This work presents a numerical investigation of a direct oil cooling system for Axial Flux Permanent Magnet (AFPM) machines. Building upon the authors’ previous study, which established the fundamental fluid dynamic mechanisms governing oil jet impingement on curved coil surfaces, the present research extends the analysis by performing a systematic parametric optimization of nozzle diameter and axial position. A validated CFD model, benchmarked against experimental data from the literature, is employed to quantify the influence of jet momentum, stagnation pressure, and flow attachment on the resulting thermal performance. Nine configurations are simulated at constant coolant mass flow rate, revealing that the nozzle diameter is the dominant parameter: smaller diameters generate higher jet velocities, stronger stagnation regions, and larger jet-induced forces, leading to significantly enhanced heat transfer coefficients and Nusselt numbers. Nozzle height plays a secondary yet relevant role, as higher positions promote a more coherent jet core and improve impingement quality. Among the nine simulated cases, the configuration with D = 3 mm and L = 14 mm achieves the lowest hotspot temperature and the most efficient energetic behavior within the simulated set, with only a modest increase in pumping power. The results confirm that direct oil impingement is highly sensitive to jet momentum and angle of attack and demonstrate that optimized nozzle design can substantially improve the thermal management of high power density AFPM machines. This extended analysis provides quantitative references for nozzle sizing and placement within the simulated operating conditions with enhanced cooling efficiency. Full article

A real downburst event that occurred in the city of Genoa, Italy, on 14 August 2018, is simulated using the full-cloud model CM1. The initiation of the thunderstorm cell is triggered through the warm bubble technique, which allows simulating the whole development of the cumulonimbus cloud in a spontaneous way. Following the release of initial instability into the lower troposphere, a sustained updraft generates an almost 13-km tall cloud. This, in turn, produces a strong downdraft that accelerates to around −20 m/s within the lowest 3 km near the ground. It is shown that, despite the downdraft’s shape is almost linear during the mature stage rather than circular, the downburst maintains to a large extent a cylindrical axisymmetry while spreading out, similar to impinging jet (IJ) downburst-like models. Like IJ models, the downburst develops multiple vortex rings at the ground, whose physical origin is mostly related to subsequent downdraft discharges. Thunderstorm outflows are validated using LiDAR wind measurements, and the simulated wind fields are made available to the scientific community as an open-access dataset in a public repository. Full article

The accessory gearbox of an aero-engine operates under high-speed and heavy-load conditions, where insufficient lubrication may lead to oil-film failure, increased frictional losses, and reduced transmission reliability. Therefore, understanding oil-jet injection and tooth surface oil-film spreading characteristics is essential for improving lubrication performance. In this study, a three-dimensional geometric model incorporating the meshing region and oil nozzles was established based on a typical accessory gear pair. The model employs the VOF multiphase flow approach and the standard k-ε turbulence model, coupled with dynamic mesh techniques to accurately capture the transient interactions between gear rotation and oil–air two-phase flow. Numerical simulations reveal the dynamic evolution of oil injection, impingement on the tooth surface, oil-film spreading, and transport into the meshing zone, while the effects of injection velocity and nozzle length on lubrication performance are quantitatively analyzed. Results indicate that an injection velocity of 45–55 m/s yields optimal oil-film coverage and uniformity, and a nozzle length of h = 30 mm minimizes jet energy decay and airflow interference, achieving uniform oil filling in the meshing zone. The optimal lubrication performance for accessory gears is obtained at an injection velocity of 45–55 m/s and a nozzle length of 30 mm. This study provides a reference for the design optimization of accessory gear lubrication systems. Full article

Efficient thermal management of high-power electronic components has become a critical engineering challenge as power densities grow and device geometries shrink. Conventional solutions based on passive heatsinks and mechanical fans are increasingly inadequate in applications where noise, reliability, and compactness are paramount. This paper presents a comprehensive Computational Fluid Dynamics (CFD) investigation of ionic wind—an Electro Hydro Dynamic (EHD) phenomenon in which a corona discharge between asymmetric electrodes generates a directed airflow without any moving part—as an energy-efficient alternative for cooling high-power electronics. A fully coupled 2D Multiphysics model is developed in COMSOL Multiphysics, integrating electrostatics, ion transport (Nernst–Planck), Navier–Stokes fluid dynamics, and convective heat transfer. The 2D formulation, while computationally efficient and consistent with prior EHD modeling studies, neglects lateral jet spreading inherent to a real three-dimensional needle configuration and is therefore expected to overestimate peak impingement velocities; quantitative comparisons with experimental temperatures are interpreted with this limitation in mind. The study focuses on a needle–collector configuration applied to a heated aluminum plate representative of a high-power electronic component such as a Light Emitting Diode (LED), a power transistor, or a microprocessor die. Simulation results are indirectly validated against experimental data obtained by Schlieren optics on a high-power (Chip-On-Board) COB LED system. The ionic wind reduces the maximum surface temperature by 8.1 K and substantially attenuates the central hotspot, redistributing heat laterally. A systematic parametric study reveals that applied voltage and needle height above the heat source are the dominant design parameters, while an energy balance shows that the EHD jet directly evacuates approximately 1.8% of the generated heat—acting primarily as a surface convection enhancer rather than a bulk heat extractor. These findings provide quantitative design guidelines applicable to any power electronic component cooled by an EHD system. Full article

The cavitation jet is regarded as a promising hydraulic rock-breaking technique for drilling and exploiting deep-sea natural gas hydrate (NGH). However, the detailed mechanisms of erosion pit formation in hydrate-bearing sediments (HBSs) under cavitation jet erosion remain unclear, and effective simulation methods are still limited. This study first conducts jet erosion experiments on HBSs using a convergent–divergent cavitation jet nozzle (CDCJ) and a conical jet (CJ) nozzle to evaluate the erosion performance of the CDCJ. The CDCJ is then applied to erode HBS specimens under different flow rates, erosion times, and stand-off distances, with the geometric characteristics of the erosion pits recorded. Subsequently, a coupled CFD-DEM framework is developed to further investigate the erosion process and mechanisms. Based on this model, the erosion characteristics of the cavitation jet at different stages and under varying jet parameters are analyzed and validated. The results show that the CDCJ exhibits a significantly stronger erosion capacity than the CJ, with the pit volume and depth reaching 1.36 and 1.19 times those produced by the CJ, respectively. The hole-forming process induced by the cavitation jet can be divided into three stages: the V-shaped hole-forming stage, the cylindrical hole-forming stage, and the spindle-shaped hole-forming stage. In the V-shaped hole-forming stage, jet impingement and the penetrating erosion of cavitation clouds dominate pit development. As erosion progresses, the axial impingement gradually weakens, whereas radial cutting decays more slowly. Meanwhile, vortices inside the pit trap cavitation clouds and promote further hole enlargement. Both the experiments and simulations indicate that higher flow rates produce larger and deeper pits, and a standoff distance of 5 mm is optimal for cavitation erosion. These findings clarify the hole-forming mechanism and flow-field evolution during the cavitation erosion of HBSs, and provide guidance for the application of the cavitation jet in NGH drilling and exploitation. Full article

This study investigates heat transfer enhancement in the cooling channels of gas turbine blade turbulators using modified transverse baffles with isosceles triangular sawtooth perforations. The proposed baffle design aims to improve convective heat transfer by promoting flow mixing and disrupting the thermal boundary layer. Experiments were conducted in a rectangular channel with an aspect ratio of 3.75 under constant heat flux conditions using air (Pr = 0.7) as the working fluid. The effects of Reynolds number (Re = 6000–24,000), sawtooth width ratio (a/W = 0.0, 0.0625, 0.125, 0.25, and 0.5), and sawtooth height ratio (b/e = 0.0, 0.25, 0.5, 0.75, and 1.0) were systematically investigated. The blockage ratio (e/H) and pitch ratio (P/H) were maintained at 0.3 and 1.5, respectively. Heat transfer characteristics were evaluated using the thermochromic liquid crystal (TLC) technique, while thermal–hydraulic performance was assessed in terms of the Nusselt number (Nu), friction factor (f), and thermal performance factor (TPF). The results demonstrate that introducing sawtooth perforations significantly enhances heat transfer compared with a smooth channel, yielding Nusselt number ratios (Nu/Nu_s) between 1.6 and 2.6. The highest heat transfer enhancement was achieved at a/W = 0.0625 and b/e = 0.25, where the relatively small sawtooth openings generated stronger jet impingement, enhanced flow mixing, and more effective disruption of the thermal boundary layer. However, these geometric modifications also increased the pressure loss due to intensified flow blockage and recirculation, resulting in friction factor ratios (f/f_s) ranging from 8.9 to 14.9. The maximum pressure-drop penalty occurred at b/e = 0.25 because the smaller openings produced stronger turbulence and increased flow resistance. Despite the increased friction loss, the optimum configuration (a/W = 0.0625 and b/e = 0.25) achieved the highest thermal performance factor of 1.2 at Re = 6000. Full article

Nanoemulsion (NEM) is an effective adjuvant and delivery system for vaccines and nucleic acids, capable of inducing immune responses against diverse pathogens. Background/Objectives: Conventional NEM manufacture uses multi-step operations, typically high-shear homogenization and then microfluidization (HSHM), thereby increasing process complexity and contamination risk. As water-rich colloidal dispersions, NEM is prone to microbial proliferation and droplet coalescence; freezing further disrupts microstructure, causing phase fusion and separation, so NEM adjuvants are often stored separately from antigens in multi-vial formats. Lyophilization could reduce cold-chain dependence and enable single-vial products, but there is no systematic study on lyoprotectants comparation and process optimization of lyophilized NEM. Methods: An impingement jet mixing (IJM) process was evaluated as a simplified, scalable route for NEM production. Key IJM parameters, including flow ratio, total flow rate, preparation temperature, microchannel type, and shear mode—were examined to match attributes of conventional HSHM. Lyophilized and reconstituted NEM were characterized by dynamic light scattering, scanning electron microscopy, transmission electron microscopy, differential scanning calorimetry and/or in vitro potency to inform lyoprotectant selection, and Taguchi Design of Experiment (DOE) methodology guided lyophilization processes. Results: IJM yielded NEM with droplet size, polydispersity index (PDI) and morphology comparable to HSHM, with higher throughput and fewer unit operations. Optimized lyophilization technique with designed lyoprotectant and process formed closed structures to prevent the easy-to-flow monolayer of the emulsion from fusing, producing robust and stable NEM. Conclusions: Coupling IJM with targeted lyophilization establishes a scalable, lower-risk manufacturing paradigm for NEM that preserves critical quality attributes, reduces cold-chain reliance and enables single-vial adjuvanted vaccine formats with tangible industrial and clinical benefits. Full article

Cavitating jet impingement is a key phenomenon in marine and ocean engineering that is responsible for cavitation-induced material erosion while also being harnessed for surface treatment applications. However, decoupling these concurrent effects is challenging since hydrodynamic jet pressure, microjet impacts, and shockwave emissions often coincide in space and time, making it difficult to isolate their individual contributions. To address this challenge, this review surveys recent advances in measurement techniques designed to decouple these overlapping effects. It highlights multi-source synchronous measurement methods, such as high-speed optical imaging and broadband piezoelectric pressure sensing combined with advanced signal and image processing, to capture mechanism-specific signatures. The review treats mechanism decoupling as a linked task of mechanism identification, mechanism attribution, and contribution quantification and synthesizes the literature under distinct criteria, such as energy, peak pressure, and damage dominance. It shows that synchronized multi-source diagnostics improve attribution reliability but that true quantitative decoupling remains limited by configuration dependence, inconsistent normalization, and a lack of benchmark evaluation criteria. Full article

To improve the efficiency of jet-based fire suppression for high-rise building façade fires, this study experimentally investigates the liquid film formation characteristics and fire suppression behavior of water jets impinging on insulated vertical surfaces. The effects of operating pressure (flow rate), nozzle-to-wall distance, and jet inclination angle on liquid film spreading morphology, wetted area, and effective water supply rate are systematically analyzed. The results show that increasing the flow rate significantly enlarges the wetted area, while reducing the effective water supply rate. As the nozzle-to-wall distance increases, the liquid film gradually develops a “top-wide and bottom-narrow” morphology. Although increasing the jet inclination angle decreases the wetted area, it enhances the continuity and stability of wall-adhering liquid film flow, thereby improving cooling efficiency near the flame root region. During the fire suppression experiments, low-flow-rate jets exhibit insufficient suppression stability, whereas high-flow-rate horizontal jets are capable of suppressing the flame to a residual burning state near the bottom of the façade. Further increasing the jet inclination angle enables complete flame extinguishment. This study reveals the relationship between jet parameters, liquid film behavior, and fire suppression performance, providing experimental evidence for the optimization of jet-based façade fire suppression strategies. Full article

Exhaust piping in diesel engines is subject to severe thermal stress arising from high-temperature, high-pressure gas flows, and spray cooling with atomizing nozzles has become a widely adopted method to safeguard structural reliability. However, at present, the understanding of the spray fragmentation mechanism of two-phase flow under low inlet pressure is still not comprehensive. This study establishes a three-dimensional model of a gas–liquid impinging-jet nozzle and applies a coupled Volume-of-Fluid to Discrete-Phase-Model (VOF–DPM) approach to resolve the liquid breakup process in detail. High-speed imaging experiments were carried out to validate the numerical results. Orthogonal tests were conducted at five pressure levels for both gas and water—0.28, 0.24, 0.20, 0.16, and 0.12 MPa—producing 25 data pairs of spray cone angle and Sauter Mean Diameter (SMD). Within the 0–0.3 MPa air inlet pressure range explored here, raising the pressure consistently reduced the SMD and widened the cone angle, although both trends weakened as the pressure increased. Water inlet pressure exhibited a nonlinear influence, with local extrema appearing in the higher-pressure region. The overall SMD reached a minimum of 34.12 μm and a maximum of 149.04 μm. Using these 25 data points, a genetic algorithm was employed to optimize the pressure ratio under the constraint of total hydraulic power, yielding optimization strategies for different power budgets. An additional outcome of the simulation was the identification of a structural weakness: by reshaping the original flat impingement surface into a full conical surface, atomization quality improved by 29.36% under identical boundary conditions. These findings clarify the atomization mechanism of gas–liquid impinging jets under low inlet pressure and offer practical guidance for nozzle optimization. Full article

This study investigates the coupling between flow dynamics, acoustic response, and convective heat transfer in a rectangular impinging jet striking on a heated slotted plate at two closely spaced Reynolds numbers (Re = 3550 and Re = 3750). Velocity fields were obtained using Particle Image Velocimetry (PIV), and coherent structures were analyzed using Proper Orthogonal Decomposition (POD) while acoustic measurements were used to characterize the tonal behavior. Infrared thermography was employed to determine local and mean Stanton numbers. The mean Stanton number increased by 6.6% when the Reynolds number increased from Re = 3550 to Re = 3750, while the sound pressure level decreased from 78 dB to 71 dB. At Re = 3550, the acoustic spectrum exhibited multi-tone behavior associated with distributed modal energy. In contrast, at Re = 3750, a single dominant frequency governed the flow dynamics. The energy of the first POD mode nearly doubled when passing from Re = 3550 to Re = 3750. The cross-correlation coefficients between the first POD mode and the acoustic field increase from 0.76 to 0.93 when changing from Re = 3550 to Re = 3750. These findings show that the dominant vortex mode which contains nearly 20% of the fluctuating energy (for Re = 3750), significant influences the energy transfer from the dynamic field to the acoustic field resulting in a strong noise reduction. Simultaneously, convective heat transfer increases, highlighting the key role of coherent flow organization on both acoustic and thermal behavior of the system. Full article

This study examines the effects of jet Reynolds number (Re) and jet hole diameter (d) on flow and heat transfer in the leading-edge full-impingement cooling channel of a gas turbine nozzle guide vanes (NGV). Experiments via transient liquid crystal and numerical simulations were conducted. Results reveal that the peak Nusselt number (Nu) initially increases and then reaches a fixed value from root to tip in the spanwise direction. The area-averaged Nu presents the descending trend of the shower-head surface, pressure surface, and suction surface. In addition, the bleeding from film holes causes significant local flow acceleration and Turbulence Kinetic Energy (TKE) enhancement of 10.69%, resulting in local heat transfer elevation. The heat transfer enhancement region on both pressure and suction surfaces is inclined towards the shower-head at a 5% span region. Increasing the jet hole diameter (d) results in a decrease in both averaged Nu and TKE on the target surface. Simultaneously, the Nu gradient increases. When d = 1.6 mm, there is a recirculation zone near the hub on the suction surface and a strong crossflow near the hub on the pressure surface. The jet flow on the target surface is bending towards the shower-head. When d = 0.8 mm, the overall heat transfer is highest. However, considering heat transfer uniformity, a jet hole diameter of d = 1.2 mm offers better application. Full article

Building upon our previous aerodynamic characterizations of skewed jets, this study extends the investigation to systematically evaluate their thermal performance. Turbulent air jets are produced by unilaterally supplying coolant and forcing it through a series of concave perforated blockages having varying relative inner diameters (D_in/D_j = 3.0, 4.0 and 5.0) or relative thicknesses (t/D_j = 0.5, 2.0, 4.0, 6.0 and 8.0), with the jet diameter and Reynolds number fixed at D_j = 21 mm and Re_j = 20,000, respectively. The results demonstrate that the skewed jets exhibit pronounced asymmetric velocity profiles in both the x-z and y-z planes. Unlike the Gaussian distributions characteristic of conventional axisymmetric jets, these profiles manifest as distinctly skewed or saddle-shaped topologies. This topological distortion is exacerbated by reducing either D_in/D_j or t/D_j, albeit through fundamentally different mechanisms: the former only leads to jet deflection from the geometric axis, with the deflection angle increasing non-linearly from α = 4°, 5° to 12°; whilst the latter induces asymmetric internal flow development and exit momentum redistribution. The thermal performance of these jets on an iso-flux target flat plate, characterized by Nusselt number distributions at different jet-to-target spacings (H/D_j = 0 to 8.0), is shown to significantly differ from conventional axisymmetric jets. Full article

Liquid rocket engine injectors play a fundamental role in determining combustion efficiency, stability, and overall propulsion performance. This review paper provides a comprehensive analysis of liquid-injector technologies used in space propulsion systems, with emphasis on their historical evolution, atomization mechanisms, and cross-domain insights from aviation fuel injection systems. The study begins by examining the fundamental processes governing liquid jet breakup, including primary and secondary atomization, ligament formation, and droplet generation, together with the non-dimensional parameters that control these phenomena. The historical development of injector architectures -from early orifice-based and impinging designs to modern coaxial and pintle configurations—is then discussed in relation to increasing performance requirements and combustion stability challenges. A comparative perspective with aviation gas turbine injectors is introduced to highlight similarities in atomization physics and differences in operating conditions and design constraints. The paper also reviews experimental and numerical approaches used to characterize spray formation and injector performance. The results indicate that injector geometry and flow conditions strongly influence mixing efficiency, droplet size distribution, and combustion–acoustic coupling mechanisms. The study concludes that integrating cross-domain knowledge and modern design techniques is essential for advancing injector performance in next-generation propulsion systems. Full article

A coupled modeling framework is developed to predict coating thickness after air knife wiping in hot-dip galvanizing. A 3D large eddy simulation (LES) using the WALE sub-grid scale (SGS) model is performed to resolve the jet impingement on the moving strip. Time-averaged wall static pressure $p_{\omega }\left(y\right)$ and wall shear stress ${\tau }_{\omega }\left(y\right)$ along the strip direction are extracted and used as driving inputs for a thin film model. Starting from the continuity and momentum equations, a lubrication-type formulation is derived, leading to a local cubic equation for film thickness $h\left(y\right)$ that accounts for both pressure gradient and gravity. A coupling workflow is established to preprocess the LES wall signals and compute the final coating thickness $h_{final}$. Parametric sweeps of inlet total pressure $P_0$ and the knife-to-strip distance $H$ are employed to construct operating window maps. The predicted trends show that increasing $P_0$ or decreasing $H$ intensifies wall loading and reduces $h_{final}$, while the operating window boundary is governed by the balance between the gas-induced shears. Representative results, including peak wall loading and thickness ranges, are reported for industrially relevant operating conditions. Full article
