Search Results (33)

To address the challenge of assessing the thickness uniformity of epoxy asphalt layers on steel bridge decks, three-dimensional ground-penetrating radar (3D-GPR) was employed for non-destructive, full cross-sectional detection of the pavement layer’s thickness. The antenna array spacing was optimized using the common midpoint (CMP) method, enabling precise measurement of the relative permittivity of epoxy asphalt mixtures. A significant correlation between relative permittivity and the void ratio was established, providing a novel approach to identifying areas prone to coarse segregation and early-stage water damage. Grayscale maps of the thickness distribution enabled precise detection of regions with acceptable, under-thickness and over-thickness values. The uniformity of construction thickness was quantitatively evaluated using standard deviations and coefficients of variation. Results indicated that when the coefficient exceeds 12%, improvements in the pavement construction process are necessary. This research demonstrates the capability of 3D-GPR to effectively detect thickness variations, offering a valuable tool for enhancing pavement paving and compaction practices on steel bridge decks. Full article

This paper presents the world’s first radar detection experiment conducted in a 7500-m ultra-deep well. By applying ground-penetrating radar technology to petroleum logging, the developed borehole radar system successfully achieved stratigraphic information detection in the 7200–7500 m section of Shunbei Well No. 2. Utilizing electromagnetic wave reflection principles, the system acquires echo signals carrying medium characteristics through transmit–receive antenna arrays coupled with field-programmable gate array (FPGA)-based high-speed acquisition for real-time downhole data transmission. Experimental results demonstrate high consistency in Gamma Ray (GR) curves (correlation coefficient: 0.92) between radar data and Sinopec’s geological drilling data, particularly in key stratigraphic features such as casing reflections at a 7250-m depth (error of 0.013%). This breakthrough validates the operational stability and detection accuracy of borehole radar in complex subsurface environments, providing an innovative technological approach for ultra-deep hydrocarbon exploration. Full article

The growing application of Fiber-Reinforced Polymer (FRP) composites in rehabilitating deteriorating concrete infrastructure underscores the need for reliable, cost-effective, and automated nondestructive testing (NDT) methods. This review provides a comprehensive analysis of existing and emerging NDT techniques used to assess externally bonded FRP (EB-FRP) systems, emphasizing their accuracy, limitations, and practicality. Various NDT methods, including Ground-Penetrating Radar (GPR), Phased Array Ultrasonic Testing (PAUT), Infrared Thermography (IRT), Acoustic Emission (AE), and Impact–Echo (IE), are critically evaluated in terms of their effectiveness in detecting debonding, voids, delaminations, and other defects. Recent technological advancements, particularly the integration of artificial intelligence (AI) and machine learning (ML) in NDT applications, have significantly improved defect characterization, automated inspections, and real-time data analysis. This review highlights AI-driven NDT approaches such as automated crack detection, hybrid NDT frameworks, and drone-assisted thermographic inspections, which enhance accuracy and efficiency in large-scale infrastructure assessments. Additionally, economic considerations and cost–performance trade-offs are analyzed, addressing the feasibility of different NDT methods in real-world FRP-strengthened structures. Finally, the review identifies key research gaps, including the need for standardization in FRP-NDT applications, AI-enhanced defect quantification, and hybrid inspection techniques. By consolidating state-of-the-art research and emerging innovations, this paper serves as a valuable resource for engineers, researchers, and practitioners involved in the assessment, monitoring, and maintenance of FRP-strengthened concrete structures. Full article

The acoustically actuated antenna technology enables a significant reduction in antenna dimension, facilitating miniaturization of ground-penetrating radar systems in the very high-frequency (VHF) band. However, the current acoustically actuated antennas suffer from narrow bandwidth and low range resolution. To address this issue, this paper proposed a three-dimensional (3D) localization method for underground targets, which combined two-dimensional (2D) array direction-of-arrival (DOA) estimation with continuous spatial sampling without relying on range resolution. By leveraging the small dimension of acoustically actuated antennas, a 2D uniform linear array was formed to obtain the target’s angle using DOA estimation. Based on the variation pattern of 2D angles in continuous spatial sampling, the genetic algorithm was employed to estimate the 3D coordinates of underground targets. The numerical simulation results indicated that the root mean square error (RMSE) of the proposed 3D localization method is 1.68 cm, which outperforms conventional methods that utilize wideband frequency-modulated pulse signals with hyperbolic vertex detection in theoretical localization accuracy, while also demonstrating good robustness. The gprMax electromagnetic simulation results further confirmed that this method can effectively localize multiple targets in ideal homogeneous underground media. Full article

Maintaining the integrity of urban road pavements is vital for public safety, transportation efficiency, and economic stability. However, aging infrastructure and limited budgets make it challenging to detect subsurface defects that can lead to pavement collapses. Traditional inspection methods are often inadequate for identifying such underground anomalies. Ground Penetrating Radar (GPR), especially dual-polarized array systems, offers a non-destructive, high-resolution solution for subsurface inspection. Despite its potential, effectively detecting and analyzing areas at risk of collapse in urban pavements remains a challenge. This study employed a dual-polarized array GPR system to inspect road pavements in London. The research involved comprehensive field testing, including data acquisition, signal processing, calibration, background noise removal, and 3D migration for enhanced imaging. Additionally, Short-Fourier Transform Spectrum (SFTS) analysis was applied to detect moisture-related anomalies. The results show that dual-polarized GPR systems effectively detect subsurface issues like voids, cracks, and moisture-induced weaknesses. The ability to capture data in multiple polarizations improves resolution and depth, enabling the identification of collapse-prone areas, particularly in regions with moisture infiltration. This study demonstrates the practical value of dual-polarized GPR technology in urban pavement inspection, offering a reliable tool for early detection of subsurface defects and contributing to the longevity and safety of road infrastructure. Full article

The main purpose of this study is the subsurface investigation of two complex geological environments focusing on the improvement of data acquisition and processing parameters regarding electric and seismic tomographic techniques. Two different study areas, in central–east Peloponnese and SE Attica, were selected, where detailed geological mapping and surface geophysical survey were carried out. The applied geophysical survey included the application of electrical resistivity tomography (ERT), seismic refraction tomography (SRT) and ground penetrating radar (GPR). The geoelectrical measurements were acquired with different arrays and electrode configurations. Moreover, various types of seismic sources were used at seventeen shot locations along the seismic arrays. For the processing of geoelectrical data, clustered datasets were created, increasing the depth of investigation and discriminatory capability. The seismic data processing included the following: (a) the creation of synthetic models and seismic records to determine the effectiveness and capabilities of the technique, (b) spectral analysis of the seismic records to determine the optimal seismic source type and (c) inversion of the field data to create representative subsurface velocity models. The results of the two techniques successfully delineated the complex subsurface structure that characterizes these two geological environments. The application of the ERT combined with the SRT are the two dominant, high-resolution techniques for the elucidation of complex subsurface structures. Full article

To optimally preserve and manage our civil structures, we need to have accurate information about their (1) geometry and dimensions, (2) boundary conditions, (3) material properties, and (4) structural conditions. The objective of this article is to show how imaging and image fusion using non-destructive testing (NDT) measurements can support structural engineers in performing accurate structural evaluations. The proposed methodology involves imaging using synthetic aperture focusing technique (SAFT)-based image reconstruction from ground penetrating radar (GPR) as well as ultrasonic echo array (UEA) measurements taken on multiple surfaces of a structural member. The created images can be combined using image fusion to produce a digital cross-section of the member. The feasibility of this approach is demonstrated using a case study of a prestressed concrete bridge that required a bridge load rating (BLR) but where no as-built plans were available. Imaging and image fusion enabled the creation of a detailed cross-section, allowing for confirmation of the number and location of prestressing strands and the location and size of internal voids. This information allowed the structural engineer of record (SER) to perform a traditional bridge load rating (BLR), ultimately avoiding load restrictions being imposed on the bridge. The proposed methodology not only provides useful information for structural evaluations, but also represents a basis upon which the digitalization of our infrastructure can be achieved. Full article

A common practice used by the Germans and collaborators in World War II, as part of the Holocaust, was to use existing Jewish cemeteries as places for mass burial. Research was completed at the Old Jewish Cemetery in Riga, Latvia, the Livas Jewish Cemetery in Liepaja, Latvia, and the Zaliakalnis Jewish Cemetery in Kaunas, Lithuania. The Old Jewish Cemetery in Riga was adjacent to the Riga Ghetto and was used to bury individuals murdered in the ghetto. In Kaunas, an area of the Zaliakalnis Jewish Cemetery is devoid of grave stones, and literature sources and testimony indicate that this area was used for the mass burial of Jews from the Kaunas Ghetto and other mass killings. In Liepaja, the local Jewish Heritage Foundation believes that there are mass graves within the Livas Cemetery. Methodologies for this research include the use of a pulseEkko Pro 500-megahertz ground-penetrating radar (GPR) system. Electrical resistivity tomography (ERT) data were collected through a linear array of electrodes coupled to a direct current (DC) resistivity transmitter and receiver. Analysis of aerial photography and satellite images was also employed at each location. ERT and GPR data indicate three separate trench anomalies in the Old Jewish Cemetery in Riga. The presence of these anomalies corroborates Holocaust survivor testimony that bodies were buried in mass graves in that area. In the Zaliakalnis Jewish Cemetery in Kaunas, ERT and GPR data indicate an anomaly in the western part of the cemetery, and ERT data further indicate two other possible mass graves. In Liepaja, preliminary GPR analysis indicates an anomaly in a cleared section of the cemetery. Based on the presence of geophysical anomalies in all three cemeteries, which correlate with literature sources and Holocaust survivor testimony, there is a high probability that mass graves are present at each site. Future research directions include expanding the search areas in each cemetery, additional literature and testimony-based research, and the addition of other geophysical methodologies. Full article

This study focused on the detection of water inrush in tunnels excavated by full-section hard rock tunnel boring machines (TBMs) and employed ground penetrating radar methods for conducting research on radar signal processing algorithms. The research demonstrates that conventional techniques are inadequate for eliminating the interference of TBM equipment on radar signal propagation. This study employs a radar antenna array method for signal transmission, utilizing a wavelet double-threshold filtering algorithm and wave propagation theory to suppress clutter. These methods exhibit strong signal reception capabilities and are effective in eliminating 13.1% of the direct wave components. The adoption of a novel, efficient radar signal imaging algorithm simplifies the imaging process. Results of verification indicate that the synthetic aperture algorithm, enhanced with cross-correlation calculation, yields the optimal imaging effect. This investigation, which was conducted in conjunction with the construction of a diversion tunnel in a specific region, has confirmed the applicability of the ground penetrating radar method for the detection of water inrush in TBM tunnels by conducting a comparative analysis of the direct wave removal algorithm and the integration of the optimal imaging algorithm. The innovative application of ground penetrating radar within TBM tunnels, along with a targeted technology to mitigate signal interference from metal equipment, has led to the selection of an appropriate algorithm for both signal processing and imaging. This approach offers a novel solution for the detection of water source disasters in TBM tunnels. Full article

Since Mars is far away from Earth, the propagation delay between Mars and Earth is very large. To ensure the effective use of the link transmission bandwidth, China’s first Mars exploration mission has put forward a demand for data compression for all scientific payloads. The on-board mature algorithms for data compression are mainly focused on optical images and microwave imaging radar applications. No articles have been published on data compression methods that are applied to subsurface-penetrating radar. Based on the background of this application, this paper proposes a logarithmic lossy compression algorithm which can meet the mission requirements for high compression ratios of 4:1 and 2.5:1. Its compression error is less than that of the block adaptive quantization (BAQ) algorithm. The algorithm is not only easy to implement on field-programmable gate array (FPGA) platforms, but also offers simple ground decompression and fast imaging. The experimental results show that high compression ratios of 4:1 and 2.5:1 can be realized, even if the data in and between traces do not have a strong correlation. And its relative error is less than 2%, which is a new type of high-efficiency data compression method that can be implemented on-board to meet with the demand of subsurface penetrating radar. Full article

Fiber-Reinforced Polymer (FRP) composites have emerged as a promising alternative to conventional steel reinforcements in concrete structures owing to their benefits of corrosion resistance, higher strength-to-weight ratio, reduced maintenance cost, extended service life, and superior durability. However, there has been limited research on non-destructive testing (NDT) methods applicable for identifying damage in FRP-reinforced concrete (FRP-RC) elements. This knowledge gap has often limited its application in the construction industry. Engineers and owners often lack confidence in utilizing this relatively new construction material due to the challenge of assessing its condition. Thus, the main objective of this study is to determine the applicability of two of the most common NDT methods: the Ground-Penetrating Radar (GPR) and Phased Array Ultrasonic (PAU) methods for the detection of damage in FRP-RC elements. Three slab specimens with variations in FRP type (glass-, carbon- and basalt-FRP, i.e., GFRP, CFRP, and BFRP, respectively), bar diameter, bar depths, and defect types were investigated to determine the limitations and detection capabilities of these two NDT methods. The results show that GPR could detect damage in GFRP bars and CFRP strands, but PAU was limited to damage detection in CFRP strands. The findings of this study show the applicability of conventional NDT methods to FRP-RC and at the same time identify the areas with a need for further research. Full article

In the ever-evolving landscape of tomographic imaging algorithms, this literature review explores a diverse array of themes shaping the field’s progress. It encompasses foundational principles, special innovative approaches, tomographic implementation algorithms, and applications of tomography in medicine, natural sciences, remote sensing, and seismology. This choice is to show off the diversity of tomographic applications and simultaneously the new trends in tomography in recent years. Accordingly, the evaluation of backprojection methods for breast tomographic reconstruction is highlighted. After that, multi-slice fusion takes center stage, promising real-time insights into dynamic processes and advanced diagnosis. Computational efficiency, especially in methods for accelerating tomographic reconstruction algorithms on commodity PC graphics hardware, is also presented. In geophysics, a deep learning-based approach to ground-penetrating radar (GPR) data inversion propels us into the future of geological and environmental sciences. We venture into Earth sciences with global seismic tomography: the inverse problem and beyond, understanding the Earth’s subsurface through advanced inverse problem solutions and pushing boundaries. Lastly, optical coherence tomography is reviewed in basic applications for revealing tiny biological tissue structures. This review presents the main categories of applications of tomography, providing a deep insight into the methods and algorithms that have been developed so far so that the reader who wants to deal with the subject is fully informed. Full article

Different engineering geological and geophysical investigations were performed at the Sopu promontory in the island of Gozo (Malta), involved in an impressive lateral spreading process due to the superimposition of a stiff limestone (ULC) on a ductile clay (BC). The applied techniques include: traditional geological and engineering geological surveys, unmanned aerial vehicles (UAV) survey, electrical resistivity tomography (ERT) survey, ground-penetrating radar (GPR) investigations, single-station seismic ambient noise measurements, and array seismic ambient noise measurements. The integration of the obtained results allowed us to reconstruct a subsoil model of the promontory that includes features related to the local geology of the slope and to the landslide process, as well as to define a conceptual model that describes the main evolution phases of the expansion process. The presence of back-tilted rock blocks with no features of polarization of Rayleigh waves evidenced the different failure mechanism of the rigid UCL plateau at the Sopu promontory with respect to the Selmun promontory, located in the close island of Malta, where the lateral spreading due to the same geological setting tends to produce unstable rock blocks with a toppling mechanism. This result encourages further future observations and analyses of this topic. Full article

This paper describes the development of a new 3D ground-penetrating radar (GPR) acquisition and control technology for road underground diseases with dual-band antenna arrays. The 3D GPR system can be mounted on a vehicle-loading device and used by vehicles to detect road underground diseases at regular speeds. Compared with existing 3D GPR systems, this new type of 3D GPR has the following design features: it has dual-band antenna arrays, including a 16-channel 400 MHz antenna array and an 8-channel 200 MHz antenna array, which not only improves the detection efficiency, but also effectively balances the detection depth and detection resolution. A novel antenna switching method for time division step multiplexing (TDSM) is realized via field programmable gate array (FPGA), which not only avoids the crosstalk of antenna echo signals of different frequencies, but also ensures the interval of the same antenna working time. By combining the advantages of the FPGA and micro-control unit (MCU), and utilizing the high-speed transmission of the network port, the high-speed real-time transmission of the 3D GPR echo data is achieved. Finally, the integration of all software and hardware verified the correctness of the system, with good results. Full article

Among many agricultural practices proposed to cut carbon emissions in the next 30 years is the deposition of carbon in soils as plant matter. Adding rooting traits as part of a sequestration strategy would result in significantly increased carbon sequestration. Integrating these traits into production agriculture requires a belowground phenotyping method compatible with high-throughput breeding (i.e., rapid, inexpensive, reliable, and non-destructive). However, methods that fulfill these criteria currently do not exist. We hypothesized that ground-penetrating radar (GPR) could fill this need as a phenotypic selection tool. In this study, we employed a prototype GPR antenna array to scan and discriminate the root and rhizome mass of the perennial sorghum hybrid PSH09TX15. B-scan level time/discrete frequency analyses using continuous wavelet transform were utilized to extract features of interest that could be correlated to the biomass of the subsurface roots and rhizome. Time frequency analysis yielded strong correlations between radar features and belowground biomass (max R −0.91 for roots and −0.78 rhizomes, respectively) These results demonstrate that continued refinement of GPR data analysis workflows should yield an applicable phenotyping tool for breeding efforts in contexts where selection is otherwise impractical. Full article
