Search Results (30)

The analysis of ground-penetrating radar data generally relies on the visual identification of structures on selected profiles and their interpretation in terms of buried features. In simple cases, inverse modelling of the acquired data set can facilitate interpretation and reduce subjectivity. These methods suffer from severe restrictions due to antenna resolution limits, which prevent the identification of tiny structures, particularly in forensic, stratigraphic, and engineering applications. Here, we describe a technique to obtain a high-resolution characterization of the underground, based on the forward modelling of individual traces (A-scans) of selected radar profiles. The model traces are built by superposition of Ricker wavelets with different polarities, amplitudes, and arrival times and are used to create reflectivity diagrams that plot reflection amplitudes and polarities versus depth. A thin bed is defined as a layer of higher or lower permittivity relative to the surrounding material, such that the top and bottom reflections are subject to constructive interference, determining the formation of an anomalous peak in the trace (tuning effect). The proposed method allows the detection of ultra-thin layers, well beyond the Rayleigh vertical resolution of GPR antennas. This approach requires a preliminary estimation of the instrumental uncertainty of common monostatic antennas and takes into account the frequency-dependent attenuation, which causes a spectral shift of the dominant frequency acquired by the receiver antenna. Such a quantitative approach to analyzing radar data can be used in several applications, notably in stratigraphic, forensic, paleontological, civil engineering, heritage protection, and soil stratigraphy applications. Full article

The Cathedral of San Giorgio, a chief example of Baroque architecture in Sicily (Italy), has been the focus of extensive geophysical investigations aimed at structural and subsoil characterization to support heritage conservation efforts. This study is among the few to apply a high-resolution Ground Penetrating Radar (GPR) survey to the pillars of a Baroque Church, revealing internal structural details not documented in any available historical sources. Using a 2 GHz antenna, parallel radar profiles, spaced 0.05 m apart in both directions, were collected to reconstruct a detailed 3D model of the internal structure. Depth-slice and 3D-view analyses revealed multiple reflector sets corresponding to the different masonry blocks forming the pillars. Distinct internal layers were identified at depths of 0.22–0.30 m and 0.40–0.55 m, indicating blocks approximately 0.20–0.30 m in height and the possible presence of vertical connectors. These results complement previous studies that defined the dynamic parameters of the structure and a 3D velocity model of the subsoil, which suggested anomalies linked to remnants of the ancient Byzantine church of San Nicola. Overall, the findings provide valuable insights into the construction techniques and current condition of the pillars, contributing essential data for the planning of conservation and restoration strategies. Full article

Ground-penetrating radar (GPR), due to its efficiency and non-invasive nature, has become an important tool for detecting the permafrost table, overcoming the limited spatial coverage and high costs associated with drilling and in situ temperature monitoring. Compared with the commonly used 50–100 MHz antennas, the potential of high-frequency antennas to improve detection accuracy and interface resolution has not been fully explored. To address this gap, this study introduces a multi-strategy interface identification method incorporating envelope analysis. Field experiments were conducted in the island-like permafrost zone of the Da Xing’anling Mountains, Heilongjiang Province, using shielded GPR systems operating at 250 MHz and 500 MHz to detect the permafrost table. Potential interfaces were extracted using centroid and edge-detection algorithms and validated against ground temperature observations. The results indicate that: (1) integrating GPR with multi-source data enables accurate estimation of active layer thickness, and the envelope-based multi-strategy approach is effective for interface identification; (2) the 250 MHz antenna is better suited for capturing broader subsurface structures, while the 500 MHz antenna provides higher resolution for shallow layers—combining the two enhances overall interpretive quality; and (3) snow cover significantly affects electromagnetic wave propagation, reducing the accuracy of radar detection. This study provides valuable guidance for engineering investigations, site selection, and foundation design in permafrost regions, contributing to improved precision and efficiency in GPR-based detection of the permafrost table. Full article

The acoustically actuated antenna technology enables a significant reduction in antenna dimension, facilitating miniaturization of ground-penetrating radar systems in the very high-frequency (VHF) band. However, the current acoustically actuated antennas suffer from narrow bandwidth and low range resolution. To address this issue, this paper proposed a three-dimensional (3D) localization method for underground targets, which combined two-dimensional (2D) array direction-of-arrival (DOA) estimation with continuous spatial sampling without relying on range resolution. By leveraging the small dimension of acoustically actuated antennas, a 2D uniform linear array was formed to obtain the target’s angle using DOA estimation. Based on the variation pattern of 2D angles in continuous spatial sampling, the genetic algorithm was employed to estimate the 3D coordinates of underground targets. The numerical simulation results indicated that the root mean square error (RMSE) of the proposed 3D localization method is 1.68 cm, which outperforms conventional methods that utilize wideband frequency-modulated pulse signals with hyperbolic vertex detection in theoretical localization accuracy, while also demonstrating good robustness. The gprMax electromagnetic simulation results further confirmed that this method can effectively localize multiple targets in ideal homogeneous underground media. Full article

Ground-based ground-penetrating radar (GPR) has been applied successfully for decades in archaeological geophysics. However, there are sometimes severe problems arising in cases of rough terrain, permission to enter a site, or due to vegetation. Other issues may also make it impossible to use conventional ground-based GPR. Therefore, mounting the GPR antenna below a drone could be a potential alternative. Successful applications of drone-based GPR have already been reported, e.g., in the fields of geological mapping, glaciology, and UXO-detection. However, it is not clear whether faint archaeological remains can also be mapped using this approach. In the survey discussed below, we tested such a drone-based GPR setup at an archaeological site in Bavaria, where well-preserved Roman foundations at a shallow depth are known from previous geophysical surveys with magnetics and ground-based GPR. The aim was to evaluate the possibilities and problems arising with this new approach through a comparison with the afore-mentioned data, obtained in previous ground-based surveys of this site. The results show that under certain circumstances, the archaeological remains can be resolved while using a drone. However, the remains are much harder to detect with a lower degree of resolution and survey setup and acquisition time play a crucial role for a successful survey. Especially relevant are two factors: First, the correct choice of profile orientation, as there are strong reflections caused by near-surface features (like field boundaries) due to decoupling the antenna from the ground. Second, a very dry soil is mandatory, as otherwise too much signal is lost at the air-ground-interface. Considering these factors, drone-based GPR represents a valuable tool for modern archaeological geophysics. Full article

Ground-Penetrating Radar (GPR) systems with ultra-wideband (UWB) antennas introduce the benefits of both high and low frequencies. Higher frequencies offer finer spatial resolution, enabling the detection of small-scale features and details, while lower frequencies improve depth penetration by minimising signal attenuation, allowing the system to explore deeper subsurface layers. This combination optimises the performance of GPR systems by balancing the need for detailed imaging with the requirement for deeper penetration. This work presents the design of a wideband inverted U-shaped patch antenna with a wide rectangular slot centred at a frequency of 1.5 GHz. The antenna is fed through a microstrip feed line and employs a partial ground plane. Through simulation, the antenna is optimised by varying the patch dimensions and slot size. Further modifications to the partial ground plane improve the UWB and gain characteristics of the antenna. The optimised antenna is fabricated using a double-sided copper-clad FR4 substrate with a thickness of 1.6 mm and characterised using a Vector Network Analyser (VNA), with final dimensions of 200 mm × 300 mm. The experimental results demonstrate a return loss below −10 dB across the operational band from 1.068 GHz to 4 GHz and a maximum gain of 7.29 dB at 4 GHz. In addition to other bands, the antenna exhibits a return loss consistently below −20 dB in the frequency range of 1.367 GHz to 1.675 GHz. These results confirm the antenna’s UWB performance and its suitability for GPR applications in utility mapping, landmine and artefact detection, and identifying architectural defects. Full article

This study investigates the detectability of a putative layer of regolith containing water ice in the lunar polar regions using ground penetrating radar (GPR). Numerical simulations include realistic variations in the relative permittivity of the lunar regolith, considering both density and, for the first time, the effects of temperature on permittivity profiles. We follow the case of previous theoretical studies of water migration, which suggest that water ice accumulates at depths ranging from a few centimeters to tens of centimeters, appropriate depths to explore using GPR. In particular, frequency-modulated continuous wave (FMCW) radar is well-suited for this purpose due to its high range resolution and robust signal-to-noise ratio. This study evaluates two scenarios for the presence of lunar water ice: (1) a layer of regolith containing water ice at a depth of 5 cm, with a thickness of 5 cm, and (2) a layer of regolith containing water ice at a depth of 20 cm, with a thickness of 10 cm. Our computational results show that FMCW GPR, equipped with a dynamic range of 90 dB, is capable of detecting reflections from the interfaces of these layers, even under conditions of low water ice content and using antennas with low directivity. In addition, optimized antenna offsets improve the resolution of the upper and lower interfaces, particularly when applied to the surface of ancient crater ejecta. This study highlights the critical importance of understanding subsurface density and temperature structures for the accurate detection of water-ice-bearing regolith layers. Full article

The quality of newly constructed pavement depends mostly on compaction, which is essential for ensuring the pavement’s longevity and performance. Traditional methods of evaluating pavement compaction and density, such as core sampling and nuclear gauge measurements, are often time-consuming and invasive and provide only a limited amount of data at a low spatial resolution on the potential air void content of the asphalt layers. The present study aimed to assess the specific gravity (G_mb) of a dolomitic asphalt mixture at different degrees of compaction using GPR techniques. Relative density (RD) maps were generated to visualize the spatial homogeneity of the asphalt density. Nuclear density gauging was applied for the calibration, and cores were used to validate the results. The survey was conducted on two recently paved roads in Szeged, Hungary. After testing various approaches, it was found that applying horn antennas and the surface reflection (SR) method is the most feasible way to obtain reliable and accurate dielectric permittivity (ε) data. Based on the measurements, clear relationships were found between dielectric constants, G_mb, and aggregate size. The findings highlight that it is possible to indirectly determine the G_mb of asphalts composed of dolomite and limestone aggregates using GPR, with aggregate sizes ranging from 11 mm to 25 mm and G_mb values between 2.43 and 2.57 g/cm³. Consequently, a robust function was developed, which can be applied to other asphalts with similar compositions. Full article

We present a technique for the detection of vertebrate skeletons buried at shallow depths through the use of a ground-penetrating radar (GPR). The technique is based on the acquisition of high-resolution data by medium-to-high frequency GPR antennas and the analysis of the radar profiles by a new forward modelling method that is applied on a set of representative traces. This approach allows us to obtain synthetic traces that can be used to build detailed reflectivity diagrams that plot spikes with a distinct amplitude and polarity for each reflector in the ground. The method was tested in a controlled experiment performed at the top of Cerro Los Quesos, one of the most fossiliferous localities in the Ica Desert of Peru. We acquired GPR data at the location of a partially buried fossil skeleton of a large whale and analyzed the reflections associated with the bones using the new technique, determining the possible signature of vertebrae, ribs, the cranium (including the rostrum), and mandibles. Our results show that the technique is effective in the mapping of buried structures, particularly in the detection of tiny features, even below the classical (Ricker and Rayleigh) estimates of the vertical resolution of the antenna in civil engineering and forensic applications. Full article

Ground-penetrating radar (GPR) is widely employed as a non-destructive tool for subsurface detection of transport infrastructures. Typically, data collected by high-frequency antennas offer high resolution but limited penetration depth, whereas data from low-frequency antennas provide deeper penetration but lower resolution. To simultaneously achieve high resolution and deep penetration via a composite radargram, a Non-Subsampled Contourlet Transform (NSCT) algorithm-based multifrequency GPR data-fusion method is proposed by integrating NSCT with appropriate fusion rules, respectively, for high-frequency and low-frequency coefficients of decomposed radargrams and by incorporating quantitative assessment metrics. Despite the advantages of NSCT in image processing, its applications to GPR data fusion for concealed damage identification of transport infrastructures are rarely reported. Numerical simulation, tunnel model test, and on-site road test are conducted for performance validation. The comparison between the evaluation metrics before and after fusion demonstrates the effectiveness of the proposed fusion method. Both shallow and deep hollow targets hidden in the simulated concrete structure, real tunnel model, and road are identified through one radargram obtained by fusing different radargrams. The significance of this study is producing a high-quality composite radargram to enable multi-depth concealed damage detection and exempting human interference in the interpretation of multiple radargrams. Full article

The conservation of Cultural Heritage in cave environments, especially those hosting cave art, requires comprehensive conservation strategies to mitigate degradation risks derived from climatic influences and human activities. This study, focused on the Polychrome Hall of the Cave of Altamira, highlights the importance of integrating remote sensing methodologies to carry out effective conservation actions. By coupling a georeferenced Ground Penetrating Radar (GPR) with a 1.6 GHz central-frequency antenna along with photogrammetry, we conducted non-invasive and high-resolution 3D studies to map preferential moisture pathways from the surface of the ceiling to the first 50 cm internally of the limestone structure. In parallel, we monitored the dynamics of surface water on the Ceiling and its correlation with pigment and other substance migrations. By standardizing our methodology, we aim to increase knowledge about the dynamics of infiltration water, which will enhance our understanding of the deterioration processes affecting cave paintings related to infiltration water. This will enable us to improve conservation strategies, suggesting possible indirect measures to reverse active deterioration processes. Integrating remote sensing techniques with geospatial analysis will aid in the validation and calibration of collected data, allowing for stronger interpretations of subsurface structures and conditions. All of this puts us in a position to contribute to the development of effective conservation methodologies, reduce alteration risks, and promote sustainable development practices, thus emphasizing the importance of remote sensing in safeguarding Cultural Heritage. Full article

This article discusses the methods and results of assessing the angular resolution and sounding depth of enhanced-power ground penetration radars obtained during archaeological and geographical expeditionary works in various natural areas. Elongated local objects were used as test objects to evaluate the horizontal radiation pattern of the Loza–V georadar in the upper- and lower-half spaces. The depth of operation of the Loza–N low-frequency radar was estimated during a geophysical study of a unique natural object in the Siberian taiga. The variability of the GPR antenna radiation patterns in different materials (air, dry, or wet soils) confirms the necessity of quantitative measurements with controlled electrophysical parameters. Full article

This paper describes the development of a new 3D ground-penetrating radar (GPR) acquisition and control technology for road underground diseases with dual-band antenna arrays. The 3D GPR system can be mounted on a vehicle-loading device and used by vehicles to detect road underground diseases at regular speeds. Compared with existing 3D GPR systems, this new type of 3D GPR has the following design features: it has dual-band antenna arrays, including a 16-channel 400 MHz antenna array and an 8-channel 200 MHz antenna array, which not only improves the detection efficiency, but also effectively balances the detection depth and detection resolution. A novel antenna switching method for time division step multiplexing (TDSM) is realized via field programmable gate array (FPGA), which not only avoids the crosstalk of antenna echo signals of different frequencies, but also ensures the interval of the same antenna working time. By combining the advantages of the FPGA and micro-control unit (MCU), and utilizing the high-speed transmission of the network port, the high-speed real-time transmission of the 3D GPR echo data is achieved. Finally, the integration of all software and hardware verified the correctness of the system, with good results. Full article

Bow-tie antennas are utilized extensively in ground-penetrating radar (GPR) systems. In order to achieve sufficient penetration depth and resolution, the bow-tie antennas for GPR applications require low operating frequency, high gain, and excellent broadband. A novel ultra-wideband (UWB) bow-tie antenna with gain enhancement for GPR applications is proposed in this paper. First, a UWB bow-tie antenna with resistive loading is designed. The metal reflector and metamaterial loading make the bow-tie antenna directional, and loading the same metamaterial on the front side of the antenna further improves directional gain. After testing, the lowest frequency of the fabricated antenna is 317 MHz, the relative bandwidth is 98.6%, the peak gain in the frequency range is 9.3 dBi, and the size is only 0.38 λ at the lowest frequency. The proposed compact antenna takes both gain and bandwidth into consideration. Finally, in order to further verify the effectiveness of the proposed antenna in the GPR system, a stepped frequency continuous wave ground-penetrating radar (SFCW-GPR) system was built. The experimental results show that the designed antenna is suitable for the GPR system of deep penetration and high-resolution detection, which is beneficial to the imaging of underground structures. Full article

Although geomorphic evidence and shallow geometry of active faults are significant for the understanding and assessing of fault activity and seismic hazards, it is challenging to acquire high-resolution topographic data and shallow geometry of the Yushu fault by conventional methods. Here, we present a case study to reconstruct the detailed surficial and subsurface geometry of the Yushu fault using terrestrial laser scanning (TLS), multi-frequency ground penetrating radar (GPR) and trenching. TLS was suitable for measuring the high-resolution three-dimensional (3D) topographic data of the fault. GPR surveys with different frequency antennas (25 MHz, 100 MHz, 250 MHz and 500 MHz) were conducted to image the shallow geometry of active faults at different depths and spatial resolutions. The typical groove landscape, parallel to surface traces of the fault, was clearly observed on the TLS-derived data. A ~40 m width narrow fault system and three faults were identified on the different frequency GPR profiles. Furthermore, faults F₁ and F₂ were supposed to be boundary faults but were sinistral-lateral strike-slip faults with a normal component, while fault F₃ was inferred as the secondary fault. The western trench section, despite the limited investigation depth (~2 m), was well consistent with the 500 MHz GPR result, especially in the location of fault F₂. Finally, a 3D surficial and subsurface model was established from the TLS-derived data and GPR data offering multi-sensor and multi-view spatial data to characterize and understand the fault’s kinematics and characteristics. In addition, the shallow geometry of the fault on the GPR results would be better interpreted with the help of the corresponding surficial data. The study results demonstrate that a combination of TLS, multi-frequency GPRs and trenching can be successfully used for reconstructing a detailed surficial and subsurface geometry of the Yushu fault. It will play an increasing role in comprehensive understanding and assessing fault behavior and seismic hazards, especially on the Tibetan Plateau and the adjacent area. Full article
