A growing interest in offshore wind energy in the Mediterranean Sea has been recently observed thanks to the potential for scale-up and recent advances in floating technologies and dynamic cables: in the Italian panorama, the offshore wind connection requests to the National Transmission Grid (NTG) reached almost 84 GW at the end of September 2024. Starting from a realistic estimate of the offshore wind power plants (OWPPs) to be realized off the southern coasts in a very long-term scenario, this paper presents a novel optimization procedure for meshed AC offshore network configuration, aiming at minimizing the offshore wind generation curtailment based on the DC optimal power flow approximation, assessing the security condition of the whole onshore and offshore networks. The reactive power compensation aspects are also considered in the optimization procedure: the optimal compensation sizing for export cables and collecting stations is evaluated via the AC optimal power flow (OPF) approach, considering a combined voltage profile and minimum short circuit power constraint for the onshore extra-high voltage (EHV) nodes. The simulation results demonstrate that the obtained meshed network configuration and attendant re-active compensation allow most of the offshore wind generation to be evacuated even in the worst-case scenario, i.e., the N1 network, full offshore wind generation output, and summer line rating, testifying to the relevance of the proposed methodology for real applications. Full article

The asymmetric operation is a method that allows High and Extra-High Voltage (HV, EHV) power lines to function with one or two phases open. With the increasing share of Renewable Energy Sources (RES) in National Power Systems (NPS), they are becoming more volatile and less reliable due to decreasing inertia and other issues related to the integration and exploitation of the Inverter-Based Resources (IBR) (decreasing short-circuit ratio, different types of interactions, etc.). On the other hand, phase-to-ground faults are a common cause of tripping off power lines which affects the overall reliability of the power system. Thus, for power systems experiencing a decreasing trend in reliability and robustness, the asymmetrical operation of the power lines may enhance them. In this way, this article reviews the state of the art and new developments in the academic landscape regarding asymmetrical operation. The review is not, however, limited to HV and EHV systems, so it examines cases of asymmetric operation in Low and Medium Voltages (LV, MV) as well. The challenges and opportunities that this unique mode of operation imposes on power networks are also presented, providing a fresh reference for researchers looking to enter this topic. Full article

This paper presents an extra-high voltage synthetic test system that consists of 500 kV and 765 kV voltage levels, specifically designed for transmission expansion planning (TEP) studies. The test network includes long transmission lines whose series impedance and shunt admittance are calculated using the equivalent π circuit model, accurately reflecting the distributed nature of the line parameters. The proposed test system offers technically feasible steady-state operation under normal and all single contingency conditions. By incorporating accurate modeling for long transmission lines and EHV voltage levels, the test system provides a realistic platform for validating models and theories prior to their application in actual power systems. It supports testing new algorithms, control strategies, and grid management techniques, aids in transmission expansion planning and investment decisions, and facilitates comprehensive grid evaluations. Moreover, a TEP study is conducted on this test system and various scenarios are evaluated and compared economically. Full article

The ongoing replacement of synchronous machine generators (SMs) with converter-interface generators (CIGs) is raising the voltage unbalance of power systems, affecting power quality and grid stability. This paper focuses on a key power quality index for power systems, i.e., the voltage unbalance factor. The purpose of this work is twofold. First, it presents the generalization of a three-phase power flow algorithm developed by University of Padova, named PFPD_3P, to assess the voltage unbalance factors of power systems supplied by CIGs. In particular, it is demonstrated that CIGs can be modelled as three-phase PV/PQ constraints embedding their positive-, negative- and zero-sequence admittances. Then, the concept of three-phase contingency analysis is introduced. Indeed, for static security evaluation, the classical single-phase contingency analysis may no longer be sufficient, as it lacks power quality computations, e.g., voltage/current unbalance factors. Numerical simulations evaluating the unbalance factors due to different generation mix scenarios and contingencies are tested on the Italian extra-high-voltage/high-voltage (EHV/HV) grid. The choice of this network relies on its representativeness, as CIGs are the majority of new installations in the Italian generation mix. Full article

Transmission lines are affected by external environmental factors such as strong winds and ice cover. In recent years, extreme weather events have increased, leading to recurrent disturbances in transmission lines because of wind deflection. These incidents have resulted in significant financial losses and have disrupted regular industrial and domestic activities. In this paper, the ANSYS Workbench 2020 R2 finite element analysis platform was used to establish a transmission line-hanging insulator string system model. Calculations on transmission lines were conducted considering variations in different stall spacing, height differences, wind speed, and the wind attack angle. The impact of these diverse factors on the wind deflection of insulators was scrutinized, leading to the derivation of patterns describing how the wind deflection angle shifts in response to changes in stall spacing, height differences, wind speed, and the wind attack angle. Based on the generalized linear regression network and particle swarm improved support vector machine algorithm, a meteorological prediction-based early warning method for wind deflection of transmission lines was proposed, a transmission line wind deflection early warning model was established, and the practical effect of the model was evaluated. The outcomes of this study provide crucial data for the formulation and development of ultra-high voltage (UHV) and extra-high voltage (EHV) transmission networks. Furthermore, they can contribute to the advanced detection of wind deflection issues. Full article

Boundary protection is a protection that takes advantage of the characteristic that signals will be attenuated when passing through the “line boundary”. The location of the traps and current transformers in the structure of extra-high voltage (EHV) transmission lines makes it difficult to apply current-based travelling wave protection in engineering practice. If the protection is put into use, it is necessary to carry out a large number of engineering modifications to the existing transmission lines, which greatly increases the economic cost. And after simulation, the protection will be misjudged under weak fault conditions, and it has low reliability. After analyzing the influence of fault factors, a boundary protection method using high-frequency voltage component energy is proposed. The fault signal is processed by S-transform, and the transient voltage energy is normalized with the initial fault phase and transition resistance. The reduced characteristic quantity is used to construct a criterion to judge the fault condition of the protection line. This protection eliminates the influence of fault factors on transient protection. The ATP-Draw 6.0 simulation results based on the proposed protection scheme show that the protection scheme can distinguish internal and external faults, and can work normally under weak faults with high reliability. Full article

The deployment of small unmanned aerial vehicles (UAVs), or drones, for transmission line inspections, has brought attention to the potential impact of electromagnetic fields (EMFs) on UAV operations. This work describes a mathematical model based on the finite elements method (FEM), designed to examine the electric and magnetic fields produced by extra-high voltage (EHV) conductors. The current study extends the analysis to encompass both electric and magnetic fields and evaluates the safe distances for UAVs operating near 345 kV, 500 kV, and 765 kV transmission lines. The electromagnetic environment around these EHV transmission lines was simulated using electrostatic, magnetostatic, and transient magnetic modules within the QuickField software 6.6. Electric and magnetic profiles were estimated using 2D finite element analysis, including a numerical simulation for phase-to-phase fault EMFs for the above transmission lines. These results were then cross-verified with theoretical calculations at specific intervals and further validated using the EMFACDC analytical method developed by the International Telecommunication Union. This comprehensive assessment concludes that precise distance considerations are necessary to ensure UAV safety during power line inspections, mitigating potential risks from EMF interference. Full article

To perform a capacitive current switching test (CCT) at AC extra-high-voltage (EHV) and above level, this paper proposes a new multi-transformer synthetic circuit (MTSC) test method that replaces the general synthetic test method using capacitor banks. An MTSC method has a simpler circuit structure compared to other synthetic testing methods and has higher equivalence (especially recovery voltage and TRV) and validity. Using this method, CCTs for circuit breakers (CBs) of the AC 420 kV voltage class were performed as a field test using the IEC 62271-100 standard. To verify that the test method was valid, test results were analyzed and compared with the requirements of a standard. Consequently, the MTSC method completely covered the requirements of the standard. Full article

Very fast transient overvoltage (VFTO) generated by an operating disconnector is one of the main reasons for electromagnetic disturbance in gas-insulated switchgear (GIS) substations. Generally, the amplitude of VFTO can be used as one of the references for the insulation design of GIS primary electric power equipment, so it is necessary to obtain its accurate amplitude. In this study, a new VFTO measuring sensor is developed and its measurement performance is demonstrated through hundreds of operations by a disconnector in a 220 kV GIS test circuit. The validation shows that the low cut-off frequency of the new VFTO measuring sensor has been greatly expanded to 0.01 mHz, which is improved by about 50% compared with the old sensor. The measurement accuracy of amplitude of VFTO micro-pulse improves greatly by about 80% compared with the old one. Thus, the new VFTO measuring sensor can fully meet the measurement needs of trapped charge voltage, power frequency voltage, and high-frequency transient voltage in VFTO waveform. It can be used to provide more accurate data support for insulation design of GIS primary power electric equipment in extra-high voltage (EHV) and ultra-high voltage (UHV) GIS substations. Full article

Resin-impregnated paper (RIP) bushing has gained significant interest due to its extended application in Extra High Voltage (EHV) and Ultra High Voltage (UHV) electricity transmission systems. However, the design criterion of its overall structure, the geometry parameters of the condenser layers, and stress release devices, etc., are still not fully understood. This article proposes a unique electric field optimization technique to integrate both the analytical and the numerical methods. The charge simulation method (CSM) is employed to create the overall equipotential surface, within which the finite element analysis (FEA) is adapted to study the localized field enhancement effects, taking into consideration the multi-physics coupled fields. A case study is performed on an actual UHV bushing. The results are compared to the traditional methods, to demonstrate the benefit of the hybrid method. Full article

Damage to devices installed in electric substations, which have shown vulnerable behaviour under strong earthquakes in the last decades, may endanger power delivery in the emergency phases during and after an earthquake. Within seismic risk assessment of power networks, the definition of the fragility functions of electric equipment is paramount. However, in the current literature the availability of such fragility models for some specific electric substation components, including instrument transformers, is relatively limited, this being the reason behind the deployment of the current experimental and numerical research endeavour. Two voltage transformers and two current transformers having different system voltage levels (respectively in the high voltage HV and extra-high voltage EHV ranges) were subjected to shake table tests, and the experimental results were used to calibrate the corresponding 3D numerical models developed in OpenSees. A number of nonlinear dynamic analyses carried out within a multiple-stripe analysis (MSA) framework allowed the derivation of 16 fragility curves for the four transformers in both stand-alone and elevated/supported configurations, considering also two different soil types. Based on the derived curves, one of the voltage transformers is expected to experience light or negligible damage due to earthquake shaking, owing to its high resonance frequencies (and hence stiffness), whilst the remaining three devices may suffer moderate damage under medium to strong shaking intensities; however, their seismic risk is in effect mitigated by the presence of the typically employed supporting column. Comparison against models available in the literature lent valuable reassurance on the adequacy of the employed methodology and the reliability of the derived fragility curves. Full article

For assessment of the insulation performance of high-voltage (HV) equipment installed in extra-high-voltage (EHV) systems, switching impulse voltage tests are performed in an HV testing laboratory. The waveform parameters of the switching impulse voltages are defined by peak voltage (U_p), time to crest (T_p), and time to half (T₂) according to IEC 60060-1. In this paper, a new, simplified, and accurate approach used for determination of the waveform parameters of the switching impulse voltages is presented. The formula used in the evaluation of T_p was derived from analytically simulated two-exponential waveforms, where T_p and T₂ are in the ranges of 20 μs to 300 μs and 1000 μs to 4000 μs, respectively. The accuracy of the proposed approach was validated by the waveforms collected from the test waveform data generator (TDG) provided by IEC 61083-2, simulations, and experiments. It is found that the accuracy of the proposed approach is relatively higher than the expressions provided by IEC 60060-1 and previously developed. The proposed method is an alternative and useful approach for evaluating the waveform parameters of the standard switching impulse voltage. Full article

In power systems, the programmable numerical differential relays are widely used for the protection of generators, bus bars, transformers, shunt reactors, and transmission lines. Retrofitting of relays is the need of the hour because lack of proper testing techniques and misunderstanding of vital procedures may result in under performance of the overall protection system. Lack of relay’s proper testing provokes an unpredictability in its behavior, that may prompt tripping of a healthy power system. Therefore, the main contribution of the paper is to prepare a step-by-step comprehensive procedural guideline for practical implementation of relay testing procedures and a detailed insight analysis of relay’s settings for the protection of an Extra High Voltage (EHV) auto transformer. The experimental results are scrutinized to document a detailed theoretical and technical analysis. Moreover, the paper also covers shortcomings of existing literature by documenting specialized literature that covers all aspects of protection relays, i.e., from basics of electromechanical domain to the technicalities of the numerical differential relay covering its detailed testing from different reputed manufacturers. A secondary injection relay test set is used for detailed testing of differential relay under test, and the S1 Agile software is used for protection relay settings, configuration modification, and detailed analysis. Full article

It is inevitable that high-intensity, wide-spectrum electromagnetic emissions are generated by the power electronic equipment of the Extra High Voltage (EHV) power converter station. The surveillance flight of Unmanned Aerial Vehicles (UAVs) is thus, situated in a complex electromagnetic environment. The ubiquitous electromagnetic interference demands higher electromagnetic protection requirements from the UAV construction and operation. This article is related to the UAVs patrol inspections of the power line in the vicinity of the EHV converter station. The article analyzes the electromagnetic interference characteristics of the converter station equipment in the surrounding space and the impact of the electromagnetic emission on the communication circuits of the UAV. The anti-electromagnetic interference countermeasures strive to eliminate or reduce the threats of electromagnetic emissions on the UAV’s hardware and its communication network. Full article

The paper focuses on finding short circuit duration for computing the dynamic effects in Extra High Voltage (EHV) distribution substations with flexible conductors with the use of probabilistic method. To find fault duration for selected substation points, a risk criterion was involved, namely the expected annual frequency of exceeding the calculated values of dynamic forces. A dedicated simulation model based on the Monte Carlo method was used to analyze the dynamic effects of short circuit current flow in the substation during faults within it and in its vicinity. The short circuit duration model is the key part of the simulation model. Due to the discussion of how the selected factors affect the estimated short circuit duration, indications helpful to find the values of the latter were formulated and some examples for the 220 kV distribution substation were given. Full article
