This article introduces the current status of the 0.18-micron CMOS MEMS foundry service platform provided by the Taiwan Semiconductor Research Institute (TSRI), extensively covering the CMOS MEMS components that it has supported in development and fabrication. It also attempts to expand the foundry service scope to the broader categories of capacitive sensors and electrostatic actuators. On the one hand, for fabless MEMS component designers, TSRI currently directly allows the design of two types of components: flow sensors with uniformly perforated membranes and actuators with comb-shaped interdigital electrodes. This service also includes tape-out and wire bonding packaging procedures, following procedures similar to those used by general IC designers. On the other hand, this article specifically presents a clear and feasible approach for MEMS designers equipped with simple wet-etching facilities and a clear and feasible approach to develop further CMOS MEMS components such as capacitive pressure sensors, accelerometers, micro mirrors, and scratch drive actuators with minimal post-processing and chip packaging steps. This work provides a practical CMOS-MEMS design and post-processing guideline for extending the current TSRI foundry platform toward capacitive sensing and electrostatic actuation applications with minimal additional fabrication complexity. Full article

Indispensable roles in personalized health monitoring and human–machine interaction are played by flexible humidity sensors. However, high costs and complex vacuum processes are often involved in current fabrication methods, thereby restricting their broader applications. In this work, a high-performance flexible capacitive humidity sensor is presented, wherein a ternary composite of graphene oxide, PEDOT:PSS, and MXene (GO-PEDOT:PSS-MXene) is loaded onto a laser-induced graphene (LIG) interdigitated electrode. A pronounced synergistic effect among the three components is systematically exploited by this multidimensional architecture to significantly optimize the overall sensing performance. Within a relative humidity range extending from 11% to 97%, a remarkable measurement sensitivity of 18,643.02 μF/%RH is recorded. Furthermore, a characteristic negative capacitive response is consistently induced by moisture-driven microstructural swelling, by which the internal interlayer spacing is increased. The continuous monitoring of human respiratory rhythms and precise non-contact spatial sensing is successfully enabled by rapid response and recovery times of 31.7 s and 11.2 s, respectively. Uniquely, a vacuum-free, synergistic multidimensional architecture is successfully utilized to achieve an ultrahigh sensitivity. Practically, a highly scalable and low-cost paradigm is established by this research for the mass deployment of future wearable electronic systems across diverse monitoring scenarios. Full article

Polymer–liquid crystal (polymer–LC) composites enable electrically tunable optical modulation through the coupling of molecular anisotropy and polymer-induced stabilization. However, most dual-cell LC architectures that independently control absorption and scattering rely on four substrates and multiple independently driven electrode layers, resulting in increased fabrication complexity. In this work, a dual-cell polymer–LC device employing a simplified asymmetric electrode architecture is demonstrated to achieve independent control of absorption and scattering within a three-substrate configuration. The device integrates a dye-doped vertically aligned super-twisted nematic (DDVSTN) cell for absorption-based modulation and a reverse-mode polymer-stabilized cholesteric texture (PSCT) cell for electrically induced scattering. The PSCT layer is driven by interdigitated electrodes on the bottom substrate, while the DDVSTN layer is driven by vertical electric fields, preserving electrical decoupling between the two cells. Four distinct optical states—clear, tinted, private, and tinted-private—are achieved through selective voltage addressing. Spectral measurements confirm stable four-state optical modulation with transmittance varying from approximately 60% in the clear state to about 13% in the tinted-private state. The proposed architecture reduces electrode-layer complexity while maintaining independent optical control, providing a fabrication-efficient platform for smart window systems and polymer–LC photonic devices. Full article

With parylene coatings, conventional layer thickness measurement methods such as gravimetry, reflectometry, and cross-sectional microscopy are performed post-process and do not allow real-time monitoring or control. This paper presents a novel in situ measurement method based on the capacitance change in interdigitated copper electrodes fabricated on a printed circuit board (PCB). As parylene deposits on this sensor, the effective permittivity above the electrodes increases from ${ϵ}_{\mathrm{r}}\approx 1$ (vacuum) to ${ϵ}_{\mathrm{r}}=2.1\text{–}3.2$ (parylene), causing a measurable capacitance change. Finite element simulations were performed to model the relationship between layer thickness and sensor capacitance. Experimental validation with parylene C and F-VT4 demonstrated good agreement between simulation and measurement. Four consecutive parylene C runs with 60 g raw material showed reproducible capacitance increases of 49–53 pF, corresponding to layer thicknesses of 20–25 µm, verified by cross-sectional microscopy. Two coating runs were performed with parylene F-VT4 with target layer thicknesses of 2.5 µm and 5 µm. They show particularly good agreement with the simulation. The proposed method enables real-time process monitoring and provides a foundation for closed-loop control of parylene CVD processes. Full article

To realize the real-time structural health and operational safety monitoring of military and industrial devices, such as hypersonic vehicles, aero-engine blades, and thermal power plant boilers, at operating temperatures up to and beyond 1400 °C, this study presents a miniaturised, integrated, high-thermal-stability wireless sensor device. This study investigated the influence of temperature on the interdigital electrodes (IDEs) of surface acoustic wave (SAW) temperature sensors for three configurations: bare electrode, single-layer protective film, and multilayer composite film. While the exposed electrode exhibited thermal stability at 1000 °C, it underwent structural failure at 1250 °C. To achieve health monitoring at temperatures exceeding 1400 °C, an Al₂O₃/AlN/Al₂O₃ multilayer protective architecture was developed. The device demonstrated functionality up to 1400 °C with a temperature coefficient of frequency (TCF) of −40.03 ppm/°C, yielding a sensitivity of 12.0 kHz/°C at a center frequency of ~300 MHz. The electrode protection structure elevated the maximum operating temperature. A hybrid heterogeneous integration of high-temperature co-fired ceramic (HTCC) inverted-F antenna and a Langasite (LGS) SAW device with a multilayer composite film was realised. The wireless device maintained functionality from room temperature to 1400 °C and withstood 1400 °C for 2 h, exhibiting a maximum repeatability error of 12.67% (corresponding to a temperature measurement error of ~177.4 °C at 1400 °C). This integrated design enables the miniaturization of high-temperature wireless sensors, making them suitable for harsh environments. Full article

This study develops high-performance ammonia sensors based on composites of metal-organic frameworks (MOF-808 and MOF-818) with reduced graphene oxide (rGO). Two sensor architectures were fabricated: interdigital electrodes and silicon micropillar arrays. The MOF-808/rGO composite demonstrated superior sensing performance for 40 ppm NH₃ at room temperature, with faster response kinetics and higher sensitivity compared to pristine rGO and MOF-818/rGO. Silicon micropillar array sensors showed enhanced performance through optimized periodic arrangements, while oxygen plasma surface modification improved both sensor types. Comprehensive testing confirmed that the MOF-808/rGO sensor maintains reliable NH₃ detection at concentrations as low as 5 ppm under high humidity conditions, exhibiting excellent stability and selectivity. These findings provide valuable insights for developing advanced gas sensors for environmental monitoring applications. Full article

Soil moisture monitoring is critical to agricultural production and water resource management, yet existing sensors often exhibit limitations in accuracy, cost-effectiveness, and long-term stability. This study aimed to develop a high-performance capacitive soil moisture sensor to address these issues. We selected eco-friendly lead-free K₂CuBr₃ as the hygroscopic material and optimized the interdigital electrode (IE) structure via theoretical analysis and finite element simulation. The sensors were fabricated using micro-electro-mechanical system (MEMS) technology, and their performance was systematically evaluated with real soil samples. The results demonstrated that K₂CuBr₃ substantially enhanced the sensor sensitivity. The optimal sensor exhibited a measurement error of approximately 5% over the soil moisture range of 0–42.5%, a relative standard deviation (RSD) of less than 2%, and good stability. This low-cost, lead-free MEMS capacitive sensor, based on K₂CuBr₃, offers high accuracy and excellent stability. It resolves key drawbacks of traditional sensors and offers a reliable solution for in situ real-time soil moisture monitoring, with broad prospects in smart agriculture. Full article

We report the fabrication and electrochemical characterization of TiO₂-based impedimetric sensors for the analysis of artificial sweat compositions. Two-electrode topologies were patterned on indium tin oxide (ITO) substrates: an interdigitated electrode (IDE) configuration and a Hilbert fractal electrode (HFE) geometry. TiO₂ thin films with thickness up to 350 nm were deposited by dip-coating and evaluated as photoactive sensing layers. The impedimetric response of the sensors was investigated by electrochemical impedance spectroscopy in artificial sweat with composition varied in terms of ionic content (0–100 mM Na⁺) and organic content (2.5–30 mM lactic acid and 5–50 mM urea). Regardless of TiO₂ thickness, the high-frequency response is predominantly governed by electrode topology, with the HFE design exhibiting up to 2.5-fold higher modulation compared to the IDE configuration. Under UV illumination, a low-frequency, photo-assisted response emerges, influenced by the TiO₂ layer thickness and primarily sensitive to the organic components of the solution, particularly lactic acid. These results suggest that frequency-resolved impedance measurements in TiO₂|ITO structures may enable partial differentiation between ionic conductivity and organic contributions in sweat, providing a promising basis for multi-parameter sweat analysis. Full article

Methanol (MeOH) is widely used in industry and is highly toxic when ingested. In this work, a new micro-conductometric transducer is functionalized with magnetic Fe₃O₄ nanoparticles capped with Artemisia Herba Alba (AHA) extract. The resulting AHA-Fe₃O₄ nanoparticles, crystallized in the cubic spinel phase, exhibit an average crystallite size of 6 nm. These nanoparticles were homogeneously dispersed within an electrodeposited chitosan film on interdigitated electrodes for conductometric measurements. The gas-sensing behavior of the films was evaluated at room temperature toward methanol, ethanol, and acetone vapors. For methanol, the sensor shows response times (t_Res) ranging from 9 to 12 s depending on the analyte concentration, with a detection limit of 600 ppm in the gas phase. The methanol sensor presents a sensitivity 30 times lower for acetone and 3.7 times lower for ethanol. The sensor exhibited stable detection sensitivity over two months, under intermittent storage at 4 °C. Methanol was detected in the headspace of commercial product samples, in good agreement with the producer’s value. Full article

Measuring soil moisture is crucial for optimizing agricultural irrigation, but also, from an energy efficiency standpoint, for the proper design of very-low-enthalpy geothermal energy (VLEGE) facilities. VLEGE represents a renewable energy resource with great potential for residential and industrial applications, as it can provide heating and cooling with high energy efficiency and minimal environmental impact. Soil moisture plays a decisive role in the thermal performance of VLEGE facilities, where small variations in water content can significantly alter the thermal conductivity of the soil and, consequently, the efficiency of their horizontal heat exchangers. This paper presents a low-cost capacitive soil moisture sensor featuring optimized interdigitated electrodes and a controlled dielectric coating that ensures mechanical and electrical stability in subsurface environments. The novelty of this work lies in the validated integration of optimized IDE design, dielectric protection, embedded capacitance acquisition, and gravimetric calibration into a low-cost soil water content measurement device for environmental, agricultural, and VLEGE applications. The developed system converts capacitance variations into direct estimates of soil water content through an integrated microcontroller-based signal-conditioning stage. The developed device is robust, reliable, and readily reproducible. Furthermore, given its low cost (around €50 if manufactured manually; mass-produced it would be much cheaper) and its excellent sensitivity and precision, it is ideal for setting up continuous monitoring networks, even for domestic applications, both in VLEGE installations and in other application domains, such as agriculture and environmental monitoring, where soil moisture measurement is a crucial parameter. This work contributes to the development of more efficient and accessible solutions for harnessing geothermal energy, particularly in installations where dynamic tracking of soil moisture is essential to ensure stable long-term performance. Full article

This paper presents a yarn tension sensor based on Surface Acoustic Waves (SAW). To enhance the detection accuracy of the sensor, an improved beam structure is designed for tension measurement, along with intelligent algorithms for temperature compensation. Firstly, regarding the sensor structure, a simply supported beam with a hyperbolic surface is designed to achieve stress concentration by reducing the section modulus at the beam’s midpoint. Secondly, by incorporating an unbalanced split-electrode Interdigital Transducer (IDT) design, the sensor effectively suppresses signal sidelobe interference and significantly improves the structure’s tension sensitivity. Finally, in terms of signal processing, to eliminate the influence of environmental temperature fluctuations on measurements, a temperature-compensation algorithm based on Bayesian Optimization Least Squares Support Vector Machine (BO-LSSVM) with Gaussian Process regression is proposed. Experimental results show that the tension sensitivity of the improved structure was 8.2% higher than that of the doubly clamped beam and 12.7% higher than that of the cantilever beam. For temperature compensation, the BO-LSSVM model reduced the Mean Relative Error (MRE) by 5.67 percentage points relative to raw data and by 2.04 percentage points relative to the fixed-parameter LSSVM model, lowering the temperature sensitivity coefficient from 4.09 $(\times {10}^{-3}/°\mathrm{C})$ to 0.41 $({10}^{-3}/°\mathrm{C})$. Full article

Droplet microfluidics enables precise manipulation of picoliter-to-nanoliter-scale droplets and supports key operations such as merging, splitting, sorting, and trapping, facilitating controlled handling of minute fluid volumes. These capabilities have significantly advanced high-throughput drug discovery, single-cell analysis, molecular diagnostics, and synthetic biology. Among these operations, droplet splitting is particularly important for multi-step biochemical assays and parallel processing. Splitting strategies can be broadly categorized as passive, relying on channel geometry or microstructures, or active, employing external stimuli such as thermal, magnetic, acoustic, or electric fields. Electric-field-based methods are especially attractive due to their rapid response and tunability; however, many reported systems require relatively high operating voltages. Here, we present a low-voltage microfluidic platform that integrates tilted interdigitated electrodes (IDEs) with an asymmetric Y-junction to enable electrically tunable droplet splitting and sorting within a single device architecture. Two independently addressable tilted IDE arrays generate localized electric-field gradients that induce dielectrophoretic droplet deflection at moderate voltages. By adjusting the applied voltage amplitude and selectively activating the electrode arrays, droplets can be dynamically routed into designated outlets or deterministically split in real time, providing adaptable electrohydrodynamic control with minimal structural complexity. Full article

This work presents the design and simulation of DEP electrodes with an interdigitated electrode (IDE) pattern for the alignment of 1D nanostructures using COMSOL simulations. The impact of electric field distribution with varying electrode geometry, voltage, and frequency were studied using these simulations. The maximum electric field value of 2.6 × 10⁶ V/m was observed at electrode edges and gaps. Moreover, a significant increase in the electric field was observed with a decrease in finger width. These simulation results for DEP electrodes have huge potential in advancing 1D nanowire-based flexible and wearable electronic devices in the future. Full article

In this paper, a study on the development of indium-doped Cu_xS heterojunction-based conductometry sensors is presented. To fabricate the sensors, thick films of In-Cu_xS heterojunctions were sprayed directly on the alumina sensing platform provided with interdigitated Pt electrodes. The effect of the doping level with different nominal amounts of InCl₃ additive (0%, 3%, and 5%) on the structural, morphological and optical properties of Cu_xS films was first studied by XRD, AFM, UV-Vis and Raman spectroscopy. Moreover, the electrical and sensing characteristics towards low concentrations of hydrogen sulfide (H₂S) in air were investigated. The tests carried out clearly demonstrated the positive effect of In doping on the H₂S sensing performance of Cu_xS. The 5%-doped Cu_xS sensor showed the highest sensitivity to the target gas compared to the other sensor, as well as good stability and selectivity properties. Full article

To address the challenges of traditional flexible humidity sensors, such as reliance on external power supply, complex fabrication processes, and poor adaptability to energy-limited scenarios, this study successfully developed a low-cost, easily scalable, self-powered flexible humidity sensor based on hydroxypropyl trimethyl ammonium chitosan/lithium chloride (HACC/LiCl) composite electrolyte using a screen-printing process. The device employs A4 paper as the flexible substrate, and interdigitated manganese dioxide (MnO₂) positive electrodes, zinc (Zn) negative electrodes, and HACC/LiCl composite electrolyte layers are sequentially fabricated via screen-printing, ultimately constructing a simple primary battery structure. Through a series of performance screening and optimization, 0.1 mol/L LiCl-modified HACC (HL-1) is identified as the optimal electrolyte system. The test results show that the HL-1 sensor exhibits a wide humidity detection range of 11~97% relative humidity (RH), with the output voltage displaying a good quadratic function relationship with humidity (R² = 0.996), and a peak output voltage of up to 1.2 V. The device possesses excellent cyclic stability and long-term stability, with no significant fluctuation in output voltage under different bending deformation states. This sensor demonstrates broad application prospects in fields such as respiratory monitoring and non-contact sensing, providing a feasible technical path for the development of low-cost passive humidity monitoring equipment. Full article
