Search Results (51)

Efficient simplification of 3D models is essential for mobile and other resource-constrained application scenarios. Industrial 3D assemblies, typically composed of numerous components and dense triangular meshes, often pose significant challenges in rendering and transmission due to their large scale and high complexity. The Quadric Error Metrics (QEM) algorithm offers a practical balance between simplification accuracy and computational efficiency. However, its application to large-scale industrial models remain limited by performance bottlenecks, especially when combined with curvature-based optimization techniques that improve fidelity at the cost of increased computation. Therefore, this paper presents a parallel implementation of the QEM algorithm and its curvature-optimized variant using the OpenMP framework. By identifying key bottlenecks in the serial workflow, this research parallelizes critical processes such as curvature estimation, error metric computation, and data structure manipulation. Experiments on large industrial assembly models at a simplification ratio of 0.3, 0.5, and 0.7 demonstrate that the proposed parallel algorithms achieve significant speedups, with a maximum observed speedup of 5.5×, while maintaining geometric quality and topological consistency. The proposed approach significantly improves model processing efficiency, particularly for medium- to large-scale industrial models, and provides a scalable and practical solution for real-time loading and interaction in engineering applications. Full article

Background: Congenital talipes equinovarus (clubfoot) affects 1–2 per 1000 newborns worldwide. The Ponseti method, based on staged manipulations and casting, is the gold standard for correction. However, the biomechanical processes underlying these corrections remain poorly understood, as infants rarely undergo imaging. Computational modeling may offer a non-invasive approach to studying correction pathways and exploring novel applications, such as customized casts. Methods: We developed a proof-of-concept framework using iterative finite element analysis (iFEA) to approximate the surface-level geometric corrections targeted in Ponseti treatment. A 3D surface model of a training clubfoot foot was scanned, meshed, and deformed stepwise under applied computational loads. The model was assumed to be homogeneous and hyperelastic, and correction was quantified using Cavus, Adductus, Varus, Equinus, and Derotation angles. We also introduced a secondary adult leg 3D surface model to assess whether model simplification influences correction outcomes, by comparing a homogeneous soft tissue model with a non-homogeneous model incorporating bone structure. Results: In the training model, iFEA generated progressive deformations consistent with Ponseti correction, with mean angular deviations of ±3.2°. In the adult leg model, homogeneous and non-homogeneous versions produced comparable correction geometries, differing by <2° in outcomes. The homogeneous model required less computation, supporting its use for feasibility testing. Applied loads were computational drivers, not physiological forces. Conclusions: This feasibility study shows that iFEA can reproduce surface-level geometric changes consistent with Ponseti correction, independent of model homogeneity. While not replicating clinical biomechanics, this framework lays the groundwork for future work that incorporates clinician-applied forces, pediatric tissue properties, and patient-specific geometries, with potential applications in customized 3D-printed casts. Full article

An efficient solution strategy based on fluid network modeling, computational fluid dynamics (CFD) and discrete particle modeling (DPM) is presented in order to predict and improve air quality, specifically regarding breathing aerosol concentration, in a person-occupied mechanically ventilated room. The efficiency of the proposed workflow is evaluated for the specific case of a lecture hall. It is found that the actual vent system is imbalanced and inefficient in managing the aerosol concentration within the room. Despite a high volumetric exchange rate, aerosol residence times and local aerosol concentrations remain high over an extended period of time, without additional efforts to alter air flow circulation throughout the room. The proposed strategy illustrates how such changes can be efficiently implemented in the basic 1D/3D co-simulation workflow. Analysis of the lecture hall and vent system shows that the execution time for the overall process workflow can be optimized by the following: (1) CAD geometry generation of the room via 3D laser scanning, (2) mesh generation based on the anticipated air discharge behavior from the vent system and (3) by employing HPC resources. Additional simplifications such as the decoupling of vent air flow and room aerodynamics, as observed for the investigated test case, one-way coupling between air flow and aerosol dispersion at low aerosol concentrations and the successive solution of flow field equations can further reduce the problem’s complexity and processing times. Full article

To enhance the intelligence and digital management level of radio telescopes and ensure the safe and stable operation of antennas, this paper proposes a real-time state evaluation method for the antenna structure of radio telescopes based on digital twin (DT) technology. Firstly, based on the five-dimensional model of DT, a digital twin system (DTs) framework for radio telescopes is designed. Secondly, the quadric error metrics (QEM) mesh-simplification algorithm and mesh-reconstruction technology are employed to obtain a lightweight twin model of the antenna. Furthermore, a random forest (RF) regression surrogate model is established using finite element point cloud data samples. The K-nearest neighbor (KNN) algorithm and radial basis function (RBF) interpolation algorithm are utilized to construct the virtual–physical mapping model of the antenna, enabling rapid prediction and evaluation of the antenna structure state. Finally, a DT for real-time antenna structure state evaluation is developed using the Unity3D engine, with an experimental prototype of a reflector antenna as the object. Experimental results show that the average prediction accuracy of the physical field surrogate model of the system is 0.98, and the average computation time is 0.4 s. The system meets the precision and computational efficiency requirements for the real-time and accurate evaluation of the antenna structure state. Full article

In advanced microelectronic packaging, high thermo-mechanical loads arise on the solder interconnects. Accurate and efficient modeling of the mechanical behavior is crucial in the design of the package, and the simulation results can provide a basis for estimations of the reliability of the assembly. However, the accuracy of the simulation results depends on the accuracy of the modeled geometry and the modeling simplifications and assumptions employed to achieve computational cost-efficient calculations. In this work, finite element analysis (FEA) of a Fan Out—Wafer Level Packaging (FO-WLP) layout was carried out considering the following variations: modeling domain (2-D and pseudo-3-D) was defined for creating the efficient calculation framework, where soldering material (SAC 305 and SACQ), incorporation of intermetallic compound (IMC), bond pad edge geometry (sharp and blunt) were modeled for cycles of thermal load. Stress and strain analysis was carried out to evaluate the solder behavior for the parameter variations. Furthermore, fatigue indicators were evaluated. An efficient planar simulation framework with 2-D and pseudo-3-D meshed geometries provides a quick estimate for the lower and upper bound for the strain, stress and strain energy-related parameters, respectively. This calculation framework can be employed for extensive parameter studies solved rapidly at low computational costs. Full article

The paper deals with the issue of determining the optimal setting of input variables in Ansys CFX for modeling pump flow in turbine operation (PAT). The pump model was created in Autodesk Inventor. The mesh for numerical simulations was created using Ansys Fluent Meshing, considering the mesh quality parameters’ skewness and aspect ratio. The Ansys CFX computational model was experimentally verified on an actual pump by measuring the performance parameters on a test circuit and using the PIV (particle image velocimetry) method. The research indicated that the most suitable setting for the model input variables was the inlet pressure and PAT flow rate combination. Another option was to adjust the pressure at the pump inlet and outlet. However, the calculation time in this case was up to 30% longer. The comparison of the model results with the experiment showed that the deviations in the numerical model performance values did not exceed 10% of the values measured on the test circuit. Only the calculated torque was 1.2 ± 0.13 Nm higher on average than the torque measured on the test circuit. This difference is most likely due to the simplification of the geometry of the computational mesh in order to reduce the computation time. Full article

The efficient extraction, storage, and visualization of geometric and semantic information is a key foundation for the operation of the building information modeling (BIM) platform. This study aims to develop a lightweight BIM system and optimize the system’s performance according to the specific characteristics of steel structures. This study proposes several novel techniques for extracting and decoupling the geometric and semantic information of components from industry foundation class (IFC) files. A redundancy removal approach combining the principal content analysis (PCA) algorithm and the Hausdorff-based comparison algorithm is proposed to identify standardized steel components, and a lightweight visualization method on Web3D for redundant instances is also presented. A loading mechanism of the level of detail (LOD) model based on a mesh simplification algorithm is presented to optimize the display efficiency. The developed system is evaluated by three steel structural models. Using the redundancy removal approach, the number of instances is decreased by 96.46% in less than 30 s and over 30 FPS (frame per second) is kept when rendering. Using the LOD loading mechanism, 95.38% of vertices and 98.46% of patches are eliminated under 50 mm precision. The experiment results indicate that users can quickly load large BIM models and fetch sufficient information from the website. Full article

In this paper, the notch effect in weldments has been investigated, and the optimal configuration of different types of welded joints has been analysed using the implicit gradient approach. By considering this implicit gradient method, it is possible to calculate the effective stress related to fatigue damage, with the effective stress being a continuous scalar function of the real stress tensor components, even in the presence of sharp edges. Hence, the search for the optimal configuration that maximises fatigue life can be tackled as the condition of minimum effective stress obtained by changing the weld shape and geometrical parameters. Both load-carrying cruciform joints and spot welds made of steel have been considered. The structural details have been studied by modelling actual shapes without any geometric simplification. Moreover, the same numerical procedure has been considered independently of the size, shape or load condition without imposing restrictive rules on the FE mesh. Full article

The emergence of electric vehicles has brought new issues such as the problem of rolling element bearings (REBs) operating at high speeds. Losses due to these components in mechanical transmissions are a key issue and must therefore be taken into account right from the design stage of these systems. Among these losses, the one induced by the motion of rolling elements, known as drag loss, becomes predominant in high-speed REBs. Although an experimental approach is still possible, it is difficult to isolate this loss in order to study it properly. A numerical approach based on CFD is therefore a possible way forward, even if other issues arise. The aim of this article is to study the ability of such an approach to correctly estimate the drag coefficient associated with the motion of rolling elements. The influence of the numerical domain extension, the mesh refinement, the simplification of the ring shape, and the presence of the cage on the values of the drag coefficient is presented. While it seems possible to compromise on the calculation domain and mesh size, it appears that the other parameters must be taken into account as much as possible to obtain realistic results. Full article

Additive manufacturing (AM) by using direct metal deposition (DMD) often causes erratic distortion patterns, especially on large parts. This study presents a systematic distortion analysis by employing numerical approaches using transient–thermal and structural simulations, experimental approaches using tomography, X-ray diffraction (XRD), and an analytical approach calculating the buckling distortion of a piston. The most essential geometrical features are thin walls situated between massive rings. An eigenvalue buckling analysis, a DMD process, and heat treatment simulation are presented. The eigenvalue buckling simulation shows that it is highly dependent on the mesh size. The computational effort of the DMD and heat treatment simulation was reduced through simplifications. Moreover, artificial imperfections were imposed in the heat treatment simulation, which moved the part into the buckling state inspired by the experiment. Although the numerical results of both simulations are successful, the eigenvalue and DMD simulation cannot be validated through tomography and XRD. This is because tomography is unable to measure small elastic strain fields, the simulated residual stresses were overestimated, and the part removal disturbed the residual stress equilibrium. Nevertheless, the heat treatment simulation can predict the distortion pattern caused by an inhomogeneous temperature field during ambient cooling in an oven. The massive piston skirt cools down and shrinks faster than the massive core. The reduced yield strength at elevated temperatures and critical buckling load leads to plastic deformation of the thin walls. Full article

Running a numerical model for a cracked arch dam that takes into account all the particularities of the materials and dam with a high level of detail has a great computational cost involved. For this reason, it is usual to simplify such a model in search of a simpler solution while preserving the characteristic of being representative, with all the particularities that the model of an arch dam has. A common simplification lies in not considering open transverse joints in the construction phase of a cracked dam. An aim of this study is to propose a methodology that combines open joints and cracking, something on which, to the authors’ knowledge, no studies have been published. An additional goal is a study of the need and adequacy of different approaches on performance (computational time) and its consequences for model accuracy. For this purpose, an accurate methodology for a stationary finite element method numerical simulation of deformations in cracked arch dams is presented. Using a tetrahedron mesh of a real dam, different simplifications commonly used in numerical models are compared. It is concluded that some of the standard simplifications produce a significant effect on the computation time and accuracy of the results. Full article

Existing contour-based building-reconstruction methods face the challenge of producing low-poly results. In this study, we introduce a novel iterative contour-based method to reconstruct low-poly meshes with only essential details from mesh soups. Our method focuses on two primary targets that determine the quality of the results: reduce the total number of contours, and generate compact surfaces between contours. Specifically, we implemented an iterative pipeline to gradually extract vital contours by loss and topological variance, and potential redundant contours will be removed in a post-processing procedure. Based on these vital contours, we extracted the planar primitives of buildings as references for contour refinement to obtain compact contours. The connection relationships between these contours are recovered for surface generation by a contour graph, which is constructed using multiple bipartite graphs. Then, a low-poly mesh can be generated from the contour graph using our contour-interpolation algorithm based on polyline splitting. The experiments demonstrated that our method produced satisfactory results and outperformed the previous methods. Full article

With the rapid advancement of computer graphics and three-dimensional modeling technology, the processing and optimization of three-dimensional (3D) models have become contentious research topics. In the context of mobile devices or web applications, situations may arise where it becomes necessary to load a 3D model with a substantial memory footprint in real-time or dynamically adjust the level of detail of a model based on the scene’s proximity. In such cases, it is imperative to optimize the original model to ensure smoothness and responsiveness. Due to the simplicity of their algorithm, quadric error metrics (QEMs) can deliver excellent results in simplifying 3D models while maintaining high efficiency. Therefore, QEM is widely employed in engineering applications within the realm of computer graphics development. Moreover, in the pursuit of enhanced quality and efficiency, numerous scholars have improved it based on QEM algorithms. This study aims to provide a systematic review and summary of the principles and applications of current research on QEM algorithms. First, we conducted a bibliometric analysis of 128 studies in related fields spanning from 1998 to 2022 using CiteSpace. This allowed us to sort QEM algorithms and gain insights into their development status and emerging trends. Second, we delve into the fundamental principles and optimizations of the QEM algorithms to provide a deeper understanding of their implementation process. Following that, we explore the advantages and limitations of the QEM algorithms in practical applications and analyze their potential in various domains, including virtual reality and game development. Finally, this study outlines future research directions, which encompass the development of more efficient error metric calculation methods, the exploration of adaptive simplification strategies, and the investigation of potential synergies with deep learning technologies. Current research primarily centers on enhancing QEM algorithms by incorporating additional geometric constraints to better differentiate between flat and irregular areas. This enables a more accurate determination of the areas that should be prioritized for folding. Nevertheless, it is important to note that these improvements may come at the cost of reduced computational efficiency. Therefore, future research directions could involve exploring parallel computing techniques and utilizing GPUs to enhance computational efficiency. Full article

Intussusceptive pillars, regarded as a hallmark of intussusceptive angiogenesis, have been described in developing vasculature of many organs and organisms. The aim of this study was to resolve the question about pillar formation and their further maturation employing zebrafish caudal vein plexus (CVP). The CVP development was monitored by in vivo confocal microscopy in high spatio-temporal resolution using the transgenic zebrafish model Fli1a:eGPF//Gata1:dsRed. We tracked back the formation of pillars (diameter ≤ 4 µm) and intercapillary meshes (diameter > 4 µm) and analysed their morphology and behaviour. Transluminal pillars in the CVP arose via a combination of sprouting, lumen expansion, and/or the creation of intraluminal folds, and those mechanisms were not associated directly with blood flow. The follow-up of pillars indicated that one-third of them disappeared between 28 and 48 h post fertilisation (hpf), and of the remaining ones, only 1/17 changed their cross-section area by >50%. The majority of the bigger meshes (39/62) increased their cross-section area by >50%. Plexus simplification and the establishment of hierarchy were dominated by the dynamics of intercapillary meshes, which formed mainly via sprouting angiogenesis. These meshes were observed to grow, reshape, and merge with each other. Our observations suggested an alternative view on intussusceptive angiogenesis in the CVP. Full article

Animation visualization is one of the primary methods for analyzing unsteady flow fields. In this paper, we addressed the issue of data visualization for large-scale unsteady flow fields using animation. Loading and rendering individual time steps sequentially can result in substantial frame delay, whereas loading and rendering all time steps simultaneously can result in excessive memory usage. To address these issues, the proposed method analyzes the variable description information in the data files to bypass redundant variables and read the flow field data as required. Second, a hash table is constructed to derive the two-dimensional surface mesh of the flow field and complex mesh cells are simplified into simple linear cells to reduce the mesh’s complexity. This paper presents a method for reducing the memory usage of complex data sets by more than 90%, compared with the ParaView data reading method. The proposed method is tested on four sets of unstructured unsteady flow field data with different data structures. The animation visualization method based on simplified data can achieve an average frame rate of less than 100ms and supports real-time user interaction on personal computers. It extends the ability of personal computers to analyze large-scale unstructured unsteady flow fields. Full article
