Search Results (183)

Sonar is a fundamental tool for underwater target detection. However, conventional detection systems often suffer from poor sensor consistency and high fabrication costs. More critically, for low-frequency operation, the required array aperture becomes prohibitively large, limiting their deployment on small, mobile underwater platforms. To address the demand for compact, high-performance sensing solutions, this paper presents a miniaturized Micro-electromechanical Systems (MEMS) hydrophone array designed for underwater target detection. The array consists of six elements with a spacing of 0.25 m. Each element is approximately 22 mm in diameter and encapsulated in polyurethane via a casting and curing process. The core sensing element, a MEMS acoustic pressure hydrophone, exhibits a sensitivity of −177.2 ± 1.5 dB (re: 1 V/µPa) across the 20 Hz to 4 kHz frequency range and a noise resolution of approximately 59.5 dB (re: 1 µPa/√Hz) at 1 kHz. A key challenge in array-based detection is the phase mismatch among acquisition channels, which degrades algorithm performance. To mitigate this, we propose a phase self-correction method based on interleaved ADC acquisition control, enabling synchronous multi-channel sampling and effectively eliminating system-level phase errors. Furthermore, to overcome the inherent aperture limitations of conventional beamforming (CBF) applied to a miniaturized array, a differential beamforming (DBF) algorithm is adopted. This approach is less frequency-dependent and can approximate a frequency-invariant beam pattern, making it well-suited for miniaturized arrays. Simulation results confirm the theoretical validity of the DBF algorithm for the proposed MEMS hydrophone array. Sea trial data further demonstrate that this method achieves higher target detection accuracy compared to CBF techniques. Full article

This paper presents a methodology enabling the use of a Pitot probe for static pressure measurement in supersonic flow under severely confined spatial conditions where standard design guidelines cannot be satisfied. In particular, the recommended placement of a static pressure tapping at a distance of 10–20 tube diameters is not feasible; the proposed approach allows for the tapping to be located immediately downstream of the static tube cone. The methodology combines theoretical analysis, experimental measurements, and Computational Fluid Dynamics (CFD) simulations. Experiments were performed using appropriately selected pressure sensors, while detailed simulations in Ansys Fluent (Ansys 2024 R2) included both a high-fidelity probe model and free-stream flow analysis. By comparing experimental and numerical results, a correction coefficient was established based on the free-stream dynamic pressure obtained from CFD. This enables the accurate estimation of static pressure even in non-ideal probe configurations. The measurement error did not exceed 20%, while in most cases, very good agreement between experimental and CFD results was achieved. The main contribution of this paper is the validated methodology, which extends the applicability of Pitot probes to geometrically constrained environments where conventional static pressure measurement techniques cannot be implemented. Full article

Experiments on hypersonic boundary-layer instability of a fin–cone configuration were conducted in a Φ 0.5 m Mach 6 Ludwieg tube tunnel. Infrared thermography and high-frequency pressure sensors were used to measure the transition front and instability waves under four different nose bluntness conditions. On the leeward surface, transition is delayed near the centerline due to expansion waves generated by the double-cone structure. The region close to the corner is strongly influenced by the horseshoe vortex, whereas instability waves around 110 kHz manifest as the flow moves away from it. In contrast, transition on the windward surface occurs earlier and broadband high-frequency instability waves of 160–300 kHz are present near the corner. Increasing nose bluntness strongly suppresses transition away from the fin root, especially near the centerline and on the fin-off cone side, but has a relatively limited impact on the shock-interaction regions near the fin–cone corner. Transition on the fin surface remains insensitive to nose bluntness variations. This work elucidates the distinct transition behaviors across different regions of a complex fin–cone configuration and their differential responses to nose bluntness, providing valuable insights for the aerodynamic design and transition prediction of hypersonic vehicles. Full article

This work presents the fabrication and a systematic evaluation of an ionic polymer-metal composite (IPMC) sensor, focusing on its potential for human motion monitoring and human–computer interaction. The sensor was fabricated via a solution casting and electroless plating process, and its morphology characterized using scanning electron microscopy. The sensing performance was comprehensively assessed, revealing high sensitivity (1.059 mV/N) in the low-pressure region, a fast response time (~50 ms), and reliable stability over prolonged cyclic testing. Furthermore, the sensor can respond to both the magnitude and rate of applied mechanical stimuli. To explore its application potential, the IPMC was tested in scenarios ranging from input pattern recognition—including distinguishing mouse-click patterns, handwritten letters, and binary-encoded presses—to human motion monitoring, where it effectively captured and differentiated signals from facial expressions, swallowing, breathing, and joint movements. The results suggest that the developed IPMC sensor is a promising candidate for applications in wearable health monitoring and flexible interactive systems. Full article

Large-scale bulk models offer a promising approach for the experimental investigation of flow in porous media. However, conventional configurations frequently lack adequate confinement systems, resulting in model instability under dynamic flow conditions. This paper introduces a novel experimental apparatus designed for large-scale porous media flooding studies. The porous medium is represented by a tubular granular bulk model measuring one meter in length and 95 mm in diameter. An integrated array of distributed pressure, temperature, and electrical resistance sensors allows for the acquisition of a longitudinal pressure profile, the evaluation of the model’s consolidation state, and the assessment of its stress sensitivity. Comparative studies of filtration processes are presented for a granular bulk model under both confined and unconfined conditions. The results indicate that in the absence of confinement, the model exhibits high sensitivity to pressure differentials, manifesting as a nonlinear relationship between flow rate and pressure drop alongside significant fluctuations in electrical resistance. Conversely, cyclic loading under confining pressure promotes uniform and stable consolidation of the model, thereby minimizing hysteresis and particle displacement. These findings underscore that effective confinement is critical for ensuring the representativeness of data derived from large-scale bulk models of unconsolidated porous media. Full article

The study of the flow of water through soils is important and has applications in many fields such as irrigation in agriculture, engineering, hydrogeology, and earth sciences. Many research efforts have been focused on different aspects of the subject of flow through soils. These include flow through the vadose zone where the flow is transient, saturated flow, soil water evaporation, Darcian or laminar flow, macroporous or differential flow, flow through homogeneous soils, and flow through heterogeneous soils. Although Darcy’s law is the most fundamental law governing soil water subsurface flow, it considers a linear relation between flow velocity and pressure gradient. Formulation of Darcy’s law is based on steady flow of incompressible liquid when the porous medium is isotropic, homogeneous, and saturated. However, these classical representations of water flow are not adequate when considering flow through natural soils, due to influences caused by the existence of macropores and spatial variability of soil properties. Despite researchers’ non-linear models which modify Darcy’s law, such as Richard’s equation for transient unsaturated flow of water in soils, determination of soil hydraulic properties also requires other techniques and measurement methods. This study focuses on model approaches and experimental investigations of water flow through the soil subsurface with instruments and sensors for determination of hydraulic properties and parameters for flow characterisation. It critically examines challenges and the accuracy of best practices and aims to present novel methods of experimental approach for potential solutions. Full article

With the increasing number of patients with Parkinson’s disease, the detection of Parkinson’s disease is crucial for the early intervention and treatment of this condition. The motor characteristics of Parkinson’s disease primarily include typical motor features. Flexible pressure sensor arrays, due to their unique mechanical properties and biocompatibility, have shown great potential for capturing movement characteristics. This research aims to develop a deep learning model based on foot pressure data for the detection of Parkinson’s disease. By collecting the pressure data of patients during walking and analyzing the distribution of foot pressure, the model can capture the unique biomechanical characteristics of Parkinson’s disease patients. To address the core challenges of spatial irregularity and data disorder in footprint data, we propose an innovative approach that leverages the Transformer-based attention mechanism and tensor fusion technique to enable accurate identification of Parkinson’s disease. This attention mechanism has inherent permutation invariance, which is highly suitable for the feature learning of footprint data. The tensor fusion technique can effectively integrate the foot features at different levels. A large-scale dataset of foot pressure data was used for training and validation. The experimental results show that the model achieves a high accuracy of 87.03% and good stability in Parkinson’s disease detection, enabling effective differentiation between patients and healthy individuals. On the one hand, our work is critical for analyzing pressure data and fusion features from large-area flexible force-sensitive sensors, which enables the accurate identification of foot data. On the other hand, it greatly facilitates gait analysis, gait evaluation, and the diagnosis of Parkinson’s disease. Full article

In extremely harsh high-temperature environments in aerospace, industrial manufacturing and other fields, traditional ultrasonic temperature measurement technology has certain limitations. This paper proposes a differential single crystal sapphire ultrasonic temperature measurement method based on the magnetostrictive effect. This method abandons the traditional sensitive flexural structure and uses two single-crystal sapphire waveguides of the same material, same diameter, and slightly different lengths as sensing elements. By measuring the time delay difference between their end-face echoes, the sound velocity is inverted and the temperature is measured. COMSOL multi-physics v6.1 simulation was used to optimize the bias magnetic field design of the magnetostrictive transducer, which improved the system’s energy conversion efficiency and high-temperature stability. Experimental results show that in the range of 300–1200 °C, the sensor delay increases monotonically with increasing temperature, the sound speed shows a downward trend, and the repeatability error is less than 5%; the differential processing method effectively suppresses common mode noise in the range of 300–700 °C, and still shows high sensitivity above 800 °C. This research offers a technical solution with high reliability and accuracy for temperature monitoring in extreme environments such as those characterized by high temperatures and high pressures. Full article

It is demonstrated that the general representation of a dynamic multiphase wellbore flow model may be identified from the available physical measurements. The proposed approach is based on the techniques of numerical optimization and also requires the availability of solvers for the general type of partial differential equations describing two-phase gas–oil flow. A solution is obtained both for the case of the homogeneous no-slip model and the drift-flux model with velocity slip. The feasibility of the proposed approach for system identification and parameter estimation has been demonstrated using simulated flow data. Two distinct scenarios have been considered: firstly, when the well is fully instrumented with multiple pressure sensors and a multiphase flow meter, and secondly, when only a single downhole pressure gauge is available. Full article

This study presents a model-driven approach to the design, calibration, and application of frequency-output pressure sensors integrated within an intelligent system for real-time monitoring of rowing performance. The proposed system captures biomechanical parameters of the “boat–rower” complex across 50 parallel channels with a temporal resolution of 8–12 ms. At the core of the sensing architecture are parametric pressure transducers incorporating strain-gauge primary elements and microelectronic auto-generator circuits featuring negative differential resistance (NDR). These oscillating circuits convert mechanical stress into high-frequency output signals in the 1749.9–1751.9 MHz range, with pressure sensitivities from 0.365 kHz/kPa to 1.370 kHz/kPa. The sensor models are derived using physical energy conversion principles, enabling the formulation of analytical expressions for transformation and sensitivity functions. These models simplify sensitivity tuning and allow clear interpretation of how structural and electronic parameters influence output frequency. The system architecture eliminates the need for analog-to-digital converters and signal amplifiers, reducing cost and power consumption, while enabling wireless ultra high frequency (UHF) transmission of sensor data. Integrated algorithms analyze the influence of biomechanical variables on athlete performance, enabling real-time diagnostics. The proposed model-based methodology offers a scalable and accurate solution for intelligent sports instrumentation and beyond. Full article

The convergence of Industrial Internet of Things (IIoT) and digital twin technology offers new paradigms for process automation and control. This paper presents an integrated IIoT and digital twin framework for intelligent control of a gas–liquid separation unit with interacting flow, pressure, and differential pressure loops. A comprehensive dynamic model of the three-loop separator process is developed, linearized, and validated. Classical stability analyses using the Routh–Hurwitz criterion and Nyquist plots are employed to ensure stability of the control system. Decentralized multi-loop proportional–integral–derivative (PID) controllers are designed and optimized using the Integral Absolute Error (IAE) performance index. A digital twin of the separator is implemented to run in parallel with the physical process, synchronized via a Kalman filter to real-time sensor data for state estimation and anomaly detection. The digital twin also incorporates structured singular value ($\mu$) analysis to assess robust stability under model uncertainties. The system architecture is realized with low-cost hardware (Arduino Mega 2560, MicroMotion Coriolis flowmeter, pneumatic control valves, DAC104S085 digital-to-analog converter, and ENC28J60 Ethernet module) and software tools (Proteus VSM 8.4 for simulation, VB.Net 2022 version based human–machine interface, and ML.Net 2022 version for predictive analytics). Experimental results demonstrate improved control performance with reduced overshoot and faster settling times, confirming the effectiveness of the IIoT–digital twin integration in handling loop interactions and disturbances. The discussion includes a comparative analysis with conventional control and outlines how advanced strategies such as model predictive control (MPC) can further augment the proposed approach. This work provides a practical pathway for applying IIoT and digital twins to industrial process control, with implications for enhanced autonomy, reliability, and efficiency in oil and gas operations. Full article

This study examines the design and implementation of a sensor developed to measure total pressure in supersonic flow conditions using nitrogen as the working fluid. Using a combination of absolute and differential pressure sensors, the total pressure distribution downstream of a nozzle—where normal shock waves are generated—was characterized across a range of low-pressure regimes. The experimental results were employed to validate and calibrate computational fluid dynamics (CFD) models, particularly within pressure ranges approaching the limits of continuum mechanics. The validated analyses enabled a more detailed examination of shock-wave behavior under near-continuum conditions, with direct relevance to the operational environment of differentially pumped chambers in Environmental Scanning Electron Microscopy (ESEM). Furthermore, an entropy increase across the normal shock wave at low pressures was quantified, attributed to the extended molecular mean free path and local deviations from thermodynamic equilibrium. Full article

This research presents the design and implementation of a cascade Proportional–Integral (PI) controller tailored for a Variable Air Volume (VAV) system that was specially created and executed particularly for hospital operating rooms. The main goal of this work is to make sure that the temperature and positive pressure stay within the limits set by ASHRAE Standard 170-2017. This is necessary for patient safety, surgical accuracy, and system reliability. The proposed cascade design uses dual-loop PI controllers: one loop controls the temperature based on user-defined setpoints by local control touch screen, and the other loop accurately modulates the differential pressure to keep the pressure of the environment sterile (positive pressure). The system works perfectly with Building Automation System (BAS) parts from Automated Logic Corporation (ALC) brand, like Direct Digital Controllers (DDC) and Web-CTRL software with Variable Frequency Drives (VFDs), advanced sensors, and actuators that give real-time feedback, precise control, and energy efficiency. The system’s exceptional responsiveness, extraordinary stability, and resilient flexibility were proven through empirical validation at the Korean Iraqi Critical Care Hospital in Baghdad under a variety of operating circumstances. Even during rapid load changes and door openings, the control system successfully maintained the temperature between 18 and 22 °C and the differential pressure between 3 and 15 Pascals. Four performance scenarios, such as normal (pressure and temperature), high-temperature, high-pressure, and low-pressure cases, were tested. The results showed that the cascade PI control strategy is a reliable solution for critical care settings because it achieves precise environmental control, improves energy efficiency, and ensures compliance with strict healthcare facility standards. Full article

The Hunga-Tonga volcanic eruption on 15 January 2022, produced significant atmospheric and ionospheric disturbances that may degrade global navigation satellite system (GNSS) and precise point positioning (PPP) accuracy. Using data from the GEONET GNSS network and Soratena barometric pressure sensors across Japan, we analyzed the eruption’s effects through the gradient ionospheric index (GIX) and the rate of TEC index (ROTI) to characterize the propagation and effects of these disturbances on ionospheric total electron content (TEC) gradients. Our analysis identified two separate ionospheric disturbance events. The first event, coinciding with the arrival of atmospheric Lamb waves, was characterized by wave-like pressure anomalies, differential TEC (dTEC) fluctuations, and modest horizontal gradients of vertical TEC (VTEC). In contrast, the second, more pronounced disturbance was driven by equatorial plasma bubbles (EPBs), which generated severe ionospheric irregularities and large TEC gradients. Further analysis revealed that these two disturbances had markedly different impacts on GNSS positioning accuracy. The Lamb wave–induced disturbance mainly caused moderate TEC fluctuations with limited effects on positioning accuracy, and mid-latitude stations maintained both average and 95th percentile positioning ($\mathrm{p}\mathrm{p}\mathrm{p},{\mathrm{P}}_{95}$) errors below 0.1 m throughout the event. In contrast, the EPB-driven disturbance had a substantial impact on low-latitude regions, where the average horizontal PPP error peaked at 0.5 m and the horizontal and vertical $\mathrm{p}\mathrm{p}\mathrm{p},{\mathrm{P}}_{95}$ errors exceeded 1 m. Our findings reveal two episodes of spatial-gradient enhancement and successfully estimate the propagation speed and direction of the Lamb waves, supporting the potential application of ionospheric gradient monitoring in forecasting GNSS performance degradation. Full article

In this study, a prototype system was developed as a potential alternative to lockdown measures against the spread of airborne infectious diseases such as COVID-19. The system integrates real-time estimation functions for respiratory flow and mask leakage into a low-cost powered air-purifying respirator (PAPR) designed for the general public. Using only a single differential-pressure sensor (SDP810) and a controller (Arduino UNO R4 WiFi), the respiratory flow (Q_3e) is estimated from the differential pressure (ΔP) and battery voltage (V_b), and both the wearing status and leak status are transmitted to and displayed on a smartphone application. For evaluation, a testbench called the Respiratory Airflow Testbench was constructed by connecting a cylinder–piston drive to a mannequin head to simulate realistic wearing conditions. The estimated respiratory flow Q_3e, calculated solely from ΔP and V_b, showed high agreement with the measured flow Q_3m obtained from a reference flow sensor, confirming the effectiveness of the estimation algorithm. Furthermore, an automatic leak detection method based on the time-integrated value of Q_3e was implemented, enabling the detection of improper wearing. This system thus achieves respiratory flow estimation and leakage detection based only on ΔP and V_b. In the future, it is expected to be extended to applications such as pressure control synchronized with breathing activity and health monitoring based on respiratory and coughing analysis. This platform also has the potential to serve as the foundation of a PAPR Wearing Status Network Management System, which will contribute to societal-level infection control through the networked sharing of wearing status information. Full article
