motor (PMSM), lithium iron phosphate (LFP) batteries, an on-board charger (OBC) system, and a battery management system (BMS). The process involves integrating the PMSM with the vehicle’s existing transmission system. This research compares the driving range of battery electric vehicles (BEVs) using different testing methods under the same conditions: simulation, dynamometer (dino), and actual on-road testing. Based on Raminthra’s public roads (RITA drive cycle), one drive cycle covers 7.64 km in 11.25 min. The simulation test by MATLAB/SIMULINK R2016a predicts a driving distance of up to 282.14 km. The dino test, using a chassis dynamometer to simulate driving conditions while the vehicle remains stationary, indicates a driving distance of 264.68 km. In contrast, actual on-road tests show a driving distance of 259.09 km, accounting for real-world driving conditions, including variations in speed, road types, weather, and traffic. The motor achieves 95% efficiency at 2400 rpm and 420 Nm torque. The simulated distance differs from the actual road distance by approximately 8.17%, suggesting reasonable accuracy of the model. Full article

Climate change risks have triggered the international community to find efficient solutions to reduce greenhouse gas (GHG) emissions mainly produced by the energy, industrial, and transportation sectors. The problem can be significantly tackled by promoting electric vehicles (EVs) to be the dominant technology in the transportation sector. Accordingly, there is a pressing need to increase the scale of EV penetration, which requires simplifying the manufacturing process, increasing the training level of maintenance personnel, securing the necessary supply chains, and, importantly, developing the charging infrastructure. A new modular trend in EV manufacturing is being explored and tested by several large automotive companies, mainly in the USA, the European Union, and China. This modular manufacturing platform paves the way for standardised manufacturing and assembly of EVs when standard scalable units are used to build EVs at different power scales, ranging from small light-duty vehicles to large electric buses and trucks. In this context, modularising EV electric systems needs to be considered to prepare for the next EV generation. This paper reviews the main modular topologies presented in the literature in the context of EV systems. This paper summarises the most promising topologies in terms of modularised battery connections, propulsion systems focusing on inverters and rectifiers, modular cascaded EV machines, and modular charging systems. Full article

The rising Greenhouse Gas (GHG) emissions stemming from the extensive use of automobiles across the globe represent a critical environmental challenge, contributing significantly to phenomena such as global warming and the deterioration of air quality. To address these challenges, there is a critical need for research and development in electric vehicles (EVs) and their associated charging infrastructure, including off-board and on-board chargers (OBCs). This paper aims to bridge the gaps in existing review literature by offering a comprehensive review of both integrated and non-integrated OBCs for EVs, based on the authors’ knowledge at the time of writing. The paper begins by outlining trends in the EV market, including voltage levels, power ratings, and relevant standards. It then provides a detailed analysis of two-level and multi-level power converter topologies, covering AC-DC power factor correction (PFC) and isolated DC-DC topologies. Subsequently, it discusses single-stage and two-stage non-integrated OBC solutions. Additionally, various categories of integrated OBCs (iOBCs) are explored, accompanied by relevant examples. The paper also includes comparison tables containing technical specifications and key characteristics for reference and analysis. Full article

This paper presents operation and control systems for a new modular on-board charger (OBC) based on a SEPIC converter (MSOBC) for electric vehicle (EV) applications. The MSOBC aims to modularise the battery units in the energy storage system of the EV to provide better safety and improved operation. This is mainly achieved by reducing the voltage of the battery packs without sacrificing the performance required by the HV system. The proposed MSOBC is an integrated OBC which can operate the EV during traction and braking, as well as charge the battery units. The MSOBC is composed of several submodules consisting of a full-bridge voltage source converter connected on the ac side and SEPIC converter installed on the battery side. The SEPIC converter controls the battery segments with a continuous current because it has an input inductor which can smooth the battery’s currents without the need for large electrolytic capacitors. The isolated version of the SEPIC converter is employed to enhance the system’s safety by providing galvanic isolation between the batteries and the ac output side. This paper presents the necessary control loops to ensure the optimal operation of the EV with the MSOBC in terms of charge and temperature balance without disturbing the required modes of operation. The mathematical analyses in this paper are validated using a full-scale EV controlled by TMS320F28335 DSP. Full article

The wide-scale adoption and accelerated growth of electric vehicle (EV) use and increasing demand for faster charging necessitate the research and development of power electronic converters to achieve high-power, compact, and reliable EV charging solutions. Although the fast charging concept is often associated with off-board DC chargers, the importance of on-board AC fast charging is undeniable with the increasing battery capacities. This article comprehensively reviews gallium nitride (GaN) semiconductor-based bidirectional on-board charger (OBC) topologies used in both 400 V and 800 V EV applications. Moreover, comparative evaluations of GaN-based bi-directional OBC topologies regarding power conversion losses (conduction loss and soft switching capabilities), power density, implementation considerations, power quality, electromagnetic interference, and reliability aspects have been presented. The status of commercially available GaN power modules, advancements in GaN technology, applicable industry standards, and application requirements for OBCs have been also included in this study. Finally, in light of forthcoming advancements in GaN power transistor technology, this study highlights potential areas of research related to the reviewed topologies. Such research can aid researchers and designers in improving the performance and user experience of electric vehicles, ultimately supporting the widespread adoption of EVs. Full article

This paper proposes a dynamic characteristic improvement of an integrated on-board charger (OBC) using a model predictive control (MPC) method. The integrated OBC performs both battery charging and starter generator (SG) driving for engine starting in plug-in hybrid electric vehicles (PHEVs). If it performs battery charging, battery-side voltage and battery-side current are control objects which are usually controlled by using a proportional-integral (PI) controller. However, it has the disadvantage of undesirable dynamic characteristics, and gain tuning of the PI controller is necessary to properly control the voltage and current. Therefore, this paper proposes the MPC method for the dynamic characteristic improvement of integrated OBC. It can achieve not only dynamic characteristic improvement, but also robustness from the abrupt change of load impedance. By using the proposed MPC method for integrated OBC, the settling time to control the output voltage is decreased by 50% in the transient state compared to that by using the PI controller. The effectiveness of the proposed MPC method is verified by simulation and experimental results. Full article

Recently, Plug-in Hybrid Electric Vehicles (PHEVs) have gathered a lot of attention by integrating an electric motor with an Internal Combustion Engine (ICE) to minimize fuel consumption and greenhouse gas emissions. The On-Board Chargers (OBCs) are selected in this research because they are limited by dimensions and mass, and also consume low amounts of power. The Equivalent Series Resistance (ESR) of a filter capacitor is minor, so the zero produced by the ESR is positioned at a high frequency. In this state, the system magnitude gradually drops, causing a ripple in the circuit that generates a harmful impact on the battery’s stability. To improve the stability of the system, a Neural Network with an Improved Particle Swarm Optimization (NN–IPSO) control algorithm was developed. This study establishes an isolated converter topology for PHEVs to preserve battery-charging functions through a lesser number of power electronic devices over the existing topology. This isolated converter topology is controlled by NN–IPSO for the PHEV, which interfaces with the battery. The simulation results were validated in MATLAB, indicating that the proposed NN–IPSO-based isolated converter topology minimizes the Total Harmonic Distortion (THD) to 3.69% and the power losses to 0.047 KW, and increases the efficiency to 99.823%, which is much better than that of the existing Switched Reluctance Motor (SRM) power train topology. Full article

This article reviews the different topologies compatible with V2G feature and control approaches of integrated onboard charger (iOBC) systems for battery electric vehicles (BEVs). The integrated topologies are presented, analyzed, and compared in terms of component count, switching frequency, total harmonic distortion (THD), charging and traction efficiencies, controllability, reliability and multifunctionality. This paper also analyzes different control approaches for charging and traction modes. Moreover, the performance indices such as setting time, rise time, overshoot, etc., are summarized for charging and traction operations. Additionally, the feasibility of a Level 3 charging (AC fast charging with 400 Vac) of up to 44 kW iOBC is discussed in terms of converter efficiencies with different switching frequencies and switch technologies such as SiC and GaN. Finally, this paper explores the power density trends of different commercial integrated charging systems. The power density trend analysis could certainly help researchers and solution engineers in the automotive industry to select the suitable converter topology to achieve the projected power density. Full article

Onboard charging systems (OBCs) convert AC power from an external charging source into a DC voltage used to charge the battery pack of an electric vehicle (EV). OBCs are versatile since they can convert energy from almost every AC source, including standard household electrical receptacles, without needing wall chargers or charging stations. Since the same motor-drive electronics are reconfigured for onboard charging, weight and cost barely increase. However, the power quality and reliability of the OBCs are essential elements for proper grid interconnection. This article reviews the failures of power electronic converters that can be used for onboard charging and their most prominent fault-tolerance techniques. The various fault-tolerance methods are evaluated and compared in terms of complexity, cost, and performance to provide insights for future developments and research directions. Full article

This paper proposes a single-stage AC-DC rectifier with power factor correction (PFC), high-frequency isolation and bidirectional power conversion capability for on-board battery charger (OBC) applications. The proposed converter is based on the interleaving technique and the Dual Active Bridge (DAB) operation, applying the phase-shift control to regulate the power flow. In addition to topology, this article presents a control strategy for reducing low-frequency power ripples transferred to the secondary side without any additional component and hence maintaining overall size and cost. The single-phase OBC can interchange active power with the grid to charge batteries while performing grid-to-vehicle (G2V) functionality or transferring energy back to the grid via vehicle-to-grid (V2G) mode. The theoretical analysis of the converter including modulation strategy and feedback control scheme are presented. The proposed topology and control strategy have been verified by experimental results of a 650 W SiC-based prototype. Full article

Permanent magnet machines (PMs) equipped with fractional slot concentrated windings (FSCWs) have been preferably proposed for electric vehicle (EV) applications. Moreover, integrated on-board battery chargers (OBCs), which employ the powertrain elements in the charging process, promote the zero-emission future envisaged for transportation through the transition to EVs. Based on the available literature, the employed machine, as well as the adopted winding configuration, highly affects the performance of the integrated OBC. However, the optimal design of the FSCW-based PM machine in the charging mode of operation has not been conceived thus far. In this paper, the design and multi-objective optimization of an asymmetrical 12-slot/10-pole integrated OBC based on the efficient magnetic equivalent circuit (MEC) approach are presented, shedding light on machine performance during charging mode. An ‘initial’ surface-mounted PM (SPM) machine is first designed based on the magnetic equivalent circuit (MEC) model. Afterwards, a multi-objective genetic algorithm is utilized to define the optimal machine parameters. Finally, the optimal machine is compared to the ‘initial’ design using finite element (FE) simulations in order to validate the proposed optimization approach and to highlight the performance superiority of the optimal machine over its initial counterpart. Full article

This paper presents control methods for performance improvement of an integrated on-board battery charger (OBC) in hybrid electric vehicles (HEVs). HEVs generally consist of an OBC and a starter generator system (SGS). Since these each have a power conversion device for independent operation, such as battery charging and starter generator driving for engine starting, it necessarily increases the number of components, weight, and volume of the HEV. In order to overcome these disadvantages, recent research concerning the integrated OBC has progressed. Although it demands installation of power relays and an additional circuit, the integrated OBC is effectively operated for battery charging and starter generator driving. This paper proposes not only a harmonic reduction method of grid current, but also a feed-forward control method for performance improvement of the integrated OBC in HEVs. The effectiveness of the proposed control methods is verified by simulation and experimental results. Full article

Recently, the integrated On-Board Charger (OBC) combining an OBC converter with a Low-Voltage DC/DC Converter (LDC) has been considered to reduce the size, weight and cost of DC-DC converters in the EV system. This paper proposes a new integrated OBC converter with V2G (Vehicle-to-Grid) and auxiliary battery charge functions. In the proposed integrated OBC converter, the OBC converter is composed of a bidirectional full-bridge converter with an active clamp circuit and a hybrid LDC converter with a Phase-Shift Full-Bridge (PSFB) converter and a forward converter. ZVS for all primary switches and nearly ZCS for the lagging switches can be achieved for all the operating conditions. In the secondary side of the proposed LDC converter, an additional circuit composed of a capacitor and two diodes is employed to clamp the oscillation voltage across rectifier diodes and to eliminate the circulating current. Since the output capacitor of the forward converter is connected in series with the output capacitor of the auxiliary battery charger, the energy from the propulsion battery can be delivered to the auxiliary battery during the freewheeling interval and it helps reduce the current ripple of the output inductor, leading to a smaller volume of the output inductor. A 1 kW prototype converter is implemented to verify the performance of the proposed topology. The maximum efficiency of the proposed converter achieved by the experiments is 96%. Full article
