This paper presents a corrugated Vivaldi antenna architecture targeting sub-6 GHz and millimeter-wave frequency bands for 5G CubeSat applications, combining experimental validation at sub-6 GHz with a simulation-based scaling study at 26.5 GHz. Existing CubeSat antenna designs either target a single frequency band or rely on complex metamaterial structures incompatible with nanosatellite fabrication constraints. To address this gap, a single-element corrugated Vivaldi antenna measuring 90 mm × 80 mm is designed, fabricated on FR-4 substrate, and experimentally validated at 3.5 GHz, confirming a wide impedance bandwidth of 2.75 GHz and a peak gain of 9.6 dBi. The strong agreement between CST Studio Suite simulations and measurements validates the electromagnetic solver configuration, which is subsequently applied, as a simulation-based design study, to a geometrically scaled version on Taconic RF-60A substrate operating at 26.5 GHz. The miniaturized single-element version achieves a simulated 17 GHz ultra-wideband response and 6 dBi gain in a 7.32 mm × 6.32 mm footprint. Two- and four-element array configurations at 26.5 GHz demonstrate systematic simulated gain progression to 9 dBi and 13 dBi, respectively, with beamwidth narrowing from 49° to 30°. All 26.5 GHz designs are simulated with lossy copper metallization ($\sigma =5.8\times {10}^7$ S/m) and are entirely simulation-based; experimental mmWave validation is a designated target for future work. These results establish a validated design and scaling roadmap for corrugated Vivaldi antennas spanning sub-6 GHz and millimeter-wave bands, offering a cost-effective and CubeSat-compatible solution for high-data-rate inter-satellite communication links. Full article

There is a substantial demand for lightweight, low-profile, and conformal antenna integration on the wing platforms of unmanned aerial vehicles (UAVs). This paper presents an S-band (2–4 GHz) flexible conformal metasurface array antenna based on a highly conductive graphene-assembled film (GAF). The main contributions of this work are twofold. First, flexible and highly conductive GAF is used as the conductor together with a flexible polyimide (PI) dielectric substrate to form a GAF-based wing-conformal antenna configuration with a low-profile, lightweight, and easily conformal performance. Second, a GAF conformal antenna element is developed by combining a dipole antenna with a directive and reflective frequency selective surface (FSS), achieving effective control of the beam and stable directional radiation at 2.4 GHz. Full-wave simulations using CST Studio Suite show that the directive FSS narrows the feed beam, whereas the reflective FSS redirects and narrows the H-plane radiation. The simulated results show that the integrated wing-conformal antenna operates over 2.19–2.65 GHz and achieves a gain of 4.65 dBi at 2.4 GHz. The measurement results indicate that the GAF conformal antenna and 1 × 4 GAF conformal array antenna shows measured reflection coefficients below $-10$ dB at 2.4 GHz and effective adjacent-element isolation. In addition, simulated results indicate that the GAF array antenna can perform beam scanning within the ±40° range, verifying the beam-control capability of this structure for UAV forward communication. Overall, this work highlights the feasibility of using GAF as a conductive material for both a high-efficiency radiator and an FSS beamforming structure, offering a practical material and design approach for lightweight, low-profile, and wing-conformal airborne array antennas. Full article

Polyolefin bonding technologies with metal foils are extensively employed in various sectors, particularly in automotive, electronics, and aerospace industries. This research examined the innovative electromagnetic joining of polyolefins to aluminum by evaluating the behavior of hot-melt adhesives derived from polyolefins containing metallic particles. The study aimed at establishing the specific absorption rate (SAR, expressed in W/kg) via electromagnetic simulation using CST Studio Suite software. It was observed that, regardless of particle size, Al was the most efficient particle, while the distribution of particles has a negligible impact on Total SAR values. The most significant beneficial effect of the inserts on the absorption capacity of the hot-melt material is primarily observed with a particle size of 1 μm. When connecting polyolefins to aluminum, the power loss density and SAR values exceed those for bonding polyolefins to polyolefins by at least 10 times, owing to aluminum’s conductive properties, which influence the absorption of additional energy in the hot melt mass, likely due to the Salisbury screen effect generated by the bonding arrangement. For hot melts made from polyethylene, a higher frequency of 5.8 GHz is suggested, which is a newly approved frequency used in advanced industrial applications. This positively impacts the effectiveness and viability of the bonding process of polyolefins to aluminum, resulting in reduced exposure times and/or decreased microwave exposure power. It was observed that the hot melts derived from HDPE and PP yielded greater SAR values. Conversely, the SAR values increase when aluminum is attached to HDPE. As a result, the strongest bond of polyolefins to Al occurs when connecting HDPE to Al using HDPE-based hot melts. The proposed simulation methodology may offer considerable improvement in evaluating the efficacy of bonding technology for dissimilar materials subjected to electromagnetic energy Full article

This study investigates the “soft-kill” mechanism of unmanned aerial vehicles (UAVs) under high-power electromagnetic pulse (EMP) exposure. Unlike previous research focused on hardware destruction, we identify flight control paralysis caused by Pulse Width Modulation (PWM) signal logic threshold violation as the primary failure mode. To resolve discrepancies between theory and experiment, a 1 × 1 m loop antenna model was implemented in CST Studio Suite. Results demonstrate that EMP coupling in drone arm wiring predominantly generates differential mode (DM) noise. This explains why conventional ferrite beads fail while full-body shielding remains effective. Our findings provide a theoretical basis for low-power anti-drone system optimization and hardened UAV design guides. Full article

This study proposes a high-isolation four-port wideband MIMO antenna array designed for sub-6 GHz 5G, IoT, and radar applications. The array is fabricated on a polycarbonate substrate with overall dimensions of 500 × 500 mm² (ε_r = 2.8, h = 1 mm). Four orthogonally arranged modified circular patches with triangular ground planes and optimized inter-element spacing (D₁ = 90 mm) are employed in the antenna’s design to achieve an impedance bandwidth of 0.7–7.0 GHz (Fractional Bandwidth (FBW) > 163.63%) with |S_ii| < −10 dB across all ports. The measurement results indicate that the inter-port isolation is better than 15 dB (worst-case) across the 0.7–7 GHz band, exceeding 25 dB over 63.5% of the bandwidth (with a peak of approximately 50 dB); the envelope correlation coefficient (ECC) is ultra-low (<0.008); the total active reflection coefficient (TARC) is less than −10 dB for primary multi-port excitations; the mean effective gain (MEG) is balanced (≈−3 dB); and the group delay is consistent (~0.5 ns). With a maximum realized gain of 10 dBi, the antenna exhibits omnidirectional radiation patterns, showing a significant correlation between the simulation (CST Microwave Studio) and measurement results. The proposed antenna is particularly well-suited for use in high-throughput sub-6 GHz 5G base stations and wideband wireless systems, offering superior port isolation through multi-mode resonance without the need for metamaterials and outperforming existing four-port designs. Full article

This paper presents a systematic numerical investigation of a hybrid plasmonic–photonic Panda-ring antenna with an embedded gold grating, designed to enable efficient dual-mode radiation for optical and terahertz communication systems. The proposed structure integrates high-Q whispering-gallery mode (WGM) confinement in a multi-ring dielectric resonator with plasmonic out-coupling at the metal–dielectric interface, allowing controlled conversion of resonantly stored photonic energy into free-space radiation. The electromagnetic behavior is analyzed through a hierarchical structural evolution, progressing from a linear silicon waveguide to single-ring, add–drop, and Panda-ring resonator configurations. Gold is modeled using a dispersive Drude formulation with complex permittivity to accurately capture frequency-dependent plasmonic response at 1.55 µm. Power redistribution within the resonator system is described using coupled-mode theory, with coupling and loss parameters evaluated consistently from full-wave numerical simulations. Full-wave simulations using OptiFDTD and CST Studio Suite demonstrate that purely photonic resonators exhibit strong WGM confinement but negligible radiation, while plasmonic gratings alone suffer from low efficiency due to the absence of coherent photonic excitation. In contrast, the proposed hybrid Panda-ring antenna achieves stable and directive far-field radiation under WGM excitation, with a realized gain of approximately 8.05 dBi at 193.5 THz. The performance enhancement originates from synergistic hybrid SPP–WGM coupling, establishing a WGM-driven radiation mechanism suitable for Li-Fi and terahertz wireless applications. Full article

FLASH radiotherapy requires real-time, non-invasive beam monitoring systems capable of operating under ultra-high dose rate (UHDR) conditions without perturbing the therapeutic beam. In this work, we characterized the extraction system of Supersonic Gas Curtain-based Ionization Profile Monitor (SGC-IPM) for its capabilities as a transverse beam profile and position monitor for FLASH protons. The monitor utilizes a tilted gas curtain intersected by the incident beam, leading to the generation of ions that are extracted through a tailored electrostatic field, and detected using a two stage microchannel plate (MCP) coupled to a phosphor screen and CMOS camera. CST Studio Suite was employed to conduct electrostatic and particle tracking simulations evaluating the ability of the extraction system to measure both beam profile and position. The ion interface, at the interaction region of proton beam and gas curtain, was modeled with realistic proton beam parameters and uniform gas curtain density distributions. The ion trajectory was tracked to evaluate the performance across multiple beam sizes. The simulations suggest that the extraction system can reconstruct transverse beam profiles for different proton beam sizes. Simulations also supported the system’s capability as a beam position monitor within the boundary defined by the beam size, the dimensions of the extraction system, and the height of the gas curtain. Some simulation results were benchmarked against experimental data of 28 MeV proton beam with 70 nA average beam current. This study will further help to optimize the design of the extraction system to facilitate the integration of SGC-IPM in medical accelerators. Full article

This study employs numerical simulations to analyse current densities in modelled human organs originating from extremely low frequency (ELF) electromagnetic fields emanating from a 110 kV single-circuit high-voltage transmission line. Exposure to these ELF fields gives rise to both conduction and displacement currents within the human body, potentially perturbing endogenous bioelectric currents and raising concerns of health risks. Using CST Studio Suite 2018 software, a three-dimensional multipart ellipsoidal anatomical model is developed to analyse these phenomena. Although displacement currents have lower magnitudes than conduction currents, they contribute significantly to the total current density and must therefore be included in rigorous safety assessments. Simulation results indicate that the current density values remain below the basic restrictions of the International Commission on Non-Ionizing Radiation Protection. Full article

Additive manufacturing (AM) offers significant potential for producing complex, cost-effective, and high-performance components in the radio frequency and microwave industry. To significantly benefit from the manufacturing and design freedoms AM offers, AM-based microwave research must shift toward creating designs inherently optimized for AM. This study investigates various AM methods and materials for fabricating a polarizer operating in the K-band, a device widely used in microwave systems and well-suited for AM due to its intricate geometry. Four manufacturing approaches—machining and electroforming, stereolithography and electroless plating, bound metal deposition, and selective laser melting—were evaluated for accuracy, surface quality, and electrical performance. The polarizers were characterized through both single and back-to-back measurements and compared against CST Studio Suite simulations. To better understand discrepancies in performance, further analysis of material properties was conducted using conductivity measurements, skin depth calculations, optical microscopy, and scanning electron microscopy imaging. The results demonstrate that AM techniques can achieve good agreement with simulations and reveal the strengths and limitations of each method, guiding the selection of suitable AM processes for reliable and precise microwave component fabrication in the K-band. Full article

This paper presents an innovative end-to-end framework for conformal antenna array design and beam steering in Low Earth Orbit (LEO) satellite-based IoT communication systems. We propose a multi-stage learning architecture that integrates machine learning (ML) for antenna parameter prediction with reinforcement learning (RL) for adaptive beam steering. The ML module predicts optimal geometric and material parameters for conformal antenna arrays based on mission-specific performance requirements such as frequency, gain, coverage angle, and satellite constraints with an accuracy of 99%. These predictions are then passed to a Deep Q-Network (DQN)-based offline RL model, which learns beamforming strategies to maximize gain toward dynamic ground terminals, without requiring real-time interaction. To enable this, a synthetic dataset grounded in statistical principles and a static dataset is generated using CST Studio Suite and COMSOL Multiphysics simulations, capturing the electromagnetic behavior of various conformal geometries. The results from both the machine learning and reinforcement learning models show that the predicted antenna designs and beam steering angles closely align with simulation benchmarks. Our approach demonstrates the potential of combining data-driven ensemble models with offline reinforcement learning for scalable, efficient, and autonomous antenna synthesis in resource-constrained space environments. Full article

The continuous-wave (CW) illuminator, whose fundamentals are related to the theoretical understanding of loop antennas loaded with ferrite materials, is a device which plays an important role in electromagnetic pulse (EMP) susceptibility assessment. However, existing theoretical formulas do not consider cases where ferrite materials are loaded into the loop antenna. This paper provides a new explicit theoretical formula for the impedance of a circular loop antenna loaded with ferrite materials for CW illuminator design, and explores the variation regularity of its input impedance. Loading ferrite materials affects the internal impedance of the loop antenna and forces some modifications to the classical calculation procedure, resulting in an asymptotic numerical calculation method and a closed-form solution. The full-wave simulation results from CST Studio Suite show a maximum error of less than 0.99%, compared to the classical theory. With ferrite material loaded, the input impedance of the loop antenna is significantly reduced and smoothed in a wide range of normalized radii. For a loop antenna with a fixed circumference, the input impedance indicates that the Q-factor decreases as the thickness of the ferrite material increases. Conversely, for a ferrite-loaded loop antenna with a constant material thickness, a larger loop circumference results in a higher Q-factor. In summary, this study provides a fast and accurate computational method for the input impedance design of CW illuminators, while also offering an effective tool for further research on the performance of ferrite-loaded loop antennas. Full article

This paper presents the design of a wideband circularly polarized crossed-dipole antenna for multi-GNSS applications, covering the frequency range of 1.16–1.61 GHz. The proposed antenna employs orthogonally placed dipole elements fed by a three-branch quadrature hybrid coupler for broadband and wide gain/axial ratio beamwidth. The design is carried out using CST Studio Suite for a single dipole antenna followed by a crossed-dipole antenna, a feed network, and the entire antenna structure. The designed multi-GNSS antenna shows, at 1.16–1.61 GHz, a reflection coefficient of less than −17 dB, a zenith gain of 3.9–5.8 dBic, a horizontal gain of −3.3 to −0.2 dBic, a zenith axial ratio of 0.6–1.0 dB, and horizontal axial ratio of 0.4–5.9 dB. The proposed antenna has a dimension of 0.48 × 0.48 × 0.25 λ at the center frequency of 1.39 GHz. The proposed antenna can also operate as an LHCP antenna for L-band satellite phone communication at 1.525–1.661 GHz. Full article

The growing need for lightweight, customizable electromagnetic wave absorbers with weather resistance in aerospace and electromagnetic compatibility applications motivates this study, which addresses the limitations of conventional materials in simultaneously achieving structural efficiency, broadband absorption, and environmental durability. We propose a fused deposition modeling (FDM)-based approach for fabricating lightweight wave-absorbing structures using acrylonitrile-styrene-acrylate (ASA)/multi-walled carbon nanotube (MWCNT) composites. Results demonstrate that CST Studio Suite simulations reveal a minimum reflection loss of −18.16 dB and an effective absorption bandwidth (RL < −10 dB) of 3.75 GHz for the 2 mm-thick composite plate when the MWCNT content is 2%. Through FDM fabrication and structural optimization, significant performance enhancements are achieved: The gradient honeycomb design with larger dimensions achieved an effective absorption bandwidth of 6.56 GHz and a minimum reflection loss of −32.60 dB. Meanwhile, the stacked stake structure exhibited a broader effective absorption bandwidth of 10.58 GHz, with its lowest reflection loss reaching −22.82 dB. This research provides innovative approaches for developing and manufacturing tailored lightweight electromagnetic wave-absorbing structures, which could be valuable for aerospace stealth technology and electromagnetic compatibility solutions. Full article

The paper describes the simulation of energy absorption in polymer micro-composites that include dielectric inserts (commercial Al₂O₃ and TiO₂ particles, with three particle sizes of 1, 5 and 25 µm, respectively). The investigated frequency spectrum, mainly from 0.001 to 100 GHz, is designed for various uses as substrates in electronic technologies. The electromagnetic simulation software chosen was CST Studio Suite, which evaluates the power loss at different frequencies, playing a crucial role in creating the ideal structure of these substrates. The effective limits of the electromagnetic simulation are specified. It is shown that a considerable increase in absorption occurs, by a factor of 12 to 120, depending on the dielectric material used for the inserts and the mass ratio applied in the insertion technique. Dielectrics with high permittivity provide higher absorption, but also create a nonuniform field distribution within the material, resulting in a high peak-to-average absorption ratio. In scenarios where this behavior is intolerable, the technology must be carefully tuned to improve the consistency of the insertions in the substrate material. The final outcomes of the simulations indicated that for creating new substrates for flexible electronics, polyethylene composites with TiO₂ insertions are suggested, particularly at lower concentrations of up to 7% and with a larger radius, such as 25 μm, which could offer significant economic advantages considering that the current concept advises the use of costly particles ranging from nanoscale particles to those 1 μm in size and a composition exceeding 10%. Full article

The generation of high-quality mid-infrared free-electron laser (MIR-FEL) radiation depends critically on precise control of electron beam parameters, including energy, energy spread, transverse emittance, bunch charge, and bunch length. At the PBP-CMU Electron Linac Laboratory (PCELL), effective beam diagnostics are essential for optimizing FEL performance. However, dedicated systems for direct measurement of transverse emittance and bunch length at the undulator entrance have been lacking. This paper addresses this gap by presenting the design, simulation, and analysis of diagnostic stations for accurate characterization of these parameters. A two-quadrupole emittance measurement system was developed, enabling independent control of beam-focusing in both transverse planes. An analytical model was formulated specifically for this configuration to enhance emittance reconstruction accuracy. Systematic error analysis was conducted using ASTRA beam dynamics simulations, incorporating 3D field maps from CST Studio Suite and fully including space-charge effects. Results show that transverse emittance values as low as 0.15 mm·mrad can be measured with less than 20% error when the initial RMS beam size is under 2 mm. Additionally, quadrupole misalignment effects were quantified, showing that alignment within ±0.95 mm limits systematic errors to below 33.3%. For bunch length measurements, a transition radiation (TR) station coupled with a Michelson interferometer was designed. Spectral and interferometric simulations reveal that transverse beam size and beam splitter properties significantly affect measurement accuracy. A 6% error due to transverse size was identified, while Kapton beam splitters introduced additional systematic distortions. In contrast, a 6 mm-thick silicon beam splitter enabled accurate, correction-free measurements. The finite size of the radiator was also found to suppress low-frequency components, resulting in up to 10.6% underestimation of bunch length. This work provides a practical and comprehensive diagnostic framework that accounts for multiple error sources in both transverse emittance and bunch length measurements. These findings contribute valuable insight for the beam diagnostics community and support improved control of beam quality in MIR FEL systems. Full article
