In recent years, deep learning methods have made breakthroughs in the field of rotating equipment fault diagnosis, thanks to their powerful data analysis capabilities. However, the vibration signals usually incorporate fault features and background noise, and these features may be scattered over multiple frequency levels, which increases the complexity of extracting important information from them. To address this problem, this paper proposes a Masked and Cascaded Multi-Branch Attention Network (MCMBAN), which combines the Noise Mask Filter Block (NMFB) with the Multi-Branch Cascade Attention Block (MBCAB), and significantly improves the noise immunity of the fault diagnostic model and the efficiency of fault feature extraction. NMFB novelly combines a wide convolutional layer and a top k neighbor self-attention masking mechanism, so as to efficiently filter unnecessary high-frequency noise in the vibration signal. On the other hand, MBCAB strengthens the interaction between different layers by cascading the convolutional layers of different scales, thus improving the recognition of periodic fault signals and greatly enhancing the diagnosis accuracy of the model when processing complex signals. Finally, the time–frequency analysis technique is employed to explore the internal mechanisms of the model in depth, aiming to validate the effectiveness of NMFB and MBCAB in fault feature recognition and to improve the feature interpretability of the proposed modes in fault diagnosis applications. We validate the superior performance of the network model in dealing with high-noise backgrounds by testing it on a standard bearing dataset from Case Western Reserve University and a self-constructed composite bearing fault dataset, and the experimental results show that its performance exceeded six of the top current fault diagnosis techniques. Full article

This study introduces an electronically tunable resistorless mixed-mode universal filter and dual-mode quadrature oscillator configuration utilizing merely two voltage differencing gain amplifiers and two grounded capacitors. The suggested filter can perform all generic biquadratic filter functions in all four modes: voltage mode, trans-admittance mode, current mode, and trans-impedance mode, while utilizing the same design. The pole frequency and the quality factor can be tuned electronically and orthogonally by means of the transconductances of the voltage differencing gain amplifier. The dual-mode quadrature oscillator featuring both voltage and current outputs can also be obtained from the proposed filter core. It additionally provides separate electronic control of the oscillation condition and frequency. Several PSPICE simulations with the TSMC 0.18 μm CMOS model confirm the feasibility of the proposed configurations. Both proposed circuits were experimentally evaluated using commercially available integrated circuit LM13600s. Both simulation and experimental results have validated the performance of the design. Full article

In this paper, a novel multiple-input operational transconductance amplifier (MI-OTA) is proposed. The MI-OTA can be obtained by using the multiple-input bulk-driven MOS transistor (MIBD MOST) technique. The circuit structure is simple, can operate with a supply voltage of 0.5 V, and consumes 937 pW at a current setting of 625 pA. The proposed MI-OTA was used to implement a high-order multiple-input voltage-mode universal filter. The proposed filter can provide non-inverting and inverting low-pass, high-pass, band-pass, band-stop, and all-pass transfer functions to the same topology. In addition, it has a high input impedance and does not need any inverted input signals, so there is no additional buffering circuit. The proposed filter can be used for biological signal processing. The proposed MI-OTA and the second-order universal filter were simulated in Cadence using CMOS process parameters of 0.18 μm from TSMC to verify the functionality and performance of the new structures. Full article

This paper presents an ultra-low-power, inverter-based, universal Gm-C filter capable of operating in multiple modes: voltage, current, transconductance, and trans-resistance. The proposed filter features orthogonal tunability of the center frequency (ω₀) and quality factor (Q). To achieve ultra-low power consumption, all transistors are biased in the subthreshold region with a supply voltage of 0.5 V. A Nauta inverter-based gm block is utilized as the operational transconductance amplifier (OTA), further enhancing power efficiency. The filter is capable of generating all filtering responses across a supply voltage ranges from 1.2 V down to 0.5 V. Moreover, the center frequency and quality factor can be tuned by adjusting capacitance values. The proposed Gm-C filter achieves a power consumption of 48 nW, with the center frequency ranging from 50.6 Hz to 1270 Hz. Full article

This paper presents a low-voltage, low-power current differencing transconductance amplifier (CDTA) utilizing the bulk-driven MOS transistor technique in the subthreshold region for reduced voltage and power consumption. The proposed CDTA includes a z-copy terminal, which enhances its functionality in current-mode circuit applications. Designed in the Cadence Virtuoso environment using 0.18 µm CMOS technology from Taiwan Semiconductor Manufacturing Company (TSMC), the amplifier operates with a supply voltage of 0.45 V and consumes 328 nW of power, with a bias current set to 10 nA. The current bandwidth and offset of the CDTA are 35 kHz and 0.3 nA, respectively. To demonstrate its performance, the CDTA is applied in a current-mode universal filter, which can realize low-pass, band-pass, high-pass, band-stop, and all-pass responses within a single topology. This design eliminates issues related to inverting input signals, input signal matching, or the need for multiple input signals. Additionally, the natural frequency of these filtering functions can be electronically controlled. The low-pass filter achieves a dynamic range of 61 dB, with a total harmonic distortion of 0.8%. Full article

Energy storage systems (ESSs) and active power filters (APFs) are key power electronic technologies for FACTS (Flexible AC Transmission Lines). Battery energy storage has a structure similar to a shunt active power filter, i.e., a storage element and a voltage source inverter (VSI) connected to the grid using a PWM filter and/or transformer. This similarity allows for the design of an ESS with the ability to operate as a shunt APF. One of the key milestones in ESS or APF development is the DC-link design. The proper choice of the capacitance of the DC-link capacitors and their equivalent resistance ensures the proper operation of the whole power electronic system. In this article, it is proposed to estimate the required minimum DC-link capacitance using a spectral analysis of the DC-link current for different operating modes, battery charge mode and harmonic compensation mode, for a nonlinear load. It was found that the AC component of the DC-link current is shared between the DC-link capacitors and the rest of the DC stage, including the battery. This relation is described analytically. The main advantage of the proposed approach is its universality, as it only requires calculating the harmonic spectrum using the switching functions. This approach is demonstrated for DC-link capacitor estimation in two-level and three-level NPC inverter topologies. Moreover, an analysis of the AC current component distribution between the DC-link capacitors and the other elements of the DC-link stage was carried out. This part of the analysis is especially important for battery energy storage systems. The obtained results were verified using a simulation model. Full article

This paper presents a novel low-power low-voltage current differencing transconductance amplifier (CDTA). To achieve a low-voltage low-power CDTA, the BD-MOST (bulk-driven MOS transistor) technique operating in a subthreshold region is used. The proposed CDTA is designed in 0.18 µm CMOS technology, can operate with a supply voltage of 0.5 V, and consumes 1.05 μW of power. The proposed CDTA is used to realize a current-mode universal filter. The filter can realize five standard transfer functions of low-pass, band-pass, high-pass and band-stop, and all-pass from the same circuit. Neither component-matching conditions nor input signals of the inverse type are required to realize these filter functions. The current-mode filter offers low-input and high-output impedance and uses grounded capacitors. The natural frequency and quality factor of the filters can be orthogonally controlled. The proposed CDTA and its applications are simulated using SPICE to confirm the feasibility and functionality of the new circuits. Full article

This paper presents a mixed-mode universal filter using differential difference current conveyor transconductance amplifiers (DDCCTA). Despite using a minimum number of MOS differential pairs, the proposed DDCCTA is a multiple-input, multiple-output device, that was achieved using the multiple-input bulk-driven MOS transistor (MIBD-MOST) technique, multiple-output current followers and transconductance gains. A subthreshold technique is used to achieve minimum power consumption of the DDCCTA. Thanks to the multiple-input and multiple-output of DDCCTA, the mixed-mode universal filter based on the proposed element can realize five standard filter responses, i.e., low-pass, high-pass, band-pass, band-stop, and all-pass responses, of four modes, i.e., voltage-mode, current-mode, transadmittance-mode, and transimpedance-mode, thus providing 194 filter responses from a single circuit. The natural frequency and quality factor of the filter response can be controlled electronically and orthogonally. The proposed DDCCTA and mixed-mode universal filter are simulated and designed using 0.18 μm CMOS technology to confirm the functionality of the new circuit. The mixed-mode universal filter uses ±0.5 V of supply voltage and consumes 0.374 mW of power when operating at a natural frequency of 10 kHz. Full article

This paper presents the findings of the research aimed at developing computer models to determine the operating conditions in electric power systems (EPSs) feeding DC and AC railway substations. The object of the research is an EPS with a predominant traction load whose high-voltage power lines are connected to transformer and converter substations with 3 kV and 27.5 kV traction networks. The supply network includes 110 kV and 220 kV power lines. The EPS operating parameters are calculated based on the decomposition of the system into alternating and direct current segments. Calculations are performed for the fundamental frequency and high harmonic frequencies. The modeling technique is universal and can be used to determine the operating parameters and power quality indices for any configuration of an EPS and various designs of traction networks. With this technique, one can solve numerous additional problems, such as calculating the processes of ice melting in traction networks and power lines, determining electromagnetic field strengths, and assessing the heating of power line wires and catenary suspensions. The results obtained show that the voltages on the current collectors are within acceptable limits for all AC and DC electric locomotives. The levels of asymmetry on the 110 and 220 kV tires of traction substations (TP) do not exceed the normally permissible values. The values of the asymmetry coefficients for DC TP are tenths of a percent. With an increase in the size of traffic and in post-emergency conditions caused by the disconnection of communication between one of the support substations and the EPS, the asymmetry indicators on the 220 kV buses of AC substations may exceed the permissible limits. Phase-controlled reactive power sources can be used to reduce them. The analysis of the results of the determination of non-sinusoidal modes allows us to formulate the conclusion that the values of harmonic distortion go beyond the normative limits. Passive and active filters of higher harmonics can be used to normalize them. Calculations of thermal modes of traction transformers show that the temperatures of the most heated points do not exceed acceptable values. Full article

This paper presents a new current-mode first-order versatile active filter employing one extra-x second-generation current controlled current conveyor (EX-CCCII) and one grounded capacitor. The proposed filter can realize first-order filtering functions of a low-pass filter (LPF), high-pass filter (HPF), and all-pass filter (APF) within the same topology with low-input and high-output impedances required for current-mode circuits. This multiple-output EX-CCCII-based filter can provide six transfer functions as both non-inverting and inverting filtering functions of the LPF, HPF, and APF are obtained. The filter also offers electronic control of the pole frequency of all filtering. The proposed current-mode filter can be applied to work as a mixed-mode active filter, namely in the transadmittance-mode (TAM), transimpedance-mode (TIM), and voltage-mode (VM). Each operation mode can provide six transfer functions. The proposed filter was simulated and designed using SPICE and 0.18 µm CMOS technology. Experimental results using the commercially available integrated circuit AD844 were used to confirm the functionality of the new circuits. Full article

A low-power, low-voltage universal multi-mode Gm-C filter using a 180 nm TSMC technology node is presented in this paper. The proposed filter employs only three transconductance operational amplifiers (OTAs) operating in the sub-threshold region with a supply voltage of 0.5 V, resulting in a power consumption of 32 nW. Moreover, without additional active elements, the proposed circuit can operate various functional modes, such as voltage, current, transconductance, and trans-resistance. The filter’s frequency, centered at 462 Hz, and a compact and low-power solution showing only 93.5 µVrms input-referred noise make the proposed filter highly suitable for bio-signal processing. Full article

This paper presents a novel multiple-input and multiple-output current-mode universal analog filter with electronic tuning capability. The proposed circuit uses a single second-generation current-controlled current conveyor with extra-X terminals (EX-CCCII) and two grounded capacitors. The filter can offer five standard filtering functions, namely low-pass, high-pass, band-pass, band-stop, all-pass responses, in the same circuit without changing the internal configuration of the filter by selecting appropriate input and output signals. To obtain the five standard filtering functions, inverted input signal and input matching conditions are absent. The natural frequency of all filter responses can be electronically controlled. The proposed circuit was simulated by SPICE using 0.18 μm CMOS process from Taiwan Semiconductor Manufacturing Company (TSMC). The results of experiments using the integrated circuit operational amplifier AD844 confirm the functionality of the new filter. Full article

This paper presents a new multiple-input single-output voltage-mode universal filter employing four multiple-input operational transconductance amplifiers (MI-OTAs) and three grounded capacitors suitable for low-voltage low-frequency applications. The quality factor (Q) of the filter functions can be tuned by both the capacitance ratio and the transconductance ratio. The multiple inputs of the OTA are realized using the bulk-driven multiple-input MOS transistor technique. The MI-OTA-based filter can also offer many filtering functions without additional circuitry requirements, such as an inverting amplifier to generate an inverted input signal. The proposed filter can simultaneously realize low-pass, high-pass, band-pass, band-stop, and all-pass responses, covering both non-inverting and inverting transfer functions in a single topology. The natural frequency and the quality factors of all the filtering functions can be controlled independently. The natural frequency can also be electronically controlled by tuning the transconductances of the OTAs. The proposed filter uses a 1 V supply voltage, consumes 120 μW of power for a 5 μA setting current, offers 40 dB of dynamic range and has a third intermodulation distortion of −43.6 dB. The performances of the proposed circuit were simulated using a 0.18 μm TSMC CMOS process in the Cadence Virtuoso System Design Platform to confirm the performance of the topology. Full article

This study introduces an innovative filter topology capable of providing simultaneous positive and negative gain outputs for one-fractional order LP, with high-pass, all-pass, and fractional-order shelving filter responses. The circuit, utilizing multi-output second-generation current-controlled conveyors, stands out as the first to deliver ten outputs, incorporating both integer and fractional-order filter responses, without requiring additional components. Its current-mode design simplifies the process, employing minimal active and grounded passive elements, making it appropriate for low-voltage/low-power applications. The filter utilizes fifth-order Oustaloup approximation and Foster type-I RC networks for fractional-order capacitors, providing enhanced control over the transition slope. PSpice simulations confirmed a 1 kHz cut-off, showcasing low power consumption, minimal noise, and a wide dynamic range, positioning the filter as suitable for sensors, control, and acoustic applications. Full article

This paper presents electronically tunable current conveyors using low-voltage, low-power, multiple-input operational transconductance amplifiers (MI-OTAs). The MI-OTA is realized using the multiple-input bulk-driven Metal Oxide Semiconductor transistor (MIBD-MOST) technique to achieve minimum power consumption. The MI-OTA also features high linearity, a wide input range, and a simple Complementary Metal Oxide Semiconductor (CMOS). Thus, high-performance electronically tunable current conveyors are obtained. With the MI-OTA-based current conveyor, both an electronically tunable differential difference current conveyor (EDDCC) and a second-generation electronically tunable current conveyor (ECCII) are available. Unlike the conventional differential difference current conveyor (DDCC) and second-generation current conveyor (CCII), the current gains of the EDDCC and ECCII can be controlled by adjusting the transconductance ratio of the current conveyors. The proposed EDDCC has been used to realize a voltage-to-current converter and current-mode universal filter to show the advantages of the current gain of the EDDCC. The proposed current conveyors and their applications are designed and simulated in the Cadence environment using 0.18 μm TSMC (Taiwan Semiconductor Manufacturing Company) CMOS technology. The proposed circuit uses ±0.5 V of power supply and consumes 90 μW of power. The simulation results are presented and confirm the functionality of the proposed circuit and the filter application. Furthermore, the experimental measurement of the EDDCC implemented in the form of a breadboard connection using a commercially available LM13700 device is presented. Full article
