Search Results (20)

Search Parameters:
Keywords = Ohmic drain

Order results
Result details
Results per page
Select all
Export citation of selected articles as:
9 pages, 2176 KB
Article
High Power Density X-Band GaN-on-Si HEMTs with 10.2 W/mm Used by Low Parasitic Gold-Free Ohmic Contact
by Jiale Du, Hao Lu, Bin Hou, Ling Yang, Meng Zhang, Mei Wu, Kaiwen Chen, Tianqi Pan, Yifan Chen, Hailin Liu, Qingyuan Chang, Xiaohua Ma and Yue Hao
Micromachines 2025, 16(9), 1067; https://doi.org/10.3390/mi16091067 - 22 Sep 2025
Viewed by 1300
Abstract
To enhance the RF power properties of CMOS-compatible gold-free GaN devices, this work introduces a kind of GaN-on-Si HEMT with a low parasitic regrown ohmic contact technology. Attributed to the highly doped n+ InGaN regrown layer and smooth morphology of gold-free ohmic [...] Read more.
To enhance the RF power properties of CMOS-compatible gold-free GaN devices, this work introduces a kind of GaN-on-Si HEMT with a low parasitic regrown ohmic contact technology. Attributed to the highly doped n+ InGaN regrown layer and smooth morphology of gold-free ohmic stacks, the lowest ohmic contact resistance (Rc) was presented as 0.072 Ω·mm. More importantly, low RF loss and low total dislocation density (TDD) of the Si-based GaN epitaxy were achieved by a designed two-step-graded (TSG) transition structure for the use of scaling-down devices in high-frequency applications. Finally, the fabricated GaN HEMTs on the Si substrate presented a maximum drain current (Idrain) of 1206 mA/mm, a peak transconductance (Gm) of 391 mS/mm, and a breakdown voltage (VBR) of 169 V. The outstanding material and DC performances strongly encourage a maximum output power density (Pout) of 10.2 W/mm at 8 GHz and drain voltage (Vdrain) of 50 V in active pulse mode, which, to our best knowledge, updates the highest power level for gold-free GaN devices on Si substrates. The power results reflect the reliable potential of low parasitic regrown ohmic contact technology for future large-scale CMOS-integrated circuits in RF applications. Full article
(This article belongs to the Section D:Materials and Processing)
Show Figures

Figure 1

22 pages, 5844 KB
Article
Scaling, Leakage Current Suppression, and Simulation of Carbon Nanotube Field-Effect Transistors
by Weixu Gong, Zhengyang Cai, Shengcheng Geng, Zhi Gan, Junqiao Li, Tian Qiang, Yanfeng Jiang and Mengye Cai
Nanomaterials 2025, 15(15), 1168; https://doi.org/10.3390/nano15151168 - 28 Jul 2025
Cited by 2 | Viewed by 1880
Abstract
Carbon nanotube field-effect transistors (CNTFETs) are becoming a strong competitor for the next generation of high-performance, energy-efficient integrated circuits due to their near-ballistic carrier transport characteristics and excellent suppression of short-channel effects. However, CNT FETs with large diameters and small band gaps exhibit [...] Read more.
Carbon nanotube field-effect transistors (CNTFETs) are becoming a strong competitor for the next generation of high-performance, energy-efficient integrated circuits due to their near-ballistic carrier transport characteristics and excellent suppression of short-channel effects. However, CNT FETs with large diameters and small band gaps exhibit obvious bipolarity, and gate-induced drain leakage (GIDL) contributes significantly to the off-state leakage current. Although the asymmetric gate strategy and feedback gate (FBG) structures proposed so far have shown the potential to suppress CNT FET leakage currents, the devices still lack scalability. Based on the analysis of the conduction mechanism of existing self-aligned gate structures, this study innovatively proposed a design strategy to extend the length of the source–drain epitaxial region (Lext) under a vertically stacked architecture. While maintaining a high drive current, this structure effectively suppresses the quantum tunneling effect on the drain side, thereby reducing the off-state leakage current (Ioff = 10−10 A), and has good scaling characteristics and leakage current suppression characteristics between gate lengths of 200 nm and 25 nm. For the sidewall gate architecture, this work also uses single-walled carbon nanotubes (SWCNTs) as the channel material and uses metal source and drain electrodes with good work function matching to achieve low-resistance ohmic contact. This solution has significant advantages in structural adjustability and contact quality and can significantly reduce the off-state current (Ioff = 10−14 A). At the same time, it can solve the problem of off-state current suppression failure when the gate length of the vertical stacking structure is 10 nm (the total channel length is 30 nm) and has good scalability. Full article
(This article belongs to the Special Issue Advanced Nanoscale Materials and (Flexible) Devices)
Show Figures

Figure 1

12 pages, 2851 KB
Article
Low Saturation Voltage and High Stability in Dual-Mode Schottky Barrier TFTs Using Bilayer IGZO
by Yi Huang, Xiaoci Liang, Li Zhang, Mengye Wang, Tianyue Wang and Chuan Liu
Electronics 2025, 14(7), 1380; https://doi.org/10.3390/electronics14071380 - 29 Mar 2025
Cited by 1 | Viewed by 1538
Abstract
Schottky barrier thin-film transistors (SBTFTs) are promising for low-power electronics due to advantages such as low saturation voltage and high stability. In this study, we developed a high-performance bilayer IGZO SBTFT by combining a 4.7 nm atomic layer deposition (ALD) IGZO layer with [...] Read more.
Schottky barrier thin-film transistors (SBTFTs) are promising for low-power electronics due to advantages such as low saturation voltage and high stability. In this study, we developed a high-performance bilayer IGZO SBTFT by combining a 4.7 nm atomic layer deposition (ALD) IGZO layer with an 11.8 nm sputtering IGZO layer, using platinum (Pt) and molybdenum (Mo) electrodes. The device exhibits dual-mode operation. In Schottky barrier TFT (SB-TFT) mode (Pt as source), the bilayer structure reduces defect density, achieving a very low saturation voltage (~0.4 V), high field-effect mobility (up to 20 cm2/V·s), and enhanced stability under stress conditions, including positive/negative bias and negative illumination. In quasi-Ohmic TFT (QO-TFT) mode (Pt as drain), the device retains conventional saturation behavior in output characteristics while delivering similar mobility and robust stability. This work provides a novel bilayer SBTFT design with dual functionality, enabling a higher current drive, improved stability, and flexibility for energy-efficient applications. Full article
(This article belongs to the Special Issue Feature Papers in Semiconductor Devices)
Show Figures

Figure 1

11 pages, 1777 KB
Article
Study of Vertical Phototransistors Based on Integration of Inorganic Transistors and Organic Photodiodes
by Jui-Fen Chang, Ying-You Lin and Yu-Ming Li
Micromachines 2024, 15(11), 1397; https://doi.org/10.3390/mi15111397 - 20 Nov 2024
Cited by 2 | Viewed by 2005
Abstract
We investigate the inorganic/organic hybrid vertical phototransistor (VPT) by integrating an atomic layer deposition-processed ZnO (ALD-ZnO) transistor with a prototype poly(3-hexylthiophene):[6,6]-phenyl-C61-butyric acid methyl ester (P3HT:PC61BM) blend organic photodiode (OPD) based on an encapsulated source electrode geometry, and discuss the [...] Read more.
We investigate the inorganic/organic hybrid vertical phototransistor (VPT) by integrating an atomic layer deposition-processed ZnO (ALD-ZnO) transistor with a prototype poly(3-hexylthiophene):[6,6]-phenyl-C61-butyric acid methyl ester (P3HT:PC61BM) blend organic photodiode (OPD) based on an encapsulated source electrode geometry, and discuss the device mechanism. Our preliminary studies on reference P3HT:PC61BM OPDs show non-ohmic electron injection between the ALD-ZnO and P3HT:PC61BM layers. However, the ALD-ZnO layer enables the accumulation of photogenerated holes under negative bias, which facilitates electron injection upon illumination and thereby enhances the external quantum efficiency (EQE). This mechanism underpins the photoresponse in the VPT. Furthermore, we demonstrate that the gate field in the VPT effectively modulates electron injection from the ALD-ZnO layer to the top OPD, resulting in the VPT operating as a non-ohmic OPD in the OFF state and as an ohmic OPD in the ON state. Benefiting from the unique transistor geometry and gate modulation capability, this hybrid VPT can achieve an EQE of 45,917%, a responsivity of 197 A/W, and a specific detectivity of 3.4 × 1012 Jones under 532 nm illumination and low drain-source voltage (Vds = 3 V) conditions. This transistor geometry also facilitates integration with various OPDs and the miniaturization of the ZnO channel area, offering an ideal basis for the development of highly efficient VPTs and high-resolution image sensors. Full article
Show Figures

Figure 1

13 pages, 2816 KB
Article
Optimization of Contact Resistance and DC Characteristics for AlGaN/GaN HEMTs Utilizing Sub-10 nm Nanohole Etching
by Hsin-Jung Lee, Cheng-Che Lee, Hong-Ru Pan and Chieh-Hsiung Kuan
Electronics 2024, 13(13), 2490; https://doi.org/10.3390/electronics13132490 - 25 Jun 2024
Cited by 4 | Viewed by 4391
Abstract
In this paper, the contact resistance of AlGaN/GaN high electron mobility transistor (HEMT) was improved by introducing nanoscale hole arrays in ohmic regions, and the DC characteristics of the conventional structure and nanohole etching structure for HEMTs were measured for comparison. Sub-10 nm [...] Read more.
In this paper, the contact resistance of AlGaN/GaN high electron mobility transistor (HEMT) was improved by introducing nanoscale hole arrays in ohmic regions, and the DC characteristics of the conventional structure and nanohole etching structure for HEMTs were measured for comparison. Sub-10 nm nanoholes were patterned on the ohmic area surface of AlGaN using electron beam lithography and a low-temperature short-time development. Various dwell times of e-beam exposure from 5 to 30 μs were investigated and the corresponding contact resistance of the nano hole etching structure and planar structure were compared by the transmission line model (TLM) method. We observed a reduced contact resistance from 1.82 to 0.47 Ω-mm by performing a dwell time of 5 μs of exposure for nanohole formation compared to the conventional structure. Furthermore, the DC characteristics demonstrate that the maximum drain current for HEMTs was enhanced from 319 to 496 mA/mm by utilizing this optimized ohmic contact. These results show that devices with sub-10 nm nanohole ohmic contacts exhibit an improved contact resistance over the conventional structure, optimizing device performance for HEMTs, including a lower on-resistance and higher maximum drain current. Full article
Show Figures

Figure 1

11 pages, 3364 KB
Article
SiC Fin-Channel MOSFET for Enhanced Gate Shielding Effect
by Ling Sang, Rui Jin, Jiawei Cui, Xiping Niu, Zheyang Li, Junjie Yang, Muqin Nuo, Meng Zhang, Maojun Wang and Jin Wei
Electronics 2024, 13(9), 1701; https://doi.org/10.3390/electronics13091701 - 28 Apr 2024
Cited by 3 | Viewed by 3015
Abstract
A SiC fin-channel MOSFET structure (Fin-MOS) is proposed for an enhanced gate shielding effect. The gates are placed on each side of the narrow fin-channel region, while grounded p-shield regions below the gates provide a strong shielding effect. The device is investigated using [...] Read more.
A SiC fin-channel MOSFET structure (Fin-MOS) is proposed for an enhanced gate shielding effect. The gates are placed on each side of the narrow fin-channel region, while grounded p-shield regions below the gates provide a strong shielding effect. The device is investigated using Sentaurus TCAD. For a narrow fin-channel region, there is difficulty in forming an Ohmic contact to the p-base; a floating p-base might potentially store negative charges upon high drain voltage, and, thus, causes threshold voltage instabilities. The simulation reveals that, for a fin-width of 0.2 μm, the p-shield regions provide a stringent shielding effect against high drain voltage, and the dynamic threshold voltage shift (∆Vth) is negligible. Compared to conventional trench MOSFET (Trench-MOS) and asymmetric trench MOSFET (Asym-MOS), the proposed Fin-MOS boasts the lowest OFF-state oxide field and reverse transfer capacitance (Crss), while maintaining a similar low ON-resistance. Full article
(This article belongs to the Special Issue Wide Bandgap Semiconductor: From Epilayer to Devices)
Show Figures

Figure 1

10 pages, 4841 KB
Article
A 2.8 kV Breakdown Voltage α-Ga2O3 MOSFET with Hybrid Schottky Drain Contact
by Seung Yoon Oh, Yeong Je Jeong, Inho Kang, Ji-Hyeon Park, Min Jae Yeom, Dae-Woo Jeon and Geonwook Yoo
Micromachines 2024, 15(1), 133; https://doi.org/10.3390/mi15010133 - 14 Jan 2024
Cited by 20 | Viewed by 4904
Abstract
Among various polymorphic phases of gallium oxide (Ga2O3), α-phase Ga2O3 has clear advantages such as its heteroepitaxial growth as well as wide bandgap, which is promising for use in power devices. In this work, we demonstrate [...] Read more.
Among various polymorphic phases of gallium oxide (Ga2O3), α-phase Ga2O3 has clear advantages such as its heteroepitaxial growth as well as wide bandgap, which is promising for use in power devices. In this work, we demonstrate α-Ga2O3 MOSFETs with hybrid Schottky drain (HSD) contact, comprising both Ohmic and Schottky electrode regions. In comparison with conventional Ohmic drain (OD) contact, a lower on-resistance (Ron) of 2.1 kΩ mm is achieved for variable channel lengths. Physics-based TCAD simulation is performed to validate the turn-on characteristics of the Schottky electrode region and the improved Ron. Electric-field analysis in the off-state is conducted for both the OD and HSD devices. Furthermore, a record breakdown voltage (BV) of 2.8 kV is achieved, which is superior to the 1.7 kV of the compared OD device. Our results show that the proposed HSD contact with a further optimized design can be a promising drain electrode scheme for α-Ga2O3 power MOSFETs. Full article
(This article belongs to the Special Issue Power Semiconductor Devices and Applications, 2nd Edition)
Show Figures

Figure 1

12 pages, 4378 KB
Article
Improvement of AlGaN/GaN High-Electron-Mobility Transistor Radio Frequency Performance Using Ohmic Etching Patterns for Ka-Band Applications
by Ming-Wen Lee, Cheng-Wei Chuang, Francisco Gamiz, Edward-Yi Chang and Yueh-Chin Lin
Micromachines 2024, 15(1), 81; https://doi.org/10.3390/mi15010081 - 30 Dec 2023
Cited by 8 | Viewed by 3709
Abstract
In this paper, AlGaN/GaN high-electron-mobility transistors (HEMTs) with ohmic etching patterns (OEPs) “fabricated to improve device radio frequency (RF) performance for Ka-band applications” are reported. The fabricated AlGaN/GaN HEMTs with OEP structures were used to reduce the source and drain resistances (R [...] Read more.
In this paper, AlGaN/GaN high-electron-mobility transistors (HEMTs) with ohmic etching patterns (OEPs) “fabricated to improve device radio frequency (RF) performance for Ka-band applications” are reported. The fabricated AlGaN/GaN HEMTs with OEP structures were used to reduce the source and drain resistances (Rs and Rd) for RF performance improvements. Within the proposed study using 1 μm hole, 3 μm hole, 1 μm line, and 3 μm line OEP HEMTs with 2 × 25 μm gate widths, the small signal performance, large signal performance, and minimum noise figure (NFmin) with optimized values were measured for 1 μm line OEP HEMTs. The cut-off frequency (fT) and maximum oscillation frequency (fmax) value of the 1 μm line OEP device exhibited optimized values of 36.4 GHz and 158.29 GHz, respectively. The load–pull results show that the 1 μm line OEP HEMTs exhibited an optimized maximum output power density (Pout, max) of 1.94 W/mm at 28 GHz. The 1 μm line OEP HEMTs also exhibited an optimized NFmin of 1.75 dB at 28 GHz. The increase in the contact area between the ohmic metal and the AlGaN barrier layer was used to reduce the contact resistance of the OEP HEMTs, and the results show that the 1 μm line OEP HEMT could be fabricated, producing the best improvement in RF performance for Ka-band applications. Full article
(This article belongs to the Special Issue III-V Optoelectronics and Semiconductor Process Technology)
Show Figures

Figure 1

11 pages, 7511 KB
Article
Comprehensive Comparison of MOCVD- and LPCVD-SiNx Surface Passivation for AlGaN/GaN HEMTs for 5G RF Applications
by Longge Deng, Likun Zhou, Hao Lu, Ling Yang, Qian Yu, Meng Zhang, Mei Wu, Bin Hou, Xiaohua Ma and Yue Hao
Micromachines 2023, 14(11), 2104; https://doi.org/10.3390/mi14112104 - 16 Nov 2023
Cited by 11 | Viewed by 4290
Abstract
Passivation is commonly used to suppress current collapse in AlGaN/GaN HEMTs. However, the conventional PECV-fabricated SiNx passivation layer is incompatible with the latest process, like the “passivation-prior-to-ohmic” method. Research attention has therefore turned to high-temperature passivation schemes. In this paper, we systematically [...] Read more.
Passivation is commonly used to suppress current collapse in AlGaN/GaN HEMTs. However, the conventional PECV-fabricated SiNx passivation layer is incompatible with the latest process, like the “passivation-prior-to-ohmic” method. Research attention has therefore turned to high-temperature passivation schemes. In this paper, we systematically investigated the differences between the SiNx/GaN interface of two high-temperature passivation schemes, MOCVD-SiNx and LPCVD-SiNx, and investigated their effects on the ohmic contact mechanism. By characterizing the device interface using TEM, we reveal that during the process of MOCVD-SiNx, etching damage and Si diffuses into the semiconductor to form a leakage path and reduce the breakdown voltage of the AlGaN/GaN HEMTs. Moreover, N enrichment at the edge of the ohmic region of the LPCVD-SiNx device indicates that the device is more favorable for TiN formation, thus reducing the ohmic contact resistance, which is beneficial to improving the PAE of the device. Through the CW load-pull test with drain voltage VDS = 20V, LPCVD-SiNx devices obtain a high PAE of 66.35%, which is about 6% higher than MOCVD-SiNx devices. This excellent result indicates that the prospect of LPCVD-SiNx passivation devices used in 5G small terminals will be attractive. Full article
(This article belongs to the Special Issue Latest Advancements in Semiconductor Materials, Devices, and Systems)
Show Figures

Figure 1

18 pages, 7064 KB
Review
Recent Progress in Source/Drain Ohmic Contact with β-Ga2O3
by Lin-Qing Zhang, Wan-Qing Miao, Xiao-Li Wu, Jing-Yi Ding, Shao-Yong Qin, Jia-Jia Liu, Ya-Ting Tian, Zhi-Yan Wu, Yan Zhang, Qian Xing and Peng-Fei Wang
Inorganics 2023, 11(10), 397; https://doi.org/10.3390/inorganics11100397 - 11 Oct 2023
Cited by 13 | Viewed by 7034
Abstract
β-Ga2O3, with excellent bandgap, breakdown field, and thermal stability properties, is considered to be one of the most promising candidates for power devices including field-effect transistors (FETs) and for other applications such as Schottky barrier diodes (SBDs) and solar-blind [...] Read more.
β-Ga2O3, with excellent bandgap, breakdown field, and thermal stability properties, is considered to be one of the most promising candidates for power devices including field-effect transistors (FETs) and for other applications such as Schottky barrier diodes (SBDs) and solar-blind ultraviolet photodetectors. Ohmic contact is one of the key steps in the β-Ga2O3 device fabrication process for power applications. Ohmic contact techniques have been developed in recent years, and they are summarized in this review. First, the basic theory of metal–semiconductor contact is introduced. After that, the representative literature related to Ohmic contact with β-Ga2O3 is summarized and analyzed, including the electrical properties, interface microstructure, Ohmic contact formation mechanism, and contact reliability. In addition, the promising alternative schemes, including novel annealing techniques and Au-free contact materials, which are compatible with the CMOS process, are discussed. This review will help our theoretical understanding of Ohmic contact in β-Ga2O3 devices as well as the development trends of Ohmic contact schemes. Full article
(This article belongs to the Special Issue Advanced Inorganic Semiconductor Materials)
Show Figures

Graphical abstract

11 pages, 2412 KB
Article
Poole–Frenkel (PF)-MOS: A Proposal for the Ultimate Scale of an MOS Transistor
by Hei Wong and Kuniyuki Kakushima
Nanomaterials 2023, 13(3), 411; https://doi.org/10.3390/nano13030411 - 19 Jan 2023
Cited by 14 | Viewed by 3771
Abstract
This work reports, for the first time, the phenomenon of lateral Poole–Frenkel current conduction along the dielectric/Si interface of a silicon nanowire metal-oxide semiconductor (MOS) transistor. This discovery has a great impact on the study of device characteristic modeling and device reliability, leading [...] Read more.
This work reports, for the first time, the phenomenon of lateral Poole–Frenkel current conduction along the dielectric/Si interface of a silicon nanowire metal-oxide semiconductor (MOS) transistor. This discovery has a great impact on the study of device characteristic modeling and device reliability, leading to a new kind of electronic device with a distinct operation mechanism for replacing the existing MOS transistor structure. By measuring the current–voltage characteristics of silicon nanowire MOS transistors with different nanowire widths and at elevated temperatures up to 450 K, we found that the current level in the conventional ohmic region of MOS transistors, especially for the transistors with a nanowire width of 10 nm, was significantly enhanced and the characteristics are no longer linear or in an ohmic relationship. The enhancement strongly depended on the applied drain voltage and strictly followed the Poole–Frenkel emission characteristics. Based on this discovery, we proposed a new type of MOS device: a Poole–Frenkel emission MOS transistor, or PF-MOS. The PF-MOS uses the high defect state Si/dielectric interface layer as the conduction channel and is expected to possess several unique features that have never been reported. PF-MOS could be considered as the ultimate MOS structure from a technological point of view. In particular, it eliminates the requirement of a subnanometer gate dielectric equivalent oxide thickness (EOT) and eradicates the server mobility degradation issue in the sub-decananometer nanowires. Full article
(This article belongs to the Special Issue Abridging the CMOS Technology II)
Show Figures

Figure 1

18 pages, 4420 KB
Review
Process of Au-Free Source/Drain Ohmic Contact to AlGaN/GaN HEMT
by Lin-Qing Zhang, Xiao-Li Wu, Wan-Qing Miao, Zhi-Yan Wu, Qian Xing and Peng-Fei Wang
Crystals 2022, 12(6), 826; https://doi.org/10.3390/cryst12060826 - 10 Jun 2022
Cited by 17 | Viewed by 13294
Abstract
AlGaN/GaN high electron mobility transistors (HEMTs) are regarded as promising candidates for a 5G communication system, which demands higher frequency and power. Source/drain ohmic contact is one of the key fabrication processes crucial to the device performance. Firstly, Au-contained metal stacks combined with [...] Read more.
AlGaN/GaN high electron mobility transistors (HEMTs) are regarded as promising candidates for a 5G communication system, which demands higher frequency and power. Source/drain ohmic contact is one of the key fabrication processes crucial to the device performance. Firstly, Au-contained metal stacks combined with RTA high-temperature ohmic contact schemes were presented and analyzed, including process conditions and contact formation mechanisms. Considering the issues with the Au-contained technique, the overview of a sequence of Au-free schemes is given and comprehensively discussed. In addition, in order to solve various problems caused by high-temperature conditions, novel annealing techniques including microwave annealing (MWA) and laser annealing (LA) were proposed to form Au-free low-temperature ohmic contact to AlGaN/GaN HEMT. The effects of the annealing method on surface morphology, gate leakage, dynamic on-resistance (RON), and other device characteristics are investigated and presented in this paper. By using a low-temperature annealing atmosphere or selective annealing method, gate-first Si-CMOS compatible AlGaN/GaN HEMT technology can be realized for high frequency and power application. Full article
(This article belongs to the Special Issue Recent Advances in III-Nitride Semiconductors)
Show Figures

Figure 1

7 pages, 2055 KB
Article
A Direct n+-Formation Process by Magnetron Sputtering an Inter-Layer Dielectric for Self-Aligned Coplanar Indium Gallium Zinc Oxide Thin-Film Transistors
by Xinlv Duan, Congyan Lu, Xichen Chuai, Qian Chen, Guanhua Yang and Di Geng
Micromachines 2022, 13(5), 652; https://doi.org/10.3390/mi13050652 - 19 Apr 2022
Cited by 11 | Viewed by 2847
Abstract
An inter-layer dielectric (ILD) deposition process to simultaneously form the conductive regions of self-aligned (SA) coplanar In-Ga-Zn-O (IGZO) thin-film transistors (TFTs) is demonstrated. N+-IGZO regions and excellent ohmic contact can be obtained without additional steps by using a magnetron sputtering process [...] Read more.
An inter-layer dielectric (ILD) deposition process to simultaneously form the conductive regions of self-aligned (SA) coplanar In-Ga-Zn-O (IGZO) thin-film transistors (TFTs) is demonstrated. N+-IGZO regions and excellent ohmic contact can be obtained without additional steps by using a magnetron sputtering process to deposit a SiOx ILD. The fabricated IGZO TFTs show a subthreshold swing (SS) of 94.16 mV/decade and a linear-region field-effect mobility (μFE) of 23.06 cm2/Vs. The channel-width-normalized source/drain series resistance (RSDW) extracted using the transmission line method (TLM) is approximately as low as 9.4 Ω·cm. The fabricated ring oscillator (RO) with a maximum oscillation frequency of 1.75 MHz also verifies the applicability of the TFTs. Full article
Show Figures

Figure 1

23 pages, 6146 KB
Article
Electronic Sensing Platform (ESP) Based on Open-Gate Junction Field-Effect Transistor (OG-JFET) for Life Science Applications: Design, Modeling and Experimental Results
by Abbas Panahi, Deniz Sadighbayan and Ebrahim Ghafar-Zadeh
Sensors 2021, 21(22), 7491; https://doi.org/10.3390/s21227491 - 11 Nov 2021
Cited by 8 | Viewed by 4741
Abstract
This paper presents a new field-effect sensor called open-gate junction gate field-effect transistor (OG-JFET) for biosensing applications. The OG-JFET consists of a p-type channel on top of an n-type layer in which the p-type serves as the sensing conductive layer between two ohmic [...] Read more.
This paper presents a new field-effect sensor called open-gate junction gate field-effect transistor (OG-JFET) for biosensing applications. The OG-JFET consists of a p-type channel on top of an n-type layer in which the p-type serves as the sensing conductive layer between two ohmic contacted sources and drain electrodes. The structure is novel as it is based on a junction field-effect transistor with a subtle difference in that the top gate (n-type contact) has been removed to open the space for introducing the biomaterial and solution. The channel can be controlled through a back gate, enabling the sensor’s operation without a bulky electrode inside the solution. In this research, in order to demonstrate the sensor’s functionality for chemical and biosensing, we tested OG-JFET with varying pH solutions, cell adhesion (human oral neutrophils), human exhalation, and DNA molecules. Moreover, the sensor was simulated with COMSOL Multiphysics to gain insight into the sensor operation and its ion-sensitive capability. The complete simulation procedures and the physics of pH modeling is presented here, being numerically solved in COMSOL Multiphysics software. The outcome of the current study puts forward OG-JFET as a new platform for biosensing applications. Full article
(This article belongs to the Special Issue Advanced Field-Effect Sensors)
Show Figures

Figure 1

9 pages, 2853 KB
Article
Optimization of Oxygen Plasma Treatment on Ohmic Contact for AlGaN/GaN HEMTs on High-Resistivity Si Substrate
by Pengfei Li, Shuhua Wei, Xuanwu Kang, Yingkui Zheng, Jing Zhang, Hao Wu, Ke Wei, Jiang Yan and Xinyu Liu
Electronics 2021, 10(7), 855; https://doi.org/10.3390/electronics10070855 - 3 Apr 2021
Cited by 8 | Viewed by 6271
Abstract
The oxygen plasma surface treatment prior to ohmic metal deposition was developed to reduce the ohmic contact resistance (RC) for AlGaN/GaN high electron mobility transistors (HEMTs) on a high-resistive Si substrate. The oxygen plasma, which was produced by an inductively coupled [...] Read more.
The oxygen plasma surface treatment prior to ohmic metal deposition was developed to reduce the ohmic contact resistance (RC) for AlGaN/GaN high electron mobility transistors (HEMTs) on a high-resistive Si substrate. The oxygen plasma, which was produced by an inductively coupled plasma (ICP) etching system, has been optimized by varying the combination of radio frequency (RF) and ICP power. By using the transmission line method (TLM) measurement, an ohmic contact resistance of 0.34 Ω∙mm and a specific contact resistivity (ρC) of 3.29 × 10–6 Ω∙cm2 was obtained with the optimized oxygen plasma conditions (ICP power of 250 W, RF power of 75 W, 0.8 Pa, O2 flow of 30 cm3/min, 5 min), which was about 74% lower than that of the reference sample. Atomic force microscopy (AFM), energy dispersive X-ray spectroscopy (EDX), and photoluminescence (PL) measurements revealed that a large nitrogen vacancy, which was induced near the surface by the oxygen plasma treatment, was the primary factor in the formation of low ohmic contact. Finally, this plasma treatment has been integrated into the HEMTs process, with a maximum drain saturation current of 0.77 A/mm obtained using gate bias at 2 V on AlGaN/GaN HEMTs. Oxygen plasma treatment is a simple and efficient approach, without the requirement of an additional mask or etch process, and shows promise to improve the Direct Current (DC) and RF performance for AlGaN/GaN HEMTs. Full article
(This article belongs to the Section Semiconductor Devices)
Show Figures

Figure 1
